Cat5e Ethernet Patch Cable with Snagless RJ45
Connectors - 0.5 m, White
Product ID: 45PAT50CMWH
This Cat5e patch cable delivers reliable network connections, which ensures high-performance capability
for your demanding Ethernet applications.
Find the length and color you need
This 0.5-meter white network cable is perfect for use in server closets, patch panels and with Ethernet
hubs. The cable is intended for short-distance applications such as point-to-point in-rack and across-rack
network switch and server connections.
For easier network installations, our Cat 5e cables are available in a wide variety of lengths and colors.
This ensures you have the right size of cable available when you need it and it lets you color code your
connections for a more organized setup.
Snagless RJ45 clips help protect your network connections
For trouble-free cable runs, this durable cable features snagless connectors that protect the RJ45 clips
during installation, making them less likely to snag or break.
www.startech.com
1 800 265 1844
The cable also features moulded boots which offer connector strain relief by stopping the RJ45 connector
termination points from bending at sharp angles. This reduces the risk of damage to the cable, which
could decrease network connectivity and performance.
100% copper for outstanding value
Get the highest value for your cable investment with our Cat5e Ethernet cables, each one manufactured
using high-quality copper conductors. They are carefully constructed and tested, to keep Near-End
Crosstalk (NEXT) well within acceptable limits.
24-gauge wire for high-performance network connection
Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-
Ethernet and 4K or 1080p video streaming, using cables that include 24 AWG copper.
50-micron gold connectors provide peak conductivity
You can rely on our RJ45 connectors to deliver optimum conductivity, while eliminating signal loss due to
oxidation or corrosion.
The 45PAT50CMWH is backed by StarTech.com’s lifetime warranty for guaranteed reliability.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Designed for use with Fast Ethernet networks
• Connect between computers, hubs, switches, print servers and patch
panels
• Connects workstation to wall outlet
Features
• RJ45 connector-clip protectors eliminate cable snags and breaks
during installation
• White PVC jacket for color coding your connections
• 50 cm in length for shorter connections, without the clutter of excess
cable
• Moulded RJ45 connectors prevent cable damage and also provide
strain relief
• 50-micron gold-plated connectors for a clear signal
• High-quality 24 AWG copper wire
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Cable Jacket Type PVC - Polyvinyl Chloride
Cable Type Snagless
Fire Rating CM Rated
Number of Conductors 4 pair UTP
Performance Cable Rating CAT5e - 350 MHz
Connector(s) Connector A 1 - RJ-45 Male
Connector B 1 - RJ-45 Male
Physical
Characteristics
Cable Length 0.5 m [1.6 ft]
Color White
Conductor Type Stranded Copper
Product Height 0.000
Product Length 0.5 m [1.6 ft]
Product Width 0.000
Weight of Product 23 g [0.8 oz]
Wire Gauge 24 AWG
Packaging
Information
Package Height 12 mm [0.5 in]
Package Length 22 cm [8.7 in]
Package Quantity 1
Package Width 20 cm [7.9 in]
Shipping (Package) Weight 32 g [1.1 oz]
What's in the Box Included in Package 1 - Cat5e patch cable
Product appearance and specifications are subject to change without notice.
