Cat5e Ethernet Patch Cable with Snagless RJ45
Connectors - 5 m, Green
Product ID: 45PAT5MGN
This Cat5e patch cable delivers reliable network connections, which ensures high-performance capability
for your demanding Ethernet applications.
Find the length and color you need
This 5-meter green network cable is perfect for use in network conduits and raceways. The cable is
intended for longer distance applications, such as running up a post or throughout the office from a hub to
a wall- jack.
For easier network installations, our Cat 5e cables are available in a wide variety of lengths and colors.
This ensures you have the right size of cable available when you need it and it lets you color code your
connections for a more organized setup.
www.startech.com
1 800 265 1844
Snagless RJ45 clips help protect your network connections
For trouble-free cable runs, this durable cable features snagless connectors that protect the RJ45 clips
during installation, making them less likely to snag or break.
The cable also features moulded boots which offer connector strain relief by stopping the RJ45 connector
termination points from bending at sharp angles. This reduces the risk of damage to the cable, which
could decrease network connectivity and performance.
100% copper for outstanding value
Get the highest value for your cable investment with our Cat5e Ethernet cables, each one manufactured
using high-quality copper conductors. They are carefully constructed and tested, to keep Near-End
Crosstalk (NEXT) well within acceptable limits.
24-gauge wire for high-performance network connection
Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-
Ethernet and 4K or 1080p video streaming, using cables that include 24 AWG copper.
50-micron gold connectors provide peak conductivity
You can rely on our RJ45 connectors to deliver optimum conductivity, while eliminating signal loss due to
oxidation or corrosion.
The 45PAT5MGN is backed by StarTech.com’s lifetime warranty for guaranteed reliability.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Designed for use with Fast Ethernet networks
• Connect between computers, hubs, switches, print servers and patch
panels
• Connects workstation to wall outlet
Features
• RJ45 connector-clip protectors eliminate cable snags and breaks
during installation
• Green PVC jacket for color coding your connections
• 5 meters in length for longer connections
• Moulded RJ45 connectors prevent cable damage and also provide
strain relief
• 50-micron gold-plated connectors for a clear signal
• High-quality 24 AWG copper wire
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Cable Jacket Type PVC - Polyvinyl Chloride
Cable Type Snagless
Fire Rating CM Rated
Number of Conductors 4 pair UTP
Performance Cable Rating CAT5e - 350 MHz
Connector(s) Connector A 1 - RJ-45 Male
Connector B 1 - RJ-45 Male
Physical
Characteristics
Cable Length 5 m [16.4 ft]
Color Green
Conductor Type Stranded Copper
Product Height 0.000
Product Length 5 m [16.4 ft]
Product Width 0.000
Weight of Product 175 g [6.2 oz]
Wire Gauge 24 AWG
Packaging
Information
Package Height 21 mm [0.8 in]
Package Length 33 cm [13 in]
Package Width 25.5 cm [10 in]
Shipping (Package) Weight 202 g [7.1 oz]
What's in the Box Included in Package 1 - Cat5e patch cable
Product appearance and specifications are subject to change without notice.
