Introduction
The STM32479I-EVAL evaluation board is a complete demonstration and development
platform for STMicroelectronics ARM
®
Cortex® -M4 core-based STM32F479NIH6
microcontroller. It features three I
2
C, six SPIs with two multiplexed full-duplex I2S interfaces,
SDMMC, four USARTs and four UARTs, two CANs, three 12-bit ADCs, two 12-bit DACs,
one SAI, 8 to 14-bit digital camera module interface, internal 320+4 Kbytes of SRAM and 2
Mbytes of Flash memory, USB HS OTG and USB FS OTG, Ethernet MAC, FMC interface,
MIPI DSI interface, Quad-SPI interface, Cryptographic acceleration, JTAG and ETM
debugging support. This evaluation board can be used as a reference design for user
application development but it cannot be considered as a final application.
The full range of hardware features on the board helps the user to evaluate all peripherals
(USB OTG HS, USB OTG FS, Ethernet, motor control, CAN, microSD Card, USART, Audio
DAC and ADC, digital microphone, IrDA, RF-EEPROM, SRAM, NOR Flash, SDRAM,
Quad-SPI Flash, 4" TFT LCD with MIPI DSI interface and capacitive touch panel and
others) and to develop his own applications. Extension headers make it possible to easily
connect a daughterboard for specific application.
The integrated ST-LINK/V2-1 provides an embedded in-circuit debugger and programmer
for the STM32 MCU.
Figure 1. STM32479I-EVAL evaluation board
1. Picture not contractual.
