Quad-Monitor Mount - Full Motion - Premium
Product ID: ARMQUADPS
Create a highly productive ergonomic workspace with this premium quad monitor mount, supporting
four monitors up to 27" each. Four articulating monitor arms feature dual-swivel action, providing a wide
range of motion side to side. The attractive silver finish enhances the aesthetics of your workspace.
Enjoy a Wide Range of Motion with Four Displays
The full motion monitor mount lets you maximize your productivity and work in comfort. Each of
the four articulating monitor arms extends a full 16.5” (420 mm) and offer a wide range of motion on
several axes. Adjust the position of each screen effortlessly as you work.
Sleek and Stable Aluminum Design
Made of robust aluminum, the four-monitor setup provides stable support
for VESA compatible monitors (75x75, 100x100) with a weight capacity of up to 24.8 lb. (11.25 kg) per
display. The cable-management channel helps to keep your workstation neat and tidy.
www.startech.com
1 800 265 1844
Adjust your Viewing Angle
Share your screen with ease. The four arm monitor mount offers a full +180-degree / -180-degree pan, to
move your screen left or right. It tilts freely +90 / -15 degrees to adjust the angle up or down. Rotate your
screens for landscape or portrait viewing.
Height Adjustment
Work in comfort. This height adjustable monitor mount lets you raise or lower the monitor arms along
the 708 mm (27.9”) pole.
Tool-less Assembly
The fully assembled desk clamp and pole, plus quick slide-and-click connections, ensure easy assembly.
It also saves time when setting up multiple units. The four screen mount gives you the option of desk clamp
or grommet hole mounting (hardware included).
The TAA compliant ARMQUADPS is backed by a StarTech.com 10-year warranty and free lifetime technical
support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Mount four displays to the side of your desk or table in commercial,
industrial or office settings
• Grommet mount your displays for four-screen access in a media
room
• Rotate displays to portrait orientation for web design and coding
Features
• Enhance productivity and create a versatile four-monitor setup for
monitors up to 27"
• Four articulating monitor arms provide a wide range of motion, plus
height adjustment along the pole
• Easy tool-less assembly with fully assembled desk clamp and pole,
plus quick slide-and-click connections
• Adjust your viewing angle with tilt, pan and rotation
• Robust and stable aluminum design supports VESA mount displays
(75x75, 100x100) with maximum weight of 24.8 lb. (11.25 kg) per
display
www.startech.com
1 800 265 1844
Warranty 10 Years
Hardware # of Displays Supported 4
Articulating Yes
Cable Management Yes
Mounting Options Desk & Grommet Clamp
Mounting Surface Thickness Desk Clamp: Table Thickness 0.78 - 2.36 in. (20 - 60 mm)
Grommet Clamp: Table Thickness 0.78 - 2.36 in. (20 - 60
mm)
Grommet Mount Hole Size: 0.39 - 2.36 in. (10 - 60 mm)
VESA Hole Pattern(s) 75x75 mm
100x100 mm
Performance Display Rotation 360°
Display Swivel +180° / -180°
Display Tilt +90° / -15°
Height Adjustment Yes
Maximum Arm Extension 16.5 in [420 mm]
Maximum Arm Span 37 in [940 mm]
Maximum Display Size 27in
Minimum Display Size 13"
Weight Capacity (Per Display) 24.9 lb [11.3 kg]
Physical
Characteristics
Color Silver
Material Aluminum
Product Height 35.8 in [910 mm]
Product Length 16.5 in [420 mm]
Product Width 37 in [940 mm]
Weight of Product 335.3 oz [9500 g]
Packaging
Information
Package Height 13.6 in [345 mm]
Package Length 34.8 in [885 mm]
Package Width 10.6 in [270 mm]
Shipping (Package) Weight 28.1 lb [12.7 kg]
What's in the Box Included in Package 1 - Pole Assembly
2 - Shoulders
www.startech.com
1 800 265 1844
8 - Swivel Arms
4 - VESA Mounts
1 - Upper Desk Clamp
1 - Lower Desk Clamp
1 - Grommet Adapter Plate
1 - EVA Foam Pad
1 - Grommet Clamping Plate
4 - Cable Management Clips
16 - VESA Screws
4 - M3 Hex Keys
10 - M5 x 14 mm Hex Screws
1 - User Manual
Product appearance and specifications are subject to change without notice.
