Dual M.2 NGFF SATA Adapter with RAID
StarTech ID: 25S22M2NGFFR
Boost your system performance by enhancing the capacity, speed and security of your data storage. This twodrive M.2 to SATA adapter lets you install two M.2 solid-state drives in a single 2.5” drive bay and configure a
powerful RAID array.
Build a RAID array to enhance system performance
The dual M.2 to SATA adapter supports multiple RAID modes (RAID 0, 1, BIG) helping you to achieve greater
SSD capacity or data redundancy, depending on your selected RAID mode. The SSD adapter also supports
non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used
independent of one another.
Maximize file transfer speeds
The dual SSD adapter lets you utilize the full potential of your SATA III controller. Using M.2 SSDs in place of a
platter drive reduces your data transfer bottlenecks and gives you file transfer speeds of up to 6 Gbps. M.2
SSDs also save you money by reducing your power consumption over regular platter drives.
The M.2 NGFF SATA RAID adapter also provides TRIM support to enhance the stability and performance of
your M.2 NGFF SSDs.
Get dependable drive protection
The M.2 to SATA adapter features an enclosed housing that helps protect your NGFF (Next Generation Form
Factor) SSD. The added protection gives you peace of mind when you are using your M.2 drives in applications
that require an added level of durability such as hot-swap drive bays, or external SATA docking stations.
The 25S22M2NGFFR is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Applications
Add data redundancy to your system, by adding a mirrored SSD (RAID 1)
Increase the storage capacity of your system by adding an additional SSD in a RAID array (RAID 0/BIG)
Turn two unused M.2 drives into a regular 2.5in SATA solid-state drive
Retrieve/backup data from an M.2 (NGFF) drive using a standard SATA computer
Use M.2 drives in any 2.5 in. SATA application
Features
Install two M.2 NGFF SSDs into a single 2.5” SATA bay and build a powerful RAID array
Supports RAID 0, RAID 1, spanning, or JBOD
Add M.2 SSD performance to any computer system by converting M.2 to SATA
Protect your M.2 (NGFF) SSDs in any 2.5in application with enclosed housing
Supports TRIM to help ensure stable performance of your M.2 SSDs
Supports SATA I/II/III (up to 6Gbps)
2.5in SATA form factor housing
Broad compatibility with support for the most common SATA M.2 SSDs (2230, 2242, 2260, 2280)
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Chipset ID ASMedia - ASM1092R
Compatible Drive Types (Type and Rate) M.2 (NGFF; B-Key)
Drive Installation Fixed
Drive Size 22m - M.2 NGFF
Interface SATA
Number of Drives 2
Supported Drive Height(s) 2230
Supported Drive Height(s) 2242
Supported Drive Height(s) 2260
Supported Drive Height(s) 2280
Maximum Data Transfer Rate 6Gbps
MTBF 500000
Port Multiplier Yes
RAID Yes
Supported RAID Modes RAID 0 (Striped Disks)
Supported RAID Modes RAID 1 (Mirrored Disks)
Supported RAID Modes JBOD - (Just a Bunch of Disks)
Supported RAID Modes BIG (Spanning or Concatenation)
Type and Rate SATA III (6 Gbps)
Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Female
Host Connectors 2 - M.2 (NGFF; B-Key) Male
OS Compatibility OS independent; No software or drivers required
LED Indicators 2 - Drive Error
Humidity 5% ~ 95% RH
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -10°C to 85°C (14°F to 185°F)
Color Black & Silver
Enclosure Type Steel and Plastic
Product Height 0.3 in [8 mm]
Product Length 3.9 in [99 mm]
Product Weight 1.9 oz [55 g]
Product Width 2.8 in [70 mm]
www.startech.com
1 800 265 1844
Shipping (Package) Weight 4.2 oz [118 g]
Included in Package 1 - dual M.2 NGFF SATA RAID adapter
Included in Package 2 - M.2 drive mount hardware
Included in Package 4 - screws
Included in Package 1 - mini screwdriver
Included in Package 1 - quick start guide
