D8
Page 10
PARTS LIST
8D
BELGIAN WAFFLE BAKER MODEL NBWB-CL & NBWB-CH
MODEL
Number
Key
Number
D1 Handle Lock Nut (no longer available)
D2 B9-70-WB-0009 1 Spring
D2A B9-70-WB-0067 1 Rod for Spring Handle
D4A 2F-Z6667 1 Top Grid (cast aluminum)
D8 B9-51-WB-0028 1 Top Housing Cup
D9 Large Acorn Nut (no longer available)
D11 2I-09-WB-0002 2 Insulation, Top and Bottom
D12 2R-09-WB-0006 1 Bell Knob
D13 2C-08-WB-0008 1 Bell Nut
D14 Decal for Bell Timer, K-Mart only (no longer available)
D14A 2C-09-WB-0005 1 Bezel
D15 2P-09-WB-0007 1 Bell Timer
D16A 2E-Y6144 1 On/Off Switch
2E-05-07-0030 1 On/Off Switch (120V) NBWB-A
D17A 2S-Z3823 1 Pilot Light (120V)
B9-05-07-0006 1 Pilot Light (120V) NBWB-B
2J-05-07-0010 1 Pilot Light (208/230V)
D18 Screw for Brass Housing (no longer available)
D19 2C-Y4041 1 Screw for Clamp Pad
D20 B9-04-WB-0055 1 Clamp Pad
D21A B9-04-WB-0056 1 Bronze Tension Pad
D23A B9-04-WB-0054 1 Brass Housing
D24 1N-E2075 High Heat Wire
D25 2E-05-07-0005 1 Lead-In-Cord (120V) / 2E-05-07-0052 (208V/230V)
D26 2K-05-07-0017 1 Cord Clamp / STRAIN RELIEF
D26A B9-04-WB-0065 1 Plate for Cord Grommet
D27B Tall Bottom Plate (no longer available)
D28 Terminal Assembly (no longer available)
D29A Back Frame (no longer available)
D30 B9-30-WB-0102 Hinge Collar Assy
D30A B9-30-WB-0086 1 Hinge Tube Assy
D31A 2C-08-07-0205 1 Nut
D32A B9-51-WB-0003A5 1 Hinge
D33 B9-04-WB-0057 1 Hinge Spacer
D34 2C-08-07-0048 1 Screw
D36 B9-50-WB-0138 1 Clamp
D38R B9-04-WB-0042 1 Bottom Housing Cup
D40A B9-30-WB-0096 1 Flat Yoke Assembly
B9-04-WB-0150 1 Yoke Base (no longer available) NBWB-B
D43A 2F-Z6668 1 Bottom Grid (cast aluminum)
D46A Bolt for Yoke
D75 B9-04-WB-0066 1 Spacer
D76 2C-08-07-0205 1 Screw with Point
D77 Locating Screw (no longer available)
D78 2P-09-WB-0003 1 Button
D79R Knob for Beeper Timer, K-Mart only (no longer available)
D81 B9-30-WB-0102 1 Collar
D82A 2T-05-WB-0055 1 Thermostat - Stemco w/o Bracket (vendor # CAP-380)
B9-04-WB-0202 1 Bracket for Stemco Thermostat
D82B 2T-05-WB-0013 1 Thermostat - Robertshaw (vendor # K-547)
Part
Number
Per
Unit
Description
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
SK1492A
Star Manufacturing International, Inc.
Page 11
PARTS LIST
8D
BELGIAN WAFFLE BAKER MODEL NBWB-CL & NBWB-CH
MODEL
Number
Key
Number
D82C 2E-05-WB-0006 1 Thermostat - Zytron
D82D 2E-70-WB-0047 1 Probe for Thermostat - Zytron
D82E B9-04-WB-0047 1 Tube for Probe - 1/4” machined
D83 2P-09-WB-0007 1 Electrical Timer NBWB-A
D83R 2P-05-WB-0031 1 Timer - Electrical (208/230V)
D84 Z1-70-07-0006 4 Metal Leg
D85 2A-09-07-0076 4 Plastic Cap for Metal Leg
D86 B9-40-WB-0046 1 Terminal Assembly for Front Arms
D87 1 Element Plate included with Key # D88
D88 B9-40-WB-0050 2 Element, Top and Bottom with Element Plate
D89 2C-08-07-0147 2 Element Clip
D90 Box and Pads (no longer available) (not shown)
D91 2Z-09-WB-2001 Grid Cleaner - SOKOFFR (1 Pint) (not shown)
D92 Screw & Grid Spacer Assy for new Diehl Timer (no longer available)
D93 B9-04-WB-0063 1 Bottom Cover
D94 Beeper (no longer available)
D95 B9-73010 1 Top Hinge - Casted Housing with Pin
D96 B9-70-WB-0115 1 Support Bar for 7” Cup
D97 Large Bolt (no longer available)
2P-09-07-0002 1 Spring Cover for High Heat wires (not shown)
2I-07-WB-0001 Gasket for Top and Bottom Housing Cup
Part
Number
Per
Unit
Description
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 2
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
SK1492A
Star Manufacturing International, Inc.
