Star Manufacturing International CSD-1_PB Installation And Operating Instructions Manual

Star
Manufacturing
International Inc.

10 Sunnen Drive
St. Louis, MO 63143

Installation

and
Operating
Instructions

Phone: [phone]
Fax: [phone]

SINGLE PERISTALTIC

CHEESE DISPENSER

MODEL CSD-1_PB

2M-Z3605 Rev. E 8/6/02

PRODUCT IDENTIFICATION

Star Mfg. International, Inc.
Single Peristaltic Cheese Dispenser, Model CSD-1_PB

SPECIFICATIONS:

Capacity: Two 6 pound bags
Electrical: 120V; 650 Watts; 60 Cycle; single phase
Dimensions: 9 9/16" W x 19 9/16" D x 27" H
Net Weight: 42 lbs.

2

CAUTION

This equipment is designed and sold for
commercial use only by personnel trained and
experienced in its operation and is not sold for
consumer use in and around the home nor for
use directly by the general public in food service
locations.

NOTE

Read this manual completely before attempting
installation.

INSTALLATION

This cheese dispenser is equipped for the voltage
and wattage indicated on the nameplate mounted
on the back of the unit, and is designed for use on
alternating current (AC) only.

CAUTION

Loading Product

1. Turn dispenser OFF.

2. Unhook the tension spring from the catch.

3. Slide the pump block away from the pump
head.

4. Insert the new bag into tray and route the tube
around the rollers.

(Note: Make sure hose is not twisted)

5. Place the end of the hose in the slot of the

bottom bracket.

6. Slide the pump block towards the pump head.

7. Hook the tension spring onto the catch.

8. Install the tube cover back onto the dispenser,

extending the tube through the cover. Leave
1/2" of the tube below the cover.

9. Dispense a small amount of product to insure

the tube is seated correctly, and the product is
flowing.

Operation Notes

The product should be preheated according to
the manufacturer’s instructions. The product
should be heated to 140°F before dispensing.

DO NOT CONNECT TO DIRECT
CURRENT (DC).

GENERAL OPERATING INSTRUCTIONS

This cheese dispenser is designed to be used with
a 9” x 14” poly bag with a 1 inch outlet fitment.
The peristaltic pump is designed to be used with
1/4 inch id. to 1/2 inch id. tubing with 1/16 inch
wall thickness.

The dispenser is designed with a preset non­adjustable thermostat. It is designed to maintain a
product temperature of 140°F to 160°F.

The thermometer reading will vary with the
heating cycle of the dispenser over a range of
20°F. The thermometer should read between
135°F and 180°F during normal dispenser
operation. Do not open the door during
operation because heat will escape resulting in
lower product temperature.

The pump will not function correctly if the
product is not at the correct temperature.

If the pump drips, or does not dispense
product, check to make sure the hose is
routed correctly, and that the spring is
latched onto the catch. Run the dispenser for
a short period of time.

The dispenser is designed to operate 24 hours a
day. Once the product is placed in the dispenser
it should not be removed until the pouch is
empty, or the holding period of the product has
expired.

3

To set portion:

1. Load preheated product pouch into dispenser

2. Dispense product until there is a steady flow

3. Dispense the product into a clean container,
and measure the product to verify the
dispensed amount.

4. Using a small screwdriver, turn the control
dial, located on the back of the unit, clockwise
for more product, and counter-clockwise for
less product.

5. Repeat steps 3 & 4 until the desired amount is
reached.

Note: This dispenser control is based on a time
setting. Variations in product temperature and
consistency will affect the dispensed amount. To
insure a consistent portion, use product that is at
the correct temperature (145°F to 160°).

Note: To increase the evacuation of thicker
products, open the dispenser and pull the
product towards the outlet fitment once or twice
during operation.

CHECKING PRODUCT TEMPERATURE

The machine should be plugged in and turned on
with product in the dispenser for a least 5 hours.

1. Dispense at least 3 inches of product into an

insulated cup.

2. Without hesitation, insert the thermometer to

the bottom of the cup and stir the product
gently with the stem of the thermometer.

3. Position the tip of the thermometer in the

center of the product mass.

4. The temperature should read between 140°F

and 165°F.

The pump mechanism should not need cleaning
during normal use. If product should spill onto the
pump head, it can be removed for easy cleaning.

To remove and clean the pump head:

1. Remove the bag according to the instructions

2. Unscrew the knob from the pump head

3. Remove the pump head

4. Slide the pump block out of the track

5. Clean the parts in a solution of mild soap and
water using a soft cloth

6. If needed the rollers can also be disassembled
for cleaning

7. Dry parts before reassembling

The spring can also be removed for cleaning by
removing the knob and retaining washer.

Note: When installing the pump head onto the
drive shaft, make sure the pump head is fully
seated onto the square end of the drive shaft
before installing the knob.

WARNING: The drive shaft and pump head
could be damaged if the pump head is
installed incorrectly.

MAINTENANCE AND REPAIRS

Contact the factory, a service representative or a
local service company for service or required
maintenance.

CLEANING INSTRUCTIONS

To clean the stainless steel body:

Stainless steel is corrosion resistant, but may
corrode if not cleaned properly. The dispenser
should be cleaned with a soft cloth with mild soap
and water. Do not use detergents, strong
abrasives, or metal scouring pads on the stainless
steel.

RETAIN THIS MANUAL FOR FUTURE REFERENCE
PART NO. 2M-Z3605 REV. E 8/6/02

4

Visit our Website at: www.star-mfg.com Email: [e-mail] For Fax-On-Demand Literature: [phone]

THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL

This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in
which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the
transportation company who delivered the item to you and initiate your claim with same. If this procedure is not followed, it may affect the warranty
status of the unit.

LIMITED EQUIPMENT WARRANTY

All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is
limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited
to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies. Models that are considered portable (see below)
should be taken to the closest Star service agency, transportation prepaid.

> Star will not assume any responsibility for loss of revenue.
> On all shipments outside the United States and Canada, see International Warranty.
* The warranty period for the JetStar series six (6) ounce popcorn machines is two (2) years.
* The warranty period for the Chrome-Max Griddles is five (5) years on the griddle surface. See detailed warranty provided with unit.
* The warranty period for Teflon/Dura-Tec coatings is one year under normal use and reasonable care. This warranty does not apply if damage occurs to

Teflon/Dura-Tec coatings from improper cleaning, maintenance, use of metallic utensils, or abrasive cleaners. This warranty does not apply to the
“non-stick” properties of such materials.

> This warranty does not apply to "Special Products" but to regular catalog items only. Star's warranty on "Special Products" is six (6) months on parts

and ninety (90) days on labor.

> This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by a Star Authorized Service Center or

the Service Center's sub-agency.

> This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage, wrong gas or operated contrary to the Installation and

Operating instructions.

PARTS WARRANTY

Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The part only is warranted. Labor to replace the part is
chargeable to the customer.

SERVICES NOT COVERED BY WARRANTY

1. Travel time and mileage rendered beyond the 50 mile radius limit

2. Mileage and travel time on portable equipment (see below)

3. Labor to replace such items that can be replaced easily during a daily cleaning
routine, ie; removable kettles on fryers, knobs, grease drawers on griddles, etc.

4. Installation of equipment

5. Damages due to improper installation

6. Damages from abuse or misuse

7. Operated contrary to the Operating and Installation Instructions

8. Cleaning of equipment

9. Seasoning of griddle plates

PORTABLE EQUIPMENT

Star will not honor service bills that include travel time and mileage charges for servicing any products considered "Portable" including items listed below.
These products should be taken to the Service Agency for repair:

* The Model 510F Fryer. * The Model CFS Series Food Steamer.
* The Model 526TO Toaster Oven. * The Model 526WO Warming Oven.
* The Model J4R, 4 oz. Popcorn Machine.
* The Model 518CM & 526CM Cheese Melter.
* The Model 12NCPW & 15NCPW Nacho Chip/Popcorn Warmer.
* All Hot Dog Equipment except Roller Grills & Drawer Bun Warmers.
* All Nacho Cheese Warmers except Model 11WLA Series Nacho Cheese Warmers.
* All Condiment Dispensers except the Model CSD Series Chili/Cheese Dispenser.
* All Specialty Food Warmers except Model 130R, 500, 11RW Series, and 11WSA Series.

10. Voltage conversions

11. Gas conversions

12. Pilot light adjustment

13. Miscellaneous adjustments

14. Thermostat calibration and by-pass adjustment

15. Resetting of circuit breakers or safety controls
16 . Replacement of bulbs

17. Replacement of fuses
18 . Repair of damage created during transit, delivery, &

installation OR created by acts of God

ALL:
* Pop-Up Toasters
* Butter Dispensers
* Pretzel Merchandisers
* Pastry Display Cabinets
* Nacho Chip Merchandisers
* Accessories of any kind

* Sneeze Guards
* Pizza Ovens
* Heat Lamps
* Hot Cups
* Pumps

The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.

Should you need any assistance regarding the Operation or Maintenance of any Star equipment; write, phone, fax or email our Service Department.

In all correspondence mention the Model number and the Serial number of your unit, and the voltage or type of gas you are using.

FOR ASSISTANCE

Part# 2M-4497-2 01/02
