Startech CDP2DP141MB Product Data Sheet

3.3ft/1m USB C to DisplayPort 1.4 Cable - 8K/5K/4K USB Type-C to DP 1.4 Alt Mode Video Adapter
Converter - HBR3/HDR/DSC - 8K 60Hz DP Monitor Cable - USB-C/Thunderbolt 3

Product ID: CDP2DP141MB

This USB-C to DisplayPort 1.4 cable lets you connect your USB Type-C device to a DisplayPort monitor with just one
cable, providing you with a convenient, clutter-free solution.

Supporting four times the resolution of 4K, this 8K DP 1.4 adapter cable delivers the stunning quality of UHD at
resolutions up to 76804320, and also features HBR3 functionality, providing a bandwidth of up to 32.4Gbps.

With cutting-edge picture quality, this cable is ideal for:

• Displaying crisp digital signage walls

• Creating eye-catching visuals for photography and videography

The USB-C to DP cable is backward compatible with 4K and 1080p displays, which makes it a great accessory for
home, office or other work environments, while future-proofing for 8K implementation.

At 3.3 ft. (1 m) in length, this DisplayPort adapter cable delivers a compact connection that eliminates excess cabling,
ensuring a tidy installation. For installations requiring a longer length, we also offer a 6 ft. (1.8 m) DisplayPort cable,
enabling you to customize your connection needs.

To ensure easy operation, this DisplayPort converter cable supports plug-and-play installation, removing the need for
additional software or drivers.

CDP2DP141MB is backed by a 3-year StarTech.com warranty and free lifetime technical support.

Note:

• Your USB-C device must support DP Alt Mode to work with this adapter cable.

• To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4.

Certifications, Reports and Compatibility

Hardware

Warranty

3 Years

Active or Passive Adapter

Active

AV Input

USB-C

Ports

1

AV Output

DisplayPort - 1.4

Chipset ID

STM32F072CBY6TR

Performance

Video Revision

DisplayPort 1.4
Supported Resolutions

DisplayPort: 7680x4320 (8K) / 60Hz

Applications

• Stream 8K video to a DisplayPort 1.4 screen or monitor

• Ultimate accessory for early adopters of 8K technology

• Deliver eye-catching presentations while you’re on the go

• Perfect for creative professionals

Features

• HIGH PERFORMANCE: USB-C to DisplayPort 1.4 (32.4Gbps) adapter cable compatible w/ HDR/DisplayHDR,
HBR3, Display Stream Compression (DSC), HDCP 2.2/1.4; 8K 60Hz (7680x4320), 5K 60Hz, 4K 120Hz & 1080p

• EXPERIENCE 8K: USB C to DisplayPort 1.4 cable was tested w/ 8K monitors, displays & compliance test
hardware/software for optimal performance & color depth for high res imaging & content creators

• INTEGRATED VIDEO ADAPTER CABLE: This 3.3'/1m USB-C to DP cable minimizes signal loss & potential failure
points w/ a latching DP connector, Level 4 Air/Contact ESD immunity/protection & EMI shielding

• TESTED & VERIFIED: With USB-C DP Alt Mode & Thunderbolt 3 devices like Lenovo ThinkPad X1
Carbon/Extreme, Dell XPS, HP EliteBook/ZBook, TB3 MacBook Pro 13 and 16/Air, iPad Pro, Surface Laptop 3/Pro 7

• COMPATIBILITY: This USB Type-C to DisplayPort converter cable requires no software/drivers & is backward
compatible with DisplayPort 1.2; works w/Windows, MacOS, Linux, iPadOS, Chrome OS, Android
