Stagg BLAXX FLANGER Quick Start Manual

FEATURES

- Full aluminium-alloy housing, stable and durable.

- True bypass provides clear tone.

- LED indicator.

SPECIFICATIONS

- Input impedance: 1M Ohms

- Output Impedance: 510 Ohms

- Working current: 20mA

- Power supply: needs 9V DC (negative polarity)

- Dimensions: 95mm(D) x 45mm(W) x 48mm(H)

- Weight: 240g (with box)

Pour obtenir ce mode d’emploi en français,

veuillez vous rendre sur www.staggmusic.com

Um die Gebrauchsanweisung in Deutsch zu erhalten,

gehen Sie bitte auf www.staggmusic.com

Deze handleiding is beschikbaar in het Nederlands op

Para obtener este modo de empleo en espanol

www.staggmusic.com

vayan sobre www.staggmusic.com

Per ottenere questo manuale in italiano,

consultare www.staggmusic.com

FLANGER

EMD Music - 01-2015

Thank you for purchasing our Flanger Pedal.

Before operating this product, please

read the enclosed Operation Instructions

OPERATING INSTRUCTIONS

9

5

3

8

6

4

7

2

1

1. True BYPASS Footswitch

Push down on the footswitch to switch between effect
and bypass status.

2. LED Indicator

On: effect is active. Off: bypass mode is active.

3. RATE

Adjusts the flange rate. Turn clockwise to increase,
and anti-clockwise to decrease.

4. RANGE

Controls the range of flange sweep.

5. COLOR

Controls the depth of the flange sweep.

6. FLANGER SWITCH

Switch between ‘normal’ and ‘filter’ sweep.

7. INPUT

Connect your guitar or other effect unit to the standard
Ø 6.3 mm INPUT jack of the pedal.

8. OUTPUT

Connect the output of your pedal to your amp
or other effect unit using the standard Ø 6.3 mm
OUTPUT jack.

9. 9V POWER ADAPTER INPUT
Connect your 9V DC regulated power supply adapter
plug here (negative polarity) (not included).

!

Use only the specified AC adaptor and connect
it to an AC outlet of the correct voltage.
Do not use any other AC adaptor, since this
may cause malfunction.
