Page 1

mPOS • RETAIL • RECEIPTS • HOSPITALITY • LABELS • KIOSK • TICKETS

POS Printing Solutions

The Ultimate Collection

Page 2

Once again Star has shown it doesn’t follow the market – it leads, with the introduction of UNIQUE & MARKET CHANGING products…

NEW

The World’s 1st Bluetooth Combined 58mm Printer and Cash Drawer

The ultimate, unique peripheral for merchants requiring a Bluetooth combined printer and cash drawer that simplifies integration and whose good looks will complement any counter top. The only decision is whether to use a smartphone, Apple or Android tablet –

for more details see pages 6 & 7.

NEW

10" Universal Tablet Holder

with 180° rotation, mPOP top plate and Payment device holder available in black or white. Red, yellow, green, blue versions

available on special order.

option

NEW

View and store receipts / coupons on your customer’s phones at no charge

The fast, secure and easy route to digital receipting

AllReceipts Digital Receipting with Star’s AllReceipts App – now included in the printer

driver and FREE to retailers and customers with analytics and new coupon notification tools

– see page 8 for more information.

Star POPPack

Digital Receipt Service

STAR CLOUD SERVICES

Just download the App!

ANDROID APP ON

NEW

TSP100III Series

with Cable-Free Connectivity including Entry-Level Wireless Model

Star’s iconic TSP100 Series has three new models printing at a faster 250mm/second with a tablet charging USB port.

 TSP143III WLAN NEW WiFi model  TSP143III LAN NEW LAN model  TSP143III BI NEW Bluetooth model

All feature Star’s unique futurePRNT software (Windows) and facility to add Star’s FREE-OFCHARGE Digital Receipting solution (see page 8).

SDKs and drivers for all models available from

www.StarMicronics.com/support

Further information for Europe, M.East, Africa and India available at www.Star-EMEA.com in five languages.

Page 3

Contents

What’s New

NEW AllReceiptsTM NEW CloudPRNT NEW mPOP NEW TSP100III Series

Summary of the latest developments from Star

NEW FREE-OF-CHARGE Digital Receipting on TSP100 / 654 / 743 / 847 / FVP10 models – no email required 8

Printer internet connection through WiFi, LAN with remote document printing from your web server 14

Combined cash drawer & 58mm printer with Bluetooth connectivity designed specifically for the mobile mPOS market 6-7

NEW 250mm/second Bluetooth, LAN & Wireless LAN models 9-11

Direct Thermal 203 dpi Label, Receipt & Ticket mPOS & POS Printers

NEW mPOP NEW TSP100 Series

TSP100

futurePRNT Software TSP654II Series TSP700II & TSP800II Series FVP10 Series TSP1000 Series TSP-L10 Series

Combined cash drawer & 58mm printer with Bluetooth connectivity designed specifically for the mobile mPOS market

Entry-level 80mm receipt printers

Innovative TSP100 installation & marketing software included free-of-charge for all sizes of retailer

HIGH SPEED, 80mm entry-level 300mm/sec. receipt printers with interchangeable interfaces & new super white versions

Multi-functional 80mm & 112mm wide receipt, label & ticket printers NEW Bluetooth & CloudPRNT versions

Front operating, under counter, multi-functional 80mm wide receipt, label & ticket printers NEW Bluetooth & CloudPRNT versions

Versatile low cost 80mm thermal printer with receipt / ticket stacker & 18cm paper roll

High performance 80mm printer for secure transactions including coupon, lottery & ticketing & 20cm paper roll capacity

★ NEW 250mm/sec. Bluetooth, LAN, WLAN models ★

FREE Digital Receipting with App feature

Dot Matrix Kitchen & Receipt Printers

SP298 Series HSP7000 Series SP700 Series SP500 Series DP8340 Series

Fast 3.1 lps, reliable, cost-effective 9-pin matrix impact slip printers

HIGH SPEED, 203 dpi direct thermal / 9-pin matrix hybrid combination receipt / cheque printer

Advanced, high speed red / black ClamshellTMreceipt / kitchen printers NEW Bluetooth & CloudPRNT versions

Entry-level receipt / kitchen printers with 6 position black mark sensors

Versatile, wide (114mm), mobile, compact receipt / label printers (up to 2 lps)

mPOS Connectivity

NEW Bluetooth Desktop Direct Thermal & Matrix Kitchen Printers with Apple iOS (including Auto Connect) / Android / Windows connectivity NEW TSP143IIIBI

TSP654IIBI TSP743IIBI TSP847IIBI FVP10BI SP742BI

Please see Mobile Range below for hand-held / belt printers

NEW mPOP

DK-AirCash DK-USB WiFi Power Pack ProxiPRNT BLE Beacons WebPRNT

250mm/second receipt printer with unique futurePRNT software

Entry-level, high performance 300mm/sec. receipt printer with cash drawer support

Multi-functional printer capable of producing 80mm wide high quality receipts, labels & tickets on media up to 0.15mm thick

Multi-functional printer capable of producing 112mm wide high quality receipts, labels & tickets on media up to 0.15mm thick

Front operating, multi-functional printer capable of producing 80mm wide high quality receipts, labels & tickets

High speed, Clamshell kitchen printer with splash proof design, internal power supply and red / black output

Combined 6 or 8 coin holder / 4 note cash drawer & 58mm printer with Bluetooth connectivity

Unique accessory to “remotely” mobilise any RJ11 traditional cash drawer – LAN, Bluetooth & LAN, WiFi & LAN versions available

Star Printer Power Provider option for WiFi Pack or other 3rd party dongles such as 3G etc.

Low cost device enabling wireless printing from any Star LAN printer

Proximity based printing & secure cash management beacons for mobile device distance detection to Star printers & cash drawers

Multi-platform plug-In hardware interface & Star WebPRNT Browser solutions for direct printing from a Web page

4-5

10-11 12-13 16-17

6-7

9-11

15 18 19

20 20 21 21 18

9-11

13 16 17 15 21

6-7

25 25 25

Mobile Receipt & Label Printers WiFi & Bluetooth versions

NEW SM-L200

NEW SM-S230i

SM-S220i SM-T300i & SM-T400i SM-T300DW

Classic Bluetooth / BLE – Low cost, 2" (58mm) mobile receipt & label printer with simple, no pin required connection with

Bluetooth 4 devices including Apple iOS, Android, Linux & W

Bluetooth – Super compact 2" (58mm) mobile receipt printer with OS auto-detect pairing. Apple iOS (MFi certified), Android, Linux & Windows

Bluetooth – Counter top mobile 2" (58mm), Apple iOS (MFi certified) / Android / Windows mobile receipt printer

Bluetooth – 3" (80mm) & 4" (112mm), rugged, IP54 splash proof, Apple iOS (MFi certified) / Android / Windows printers

WiFi – 3" (80mm) rugged, IP54 dust & splash proof mobile receipt printer

indows ★ NEW Desktop, Drop-in Cradle Charger ★

POS Peripherals, Customer Displays & Cash Drawers

NEW AsuraCPRNT

CB-2002 / CB-92II DK-AirCash

NEW mPOP

SCD122 & SCD400

“All-in-One” Linux or Android driven interactive communication platform & printer with WebPRNT

Cash drawers available in charcoal grey, TSP143ECO black, Star white and the NEW Ultra white to match mPOS devices

Unique accessory to “remotely” mobilise any RJ11 traditional cash drawer – LAN, Bluetooth & LAN, WiFi & LAN versions available

Combined 6 or 8 coin holder / 4 note cash drawer & 58mm printer with Bluetooth connectivity

★ NEW Star POPPack 10" Universal Tablet Stand Holder & Plate Option ★

ESC/POSTMcompatible customer displays with stand alone, telescopic pole & USB versions

Terminal Embedded / Kiosk Printers

Sanei

SK1-21A/22 /31A/32 /41A

TUP500 & TUP900 Series

Range of compact, open

Modular, open frame 80mm & 112mm wide receipt, label & ticket printers with A4 Replacement version using Scalable Raster Driver to reduce traditional laser running costs by 90%

frame printers ★ NEW SK1-22 – 2"/58mm Clamshell model ★

Key Product Summary with Specifications

AsuraCPRNT “All-in-One” 32 Mobile / mPOS Printers (Wireless & Bluetooth) 32 Bluetooth Desktop Printers 33

Dot Matrix, Impact Receipt & Kitchen Printers 33 Specialist Thermal Kiosk / Terminal, Lottery & Ticketing Printers Direct Thermal mPOS, POS and Kiosk Printers 35

Star Support & Connectivity

22-23

22-23 22-23 22-23

26-27

30-31

24 25

6-7

28 29

Page 4

WHAT’S NEW

What’s from Star

NEW

Star has not only extensively researched the needs of its users with new products reflecting worldwide market POS & mPOS innovations but has also developed more software related products including AllReceipts. This solution enhances Star’s printer range & works independently of the retailer’s software, minimising installation costs.

Digital

Receipt Service

STAR CLOUD SERVICES

Star

POPP ac k

Option

Digital Receipt Service

STAR CLOUD SERVICES

Star has taken printer enhancement to a new level with Star Cloud Service’s Digital Receipting Service included within the Star printer driver or SDK.

Star’s digital receipting offers retailers a free of charge and fast route to providing the customer with a digital image of a printed receipt with full colour coupons as well as access to analytics, an in-store customer survey and device management tools. With zero development required, AllReceipts is enabled within the Star printer driver and works independently of a retailer’s POS software. Retailers can not only link customers to a promotional landing page but also send new promotional notifications to the customer’s phone. No need to login, no need to give up personal information (email / phone numbers)

and the best part is the service is FREE !

The World’s 1st Bluetooth Combined

The World’s 1st Digital Receipting function with Customer App

(see page 8 for more details)

58mm Printer and Cash Drawer

Star is known worldwide as the most dominant printer manufacturer for mPOS with connectivity at all levels, so it is only natural for Star to create the world’s 1st Bluetooth all-in-one mPOS cash drawer. Designed for use under and above the counter with just one power cable for all mPOP functions including scanner use, as well as one or two external device charging. Star POPPack option now available to complete the POS Station look with 10" tablet stand and heavy metal plate.

NEW

TSP143III

Bluetooth, LAN & Wireless models

(see pages 6 & 7 for more details)

TSP143III

SM-S230i

SM-L200

Three new models from Star’s renowned TSP100 Series, used by retailers and restaurateurs across the globe from major retailers and fast food restaurants to your local corner shop and café. NEW Bluetooth & Ethernet LAN models plus a simple, yet effective wireless version, the TSP143III WLAN supports 802.11b/g/n (2.4GHz) with an easy-to-use and ready to go WPS setup. Compact footprint, fast 250mm/second speed with internal power supply and vertical mount kit in the box makes this the perfect wireless kitchen / pop-up receipt printer.

NEW

Apple iOS certified & Star’s 1st 58mm Classic Bluetooth / BT4.0 Low Energy Mobile Printers

The NEW SM-L200 has been designed specifically for the mPOS market and happily connects with Classic Bluetooth 2.1 and Bluetooth 4.0 devices without the need for pin codes or traditional pairing methods. The compact design, convenient USB charging and 13 hour battery life is perfect for environments where retailers do not want to pair one printer to just one tablet. A new desktop, cradle charging option is now available as well as an in-vehicle mount with temporary or fixed charging for taxis, receipting and labelling etc.

SM-S230i is Star’s latest traditional Bluetooth mobile with next generation features

including auto-detect pairing to Apple iOS (with MFi certification), Android and Windows devices. Battery life has been increased to 13 hours with a more compact, yet durable design with a drop test of 1.5 metres.

(see pages 22, 23 & 32 for more information)

mPOS Ultra White Range

Today’s mPOS marketplace is currently experiencing exponential growth worldwide and Star is at the forefront of this mPOS revolution with the widest selection of printers and accessories available today, including a new super white range to aesthetically match the user’s chosen device whether it be an Android, Apple or Windows Smartphone or tablet – see TSP100ECO, TSP100LAN & TSP654II.

Page 5

mPOS Peripherals

The World’s Largest Range of Bluetooth Kitchen Label, Receipt & Ticket Printers

Including entry-level Receipt, Kitchen Matrix, Label and 80 or 112mm wide Ticket Printers using media up to 0.15mm thick for Apple iOS, Android & Windows – see TSP143III, TSP654II, TSP743II, TSP847II, SP742 & FVP10.

Star DK-AirCash Unique accessory to mobilise any Cash Drawer

Low cost, Cash Drawer Accessory enabling mPOS users to open the cash drawer of their choice with a standard RJ-11 printer connection via their mobile device in a variety of environments with Star’s unique Auto Connect feature.

(see page 25 for more details)

Star WiFi Power Pack with DK-USB Printer Power Connection

No 2nd power socket needed. For use with Star LAN & WebPRNT printers.

 Star DK-USB – designed to provide USB power for external 3rd party dongles minimising the

number of external cables and power sockets required

(see page 25 for more details)

WHAT’S NEW

Developer’s Tools

NEW

8 & 10 for Star’s TSP100, 650, 743II, 847II, FVP10 counter top & mobile printers or by using the new HI X Connect interface (for TSP654II, 743II, 847II) with the Digital Receipting Service automatically integrated for any platform. iOS and Android applications can use Star Cloud Services SDKs available from www.starmicronics.com/support (see page 8 or contact Star for more details)

NEW

scheme to then print on a Star Bluetooth, LAN / WLAN or USB printer. New features include PDF print & Black mark support. Star PassPRNT supported models include Star mobile printers, BSC10, FVP10, TSP100III, TSP654II, TSP743II & TSP847II.

NEW

AllReceipts as well as support for “emulation free” development under Windows, Android & iOS (including Swift & Objective-C support) for Star printers. Star supports both “rich sample codes” for flexible application development and “new API” for easier application development.

Digital Receipt Service

STAR CLOUD SERVICES

Introducing PassPRNT from Star Micronics

A sophisticated print data relaying application available for Android & iOS software developers. PassPRNT effectively receives data from an application such as Filemaker Go or any web browser including Safari / Chrome using a URL

StarPRNT SDK

Including thermal printers, kitchen printers, portable printers, mPOP, kiosk printers and

Supports all popular Star product categories in one SDK

NEW

Star’s new HI X Interface (IFBD-HI01X / HI02X) is now available with Cloud connectivity at every level including Star’s new CloudPRNT technology allowing remote printing direct from your web server to any printers anywhere in the world. Star’s traditional POS printer 300mm/second TSP654II receipt printer, SP700 matrix kitchen printer or the 80 /112mm label, ticket and receipt printers TSP743II, TSP847II can be bought with, or upgraded, to take the new low cost HI X (IFBD-HI01X / HI02X for SP700) Interface option which is…

 WiFi Ready using a compatible, locally sourced USB WiFi dongle matching

the customer’s preference and budget. Approved dongles can be found at

www.star-emea.com/products/hixconnect

 Dual Interface USB / LAN  CloudPRNT internet connection through WiFi, LAN with remote document printing

from your web server. Perfect for restaurant aggregation, warehousing etc.

 Star’s previous WebPRNT LAN platform independent HTML / JavaScript printing from

the Web included free-of-charge (previous HE07/8 versions needed a licence)

 Peripheral Ready no PC required peripheral use including scanners with 2 USB

host ports

Star’s Digital Receipting Service from Star Cloud Services with the customer AllReceipts App works without integration on Windows 7,

(see page 14 for more details)

HI X Connect Interface

with CloudPRNT & Star’s Digital Receipting Service already on board

POS Station 1

(see page 14 for more details)

DK-AirCash

DK-USB

POS Station 2

Proximity Based Printing & Secure Cash Management for mPOS

Using BLE beacons integrated with

StarIO Printer and Cash Drawer support API or SDK to provide remote tablet access to Star printers and cash drawers. Once integrated with the Star receipt printer or cash drawer, Star’s ProxiPRNT will enable the sales assistant to automatically select and print to the closest printer as well as ensure that a cash drawer can only be opened wirelessly if the sales assistant is standing right next to it.

 Threshold distances can be set as required  Supports Star & compatible cash drawers fitted with DK-AirCash  Full Star IO and SDK support

Automatically selects and connects to the

closest printer and cash drawer

POS Station 1

POS Station 2

Page 6

THERMAL

NEW

THE MOBILE POINT OF PURCHASE SOLUTION

“The NEW ultimate and unique peripheral for merchants requiring a Bluetooth combined

mPOS

printer and cash drawer.”

PERIPHERALS

Outstanding connectivity and design, plus intuitive functionality and simple integration are delivered ready to work with your chosen, mobile, software and card payment system. Welcome to a new era for mPOS.

Tablet and phone not included.

Use with YOUR choice of mobile device.

The World’s 1st Bluetooth Combined 58mm Printer and Cash Drawer

Advanced mobile devices and app software have opened up new avenues for retailers. At Star Micronics we’ve developed the world’s first conceptually driven, combined point of purchase cash drawer and printer in response to the need for an easily integrated mobile POS system. In the mPOP we’ve created something that’s aesthetically simple and elegant, yet loaded with intuitive design features. At just 10cm high and 30cm wide it’s easily transportable, whilst the Bluetooth connectivity means only one mains cable is needed for full operation.

mPOP works with all major mobile operating systems including Apple iOS, Android and Windows, giving retailers the freedom to use the platform that works for them.

ANDROID APP ON

The multiple functions and connectivity of the mPOP make processing customer transactions smooth and effortless for outlets such as bars and cafés, florists and pop up shops. The sleek design will complement any counter top or, for an even less intrusive look, it can be secured underneath a countertop.

NEW

10" Universal Tablet Holder

with 180° rotation, mPOP top plate and Payment device holder available in black or white.

Red, yellow, green and blue versions available on special order.

Star POPPack option

Page 7



Compact, stylish and functional

Just 10cm high and 30cm wide, the mPOP unit will sit happily in retail and hospitality environments providing receipts and change for your sale. Just add the latest third party card pin pad to your set-up.

THERMAL

100 mm

Cable exit choices



Effective cable management

Enhanced cable routing and various cable

300mm

308mm

Reliable 100mm/second printer with intuitive top loading & easy

exit options maintain the sleek design in your retail environment.

front feed, the printer uses traditional direct thermal receipt paper which does not need ribbons or toner and is readily available. The partial cut guillotine automatically cuts the 58mm wide receipt so it won’t drop on the floor. Simple paper loading – just push the front printer panel and press the easy release lever to drop in the paper roll and then print.

Functional but compact cash drawer

A clean, fast drawer release reveals 6 coin holders capable of taking full bank bags of coins and 4 upright note dividers. There is a low cost 8 coin option if required. Higher value notes can be stored securely under the coin inserts and a software lock provides extra security.

Classic Bluetooth Connectivity

Choose the mobile device of your choice – Android, Apple, Linux or Windows tablet / smartphone for simple Bluetooth pairing. The mPOP LED display will quickly let you know pairing status as well as any issues such as paper out etc.

Compact, mobile POS design for the

retail environment is further enhanced by the need for just one single mains cable for all mPOP functions. One or two external device chargers are included as well as the Star scanner which can be included at purchase or bought at a later date. USB connectivity ports are neatly positioned in a recess in the base of the unit, offering quick and easy access as well as providing its own secure cable management… simply plug in and go!

Security – a secure counter clip is supplied to help protect the mPOP unit

when used above the counter along with the 3rd party Kensington under-counter mount kit option will enable you to position the mPOP unit in a more secure environment if preferred.

lock facility. The

In the box at purchase:

 mPOP can be purchased with

the plug and play Star scanner, or this can be added as a later option

 For immediate set-up, a

complementary stand is included. Options for one or two devices could provide both customer & retailer displays if allowed by software. Or alternatively, choose a 3rd party stand to match the secure VESA mount screw-down option

 Secure clip for mounting to

retail station counter

 Kensington

lock facility for enhanced security using a wide range of compatible 3rd party locks

Options include:

 Plug and play Star scanner  Under-counter mount kit

mPOS

PERIPHERALS

mPOP Specifications

Two versions available: 1. With Star Scanner 2. Without Star Scanner (Star scanner can be purchased as an option)

Print Method

Printer

Print Speed 100mm/sec mPOP Case Colour White & Silver / Black & Silver

Cutter Guillotine Interface Bluetooth 2.1 & USB

Width 58mm Status LEDs Yes (Power, Error, Bluetooth Status, etc.)

Roll Diameter 50mm Operating System iOS / Android / Windows

Paper

Paper Thickness 53μm – 75μm Emulation Star Line Mobile Mode

Print Area 54mm or 48mm (software adjustable)

Paper Load Drop In / Front presenta tion

Notes & Coins

Cash Drawer

Lock Key

mPOP Options • Wired Star BarCode Scanner • Under Counter Mount kit • 3rd Party VESA Stand Fixing Base

Included in mPOP Box • Simple double sided stand • mPOP fixing tool • AC cable • Paper roll • BCR (with scanner version)

2" Direct Thermal

with Front Loading Design

4 upright note holders & 6 coin slots

(8 slot option)

Software controlled lock with

emergency lock release

Internal Power Supply

USB Port

Sensors Cover open, PE

External Dimensions

1 Slave USB Port, 2 x 0.5A USB Host,

2 x 1.5A USB Host for external device

Energy Star

charging / peripherals

308 x 300 x 100mm (w x d x h)

3.5kg

 Secure VESA mount for industry

standard 3rd party device stands

 3rd party Kensington

lock

NEW

Digital Receipt Service

Star Developer Tool – Star Cloud

Service’s Digital Receipting Service is available for easy

integration using Star’s SDK from

www.starmicronics.com/support

See page 8 or contact Star for more details.

STAR CLOUD SERVICES

Page 8

“Star’s ever

NEW

expanding

FREE DIGITAL RECEIPTING SERVICE uses the Cloud and

AllReceipts

mobile App to bridge the gap between the retailer & shopper.”

Star Digital Receipt Service

is available on Star counter top thermal receipt & mobile printers.

• TSP100 using futurePRNT driver for

Windows

• TSP654II, 743II, 847II, FVP10 Series via

Windows StarPRNT Intelligence driver

• mPOS iOS & Android available within

the Star SDK for Star Developers for counter top printers as above and Star’s mobile printer range.

All drivers available at:

www.starmicronics.com/support

Check with Star for latest list of software integrators.

Digital Receipt Service

from

The NEW, FAST & LOW COST ROUTE to DIGITAL RECEIPTING for Retailers

Star Digital Receipt Service is FREE-OF-CHARGE, simple to install and works “above”

the retailer’s software. All you need is a Star printer linked to the internet to send an image of the receipt and coupon to the AllReceipts App on your customer’s phone – no email

address required!

Valuable Promotional & Cloud based Reporting Tools for Retailers have also been included, plus:



NEW Receipt Flip Tool providing the opportunity to upload four colour promotions /

images / terms and conditions to the customer’s smartphone as normally available on the reverse side of a receipt except the retailer can now change these images as and when required without cost.



NEW Engage NOW Tool allowing retailers to communicate with customers despite the

anonymity advantages. Retailers can link their logo on the AllReceipts App on the customer’s smart phone dynamically to their choice of web page for further customer interaction – welcome discounts, promotions etc., changeable as and when required.



Star’s Device Management Tool provides real time status across the installed base of

printers including different locations with refreshed error status notification on a comprehensive cloud based dashboard.



“Instant” Customer Satisfaction Survey which the customer completes while

“claiming” the receipt.



Increased Coupon Redemption customers will no longer have to remember receipts

and will be grateful you have made the coupon so simple to use, including checking redemption dates.

STAR CLOUD SERVICES

Contact Star for more details at Sales@Star-EMEA.com

RECEIPTS

c 2014

ec 20

ec 2014

8 De

11 Dec 2014



Zero development is needed as all of the above is enabled within the Star printer driver

12 Dec 2014

13 Dec 2014

2014

15 Dec 2014

14 Dec

132

120

100

2014

8 De

9 De

FEEDBACK

014

2014

c 2014

0 De

11 De

12 Dec 201

GroupedStacked



014

Dec

DEVICE MANAGEMENT

New Device

Name Identifier Status

Printer 1 000780676E6F Printer Ready

Printer 2 00078078B6A3 Offline

Dec 5

user_name

and is triggered by printing a traditional receipt. Working independently of a retailer’s existing POS software, it automatically generates and securely sends an image of the receipt, coupon, full colour flip image & Engage Now URL (where relevant) to the cloud until claimed.

AllReceipts App

ANDROID APP ON

Available NOW!

Star’s Digital Receipt Service is subject to local country legislative requirements and is available in English, Finnish,

French, German, Portuguese & Spanish for Europe, South Africa, South & North America.

Page 9

TSP100 Introduction

Setting new standards for POS printing technology, Star’s best selling printer worldwide, the TSP100, is the first software-driven POS receipt printer to provide an immediate plug & play application. This allows retailers to tailor and continuously modify all aspects of receipting output to meet their individual needs.

Advanced features such as receipt re-design, electronic journal, print-on-demand, graphic dependent multi-copy receipting and automatic text reduction are also included as simple tick-box changes.

The unique TSP100 set-up utility reduces integration time to minutes as it can simply mirror individual printer settings to multiple units in different locations, if required. The printer does not have to be taken out of the box for pre-installation. This is all achieved outside of the core POS software, providing endless possibilities.

TSP100

futurePRNT

NEW

to match today’s mPOS mobile devices.

Ultra White versions

NEW

TSP143III WLAN

is the latest model from Star’s renowned TSP100 Series used by retailers and restaurateurs across the globe, from major retailers and fast food restaurants, to your local corner shop and café.

The TSP143III WLAN offers simple, yet effective wireless communication, supporting 802.11b/g/n (2.4GHz) with an easy-to-use and ready to go WPS setup.

RETAIL

 Point-of-Sale  Retail Couponing

HOSPITALITY

 Table Receipting  Hotel Invoicing  Kitchen Printing

DELIVERY LOGISTICS

– and so much more.

WiFi

READY

THERMALmPOS

The advantages of the TSP100 stretch from the retailer, POS reseller to the system integrator.

TSP100 – Product Range

NEW

TSP100 U / GT TSP100ECO TSP143III LAN TSP143III Wireless LAN TSP143IIIBI Bluetooth

Model Summary

Key Features

Digital

Receipt

TSP143U – 125mm/sec. USB Autocutter model. Available in Charcoal Grey or Star White TSP143GT – 250mm/sec. USB Autocutter model. Available in High Gloss Piano Black & Star White

• Easy-Load “Drop-In & Print” paper loading

• Unique futurePRNT software included with Mass Install Tool so you do not need to take the printer out of the box to install. All the settings are held on the PC!

TSP143ECO – 150mm/sec. USB Autocutter model. Available in Black, Star White & NEW Ultra White

• Easy-Load “Drop-In & Print” paper loading

• Unique futurePRNT software included with Mass Install Tool so you do not need to take the printer out of the box to install. All the settings are held on the PC!!

TSP143IIILAN – 250mm/sec. Ethernet Autocutter model. Autocutter Life: 2 million cuts. Available in Black & NEW Ultra White

• Unique Ethernet Print on Disconnection Feature

• Easy-Load “Drop-In & Print” paper loading

• Unique futurePRNT software included with Mass Install Tool so you do not need to take the printer out of the box to install. All the settings are held on the PC!

TSP143III WLAN – 250mm/sec. Wireless 802.11 b/g/n (2.4GHz) Autocutter model. Autocutter Life: 2 million cuts. Available in Black & NEW Ultra White

• WLAN cable-free interface

• Unique Print on Disconnection Feature

• Easy WPS set-up

• “Drop-In & Print” paper loading

• THIN paper capability (0.053 to

0.085mm)

• Unique futurePRNT software with Print on Demand ECO feature

Service

NEW FREE-OF-CHARGE Digital Receipting using Star’s AllReceipts App – see page 8 for details

What’s in the box

Optional extras

• USB Cable

• Internal Power Supply with 1.8m Power Cord

• Wall Mount Bracket Vertical Mount Accessory

•

• 58mm Paper Guide

• Power Switch Cover

• Installation CD and Value-Added Software

• Splash Proof Cover

• Display Stand for vertical use

4 Year Warranty on all models within the TSP100 futurePRNT Series including print head and cutter

• USB Cable

• Internal Power Supply with 1.8m Power Cord

• Wall Mount Bracket Vertical Mount Accessory

•

• 58mm Paper Guide

• Installation CD and Value-Added Software

• Splash Proof Cover

• Display Stand for vertical use

• LAN Cable

• Internal Power Supply with

1.8m Power Cord

• Wall Mount Bracket

• Vertical Mount Accessory

• 58mm Paper Guide

• Power Switch Cover

• Installation CD and ValueAdded Software

• Splash Proof Cover

• Display Stand for vertical use

• WiFi Power Pack

• Internal Power Supply with

1.8m Power Cord

• Wall Mount Bracket

• Vertical Mount Accessory

• 58mm Paper Guide

• Power Switch Cover

• Set-up Instructions

• Splash Proof Cover

• Display Stand for vertical use

Full specifications on page 35 or www.futurePRNT.com

NEW

WiFi

TSP143IIIBI – 250mm/sec. Bluetooth Autocutter model. Autocutter Life: 2 million cuts. Available in Black & NEW Ultra White

• iOS (Apple iPad) automatic recognition for AutoConnect after power on or out of range situation

• Easy-Load “Drop-In & Print” paper loading

• Unique futurePRNT software included with easy-to-use, “instant” coupon and voucher creation software tools (see page 10)

• SDKs for integration at

www.starmicronics.com/support

• Internal Power Supply with

1.8m Power Cord

• Wall Mount Bracket

• Vertical Mount Accessory

• 58mm Paper Guide

• Power Switch Cover

• Set-up Instructions

• Splash Proof Cover

• Display Stand for vertical use

(Europe and South Africa)

Page 10

THERMAL

mPOS

“Giving retailers and restaurateurs powerful and invaluable marketing tools at their disposal that work on top of their current POS software.”

TSP100 options:

CB2002 Cash Drawer

ECO black, Ultra white or standard white version for TSP654II Series

Vertical Desk Stand Splash Proof Cover

futurePRNT software

Star’s futurePRNT™free-of-charge, value-added software far exceeds installation tools normally provided, enabling users to install high volume, custom set-ups without even taking the printer out of its box.

Pre-Installation Software

All settings are stored on the PC removing the need to pre-configure the printer itself. Time and maintenance savings are the key reasons why the TSP100 is the printer of choice, used by so many high profile retailers. Please ring Star for more details.

Star futurePRNT software is supplied in the box in 18 European languages from Croatian to Norwegian.

Create branded and motivating receipts to inspire customers with futurePRNT’s Receipt Redesign Tools including:



Image Import Tool for any size mono or colour BMPs, JPEGs or GIFs



Receipt Pre-View Tool



Receipt Cropping Tool, Font Replacement Tool, Coupon Marketing Tool and Text Trigger Tool all work

independently of current retail software allowing customers to pre-determine words to “trigger” coupons and graphics



Journal and Multi-Copy Tool – provides up to four copies with individual text and graphics per copy – perfect for DIY stores, fast food outlets etc.



Auto-Text Reversal™Tool – for vertical / wall mount use



Dedicated futurePRNT SDKs – Star’s futurePRNT software is accompanied by a dedicated Software Developer Kit with a wide range of tools available, allowing the system designer to take advantage of the TSP100’s software and hardware features

STAR PIZZAS

Date: 17/09/16 14.46 Your server: Jane

1 x Peroni £4.50 1 x Coke £4.25 1 x Four Seasons Pizza £14.50 1 x Siciliana Pizza £14.00 1 x Green Salad £8.00 1 x Caesar Salad £8.50

Change the “look” of your receipts without changing your software!

Sub Total: £53.75

Card Number ************2112 Expiry Date 09/18 Merchant ID 5150345 Authorisation Code 034765

Visa Sale £53.75

Total: £53.75

Star Pizzas

Date: 17/09/16 14.46 Your server: Jane

1 x Peroni £4.50 1 x Coke £4.25 1 x Four Seasons Pizza £14.50 1 x Siciliana Pizza £14.00 1 x Green Salad £8.00 1 x Caesar Salad £8.50

Card Number Expiry Date 09/18 Merchant ID 5150345 Authorisation Code 034765 Visa Sale £53.75

FREE Ice Cream!

Star Pizzas

Date: 17/09/16 14.46 Your server: Jane

1 x Peroni £4.50 1 x Coke £4.25 1 x Four Seasons Pizza £14.50 1 x Siciliana Pizza £14.00 1 x Green Salad £8.00 1 x Caesar Salad £8.50

Sub Total: £53.75

Total: £53.75

Card Number

✳✳✳✳✳✳✳✳✳✳✳✳

Expiry Date 09/18 Merchant ID 5150345 Authorisation Code 034765 Visa Sale £53.75

FREE Ice Cream!

Chill out with a FREE ice cream on us! If you spend £25.00 with us on your next visit, just present this voucher and claim Free Ice-Creams for your entire party!! Offers ends 31/12/16

Star Pizzas

✳✳✳✳✳✳✳✳✳✳✳✳

Chill out with a FREE ice cream on us! If you spend £25.00 with us on your next visit, just present this voucher and claim Free Ice-Creams for your entire party!! Offers ends 31.12.2016

2112



2112

ESC/POS

Sub Total: £53.75

Total: £53.75

Star Pizzas

Offers ends 31/12/16 Free Ice-Creams for your entire party!! visit, just present this voucher and claim If you spend £25.00 with us on your next Chill out with a FREE ice cream on us!

✳✳✳✳✳✳✳✳✳✳✳✳

Total: £53.75

Sub Total: £53.75

2112

FREE Ice Cream!

Visa Sale £53.75 Authorisation Code 034765 Merchant ID 5150345 Expiry Date 09/18 Card Number

1 x Caesar Salad £8.50 1 x Green Salad £8.00 1 x Siciliana Pizza £14.00 1 x Four Seasons Pizza £14.50 1 x Coke £4.25 1 x Peroni £4.50

Your server: Jane Date: 17/09/16 14.46

Star Pizzas

NEW

TSP100 U / GT TSP100 ECO

NEW

View and store receipts / coupons on your customer’s phones at no charge

Digital Receipt Service

STAR CLOUD SERVICES

Star’s Digital Receipting Service with AllReceipts Customer App – now included

TSP143IIILAN TSP143III Wireless LAN

The fast, secure and easy route to digital receipting

NEW

ANDROID APP ON

in the printer driver and FREE to retailers and customers with analytics and new coupon / full image notification tools

– see page 8 for more information.

Just download the AllReceipts App or register at www.starcloudservices.com

4 Year Warranty on all models within the TSP100 futurePRNT Series including print head and cutter

NEW

TSP143IIIBI Bluetooth

(Europe and South Africa)

Page 11

TSP100ECO futurePRNT

Providing low cost printing with superior quality, the TSP100ECO offers unique paper saving features that could help retailers use up to 70% less paper. This not only reduces paper consumption but means less frequent paper roll changes at the checkout, lower transportation and logistics costs.

11mm 3mm default

Paper Saving Tools



Unique Partial Cut 3mm Default Top Margin



Receipt Auto Reduction – automatically reduce the length and width of receipts without changing the customer’s original software set-up. With simple tick commands the TSP100ECO software can reduce the size of receipts by up to 72.5% horizontally and 50% vertically.

80mm

Food doesn’t get any fresher

5 The Square, Middletown, MT2 5RT

VAT No: 123 4567 89 Tel: 01986 1234569

White Mushrooms 1.29 Smoked Salmon 4.99 Baked Beans in Tom Sauce 840g 1.25 Macaroni Cheese 400g 0.93 Gazpacho Soup 745g 3.39 Echo Falls Shiraz 75cl 5.49

100%

After Shave Conditioning Gel 3.49 Fairtrade Bananas 0.99 Organic Skimmed Milk 1L 0.99 Soya Light Milk 1L 1.28 6 Yorkshire Puddings180g 3.39 Chicken Stock 2.48 Arborio Risotto Rice 500g 2.96 Egg Noodles Medium 300g 1.21 Giant Couscous 300g 1.99 Extra Virgin Olive Oil 1L 7.39 Chocolate Malt Syrup 623g 3.89 Dried Organic Basil 12g 1.89

Reduce your receipts and paper usage without

changing your current POS Software.

White Mushrooms 1.29

Smoked Salmon 4.99 Baked Beans in Tom Sauce 840g 1.25 Macaroni Cheese 400g 0.93 Gazpacho Soup 745g 3.39 Echo Falls Shiraz 75cl 5.49

75%

50%

80mm

Food doesn’t get any fresher

5 The Square, Middletown, MT2 5RT

VAT No: 123 4567 89

Tel: 01986 1234569

Original Font Size

58mm

Food doesn’t get any fresher

5 The Square, Middletown, MT2 5RT

VAT No: 123 4567 89 Tel: 01986 1234569

White Mushrooms 1.29 Smoked Salmon 4.99 Baked Beans in Tom Sauce 840g 1.25 Macaroni Cheese 400g 0.93 Gazpacho Soup 745g 3.39 Echo Falls Shiraz 75cl 5.49 After Shave Conditioning Gel 3.49 Fairtrade Bananas 0.99 Organic Skimmed Milk 1L 0.99 Soya Light Milk 1L 1.28 6 Yorkshire Puddings180g 3.39 Chicken Stock 2.48 Arborio Risotto Rice 500g 2.96 Egg Noodles Medium 300g 1.21 Giant Couscous 300g 1.99 Extra Virgin Olive Oil 1L 7.39 Chocolate Malt Syrup 623g 3.89 Dried Organic Basil 12g 1.89

Greene& Brown’s

THE ORGANIC PROVISIONS PEOPLE

Date: 17/09/16 20.26

1 x Marmalade £3.00 1 x Fish Pie £4.80 2 x Miso Soup £3.50 1 x Veg Gyoza £2.50

Retailer Tip: Many competitors cannot achieve a 3mm Top Margin and may lose the retailer’s logos when changing the paper. Retailers should always check the margins very carefully when comparing competitive POS printers.

TSP100ECO Power Management

Star has designed the TSP100ECO to correspond directly with the PC it has been attached to. The printer will only be activated when attaching the included USB cable to the printer and PC / terminal and the PC / terminal is powered, otherwise it will remain in standby mode.

Star’s power efficient method means the printer will revert with the PC to a very low powered standby mode when not in use, “instantly” waking up when needed, saving costs and power usage.

“TSP100ECO futurePRNT tools & features could reduce paper consumption by 70% or more.”

Greene& Brown’s

THE ORGANIC PROVISIONS PEOPLE

Date: 17/09/16 20.26

1 x Marmalade £3.00 1 x Fish Pie £4.80 2 x Miso Soup £3.50 1 x Veg Gyoza £2.50 1 x Cider £3.50 1 x Organic Ale £3.20 1 x Sourdough £3.65

THERMAL

mPOS

72.5%



Receipt Printing on Demand – using its Operator Prompt function the TSP100ECO futurePRNT software prompts the retailer as to whether a receipt is required. The receipt can then either be cancelled or printed providing the perfect solution for low cost consumables where receipts are not essential. All cancelled receipts can be saved graphically and be reviewed or reprinted. (Note: Not all countries will

allow this feature so the software may be modified on a regional basis). Also available on TSP143III WLAN.

Typical Retail Power Usage

18 Hour Day / 12 Hour Day Results

Typical Power Consumption Scenarios:

A. POS System-On Mode: 18 hour day – 26.8 kWh

B. POS System-On Mode: 12 hour day – 19.11 kWh

No competitor today can match this.

Just ask Star for comparative details.

(Estimated power consumption based on evaluation results by

Star Japan R&D, using Hioki 3332 POWER HiTESTER for

300 x 150mm receipts per day, 365 days a year for 5 years.)

Full specifications on page 35 or www.futurePRNT.com

4 Year Warranty on all models within the TSP100 futurePRNT Series including print head and cutter

(Europe and South Africa)

Page 12

“Entry level, ergonomic

THERMAL

receipt printer fits

TSP654II Series

seamlessly into the majority of Hospitality, Retail and Kiosk environments.”

TICKETING

RETAIL

 Retail Couponing  Point-of-Sale Receipting

KIOSK / TERMINAL

HOSPITALITY

 Hotel Invoicing  Table Receipting

mPOS

KIOSK

…and so much more.

Entry Level, 300mm/second POS Receipt Printer

 Fast single station transaction receipt printer

producing receipts and tickets at 300mm/sec.

 High resolution print output 203 dpi with

standard and 2D barcode support

 Energy Star Certified including PS60  Near end sensor for horizontal and vertical use  Ergonomic design with optional splash proof

cover

 Star AutoLogo™feature to independently add

logos and coupons to receipts

 Easy “Drop-In & Print” paper loading  User friendly, interchangeable plug-in

interfaces allow for easy system upgrades

 NEW Digital Receipting available (see page 8)

Tablet Connectivity options:

 NEW Star CloudPRNT Printing “Plug-In”

interface option for simple WiFi / LAN / Remote printing anywhere in the world (IFBD-HI01X)

Interface versions available:

 TSP654II Non Interface, available in

White / Grey & NEW Ultra White models

 TSP654IID Serial, available in White / Grey  TSP654IIC Parallel, available in White / Grey  TSP654IIE Ethernet, available in Grey  TSP654IIU USB, available in Grey  TSP654IIBI  NEW TSP654II CloudPRNT – upgrade with

the new HI X Connect interface (IFBD-HI01X) or buy the dual LAN / USB printer with Star CloudPRNT technology version (see page 13)

Included in Box at purchase:

Set-Up CD-ROM, wall mount kit, power switch cover, sample paper roll

Options available:

S60 Power Supply, Splash Proof Cover, Vertical Desk Stand

Bluetooth, available in White / Grey

TSP654II options:

CB2002 Cash Drawer

ECO black, Ultra white or standard white version for TSP654II Series

Vertical Desk Stand

Splash Proof

Cover

NEWS …

All TSP654II models will include Star PS60 Power Supply free-of-charge.

(TSP654SK not included)

Page 13

TSP654IIBI Bluetooth

Market’s First, High Performance, Entry Level iOS Compatible Bluetooth Desktop Printer with Cash Drawer Support

ANDROID APP ON

 Switches easily from Apple iOS Bluetooth to

Android

 Out-of-the-box wireless desktop printing

solution

 Apple MFi Certified – Pairs with iPad, iPhone,

iPod Touch as well as all Bluetooth Devices supporting Serial Port Profile (SPP)

 AutoConnect feature will reconnect to the last

host after power on or out of range situation

 Compatible with major operating systems

including Apple iOS, Android, Windows, Linux handheld devices allowing the user to seamlessly migrate to another operating system, if required

 Demo apps available on Google Play and

iTunes stores

 Star WebPRNT Browser for direct web printing

from a web page from Google Play or App Store

“Combining high performance and reliability, the TSP654IIBI iOS compatible Bluetooth Desktop Printer is designed to work with Apple iOS, Android, Windows, Linux or any operating system enabled

THERMAL

TICKETINGKIOSK / TERMINAL

TSP654II CloudPRNT

NEW

LAN / WiFi remote printing direct from your web server to any printers anywhere in the world

 Out-of-the-box CloudPRNT internet connection

through WiFi or LAN with remote document printing from your web server. Perfect for restaurant aggregation, warehousing etc.

 WiFi Ready using a compatible, locally sourced

USB WiFi dongle matching the customer’s preference and budget

 Dual Interface USB / LAN  Star’s previous WebPRNT LAN platform

independent HTML / JavaScript printing from the Web included free-of-charge, along with Star’s AllReceipts Digital Receipting platform

 Peripheral Ready no PC required peripheral use

including scanners with 2 USB host ports

TSP654SK Re-Stick

The variable length alternative to traditional labelling

 The Thermal Post-It™note solution for the POS

market providing the ideal “Re-Stick” customer labelling solution for Pizzerias, Take-Out, Cafés, Promotional Couponing, Special Fast Food Orders etc.

 Reduced speed version of TSP650 designed to

work with self-adhesive media. Contact Star for list of approved suppliers

 Environmentally friendly labelling with increased

percentage of labels available per roll when compared to traditional methods

handheld device.”

Digital Receipt Service

STAR CLOUD SERVICES

AllReceipts

“The TSP654SK Re-Stick designed to work with liner-free labelling applications.”

Full specifications on pages 33 & 35 or www.Star-EMEA.com

printer is

mPOS

Page 14

“NEW plug-in CloudPRNT

THERMAL

interface enabling multiplatform remote Web printing with Star’s Digital Receipting Service & AllReceipts App.”

NEW

HI X Connect Interface for Star TSP654II, TSP743II, TSP847II & SP700

Cloud ready for hospitality,

retail and logistics!

mPOS

MATRIXMOBILE

Reseller Tip:

Low cost, easy & simple

to use! Retailers can install multiple platforms according to system requirements and expect the same outstanding results.

LOGISTICS

 Web-Based Labelling for Couriers

RETAIL

 Queue Busting  Stock Checker  Mobile Receipting  Cloud-Based POS

HOSPITALITY

 Cloud-Based Hotel Check-In

Applications

 Web-based Ticketing  Cable Free Kitchen Printing

– and so much more.

WiFi

READY

Dual

PERIPHERAL

READY

Star’s new CloudPRNT technology allows remote printing directly and securely from your web server to printers anywhere in the world without complicated network configurations – perfect for restaurant aggregation etc. Just purchase a HI X Printer or upgrade your current Star direct thermal TSP654II, TSP743II, TSP847II or matrix SP700 and your Cloud services will take control. This intentionally simple solution will have support documentation at www.starmicronics.com/support

Star’s Digital Receipting platform & AllReceipts App will allow you to log into the printer interface to automatically upload all receipts and coupon images to Star’s Cloud Services for customers to download to their mobile device by simply scanning the automatically generated QR code.

WiFi Ready using a compatible, locally sourced USB WiFi dongle matching the customer’s preference and budget. Approved dongles can be found at www.star-emea.com/products/hixconnect

 CloudPRNT Interface option: HI01X for TSP654II, TSP743II, TSP847II. HI02X for SP700

Star’s LAN platform independent WebPRNT solution is designed to generate print data via a web browser to output directly to any Star printer fitted with a WebPRNT interface or using Star’s WebPRNT Browser available from GooglePlay or the App Store (IFBD-HE07X / HE08X)

PORT

LAN USB

Printers able to use HE07X / HE08X Plug-In Interface solution:

 TSP654II Series  TSP700II Series  TSP800II Series  SP700 Series  FVP10 Series (BE07X)

Printers able to use Star WebPRNT Browser:

 Star Bluetooth Mobile range – SM-L200, SM-S220i,

SM S230i, SM-T300i, SM-T400i

 Star Thermal Bluetooth range, including – TSP654IIBI,

TSP743IIBI, TSP847IIBI, SP742BI, FVP10 BI

AllReceipts

Digital Receipting

™

(HE08X)

Safari

ANDROID APP ON

Chrome

FileMak er®

Introducing PassPRNT from

NEW

Star Micronics, a sophisticated print data relaying application available for Android & iOS with Windows

PassPRNT effectively receives data from an application such as Filemaker Go or any web browser

including Safari / Chrome using a URL scheme to then print on a Star Bluetooth, LAN / WLAN or USB printer. Star PassPRNT supported models include:

58mm Mobile models: SM-L200, SM-S220i, SM-S230i 80mm Mobile models: SM-T300i 80mm Desktop models: FVP10 (Bluetooth / USB / LAN), TSP100III (WLAN / LAN),

TSP654II (Bluetooth / USB / LAN), TSP743II (Bluetooth / USB / LAN) –

Receipt, Label & Ticket up to 0.15mm thick media

112mm Mobile models: SM-T400i 112mm Desktop models: TSP847II (Bluetooth / USB / LAN) – Receipt, Label & Ticket up to 0.15mm

thick media…with other Star printer models to follow.

Star’s PassPRNT companion App allows printing to both ranges of Star Mobile & Desktop printers from a web browser or any application supporting the URL scheme. The simple and user-friendly “one tap” request to print from an device to a Star printer is now possible. The operating system is capable of automatically switching from a host application to the PassPRNT application making this a valuable, time–saving tool for any system integrator / developer.

NEW PDF print and Black Mark capability from early Qtr 4 2016 with Star’s Digital Receipting platform AllReceipts included.

Star Micronics’ PassPRNT is now available on Google Play and the App Store.

to follow

Page 15

“Multi-Functional undercounter printer, with front operation, offering a new method of user and printer interaction with unique voice communication tool.”

Reseller & Retailer Tip:

The FVP10 features a

dual interface facility with USB as standard and additional port for second plug-in options – Serial, Parallel, Ethernet, WebPRNT.

LABELS & TICKETINGKIOSK / TERMINAL THERMAL

FVP10 Series

The World’s Only Front Operating, Under-Counter Thermal Receipt and Label Printer

 High quality 203 dpi output combined with

speeds of up to 250mm/second

 High reliability – (60 million lines MCBF)  Unique front loading drawer with easy

“Drop-In & Print” paper loading

 Tough and durable splash proof casing with

IPX1 certification and downward angled paper exit to prevent liquid intake

 Intuitive square design provides space-saving

opportunities on and below the counter

 Black mark sensor support for barcodes,

receipts, labels & tickets

 58 – 80mm fully adjustable paper widths

Features like Unique Drawer Paper Loading and “Drop-In & Print” Easy Load have made the FVP10 the “Receipt

Printer of Choice” for

well-known Fast Food retailers, as well as luxury brands – contact Star for more details.

 Full audio capability with line-out option for

external speakers

 NEW Digital Receipting available (see page 8)

Interfaces available:

 FVP10U – Built-in USB with Parallel,

Serial (BD03) & Ethernet (BE07X) options

 WiFi option available, see page 25 for more

information on the Star WiFi Power Pack

 Star WebPRNT Printing – “Plug-In” interface

solution for simple Web printing

NEW FVP10BI Bluetooth version for Apple

iOS, Android & Windows (MFi certified)

The FVP10 offers compact shelving opportunities with the Shelf mount option and power supply holder

FVP10 options:

CB2002 Cash Drawer

New grey or white versions

Under Shelf Mount

option with power supply holder

Providing additional flexibility, why not upgrade your current FVP10 in the following ways:



Star WiFi Power Pack – low cost accessory, providing simple WiFi printing directly from Smartphones, Tablets, PCs or any other mobile device to a Star FVP10 printer. For more information, see page 25



WebPRNT – add Star WebPRNT plug-in interface BE07X option for simple web printing. For more information on the benefits of Star WebPRNT, see page 14

FVP10 “Plug-in” 2nd interface

option

Full specifications on pages 33 & 35 or www.Star-EMEA.com

Page 16

“Star’s intuitive design

THERMAL

allows users to change its interface efficiently, allowing the upgrade of a POS system without the need to upgrade the printer.

RETAIL

 Point-of-Sale Transactions

LABELS & TICKETING

 Shelf Edge Labels / Product Labelling

HOSPITALITY

 Table-Service  Kitchen Printing

DELIVERY LOGISTICS

 Reports  Parts Lists  Delivery Receipting  Product Labelling

KIOSK

 Remote Printing

TRADITIONAL / mPOS TICKETING

 Event Ticketing  Lottery Printing

”

TSP700II Series

The World’s Only High Speed 80mm wide Barcode, Label, Receipt and Ticket Printers

KIOSK / TERMINAL mPOS

Combining speed, reliability and ease-of-use, the TSP700II multifunctional 80mm printer produces high resolution graphics and barcodes for tickets, receipts and labels

 Fast single transaction receipt printer capable

of producing barcodes, labels and tickets at 250mm/sec.

 Large paper roll capacity, diameter 100mm

(offering up to 60% more paper than a standard 80mm roll)

 “Drop-In & Print” easy paper loading  Full or partial cut AutoCutter (centre tab) life

2 million cuts

 Ergonomic splash resistant design with

easy-clean (case) and Splash Proof Cover available

 Double Density (406 x 203 dpi) for high quality

graphics, 1D & 2D barcodes etc.

 Compatibility with all major operating platforms

with a comprehensive suite of drivers including Microsoft WHQL certification for seamless USB integration

 NEW Digital Receipting available (see page 8)

Tablet Connectivity options:

 Star WebPRNT Printing – HE07X “Plug-In”

Interface option for simple Web printing or Star WebPRNT Browser available from App Store or Google Play (see page 14)

Interface versions available:

 TSP743IID Serial Interface  TSP743IIC Parallel Interface  TSP743IIU USB Interface  TSP743II Non-interface version for use with

low cost Ethernet (HE07) / WebPRNT (HE07X) options

 WiFi Option available, see page 25 for more

information on the Star WiFi Power Pack

 NEW CloudPRNT “Plug-In” HI01X interface

for remote web printing anywhere (see

option page 14)

NEW TSP743IIBI Bluetooth grey version now

available with unique Auto Connect facility

TSP700II DRIVER / ADVANCED CONFIGURATION UTILITY

• The “Image List” allows users to name and

import multiple file types without having to use an external image editing utility. This is particularly useful for single users to prepare an image (size, shade, pixel output) and then test print it to check the final quality

• NV logo allows users to quickly and easily

download logos to the printer

• Ability to change Memory Switches in an

easy-to-use graphical user interface

• The new built-in Ethernet Set-up feature

avoids having to download a separate utility

• Auto-Text Reverse for vertical use is

available from the Device settings menu in raster mode

• Intuitive simple set-up provides

compatibility with all Star single station printers

Barcodes, labels, receipts and tickets all from one model

Accessories included in box with printer at purchase: Driver CD, Wall Mount Kits, Interface & Power Switch Covers

Page 17

TSP800II

TSP800II Series

The World’s Only High Speed 112mm wide Barcode, Label, Receipt and Ticket Printers

Providing unique versatility and cost effectiveness, the TSP800II series is capable of printing on wider than average media up to 112mm with an automatic A4 raster driver scaling A4 images onto A6

 180mm/second Barcode, Label, Receipt and

Ticket Printer with Autocutter as standard

 Wide 4" (104mm) print width – on paper stock

up to 0.15mm thick. Paper guide for 80mm paper roll printing

 Internal or External paper feed paths (external

for large capacity or fanfold applications)

 “Drop-In & Print” easy paper loading

Compact footprint with vertical “Desk Boot” and



Wall Mount options – ideal for kiosk applications

 ESC/POS™compatible in Standard and “Super

Large” mode

 Automatic scalable raster driver for immediate

A4 reduction to A6

 NEW Digital Receipting available (see page 8)

Two in One – POS & A4 Replacement Printer

The TSP800II direct thermal printer can automatically print A4 output on 112mm wide paper simply by selecting the TSP800II scalable raster driver

Obvious advantages include:

 Lower running costs – TSP800II costs 90.47%* less to run than a typical laser printer  Compact printer footprint – at only 180 (w) x 213 (d) x 148 (h) mm valuable desk space saved  Faster to first page out and faster print speed than a typical laser at 180mm/second  Greener solution – less paper wasted due to variable paper length so scaled A4 pages are not used

for minimal print, less CO2output and power used

(*contact Star for more information on the latest statistics)

AUTOMATIC PAGE SCALING – A4 to A6

The TSP800II Scalable Raster Driver provides the ability to format a page or screen image in the same way as a standard PC printer and then print that image on 112mm wide paper up to 0.15mm thick.

All this at up to 180mm/second,

without the need for additional

software and zero warm-up time!

Interface versions available:

 TSP847IID Serial Interface  TSP847IIC Parallel Interface  TSP847IIU USB Interface  TSP847II Non-Interface version for use with

low cost Ethernet / WebPRNT

 WiFi option available, see page 25 for more

information on the Star WiFi Power Pack

 NEW CloudPRNT “Plug-In” HI01X interface

option

for remote web printing anywhere (see

page 14)

NEW TSP847IIBI Bluetooth grey version

now available with unique Auto Connect facility with WebPRNT Browser

A4 automatic scalable invoice feature is now in use in the UK’s largest and fastest-growing budget hotel brand, Whitbread’s Premier Inn with over 650 budget hotels

“The TSP800II offers approximately 90% lower running costs than a typical A4 laser printer offering the perfect printing alternative for end of day reporting, hotel invoicing, etc.”

RETAIL

 Point-of-Sale Receipting  End-of-Day Reporting  Pharmaceutical Prescriptions  Retail Couponing  Shelf Edge Labels / Product Labelling  Gift Certificates

HOSPITALITY

 Hotel Invoicing  Table Receipting

DELIVERY LOGISTICS

 Delivery Invoicing  Reports  Product Labelling – 112mm with auto

status

KIOSK

 Remote Printing

TRADITIONAL / mPOS TICKETING

 Event Ticketing  Lottery Printing

…and so much more.

Customer success:

The printer used by hotels

all over the world due to its 90% running cost reduction and CO2advantages compared to a laser printer – ask Star for more information.

NEW

Low cost HI X Connect interface option for TSP743II & TSP847II

Star’s CloudPRNT and Digital Receipt Service technology will

enable remote printing to Star printers anywhere in the world without complicated network configurations.

Digital Receipt Service

STAR CLOUD SERVICES

LABELS & TICKETINGKIOSK / TERMINALmPOS THERMAL



Full specifications on pages 33 & 35 or www.Star-EMEA.com

Page 18

THERMAL

LABELS & TICKETING

RECEIPTS

RECORDS

 Data logging  Measuring equipment

MOBILE PRINTING

 12 volt applications

LABEL PRINTING

 Sprocket version

GRAPHICS VERSION (details upon request)

DP8340 Reseller Tip:

Ink Ribbons needed

include Red / Black SF-03BR (800k Black / 400k Red character life) or Black SF-03B (800k character life). Note: two versions using either

4.5" / 114.3mm wide (0.09mm thick) sprocket fanfold or roll paper (outside roll diameter 80mm).

DP8340 Series

Unique 114mm wide report, receipt & data printer available for 12V or 24V usage in mobile, rugged or unattended environments

 Reliable 2 lines per second budget entry level

printer with tear bar (MCBF 10 million lines)

 Compact receipt / label / data output solution

202 (w) x 200 (d) x 98 (h) mm (w/o paper holder). Weight approx. 1.9kg

 Reliable  Black and Red printing  Separate 230V AC power supply with 12V DC

output

 In-vehicle power cable & wall mount options

available

Versions available:

 DP8340FD Serial Friction, Black / Red  DP8340FC Parallel Friction, Black / Red  DP8340SD Serial Sprocket, Black / Red  DP8340SC Parallel Sprocket, Black / Red

TSP1000 Series

TICKETING AND LOTTERY

 Lottery Application  Event Ticketing

LOGISTICS

 Warehouse Picking

HOSPITALITY

 Kitchen Printing

Customer success:

Sold to the Lottery Market

worldwide, the TSP1000 printed tickets across the US for the world’s largest lottery stake in history in 2012.

Full specifications on page 34 or www.Star-EMEA.com

Versatile Low Cost Thermal Printer with Receipt / Ticket Stacker and 18cm Paper Roll

Low cost and highly reliable, the TSP1000 Series offers high capacity ticket and lottery printing



High speed output – up to 180mm per second



“Drop-In & Print”, easy paper load



Large paper roll capacity (up to 180mm diameter) with adjustable paper low sensor



Ticket stacker fitted as standard (up to 30 tickets) with fitted sensor for software driven multiple or single print outs



Multiple paper width (45 – 82.5mm adjustable)



Guillotine cutter



Variable position, high quality black mark sensor

Interface versions available:

 TSP1043D Serial Interface  TSP1043C Parallel Interface  TSP1043U USB Interface  TSP1043 No Interface

Page 19

TSP-L10 Series

High Performance Printer for Secure Transactions including Coupon, Lottery & Ticketing with Internal Verification Scanner Option and 100 Ticket Stacker

Customer success:

Star’s domination of the

world’s lottery market for the past two decades has enabled Star to design the world’s best lottery printer on the market today.

TICKETING / LOTTERY

 Lottery Applications  High Sale Ticketing

RETAIL

 High Volume Point-of-Sale  Customer Loyalty Couponing

WARHOUSE / LOGISTICS

 Product Picking  Invoicing

LABELS & TICKETING THERMAL

The TSP-L10 is the latest Specialist printer to confirm Star’s market-leading position within the lottery printer market. Designed for Linux, the specialist features detailed below can all be integrated using an advanced, high security, custom API from Star

 High speed printing performance with high resolution 203 dpi output

and 16 shade Greyscale for accurate image printing

 Compact design with easy load 200mm diameter paper roll and ticket

stacker for up to 100 printed receipts / tickets

 Internal scanner for real-time ticket verification or complete / partial

journal

 High reliability, print head dot check and cutter damage prevention  Host terminal barcoding for all types of barcode  Star graphic mode emulation controlled by custom Star API  Energy Star certified

TSP-L10 low power consumption mode with dual USB and Ethernet interfaces and USB host

TSP-L11 with internal ticket scanner for verification / journaling

Interface versions available:

 TSP-L10UE 24V DC Grey USB / Ethernet

without internal Ticket Scanner

 TSP-L11UE 24V DC Grey USB / Ethernet

with internal Ticket Scanner

Reseller & Retailer Tip:

The TSP-L10’s unique

20cm high capacity paper roll allows for longer unattended ticketing and is ideal for high volume lottery sales.

Full specifications on page 34 or www.Star-EMEA.com

Page 20

MATRIX

HOSPITALITY

 Hotel Invoicing  Restaurant Receipting

RETAIL

 Point-of-Sale

PHARMACY

 Prescription Receipting

Customer Success:

The SP298 is the fastest

slip printer on the market, offering 9-pin quality and unique form Autoside Loading many applications worldwide.

™

for

SP298 Series

The World’s Fastest Slip Printer with Unique 9-Pin Printing

Compact, robust and reliable, the SP298 Series with its unique Autoside Loading™is ideal for printing cut sheet media such as pre-printed company branded multi part receipts or forms

 Rugged bi-directional printer capable of

graphics using a highly reliable 9-pin print head

 High reliability with helix head drive 9 million

lines MCBF

 Up to 3.1 lines per second with bi-directional

cheque mode

 Unique Autoside Loading™making document

loading quick, easy and reliable

 Ribbons: RC200B Black, RC200D Laundry  Power supply: Star PS60 option (24V)  Copy Capability: Original + two copies

 Paper Width / Length: up to 182mm / 80 to

257mm

 Margin Top / Bottom: 5 / 14mm

Print Width: 63mm

 Dimensions / Weight: 180 (w) x 190 (d) x

138.5 (h) mm / 2.1kg

Interface versions available:

 SP298 MD Serial Version  SP298 MC Parallel Version

RETAIL

 Point-of-Sale  Coupon Redemption  Cheque Printing

HOSPITALITY

 Hotel Invoicing  Restaurant Receipting

TICKETING

Reseller & Retailer Tip:

Combining high speed

203 dpi and 9-pin high quality resolution, the HSP7000 completes transactions quickly and efficiently.

HSP7000 – full specifications at www.Star-EMEA.com

HSP7000 Series

High speed, 203 dpi Thermal / Matrix 2 Station Hybrid Printer

Incorporating a high quality thermal printing mechanism, the HSP7000 Series offers high performance print resolution and superior print speed creating the perfect POS printer for printing cheques and receipts

 High speed 250mm/second thermal receipt

printer, combined with high speed 9-pin matrix cheque / validation printer

 “Drop-In & Print”, easy paper loading  High resolution 203 dpi output for fast,

superior quality logo / barcode receipt output

 Auto status back for paper loading, sensor

reporting etc

 Easy-to-use AutoLogo

independently add logos and coupons to receipts

 Ribbon: RC-7KB Black  Power supply: Star PS60 option (24V)  Dimensions / Weight: 186 (w) x 296 (d) x

177 (h) mm / 4.6kg

™

feature to

Models available:

 HSP7543 Hybrid Combination without MICR

(Non-Interface & USB versions)

 HSP7643 Hybrid Combination with top

position MICR (Non-Interface version)

 HSP7743 Hybrid Combination with bottom

position MICR (USB, Serial, Parallel & Non-Interface versions)

Interface options:

 Serial HD04, 9-pin Serial HN04, Parallel HC04,

USB HU06, LAN HE08 with WiFi Power Pack option

(MICR = Magnetic Ink Character Recognition, used in cheque-reading devices)

Page 21

SP700 Series

Advanced, High Speed, Red & Black Printing, Clamshell

™

Receipt Printer

One of the few matrix printers on the market to offer high speed 2 colour receipt printing

 High speed, 9-pin quality matrix printer –

up to 8.9 lps

 76mm default paper width  “Drop-In & Print”, easy paper and ribbon

 Splash resistant design with easy-clean

curves for robust kitchen / bar use

 Internal power supply with universal cable

included at purchase

 Graphic Management / Logo Store Driver

Tools

 Star platform agnostic WebPRNT “Plug-in”

interface option available (see page 14)

 Wall mount / desk boot option available  Dimensions: 160 (w) x 245 (d) x 152 (h) mm

Models available:

 SP712 Tear Bar Printer  SP742 Autocutter Printer  SP712R / 742R Rewind versions

NEW SP742BI Bluetooth grey version

now available with unique Auto Connect facility and Star WebPRNT browser App from GooglePlay or App Store

Interface versions available:

 NEW CloudPRNT “Plug-In” HI02X interface

 Serial HD04, 9-Pin Serial HN04, Parallel HC04,

for remote web printing anywhere (see

option page 14)

USB HU06, LAN with optional WiFi Power Pack HE08, WebPRNT HE08X

MATRIX

SP500 Series

Offering a Unique Unbeatable Price / Performance Ratio

 High performance, logic seeking, 9-pin quality

matrix printer – up to 7.5 lps

 “Drop-In & Insert” paper loading  Adjustable 58 or 76mm paper widths  6 position black mark sensor for fixed length

tickets



Ergonomic design including hygienic spill-proof

design and cable power switch covers

 Space saving vertical or horizontal operation  Compact footprint with internal power supply

and vertical operation

 Compatible ribbons: RC200B – Black  Options: Paper roll holder for wall mount

 Dimensions: 140 (w) x 225 (d) x 163 (h) mm

Models available:

 SP512 Tear Bar Version  SP542 Autocutter Version  UP542 Kiosk Version

Fixed Interface versions available:

 Serial / Parallel

Options available for Non-Interface SP500:

 Serial HD04, 9-pin Serial HN04, Parallel HC04,

USB HU06, LAN with optional WiFi Power Pack HE08

Reseller & Retailer Tip:

The SP500 and SP700 Series require the

following ribbons:

SP500 Options:

 RC200B Black Ribbon  RC200D Laundry Ribbon

SP700 Options:

 RC700B Black Ribbon  RC700D Laundry Ribbon  RC700BR

Ribbon

RETAIL

 Point-of-Sale Receipting

HOSPITALITY

 Hotel Invoicing  Restaurant Receipting

Red & Black Coloured

Full specifications on page 33 or www.Star-EMEA.com

Page 22

MOBILE mPOS

Digital Receipt Service

STAR CLOUD SERVICES

ANDROID APP ON

Mobile Printers

mPOS – designed to create the ultimate flexible checkout experience

From retail transactions to event management and logistics, our mobile printers are fulfilling receipting, ticketing and report applications for customers worldwide from Police speeding tickets in South Africa and the US to train tickets in Egypt and Italy. Star’s range of cost-effective wireless mobile printers offer both Bluetooth SPP as well as MFi connectivity and are designed to work with Tablets and Smartphones in a range of mPOS and Mobile Payment applications.

Star MFi – Made for iPad®, iPhone®& iPod Touch

As a registered Apple iOS and Android developer, Star has developed a range of dedicated MFi (made for iPad

, iPhone®& iPod Touch®– full explanation of MFi on back page)

Bluetooth printers. Star offers comprehensive Software Development Kits (SDKs) to allow the simple set-up of Star Mobile

™

Android

, Windows™and Linux™.

Printers with all major platforms including: Apple iOS™,

Star Success

Star WiFi / Apple iOS / Android Mobile Printers

 MFi Certified – pairs with iPad®, iPhone®and iPod Touch®as well as Bluetooth devices

using SPP with Wired Serial Connection / RS-232

 Compatible with major operating systems including Apple iOS

™

handheld devices supporting SPP / RS-232

Linux

™

, Android™, Windows™,

 Bluetooth (2.1: MFi Certified for iOS / SPP) and wired Serial connections

3" SM-T300DW

Rugged, 3" (80mm) Mobile Printer with Wireless compatibility



High resolution 203 dpi and 75mm/second print speed

 Ultra rugged with IP54 dust / splash proof

certification

 1.5m drop reliability 

STANDARD

COMPLIANT

IP54

Maximum 11 hour battery life, printing at 5 minute intervals

 SM-T301DW with 1&2 track magnetic stripe reader

version

Reseller Tip:

Star offers a number of

demo apps on iTunes and Google Play which provide instant Star mobile printer functionality. See page 4 to find out more.

Included at purchase

Options available:

NEW Mobile WebPRNT

SM-L200

• Battery

• Belt clip

• Paper sample roll

• USB cable for charging

• Desk dock charger

• Extra battery pack

Star WebPRNT Browser for direct printing from a web page using Star technology.

Download from GooglePlay / App Store or see page 14.

SM-S220i SM-S230i

• Battery • Belt clip

• Paper sample roll

• Power supply

• SM-S220i: Serial cable SM-S230i: USB communication cable

• 4 unit battery charger

• Single battery charger

• Extra battery pack

• Vehicle charger

SM-T300i SM-T400i

• Battery

• Belt clip

• Paper sample roll

• Power supply

• Serial cable

• 4 unit battery charger

• Shoulder strap

• Single battery charger

• Extra battery pack

• Vehicle charger

SM-T300DW

• Battery

• Belt clip

• Paper sample roll

• Power supply

• Serial cable

• 4 unit battery charger

• Shoulder strap

• Single battery charger

• Extra battery pack

• Vehicle charger

Page 23

2" SM-L200 with Label Facility

Bluetooth Smart, Low Cost 2" (58mm) BT/BLE Mobile Receipt & Label Printer



High resolution 203 dpi and 35mm/second print speed



Super compact design just 122 x 83 x 44mm & weighing 220g with the battery



Simple, no pin required auto pairing with Bluetooth 4.0 devices including Apple iOS, Android, Linux & Windows



Bluetooth 4.0 allows the use of multiple iOS tablets as opposed to the traditional one-to-one



LCD display and 13 hour battery life



Desk dock cradle charger & in-vehicle mount options

NEW

SM-L200 option:

SM-L200 5V Desktop Cradle Charger



Convenient presentation angle for in-cradle receipt or label printing while charging with printer



USB charging cable included Charge from existing system or add power adaptor



116w x 94d x 80h mm

NEW

MOBILEmPOS

NEW

2" SM-S230i

Bluetooth Super Compact 2" (58mm) Mobile Receipt Printer with Auto Reconnect



High resolution 203 dpi and 80mm/second print speed



Super compact & durable design – just 114 x 80 x 44mm & weighing 217g (inc. battery) with 1.5m drop test



Auto detect pairing with Apple iOS (MFi certified), Android, Linux & Windows devices



Multiple LED status display for easy use



Maximum 13 hour battery life printing at 5 minute intervals

2" SM-S220i

2" (58mm) iOS and Android Bluetooth MFi Mobile Printer with Auto Reconnect

 MFi Certified – pairs with iPad®, iPhone®and iPod Touch®as well as

Bluetooth devices using SPP with Wired Serial Connection / RS-232

 High resolution 203 dpi and 80mm/second print speed 

Dual Serial Ports providing RS-232 pass through function for possible connection of Pin-Pad, NFC encoder / decoder, etc as required

 LCD display and convenient automatic sleep mode for extended

battery life

 Maximum 8 hour battery life, printing at 5 minute intervals

3" SM-T300i

Rugged, 3" (80mm) iOS & Android Bluetooth MFi Printer with Auto Reconnect

 MFi Certified – pairs with iPad®, iPhone®and iPod Touch

as well as Bluetooth devices using SPP with Wired Serial Connection / RS-232

 High resolution 203 dpi and 75mm/second print speed 

STANDARD

COMPLIANT

IP54

Rubberised design with IP54 dust/ splash proof certificate

 1.5m drop reliability

Maximum 13 hour battery life, printing at 5 minute intervals

  SM-T301i with 1&2 track magnetic stripe reader version

LOGISTICS

 Delivery Confirmation  Reporting  Vehicle Invoicing

RETAIL

 Point-of-Sale Receipting  Stock Checker  Retail Couponing

HOSPITALITY

 Event Ticketing  Table Receipting

NEW

Star WebPRNT Browser for Star Bluetooth Mobile

Simplifying direct printing from the Web to Star’s huge range of low cost ticket / label / kitchen / mobile

Bluetooth printers as well as supporting all relevant web technologies. Full screen user interface mode available for OEM /kiosk use. Download from GooglePlay or the App Store.

WebPRNT SDKs including a demonstration page are available from Star’s global support site

www.starmicronics.com/support

4" SM-T400i with Label Facility

Durable, 4" (112mm) iOS & Android Bluetooth MFi Mobile Printer with Auto

 MFi Certified – pairs with iPad®, iPhone®and iPod Touch

as well as Bluetooth devices using SPP with Wired Serial Connection / RS-232

 High resolution 203 dpi and 80mm/second print speed  Rugged design with IP54 dust / splash proof certificate  1.5m drop reliability  Maximum 24 hour battery life printing at 5 minute intervals  SM-T404i with 1,2&3 track magnetic stripe reader version

Reconnect

STANDARD

COMPLIANT

IP54

Star Digital Receipting now available for Star Mobile printers

Star’s latest SDK will allow integrators to deliver FREE Digital

Receipting via Star’s AllReceipts App into their software – see page 8

for more details.

Full specifications on page 32 or www.Star-EMEA.com

Page 24

PERIPHERALS

mPOS

The SCD122 comes with all the support choices in the box, which includes a stand alone base and telescopic pole. There’s also a CD-ROM containing the drivers, manuals and utilities.

SCD122 & SCD400 Customer Display Specifications

SCD122

POS Peripherals

SCD122 USB Powered Display

Fast easy-to-read 2 lines x 20 character display with ESC/POS™and OPOS™support.

 Supplied with a choice of support including stand alone

base and telescopic pole

 High speed data transfer using USB 2.0 interface  Clear, fast easy-to-read with wide viewing angle  ESC/POS  Cyrillic character support (multiple code pages)

SCD400 Customer Display

For use with POS and ECR Systems. The Star SCD400 Display uses the same serial interface as the Star POS printer.

 Reliable and versatile 2 lines x 20 character customer display  Large, clear, easy-to-read characters  Wide viewing angle  Single interface for display and printer  New Charcoal Grey and Star White versions available

™

emulation (dip switch selectable)

SCD400

SCD122 SCD400

Display Method

Display Colour Blue-Green

No. of Characters 40 (20 columns x 2 lines)

Character Font 5 x 7 dot matrix

Character size (h x w) 5.00 x 3.5mm 9 x 5.25mm

Brightness min. 350 cd/m

Tilt angle max 30˚ / Rotation 300˚ max 30˚ / Rotation 360˚

Power Consumption

Interface USB 2.0 Serial RS232 C

Emulation: ESC/POS compatible

Star Mode Standard Standard

max. 500mA@5V (2.5W)

™

ESC/POS™DMD110

USB powered

via dip switch

Vacuum fluorescent display

max. 400mA@12V (4.8W)

not available

CB-2002 Cash Drawer for PC Point-of-Sale

Star’s Series of cash drawers have been specifically designed to link with Star and other industry standard POS printers. These range from the basic entry level model to the larger version aimed at markets with more note sizes.

 Driven from the peripheral drive circuit of a

Star or Epson POS printer

CB-2002 UN – cash drawer with 8 upright note and 8 coin slots in Charcoal Grey and Star

White with optional lockable cover – DK-AirCash wireless mobile option available

NEW

CB-2002 FN Ultra White version now available

DK-AirCash

Star’s unique accessory that mobilises any Cash Drawer.

mPOP Combined

NEW

Bluetooth Printer & Cash Drawer

See page 6 & 7 for details.

CB-2002 FN – cash drawer with 4 flat note clips and 8 coin slots in ECO Black, Charcoal

Grey, Star White and NEW Ultra White with optional lockable cover – DK-AirCash wireless mobile option available. 410 (w) x 415 (d) x 114 (h) mm / 7kg

CB-2002 options

SCD122 SCD400

Operating Conditions: Temperature Humidity

Storage Conditions: Temperature Humidity

Dimensions (w x d x h): Display Unit Stand alone height Stand alone base Telescopic Pole height Pole Base

Weight

Colour Both available in Charcoal grey and Star white

5 ~ 45˚C

10% ~ 90% RH

–20 ~ 60˚C

10% ~ 90% RH

175 x 53 x 72mm

142 / 272 / 387 / 517mm

175 x 110 x 61mm

124 / 254 / 369 / 499mm

40mm height

80mm diameter

1.4kg packaged

with base & supports

5 ~ 45˚C

10% ~ 85% RH

–20 ~ 60˚C

10% ~ 90% RH

231 x 45 x 110mm

not available not available

380 ~ 550mm

12mm height

80mm diameter

approx 850g

 Both versions include a compulsion switch  3 position key lock

CB-2002 Specifications

Connection to Peripheral Drive Circuit of Star Printer

Cash Tray Combination as above with Cheque Slot

Dimensions 410 (w) x 415 (d) x 114 (h) mm

Weight 7kg

Input Voltage & Current DC 24 Volt, 1 amp

Pulse Time 100m.s (max), 30m.s (min)

Colour CB-2002 UN:

CB-2002 FN:

Drawer Release 3 position key lock with Drawer Release

Options available

Via 6-pin Modular plug connected to cash drawer

by shielded cable with separated ground wire

Star white or dark charcoal grey

ECO black, charcoal grey, Star white or NEW Ultra White

• Under desk “Z” brackets • Lockable cover

• Note Holder Bracket and Note Divider

Page 25

mPOS Peripherals

Star WiFi Power Pack

Providing simple WiFi printing directly from Smartphones, Tablets, PCs or any other mobile device to any Star LAN Printer.

 Designed to provide USB power for external 3rd party dongles minimising the number of external

cables and power sockets required

 Available on Star’s full range of LAN and WebPRNT printers, from the lowest cost TSP143LAN to

traditional TSP654II, TSP700II, TSP800II, SP700 Series and any other model with a DK connector

Double-sided Tape

PERIPHERALS

2nd Power Adaptor no longer needed

NEW

TP-LINK Wireless N

Nano Router

LAN

DK-USB Power Module

Cash Drawer Cable

WiFi Router

LAN Cable

Double-sided Tape

To Cash Drawer

USB Cable

The Star WiFi Power Pack includes:



150 Mbps TP-Link Wireless N Nano Router – supporting

AP (default), Client, Router, Repeater and Bridge modes



DK-USB printer link – powers the TP-Link connecting to the Cash Drawer DK connector with “pass-through” capability for full cash drawer functionality including status

mPOS

DK-USB – can also be

purchased separately to “power” additional 3rd party dongles including 3G or alternative WiFi devices and can also be used to power / charge other USB devices including tablets.

Make your cash drawer

NEW

Versions available:

cable free!

154mm

75mm

DK-AirCash

Low cost, Cash Drawer Accessory enabling mobile POS users to open the cash drawer of their choice with a standard RJ-11 printer connection via their mobile device in a variety of environments.

 Support for all traditional operating platforms

including OPOS, Java-POS, Windows

™

and many more

iOS

 Neat, compact design (154 (w) x 75 (d) x 28 (h) mm)

 Retro-fit to existing installed cash drawers  Drawer Open Status retrievable by host

 Easy-to-Access Dip Switches for LAN / Bluetooth

selection

 Auto Connect facility reconnecting to last device

after power on or out of range situation

DK-AirCash SAC10E Ethernet – Ethernet supported cash drawers can be

fired by WiFi mobile devices communicating directly with mobile printers and opening the cash drawer via the store’s network.

DK-AirCash SAC10EB Apple MFi / Android Bluetooth & Ethernet

printer and cash drawer independently.

– allows devices to communicate directly with both the mobile receipt

DK-AirCash SAC10EW WiFi & Ethernet – for direct communication with

the cash drawer over IP without the need for a wired connection.

™

, Android™,



No Printer required to open cash drawer!

ESC/POS

Page 26

THERMAL

PERIPHERALS

AIRLINES

BANKING

GOVERNMENT & SCHOOLS

 Internal Card payment Systems for

Canteens, etc.

 Queue Management  Payment Terminals

HEALTH

HOSPITALITY

 Kitchen Printing  QSR Order Building  Loyalty Programmes  Valet Parking Management  Queue Management

…and so much more.

HOTELS

 Virtual Receptionist  Information Terminal  Digital Signage  Loyalty Programmmes

MARKET RESEARCH

RETAIL

 Pharmacy Prescriptions  Gift Vouchers  Point-of-Sale Receipting  Stock and Price Checker  Retail Couponing  Queue Management  Market Research Tool

…and so much more.

TOURISM

 Cloud based Tours / Excursion Bookings

can be promoted and sold etc.

AsuraCPRNT

NEW

The World’s First Interactive Communication System

As one of the world’s largest manufacturers of POS and kiosk printing solutions, we have combined our two areas of expertise to create the ultimate user engagement

™

tool – the AsuraCPRNT

. This unique “All-in-One” POS communication platform

with integrated printer is so much more than a “mini” kiosk.

The latest communication technologies combined with a powerful CPU processor have resulted in a powerful solution which can work independently as a thin client server, mini kiosk or even POS / Information terminal depending on the software and options added. Or, it can be implemented into almost any infrastructure for customer / user engagement with the added advantage of flexible location from shelf edge, wall, counter top or even pole mounted.

“All-in-One” and just 38cm high!



7" Display

Swivel & Tilt TFT Touch Screen LCD



Powerful CPU

38cm

Customize your AsuraCPRNT

We know how important branding is in an ever-competitive market. In order to increase brand awareness for retailers and restaurateurs, cover skins can be produced for the AsuraCPRNT featuring logos or campaign graphics to create eye-catching POS, kiosk or self-service unit.

 Stylish and compact at only 180 (w) x 162 (d) x

380 (h) mm, providing design set-up flexibility

 Intuitive 7" touch screen offering media rich

graphics and sound with audio line out and MIC input, accompanied with programmable full colour LED lights

 Optional individual and combined encrypted

Magnetic Stripe Reader & 2D / QR / Barcode scanners with NFC option to follow

 Powerful CPU processor to run feature-rich

software and applications

 Linux™and Android™SDKs available

supporting Qt, Java, C++ etc.



Printer

• 300mm/sec. print speed

• 203 dpi

• 80mm wide output

 Immediate ability to run traditional Windows /

Linux desktop POS solutions using the Asura’s remote desktop protocol / thin client capabilities

 High connectivity with other technologies such

as biometric scanners, NFC readers, cameras and much more using the 4 USB-host ports. 3G connectivity & WiFi option also available

 300mm/second high speed printer capable of

printing 203 dpi print resolution coupons, receipts and documents at point of interaction with grey scale capability

Page 27

The potential uses for the AsuraCPRNT are only really limited to your imagination! Compact, user-friendly and feature-rich, it’s the perfect User

Engagement solution for all industries. Large brands and small independents the world over are using the AsuraCPRNT for the widest range of applications from virtual receptionists to loyalty programmes; queue management in retail, hospitality, government and healthcare to an endless number of customer engagement applications.

The New “All-in-One”

Unmatched by any rivals, the AsuraCPRNT delivers audio-visual content; prints high quality messages; features LAN, Bluetooth, WiFi, 3G connectivity with documented SDKs for Linux and Android development and offers multiple levels of usability and functionality. This 38cm device can be expanded to fit your requirements from VESA mounted tablets on the back of the AsuraCPRNT to all the options mentioned below.

Options to fit your requirements

The AsuraCPRNT can be completely customised with a host of options including integrated MSR, 2D and QR Barcode scanners and NFC reader. It can also be optimised to support the connection of external peripherals using the 4 on-board USB- Host ports – from a biometric scanner to WiFi or 3G options. In a busy retail environment, the AsuraCPRNT’s barcode reader allows staff and customers alike to check the latest product prices or stock levels; scan QR codes & coupons from mobile phones using the reflective dampening LCD mode whilst running other applications in the background such as videos on external screens. Other options directly from Star include WiFi as well as self standing Pole Mounts for one or two AsuraCPRNTs. The secure Base Stand which fixes the unit to the counter / desktop is supplied with the AsuraCPRNT in the box.

THERMAL

PERIPHERALS

Development with the AsuraCPRNT

Star’s development Tools for the AsuraCPRNT have been made as open as possible so that developers are able to work with the tools and technologies that they already know. Android and Linux SDKs are available – just request a log-in from support@Star-EMEA.com. The Remote Desktop Protocol can be used for instant access to an existing Windows, Linux or MAC application.

HTML5 using new Secure AsuraBrowser

Modern, HTML5 standards compatible WebKit based browser with full support for the latest features, including audio, local storage & databases, CSS3, canvas, SSL. etc. Fully compatible with all common JavaScript toolkits, e.g. jQuery enabling rich, full featured user interfaces & animations.

 Built-in JavaScript API provides direct access to the hardware

 Built-in customer facing web browser with a secure, full-screen experience /no

user navigation controls or any way to access the underlying OS. Off Line Storage (allowing for off line trading) is another of the browser’s features

POS line display solution (included with Asura OS 1.7)

Enabling external applications to use the Asura as a complete POS peripheral station with customer display, printer, BCR & MSR. Ideal for mobile applications. The Asura hosted customer display provides features that are not possible using traditional POS display poles:

 Full colour control of text and the display background with Font Scaling  Graphic image support using JPEG / PNG images loaded from a local

file or network via a URL

 Video support which can be played / positioned on the display

by command. Video files can be streamed from a local file, or network via a URL

 Customer Interaction with touch screen enabled customer response

and feedback perfect for point of sale surveys etc.

NEW

More information can be found at www.Star-EMEA.com/AsuraCPRNT or www.AsuraCPRNT.com

Full specifications on page 32 or www.Star-EMEA.com

See page 14 for details

Page 28

KIOSK / TERMINAL

“Star Micronics is very happy to introduce Sanei’s entry-level, compact, open frame printers which complete the Star range to include printing solutions for limited space enclosures.”

RETAIL

 Vending Machines  Cash Machines

 Product Locations

HOSPITALITY

 Hotel Check-in  Event Ticketing

TICKETING

 Car Parks

WAREHOUSE / LOGISTICS

 Product Picking  Logistics

Full specifications on page 34 or www.Star-EMEA.com

Sanei SK1 Series

Entry-level, Super-Compact, Open Frame Printers

Star Micronics is now stocking Sanei’s wide range of 1D and 2D barcode, ticket, receipt and label compact kiosk mechanisms which complete the Star range with printing solutions for limited space enclosures.

SK1-21A

SK1-22

SK1-31A

SK1-32

SK1-41A

NEW

SK1-21-H &

SK1-31-H

12 volt / 2" & 3"

Printers that can be powered by solar panels for remote kiosks without access to power etc.

Flashing Paper Exit guide

Models available:

SK1-21 / 22 Series

 SK1-21A – Printer only  SK1-21A-LP – Printer with presenter  SK1-22 – Clamshell style

• 200mm/second print speed

• 58 / 60mm paper width model

• Mechanism dimensions / Weight: 104 (w) x 129.2 (d) x 73.6 (h) mm / 525g

SK1-31 / 32 Series

 SK1-31A – Printer only  SK1-31A-LP – Printer with presenter  SK1-32 – Clamshell style

• “Drop-In & Print” version

• 200mm/second print speed

• 54 / 56 / 72 / 80mm model

• Mechanism dimensions / Weight: 128 (w) x 174.5 (d) x 74.2 (h) mm / 730g

SK1-41 Series

 SK1-41A-L – Printer only with Label support  SK1-41A-LP – Printer with presenter

• 150mm/second print speed

• 80 / 83 / 112mm paper width

• Mechanism dimensions / Weight:

160.9 (w) x 143.1 (d) x 76.3 (h) mm / 885g

Options:

BZ-SK-2: Bezel / Snout SK1-21 Series BZ-SK-1: Bezel / Snout SK1-31 Series PS60: PSU for SK1-21 / SK1-31 / SK1-32 CB-SK1-D3: Power Cable required for PS60 SA1-3A240: PSU for SK1-41 Series (power

lead not supplied)

PR-SK1: Presenter for SK1-21 & SK1-31 HL02: Paper Extension Arm SK1-21, SK1-31 HL03: Paper Extension Arm SK1-41

 Low profile and ultra lightweight, designed

for a wide variety of kiosk systems

 Fast, high quality 203 dpi output at print

speeds up to 200mm/second (2" & 3" models) 150mm/second (4" model) with 2D barcode capability

 Versatile operating environment (-20 to +60

degrees)

 Up to 120mm paper roll (outside diameter)

as standard with 254mm large paper roll option. SK1-32: 83mm OD Roll only. 12mm core standard with 25.4mm also available on L models with paper thickness from

0.060 to 0.15mm on SK1-21 & SK1-31

models. Up to 0.12mm on SK1-41 models.

 Dual interface USB and serial fixed

interfaces as standard

 Auto load and manual “flip top” paper

loading with retract / document capture feature and spring loaded paper roll holders to allow the kiosk builder to consider the simpler choice of operating access

 Sanei drivers are not as extensive as Star’s

range of drivers, so please check the range of drivers available directly from

Support@Star-EMEA.com

Please note these drivers are not listed on the Star Global Support website

www.StarMicronics.com/support

Page 29

TUP500 Series

“High speed and cost effective, the TUP500 is

High Speed 220mm/second Kiosk Printing Solution available in Modular or Open Frame Formats

 High speeds of up to 220mm/second (with

standard 15cm paper roll) and a default speed of 180mm/second using the optional 25cm paper roll holder

 Adjustable 45 – 82.5mm paper width

functionality with self centring width adjuster

TUP500 and TUP900 open frame and mechanism options:

 Paper exit guide / snout with flashing LEDs  25cm paper roll holder (15cm standard).

Max. capacity 18cm when mounted below printer

 PS60 Power Supply

 Barcodes, receipts, tickets, labels (TUP542)

etc, all printed on media from 0.065mm to

0.15mm thick for different applications

Interface options:

USB HU05, LAN HE07

 Large roll Damper Unit  All models supplied without interface with

optional USB, Ethernet with “print on disconnection” feature (TUP500 only), alongside traditional interface options

ideal as a fast, reliable receipt or ticket printer for kiosk environments.”

TUP500 Programmable LED Flashing Paper Exit Guide

Reseller & Retailer Tip:

Our technical team are

some of the most experienced in the business. Feel free to talk to them about your project and see if we can meet your individual customer requirements.

KIOSK / TERMINAL

TUP900 Series

80-112mm Wide (A4 Replacement) Open Frame / Modular Kiosk Printing Solution

 150mm/second high quality thermal barcode,

label, receipt, ticket and A4 kiosk printing solution for 80 – 112mm formats up to 0.15mm thick

 A4 to A6 automatic scalable raster driver for

reduced, cost-saving A4 to Internet output on 112mm wide paper



Easy paper loading and multi-position adjustable near end paper sensor with 80cm of cable for use with the high capacity paper roll supply option

 Adjustable horizontal or vertical mounted

control panel with extended cable lengths for integration flexibility

 Easy-load – simply lift and tilt the mechanism

forward and insert the paper for automatic paper loading

Interface options:

Serial HD04, Parallel HC04, USB HU06

“Offering cost efficient thermal printing, the TUP900 is designed especially for kiosk or unattended printing applications producing fast and reliable wide format tickets and receipts.”

Models available:

 TUP592 & TUP992

Open frame with moveable control panel and paper near end sensors via extended cables

 TUP542 & TUP942

Non presenter version for labels

 TUP500DP

Chassis option provides a more compact printer taking up to 25% less space with 10cm diameter paper roll

 TUP500DP Mini

Compact printer with external paper handling

Full specifications on page 34 or www.Star-EMEA.com

Page 30

Star Support

ANDROID APP ON

We’re Here To Help Every Step Of The Way

Recognised throughout the industry for its technical knowledge, Star’s highlyadvanced printers are designed in-house from the chassis up with software from the first “bit’. Star’s DNA is imprinted from its printing solution to its technical support.

Our technical team covers Europe, Middle East and Africa and offers over 50 man years of multi-system integration experience. For Star technical support from pre-sales to print system integration, print drivers & SDKs (Software Development Kits) expertise and so much more – contact Support@Star-EMEA.com

ESC/POS

Star Drivers

Star offers extensive free-to-download drivers from www.StarMicronics.com/Support See our connectivity page opposite to find out more about our printer compatibility.

StarIO & SDKs

Star’s outstanding Software Development Support is unrivalled and is the key reason why Star printers have been integrated into such a wide variety of POS Software solutions worldwide.

Star’s multi-product API forms part of Star’s iOS which are vital and valued by Software Houses all over the world wanting to take advantage of Star’s feature-rich range of products. Each StarIO based SDK package has extensively documented source code and informative explanation manuals.

A demo package is also included to demonstrate how to implement advanced functionality and customise print outs. This, together with the backup of Star's experienced support team, allows simpler integration of platform-specific applications with Star products.

Traditional Resident

POS Software

™

, Android™, Windows™and Linux™based SDKs

Web based

POS Software

Browser

Hardware

Available from

Solution

Plug-in interface

Star WebPRNT Browser

All Star Desk / Counter

& Bluetooth Models

Star Thermal Printers

with USB / LAN interfaces

Mobile SM-L200

SM-S220i /230i

SM-T300i / DW / 400i

All Bluetooth Models

Star Thermal Printers

with USB / LAN interfaces

Free

Star Page Mode Port Discovery

JavaPOS

Star Mobile Star Raster Mode

Star SDK

Star Line

StarIO

TSP100 Bluetooth SM-T301 TSP-L10

HI X Connect

IFBD-HI01X:

TSP600II /700II /800II

IFBD-HI02X: SP700

TSP654II TSP700II TSP800II

SP700

Star Mobile SDKS including ProxiPRNT Beacon Technology

Star offers helpful SDK applications on Google Play and App Store that enable a variety of customisable samples and functionalities including the ability to change the Bluetooth device name for easy pairing, along with proximity based printing and cash drawer support, for increased mPOS security.

Name Description Stores

StarIO SDK

Enabling users to test a wide variety of functionality within customisable samples for Star Cash Drawers, Desktop and Mobile Printers

ANDROID APP ON

App Store

Google Play

Page 31

Star Connectivity at all levels

COMMUNICATION INTEGRATION

Bluetooth WiFi HTML / XML SDK

Connecting your Star

Printers to the Web!

Key Advantages

What are the costs?

Wireless Connectivity

TSP100 BI / U / ECO / GT / USB

TSP143III

WLAN

future PRNT

TSP143III LAN

mPOP

TSP654IIBI

TSP654II LAN TSP654IIUSB

TSP700II

Packaged Thermal Printers

TSP800II

FVP10

Packaged Kiosk Printers

Conventional Printers

TSP1000

TSP-L10

TUP500 + DP / MINI

Open

Frame

TUP900

SM-T300DW

SM-S220i / SM-S230i SM-T300i / SM-T400i

Printers

Direct Line

SM-L200

Thermal Mobile

SP298 / SP500

SP700

HSP7000

Matrix Printers

AsuraCPRNT

in-

All-

One

ProxiPRNT

Exchanging data over short distances, Bluetooth offers high levels of security and reliable connectivity for most tablets with in-built support. Star offers Bluetooth enabled printing capabilities for both desktop and mobile including TSP143IIIBI, TSP654IIBI, TSP743IIBI, TSP847IIBI, FVP10BI, SP742BI, SM-S220i, SM-S230i, SM-L200, SM-T300i & SM-T400i. Star can also power 3rd party dongles using our unique DK-USB connected to serial interfaces.

• Uses standard serial profile or MFi for Apple iOS devices

• 10-100m connectivity range – providing cable replacement for secure wireless transmissions

• Improved legacy support

• Easy to upgrade external 3rd party dongles

PLATFORM INDEPENDENT STAR WebPRNT BROWSER

Download from the App Store and Google Play

Why settle for an overpriced proprietary solution when you could use Star’s NEW & UNIQUE external power module to combine with a wide range of specialist OEM wireless modules. The Star WiFi Power Pack provides greater connectivity and flexibility at a lower price, supporting 5 modes – AP, Router, Client, Bridge & Repeater (see page 25).

• Flexibility to choose multiple modes of WiFi networking communication

• Powered from printer

• Mounting options

• Supported on all Star traditional printers, old or new

NEW

TSP143III

NEW low cost interface with Star CloudPRNT for remote printing from the Cloud to printers anywhere plus Star’s previous LAN only networking solution WebPRNT already on board with Dual WiFi (3rd party dongle) & Lan interface.

All documentation can be found at

www.starmicronics.com/support

PLATFORM INDEPENDENT CloudPRNT HARDWARE SOLUTION with WebPRNT

Designed as a solution to cloud / web based printing issues.

HI01X for TSP654II, TSP743II, TSP847II HI02X for SP700

• Simple Installation

• Print consistent receipts from any web browser

PLATFORM INDEPENDENT STAR WebPRNT BROWSER

Download from the App Store and Google Play

Star SDKs are available to programmers at no cost, supporting major operating systems and popular programming languages. The Star SDK packages include sample code and documentation and provide a valuable tool for developers to reduce development time and cost.

• SDK packages include sample code and documentation to reduce development time and costs

• Supporting all major operating systems and programming languages

• Free downloadable software from the Star Global Support site

• Dedicated Star Technical support team, including extensive practice application developer advice

WLAN

Wireless Solution

Price of Star Bluetooth enabled printer or DK-USB + external bluetooth adaptor

Printer + WiFi, Ethernet / USB or Bluetooth Serial dongle + PSU. Or just Star’s WiFi Power Pack (see page 25)

Cost of printer + CloudPRNT (HI01X / HI02X) interface or Star WebPRNT Browser for Bluetooth models

Free downloadable SDKs from Star Global Support site: www.starmicronics.com/support, or ask Star technical team: Support@Star-EMEA.com

Bluetooth WiFi Star Cloud Technology Star SDKs

SPP* MFi

NEW

TSP143IIIBI

NEW

TSP143IIIBI

Star WiFi

Power Pack

External WiFi

Ethernet /

LAN Kit with

Star “Power”

DK-USB

3rd Party

External

WiFi

USB Kit

for USB only

Star Printers

WLAN cable-free interface

with easy WPS set up

Star

CloudPRNT

Interface

HI X Connect

HI01X / HI02X

Option

Star

WebPRNT

Interface

HE07/08

Option

Star

WebPRNT

Android LINUX Windows iOS Mac

Browser

a a a a

a a a a a

a a a a a a a

a a a a a a a a

TSP654IIBI TSP654II BI

TSP743IIBI TSP847IIBI

FVP10BI FVP10 BI

TSP743IIBI TSP847IIBI

a a

HI01X HE07X

BE07X

a a a

a a a a a a

LAN

a a a a a

a a

DK-USB

not supported

a a a a a

In-built WiFi In-built WiFi

a a a

a a a a a a

Bluetooth 2.1 & BLE

a a a a a

SP742IIBI SP742II BI

a a

HI02X HE08X

a a a a

a a a a a

a a

Proximity location based printing and Secure Cash Management for mPOS – see page 5

*SPP = Serial Port Profile – industry cable replacement profile

Standard

a a

Thin Client

Basis

Page 32

Mobile / mPOS (Wireless & Bluetooth)

SM-L200 SM-S220i SM-S230i SM-T300DW SM-T300i SM-T400i

Label Support

STAR PRINTER SERIES

Pages 22-23 Pages 22-23 Pages 22-23 Pages 22-23 Pages 22-23 Pages 22-23

Direct Thermal Mobile

Compact,

2" (58mm)

Description

Bluetooth / BLE

Mobile Printer for Apple iOS,

Android, Linux

& Windows

Max. Print Speed 35mm/sec. 80mm/sec. 80mm/sec. 75mm/sec. 75mm/sec. 80mm/sec.

Resolution 203 dpi 203 dpi 203 dpi 203 dpi 203 dpi 203 dpi

No. of Columns 42 col. 42 col. 42 col. 64 col. 64 col. 92 col.

Tear Bar / Autocutter

Paper Width 58mm 58mm 58mm 80mm 80mm 112mm

Paper Thickness 0.06 – 0.12mm 0.06 – 0.07mm 0.06 – 0.07mm 0.06 – 0.07mm 0.06 – 0.07mm 0.06 – 0.07mm

SPECIFICATIONS

Paper Roll (diameter)

Media Presentation

Print Width 48mm 48mm 48mm 72mm 72mm 104mm

Sensors

Interface

Emulation Star Line Mode

Drop Test 1.2m 1.2m 1.5m

Power Supply

Power / Battery Life

Reliability

Dimensions

(W x D x H) mm

Weight

Included in box with printer at purchase

Options

Tear Bar Tear Bar Tear Bar Tear Bar Tear Bar Tear Bar

40mm 40mm 40mm 50mm 50mm 50mm

Horizontal Desktop or

Vertical Belt Strap

Paper End, Cover Open,

Black Mark

Bluetooth 3.0 / 4.0

USB charging /

communication cable

included

USB charging /

communication cable

included

3.7V rechargeable

battery offering 13 hours

printing at 5 minute

printing intervals

37 million lines

50km

83 x 122.5 x 44

220g (including battery)

• Battery Pack

• Sample Paper Roll

• Belt Clip

• Safety Instruction Sheet

• USB Cable

• Desktop Cradle Charger

• In-vehicle Mount Bracket

• Extra Battery Pack

• Star WebPRNT

Browser App download

from the App Store &

Google Play

Compact, 2" (58mm) Apple iOS & Android

Bluetooth

Mobile Printer

Horizontal Desktop or

Vertical Belt Strap

Paper End, Cover Open,

Black Mark

Bluetooth (2.1),

iOS (MFi),

Serial (cable included)

Star Line Mode &

Battery Pack included

7.4V rechargeable

battery offering 8 hours

printing at 5 minute

printing intervals

288g (including battery)

• Sample Paper Roll

•

Belt Clip• Serial Cable

• Battery Charger

• Safety Instruction

• 4 Unit Battery Charger

• Single Battery Charger

• Extra Battery Pack

• Vehicle Charger

• Star WebPRNT

Browser App download

from the App Store &

™

ESC/POS

AC Charger &

37 million lines

50km

81 x 139 x 46

• Battery Pack

Sheet

Google Play

Compact, 2" (58mm) Apple iOS

& Android

Bluetooth

Mobile Printer

Horizontal Desktop or

Vertical Belt Strap

Paper End, Cover Open,

Black Mark

Bluetooth (2.1),

iOS (MFi),

USB communication

cable included

Star Line Mode &

ESC/POS

AC Charger &

Battery Pack included

7.4V rechargeable

battery offering 13 hours

printing at 5 minute

printing intervals

37 million lines

50km

80 x 114 x 44

217g (including battery)

• Battery Pack

• Sample Paper Roll

• Belt Clip • USB Cable

• Battery Charger

• Safety Instruction Sheet

• 4 Unit Battery Charger

• Single Battery Charger

• Extra Battery Pack

• Vehicle Charger

• Star WebPRNT

Browser App download

from the App Store &

Google Play

Rugged, 3" (80mm) Mobile Printer with

WiFi compatibility

SM-T300DW

without MSR SM-T301DW with MSR (Track 1&2)

Horizontal Desktop or

Vertical Belt / Shoulder

Strap

Paper End, Cover Open Paper End, Cover Open

WiFi,

Serial (cable included)

™

ESC/POS

1.5m

(MSR Model: 1.2m)

AC Charger &

Battery Pack included

7.4V rechargeable

battery offering 11hours

printing at 5 minute

printing intervals

37 million lines

50km

120 x 132.2 x 58.3

442g (including battery)

• Battery Pack

• Sample Paper Roll

•

Belt Clip• Serial Cable

• Battery Charger

• Safety Instruction Sheet

• 4 Unit Battery Charger

• Shoulder Strap

• Single Battery Charger

• Extra Battery Pack

• Vehicle Charger

• MSR version available

Rugged, 3" (80mm)

Android Compatible

Bluetooth Mobile

SM-T300i without

MSR (Track 1&2)

Horizontal Desktop or

Vertical Belt / Shoulder

Serial (cable included)

™

Battery Pack included

battery offering 13 hours

442g (including battery)

• Sample Paper Roll

•

Belt Clip• Serial Cable

• 4 Unit Battery Charger

• Single Battery Charger

• Extra Battery Pack

• MSR version available

Browser App download

from the App Store &

Apple iOS &

Printer

MSR

SM-T301i with

Strap

Bluetooth (2.1),

iOS (MFi),

Star Line Mode &

(MSR Model: 1.2m)

7.4V rechargeable

printing at 5 minute

printing intervals

120 x 130.5 x 58.3 120 x 132.2 x 58.3

• Battery Charger

• Safety Instruction

• Shoulder Strap

• Vehicle Charger

• Star WebPRNT

™

ESC/POS

1.5m

AC Charger &

37 million lines

50km

(with MSR)

• Battery Pack

Sheet

Google Play

Label Support

Durable, 4" (112mm)

Apple iOS &

Android Compatible

Bluetooth Mobile

Printer

SM-T400i without

MSR

SM-T404i with

MSR (Track 1&2)

Horizontal Desktop or

Vertical Belt / Shoulder

Strap

Paper End, Cover Open,

Black Mark

Bluetooth (2.1),

iOS (MFi),

Serial (cable included)

Star Line Mode &

(MSR Model: 1.2m)

Battery Pack included

7.4V rechargeable

battery offering 24 hours

printing at 5 minute

printing intervals

150.9 x 136.6 x 63.3

150.9 x 143.2 x 63.3

735g (including battery)

• Sample Paper Roll

• Belt Clip • Serial Cable

• Battery Charger

• Safety Instruction

• 4 Unit Battery Charger

• Shoulder Strap

• Single Battery Charger

• Extra Battery Pack

• Vehicle Charger

• MSR version available

• Star WebPRNT

Browser App download

from the App Store &

™

ESC/POS

1.5m

AC Charger &

37 million lines

50km

(with MSR)

• Battery Pack

Sheet

Google Play

AsuraCPRNT

“All-in-One”

Pages 30-31

Direct Thermal

38cm high

“All-in-One” User

Engagement Tool

with Display,

Fast Processor &

Direct Thermal

Printer

300mm/sec.

203 dpi

48 / 64 col. Depending

on Paper Width

Partial Cut (Guillotine)

80mm Standard

(65 / 58mm Paper Guide)

0.053 – 0.085mm

83mm

User Selectable Paper

Delivery Options with

Mounting Bracket

included

72mm (58.5 / 50.8mm)

Paper End, Cover Open,

Near End Horizontal &

Vertical, Black Mark

Ethernet, 4 USB Hosts,

1 USB Slave,

Audio Line IN / OUT,

Cash Drawer Kick,

Micro SD card support

Star Line Mode /

WebPRNT

Internal adaptor

included with cable

42.0 W Printing

8.7 W Standby

60 million lines

2 million cuts

180 x 162 x 367.5

3.5kg

• Power Supply

• Secure Counter Base Stand and screws

• Rubber Feet

• Paper Roll Guide

• Safety Instructions

• Individual / Combined

1D /2D /QR Barcode

& Magnetic Stripe

Readers

• NEW Newland

Scanner now available

• NFC, WiFi,

3G / 4G Dongles

• K-lock Desk Security

Cable

• Micro SD Card



Industry standard 1D & 2D barcode support on all printers

Page 33

Bluetooth Desktop

NEW

STAR PRINTER SERIES

See

TSP143IIIBI

TSP654IIBI FVP10BI TSP743IIBI TSP847IIBI SP742BI

Matrix

SP298 SP500 SP700

pages 6-7

Description

Max. Print Speed

Resolution

No. of Columns

Autocutter

Paper Width

Paper Thickness

Paper Roll Standard Option

Media Presentation

Print Width

Sensors

Interface

Power Supply

Power Consumption

Energy Star

Reliability

Dimensions

(W x D x H) mm

Weight

Options

Pages 9-11 Page 13 Page 15 Page 16 Page 17 Page 21

Direct Thermal BLUETOOTH Wireless Printers

Direct Thermal Label, Receipt & Ticketing

NEW

High Speed

“All-in-the-Box”

Bluetooth

printer for

Android,

Apple iOS &

Windows

250mm/sec. 300mm/sec. 250mm/sec. 250mm/sec. 180mm/sec. 4.7 to 8.9 lps

203 dpi 203 dpi

48 / 64 col.

Depending on

Paper Width

Partial Cut

(Guillotine)

80mm (58mm Using Paper Guide)

0.053 – 0.085mm 0.053 – 0.085mm 0.065 – 0.15mm 0.065 – 0.15mm 0.065 – 0.15mm

83mm 83mm 83mm

User Selectable

Paper Delivery

Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Paper End,

Cover Open

Bluetooth (2.1),

iOS (MFi)

Internal with Power

Cable included

46 W Printing

3.5 W Standby

Energy Star Certified

Internal Power

Supply (Power Cable

included)

60 million lines

2 million cuts

142 x 204 x 132

1.56kg – 1.74kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

Industry first

High

Performance,

Entry Level

iOS Compatible

Bluetooth

Desktop Printer

with Cash

Drawer Support

48 / 64 col.

Depending on

Paper Width

Partial Cut (Guillotine)

80mm Standard

(58mm Paper Guide)

User Selectable

Paper Delivery

Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Paper End,

Cover Open,

Near End Horizontal

& Vertical

Bluetooth (2.1),

iOS (MFi)

External Option

PS60A

45.6 W Printing

3.6 W Standby

External, Energy

Star Qualified

PS60A (Optional)

60 million lines

2 million cuts

142 x 203.5 x 132

1.60kg

• T100/650 Splash Proof Cover

• VS T100/650

Display Stand for

Vertical Use

• Plug-in Interfaces (see above)

• Direct Connection

Cable option with

iOS devices

• Star WebPRNT Browser download from the App Store

& Google Play

UNIQUE

UNIQUE under

Counter / Front

Operating

Printer with

Voice Tool

80mm

Bluetooth

Barcode,

Label, Ticket

& Receipt

Printing from

the ONE model

203 dpi,

406 x 203 dpi

selectable

48 / 64 col.

Depending on

Paper Width

Full or Partial Cut

(Guillotine)

58 – 80mm

Fully Adjustable

Front Output

Delivery with

Flat Shelf Mount

Bracket Option

72mm 80mm 104mm 63 / 50 / 45mm

Black Mark,

Paper End,

Cover Open,

Near End

Bluetooth (2.1),

iOS (MFi)

External Option

PS60A

37.44 W Printing

2.88 W Standby

External, Energy

Star Qualified

PS60A (Optional)

60 million lines

2 million cuts

144 x 227.7 x 114

2.8kg

• MK-FVP10

mounting bracket

• Range of plug-in alternative

interfaces could

replace Bluetooth

interface

• Star WebPRNT Browser download from the App Store

& Google Play

203 dpi,

406 x 203 dpi

selectable

48 / 64 or 53 / 71 col.

Depending on

Paper Width

Full or Partial Cut

(Guillotine)

82.5, 80, 58mm Selectable

(80mm Standard

with User Installable

Paper Guide Fitted)

100mm

External Paper Feed

User Selectable

Paper Delivery

Options with

Mounting Bracket

included & Optional

Paper Exit Guide

Black Mark, Paper

End, Cover Open,

Near End Horizontal

& Vertical

Bluetooth (2.1),

iOS (MFi)

External Option

PS60A

43.2 W Printing

3.6 W Standby

External, Energy

Star Qualified

PS60A (Optional)

60 million lines

2 million cuts

147 x 213 x 148

1.75kg

• Wall mount bracket in box at purchase

• Flashing Snout / Paper Exit Guide

option

• VS700 Deskboot option

• Star WebPRNT Browser download from the App Store

& Google Play

UNIQUE 112mm

Bluetooth

Barcode,

Label, Ticket

& Receipt

Printing from

the ONE model

203 dpi,

406 x 203 dpi

selectable

A4 Print Capability

on 112mm Paper with Auto Scaling

Software

Full or Partial Cut

(Guillotine)

112mm Standard,

80mm Options with

User Installable

Paper Guide Option

100mm

External Paper Feed

User Selectable

Paper Delivery

Options with

Mounting Bracket

Option

Black Mark, Paper

End, Cover Open,

Near End Horizontal

& Vertical

Bluetooth (2.1),

iOS (MFi)

External Option

PS60A

48 W Printing

2.88 W Standby

External, Energy

Star Qualified

PS60A (Optional)

37 million lines

2 million cuts

180 x 213 x 148

1.9kg

• Blue or Green & Red LED Flashing

Snout / Paper Exit

Guide Option

• WBT800 Wall Mount kit

• VS800 Deskboot option

• Star WebPRNT Browser download from the App Store

& Google Play

Dot Matrix

Bluetooth

UNIQUE

Bluetooth

9-pin

Red / Black

Dot Matrix

Printer

7 x 9 half dot

42 / 35

Partial Cut

76mm default,

69.5, 58mm

0.065 – 0.085mm / 1+2 copies

85mm

Vertical or

Horizontal mode

Paper End

(Near End option)

Bluetooth (2.1),

iOS (MFi)

Internal with

cable provided

36 W Printing

10.08 W Standby

22 million lines

1 million cuts

160 x 245 x 152

3.3kg

• Buzzer Alarm

• Wall Mount Kit

• Vertical Kit

• Star WebPRNT Browser download from the App Store

& Google Play

Page 20 Page 21 Page 21

9-Pin High Quality, Bi-Directional

Impact Printers

9-pin

Matrix Slip

Printers

with Letter

Descenders

3.1 lps 4.0 to 7.5 lps 4.7 to 8.9 lps

7 x 9 half dot 7 x 9 half dot 7 x 9 half dot

42 42 / 30 42 / 35

Slip Printer

up to 182mm 76, 57mm

0.09 – 0.20mm / 1+2 copies

Slips only 85mm 85mm

Horizontal mode

63mm 63 / 60 / 45mm 63 / 50 / 45mm

Auto Side

RS232C

or Parallel

External

PS60 option

24 W Printing

1.68 W Standby

External, Energy

Star Qualified

PS60 (Optional)

9 million lines

180 x 190 x 138.5

2.1kg

• PS60

Power Supply

Low Cost,

High Speed

9-pin Matrix

Printers

Tear Bar and Full / Partial (Guillotine)

Autocutter Rewind

models

0.07 – 0.10mm / 1+2 copies

Vertical or

Horizontal mode

6 position

Black Mark

RS232C

or Parallel

Internal with

cable provided

10.32 W Printing

2.88 W Standby

22 million lines

1 million cuts

140 x 225 x 163 160 x 245 x 152

• Buzzer Alarm

• Wall Mount Kit

• Vertical Kit

• SP500R Paper Rewind version

UNIQUE

Bluetooth

9-pin

Red / Black

Dot Matrix

Printer

Tear Bar and Full /

Partial (Guillotine)

Autocutter Rewind

models

76mm default,

69.5, 58mm

0.06 – 0.085mm / 1+2 copies

Vertical or

Horizontal mode

Paper End

(Near End option)

RS232C, Parallel,

non interface or Bluetooth versions + NEW HI X CloudPRNT

Internal with

cable provided

36 W Printing

10.08 W Standby

22 million lines

1 million cuts

• Buzzer Alarm

• Wall Mount Kit

• Vertical Kit

• SP700R Paper Rewind version

SPECIFICATIONS



Industry standard 1D & 2D barcode support on all printers

Page 34

Kiosk / Terminal

Specialist Thermal, Lottery & Ticketing

Hybrid

TUP592 TUP542

STAR

TUP992 TUP942

Sanei

SK1-21/22/31/32

58 or

80mm

PRINTER SERIES

Page 29 Page 29 Page 28 Page 28

Modular, Open Frame Thermal Kiosk / Terminal

Direct Thermal Label, Receipt & Ticketing

TUP592

Description

Presenter Version

TUP542

No Presenter

for labels etc.

TUP500 Modules –

mech etc.

Max. Print Speed 220mm/sec. 150mm/sec. 200mm/sec. 150mm/sec.

Resolution 203 dpi 203 dpi 203 dpi 203 dpi

No. of Columns

Autocutter

Paper Width

Paper Thickness 0.065 – 0.15mm 0.065 – 0.15mm 0.059 – 0.15mm 0.059 – 0.12mm

SPECIFICATIONS

Paper Roll Standard Option

Media Presentation

Print Width 80mm 104mm

Sensors

Interface

Unique Ethernet Print on Disconnection Feature

Power Supply External Option PS60A External Option PS60A

Power Consumption

Energy Star

Reliability

Dimensions

(W x D x H) mm

Weight (without

interface cover)

Document Capture

(Anti-litter mode)

Options

48 / 64 or 53 / 71 col.

Depending on Paper

Width

Full or Partial (Guillotine)

Full only with PR500

Presenter & TUP592

45 – 82.5mm

Adjustable

Standard: 150mm

With Option: 254mm

Presenter with

Document Capture

(not for labels).

Flashing Paper Exit

Guide option

Black Mark,

Adjustable Paper End,

Near End & Paper Low

Supplied without

Interface. Options:

9-pin or 25-Pin Serial

(IFBD-HN03 or

IFBD-HD03),

Parallel (IFBD-HC03),

USB (IFBD-HU05),

Ethernet (IFBD-HE07

Standard with

IFBD-HE07 option

40.8 W Printing

16.8 W Standby

External, Energy Star

Qualified PS60A

(optional)

60 million lines

1 million cuts

Mechanism:

135 x 101 x 103

Open Frame:

2.5kg

Guide

Option

179

160 x 234.1

Document Capture Document Capture Document Capture Document Capture

• Interfaces (see above)

• Flashing Snout Green & Red LED Paper Exit

• 25cm Paper Roll

TUP992

Presenter Version

TUP942

No Presenter for

labels etc.

TUP900 Modules –

mech etc.

A4 Print Capability on

112mm Paper with

Auto Scaling Software

Full or Partial (Guillotine)

Full Only with PR900

Presenter & TUP992

80 – 112mm

Adjustable

Standard: 150mm

With Option: 254mm

Presenter with

Document Capture

(not for labels).

Metal or Flashing Paper

Exit Guide options

Black Mark,

Adjustable Paper End,

Near End & Paper Low

Supplied without

Interface. Options:

9-pin or 25-Pin Serial

(IFBD-HN04 or

IFBD-HD04),

Parallel (IFBD-HC04),

USB (IFBD-HU06)

Contact Star

for more details

40.8 W Printing

1.92 W Standby

External, Energy Star

Qualified PS60A

(optional)

37 million lines

1 million cuts

Mechanism:

176.2 x 101 x 121 Open Frame:

249.3x 179

192

2.84kg

• Interfaces (see above)

• Metal Paper Exit Guide

• Flashing Snout Blue or Green & Red LED Paper

Exit Guide Option

• 25cm Paper Roll Option

Open Frame Thermal Ticketing

SK1-21A / SK1-31A

No Presenter

SK1-21A-LP /

SK1-31A-LP

Presenter

SK1-22 / SK1-32

Clamshell

SK1-21/22: Max 56 col. SK1-31/32: Max 80 col.

Depending on Paper

Full or Partial (Guillotine) Full Only With Presenter

SK1-21: 54 / 56mm

SK1-31: 58 / 60 / 80 / 83mm

Standard: 120mm

With Option: 200mm

SK1-21/31: Presenter

with Document Capture

(not for labels).

Plastic or Flashing Paper

Exit Guide options

SK1-21: 54 / 56mm

SK1-31: 54 / 56 / 72 / 80mm

Reflection (PE/BM)

USB as standard

External Option PS60A with CB-SK1-D3 cable

60 W Printing

1.68 W Standby

External, Energy Star

Qualified PS60A (Optional)

+ Qualified SA1-3A240

60 million lines

1.5 million cuts

SK1-21: 80mm roll

104 x 129.2 x 73.6 / 525g

SK1-31: 83mm roll

127 x 130 x 74 / 630g

SK1-22: 104 x 140.3 x 69.7

SK1-32: 128 x 174.5 x 74.2

• Plastic Bezel BZ-SK1-1

• Flashing Snout LB-SK1

• PS60 PSU +PS60

Connector CB-SK1-D3

• 20cm Paper Roll option

• Presenter PR-SK1

Width

Near End,

& Gap

Serial,

(optional)

580g

730g

HL02

Sanei

SK1-41A

SK1-41A-L

No Presenter

SK1-41A-LP with

Presenter and Label Support

Max 104 col. (8 x 16) Max 69 col. (12 x 24)

Depending on Paper

Width

Full or Partial (Guillotine) Full Only With Presenter

80 / 83 / 112mm

Standard: 120mm

With Option: 200mm

Presenter with

Document Capture

(not for labels).

Plastic or Flashing Paper

Exit Guide options

72 / 80 / 104mm

Near End,

Reflection (PE/BM)

& Gap

Serial,

USB as standard

External Option

SA1-3A240

Power Lead Now Supplied

60 W Printing

1.68 W Standby

External,

SA1-3A240 (optional)

60 million lines

1.5 million cuts

80mm roll:

160.9 x 143.1 x 76.3 102mm roll:

160.9 x151.2 x82.2 120mm roll:

160.9 x159.3 x88.1

without presenter / 885g

• Plastic Bezel BZ-SK1-1

• Flashing Snout LB-SK1

• PS60 PSU + PS60

Connector CB-SK1-D3

TSP1000 TSP-L10

Page 18 Page 19

Star Specialist Direct

Thermal Printers with

Receipt / Ticket Stacker

One of the

World’s most

successful

Lottery Printers

180mm/sec. 300mm/sec.

203 dpi 203 dpi

48 / 64 or 53 / 71 col.

Depending on Paper

Width

Full Cut (Guillotine) Full Cut (Guillotine)

45 – 82.5mm

Adjustable

0.065 – 0.15mm 0.075 – 0.09mm



180mm

30 Receipt /

Ticket Stacker

80mm 80mm

Paper End, Near End

& Stacker

Serial, Parallel or USB as Standard. Ethernet Options.

3rd Party WiFi /

Bluetooth Options

Standard with

IFBD-HE08

External Option

PS60A

48 W Printing

2.4 W Standby

60 million lines

1 million cuts

161 x 307 x 249

3.0kg

• Three Colour

Versions Available:

Cherry Red &

Star White,

Charcoal Grey or

Star Grey

High Performance

Transaction

Printer able to

print and stack

100 Tickets

48 / 64 or 53 / 71 col.

Depending on Paper

 

200mm

100 Receipt /

Ticket Stacker

Black Mark, Cover

Open, Paper End,

Near End (4 position)

High Speed USB 2.0

+ USB Host and

External Option

24 W Printing

0.48 W Standby

60 million lines

2 million cuts

165 x 343 x 276

4.4kg (including

• TSPL11 Internal Print Verification Scanner version

Secure

Width

82.5mm

Ethernet

PS60A

scanner)

Matrix / Thermal

2 Station Printer

Receipt & Matrix

Partial Cut (Guillotine)

Thermal: 58, 76, 80mm

Thermal: 0.065 –0.085mm



Powered USB options

External, Energy Star

Thermal: 60 million lines

HSP7000

Pages 20

High Speed

203 dpi Thermal

Cheque / Slip

Printer

250mm/sec. up to 8.9 lps

203 dpi / 9-pin

Receipt: 48 / 64 col.

Slip: 60 or 45 col.

Matrix: 68 –230mm

Matrix: 0.09 –0.31mm

Thermal: 83mm

Thermal: 72mm

Slip: 85.4mm max.

RS232C or Parallel

with LAN / USB /

External Option

PS60A

Qualified PS60A

(optional)

Slip: 37 million lines

186 x 296 x 177

4.6kg

• MICR & Non MICR versions



Industry standard 1D & 2D barcode support on all printers

Page 35

Direct Thermal mPOS, POS & Kiosk

STAR PRINTER SERIES

Description

Max. Print Speed

Resolution

No. of Columns

Autocutter

Paper Width

Paper Thickness

Paper Roll Standard Option

Media Presentation

Print Width

Sensors

Interface

NEW

HI X Connect Interface with CloudPRNT

Unique Ethernet Print on Disconnection Feature

Power Supply

Power Consumption

Energy Star

Reliability

Dimensions

(W x D x H) mm

Weight

Options

NEW

TSP143ECO

TSP143U

TSP143GT

Pages 9-11 Pages 9 -11 Pages 9 -11 Pages 9 -11 Pages 9 -11 Page 13 Page 16-17 Page 15

World’s Largest Range of Entry-Level Receipt Printers

Dedicated ECO

Printers with

Power & Paper

Saving Tools

All set-up accessories

in box

150mm/sec.

203 dpi 203 dpi 203 dpi 203 dpi 203 dpi 203 dpi

48 / 64 col. Depending

on Paper Width

Partical Cut (Guillotine)

with 3mm Top Margin

80mm (58mm Using

Paper Guide)

0.065 – 0.085mm 0.065 – 0.085mm 0.065 – 0.085mm 0.053 – 0.085mm 0.065 – 0.085mm 0.053 – 0.085mm 0.065 – 0.15mm 0.065 – 0.15mm

83mm 83mm 83mm 83mm 83mm 83mm 100mm 83mm

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Paper End, Cover Open Paper End, Cover Open Paper End, Cover Open Paper End, Cover Open Paper End, Cover Open

USB 2.0 Full Speed with Cable Supplied

and “Virtual” Serial

Port Emulator.

3rd Party WiFi /

Bluetooth Options

Internal with

Power Cable included

29.6 W Printing

0.76 W Standby

Energy Star Certified

Internal Power Supply

(Power Cable included)

60 million lines

1 million cuts

142 x 204 x 132

1.37kg – 1.72kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

High Speed

“All-in-the-Box”

Thermal USB

Receipt Printers

All set-up accessories

in box

TSP143GT: 250mm/sec.

TSP143U (TSP113U /

TSP143U): 125mm/sec.

48 / 64 col. Depending

on Paper Width

Partial Cut (Guillotine) Partial Cut (Guillotine) Partial Cut (Guillotine) Partial Cut (Guillotine) Partial Cut (Guillotine)

80mm (58mm Using

Paper Guide)

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

USB 2.0 Full Speed

with Cable Supplied

and “Virtual” Serial

Port Emulator.

3rd Party WiFi /

Bluetooth Options

Internal with

Power Cable included

40 W Printing

2.2 W Standby

Energy Star Certified

Internal Power Supply

(Power Cable included)

60 million lines

1 million cuts

142 x 204 x 132

1.56kg – 1.76kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

4 Year Warranty on all models within the TSP100 futurePRNT Series including

print head and cutter

TSP143III

LAN

Dedicated LAN

Thermal Printer

All set-up accessories

in box

250mm/sec. 250mm/sec. 250mm/sec. 300mm/sec.

48 / 64 col. Depending

on Paper Width

80mm (58mm Using

Paper Guide)

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Ethernet model

(10/100baseT, UTP)

with LAN Cable

Supplied and

“Virtual” Serial Port.

Star WiFi Power Pack

option available for

LAN version

TSP100LAN:

Standard

Internal with

Power Cable included

40 W Printing 6 W Standby

Energy Star Certified

Internal Power Supply

(Power Cable included)

60 million lines

2 million cuts

142 x 204 x 132

1.56kg – 1.74kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

(Europe and South Africa)

NEW

TSP143III

Wireless LAN

Dedicated

Wireless

Thermal Printer

All set-up accessories

in box

48 / 64 col. Depending

on Paper Width

80mm (58mm Using

Paper Guide)

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Supports

802.11b/g/n (2.4GHz) with an easy-to-use

and ready to go

WPS Set-up

Standard via WLAN

Internal with

Power Cable included

52 W Printing

4.5 W Standby

Energy Star Certified

Internal Power Supply

(Power Cable included)

60 million lines

2 million cuts

142 x 204 x 132

1.56kg – 1.74kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

NEW

TSP143IIIBI

Bluetooth

NEW High Speed

“All-in-the-Box”

Thermal Bluetooth

Receipt Printers

All set-up accessories

in box

48 / 64 col. Depending

on Paper Width

80mm (58mm Using

Paper Guide)

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Bluetooth (2.1)

iOS (MFi)

Internal with

Power Cable included

46 W Printing

3.5 W Standby

Energy Star Certified

Internal Power Supply

(Power Cable included)

60 million lines

2 million cuts

142 x 204 x 132

1.56kg – 1.76kg

• T100/650

Splash Proof Cover

• VS-T650/100

Display Stand for

Vertical Use

TSP654II

“Easy-Install” Kiosk / Terminal

Superfast,

Low Cost Thermal Receipt Printer including

WebPRNT / iOS

versions

48 / 64 col. Depending

on Paper Width

80mm (58mm Using

Paper Guide)

User Selectable Paper

Delivery Options with

Mounting Bracket

included

50.8mm (58mm Paper) 72mm (80mm Paper)

Paper End, Cover Open,

Near End Sensor

Horizontal & Vertical

Serial, Parallel, USB,

Ethernet, Bluetooth TSP654IIBI (Apple iOS, Android, Windows) and

Non interface versions.

Plug-in Options: Serial

(IFBD-HD03), 9-pin

Serial (HN03), Parallel

(HC03), Ethernet (HE07),

WebPRNT (HE07X),

HI X (HI01X)

Standard with

IFBD-HE07 Option

External Option PS60A External Option PS60A External Option PS60A

45.6 W Printing

3.6 W Standby

External,

Energy Star Qualified

PS60 (Optional)

60 million lines

2 million cuts

142 x 203.5 x 132

1.60kg

• Splash Proof Cover

• VS-T650/100 Display Stand for Vertical Use

• Plug-in Interfaces

• Plug-in WebPRNT

• Star WebPRNT

Browser download option for TSP654IIBI from the App Store &

Google Play

(HC03), Ethernet (HE07),

TSP743II: 43.2W Printing

TSP847II: 48 W Printing

TSP743II: 60millionlines

TSP847II: 37millionlines

147 x 213 x 148 / 1.75kg

TSP743II TSP847II

FVP10

Direct Thermal Label, Receipt & Ticketing

Barcodes, Labels,

Tickets all from the ONE model!

TSP847II:

The ALTERNATIVE

UNIQUE under

Counter / Front

Operating Printer

with Voice Tool

A4 Laser Printer

TSP743II: 250mm/sec. TSP847II: 180mm/sec.

203 dpi,

406 x 203 dpi selectable

TSP743II: 48 / 64 or

53 / 71 col.

TSP847II: “Reduced”

A4 print capability with

Auto Scaling Driver

Full or Partial Cut

(Guillotine)

TSP743II: 82.5mm,

80mm (default),

58mm selectable

TSP847II: 112mm

Standard, 80mm with

Paper Guide option

User Selectable Paper Delivery Options with

Mounting Bracket

included (TSP847II

option) & Optional

Paper Exit Guide

TSP743II: 80mm max.

TSP847II: 104mm

Black Mark, Paper End,

Cover Open, Near End

Horizontal & Vertical

Serial, Parallel, USB and Non interface versions.

Plug-in Options: Serial

(IFBD-HD03), 9-pin

Serial (HN03), Parallel

WebPRNT (HE07X)

HI X (HI01X)

NEW Bluetooth (Apple

iOS, Android, Windows)

versions available

Standard with

IFBD-HE07 Option

3.6 W Standby

2.88 W Standby

External,

Energy Star Qualified

PS60 (Optional)

2 million cuts

TSP743II:

TSP847II:

180 x 213 x 148 / 1.9kg

• Buzzer

• Blue or Green & Red LED Paper Exit Guide

• Plug-in Interfaces

• Plug-in WebPRNT

• Star WebPRNT Browser

for Bluetooth model

• TSP743II:

Splash Proof Cover

250mm/sec.

203 dpi,

406 x 203 dpi selectable

48 / 64 col. Depending

on Paper Width

Full or Partial Cut

(Guillotine)

58 – 80mm

Fully Adjustable

Front Output Delivery with Flat Shelf Mount

Bracket Option

72mm

Black Mark, Paper End,

Cover Open, Near End

USB models with

2nd interface slot for

Plug-In Options:

Serial (BD03),

Parallel,

Ethernet (BE07X),

WebPRNT

NEW Bluetooth (Apple

iOS, Android, Windows)

version available

Standard with

IFBD-HE07

Sub Chassis Option

Energy Star Qualified

144 x 227.7 x 114

• MK-FVP10 Mounting

• Plug-in 2nd Interfaces

• Plug-in WebPRNT interface solution for simple Web printing

for Bluetooth model

and

37.44 W Printing

2.88 W Standby

External,

PS60 (Optional)

60 million lines

2 million cuts

2.8kg

Bracket

• Star WebPRNT Browser

SPECIFICATIONS



Industry standard 1D & 2D barcode support on all printers

Page 36

Telephone +44 (0) 1494 471111 or visit our websites at:

www.Star-EMEA.com · www.Star-MEast.com · www.Star-POSIndia.com www.Star-Russia.com · www.Star-POSAfrica.com Global Support: www.StarMicronics.com/support

Fax: +44 (0) 1494 473333 · Email: sales@Star-EMEA.com · Technical Support: support@Star-EMEA.com

All other trademarks, where used, are acknowledged. In accordance with Star’s policy of continual product development, Star Micronics Europe Limited reserve the right to change or amend the specification and price of its products from time to time without prior notice.

“Made for iPod”, “Made for iPhone” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone and iPad respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPod is a trademark of Apple Inc., registered in the U.S. and other countries. iPod touch is a trademark of Apple Inc. iPhone is a trademark of Apple Inc. iPad is a trademark of Apple Inc.

2016 / UK2

New product information can be found at:

www.AsuraCPRNT.com · www.futurePRNT.com · www.mPOP.com

Star 99256300 Product Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
