Star CSD-1NP Parts Manual

6

PARTS LIST EFFECTIVE

4/24/02

MODEL

Single Peristaltic Cheese Dispenser CSD-1NP

Number

Key

Number

1 M2-Z2872 1 BACK

2 M2-22072 1 DIVIDER-FAN

3 M2-22061 1 ASSEMBLY-BAG TRAY

4 M2-Z2865 1 TOP CSD-1

5 M2-Z2866 1 LINER TOP-CSD-1

6 M2-22054 1 ASSEMBLY-DOOR

7 M2-Z2991 1 BRACKET-THERMOSTAT

8 M2-Z2868 1 BAG HOUSING

9 M2-Z2873 1 WALL-MOTOR MOUNT

10 M2-Z2700 1 BOTTOM

11 M2-Z2889 1 DRIP TRAY CSD-1N

12 M2-22041 1 TUBE COVER ASSY

13 M2-Z2703 1 COVER-SWITCH

14 M2-22062 1 ASSEMBLY-TRACK BLOCK

15 2U-Z1686 1 MOTOR-RIGHT

16 2I-Y6709 1 CUSHION-MOTOR

17 2N-Z2679 1 ELEMENT 120V/600W

19 E4-403009 1 LEAD IN CORD ASSEM

20 2K-H5417 1 BUSHING-HEYCO #SR-6P-3-4

21 2M-Z2882 2 LABEL SIDE PANEL NESTLE

22 2I-H7685 4 BUMPER RUBR LAVELLE 757R

23 2P-9564 4 PLUG-RUBBER

24 2T-H6335 1 THERMOSTAT

25 2P-9615 1 BEARING-SELF ALIGN .5ID

26 M2-22049 1 ASSEMBLY-BLOCK RIGHT

27 2A-Z1616 1 BUSHING

28 2P-Z1615 1 SPRING-RIGHT

29 2C-Z1689 1 WASHER 1.25 OD x 9/32 ID

30 2R-Z1623 2 KNOB-DAVIES 2810

31 2E-Z2680 1 SWITCH-PUSH BUTTON

32 2E-Y9627 1 SWITCH-ON/OFF

33 2A-Z1690 1 PIN COTTER

35 2A-Z1621 5 ROLLER

36 2C-Z1620 5 SCREW SHOULDER

37 2R-Z2883 3 MAG CATCH SOUTHCO 300

38 2M-Z1688 1 GRAPHIC ARROW

39 2T-Z0613 1 THERMOMETER-SPIRIT

40 2I-Z1894 1 HINGE-INSERT

Part

Number

2U-Z3000 1 MOTOR CCW 120 RPM - CSD-1NPC

Per

Unit

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE

INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

Star Manufacturing International, Inc.
