Stagg CITY BEAM User Manual
User Manual
Laser Show System
CITY BEAM
1. General instructions
Thank you for purchasing this product. Please read this
user guide for safety and operations information before
using the product. Keep this manual for future reference.
This product can create perfect laser programs and
effects since it has passed a series of strict tests before
delivery. Please handle with care after receiving the
unit and check the accessories listed on the page after
opening the carton. In the event of carton damage or
accessories missing in transit, please contact your dealer
or our after sales service department.
Attachments:
1. Laser Light 1 PCS 4. Tripod 1 PCS
2. Power Supply 1 PCS 5. Remote control 1 PCS
3. User Guide 1 PCS 6. Safety key 2 PCS
2. Notice:
1. Do not expose the eye directly to laser beam.
2. Before using this unit makes sure the power supply is
grounded.
3. This unit is intended for indoor use only and should
be prevented from making contact with water, moisture
and vibrations. The working temperature of this unit
is 18~30℃, do not use continuously for over 4 hours,
otherwise it shortens the lifetime of the unit.
4. Do not remove or break the warranty label, otherwise it
will void the warranty.
Installation, operation and maintenance should
be done by a professional
Warning! Do not expose the eye directly to the
laser beam.
3. Installation
1. Before installation, please make sure the input voltage
is conform to the one marked on the unit.
2. This product should be installed by a professional to
make sure it is xed safely and is adjusted to a suitable
shining angle.
3. When installing this unit, please make sure there is
nothing ammable or explosive within 0.5 meters of
the unit. Make sure there is 15 mm free space around
the unit. Please make sure to use safety rope which
can support tenfold the weight of the unit to secure the
mounting.
4. Front Panel
1. Infrared receiver
2. Laser Aperture
3. LED Aperture (For model CITY BEAM 16 ONLY)
3
2
1
2
1
