Single-Monitor Desk Mount - Height Adjustable Steel
Product ID: ARMPIVOT
Save space and work in greater comfort with this
monitor desk mount. The simple and stylish
monitor pole lets you mount a single VESA mount
monitor (75x75, 100x100) above your desk or
table, and adjust the position of your display for
ideal viewing.
www.startech.com
1 800 265 1844
Create an Ergonomic Work Space
With the computer screen mount, you can suspend your display on a support post above the desk surface
and adjust your display height, position and viewing angles easily for an ergonomic work environment.
The display mount gives you the added benefit of reclaiming valuable workspace on your desk. The steel
single-monitor mount securely supports displays up to 34", with a maximum weight of 30.9 lb. (14 kg).
Easy Height Adjustment Along the Pole
The height adjustable monitor arm features an 11.89" (302mm) tall support post, so you can adjust the
height of your monitor along the pole.
Adjust your Screen Position
Enjoy optimum viewing with easy tilt adjustment. The VESA mount can be rotated 360 degrees around
the support pole to adjust your screen position. For viewing longer pages or blocks of code without
scrolling, the monitor arm also supports landscape to portrait display rotation.
Steel Construction
The display mount is made of steel for long-lasting performance.
Easy and Flexible Installation
The desk clamp monitor mount is easy to install. For added installation flexibility, the included mounting
hardware can either clamp to the side of your desk, or mount through a grommet hole. The display mount
integrates a cable management hook to keep things neat.
The TAA compliant ARMPIVOT is backed by a StarTech.com 10-year warranty and free, lifetime technical
support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Mount a display to a desk, table or counter to save space in
commercial environments Create an ergonomic workspace in office
environments Rotate your display from landscape to portrait position
for web design or coding
• Create an ergonomic workspace in office environments
• Rotate your display from landscape to portrait position for web
design or coding
Features
• Mount a VESA (75x75, 100x100) compatible display 12" to 34", flat
screen, curved or ultrawide, with a max weight of 30.9 lb. (14 kg)
• Landscape-to-portrait display rotation (for use in portrait position,
the mount supports ultrawide displays with max width of 17.8"/45.2
cm).
• Adjustable monitor arm with several position/viewing angle
adjustments
• Tilts +90/-15 degrees for optimal viewing
• 360° rotation around the support post
www.startech.com
1 800 265 1844
Warranty 10 Years
Hardware # of Displays Supported 1
Articulating No
Mounting Options Desk & Grommet Clamp
Mounting Surface Thickness Desk Clamp: Table Thickness 0.78 - 3.93 in. (20 - 100 mm)
Grommet Clamp: Table Thickness 0.78 - 1.96 in. (20 - 50
mm)
Grommet Mount Hole Size: 0.39 - 2.36 in. (10 - 60 mm)
VESA Hole Pattern(s) 75x75 mm
100x100 mm
Wallmountable No
Performance Display Rotation 360°
Display Tilt +90° / -15°
Fits Curved Display Yes
Fits UltraWide Displays Yes
Height Adjustment Yes
Maximum Display Size 34"
Swivel / Pivot 360° around the support post
Weight Capacity (Per Display) 30.9 lb [14 kg]
Special Notes /
Requirements
Note This mount supports monitors up to 34”, including flat
screen, curved and ultrawide displays, with a max weight of
30.9 lb. (14 kg). If you choose to use an ultrawide display in
portrait position, the mount supports ultrawide displays with
a max width of 20" (50.8 cm).
Physical
Characteristics
Color Silver
Material Steel and Plastic
Product Height 0 in [0 mm]
Product Length 0 in [0 mm]
Product Width 0 in [0 mm]
Weight of Product 4.4 lb [2 kg]
Packaging
Information
Package Height 5.2 in [13.2 cm]
Package Length 21.6 in [54.8 cm]
Package Width 5.7 in [14.5 cm]
www.startech.com
1 800 265 1844
Shipping (Package) Weight 5.7 lb [2.6 kg]
What's in the Box Included in Package 1 - Support Post
1 - Monitor Mount
1 - Large C Clamp
1 - Small C Clamp
1 - Hand Screw
1 - Pressure Plate
4 - Thumb Screws
4 - M6x12mm Phillips Screws
4 - M5x14mm Hex Screws
1 - M4x15mm Phillips Screw
1 - Male Round Washer
1 - Female Round Washer
1 - Cable Clip
1 - EVA Cushion
1 - M3 (2.5mm) Allen Wrench
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
