USB C to DisplayPort Adapter with USB Power
Delivery - 4K 60Hz
Product ID: CDP2DPUCP
This USB-C™ to DisplayPort adapter lets you connect your laptop or MacBook with USB Type-C™ to a
DisplayPort monitor. The video adapter features USB Power Delivery, which enables you to power your
laptop while you're outputting video to a DisplayPort display.
USB Type-C is a universal connectivity standard that combines all of your essential functions into one
dynamic port. This adapter works with USB-C devices that pass a DisplayPort video signal, such as the
MacBook and Chromebook Pixel™. It's also compatible with Thunderbolt™ 3 ports.
Charges your laptop
Unlike some video adapters that take up one of your laptop’s USB-C ports to output video, this video
adapter features an additional USB-C charge port that supports USB Power Delivery up to 60 watts. This
means you can charge your laptop and output video using a single port, by simply connecting the laptop’s
power adapter to the adapter's USB-C port. It’s the perfect solution for laptops that have a limited
number of USB-C ports.
www.startech.com
1 800 265 1844
Promotes portability
This USB Type-C video adapter maximizes portability with a lightweight, small-footprint design. It’s the
perfect accessory to carry with your MacBook or other USB-C computer, fitting easily into your laptop bag
or carrying case. Its ultra-portable design makes this adapter perfect for BYOD (Bring Your Own Device)
applications at the office.
Connects easily
This adapter lets you utilize the versatile USB Type-C port on your portable device. USB Type-C is a
reversible connector, so no matter how you plug it in, the adapter will always connect. This saves you the
hassle and embarrassment of struggling with your device when you're trying to deliver a presentation or
sharing information.
Maintains astonishing picture quality
At four times the resolution of high-definition 1080p, you’ll be amazed at the picture quality of a 4K
monitor or television. The adapter lets you harness the video capabilities that are built into your USB
Type-C connection to deliver the astonishing quality of Ultra HD to your 4K display. 4K resolution gives
you additional screen space to simplify your approach to detailed work such as editing video and viewing
large spreadsheets.
Even if you're not running 4K, the adapter supports high-definition 1080p and lower resolutions, which
gives you peace of mind in knowing that this adapter will work with any DP display you need to connect
to.
The CDP2DPUCP is backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Charge your USB Type-C laptop and output video using the same
USB-C port
• Carry the adapter with you when you travel, and connect to any DVI
monitor or projector
• Connect to BYOD (Bring Your Own Device) and CYOD (Choose Your
Own Device) workstations at your office
• Run resource-demanding applications on 4K displays at 60Hz
Features
• Charge your laptop and output HDMI video using the same USB-C
port, with USB Power Delivery
• Hassle-free connections with the reversible USB-C connector
• Astonishing picture quality with support for UHD video resolutions up
to 4K @ 60Hz
• Maximum portability with a small footprint and lightweight design
• Thunderbolt 3 port compatible
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Adapter Style Adapters
Audio No
Chipset ID Parade Tech - PS171
Via Lab - VL100
Converter Type Adapters
Output Signal DisplayPort
Ports 1
Performance Audio Specifications 7.1 surround sound
Maximum Digital Resolutions 3840 x 2160 @ 60Hz
Supported Resolutions 3840 x 2160 @ 60Hz
2560 x 1600
2048 x 1280
1920 x 1200
1920 x 1080
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Wide Screen Supported Yes
Connector(s) Connector A 1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B 1 - HDMI (19 pin) Female Output
Power Power Delivery 60W
Environmental Humidity 0~90% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Physical
Characteristics
Cable Length 3.9 in [100 mm]
Color Black
Enclosure Type Plastic
Product Height 0.5 in [13 mm]
Product Length 2 in [50 mm]
Product Weight 0.8 oz [24 g]
Product Width 1.3 in [33 mm]
www.startech.com
1 800 265 1844
Packaging
Information
Shipping (Package) Weight 0.2 lb [0.1 kg]
What's in the Box Included in Package 1 - USB-C to DisplayPort adapter
Product appearance and specifications are subject to change without notice.
