Stagg headbanger10 User Manual
!
User Manual
HEADBANGER10
SLI MHW HB10
!
Maintenance
1. Avoid contact with high humidity or direct contact with moisture.
2. Using the product for extended run cycles without pause can shorten lifespan
3. Cleaning the lens and fan assemblies and blowing out dust from the product is
mandatory maintenance and will extend lifespan.
4. Never use petroleum-based cleaning agents or solvenst on the product, this
will damage the product permanently
Statement
All products are checked carefully before packing and shipping. Should you find
the product to be damaged when opening the box, contact your dealer. Any
misuse of the product due to neglect of the guidelines in this manual will void
your warranty. The dealer or manufacturer can never be held responsible should
this occur.
Technical details can be changed without notice
Attention
1. Never use the product in high humidity, in direct or indirect contact with
moisture or in locations with high temperatures. Failure to do so will void your
warranty.
2. Always place the product on a solid and even surface. When installed with the
hanging bracket, always make sure to use an approved mounting clamp and
check the mounting points for wear or damage.
3. A trained professional should perform all repairs and maintenance. Never open
the product without approval from your dealer.
4. Always use a stable power source within operating specifications.
5. Allow the light to cool down for 20 minutes before re-using.
!
Product Introduction
• Power Supply AC90-230V, 50Hz-60Hz
• Power consumption: 80W
• 7pcs*10W RGBW LED
• DMX-Control-channels: 7 or 12, user selectable
• Color: RGBW Color-mixing
• Strobe: Flash rate: 0-10Hz
• Dimmer: 0-100%
• Maximum PAN-movement: 540o
• Maximum TILT-movement: 270o
• Master/Slave function
DMX Channel Summary – 7 Channels Mode
CHANNEL
VALUE
FUNCTION
1
0
Stop
1~255
Adjust Pan
2
0
Stop
1~255
Adjust Tilt
3
0~10
Close
11~255
Dimmer
4
0
Close
1~255
Red 5 0
Close
1~255
Green
6
0
Close
1~255
Blue
7
0
Close
1~255
White
