HP 453154-B21 Compatible SFP Transceiver
Module - 1000BASE-T
Product ID: 453154B21ST
The 453154B21ST is a TAA compliant HP 453154-B21 compatible copper transceiver module that has
been designed, programmed and tested to work with HP® brand switches and routers. It delivers
dependable 1 GbE connectivity over copper cable, for 1000BASE-T compliant networks, with a maximum
distance of up to 100 m (328 ft).
Technical Specifications:
• Maximum Data Transfer Rate: 1000 Mbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 805,386 hours
• Power Consumption: Less than 1.3 Watt
• Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing
network disruptions.
www.startech.com
1 800 265 1844
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime
multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP
cables, providing the convenience and reliability you need to ensure dependable network performance.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Replacing defective or damaged SFP modules in HP switches and
routers
• Expand your network to remote segments
Features
• 100% compatibility with HP 453154-B21 guaranteed
• StarTech.com SFP modules are backed by a lifetime warranty
• Uses a cost-effective cabling alternative to fiber-optic set ups
• Meets or exceeds OEM specifications and Multi-Source Agreement
(MSA) industry standards
• Low power consumption of less than 1.3 W
• Hot-swappable with fiber-optic modules
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Compatible Brand HP
Industry Standards IEEE 802.3ab 1000BASE-T
Performance Auto MDIX Yes
Compatible Networks 1000 Mbps (1 Gbps)
DDM No
Max Transfer Distance 100 m (328 ft)
Maximum Data Transfer Rate 1000 Mbps
MTBF 805,386 hours
Type Copper
Connector(s) Local Unit Connectors 1 - RJ-45 Female
Special Notes /
Requirements
System and Cable Requirements MSA or HP compliant SFP port
For use in 1 Gigabit networking equipment and media
converters
Power Power Consumption (In Watts) < 1.3 W
Environmental Humidity 5~95% RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Physical
Characteristics
Color Silver
Enclosure Type Aluminum
Product Height 0.6 in [15.7 mm]
Product Length 2.9 in [74.8 mm]
Product Weight 0.8 oz [24 g]
Product Width 0.6 in [15.1 mm]
Packaging
Information
Shipping (Package) Weight 2 oz [56 g]
What's in the Box Included in Package 1 - SFP transceiver
Product appearance and specifications are subject to change without notice.
www.startech.com
1 800 265 1844
