STANLEY HAND TOOLS User Manual
STANLEY®
HAND TOOLS
Table of ConTenTs
Short tape ruleS . . . . . . . . . . 896-903
long tape ruleS . . . . . . . . . . 904-905
levelS. . . . . . . . . . . . . . . . 906-909
Chalk lineS . . . . . . . . . . . . . 910-911
layout toolS . . . . . . . . . . . . . . 912
Marking . . . . . . . . . . . . . . . . 913
SquareS . . . . . . . . . . . . . . 914-916
eleCtroniC layout toolS . . . . . . 917-921
kniveS & BladeS. . . . . . . . . . . 922-940
SawS . . . . . . . . . . . . . . . . 941-951
BladeS . . . . . . . . . . . . . . . 951-952
Miter BoxeS . . . . . . . . . . . . . . . 953
haMMerS . . . . . . . . . . . . . . 954-964
deMolition toolS . . . . . . . . . . 965-970
ChiSelS, punCheS & nail SetS . . . . 971-981
FaStening toolS . . . . . . . . . . 982-998
SCrewdriverS . . . . . . . . . . 999-1015
hex keyS . . . . . . . . . . . . . . . . 1016
FiniShing toolS . . . . . . . . . . 1017-1028
illuMination . . . . . . . . . . . 1029-1030
plierS . . . . . . . . . . . . . . .1031-1039
SnipS . . . . . . . . . . . . . . . 1040-1043
wire CutterS & ClaMpS. . . . . . . . .1044
wrenCheS . . . . . . . . . . . . 1045-1050
MeChaniC'S toolS . . . . . . . . . 1051-1071
tool Storage . . . . . . . . . . . 1072-1083
Saw horSeS. . . . . . . . . . . .1083-1084
FOR OVER 165 YEARS, THE STANLEY® BRAND HAS
BEEN SYNONYMOUS WITH QUALITY AND RELIABILITY.
STA NLE Y® has been manufacturing high qualit y measuring tools since 1834, well before Henry
Ford’s Model T and Orville and Wilbur’s fun-y at Kit ty Hawk. Ten years later, A. STANLEY &
Company was founded and began producing folding wooden rules for carpenters and other
tradesmen. From those humble beginnings, STANLEY® Tools grew to become today’s gold
standard by which other hand tools are measured.
Throughout its long history of manufacturing some of the world’s best tools—a span of over
165 years—STANLEY® has been driven by an unwavering commitment to qualit y, innovation,
and precision—principles that guide the company to this very day.
wHAT'S iN YOur TOOLbOx?
STANLEY® MUST HAVES...
FATMAx® ExO-cHANgE™ kNiFE
Magnetic and exposed slider provides fast manual blade change.
FATMAx® Tri-MATEriAL HAND SAw wiTH
bLADEArMOr® cOATiNg
Tri-material handle for comfort and durability.
Induction hardened teeth for long life.
FATMAx® FOLDiNg JAb SAw
Locking mechanism locks blade in open and close positions for
safety and convenience.
CUTTINg, STRIkINg,
MEASURINg, AND
MORE...STANLEY
®
HAS WHAT EVERY
jOB NEEDS.
FATMAx® 1" FOLDiNg
POckET cHiSEL
High impact composite handle
and steel strike cap for durability.
894
FATMAx® ANTi-VibE®
OVErSizED STrikE
FAcE HAMMEr
Patented over-sized strike face,
20% larger "Sweet Spot" than
traditional hammers.
FubAr® FOrcibLE ENTrY TOOL
8-in-1 tool for prying, splitting, board
bending, and striking jobs.
FATMAx® PrEMiuM bOx bEAM LEVEL
Magnied center block vial for easy readability.
Block plumb vials for accuracy of 0.0005"/in.
FATMAx® AuTO- LOc k TAPE ruLE
Auto-Lock Mode: For control and long blade life.
FATMAx® MAgNETic TOrPEDO LEVEL
Die-cast aluminum body for durability.
Solid block vials provide accuracy of 0.0005in/in (0.5mm/m).
14-iN-1 FOLDiNg LOckiNg
MuLTi-TOOL
Portable, compact design ts easily in
tool box, work belt, or glove box.
PrEMiuM ADJuSTAbLE Quick SQuArE®
LAYOuT TOOL
Heavy-duty aluminum construction for durability.
HEAVY- DuTY STAPLE guN brAD NAiLEr
Easy-squeeze product works overtime as a staple gun,
brad nailer, cable tacker, and wire tacker.
PrEMiuM DiE-cAST HANDLE cOMbiNATiON SQuArES
Durably etched, hard-chrome-plated blades are rust-resistant and made
to last. Solid block vials provide accuracy of 0.0005in/in (0.5mm/m).
LED TriPOD FLASHLigHTS
Tripod design provides capability for
hands-free use. 120° pivoting head.
3 bEAM SPOT L ASEr - SPL 3
Project 3 Beams – Up, Down,
Horizontal: 3 bright, self leveling
beams provide accurate, plumb and
horizontal point transfer.
895
STANLEY® FATMAX® AUTO-LOCK TAPE RULES
■ Auto-Lock Mode: For control and long blade life.
■ Manual Mode: Disengage lock for speed marking.
■ Detachable Hook: Allows user to work efciently in different applications.
■ 11' Blade Standout*: For reach and efciency.
■ BladeArmor
■ Hook Storage: Securely stores hook on tape when not in use.
■ Tether-ready: Through-hole for attaching a tool lanyard when working at
heights. (Lanyard not included.)
■ Made in the USA with global components.
■ Mylar
Short tape ruleS
Product #
FMHT33316S 16 – 1-1/4
FMHT33338 25 – 1-1/4
FMHT33504 26 8 1-1/4
FMHT33348 30 1-1/4
*Standout claims based on maximum performance
**Compared to STANLEY 30-419
®
: 10X** blade life.
®
lm extends life of entire blade.
Blade
Length (ft)
Blade
Length (m)
Width (in) Graduation
Blade
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Bottom edge: Numbered in consecutive inches.
Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Bottom edge: Numbered in consecutive inches.
Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Major scale numbered in consecutive meters. Minor scale numbered in consecutive
10 cm repeated every 100 cm.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Bottom edge: Numbered in consecutive inches.
Graduated in 16ths of an inch.
STANLEY® FATMAX® PREMIUM TAPE RULES W/ 13' BLADE STANDOUT
■ 13' blade standout.
■ 1-1/4" wide blade for easy readability.
■ BladeArmor
■ High-impact ABS case with durable rubber holds up to heavy use.
■ AirLock
■ Rubber grip provides comfortable, slip-resistant hold.
■ Three-rivet, corrosion-resistant Tru-Zero
Product #
FMHT33969 16 – 1-1/4 16, 19.2
FMHT33502 25 – 1-1/4 16, 19.2
XTHT36007 26 8 1-1/4 16, 19.2
FMHT33509 35 – 1-1/4 16, 19.2
*Standout claims based on maximum performance
®
: 10X** blade life.
®
slide lock for durability and comfort.
™
end hook for accurate measurements.
Blade
Length (ft)
Blade
Length (m)
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Graduated
in 16ths of an inch. Bottom edge: Major scale numbered in
consecutive meters. Minor scale numbered in consecutive 10 cm
repeated every 100 cm.
Top edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
896
Mylar® is a registered trademark of DuPont Teijin Films.
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® FATMAX® MAGNETIC TAPE RULES
■ 11' blade standout.
■ 1-1/4" wide blade for easy readability.
®
■ AirLock
■ Mylar
■ Tru-Zero
slide lock for durability and comfort.
®
lm extends life of entire blade.
™
magnetic hook for accurate
measurements in all positions.
■ Powerful rare earth magnet securely holds to
steel surfaces.
Product #
Blade
Length (ft)
Blade
Length (m)
FMHT33865S 25 – 1-1/4 16, 19.2
FMHT33866 26 8 1-1/4 16, 19.2
*Standout claims based on maximum performance
■ High-impact ABS case with durable rubber
holds up to heavy use.
■ Plastic blade lock makes locking and unlocking
easy.
■ Rubber grip provides comfortable, slip-
resistant hold.
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Graduated in 16ths of an inch. Bottom
edge: Major scale numbered in consecutive meters. Minor scale numbered in
Numbered in consecutive inches. Graduated in 16ths of an inch.
consecutive 10 cm repeated every 100 cm.
STANLEY® FATMAX® TAPE RULES W/ 11' BLADE STANDOUT
■ 11' blade standout.
■ 1-1/4" wide blade for easy readability.
■ BladeArmor
®
coating on the rst 3" maximizes
durability of the blade.
®
■ Mylar
lm extends life of entire blade.
■ High-impact ABS case with durable rubber
holds up to heavy use.
Product #
Blade
Length (ft)
Blade
Length (m)
33-716 16 – 1-1/4 16, 19.2
33-725 25 – 1-1/4 16, 19.2
33-726 26 8 1-1/4 16, 19.2
33-730 30 – 1-1/4 16, 19.2
33-805 33 10 1-1/4 16, 19.2
33-735 35 – 1-1/4 16, 19.2
33-740 40 – 1-1/4 16, 19.2
*Standout claims based on maximum performance Graduated in 16ths of an inch.
■ Plastic blade lock makes locking and unlocking
easy.
■ Rubber grip provides comfortable, slip-resistant
hold.
■ Three-rivet, corrosion-resistant Tru-Zero
hook for accurate measurements.
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Bottom edge: Numbered in consecutive
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Bottom edge: Numbered in consecutive
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Graduated in 16ths of an inch. Bottom
edge: Major scale numbered in consecutive meters. Minor scale numbered in
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Bottom edge: Numbered in consecutive
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Graduated in 16ths of an inch. Bottom
edge: Major scale numbered in consecutive meters. Minor scale numbered in
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Bottom edge: Numbered in consecutive
Top edge: Major scale numbered in consecutive feet. Minor scale numbered
in consecutive inches after each foot. Bottom edge: Numbered in consecutive
™
end
inches. Graduated in 16ths of an inch.
inches. Graduated in 16ths of an inch.
consecutive 10 cm repeated every 100 cm.
inches. Graduated in 16ths of an inch.
consecutive 10 cm repeated every 100 cm.
inches. Graduated in 16ths of an inch.
inches. Graduated in 16ths of an inch.
Short tape ruleS
STANLEY® FATMAX® KEYCHAIN TAPE RULE
■ 3' blade standout.
■ Polymer-coated blade withstands abrasion.
■ Convenient and lightweight. Handy for quick measurements.
Product #
Blade
Length (ft)
Blade
Width (in)
Markings (in) Graduation
FMHT33706 6 1/2 16, 19.2
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
■ Compact size ts in the pocket.
■ Durable key ring makes it easy to carry anywhere.
Stud
Scale numbered in consecutive inches and feet. First twelve inches graduated in
32nds of an inch. Remainder in 16ths of an inch.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
897
STANLEY® POWERLOCK® TAPE RULES WITH BLADEARMOR® COATING
■ 8' blade standout.
■ BladeArmor
■ Mylar
■ Compact case design.
■ Chrome high-impact ABS case is job site tough.
■ Secure blade lock won't creep during measurements.
■ Three-rivet, corrosion-resistant Tru-Zero
Short tape ruleS
Product #
®
coating on the rst 3" maximizes durability of the blade.
®
lm extends life of entire blade.
™
end hook for accurate measurements.
Blade
Length (ft)
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
33-516 16 1 16, 19.2
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
33-525 25 1 16, 19.2
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
33-530 30 1 16, 19.2
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
STANLEY® POWERLOCK® STAINLESS STEEL TAPE RULES
■ 7' blade standout.
■ Stainless steel blade and spring for rust resistance.
■ Stainless steel belt clip, hook and screws for rust resistance.
■ Nylon blade coating to help protect the blade for long life.
■ Compact case design.
■ Back-side blade print for vertical measurements.
™
■ Tru-Zero
Product #
STHT33456 16 5 3/4 16, 19.2
STHT33457 26 8 1 16, 19.2
hook for accurate inside and outside measurements.
Blade
Length (ft)
Blade
Length (m)
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Major scale numbered in consecutive meters. Minor scale numbered in consecutive
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Major scale numbered in consecutive meters. Minor scale numbered in consecutive
10 cm repeated every 100 cm.
10 cm repeated every 100 cm.
898
Mylar® is a registered trademark of DuPont Teijin Films.
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® POWERLOCK® TAPE RULES
■ 7' blade standout (excludes 33-116 and 33-158).
®
■ Mylar
lm extends life of entire blade.
■ High-impact, chrome plated ABS case.
■ Secure blade lock won't creep during measurements.
■ Corrosion-resistant Tru-Zero
Product #
Length (ft)
™
end hook for accurate measurements.
Blade
Blade
Length (m)
Blade
Width (in)
Stud
Markings (in) Graduation
33-116 16 – 3/4 16, 19.2
33-158 16 5 3/4 16, 19.2
33-425 25
–
1 16, 19.2
33-428 26 8 1 16, 19.2
33-430 30 – 1 16, 19.2
33-835 35 – 1 16, 19.2
Short tape ruleS
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot. First
twelve inches graduated in 32nds of an inch. Remainder in
16ths of an inch. Bottom edge: Numbered in consecutive
inches. First twelve inches graduated in 32nds of an inch.
Remainder in 16ths of an inch.
Top edge: Major scale numbered in consecutive inches. First
twelve inches graduated in 32nds of an inch. Remainder
graduated in 16ths of an inch. Marked every 12 inches. Bottom
edge: Major scale numbered in consecutive meters. Minor
scale numbered in consecutive 10 cm repeated every 100 cm.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Major scale
numbered in consecutive meters. Minor scale numbered in
consecutive 10 cm repeated every 100 cm.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
899
STANLEY® POWERLOCK® METAL CASE TAPE RULES
■ Durable die-cast metal case.
®
■ Mylar
lm extends life of entire blade.
■ Secure blade lock won't creep during measurements.
■ Corrosion-resistant Tru-Zero
™
end hook for accurate measurements.
Blade
Product #
Short tape ruleS
33-212 12 – 1/2 16, 19.2
Length (ft)
Blade
Length (m)
Width (in)
33-215 12 3.5 1/2 16, 19.2
33-272 12 – 1/2 16, 19.2
33-312 12 – 3/4 16, 19.2
STANLEY® POWERLOCK® POCKET TAPE RULE
■ Polymer-coated blade withstands abrasion for long life.
■ Chrome high-impact ABS case is job site tough.
■ Slim case ts easily in pocket.
■ Secure blade lock won't creep during measurements.
■ Corrosion-resistant Tru-Zero
■ Back of blade provides scale that measures up to 3' diameter graduated in 1/64".
™
end hook for accurate measurements.
Blade
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot. First
twelve inches graduated in 32nds of an inch. Remainder in
16ths of an inch. Bottom edge: Numbered in consecutive
inches. First twelve inches graduated in 32nds of an inch.
Remainder in 16ths of an inch.
Top edge: Numbered in consecutive inches. First twelve inches
graduated in 32nds of an inch. Remainder graduated in 16ths
of an inch. Marked every 12 inches. Bottom edge: Major scale
numbered in consecutive meters. Intermediate scale numbered
in consecutive 100 mm repeated every meter. Minor scale
numbered in consecutive 10 mm repeated every 100 mm.
Graduated in mm.
Top edge: Numbered in consecutive inches. First six inches
graduated in 0.03125". Remainder graduated in 0.0625".
Bottom edge: Numbered in consecutive 0.10", repeated every
inch. Graduated in 0.02" for the rst six inches. Remainder
graduated in 0.10".
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot. First
twelve inches graduated in 32nds of an inch. Remainder in
16ths of an inch. Bottom edge: Numbered in consecutive
inches. First twelve inches graduated in 32nds of an inch.
Remainder in 16ths of an inch.
900
Product #
Blade
Length (ft)
Blade
Width (in)
Stud
Markings (in) Graduation
Major scale numbered in consecutive feet. Minor scale numbered in consecutive
33-115 10 1/4 16, 19.2
inches. First twelve inches graduated in 32nds of an inch. Remainder in 16ths of an
STANLEY® POWERLOCK® KEYCHAIN TAPE RULE
■ Polymer-coated blade withstands abrasion.
■ Durable key ring makes it easy to take anywhere.
■ Convenient and lightweight.
Blade
Product #
Length (ft)
39-130 3 1/4 16
Blade
Width (in)
Stud
Markings (in) Graduation
Major scale numbered in consecutive feet. Minor scale numbered in consecutive
inches. First twelve inches graduated in 32nds of an inch. Remainder in 16ths of an
Mylar® is a registered trademark of DuPont Teijin Films.
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
inch.
inch.
STANLEY® VALUE PACK
Product #: 90-082
■ 7' blade standout.
®
■ Mylar
lm extends life of entire blade.
■ High-impact, chrome plated ABS case.
■ Secure blade lock won't creep during measurements.
■ Corrosion-resistant Tru-Zero
Contents Description
1 Tape Rule (33-425)
1 Knife (10-099)
™
end hook for accurate measurements.
Short tape ruleS
STANLEY® PREMIUM TAPE RULES
■ Rugged case design ABS structure core surrounded by rubber for superior
impact resistance.
■ Integrated lock protection lock button guarded by large ruber pad in case
of drop.
■ 10' standout best standout of MPP tapes for better efciency.
■ 1-1/8' wide blade premium feel with large easy to read numbers.
Blade
Product #
Length (ft)
STHT33594S 16 1-1/8 16, 19.2
STHT33596LW 25 1-1/8 16, 19.2
STHT33597S 30 1-1/8 16, 19.2
Blade
Width (in)
Markings (in) Graduation
Stud
GraduationTop edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
GraduationTop edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
GraduationTop edge: Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches after each foot. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
901
STANLEY® LEVERLOCK® FRACTIONAL TAPE RULES WITH MAGNETIC TIP
■ Push-release self-locking mechanism controls blade retraction.
■ Polymer-coated blade withstands abrasion.
■ Magnetic end hook holds securely to metal surfaces.
■ High-impact ABS case with durable rubber holds up to heavy use.
■ Corrosion-resistant Tru-Zero
■ fractional read blade graphics for quick and easy measurements.
™
end hook for accurate measurements.
Product #
Blade
Length (ft)
Blade
Width (in)
Short tape ruleS
STHT33281 25 1 16, 19.2 Yellow
STHT33270 25 1 16, 19.2 Orange
STANLEY® LEVERLOCK® TAPE RULE
■ Automatic blade lock holds blade securely in position.
■ Write-on label for repeated use with carpenter pencil.
■ Non-marring frictionless base to help protect work surface.
■ Easy inside/outside measurements.
■ 1.5X* stronger anti-glare blade.
Blade
Product #
Length (ft)
STHT30810 12 – 1/2
STHT30812 16 – 3/4
STHT30825 25 – 1
STHT30824S 26 8 1
STHT30830 30 – 1
STHT30758L 25 – 1
STHT30759L 25 – 1
Blade
Length (m)
Stud
Markings (in) Color Graduation
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
Blade
Width (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch.
Bottom edge: Numbered in consecutive inches. First twelve inches graduated in
32nds of an inch. Remainder in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. First twelve inches graduated in 32nds of an
inch. Remainder in 16ths of an inch. Bottom edge: Numbered in consecutive inches.
First twelve inches graduated in 32nds of an inch. Remainder in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch.
Bottom edge: Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Major scale numbered in consecutive meters. Minor scale numbered in consecutive
10 cm repeated every 100 cm.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch.
Bottom edge: Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch.
Bottom edge: Numbered in consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch.
Bottom edge: Numbered in consecutive inches. Graduated in 16ths of an inch.
*1.5X improved wear resistance of blade markings in
tests compared to STANLEY standard tape 30-419
902
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® TAPE RULES
■ Versatile 1/2", 3/4", and 1" wide blades and 7' standout (1" wide blades only).
■ Polymer-coated blade withstands abrasion.
■ Corrosion-resistant Tru-Zero
■ fractional read blade graphics for quick and easy measurements (only on 30-454).
■ Ergonomically designed high-impact, ABS case.
™
end hook for accurate measurements.
Short tape ruleS
Product #
Blade
Length (ft)
Blade
Length (m)
Blade
Width (in)
Stud
Markings (in) Graduation
30-506 6 – 1/2 16, 19.2
30-485 12 – 1/2 16, 19.2
30-495 16 – 3/4 16, 19.2
30-496 16 5 3/4 16, 19.2
30-456 26 8 1 16, 19.2
30-454 25 – 1 16, 19.2
30-455 25 – 1 16, 19.2
30-464 30 – 1 16, 19.2
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. First twelve inches graduated in 32nds of
an inch. Remainder in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. First twelve inches graduated in 32nds of
an inch. Remainder in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot. First
twelve inches graduated in 32nds of an inch. Remainder in
16ths of an inch. Bottom edge: Numbered in consecutive
inches. First twelve inches graduated in 32nds of an inch.
Remainder in 16ths of an inch.
Top edge: Numbered in consecutive inches. First twelve inches
graduated in 32nds of an inch. Remainder graduated in 16ths
of an inch. Marked every 12 inches. Bottom edge: Numbered in
consecutive cm. Graduated in mm. Marked every 10 cm.
Top edge: Numbered in consecutive inches. First twelve inches
graduated in 32nds of an inch. Remainder graduated in 16ths
of an inch. Marked every 12 inches. Bottom edge: Numbered in
consecutive cm. Graduated in mm. Marked every 10 cm.
Major scale numbered in consecutive feet. Minor scale
numbered in consecutive inches. Graduated in 16ths of an
inch. Numerical readouts every 8th of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
Top edge: Major scale numbered in consecutive feet. Minor
scale numbered in consecutive inches after each foot.
Graduated in 16ths of an inch. Bottom edge: Numbered in
consecutive inches. Graduated in 16ths of an inch.
STANLEY® HIGH-VISIBILITY TAPE RULE
■ Polymer-coated blade withstands abrasion.
■ High-impact, high-visibility green ABS case is over molded with soft-grip rubber.
■ Corrosion-resistant Tru-Zero
Product #
Length (ft)
30-305 25 1 16, 19.2
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
™
end hook for accurate measurements.
Blade
Blade
Width (in)
Stud
Markings (in) Graduation
Top edge: Major scale numbered in consecutive feet. Minor scale numbered in
consecutive inches after each foot. Graduated in 16ths of an inch. Bottom edge:
Numbered in consecutive inches. Graduated in 16ths of an inch.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
903
STANLEY® FATMAX® CLOSED CASE LONG TAPE
■ 3:1 gear drive for fast rewinds.
■ Polymer-coated blade withstands abrasion.
■ Steel roller cage protects case from being cut by blade during rewind.
■ High-impact, yellow ABS case is over molded with soft-grip rubber for
maximum comfort, slip-resistant grip, and durability.
■ Corrosion-resistant Tru-Zero
long tape ruleS
™
folding end hook for accurate measurements.
Product #
Blade
Length (ft)
Blade
Width (in)
Stud
Markings (in) Graduation
34-130 100 3/8 16
STANLEY® CLOSED CASE LONG TAPES
■ High impact, high visibility yellow ABS case.
■ Polymer-coated blade withstands abrasion for a long life.
■ Easy wind drum for easy retraction.
■ Easy to read markings.
■ Hook nests neatly into contoured case.
■ Belt clip for hands-free use and convenient transportation.
■ Corrosion-resistant Tru-Zero
™
folding end hook for accurate measurements.
Major scale in consecutive feet. Minor scale numbered in consecutive inches after
each foot. Graduated in 8ths of an inch.
904
Product #
Blade
Length (ft)
Blade
Width (in)
Markings (in) Graduation
34-103 50 3/8 16
34-106 100 3/8 16
Stud
Major scale in consecutive feet. Minor scale numbered in consecutive inches after
each foot. Graduated in 8ths of an inch.
Major scale in consecutive feet. Minor scale numbered in consecutive inches after
each foot. Graduated in 8ths of an inch.
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® POWERWINDER® OPEN REEL LONG TAPES
■ Rewinds 3X faster* with 3:1 gear drive.
■ 1/2" wide blade for easy readability.
■ 2-sided blade graphics with fractional inch/decimal foot scales for versatility.
■ Reinforced blade end for long life.
■ End loop for easy pulling and anchoring.
■ High-impact ABS case with durable rubber grip holds up to heavy use.
■ Corrosion-resistant Tru-Zero
■ Blade bumper to help prevent blade damage.
™
folding end hook for accurate measurements.
long tape ruleS
Product #
Blade
Length (ft)
Blade
Length (m)
Blade
Width (in) Graduation
Side One: Major scale in consecutive feet. Minor scale numbered in consecutive
34-760 100 – 1/2
inches after each foot. Graduated in 8ths of an inch. Side Two: Major scale in
consecutive feet. Minor scale numbered in consecutive 10ths of a foot repeated
every foot. Graduated in 100ths of a foot.
Side One: Major scale in consecutive feet. Minor scale numbered in consecutive
34-762 300 – 1/2
inches after each foot. Graduated in 8ths of an inch. Side Two: Major scale in
consecutive feet. Minor scale numbered in consecutive 10ths of a foot repeated
every foot. Graduated in 100ths of a foot.
34-771 100 30 1/2 Two sided blade graphics with fractional inch and metric graduations.
34-774 200 60 1/2 Two sided blade graphics with fractional inch and metric graduations.
*Than base STANLEY
STANLEY® FIBERGLASS OPEN REEL LONG TAPES
■ 1/2" wide blade with easy-to-read markings.
■ 2-sided blade graphics with fractional inch/decimal foot scales.
■ Polymer-coated blade withstands abrasion.
■ High-impact ABS case with rubber grip holds up to heavy use
■ Corrosion-resistant Tru-Zero
™
folding end hook for accurate measurements.
®
model.
Product #
Blade
Length (ft)
Blade
Width (in) Graduation
34-790 100 1/2
34-793 200 1/2
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
Side One: Major scale in consecutive feet. Minor scale numbered in consecutive inches after each
foot. Graduated in 8ths of an inch. Side Two: Major scale in consecutive feet. Minor scale numbered in
consecutive 10ths of a foot repeated every foot. Graduated in 100ths of a foot.
Side One: Major scale in consecutive feet. Minor scale numbered in consecutive inches after each
foot. Graduated in 8ths of an inch. Side Two: Major scale in consecutive feet. Minor scale numbered in
consecutive 10ths of a foot repeated every foot. Graduated in 100ths of a foot.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
905
STANLEY® FATMAX® PREMIUM BOX BEAM LEVELS
■ Magnied center block vial for easy readability.
■ Block plumb vials for accuracy of 0.0005"/in.
■ Enlarged vial housing for bright lit vials.
levelS
■ Removable end cap for ush and accurate markings.
■ Fold out rafter hook* on-site convenient storage solution.
■ MaxEdge
™
bridged center vial for continuous marking surface and durability.
Product #
Overall Length (in) Vials Hand Holes Magnetic Height (in) Width (in)
FMHT42355 24 3 (1 Level, 2 Plumb) 1 N 2-1/2 1-1/4
FMHT42491 32 3 (1 Level, 2 Plumb) 1 Y 2-1/2 1-1/4
FMHT42400 48 3 (1 Level, 2 Plumb) 2 N 2-1/2 1-1/4
FMHT42493 58 3 (1 Level, 2 Plumb) 2 N 2-1/2 1-1/4
FMHT42401 72 3 (1 Level, 2 Plumb) 2 N 2-1/2 1-1/4
FMHT42407 78 3 (1 Level, 2 Plumb) 2 Y 2-1/2 1-1/4
FMHT42408 96 3 (1 Level, 2 Plumb) 2 N 2-1/2 1-1/4
*Larger than 48" no rafter hook.
STANLEY® BOX BEAM LEVELS
■ Center block vial for durability and accuracy of 0.0005"/in.
■ Large 12mm tubular plumb vials for accuracy of 0.001"/in.
■ Enlarged vial housing for bright lit vials.
■ Shock-absorbing end caps for durability and long life.
■ MaxEdge
Product #
STHT42496 24 3 (1 Level, 2 Plumb) 1 N 2-5/8 1-1/4
STHT42497 24 3 (1 Level, 2 Plumb) 1 Y 2-5/8 1-1/4
STHT42504 48 3 (1 Level, 2 Plumb) 2 N 2-5/8 1-1/4
STHT42505 48 3 (1 Level, 2 Plumb) 2 Y 2-5/8 1-1/4
™
bridged center vial for continuous marking surface and durability.
Overall Length (in) Vials Hand Holes Magnetic Height (in) Width (in)
906
STANLEY® PRO I-BEAM LEVELS
■ Heavy-duty aluminum I-beam construction provides rigidity and accuracy.
■ Vials provide accuracy of 0.0015 in/in (0.15mm/m).
■ 360° vials set directly into frame never need adjustment.
■ Pipe groove for use on rounded surfaces.
■ Shock-absorbing end caps hold up to heavy use.
Product #
42-480 48 3 (1 Level, 2 Plumb) 0 2 1
42-324 24 3 (1 Level, 1 Plumb, 1 180°) 1 0 1
42-328 48 3 (1 Level, 1 Plumb, 1 180°) 1 2 1
Overall Length (in) Vials Hang Holes Hand Holes Width (in)
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® ALUMINUM TOP-READ LEVELS
■ Durable, I-beam construction made of aluminum.
■ Vials provide accuracy of 0.002 in/in (2mm/m).
■ Center top read vial for improved visibility.
■ Low prole, shock-absorbing end caps.
Overall Length
Product #
(in) Vials Hand Holes
42-072 12 3 (1 Level, 1 Plumb, 1 45°) 0
42-074 24 3 (1 Level, 1 Plumb, 1 45°) 1
42-076 48 3 (1 Level, 1 Plumb, 1 45°) 2
STANLEY® HIGH-IMPACT ABS LEVELS
■ Durable, shock-resistant ABS construction.
■ Top-read center vial designed for instant readability.
■ Measuring scale adds utility.
■ Non-marring material helps prevent damage to nished surfaces.
■ High-visibility yellow is easy to spot on the job site.
Overall Length
Product #
42-466 12 3 (1 Level, 1 Plumb, 1 45°) 0
42-468 24 3 (1 Level, 1 Plumb, 1 45°) 2
42-470 48 3 (1 Level, 1 Plumb, 1 45°) 6
(in) Vials Hand Holes
levelS
STANLEY® I-BEAM LEVELS
■ Large 12 mm tubular plumb vials for accuracy of 0.001 in/in.
■ Continuous edge to scribe and score lines.
■ Heavy-duty body design for wide base and thick extrusions.
■ Shock-absorbing end caps for durability and long life.
Product #
Overall Length (in) Vials Hand Holes Height (in) Width (in) Magnetic
STHT42409 24 3 (1 Level, 2 Plumb) 1 2-13/32 1 No
STHT42411 24 3 (1 Level, 2 Plumb) 1 2-13/32 1 Yes
STHT42420 48 3 (1 Level, 2 Plumb) 2 2-13/32 1 No
STHT42421 48 3 (1 Level, 2 Plumb) 2 2-13/32 1 Yes
STHT42425 78 3 (1 Level, 2 Plumb) 2 2-13/32 1 Yes
STANLEY® FATMAX® MAGNETIC TORPEDO LEVEL
■ Die-cast aluminum body for durability.
■ Solid block vials provide accuracy of 0.0005in/in (0.5mm/m).
■ Magnied center vial for visibility.
■ Pipe groove for use on rounded surfaces.
■ Rare-earth magnets for great holding power.
Overall
Product #
Length (in) Vials Hang Holes Magnetic
43-605 9 2 2 Yes
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
907
STANLEY® SHOCK-RESISTANT MAGNETIC TORPEDO LEVEL
■ Heavy-duty aluminum frame and bi-material body with shock absorbing
rubber ends for strength and durability.
■ Vials provide accuracy of 0.002 in/in (2mm/m).
■ Open, top-read vial provides maximum readability.
levelS
■ Magnetic strip to allow for hands-free operation on metal surfaces.
■ Lighted version with auto shutoff is designed for low-light locations.
■ Pipe groove for use on rounded surfaces.
Product #
Overall Length (in) Vials Hang Holes Magnetic
43-511 9 3 (1 Level, 1 Plumb, 1 45°) 2 Yes
STANLEY® CAST ALUMINUM MAGNETIC TORPEDO LEVEL
■ Heavy-duty, cast aluminum frame.
■ Vials provide accuracy of 0.002 in/in (2mm/m).
■ Center top read vial for improved visibility.
■ Magnetic strip to allow for hands free operation on metal surfaces.
■ Pipe groove for use on rounded surfaces.
Product #
Overall Length (in) Vials Hang Holes Magnetic
42-465 9 3 (1 Level, 1 Plumb, 1 45°) 1 Yes
STANLEY® HIGH IMPACT ABS MAGNETIC TORPEDO LEVEL
■ Durable, shock-resistant ABS construction.
■ Vials provide accuracy of 0.002 in/in (2mm/m).
■ Center top read vial for improved visibility.
■ Magnetic strip to allow for hands free operation on metal surfaces.
■ Non-marring material will not damage nished surfaces.
■ Pipe groove for use on rounded surfaces.
908
Product #
Overall Length (in) Vials Hang Holes Magnetic
42-264 9 3 (1 Level, 1 Plumb, 1 45°) 1 Yes
STANLEY® HIGH IMPACT ABS TORPEDO LEVELS
■ Durable, shock-resistant ABS construction.
■ Vials provide accuracy of 0.002 in/in (2mm/m).
■ Center top read vial for improved visibility.
■ Non-marring material will not damage nished surfaces.
■ Pipe groove for use on rounded surfaces.
Product #
42-294 8 3 (1 Level, 1 Plumb, 1 45°) 1 Orange No
42-291 8 3 (1 Level, 1 Plumb, 1 45°) 1 Black Yes
Overall Length (in) Vials Hang Holes Color Magnetic
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® FATMAX® EXTRUDED TORPEDO LEVEL – 9"
■ Magnied center block vial for durability and accuracy of 0.0005 in/in.
■ Block plumb and 45° vials for multiple leveling applications with accuracy of
0.0005 in/in.
■ Extruded aluminum body for strength and light weight.
■ Over-molded rubber end caps for non-marring leveling and shock resistance.
levelS
Product #
Overall Length (in) Vials Hang Holes Magnetic Height (in) Width (in)
FMHT42437 9 3 (1 Level, 1 Plumb, 1 45°) 2 Yes 1-15/16 7/8
STANLEY® FATMAX® MAGNETIC CAST TORPEDO LEVEL – 9"
■ Magnied center block vial provides accuracy of 0.0005 in/in.
■ Block plumb vials for an accuracy of 0.0005 in/in.
■ Rare earth magnets for ultimate holding power.
■ 180° rotating vial for duplicating precise angles.
■ Die-cast aluminum Body for strength and long life.
Product #
Overall Length (in) Vials Hang Holes Height (in) Width (in)
FMHT43610 9 3 (1 Level, 1 Plumb, 1 180°) 2 1-7/8 7/8
STANLEY® POST LEVEL
■ Folds at for easy storage in tool bins and pockets.
■ Vials enclosed when closed to reduce risk of breakage.
■ On-board storage of line level.
■ When closed, there is an area for storing small bits, blades, etc.
■ Magnetic to adhere to metal surfaces.
Product #
Overall Length (in) Vials Hang Holes
47-720 5-55/64 3 1
STANLEY® LINE LEVELS
■ Special hang hooks grip line which enables level to slide freely for positioning.
■ Flat base is ideal for surface leveling.
■ Construction of aluminum line level (42-287) is lightweight and durable.
■ High visibility plastic line level (42-193) is lightweight and provides large
viewing area.
Product #
42-193 3 1 (1 Level) High-Visibility Plastic Yellow
42-287 3 1 (1 Level) Aluminum Silver
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
Overall Length (in) Vials Type Color
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
909
STANLEY® FATMAX® CHALK REELS
■ Die-cast aluminum housing for durability.
■ 2X stronger* line – 3X* line abrasion resistance.
■ Rewinds 5X faster* – has a 5:1 gear ratio.
■ Quick gear release – crank will not spin when pulling out line.
■ Stainless steel hook and crank handle.
■ On-board hook storage.
■ ChalkView
Chalk lineS
■ Premium polymer string resists breakage and fraying.
™
case – see amount of chalk inside case.
Product #
Contents Chalk Line (ft)
47-480L (1) Aluminum Chalk Line Reel 100
47-482L
47-487L
(1) Aluminum Chalk Line Reel,
(1) 4 oz. Blue Chalk
(1) Aluminum Chalk Line Reel,
(1) 4 oz. Red Chalk
* Than base STANLEY
100
100
®
model 47-099
STANLEY® FATMAX® CHALK REELS
■ Rewinds 3X faster* – has a 3:1 gear ratio.
■ Holds up to a 4 oz. bottle of STANLEY
■ Stainless steel interlocking hook for joining lines.
■ Chalk line has 2X the tensile strength of traditional lines and lasts twice as long.
■ Water-resistant, high-impact ABS case with rubber grips is durable and easy to hold.
■ Door for simplied relling.
Product #
47-140L (1) Chalk Line Reel 100
47-681L
(1) Chalk Line Reel, (1) 4 oz. Blue Chalk,
(1) Fine Tip Marker
®
chalk.
Contents Chalk Line (ft)
100
®
* Than base STANLEY
model 47-099
STANLEY® POWERWINDER® CHALK REELS
■ Patented ChalkView
■ Rewinds 3X faster *– has a 3.5:1 gear ratio.
■ Stainless steel crank handle and hook.
■ Crank clutch – crank handle will not spin when pulling out string.
■ On-board hook storage.
■ 100 feet of high strength string.
™
Case - see amount of chalk inside the case.
910
Product #
Contents Chalk Line (ft)
47-460 (1) Chalk Line Reel 100
47-464
(1) Chalk Line Reel, (1) 4 oz. Blue Chalk,
(1) Plastic Line Level
* Than base STANLEY
®
model 47-099
STANLEY® DIE-CAST CHALK REELS
■ Durable, heavy-duty die-cast aluminum body for long life.
■ Long-wearing felt gasket hugs line and distributes uniform chalk coating.
■ Universal hook has been designed for the rigors of everyday use.
■ Can be used as plumb bob.
Product #
47-099 (1) Chalk Line Reel 100
47-117L (1) Chalk Line Reel, (1) 4 oz. Blue Chalk 100
Contents Chalk Line (ft)
100
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® CHALK LINE REELS
■ High impact ABS case.
■ On-board hook storage.
■ Stainless steel hook.
■ Folding crank handle stores neatly into case.
■ Sliding door for easy lling.
Chalk lineS
Product #
Contents Chalk Line (ft)
47-440 (1) Chalk Line Reel 100
47-442 (1) Chalk Line Reel, (1) 4 oz. Blue Chalk 100
47-443
(1) Chalk Line Reel, (1) 4 oz. Blue Chalk,
(1) Plastic Line Level
100
STANLEY® COMPACT CHALK LINE REEL
■ Less than half the size of standard chalk reels (by volume).
■ 30’ (9 m) precision line snaps clean, accurate lines.
■ High-impact ABS housing for durability and light weight.
■ Over-molded soft grip helps provide comfortable and secure grip.
■ 3:1 rewind gear ratio retracts line 3X faster than standard 1:1 reels.
■ Slide-open door for quick chalk rells.
■ Chalk reel capacity snaps more than 50 lines per rell.
■ Belt clip for convenient transport.
Product #
STHT47147 Compact Chalk Line Reel 30
STHT47244L
Contents Chalk Line (ft)
(1) Compact Chalk Line Reel,
(1) 4 oz. Blue Chalk
30
STANLEY® CHALK LINE REPLACEMENT
■ High quality replacement line.
■ 100 ft. (30 m) line cartridge.
Product #
Contents Chalk Line (ft)
47-101 Chalk Line Replacement 100
STANLEY® FATMAX® CHALK REFILLS
■ Snaps longer lasting, weather and fade resistant lines.
■ Eliminates chalk clumping in wet environment.
■ Reduces amount of chalk waste when pulling line out of chalk box.
■ Rectangular like shaped bottles won’t roll off work surfaces.
■ Pop-off cap is tethered to bottle to prevent loss.
Product #
47-821 Red 0.50
47-822 Black 0.50
47-827 Black 5.00
47-828 Red 5.00
Color Weight (lbs)
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
911
STANLEY® T-BEVEL
■ Durable stainless steel blade.
■ Built-in blade lock for transferring angles.
■ Tough plastic handle provides handy, comfortable grip.
Product #
46-825 8 5-1/2
Blade Length (in) Handle Length (in)
layout toolS
STANLEY® BRASS PLUMB BOBS
■ Polished lacquer, solid brass construction for durability and rust resistance.
■ Replaceable, hardened steel tip is long lasting.
■ Extra tip included.
■ Screw top simplies attaching string to center of plumb.
■ Thru hole ensures easy tightening.
Product #
47-973 8-11/16 0.50
47-974 8-11/16 1.00
Overall Length (in) Weight (lbs)
912
STANLEY® GREEN MASON’S LINE
■ High quality black and white twisted polyester line.
■ 250-foot length, 18-pound test.
Product #
STHT47370 250 Green
Length (ft) Color
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® FATMAX® CHISEL TIP MARKER
■ Permanent ink writes on wet and oily surfaces.
■ Durable chisel tip writes both ne and thick lines.
■ Bi-material body is easy to grip.
Marking
Product #
Color
47-314 Black
STANLEY® FINE TIP MARKERS
■ Quick-drying, water-resistant ink marks on almost all surfaces.
■ Permanent on most surfaces.
■ Durable ne tip for long-lasting usage.
Product #
47-316 (2) Black Fine Tip Markers Black
47-324B (72) Mini Black Fine Tip Markers - Bulk Black
47-329B
(72) Mini Multicolor Fine Tip Marker - Bulk Black
47-346B (50) Black Fine Tip Marker – Bulk Black
Contents Color
STANLEY® CARPENTER PENCIL
■ Rectangular #2 graphite core for clear marking.
■ Constructed of linden wood for strength.
Product #
Type Pencil Tip Lead Color
47-350 Multi-Pack Fine Black
STANLEY® PREMIUM ALUMINUM RAFTER SQUARE
■ Extra-thick aircraft-grade aluminum maximizes durability and maintains accurate square.
■ Individually inspected for accuracy.
■ Embossed graduations are painted yellow for readability in most light conditions.
■ Markings include brace measures, octagon scale, board measures and rafter table.
■ Surface treated to resist corrosion.
Product #
45-011
Graduation (in)
Face: 1/8, 1/4, 1/2
Back: 1/16, 1/8, 1/4, 1/2
Body
Length (in)
24 x 2 16 x 1-1/2
Tongue
Length (in)
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
913
STANLEY® STEEL RAFTER SQUARES
■ High quality hardened steel provides durability and long life.
■ Markings include Essex board measure, octagon scale, brace scale and rafter table.
■ Durable, embossed graduations and gures for easy reading.
■ Buffed nish with a clear lacquer that resists rust.
SquareS
Product #
45-910
45-530
Graduation (in)
Face: 1/8, 1/4, 1/2
Back: 1/16, 1/8, 1/4, 1/2
Face: 2 mm;
Back: 2 mm
Body
Length (in)
24 x 2 16 x 1-1/2
610 mm x 51 mm 400 mm x 38 mm
Tongue
Length (in)
STANLEY® ALUMINUM CARPENTER’S SQUARE
■ High quality aluminum for maximum durability.
■ Durable, embossed graduations and gures for easy reading.
■ Provides helpful reference conversion tables such as new lumber scale,
decimal equivalent table, metric conversion table, formula for squaring a
foundation, 45°, 60° and 30° angle markings, volume and area formulas,
wood screw gauge table, nail sizes (common and nish), quantity per
pound and depth scale.
■ Protective lacquer coating resists corrosion.
Product #
Graduation (in)
Length (in)
45-300 Face: 1/8; Back: 1/8 24 x 2 16 x 1-1/2
Body
Tongue
Length (in)
STANLEY® STEEL CARPENTER’S SQUARES
■ High quality hardened steel for durability and long life.
■ Embossed graduations for easy reading on face and back.
■ Reverse reading scale allows for efcient measuring.
■ Treated with a clear, protective nish that resists rust.
Product #
Graduation (in)
Body
Length (in)
Tongue
Length (in)
45-912 Face: 1/16; Back: 1/16 12 x 1-1/2 8 x 1
45-500 Face: 1/8; Back: 1/8 24 x 2 16 x 1-1/2
STANLEY® PREMIUM ADJUSTABLE QUICK SQUARE® LAYOUT TOOL
■ Heavy-duty aluminum construction for durability.
■ Black body with yellow graduations provides maximum readability in various
light conditions.
■ Features Common, Jack and Hip, and Valley scales for various applications.
■ Multipurpose, adjustable design can be used as a saw guide, bevel or protractor.
■ Comes with an adjustable arm.
Product #
46-053 1/8 10-3/4 6-3/4
Graduation (in) Base Length (in) Rule Length (in)
914
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® PREMIUM QUICK SQUARE® LAYOUT TOOL
■ Durable aluminum construction.
■ Black body with yellow graduations provides maximum readability in
various light conditions.
■ Multipurpose tool is ideal for use as a 0° to 90° protractor scale.
■ Works well as a saw guide.
SquareS
Product #
Graduation (in) Base Length (in) Rule Length (in)
46-071 1/8 7-1/4 6-7/8
STANLEY® QUICK SQUARE® LAYOUT TOOL
■ Aluminum construction for durability.
■ Multipurpose design can be used as a saw guide, for special angle
measurements and cuts, or as a protractor.
Product #
Graduation Base Length (in) Rule Length (in)
46-067 1/8 10-1/4 6-3/4
STANLEY® DUAL-COLOR SQUARES
■ Molded-in contrasting color graduations for readability.
■ Wrapping graduations for accuracy.
■ Extra-thick ABS plastic body holds up to heavy-duty use.
■ Large base helps provide grip on materials.
■ Thick body for use as saw guide.
Overall
Product #
Length (in) Base Length (in) Rule Length (in)
STHT46010 7-19/64 1-1/8 7
STHT46011 12 1-1/8 12
STANLEY® QUICK SQUARE® POCKET SQUARE LAYOUT TOOL
■ ABS plastic body holds up to heavy-duty use.
■ Versatile layout tool works as a rafter square, try square, protractor or
power saw guide.
Product #
46-060 1/8 10 6-7/8
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
Graduation (in) Base Length (in) Rule Length (in)
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
915
STANLEY® ALUMINUM TRY/MITER SQUARE WITH PLASTIC HANDLE
■ Lightweight aluminum body with durable plastic handle.
■ Ideal for laying out 45° and 90° angles.
■ 8" blade with embossed 1/16" graduations.
SquareS
Product #
Graduation (in) Blade Length (in) Blade Width (in) Handle Length (in)
46-502 1/16 8 1-1/2 5-1/8
STANLEY® PREMIUM DIE-CAST HANDLE COMBINATION SQUARES
■ Durably etched, hard-chrome-plated blades are rust-resistant and made to last.
■ Precision-machined working surfaces for improved accuracy.
■ Built-in scriber comes in handy for surface marking.
■ Easy-to-read vial.
Product #
Graduation (in) Vials Blade Length (in) Blade Width (in) Square
46-028 1/16 1 (1 Level) 12 1 45°, 90°
46-123* 1/32, 1/16, 1/8 1 (1 Level) 12 1 45°, 90°
46-131* 1/32, 1/16, 1/8 1 (1 Level) 16 1 45°, 90°
*High-visibility yellow, die-cast handle with brass hardware for durability.
STANLEY® DIE-CAST HANDLE COMBINATION SQUARE
■ Embossed hard-chrome blade is coated to resist rust.
■ Built-in scriber comes in handy for surface marking.
■ Easy-to-read vial.
■ Durable, black die-cast metal handle.
916
Product #
Graduation (in) Vials Blade Length (in) Blade Width (in) Square
46-222 1/32, 1/16, 1/8 1 (1 Level) 12 1 45°, 90°
STANLEY® PLASTIC HANDLE COMBINATION SQUARE
■ Embossed hard-chrome blade is coated to resist rust.
■ Easy-to-read vial.
■ Lightweight, plastic handle.
Product #
46-012 1/32, 1/16, 1/8 1 (1 Level) 12 1 45°, 90°
Graduation (in) Vials Blade Length (in) Blade Width (in) Square
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® 3 BEAM SPOT LASER - SPL3
■ Project 3 Beams – Up, Down, Horizontal: 3 bright, self leveling beams provide accurate, plumb and
horizontal point transfer.
■ Projects Down Beam with Raised Clearance: Provides dot visibility and alignment for wall track layout.
■ Range 100’ / Accuracy +/-1/8": Performance supports common pro and tradesman applications.
■ QuickLink
™
Bracket and Mounting System: Versatile bracket links into multiple product mounting slots
and ¼" thread, Clamps on to multiple surfaces.
■ Locking Pendulum: To help prevent damage to internal components.
■ Over-molded Grips: For comfort & control.
Overall
Product #
Length (in) Height (in) Width (in) Weight (lbs)
STHT77342 9 3-3/4 6-5/8 1.03
STANLEY® CROSS 90™ CROSS LINE LASER
■ Self Leveling Cross Lines: Projects bright horizontal & vertical lines onto at surfaces for
common leveling and alignment applications.
■ 90° Vertical Line: For an additional reference point for multiple applications.
■ QuickLink
mounting slots and ¼" thread, Clamps on to multiple surfaces.
■ Range 50’ / Accuracy +/- 3/16": Performance supports common tradesman applications.
■ Locking Pendulum: For setting angled lines: To help prevent damage to internal components.
■ Over-molded Grips: For comfort & control.
™
Bracket and Mounting System: Versatile bracket links into multiple product
eleCtroniC layout toolS
Overall
Product #
Length (in) Height (in) Width (in) Weight (lbs)
STHT77341 9-3/8 3-7/8 6-5/8 1.65
STANLEY® CUBIX™ CROSS LINE LASER
■ Self Leveling Cross Lines: Projects bright horizontal & vertical lines onto at surfaces for
common leveling and alignment applications.
■ QuickLink
™
Bracket and Mounting System: Versatile bracket links into multiple product
mounting slots and ¼" thread, Clamps on to multiple surfaces.
■ Range 40’ / Accuracy +/-5/16": Performance supports common tradesman applications.
■ Locking Pendulum: For setting angled lines, To help prevent damage to internal components.
■ Compact, Lightweight Design.
Overall
Product #
Length (in) Height (in) Width (in) Weight (lbs)
STHT77340 8-1/4 2-1/4 6-3/8 1.48
STANLEY® MANUAL WALL LASER
■ Raised bubble vials help improved visibility in most working environments.
■ 360° rotating wall attachment projects laser at any angle.
Overall
Product #
Length (in) Height (in) Width (in) Weight (lbs)
STHT77148 9-3/16 1-11/16 7-3/8 0.55
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
917
STANLEY® SELF-LEVELING WALL LASER
■ Self-leveling for quick and precise leveling.
■ AnglePro
■ 90° locking positions project horizontally or vertically.
Product #
STHT77149 9-3/16 2-3/8 7-3/8 1.01
™
automatic reference lines for projection of lines at any angle.
Overall
Length (in) Height (in) Width (in) Weight (lbs)
STANLEY® INTELLILASER™ STUD FINDER WITH LASER
■ Backlit LCD screen clearly displays all of the sensor’s readings, even in low light conditions.
eleCtroniC layout toolS
■ 180° rotatable leveling head that projects laser lines up to 20 feet onto a work surface.
■ Detects wood/metal studs through multiple wall thicknesses (1/2", 1", 1-1/2").
■ Continuous live wire detection.
■ Ergonomic design, and soft grips provide comfort and control of the tool.
Product #
Overall Length (in) Battery Needs Battery Type Scan Depth (in)
STHT77260 8-3/4 1 9V 1/2, 1, 1-1/2
STANLEY® FATMAX® STUD SENSOR 300
■ Backlit LCD screen clearly displays all of the sensor’s readings, even in low light conditions.
■ Wood and metal stud detection through up to 1-1/2" deep surface material.
■ AC detection identies live wires up to 2" deep.
■ OnePass
■ Deep metal scan senses metal through up to 3" of material.
■ Auto calibration.
■ Marking channel helps improve accuracy of marking-out readings.
■ Ergonomic design and soft grip buttons provide comfort and control.
Product #
™
Center-Find Technology locates stud centers.
Overall Length (in) Battery Needs Battery Type Height (in) Width (in) Scan Depth (in)
FMHT77407 6-1/2 1 9V 1-1/2 3-1/2 1-1/2
STANLEY® STUD SENSOR 200
■ LCD screen clearly displays all of the sensor’s readings.
■ Wood and metal stud detection through up to 3/4" deep surface material.
■ AC detection identies live wires up to 2" deep.
■ OnePass
■ Marking channel helps improve accuracy of marking-out readings.
■ Ergonomic design and soft grip buttons provide comfort and control.
™
Center-Find Technology locates stud centers.
918
Product #
Overall Length (in) Battery Needs Battery Type Height (in) Width (in) Scan Depth (in)
STHT77406 5-5/8 1 9V 1-3/8 3 3/4
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
STANLEY® STUD SENSOR 150
■ Wood and metal stud detection through up to 1-1/2" below surface material.
■ AC detection identies live wires up to 2" deep.
■ Sequential LEDs and audible beeps indicates reading.
■ Marking channel with LED identies target and makes marking surfaces easy and accurate.
■ Ergonomic design and soft grip buttons provide comfort and control.
eleCtroniC layout toolS
Product #
Overall Length (in) Battery Needs Battery Type Height (in) Width (in) Scan Depth (in)
STHT77404 5-3/4 1 9V 1-3/8 2-7/8 1-1/2
STANLEY® STUD SENSOR 100
■ Wood and metal stud detection through up to 3/4" deep surface material.
■ AC detection identies live wires up to 2" deep.
■ Sequential LEDs and audible beeps indicates tool is reading surface.
■ Marking channel with LED identies target and makes marking surfaces
easy and accurate.
■ Ergonomic design and soft grip buttons provide comfort and control.
Product #
STHT77403 5-1/8 1 9V 1-1/2 2-1/4 3/4
Overall Length (in) Battery Needs Battery Type Height (in) Width (in) Scan Depth (in)
STANLEY® STUD SENSOR 50
■ Detects wood/metal studs up to a 3/4" depth.
■ Visual indicators on face of stud sensor for easy readability.
■ LED display indicates stud edge.
Product #
Overall
Length (in)
Battery
Needs
Battery
Type
Scan
Depth (in)
77-050 5-1/4 1 9V 3/4
STANLEY® MAGNETIC STUD FINDER
■ Provides dependable detection of wall studs.
■ Magnet works by locating steel nails and screws used to hold drywall to studs.
■ Base of the stud nder is notched for convenient marking once studs are located.
Product #
47-400 1-3/8 1-1/4 1-3/8
Overall Length (in) Height (in) Width (in)
Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
WARNING: WORK SAFELY WITH TOOLS. WEAR SAFETY GOGGLES.
+1.800.800.TOOL · Fax: +1.770.648.9108 · www.protoindustrial.com
919
STANLEY® TLM330 LASER DISTANCE MEASURER
■ Measures distance, calculates area and volume.
■ Automatic calculations make job estimates quick and easy.
■ Integrated digital leveling of inclination sensor identies position for accurate measurements.
■ Continuous measurement nds distance from target quickly and easily.
■ Indirect measurement using pythagoras measures height even when point A and/or point B is
not accessible for linear measurement.
■ Unit stores last 20 measurements taken for reference.
■ Backlit, 2 line display provides visibility in all working conditions.
■ Multifunctional and folding end piece makes true corner-to-corner and edge-to-edge
measurements easy and accurate.
■ Over-molded housing and water/debris resistant for durability and protection.
Product #
eleCtroniC layout toolS
STHT77140 +/- 1/32 2 AAA 330
Accuracy (in)
Needs
Battery
Battery
Type
Measuring
Range (ft)
STANLEY® TLM165 LASER DISTANCE MEASURER
■ Measures distance, calculates area and volume.
■ Automatic calculations make job estimates quick and easy.
■ Continuous measurement nds distance from target quickly and easily.
■ Indirect measurement using pythagoras measures height even when point A and/or
point B is not accessible for linear measurement.
■ Unit stores last 5 measurements taken for reference.
■ Backlit, 2 line display provides visibility in all working conditions.
■ Corner stand-Off end post makes true corner-to-corner measurements easy and accurate.
■ Over-molded housing and water/debris resistant for durability and protection.
Product #
Accuracy (in)
Needs
STHT77139 +/- 1/16 2 AAA 165
Battery
Battery
Type
Measuring
Range (ft)
920
STANLEY® TLM99S BLUETOOTH® LASER DISTANCE MEASURER
■ Range 100' / Accuracy +/- 3/32".
■ Measures distance, calculates area and volume for quick and easy job estimates.
■ Addition/subtraction function for convenient way to compute on the job without a calculator
or manual math.
■ Contiuous measurement to help nd target distance fast.
■ Integrated Bluetooth
smartphones and tablets.
■ Links directly with STANLEY
Product #
STHT77343 +/- 3/32 2 AAA 100
®
connection links directly to STANLEY® measuring and layout Apps on
®
Floor Plan App.
Accuracy (in)
Battery
Needs
Battery
Type
Measuring
Range (ft)
Country of origin accurate at time of printing, consult www.protoindustrial.com for updated information.
Loading...
