Starmobile KNIGHT Quick Manual

KNIGHT

Quick Guide

TABLE OF CONTENTS

1. Your Phone

1.1. Phone Overview

1.2. Charging your Battery

1.3. Connecting to a Network

1.3.1. Inserting your SIM cards

1.3.2. Inserting your Memory Card

1.3.3.Turning Power On and Off

2. Getting Started

2.1. Setting up your Phone

2.2. Screen Control

2.3. Changing the Wallpaper

2.4. Touch & Type

2.5. Using the Lock Screen

2.6. Searching the Phone & the Web

3. Troubleshooting

4. Safety & Notice

1
1
3
3
3
4
4
5
5
6
7
8
8

9
10
13

KNIGHT

About Android

Enjoy a smarter mobile experience with the Android Operating
System. Featuring all Google apps plus more than 800,000 apps,
songs, books, movies and games ready for download on the Play
Store, the Android mobile platform extends your mobile device’s
functionality—keeping you connected, entertained and informed.

Source: Android Website (www.android.com)

What’s new with Android 4.2 “Jelly Bean”?

Share what’s on
your phone on
the big screen

Daydream

Expandable,
actionable
notications

Android 4.2 allows devices to enable
wireless display. You can share movies,
YouTube videos, and anything that’s on
your screen on an HDTV. Just connect a
wireless display adapter to any
HDMI-enabled TV to mirror what’s on
your screen quickly and easily.

Daydream lets your Android device display
useful and delightful information when
idle or docked. Show off your photo
albums, get the latest news from Google
Currents, and more.

Android has always put you in control
when it comes to staying notied and
connected. Just swipe down from the top
of the screen to see all your notications in
one place. Late for a meeting or missed a
call? Take action in an instant directly from
the notications shade.

1

KNIGHT

Widgets work
like magic

Amazing Photo
Sphere camera

A smarter
keyboard, now
with Gesture
Typing

Improved
Dictionaries

With Jelly Bean it's now even easier to
personalize your home screen. As you place
widgets on the screen, everything else
automatically moves to make room. When
they're too big, widgets resize on their
own. Interacting with your favorite apps
and customizing your home screen has
never been easier.

Up, down and all around you, it’s like no
camera you’ve ever seen. With Android 4.2,
snap pictures in every direction that come
together into incredible, immersive photo
spheres that put you right inside the scene.
View your photo spheres right on your
phone, share them on Google+ with your
friends and family, or even add them to
Google Maps for the world to see.

Writing messages on the go is easier than
ever with Gesture Typing – just glide your
nger over the letters you want to type,
and lift after each word. You don’t have to
worry about spaces because they’re added
automatically for you.

The keyboard can anticipate and predict
the next word, so you can nish entire
sentences just by selecting suggested
words. Power through your messages like
never before.

Android's dictionaries are now more
accurate and relevant. With improved
speech-to-text capabilities, voice typing
on Android is even better. It works even

KNIGHT

when you don't have a data connection, so
you can type with your voice everywhere
you go.

Magnication

Talkback

Full Screen
Viewnder

Source: www.android.com

Zoom in on your screen by triple tapping on
the touch panel. While on magnication mode,
you can pan by dragging two ngers across the
screen and adjust zoom levels by pinching your
ngers. This feature works everywhere except
on the keyboard and on the navigation bar.

Provides spoken feedback to help blind and
low vision users. Talkback describes what to
touch, select, and deactivate.

Use the entire screen as a widescreen viewnder
when using the camera. (Note: may reduce
maximum resolution)

KNIGHT

1. Your Phone

Thank you for choosing the Starmobile KNIGHT. This Quick Guide
contains important and useful information regarding the use and
operation of this mobile device.

Note: The contents of this Quick Guide is protected by copyright laws and
regulations. You may not by any means, copy any part of this manual in any
form or through any cable or wireless network for transmission, or have this
Quick Guide translated into any language without permission from the
company.

1.1 Phone Overview

Volume

Keys

Earphone

Jack

Front

Camera

Power Key Rear Camera

Menu Key Home Key Charger/

1

Back Key Speaker

USB

KNIGHT

Volume Keys Press to adjust ringer volume,

Charger/USB Port Allows you to connect charger or

call volume, and media volume
during music and video playback.

USB cable for data exchange

Headset Port Allows you to plug in an earphone

Menu Key Opens a list of options available in

Home Key Touch to return to Home screen;

Back Key Touch to return to the previous

Power Lock Key Press and hold to open phone

the current screen or application

Press and hold to open a window
showing your most recently used
applications

screen or close the on-screen
keypad, dialog box, options menu,
or the Notication panel

options menu: Power Off, Reboot,
Screen Capture or Airplane Mode

2

KNIGHT

1.2 Charging your Battery

• Your Starmobile KNIGHT needs to be fully charged for rst

use.

• Make sure the unit is turned off Plug one end of the charger
into the USB/charging port then plug the other end into a
standard AC power outlet.

• Once connected, the battery icon will repeatedly ash at the
top right corner of the screen. If the mobile phone is charging
while powered off, a battery indicator will also appear on the
screen. If the mobile phone has been depleted of battery life,
it will take awhile before a charging indicator appears on
screen after it has been plugged to a power source.

• When charging is complete, disconnect the charger from both
the electrical outlet and the mobile phone.

When the battery level icon has stopped ashing, this means that the
battery is fully charged. This process usually takes 3 hours. It is normal
for the mobile phone and charger to become warm during charging.

ATTENTION:

• Charging must be performed in a well-ventilated area with a
temperature between -10°C and +45°C.

• Use only the Starmobile-supplied battery and charger with your
Starmobile KNIGHT. Using accessories of other manufacturers or
vendors with your Starmobile KNIGHT may invalidate any approval
or warranty applicable to the device. It may result in non-operation
of the mobile phone or lost of information.

• If the mobile phone automatically shuts down or indicates that
“Battery is low”, it is advisable to charge your battery. If the battery
has not been entirely used up before recharging, the charging time
will automatically decrease.

1.3 Connecting to a Network

1.3.1 Inserting your SIM cards

Your Starmobile KNIGHT allows use of two separate SIM cards
at the same time (1 standard SIM and Micro SIM).

3

KNIGHT

• To install, make sure that the unit is turned off.

• Slide in the SIM card with its gold chip facing downward.

Make sure the beveled edge of the SIM card is properly
aligned with the card slot. Once the SIM card is in place, put
in the battery and replace the cover.

1.3.2 Inserting your Memory Card
Your mobile phone supports micro SD cards up to 32GB.

• To install, make sure that the unit is turned off.

• Open the back casing gently Push the memory card tray to

open the latch

• When installing a micro SD card, ensure that its gold chip is

facing downward and that its beveled edge is properly
aligned with the card slot.

• Slide the card tray back into place to lock.

1.3.3 Turning Power On and Off

• Press and hold the Power key until the phone switches on.

• If you turn on the mobile phone without having inserted a

SIM card, the phone will display “Emergency call”. If a SIM
card has been inserted, the phone will automatically check if
the SIM is useable.

4

KNIGHT

2. Getting Started

2.1 Setting Up Your Phone

The rst time you turn on the phone, you'll see a Welcome screen.

• To choose a different language, go to Menu > Settings >
Personal > Language and input.

• To set up your phone, touch Start and follow the instructions.

A series of screens takes you through the setup process. If you already
have a Google or Gmail account, use your Gmail address and
password when asked. If you don't have Gmail or any other Google
Account, you may create one on www.gmail.com.

2.1.1 Why use a Google Account？

AGoogleAccountletsyouorganizeandaccessyourpersonal
informationfromanycomputerormobiledevice:

• Never lose your contacts again. When you sign into your
phone with a Google account, all the contacts you associate
with that account in the Contacts application are automati­ cally backed up. As a result, they're always accessible through
your Gmail account from any computer.

• Synchronize and back up everything. Whether you draft
an email, add a phone number, add an event to your
calendar, or take a photo, your work gets backed up
continuously by Google and synchronized with any computer
where you use the same Google Account.

• Access from anywhere. Check your latest calendar, email,
text messages, or social stream, wherever you are, no matter
what computer or mobile device you're using.

• Keep your information secure and available. Google
works round the clock to protect your personal data from
unauthorized access and to ensure that you get it when you
need it, wherever you need it.

• Use other Google services. Your Google Account also lets
you take full advantage of any other Google apps and
services that you may want to use, such as Gmail, Google

5

KNIGHT

Maps, Navigation, Play Store, YouTube, Google Talk,
Messaging, and many more.

2.2 Screen Control

Once you have nished setting up your phone, the Home screen
opens. At the bottom of the screen, you'll nd three Navigation
buttons that will always be available.

Icon Name Description

Opens the previous screen you were

Back

Home

working in, even if it was in a different
app. Once you back up to the Home
screen, you can’t go back any further in
your history.

Opens Home. If you're viewing a left or
right Home screen, this opens the
central Home screen.

Menu Pop-up menu options

The Favorites tray is located just above the Navigation buttons:

The app icons you keep in the tray remain visible on every Home
screen.

The All Apps icon in the center is permanent. Touch it to see all
your apps and widgets.

The middle of your Home screen can hold app and widget icons, plus
folders.

3 4

6

KNIGHT

• To open an app, folder, or widget, touch its icon.

• To see additional Home screens, swipe your nger quickly left or

right.

At the top of the screen, you'll see this display:

Status icons on the left tell you which apps have sent you
notications; for example, that a message has arrived, or it's time for a
meeting.

• To see your notications, swipe your nger down from the top

of the screen.

System icons on the right display the current wireless and network
connection strength, battery level, time, and more.

The Google Search option just below the status and system icons lets
you search within your phone or on the Internet.

2.3 Changing the Wallpaper
Wallpapers are images that take the place of the default background

for your Home screens. To customize your wallpaper:

• Touch & hold anywhere on a Home screen that's not occupied.
A list of options appears.

• Select a wallpaper source:

o Gallery: displays pictures that you've taken with your Camera
or downloaded to your device
o Video Wallpapers: displays selection of videos stored in your
phone. Select the Camera icon to capture and record a new
video.
o Live Wallpapers: displays a scrolling list of animated wallpapers
o Wallpapers: displays thumbnails of default images. Touch a
thumbnail to see a larger version.

7

45

KNIGHT

• For wallpapers selected from the Gallery, you will be asked to

crop out the desired portion of the image before setting it as
your wallpaper.

2.4 Touch & Type

Touch or tap to manipulate icons, buttons, menus, the onscreen
keyboard, and other items on the touchscreen. You can also change
the screen's orientation.

To select or activate something onscreen, touch it. To type something
such as a name, password, or search terms, just tap where you want
to type. A keyboard pops up that lets you type into the eld.

Other common gestures include:

• Touch & hold: Touch & hold an item on the screen by touching
it and not lifting your nger until an action occurs.

• Drag: Touch & hold an item for a moment and then, without
lifting your nger, move your nger on the screen until you reach
the target position. For example, you can drag to reposition
shortcuts on the Home screen.

• Swipe or slide: Quickly move your nger across the surface of
the screen, without pausing when you rst touch (so you don't
drag something instead). For example, you can slide a Home
screen left or right to view the other Home screens.

• Double-tap: Quickly tap a screen to zoom in. Double tap again
to zoom out.

• Pinch: When viewing maps, web pages or photos, place two
ngers on the touchscreen at once and pinch them together to
zoom out or spread them apart to zoom in.

• Rotate the screen: The orientation of the screen rotates with
the phone as you turn it from upright to its side and back again.
You can turn this feature on and off.

2.5 Using the Lock Screen

To protect personal information, you can adjust your phone's lock
settings:

• From the Home or All Apps screen, touch the Settings icon .

8

KNIGHT

• Scroll down and touch Security.

• Touch Screen lock.

• Touch the type of lock you'd like to use.

Once enabled, a lock screen display will show up whenever your
screen wakes up, prompting you to enter the pattern, PIN, or other
specied key.

While the screen is locked, you can respond to incoming calls in three
ways. Touch the white phone icon and slide over one of these icons:

Answer call Start talking to the caller.

Reject call Decline the call.

Send a message Opens a list of default text

2.6 Searching Your Phone & the Web

Google Search can help you nd anything you need on your phone or
the web:

• At the top of any Home screen, touch Google to type your search
term, or the Microphone button to make a voice command.

As you type, suggestions from Google web search will appear below
the Search box, and results from your phone (such as apps and
contacts) below that.

Touch a suggestion to search for it immediately, or touch its arrow just
to add the term to the search eld without starting to search.

To change the way Google searches on your phone or the web:

• Touch Google at the top of the screen.

• Touch the Menu key at the lower left corner of the screen.

• Select Settings.

• Choose either Searchable items or Google Search.

9

messages. Touch one to send it
to the caller immediately.

KNIGHT

3. Troubleshooting

Possible
Concerns

Poor
reception

Echo or
noise

Shortening
of the
standby
time

Cause

Using your mobile
phone in an area
with poor
reception such as
near tall buildings
or in a basement
where radio waves
cannot be
transmitted.

Using the your
mobile phone
during network
peak hours.

Distance from the
base station built
by the network is
too great.

Caused by poor
network relay.

Some calling areas
have poor lines.

Standby time is
related to the
network system.

When you cannot

How to Fix

Please move to an area with
a stronger signal or
temporarily turn off your
smartphone.

Try again at a less congested
time.

You can request for the
network service provider to
provide you with a service
area plan.

Hang up and redial. If the
relay is changed then the
line may be better.

Please temporarily turn off
your mobile phone, as you
are located in an area with
poor reception.

Please move to an area with

10

KNIGHT

Unable to
turn on the
phone

SIM card
malfunction

Unable to
connect
with the
network

get a signal, the
phone will continue
to transmit in order
to nd a base
station, thereby
consuming large
amounts of power
which will cause
the standby time
to decrease.

The battery is
empty.

SIM card is
damaged.

SIM card is not
properly inserted.

There is visible dirt
on the metal
surface of the
SIM card.

Expired SIM card

Outside the GSM
service area

Poor signal

a stronger signal or
temporarily turn off your
mobile phone.

Look at the remaining
electricity or recharge status
to conrm. Charge battery.

Contact your network
provider.

Conrm SIM card is
properly inserted.

Use a clean, dry cloth to
wipe off the metal contact
point of the SIM card.

Contact your network
provider.

Consult your network
provider regarding the
service area.

Please move to a place with
a stronger signal and try
again.

9

11

KNIGHT

Unable to
make a call

Incorrect PIN
number

Unable to
charge

Unable to
add new
phone
book
entries

Unable to
set certain
functions

function

function

Consecutively
entering the
wrong password
three times.

The battery or
charger is
damaged.

Recharging in an
environment of less

o

than -10 or higher

o

than 55

Poor contact with
the power outlet.

The storage space
of your phone
book is full.

Your network
provider does not
support this
function or you
have not applied
for it.

Cancel the call bar function.Using the call bar

Cancel the xed call setting.Using the xed dial

Contact your network
provider.

Immediately replace the
battery or charger.

Move out of the area and
try again.

Ensure that the plug is
properly connected

Delete some of the phone
number entries.

Contact your network
provider.

12

KNIGHT

Defective/
dead pixels
on my
device’s
screen

International
standards allow for
a maximum of 5
defective pixels per
1 million pixels (ISO
9241-302:2008).
As such, only units
with 6 or more
defective pixels per
1 million pixels are
qualied for repair
or replacement.

If your device has 4 or fewer
defective pixels per 1 million
pixels, third-party detection
and remedy apps are readily
available from Google Play.
Note: Starmobile shall not
be held liable for problems,
which may arise from using
said third-party apps.

4. Safety & Notice

This section contains important information pertaining to correct and
safe usage of your mobile phone. Read carefully before using your
device.

• Your Starmobile KNIGHT supports an “Airplane mode” function.
Set your phone to “Airplane mode” when boarding an
aircraft or completely switch it off. Using wireless devices in an
aircraft may be dangerous to the operation of the aircraft,
disrupt pilot-ground communications, and may be considered
illegal.

• Power off your device in all fuel, chemicals, or blasting areas.

Keep the device away from children.

• Observe local laws and regulations when using your Starmobile

KNIGHT. Do not talk on your mobile phone while driving. Use
hands-free accessories.

• When under poor driving conditions, park your vehicle before

making or answering a call.

• Switch off your mobile phone in the hospital or other areas that

prohibit the use of mobile devices. These may adversely affect
electronic equipment and medical devices, such as pacemakers,
hearing aids and other similar equipment.

13

KNIGHT

• Non-original accessories and components do not qualify for

warranty repair.

• Do not dismantle the device or accessories. Otherwise,

Starmobile will not be held liable for damages as the device and
accessories will not be covered by the warranty.
Please do not charge the smartphone before the battery is
installed. This may short-circuit the battery.

• Smartphones must be charged in a well-ventilated and cool

environment, and away from ammable and explosive materials.

• In order to prevent demagnetization, please keep your

smartphone away from all magnetic sources, such as disks, credit
card etc.

• Keep the device dry. Precipitation, humidity, and all types of

liquids or moisture can contain minerals that may corrode
electronic circuits. If your device does get wet, remove the
battery and contact a Starmobile authorized service center.

• Do not use the smartphone in very high or very low temperature

environments, or expose it to strong sunlight or high humidity.

• Do not use any kind of liquid, or wet cloth with strong detergent,

to clean the device.

• Your Starmobile KNIGHT comes with photo, video recording, and
sound recording functions. Please follow the relevant laws and
regulations for using these. Photo, video recording and sound
recording of certain places, people, or events without the
necessary authorization may violate laws and regulations.

• While using the network functions, please do not download les

suspected of having viruses. Do not install any photos and ring
tones that were downloaded from dubious sources. Starmobile
will not be held responsible for any erratic phone behavior arising
from these.

• Please dispose of batteries according to local regulations, and

recycle whenever possible. Do not dispose of your batteries like
common household waste.

STATEMENT: Starmobile reserves the right to revise the contents of this Quick
Guide without prior notice.

14
