Star 624MZ-LP Parts List

9

PARTS LIST EFFECTIVE

8G-624MZ-LP STAR-MAX GAS GRIDDLE

MODEL

24" MANUAL VALVE CONTROL

10/18/02

Key

Number

1 2R-Z0934 2 KNOB-CONTROL
2 G3-Z6339 1 FRONT PANEL
3 2A-Z0314 4 LEG
4 G3-GD0079 1 GRIDDLE PLATE ASSEMBLY
5 G3-Y7046 1 GREASE DRAWER GRIDDLE
6 G3-Y7047 2 SLIDE DRAWER
7 G3-624008 2 BURNER ASSEMBLY
8 G3-624232 1 MANIFOLD ASSEMBLY COMPLETE

9 2P-1453 1 PLUG-PIPE
10 2V-6671 2 VALVE-PILOT
11 2V-Y8832 2 VALVE-MANUAL
12 2J-Y7250 2 ORIFICE #55 L.P.
13 2K-Y7123 1 INLET PIPE
14 G3-Y7252 1 INLET PIPE SUPPORT
15 G3-Y7355 2 TUBE-PILOT
16 G3-Y7356 2 PILOT BRACKET
17 G3-Z3785 1 REGULATOR-PRESSURE

Part

Number

Per

Unit

Number

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE

INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.
