USB C to DisplayPort Adapter - 8K/5K/4K USB Type C to DP 1.4 Alt Mode Video Converter HBR3/DSC/HDR - 8K 60Hz Thunderbolt 3 Compatible DisplayPort Monitor Display Adapter
Product ID: CDP2DP14B
This USB-C to DisplayPort adapter lets you connect your USB Type-C or Thunderbolt 3 device to a DisplayPort
monitor or display, providing you with a convenient, high-performance solution. The adapter supports High Dynamic
Range (HDR) and provides sharper images with enhanced video.
Supporting four times the resolution of 4K, this 8K DisplayPort 1.4 adapter delivers the stunning quality of UHD at
resolutions up to 76804320, and also features HBR3 functionality, providing a bandwidth of up to 32.4Gbps. With
HDR support, you can enjoy lifelike images with increased contrast, brightness and colors and greater luminosity than
standard digital imaging.
With cutting-edge picture quality, this adapter is ideal for:
• Displaying crisp digital signage walls
• Creating eye-catching visuals for photography and videography
• Streaming high-resolution, life-like content
The DisplayPort dongle is also backward compatible with 4K and 1080p displays, which makes it a great accessory
for home, office or other work environments, while future-proofing for 8K implementation.
This lightweight display adapter is highly portable, with a small-footprint design. It's the perfect accessory for your
MacBook, Microsoft Surface Book or other USB-C (or Thunderbolt 3) device, fitting perfectly into your carrying case.
To ensure easy operation, this USB C to DisplayPort adapter supports plug-and-play installation, removing the need
for additional software or drivers.
CDP2DP14B is backed by a 3-year StarTech.com warranty and free lifetime technical support.
Note:
• Your USB-C device must support DP Alt Mode to work with this adapter.
• To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4.
• This product will not work with the Samsung S8 smartphone. For hassle-free compatibility with the S8 we
recommend using CDP2DP.
Certifications, Reports and Compatibility
Applications
• Stream 8K video to a DisplayPort 1.4 monitor, projector or display
• Ultimate accessory for early adopters of 8K technology
• Deliver eye-catching presentations while you’re on the go
• Connect USB-C devices to HDR capable 8K displays
Hardware
Warranty
3 Years
AV Input
USB-C
Ports
1
AV Output
DisplayPort - 1.4
Chipset ID
STM32F072
Performance
Maximum Cable Distance
To Display
16.4 ft [5 m]
Video Revision
DisplayPort 1.4
Supported Resolutions
DisplayPort: 7680x4320 (8K) / 60Hz
Wide Screen Supported
Yes
Bandwidth
HBR3
Audio Specifications
DisplayPort - 7.1 Channel Audio
Connector(s)
• Perfect for creative professionals
Features
• HIGH PERFORMANCE: USB-C to DisplayPort 1.4 (32.4Gbps) adapter compatible w/ HDR/DisplayHDR, HBR3,
Display Stream Compression (DSC), HDCP 2.2/1.4; 8K 60Hz (7680x4320), 5K 60Hz, 4K 120Hz & 1080p
• EXPERIENCE 8K: USB C to DisplayPort adapter was tested with 8K monitors, displays & compliance test
hardware/software for optimal performance & color depth for high res imaging & content creators
• TESTED & VERIFIED: With USB-C DP Alt Mode & Thunderbolt 3 devices like Lenovo ThinkPad X1
Carbon/Extreme, Dell XPS, HP EliteBook/ZBook, TB3 MacBook Pro 13 & 16/Air, iPad Pro, Surface Laptop 3/Pro 7
• HIGH BUILD QUALITY: Robust & reliable USB Type C to DP adapter dongle w/ Level 4 Air/Contact ESD
immunity/protection and EMI shielding for consistent, uninterrupted performance / FCC certified
• COMPATIBILITY: This USB-C to DisplayPort video converter requires no software/drivers & is backwards
compatible with DisplayPort 1.2; Works w/ Windows, MacOS, Linux, iPadOS, Chrome OS, Android
Connector A
USB-C (24 pin) DisplayPort Alt Mode
Connector B
DisplayPort (20 pin)
Special Notes /
Requirements
System and Cable
Requirements
Your USB-C port must support DisplayPort over USB-C (DP Alt mode)
in order to work with this adapter.
To achieve 8K resolutions, your source and your destination must
support DisplayPort 1.4.
Note
This product will not work with the Samsung S8 smartphone. For
hassle-free compatibility with the S8 we recommend using CDP2DP.
Environmental
Operating Temperature
5C to 35C (41F to 95F)
Storage Temperature
25C
Humidity
30%-60%
Physical
Characteristics
Color
Black
Material
Plastic
Product Length
0.9 in [23.5 mm]
Product Width
2.4 in [60.0 mm]
Product Height
0.6 in [15.0 mm]
Weight of Product
1.2 oz [34.0 g]
Packaging
Information
Package Length
8.7 in [22.0 cm]
Package Width
7.9 in [20.0 cm]
Package Height
0.4 in [10.0 mm]
Shipping (Package)
Weight
1.6 oz [44 g]
What's in the
Box
Included in Package
USB-C to DisplayPort Adapter
*Product appearance and specifications are subject to change without notice.
