Vented 1U Rack Shelf - 7 in. Deep
Product ID: CABSHELF1U7V
This 1U rack shelf lets you add 7 in. of flat storage space to any EIA-310 compliant server rack or cabinet.
The shelf is vented to improve air flow and help lower temperatures in your rack.
Ensure your equipment is secure
The durable fixed-rack shelf can hold up to 20 kg (44 lbs.) of equipment and is constructed using SPCC
commercial-grade cold-rolled steel.
Make the most of your available space
The 1U cantilever shelf lets you optimize your working space by giving you the ability to mount equipment
to your rack instead of taking up desk or floor space. It’s perfect for your SOHO (small office, home office)
environment, server room or any other location with limited space available.
www.startech.com
1 800 265 1844
Customize your setup
You can install the 1U vented rack shelf in your rack at any height, giving you a stable surface for placing
equipment that's un-mountable or storing your tools.
The CABSHELF1U7V is backed by a StarTech.com lifetime warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Supply additional storage space for mission-critical hardware and
non-rackmount equipment
Features
• Improve airflow in your cabinet or rack with a vented shelf
• Ensure your equipment or tools are secure with heavy-duty steel
construction
• Save space in your office or server room by placing non-rackmount
IT or AV equipment on your rack
• Hassle-free compatibility with EIA-310 compliance
• Installs into 1U of rack space
• 7 in. shelf
• EIA-310 compliant
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Frame Type Steel
Mounting Options Front Mount (Front Only)
U Height 1U
Performance Weight Capacity 44.2 lb [20 kg]
Physical
Characteristics
Color Black
Enclosure Type Steel
External Depth 7 in [177.8 mm]
External Height 1.7 in [44.5 mm]
External Width 19 in [482.6 mm]
Product Height 1.7 in [44.5 mm]
Product Length 7 in [177.8 mm]
Product Width 19 in [482.6 mm]
Packaging
Information
Shipping (Package) Weight 7.2 lb [3.3 kg]
What's in the Box Included in Package 1 - 1U fixed shelf
4 - cage nuts
4 - mounting screws
Product appearance and specifications are subject to change without notice.
