Star Water Conditioning

Quality Features

EC Style

Economy Cabinet/

Single Tank Softener

Three-Year Limited Warranty on Control Valve

Ten-Year Limited Warranty on NSF approved mineral tank

1. Control Valve – Can be automatic valve, demand regeneration valve or solid state electronic control valve.

2. Mineral Tank – Storage tank for the mineral that softens the water, untreated water flows through this tank.

3. Distributor Tube – Directs the flow of water through the mineral tank.

4. Softening Resin – High capacity resin which removes hardness (calcium and magnesium) and ferrous iron. See individual models for hardness and iron removal rates.

5. Salt Storage Tank – Referred to in the water trade as the brine tank. Stores salt which is mixed with water to regenerate softening mineral. Salt water flows through the mineral bed attracting the calcium and magnesium ions (hardness chemicals) which are flushed to drain along with the salt water. This leaves the original mineral regenerated and ready for the next softening

Free Standing/Dual Tank

FS Style

Softener

Buy the Right Unit the

First Time. Have Water

Professionally Tested and

Avoid Costly Mistakes.

ORDER FACTORY TEST KIT

136958

EasySoft

Deluxe Cabinet/Single Tank

Softener

cycle.

6. Brine Tube – Transfers salt water to mineral bed enabling the regeneration cycle to begin.

7. Brine Well – Allows salt water to be transferred to mineral bed and keeps salt away from brine components.

8. Brine Well Cap – Prevents salt and other substances from entering brine well.

9. Safety Brine Valve – Prevents water level in salt storage tank from overflowing. Float mechanism shuts off valve located in brine line if water level gets high.

10. Overflow Fitting – When connected to a drain adds additional insurance against the possibility of water overflow.

11. Brine Line – Flexible tubing used to transfer water between the mineral and salt brine tank.

The effectiveness of all water conditioning products to enhance water quality depends on a varietyof water factors such as pH, dissolved solids, flow rates, and others. Star recommends testing all water prior to selecting any water treatment,

particularly private well water. To ensure peak performance, Star’s 136958 Comprehensive Factory Analysis Kit is available.

STAR

Water Conditioning

EasySoft

Softeners

Easy as 1-2-3!

Easy to choose Easy to install Easy to maintain

NEW

Space-Saving

Models!

EasySoft® softeners with Digital

Demand Regeneration Control

Valve

• Digitally controlled regeneration meters actual water used and regenerates only when necessary.

• Appliance style single-tank design cabinet with large salt storage capacity.

• High-capacity resin ensures maximum softening capability. Resin can be regenerated indefinitely.

S15DC29DR

29,000 grains

Meets normal

household

requirements for

1 - 4 people*

S15DC39DR

39,000 grains

Meets normal household

requirements for

• Automatic internal by-pass valve for constant household water flow during regeneration cycles.

• Bypass valve and safety brine valve included for easy installation and maintenance.

• Corrosion resistant, maintenance free tanks.

• Three-year limited warranty on control valve and

ten-year limited warranty on mineral tank. Oneyear limited warranty on other parts.

1 - 8 people*

Fleck

Model # S15DC29DR 5600SE 29,000 75 4 3/4 13 x 23 x 45 7 2.4 225 90 054757068202 S15DC39DR 5600SE 39,000 100 4 1 13 x 23 x 45 8 2.4 225 100 054757068219

(¹) Removes iron in solution (Ferrous “clear” iron) up to amounts shown. (²) Maximum service flow rates thru the softener must never exceed the specified flow rate in gallons per minute.

Valve Style

Mineral

Bed

Capacity

Grains

Hardness

Removal

Max. GPG

Iron

Removal

(Clear)¹

Max. PPM

High Cap.

Resin

cu. ft.

Total

Space

Required

(In. W x D x H)

Flow Rate GPM

Service

Max.²

Backwash

Min.

Salt

Storage

Capacity

lbs.

Approx.

Shipping

Weight

lbs. UPC #

*Depends on specific water hardness levels.

STAR

Water Conditioning

Economy Water Softener

with Multi-Day Timer

• Fully automatic motor control valve allows for multi-day programming flexibility to fit your specific needs.

• 12-volt electrical transformer.

• Circular space saving single-tank design cabinet with large salt storage capacity.

• High-capacity resin ensures maximum softening capability. Resin can be

regenerated indefinitely.

• Automatic internal by-pass valve for constant household water flow during regeneration cycles.

• Corrosion resistant, maintenance free tanks.

• Three-year limited warranty on control valve and ten-year limited warranty on

mineral tank. One-year limited warranty on other parts.

EC Style

Fleck

Model #

S07EC24 5600 24,000 75 4 3/4 13.5 x 22.5 x 44 7 2.4 250 84 054757000295

(¹) Removes iron in solution (Ferrous “clear” iron) up to amounts shown. (²) Maximum service flow rates thru the softener must never exceed the specified flow rate in gallons per minute. By-pass valve and safety brine valve not included. For by-pass valve, order 135507; for safety brine valve, order 138807.

Valve Style

Mineral

Bed

Capacity

Grains

Hardness

Removal

Max. GPG

Iron

Removal

(Clear)¹

Max. PPM

High Cap.

Resin

cu. ft.

Total

Space

Required

(Inches)

Flow Rate GPM

Service

Max.²

Backwash

Min.

Salt

Storage

Capacity

lbs.

Approx.

Ship

lbs. UPC #

Dual Tank Metered Water Softener

• Patented metered valve regenerates based on actual water usage, saves water and salt by regenerating only when needed.

• Dual tank design for easy maintenance and 225 lb. salt storage capacity.

• High capacity resin ensures maximum softening capability.

• Removes up to 4 PPM clear water iron.

• Automatic internal by-pass valve for constant household water flow

even during regeneration cycles.

• Corrosion resistant, maintenance free tanks.

• Safety brine overflow protection standard equipment.

• Three-year limited warranty on control valve and ten-year limited

warranty on mineral tank. One-year limited warranty on other parts.

FS DR Style

Fleck

Model # S07FS32DR 5600DR 32,000 100 4 1 14 x 14 x 34 8 x 44 8 1.5 225 94 054757000356 S07FS48DR 5600DR 48,000 100 4 1-1/2 14 x 14 x 34 10 x 44 9 2.4 225 12 2 054757000370

(¹) Removes iron in solution (Ferrous “clear” iron) up to amounts shown. (²) Maximum service flow rates thru the softener must never exceed the specified flow rate in gallons per minute. Valve includes manifold for easy connection. By-pass valve included.

Valve Style

Mineral

Capacity

Grains

Bed

Hardness

Removal

Max.

GPG

Iron

Removal

(Clear)¹

Max. PPM

High Cap.

Resin

cu. ft.

Space Required Flow Rates GPM

Brine

Tank (In.)

Mineral

Tank (In.)

Service

Max.²

Backwash

Min.

Salt

Storage

Capacity

Lbs.

Approx.

Ship.

Weight
