StabilizedSteps Stabilizers User Manual

Freedom to move with

confidence & stability!

Stabilizers

(SG1001)

User Guide

User Guide and Video

also available online

hps://stabilizedsteps.com/stabilizers-user-guide/

ww

We strive to achieve your

highest sasfacon!

If you have any questions please contact us.

[e-mail]

1-844-691-STEP (7837) option 2

Monday - Friday 9am - 4pm EST

We reserve the right to correct any errors that may occur

within this manual.

© 2018 Stabilized Steps, LLC

— 8 —

WARRANTY REGISTRATION

Our Stabilized Steps™ products are guaranteed for

life against manufacturer defects for the duration of

use by the original purchaser.

To ensure your warranty, please register your

product at

www.stabilizedsteps.com/stabilized-steps-lifetime-warranty/

PRODUCT DESCRIPTION

Our award winning and patented Stabilizers are a
medical device that attaches to the bottom of
medical walkers allowing them to be very stable
indoors and in various terrains such as sand, grass,
gravel, mud, and even snow; giving individuals with
mobility issues or ambulatory disabilities the

Freedom to Move Forward!

Product comes fully assembled and

ready to attach to a walker. (Walker NOT included)

NO TOOLS ARE REQUIRED

What’s Included

One set of Stabilizers that fit most walkers with 1”

diameter legs. Two pairs of extension legs
with attachment hardware and nylon pads.

Specifications

Product Weight 3.53lbs combined
Length (platform) 22”
Width (platform) 3”
Weight Capacity 500lbs

SAFETY INSTRUCTIONS

Make sure that before each use:

• Walker is adjusted to correct height and it sits

level. Always contact your physician or therapist
when using a walker to determine proper walker
height.

• Spring buttons are locked in place.

• Replace nylon pads when worn or missing.

• DO NOT exceed the 500lb weight capacity

Always follow the specific safety and user

instructions for your individual walker.

MAINTENANCE

• Wipe Stabilizers weekly with a damp cloth.

• After using the Stabilizers outdoors, shake off

any sand or small rocks that could have
gotten stuck at the bottom or around the
extension legs. If necessary, give them a
quick wash with water to make sure all the
particles are removed.

• Stabilizers may be cleaned with mild soap or

detergent. DO NOT use organic solvents,
such as acetone, which could damage the
grip. Never use abrasive cleansers or
scouring pads on any part of the Stabilizers
or the bottom pads.

• Check all hardware weekly to ensure that it is

securely attached.

• Replace bottom nylon pads when worn.

* Walker NOT included

www.StabilizedSteps.com

— 2 —

— 3 —

REPLACING THE BOTTOM NYLON PADS

(replacement pads need to be purchased separately)

It is important to note that the bottom nylon pads will not wear out evenly;

thus, not all pads need to be replaced at the same time.

• Use a Phillips screwdriver to remove the screw in the center of the pad

to remove the old pad and replace with new.

• Do not overtighten the screw.

Replacement Parts

• RP2001 – Stabilizers Replacement Pads (Nylon) 6pk

• RP2003 – Stabilizers Replacement Pads (Rubber) 6pk

INSTALLATION

Step 1:

Locate the FRONT and
OUTSIDE arrows at the

bottom of each of the
Stabilizers.

(This will be needed in
Step 4)

Step 2:

Remove the old legs of walker. Unfold the walker

frame, flip it over, and secure it with your foot by

stepping down on either handle (A), giving the walker
the steadiness during installation.

Step 3:

Proceed to remove the old legs by pushing the spring
buttons (B) and pulling up carefully.

Figure 1

RECOMMENDED USE

• Use the walker with the attached Stabilizers following a regular standard walker’s 3 point gait:

(1) Align the middle of your foot with the back legs of the walker
(2) & (3) Lift the walker and place it in front of you with all four legs on the floor
(4) & (5) then carefully step forward, one foot at a time

• Use caution when gliding indoors after outdoor use to prevent damaging sensitive indoor

flooring materials.

• The elongated design of the Stabilizers makes the walker more stable when transferring to and from a

chair or bed. Make sure to press down firmly on the handles of the walker and carefully sit down or stand
up from the chair or bed.

• Post-surgery it is recommended that the nylon pads be replaced with rubber pads (sold separately) in

order to provide solid stability that will prevent gliding. As mobility is regained with rehabilitation, the
nylon pads can be installed once again.

Step 4:

Identify which Stabilizer goes on what side of the

walker by aligning the FRONT and OUTSIDE arrows

(Figure 1) with the FRONT and OUTSIDE of the
walker frame.

Install one Stabilizer at a time
by opening the extension
legs and inserting them both
at the same time onto the
walker frame. Repeat
position on the other side.

Step 5:

Adjust proper height using the spring buttons. Make
sure both Stabilizers are adjusted with the same
height before flipping the walker frame over.

Step 6:

Flip the walker over and verify desired height for
use. See the Helpful Tips and Usage section for
product usage instructions.

HELPFUL TIPS

• Depending on the size of your walker and/or desired height, the

preassembled extension leg positions may not be the correct one for
your walker. If this is the case, you can simply adjust the position of
the extension legs by removing the cotter pin (C) and placing it in the
desired hole opening in the Stabilizer that fits ideally with your walker.

• MAKE SURE THE POSITION OF THE EXTENSION LEGS IS THE

SAME ON BOTH STABILIZERS.

(C)

— 6 —

— 7 —

— 4 — — 5 —

SG1001 (Rev. 02/27/18)
