FIRSTLINE PLT
THREE PHASE ON-LINE DOUBLE CONVERSION UPS
10 - 60 KVA
APPLICATIONS INCLUDE
Data Centers
Computer Networks
Industrial Process Manufacturing
Hospitals, Medical
Education, Research
Laboratories, Bio-tech
Pharmaceuticals
Critical Power Management Requirements
UL 924 Emergency Lighting and Emergency
Elevator Power.
PRODUCT FEATURES
Up to 94% Efficient
Lower energy costs and carbon footprint
Hot Standby Economy Mode available
Compact & Reliable
208VAC or 480VAC models with *internal batteries (10-40kVA)
allows for smaller footprint. Cooler operation extends internal
component life
AC Input Performance
High input power factor of 0.99. Low input current distortion
of < 1% (THDi) @ full load. Soft Start Power walk-in function
that ensures progressive rectifier start-up
TOGETHER WE POWER ON
MORE FEATURES
IGBT AND DIGITAL SIGNAL PROCESSOR (DSP)
Reduces the impact of the UPS on the local supply. Simplifies installation where there is limited power capacity.
DUAL INPUT
Main power and secondary bypass power increase resilience of single or parallel system configurations.
ADAPTIVE FEED CANCELLATION
Advanced control with AFC forward cancellation technology for low harmonic distortion.
MENU SELECT DISPLAY
User friendly display is easy to see and intuitive to use.
PARALLEL UP TO 4 UNITS
Provides redundancy for mission critical applications with no additional hardware. Parallel Kit, Communication through
CANBUS Parallel Card.
OPERATES AS A PRECISION POWER CONDITIONER
All PLT Models may be operated as a Power Conditioner, upgradeable with batteries at any time for normal UPS
operation.
FREQUENCY CONVERSION
All PLT Models may be operated as a Frequency Converter, set as 50 or 60Hz, and batteries can be added for backup
time.
WORLDWIDE SERVICE PROGRAM
Factory trained service personnel maximize equipment life. Full start-up service & preventive maintenance services
lowers cost of ownership.
*Internal batteries are not available for 50-60 kVA units.
BATTERY CARE SYSTEM
FirstLine® PLT uses the Battery Care System which
optimizes battery performance while extending battery
life.
TOGETHER WE POWER ON
FIRSTLINE PLT UPS
In the event of an AC power failure, the FirstLine® PLT UPS will automatically transfer to battery power
and continue to provide power without any interruption for the full amount of time you select. When
power returns, the FirstLine® PLT UPS will automatically recharge the batteries for the next unexpected
power outage or disturbance.
AC INPUT PERFORMANCE
FirstLine® PLT is a further evolution of the FirstLine® series with the added advantages offered by an IGBT-based
rectifier/inverter assembly. This feature reduces the impact of the UPS on the local supply and simplifies installation
where there is limited power capacity in the form of available electrical supply rating or generator size. The FirstLine® P
is classed as a “Zero Impact Source” and provides:
n
Low input current distortion <= 3%
n
High input power factor 0.99
n
Power walk-in function that ensures progressive rectifier start up
n
Delayed start up phased with the return of mains power supply, when several UPS are connected in the system. The
FirstLine® PLT also performs the role of a high performance filter, protecting its upstream power supply sources from
any harmonics and reactive power generated by the loads powered.
FLEXIBILITY
FirstLine® PLT models feature an output transformer with galvanic isolation (between the load and the battery supply) to
provide greater versatility and installation options. The UPS can be supplied from two separate power sources (main
power and a second source) which helps increase the resilience of system configurations.
MAIN CHARACTERISTICS
n
Efficiency ≥ 94% at full load
n
Reduced Weight
n
Battery Temp Sensor Module monitors the battery internal cabinet environmental conditions of the Battery Cabinet
connected to the UPS and displayed on the UPS front mimic panel.
The entire FirstLine® PLT range is suitable for a wide range of applications thanks to the exibility of congurations, accessories,
options, and choice of performance levels. The UPS is compatible with capacitive loads, such as blade servers, without any
reduction in active power, ranging from 0.9 lead to 0.8 lag and up to 0.8 capacitive power. Efcient and reliable power supply
for mission critical applications is guaranteed by operating in redundancy and power parallel mode with up to 4 units (N or
N+1).
TOGETHER WE POWER ON
FIRSTLINE PLT
UPS Rating KVA/KW 10/9 15/13.5 20/18 30/27 40/36 50/45 60/54
TECHNICAL SPECIFICATIONS
Input
Topology On-Line Double Conversion
Voltage
Range +15% / -20% Battery Discharge@-15% with full load
Frequency 60/50Hz +/- 5.0 Hz
Power Factor 0.99 at 100% load, 0.98 minimum at 50% load
Current Distortion <1% @100% Load, <2% @ 50% Load, <5% @ 10% Load
Input Current A (208V/208V)
Input Current Inrush Walk-In from 25% maximum to 100% full load rating in 5 seconds
208Y/120 VAC, Three Phase, 4 wire plus ground, 208VAC, 3 wire (Delta) or 220Y/127VAC congurable from the front panel
Nominal: 27
Maximum: 33
Nominal: 41
Maximum: 49
480Y277 VAC 4 wire plus ground or 480 VAC, 3 wire (Delta)
Nominal: 54
Maximum: 65
Nominal: 81
Maximum: 97
Nominal: 109
Maximum: 130
Nominal: 143
Maximum: 172
Nominal: 167
Maximum: 200
Output
Voltage 208Y/120 VAC, Three Phase, 4 wire plus ground or 220Y/127 VAC congurable from the Front Panel or 480Y/277 VAC, 4-wire
Static Voltage Regulation +/- 2%
Voltage Transient Response
Frequency (inverter synchronous) 60/50Hz (tracks frequency of static bypass source) +/- 0.5, 1.0, 2.0, 5.0 Hz (user settable)
Frequency Slew Rate (inverter synchronized to static bypass) Adjustable 0.1 to ± 10 Hz per second
Free Running Frequency (on battery or asynchronous) 60/50Hz +/- 0.01Hz
Voltage Distortion THD Less than 1% (Linear load), less than 2% with crest factor 2.5 to 1
Inverter Overload 125% for 10 minutes, 150% for 60 seconds
Bypass Overload 400% for 10 seconds, 1000% for half line cycle
Bypass Input – Range Synchronization Voltage +12% / -15%
Bypass Input Frequency Tracking Range +/- 5Hz
Overall Efciency Up to 94%
Output Current (A)
Heat Rejection (BTU/Hr) @208VAC
Voltage transient response shall not exceed the following, and shall recover to 95% within 10 milliseconds:
28 42 56 84
2,400 3,500 4,700 7,000
a) <5% RMS for 100% step load b) +/- 1% (loss or return of AC input)
111 139 167
9,300 21,000 23,500
Battery
Battery Type
Voltage 432 volts DC nominal, 486VDC oat
Internal Sealed Maintenance Free Lead Acid VRLA - 36 Batteries, Center Tap Design (NI-CAD
available).
External Battery Cabinet - 36
Batteries, Center Tap
Environmental
Altitude De-rate load capability above 1000 meters, 1% per 100 meters
Operating Temperature 40 °C Maximum
Audible Noise @ 3 feet “A” weighted scale <75 dBA
Dimensions and Weights
Height x Width x Depth – Inches (mm)
Height x Width x Depth – Inches (mm)
lbs. / [kg]
72.41 x 23.13 x 34.47 / [1839.3] x [587.4] x [875.7]
Minimum 659 / [299]
Maximum 1894 / [859]
Minimum 659 /
[299]
Maximum 1919
/ [870]
76.75 x 34.13 x 34.47 / [1949.5] x
[866.9] x [875.7]
Minimum 881 / [400]
Maximum 2013 / [913]
Communications
SNMP/WEB (Optional) SNMP Card & UPS PowerView Pro Shutdown and Monitoring Software for Windows/Novell
Modbus Monitoring & Control via RS-485/RTU Protocol/Read Holding and Write Registersl
Standards
Agency
UL listed to 1778, CUL to CSA C22.2, NEMA PE-1, ASME, ASA-C-39.1-1984, FCC Part 15 Class B, NEC, OSHA, IEEE587,
ANSI C 62.41-1980, ISO9000
TOGETHER WE POWER ON
1 (LCD) Graphic LCD
2 ENT Key <ENTER>
ESC Key <ESC>
( ) Key move up
( ) Key move down
( ) Key move to right
( ) Key move to left
3 (a) Rectier Input Voltage OK led (green)
(b) Output Voltage Unit from the Bypass led (orange)
(c) Inverter is Working led (green)
(d) Unit Working from Batteries-mains failure led (red)
(e) General Alarm-in case of any alarm of the unit led (green)
STACO SERVICE
FIELD SERVICE PROGRAM
Staco specializes in providing choice and exibility by
developing tailored solutions for preventive and
remedial maintenance services, as well as emergency
repairs for all of our products. Staco Service is built
upon a nationwide network of highly trained and
motivated customer support engineers and technicians
who can provide professional services and care
throughout the life of your equipment.
Start-Ups
Preventive Maintenance
Spare Parts
Battery Analysis/Refresh/Replacement
On-Site Training
Time & Material Services
WHY STACO ENERGY PRODUCTS?
BECAUSE WE ARE YOUR CUSTOM POWER SOLUTIONS PROVIDER!
Unique application design demands, harsh environment concerns, the need to meet non-standard physical space
requirements; providing the “not so usual” is what we do best. From leading edge uninterruptible power supplies,
power conditioners, power factor and harmonic correction equipment, to the world’s most stable voltage control
systems, we have the technology you need to protect and manage your business, and the knowledge to make
it work for you.
Since 1937, customers worldwide have relied on Staco Energy as their custom solutions provider, to solve a wide range
of electrical power problems. Headquartered in Miamisburg, Ohio, Staco Energy Products is a wholly owned subsidiary
of Components Corporation of America, located in Dallas, Texas.
Voltage Control UPS & Emergency Lighting Power Factor & Harmonics
