Starline GM Operator's Manual

Operator Manual

GM

2 GM - Operator Manual 150624

WARNING

Before installation and commisioning, you must read the safety instructions and warnings
carefully and all the warning labels attached to the equipment.

IMPORTANT

Failure to comply (even partially) with the instructions given in this manual will invalidate
the product warranty and relieves the manufacturer of any responsibility

IMPORTANT

The alteration of machine operation, design or the replacement of parts not approved by
the manufacturer may void warranties and approvals.

IMPORTANT

This machine is intended for commercial use only.

We have checked that the contents of this document correspond to the model described. There
may be discrepancies nevertheless, and no guarantee can be given that they are completely
identical. The information contained in this document is reviewed regularly and any necessary
changes will be included in the next edition. We welcome suggestions for improvement.

Specifications and document subject to change without prior notice.

Information supplied in this manual is copyright. No part of this work may be reproduced or
copied in any form or by any means, electronic or mechanical without the express permission of
the author / publisher.

Service 0800 782 754
Parts 09 829 0930

Manufactured in New Zealand by Washtech Ltd.
414 Rosebank Road, Avondale, Auckland 1026.
PO BOX 90548, Auckland

WARNING

Before installation and commissioning, you must read the safety instructions
and warnings carefully and all the warning labels attached to the equipment.

IMPORTANT

Failure to comply (even partially) with the instructions given in this manual
will invalidate the product warranty and relieves the manufacturer of any
responsibility.

IMPORTANT

The alteration of machine operation, design or the replacement of parts not

!

!

!

CONTENTS

Safety Instructions.......................................................................................................................................................3

Installation..................................................................................................................................................................... 4

Installation Diagram.................................................................................................................................................... 5

Operating Procedures................................................................................................................................................ 6

Troubleshooting........................................................................................................................................................... 8

Wiring Diagram.............................................................................................................................................................10

WARNING

Before installation and commissioning, you must read the safety instructions
and warnings carefully and all the warning labels attached to the equipment.

IMPORTANT

Failure to comply (even partially) with the instructions given in this manual
will invalidate the product warranty and relieves the manufacturer of any
responsibility.

IMPORTANT

The alteration of machine operation, design or the replacement of parts not

!

!

!

Safety Instructions

WARNING

Before installation and commissioning, you must read the safety instructions
and warnings carefully and all the warning labels attached to the equipment.

!

WARNING

Equipment contains dangerous voltages and can be hazardous if installed or operated
incorrectly. non-compliance with warnings or failure to follow the instructions
contained in this manual can result in loss of life, severe personal injury or serious
damage to property.

Installation

• Use qualified, skilled personnel

• Follow installation instructions

• Connect to correct voltage and supply current

• Provide fully accessible electrical Isolation Switch & water supply valves

Training and Supervision

• Read and understand the Operating instructions and train all staff

• This appliance must not be operated by children or infirm persons

• Machine panels must only be removed by suitably qualified and trained personnel
– internal hazards include live electrics and very hot surfaces

• This appliance is not intended for use as a stepladder

Hot Surfaces

• Some surfaces may be hot or very hot

Chemicals

• Commercial dishwashing detergents are hazardous – handle with care

• Read and follow the safety information found on the labels of detergent
containers and Material Safety Data Sheets

• Use protective eyewear and clothing if decanting containers

Hot Water

• Do not put hands in wash water which may be over 60°C and contain hazardous
caustic detergent

• Rinse water can be over 90°C

• Door safety switches are designed for emergency use only

Cleaning

• Do not hose down the machine or splash water over the exterior

• Watch for broken glass etc when cleaning the inside of the machine

Service/repair

• Under no circumstances the user should attempt to carry out repairs

• All service/repair work must be carried out by qualified personnel only

•

Power Cord Replacement

• If the supply cord is damaged, it must be replaced by the manufacturer or its ser­vice agent or a similar qualified person in order to avoid a hazard

3 GM - Operator Manual 150624

Unpack

• Unpack the machine, check for damage and complete delivery.

Positioning

• Place machine on sound waterproof self draining floor and adjust feet to level

• Allow room for adjacent chemical containers

Water

• Flush supply lines before connection

• Connect hose supplied to adjacent accessible isolator valve - 20 mm 3/4 male

• Flow rate required - 15 litres per minute

• Temperature - 65˚C

• Consumption per cycle - 2.6 litres

• Pressure required - 200-350 kPa - fit limiter above this pressure

• Back Flow - Atmospheric Vacuum Breaker

• Potable water quality is required - filter or soften if necessary

Power

• Machine shipped with cordset for 15 A 230V 50Hz via adjacent switched outlet.

• Easily upgradeable to single phase 25 A 230V 50Hz or three phase 15 A per phase 400V 50Hz

Waste

• Connect drain pump hose supplied to upstand or sink waste connection

Detergent

• Note that detergent is hazardous - read instructions and handle with care

• Insert hose into container of commercial dishwasher low foam detergent

• Refer operator procedures

Rinse Fluid

• Insert hose into adjacent container of commercial dishwasher rinse fluid

• Refer operator procedures

Operation

• Run several cycles, ensure that operator has read and understands instructions

Troubleshooting Installation

• If machine doesn’t fill after switching on power, check & ensure that hot water supply tap is
open, water supply pressure is not below specification.

Installation Checklist

4 GM - Operator Manual 150624

WARNING

Installer must be suitably qualified and ensure compliance with all codes and standards
including AS/NZS3500.1.

WARNING

Before installation and commissioning, you must read the safety instructions
and warnings carefully and all the warning labels attached to the equipment.

!

GM Installation Diagram

GM INST 08-12-14 3A

5 GM - Operator Manual 150624

GM Machine Operation

Service 0800 782 754
Parts 09 829 0930

Turn machine on at wall. Fit scrap tray, filter, upstand and shut door.
Press On/Off Key for 3 Seconds

Start key glows white as machine fills. If door is open then the start key glows
purple

Once full, rinse heating starts. Start key glows orange while heating.
Machine can be started when machine is heating. NOTE: If rinse temperature
is not sufficient cycle countdown will stop at 22 seconds. Washing continues
until rinse reaches temperature required for sanitization and countdown then
resumes.

Start key glows green when machine is fully heated. For different cycles press
the UP and DOWN arrows: Light, Medium, Heavy, Manual or Drain.

Close door/Press start key to start cycle. When manual cycle is selected
machine will continue washing until START button is pressed. Rinsing and
draining follow washing to complete cycle.

Start key glows red during cycle. Pressing Start key again terminates cycle
without rinse. Timer counts down to double zero and flashes 00 at cycle end
until door is opened.

SHUT DOWN - EVERY NIGHT

Press UP or DOWN keys to select Drain cycle. Remove drain upstand and shut
the door. Press START key to start Drain cycle. Machine drains for 100 seconds
with a cleaning rinse mid-cycle. When Draining is complete machine goes into
Standby mode. Remove upstand, filter basket and scrap tray; rinse clean and
replace.

DAILY CLEANING

The machine must be drained and cleaned at the end of each day.

Drain the machine as per the shut down instructions.

Remove, clean and replace filters.

Regularly check the wash and rinse jets and clean if necessary.

MAINTENANCE

Regular servicing of the dishwasher is essential for high

performance, efficient operation and long machine life.

Contact us for information on a maintenance programs.

PRE-RINSING

Pre-scraping of dishes is required by Food Hygiene Regulations. The best method is to pre-rinse with
warm water with a Fisher Pre-rinse Unit - or alternatively by scraping or dunking in water. Cutlery
should be pre-soaked in warm water, preferably containing cutlery pre-soak compound - refer your
chemical supplier.

RACKING PROCEDURES

Do not overload racks or cutlery containers, minimise the overlap of crockery. Wash cutlery unsorted,
handles down. Cycle times are short and water consumption per cycle low – so there is no advantage
in overloading racks.

CYCLE TIMES

The GM has a 1, 2, 3 minute cycle and extended manual cycle.

CHEMICAL

Correct type and quantity of detergent is essential for good results. Use good quality chemicals and
regularly check containers. Discuss the use of drying agent and cutlery pre soak solution with your
chemical supplier. Detergent & Rinse Fluid concentration can be changed by adjusting dispensing time
on the keypad (refer to page 8 User Programming). Prime detergent line by opening door with wash
tank empty (at installation or after draining) then switch machine on. Detergent pump will operate and
prime the line. Following priming, machine power must be switched off to reset for filling

DRYING

Single tank commercial dishwashers do not have a drying cycle. However, the machines do rinse at
high temperatures which promotes fast drying particularly when drying agents are used.
At the end of the cycle promptly remove the rack from the machine - leave the rack on the bench for 2
to 3 minutes before emptying.

Operating Procedures

Manufactured in New Zealand by Washtech Ltd.
414 Rosebank Road, Avondale, Auckland 1026
Tel [phone] | Fax [phone]
Web www.starline.co.nz

REGULAR CLEANING – at least once a week

Remove filter 1 and upstand 2. Remove wash 3 and
rinse arms 4 by undoing the central thumbscrews 5.
Remove joined wash and rinse arm 8 by undoing central
thumb screw 7. Inspect all jets – use toothpick or pa­perclip and remove arm end-caps if necessary to flush
and clear. Clean and then replace all items.

1

2

4

3

8

5

7

6

8 GM - Operator Manual 150624

User Programming

User Settings Factory Setting Selection

Power Save ON ON/OFF

Fill Detergent Injection Time 40 0 - 180 secs

Wash Detergent Injection Time 15 1 - 30

Rinse Aid Injection Time 12 1 - 30

Display Contrast 27 10 - 40

The User Settings menu is accessed for programming by pressing the UP and DOWN
keys simultaneously for a few seconds. The programming options are specified in the
table below:

Power Save function reduces the rinse temperature setting by 10°C when the machine is
idle for 5 minutes or more. The temperature settings return to the set value when door is
opened or START/STOP key is pressed.

QuickStart starts washing regardless of rinse temperature. If rinse temperature is not
sufficient cycle countdown will stop at 22 seconds. Washing continues until rinse reaches
temperature required for sanitization and countdown then resumes.

Troubleshooting

If an error message appears on the control display first try turning the machine OFF for 30
seconds and then back ON.

Display Code Cause Remedy

7. Fill Failure - wash tank
not full after fill timeout

Check drain upstand fitted Fit upstand before

filling

Check flow rate of water supply Check water supply

8. Drain Failure Drain hose jammed/blocked Check/unblock drain

hose

Drain upstand not removed Remove upstand

before draining

Keypad Start Button Colours

Machine State Colour

Door Open Purple

Filling White

Heating Orange

Ready Green

Ecopower Blue

Washing Red

Error Flashing Red

If the error message remains call for service

9 GM - Operator Manual 150624

Fault Cause Remedy

Filling

Not filling Water supply valve shut Check Water supply valve

Door Switch not operating Check Door is closed

Filling during wash cycle Upstand not fitted properly Check Drain upstand is fitted

Heating

Dishes not hot enough Rinsing but not hot Check water arms spinning freely

Cycle start

Does not start Door switch Check door is closed

Cycle Finish

Wash too long Water supply cold Check water temperature

Performance

Poor wash result Detergent not used Use quality low foam product

Overloading racks Do not overload racks

Not pre-rinsing Use Fisher pre-rinse

Wash arms not rotating Remove and clean arms/check

bushes

Wash jets blocked Remove arms and clean jets

Excessive soiling Pre-rinse/use long cycle

Unrealistic expectation E.g. baked on soiling requires

pre-soaking

Poor rinse results Rinse jets blocked Remove arms and clean jets

Rinse arms not turning Remove arms, clean jets, check

bushes

Poor racking procedures Do not overload racks

Wash tank soil build up Pre-rinse, change wash water

regularly

Not drying Poor wash/rinse performance Refer above

Low temperatures Check heating systems

Drying agent not used Use quality drying agent/rinse fluid

Foaming Wash Excessive Rinse Fluid Adjust Rinse Fluid

Troubleshooting

10 GM - Operator Manual 150624

GM7(S) Wiring Diagram

060248 19/06/15 1 B

GM7(S) WIRING DIAGRAM

IMPORTANT







11 GM - Operator Manual 150624

Accessories

Code Description

600 70080 Cuprack 450mm

600 70081 Dishrack 450mm

C660503 G Cutlery Container

Information supplied in this manual is copyright.
No part of this work may be reproduced or copied
in any form or by any means, electronic or
mechanical without the express permission of the
author/publisher

Manufactured in New Zealand by Washtech Ltd.

414 Rosebank Road
Avondale
Auckland 1026
New Zealand

PO Box 90548, Auckland

24HR Service 0800 Starline
Tel [phone]
Fax [phone]
E-mail [e-mail]
web www.starline.co.nz

ISO9001
All Washtech products are designed and
manufactured by Washtech using the
internationally recognised ISO9001 quality
management system, covering design,
manufacture and final inspection, ensuring
consistent high quality at all times.

In line with policy to continually develop and
improve its products, Washtech Ltd reserves the
right to change specifications and design without
prior notice.
