TSV620, TSV620A, TSV621, TSV621A
Rail-to-rail input/output 29 µA 420 kHz CMOS operational amplifiers
Features
VCC
6
6
5
4
4
5
5
5
4
4
4
VCC
Out
Out
V
CC+
SHDN
Out
■ Low supply voltage: 1.5 V–5.5 V
■ Rail-to-rail input and output
■ Low input offset voltage: 800 µV max (A
version)
■ Low power consumption: 29 µA typ
■ Low power shutdown mode: 5nA typ (TSV620)
■ Gain bandwidth product: 420 kHz typ
■ Unity gain stability
■ Micropackages: SC70-5/6, SOT23-5/6
■ Low input bias current: 1 pA typ
■ Extended temperature range: -40 to +125° C
■ 4kV HBM
Applications
In+
In+
1
1
1
+
+
+
_
_
_
2
2
2
VDD
VDD
In-
In-
3
3
3
TSV621ICT/ILT
SC70-5/SOT23-5
In+
1
1
+
+
_
V
CC-
In-
_
2
2
3
3
TSV620ICT/ILT
SC70-6/SOT23-6
This product features an excellent speed/power
consumption ratio, offering a 420 kHz gain
bandwidth while consuming only 29 µA at a
5 V supply voltage.
■ Battery-powered applications
■ Portable devices
■ Signal conditioning
■ Active filtering
■ Medical instrumentation
Description
The TSV620 and TSV621 are single operational
amplifiers offering low voltage, low power
operation and rail-to-rail input and output.
With a very low input bias current and low offset
voltage (800 µV maximum for the A version), the
TSV62x is ideal for applications requiring
precision. The device can operate at a power
supply ranging from 1.5 to 5.5 V, and therefore
suits battery-powered devices and extends their
battery life.
These operational amplifiers are unity gain stable
for capacitive loads up to 100 pF.
The device is internally adjusted to provide very
narrow dispersion of AC and DC parameters,
especially power consumption, product gain
bandwidth and slew rate.
The TSV62x presents a high tolerance to ESD,
sustaining 4 kV for the human body model.
The devices are offered in macropackages,
SC70-6 and SOT23-6 for the TSV620 and
SC70-5 and SOT23-5 for the TSV621. They are
guaranteed for industrial temperature ranges from
-40° C to +125° C.
All these features make the TSV620 and TSV621
ideal for sensor interfaces, battery-supplied and
portable applications, as well as active filtering.
October 2009 Doc ID 14912 Rev 2 1/24
www.st.com
24
Contents TSV620, TSV620A, TSV621, TSV621A
Contents
1 Absolute maximum ratings and operating conditions . . . . . . . . . . . . . 3
2 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Application information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1 Operating voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Rail-to-rail input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Rail-to-rail output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Shutdown function (TSV620) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.5 Optimization of DC and AC parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.6 Driving resistive and capacitive loads . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7 PCB layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.8 Macromodel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1 SOT23-5 package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 SOT23-6 package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3 SC70-5 (or SOT323-5) package mechanical data . . . . . . . . . . . . . . . . . . 19
4.4 SC70-6 (or SOT323-6) package mechanical data . . . . . . . . . . . . . . . . . . 20
5 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Absolute maximum ratings and operating conditions
1 Absolute maximum ratings and operating conditions
Table 1. Absolute maximum ratings (AMR)
Symbol Parameter Value Unit
(3)
(4)
(1)
(5)
(9)
(2)
(8)
(10)
(6)(7)
V
V
CC-
CC-
6V
±V
CC
-0.2 to V
+0.2 V
CC+
V
10 mA
-0.2 to V
+0.2 V
CC+
205
250
°C/W
240
232
4kV
300 V
1.5 kV
V
CC
V
id
V
in
I
in
SHDN
T
stg
R
thja
T
j
ESD
Supply voltage
Differential input voltage
Input voltage
Input current
Shutdown voltage
Storage temperature -65 to +150 °C
Thermal resistance junction to ambient
SC70-5
SOT23-5
SOT23-6
SC70-6
Maximum junction temperature 150 °C
HBM: human body model
MM: machine model
CDM: charged device model
Latch-up immunity 200 mA
1. All voltage values, except differential voltage are with respect to network ground terminal.
2. Differential voltages are the non-inverting input terminal with respect to the inverting input terminal.
3. Vcc-Vin must not exceed 6 V.
4. Input current must be limited by a resistor in series with the inputs.
5. Vcc-SHDN must not exceed 6 V.
6. Short-circuits can cause excessive heating and destructive dissipation.
are typical values.
7. R
th
8. Human body model: 100 pF discharged through a 1.5 kΩ resistor between two pins of the device, done for
all couples of pin combinations with other pins floating.
9. Machine mode: a 200 pF capacitor is charged to the specified voltage, then discharged directly between
two pins of the device with no external series resistor (internal resistor < 5
combinations with other pins floating.
10. Charged device model: all pins plus package are charged together to the specified voltage and then
discharged directly to the ground.
Table 2. Operating conditions
Ω), done for all couples of pin
Symbol Parameter Value Unit
T
V
V
CC
icm
oper
Supply voltage 1.5 to 5.5 V
Common mode input voltage range V
CC-
-0.1 to V
+0.1 V
CC+
Operating free air temperature range -40 to +125 °C
Doc ID 14912 Rev 2 3/24
Electrical characteristics TSV620, TSV620A, TSV621, TSV621A
2 Electrical characteristics
Table 3. Electrical characteristics at V
Symbol Parameter Conditions Min. Typ. Max. Unit
DC performance
and R
= +1.8 V with VDD = 0 V, V
connected to VCC/2 (unless otherwise specified)
L
CC+
= VCC/2, Top = 25° C,
icm
V
DV
CMR
A
V
V
Offset voltage
io
Input offset voltage drift 2 μV/°C
io
Input offset current
I
io
(V
out=VCC
Input bias current
I
ib
(V
out=VCC
Common mode rejection ratio
20 log (
Large signal voltage gain
vd
High level output voltage
OH
Low level output voltage
OL
Isink
I
out
Isource
I
Supply current (per operator)
CC
AC performance
ΔV
/2)
/2)
/ΔVio)
ic
TSV62x
TSV62xA
T
< Top < T
min
max
0.8
TSV62x
TSV62xA
2.8
110
T
< Top < T
min
max
1100
110
T
< Top < T
min
0 V to 1.8 V, V
< Top < T
T
min
R
= 10 kΩ, V
L
< Top < T
T
min
R
=10kΩ 35 5
L
< Top < T
T
min
=10kΩ 435
R
L
< Top < T
T
min
= 1.8 V 6 12
V
o
< Top < T
T
min
V
= 0 V 6 10
o
< Top < T
T
min
No load, V
< Top < T
T
min
max
= 0.9 V 53 74
out
max
= 0.5 V to 1.3 V 78 95
out
max
max
max
max
max
out=VCC
/2 25 31
max
51
73
50
4
4
1100
50
33
4
mV
6
(1)
pA
(1)
pA
dB
dB
mV
mV
mA
mA
µA
R
=10kΩ, CL= 100 pF,
GBP Gain bandwidth product
F
Unity gain frequency RL=10kΩ, CL= 100 pF 280 kHz
u
φmPhase margin R
G
Gain margin RL=10kΩ, CL= 100 pF 9 dB
m
SR Slew rate R
1. Guaranteed by design.
L
f=100kHz
=10kΩ, CL= 100 pF 45 Degrees
L
=10kΩ, CL= 100 pF, Av = 1 0.084 0.11 0.14 V/μs
L
4/24 Doc ID 14912 Rev 2
275 340 kHz
TSV620, TSV620A, TSV621, TSV621A Electrical characteristics
Table 4. Shutdown characteristics VCC=1.8V
Symbol Parameter Conditions Min. Typ. Max. Unit
DC performance
I
CC
t
on
t
off
V
V
I
IH
I
IL
I
OLeak
= V
Supply current in shutdown
mode
(all operators)
Amplifier turn-on time
Amplifier turn-off time
SHDN logic high 1.3 V
IH
SHDN logic low 0.5 V
IL
SHDN
T
min
T
min
R
L
+0.2
R
L
V
CC+
SHDN current high SHDN =V
SHDN current low SHDN =V
Output leakage in shutdown
mode
SHDN
T
min
CC-
< Top < 85° C 200 nA
< Top < 125° C 1.5 µA
=2kΩ, V
=2kΩ, V
out=VCC-
out=VCC+
to V
CC
-0.5 to
+ 0.7
CC+
CC-
=V
CC-
< Top < 125° C 1 nA
2.5 50 nA
300 ns
30 ns
10 pA
10 pA
50 pA
Doc ID 14912 Rev 2 5/24
Electrical characteristics TSV620, TSV620A, TSV621, TSV621A
Table 5. V
CC+
= +3.3 V, V
= 0 V, V
CC-
= VCC/2, Top = 25° C, RL connected to VCC/2
icm
(unless otherwise specified)
Symbol Parameter Min. Typ. Max. Unit
DC performance
V
DV
CMR
A
V
V
Offset voltage
io
Input offset voltage drift 2 μV/°C
io
I
Input offset current
io
I
Input bias current
ib
Common mode rejection ratio
20 log (
Large signal voltage gain
vd
High level output voltage
OH
Low level output voltage
OL
Isink
I
out
Isource
I
Supply current (per operator)
CC
AC performance
ΔV
/ΔVio)
ic
TSV62x
TSV62xA
< Top < T
T
min
max
TSV62x
TSV62xA
110
T
min
< Top < T
max
1 100 pA
110
T
< Top < T
min
0V to 3.3V, V
T
< Top < T
min
R
=10 kΩ, V
L
< Top < T
T
min
=10kΩ 35 5
R
L
< Top < T
T
min
R
=10kΩ 435
L
< Top < T
T
min
V
= 5 V 30 45
o
< Top < T
T
min
= 0 V 30 38
V
o
< Top < T
T
min
No load, V
T
< Top < T
min
max
= 1.75 V 57 79 dB
out
max
= 0.5 V to 2.8 V 81 98 dB
out
max
max
max
max
max
=2.5V 26 33 µA
out
max
53 dB
76 dB
50
25
25
1 100 pA
4
0.8
6
2.8
(1)
(1)
50
35 µA
mV
pA
pA
mV
mV
mA
mA
R
=10kΩ, CL= 100 pF,
GBP Gain bandwidth product
Unity gain frequency RL = 10 kΩ, CL= 100 pF 310 kHz
F
u
φmPhase margin R
G
Gain margin RL = 10 kΩ, CL= 100 pF 9 dB
m
SR Slew rate R
1. Guaranteed by design.
L
f = 100 kHz
= 10 kΩ, CL= 100 pF 45 Degrees
L
=10kΩ, CL= 100 pF, AV= 1 0.094 0.12 V/μs
L
6/24 Doc ID 14912 Rev 2
310 380 kHz
TSV620, TSV620A, TSV621, TSV621A Electrical characteristics
Table 6. V
CC+
= +5 V, V
= 0 V, V
CC-
= VCC/2, Top = 25° C, RL connected to VCC/2
icm
(unless otherwise specified)
Symbol Parameter Min. Typ. Max. Unit
DC performance
V
DV
CMR
SVR
A
V
V
I
I
Offset voltage
io
Input offset voltage drift 2 μV/°C
io
I
Input offset current
io
I
Input bias current
ib
Common mode rejection ratio
20 log (
Supply voltage rejection ratio 20
log (
ΔV
Large signal voltage gain
vd
High level output voltage
OH
Low level output voltage
OL
I
sink
out
I
source
Supply current (per operator)
CC
AC performance
ΔV
CC
/ΔVio)
ic
/ΔVio)
TSV62x
TSV62xA
< Top < T
T
min
max
TSV62x
TSV62xA
110
T
min
< Top < T
max
1 100 pA
110
T
< Top < T
min
0V to 5V, V
T
< Top < T
min
V
= 1.8 to 5 V 75 102 dB
CC
< Top < T
T
min
=10 kΩ, V
R
L
< Top < T
T
min
R
=10kΩ 35 7
L
< Top < T
T
min
R
=10kΩ 635
L
< Top < T
T
min
max
= 2.5 V 60 80 dB
out
max
max
= 0.5 V to 4.5 V 85 98 dB
out
max
max
max
55
73
80
50
1 100 pA
Vo =5V 40 69
T
min
< Top < T
max
35 65
Vo = 0 V 40 74
< Top < T
T
min
No load, V
< Top < T
T
min
max
=2.5V 29 36 µA
out
max
35 68
4
0.8
6
2.8
(1)
(1)
50
38 µA
mV
pA
pA
mV
mV
mA
mA
GBP Gain bandwidth product
F
Unity gain frequency RL = 10 kΩ, CL= 100 pF 360 kHz
u
φm Phase margin R
G
Gain margin RL = 10 kΩ, CL= 100 pF 9 dB
m
SR Slew rate R
=10kΩ, CL= 100 pF,
R
L
f = 100 kHz
= 10 kΩ, CL= 100 pF 45 Degrees
L
=10kΩ, CL= 100 pF, AV= 1 0.108 0.14 V/μs
L
350 420 kHz
Doc ID 14912 Rev 2 7/24
Electrical characteristics TSV620, TSV620A, TSV621, TSV621A
Table 6. V
= +5 V, V
CC+
= 0 V, V
CC-
= VCC/2, Top = 25° C, RL connected to VCC/2
icm
(unless otherwise specified) (continued)
Symbol Parameter Min. Typ. Max. Unit
e
Equivalent input noise voltage f = 1 kHz 70
n
THD Total harmonic distortion
1. Guaranteed by design.
Table 7. Shutdown characteristics VCC=5V
Av = 1, f = 1 kHz, R
V
= Vcc/2, V
icm
Symbol Parameter Conditions Min. Typ. Max. Unit
DC performance
= V
I
CC
t
on
t
off
V
V
I
IH
I
IL
I
OLeak
SHDN
Supply current in shutdown
mode (all operators)
Amplifier turn-on time
Amplifier turn-off time
SHDN logic high 4.5 V
IH
SHDN logic low 0.5 V
IL
T
T
R
0.2
R
V
min
min
L
L
CC+
SHDN current high SHDN =V
SHDN current low SHDN =V
Output leakage in shutdown
mode
SHDN
T
min
CC-
< Top < 85° C 200 nA
< Top < 125° C 1.5 µA
=2kΩ, V
=2kΩ, V
out=VCC-
out=VCC+
+ 0.7
CC+
CC-
=V
CC-
< Top < 125° C 1 nA
out
= 100 kΩ,
L
= 2 V
pp
to V
- 0.5 to
CC-
0.004 %
550 nA
+
300 ns
30 ns
10 pA
10 pA
50 pA
nV
-----------Hz
8/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Electrical characteristics
Gain (dB)
Phase (°)
Figure 1. Input offset voltage vs input
common mode at V
0.50.5
0.40.4
0.30.3
0.20.2
0.10.1
0.00.0
-0.1-0.1
-0.2-0.2
Input Offset Voltage (mV)
-0.3-0.3
-0.4-0.4
-0.5-0.5
-0.2-0.2 0.00.0 0.20.2 0.40.4 0.60.6 0.80.8 1.01.0 1.21.2 1.41.4 1.61.6
Input Common Mode Voltage (V)
CC+
= 1.5 V
Figure 3. Supply current vs. supply voltage
at V
icm
= VCC/2
Figure 2. Input offset voltage vs input
common mode at V
0.40.4
0.20.2
0.00.0
-0.2-0.2
Input Offset Voltage (mV)
-0.4-0.4
0.00.0 1.01.0 2.02.0 3.03.0 4.04.0 5.05.0
Input Common Mode Voltage (V)
CC+
= 5 V
Figure 4. Output current vs. output voltage at
V
= 1.5 V
CC +
Figure 5. Output current vs. output voltage at
Figure 6. Voltage gain and phase vs.
V
CC+
= 5 V
frequency at V
CC+
=1.5V
Doc ID 14912 Rev 2 9/24
Electrical characteristics TSV620, TSV620A, TSV621, TSV621A
Slew rate (V/ s)
Supply voltage (V)
Figure 7. Voltage gain and phase vs.
Gain (dB)
frequency at V
CC+
=5V
Figure 8. Phase margin vs. output current at
V
=1.5V and V
CC+
90
80
70
60
50
Phase (°)
40
30
20
Vicm=Vcc/2, Cl=100pF
Rl=4.7kohms, T=25 C
10
0
-1.5 -1.0 -0.5 0.0 0.5 1.0 1.5
CC+
= 5 V
Vcc=5V
Vcc=1.5V
Figure 9. Slew rate vs. supply voltage Figure 10. Slew rate vs. supply voltage
10µV/div
Figure 11. Distortion + noise vs. output
Figure 12. Distortion + noise vs. frequency
voltage
1
Vcc=1.5V
Rl=10kohms
Vcc=1.5V
Rl=100kohms
THD + N (%)
f=1kHz
Gain=1
BW=22kHz
Vicm=Vcc/2
Vcc=5.5V
Rl=10kohms
Vcc=5.5V
Rl=100kohms
Output Voltage (Vpp)
0.1
THD + N (%)
Ω
0.01
10 100 1000 10000
10/24 Doc ID 14912 Rev 2
Vcc=1.5V
Rl=10k
Vcc=1.5V
Rl=100k
Ω
Ω
Ω
TSV620, TSV620A, TSV621, TSV621A Electrical characteristics
Figure 13. Noise vs. frequency
Vicm=4.5V
Vicm=2.5V
Vcc=5V
Input equivalent noise density (nV/VHz)
T=25 C
Frequency (Hz)
Doc ID 14912 Rev 2 11/24
Application information TSV620, TSV620A, TSV621, TSV621A
3 Application information
3.1 Operating voltages
The TSV620 and TSV621 can operate from 1.5 to 5.5 V. Their parameters are fully specified
for 1.8, 3.3 and 5 V power supplies. However, the parameters are very stable in the full V
range and several characterization curves show the TSV62x characteristics at 1.5 V.
Additionally, the main specifications are guaranteed in extended temperature ranges from
-40° C to +125° C.
3.2 Rail-to-rail input
The TSV62x is built with two complementary PMOS and NMOS input differential pairs. The
device has a rail-to-rail input and the input common mode range is extended from
V
-0.1 V to V
CC-
the transition region, the performances of CMRR, PSRR, V
(as shown in Figure 14 and Figure 15 for V
Figure 14. Input offset voltage vs input
common mode at V
0.50.5
0.40.4
0.30.3
0.20.2
0.10.1
0.00.0
-0.1-0.1
-0.2-0.2
Input Offset Voltage (mV)
-0.3-0.3
-0.4-0.4
-0.5-0.5
-0.2-0.2 0.00.0 0.20.2 0.40.4 0.60.6 0.80.8 1.01.0 1.21.2 1.41.4 1.61.6
Input Common Mode Voltage (V)
+0.1 V. The transition between the two pairs appears at VCC -0.7 V. In
CC+
= 1.5 V
CC+
and THD are slightly degraded
vs. V
io
icm
io
).
Figure 15. Input offset voltage vs input
common mode at V
0.40.4
0.20.2
0.00.0
-0.2-0.2
Input Offset Voltage (mV)
-0.4-0.4
0.00.0 1.01.0 2.02.0 3.03.0 4.04.0 5.05.0
Input Common Mode Voltage (V)
CC+
= 5 V
CC
The device is guaranteed without phase reversal.
3.3 Rail-to-rail output
The operational amplifier’s output level can go close to the rails: 35 mV maximum above and
below the rail when connected to a 10 kΩ resistive load to V
12/24 Doc ID 14912 Rev 2
CC
/2.
TSV620, TSV620A, TSV621, TSV621A Application information
3.4 Shutdown function (TSV620)
The operational amplifier is enabled when the SHDN pin is pulled high. To disable the
amplifier, the SHDN
output is in a high impedance state. The SHDN
V
or V
CC+
CC-
The turn-on and turn-off times are calculated for an output variation of
and Figure 17 show the test configurations).
Figure 16. Test configuration for turn-on time
(Vout pulled down)
pin must be pulled down to V
.
. When in shutdown mode, the amplifier
CC-
pin must never be left floating but tied to
±200 mV (Figure 16
Figure 17. Test configuration for turn-off time
(Vout pulled down)
+Vcc
GND
Vcc-0.5V
+
DUT
-
GND
Figure 18. Turn-on time, VCC=5V,
Voltage (V)
Vout pulled down, T = 25° C
Shutdown pulse
Vout
+Vcc
GND
2KO
Vcc-0.5V
+
2KO
DUT
-
GND
Figure 19. Turn-off time, VCC=5V,
Vout pulled down, T = 25° C
Shutdown pulse
Output voltage (V)
Vcc = 5V
T = 25°C
Vout
Time( s)
Vcc = 5V
T = 25°C
Time( s)
Doc ID 14912 Rev 2 13/24
Application information TSV620, TSV620A, TSV621, TSV621A
3.5 Optimization of DC and AC parameters
This device uses an innovative approach to reduce the spread of the main DC and AC
parameters. An internal adjustment achieves a very narrow spread of current consumption
(29 µA typical, min/max at ±17%). Parameters linked to the current consumption value, such
as GBP, SR and AVd benefit from this narrow dispersion. All parts present a similar speed
and the same behavior in terms of stability. In addition, the minimum values of GBP and SR
are guaranteed (GBP = 350 kHz min, SR = 0.15 V/µs min).
3.6 Driving resistive and capacitive loads
These products are micro-power, low-voltage operational amplifiers optimized to drive rather
large resistive loads, above 5 kΩ. For lower resistive loads, the THD level may significantly
increase.
In a follower configuration, these operational amplifiers can drive capacitive loads up to
100 pF with no oscillations. When driving larger capacitive loads, adding a small in-series
resistor at the output can improve the stability of the device (see Figure 20 for
recommended in-series resistor values). Once the in-series resistor value has been
selected, the stability of the circuit should be tested on bench and simulated with the
simulation model.
Figure 20. In-series resistor vs. capacitive load
3.7 PCB layouts
For correct operation, it is advised to add 10 nF decoupling capacitors as close as possible
to the power supply pins.
(Ω)
In-series resistor
14/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Application information
3.8 Macromodel
An accurate macromodel of TSV620-TSV621 is available on STMicroelectronics’ web site at
www.st.com. This model is a trade-off between accuracy and complexity (that is, time
simulation) of the TSV62x operational amplifiers. It emulates the nominal performances of a
typical device within the specified operating conditions mentioned in the datasheet. It helps
to validate a design approach and to select the right operational amplifier, but it does not
replace on-board measurements.
Doc ID 14912 Rev 2 15/24
Package information TSV620, TSV620A, TSV621, TSV621A
4 Package information
In order to meet environmental requirements, ST offers these devices in different grades of
ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
ECOPACK
®
packages, depending on their level of environmental compliance. ECOPACK®
®
is an ST trademark.
16/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Package information
4.1 SOT23-5 package mechanical data
Figure 21. SOT23-5L package mechanical drawing
Table 8. SOT23-5L package mechanical data
Dimensions
Ref.
Min. Typ. Max. Min. Typ. Max.
A 0.90 1.20 1.45 0.035 0.047 0.057
A1 0.15 0.006
A2 0.90 1.05 1.30 0.035 0.041 0.051
B 0.35 0.40 0.50 0.013 0.015 0.019
C 0.09 0.15 0.20 0.003 0.006 0.008
D 2.80 2.90 3.00 0.110 0.114 0.118
D1 1.90 0.075
e 0.95 0.037
E 2.60 2.80 3.00 0.102 0.110 0.118
F 1.50 1.60 1.75 0.059 0.063 0.069
L 0.10 0.35 0.60 0.004 0.013 0.023
K0
° 10°
Millimeters Inches
Doc ID 14912 Rev 2 17/24
Package information TSV620, TSV620A, TSV621, TSV621A
4.2 SOT23-6 package mechanical data
Figure 22. SOT23-6L package mechanical drawing
Table 9. SOT23-6L package mechanical data
Dimensions
Ref.
Min. Typ. Max. Min. Typ. Max.
A 0.90 1.45 0.035 0.057
A1 0.10 0.004
A2 0.90 1.30 0.035 0.051
b 0.35 0.50 0.013 0.019
c 0.09 0.20 0.003 0.008
D 2.80 3.05 0.110 0.120
E 1.50 1.75 0.060 0.069
e 0.95 0.037
H 2.60 3.00 0.102 0.118
L 0.10 0.60 0.004 0.024
° 0 10°
Millimeters Inches
18/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Package information
4.3 SC70-5 (or SOT323-5) package mechanical data
Figure 23. SC70-5 (or SOT323-5) package mechanical drawing
DIMENSIONS IN MM
GAUGE PLANE
SEATING PLANE
SIDE VIEW
COPLANAR LEADS
TOP VI EW
Table 10. SC70-5 (or SOT323-5) package mechanical data
Dimensions
Ref
Min Typ Max Min Typ Max
A 0.80 1.10 0.315 0.043
A1 0.10 0.004
A2 0.80 0.90 1.00 0.315 0.035 0.039
b 0.15 0.30 0.006 0.012
c 0.10 0.22 0.004 0.009
D 1.80 2.00 2.20 0.071 0.079 0.087
E 1.80 2.10 2.40 0.071 0.083 0.094
E1 1.15 1.25 1.35 0.045 0.049 0.053
e 0.65 0.025
e1 1.30 0.051
L 0.26 0.36 0.46 0.010 0.014 0.018
<0
° 8°
Millimeters Inches
Doc ID 14912 Rev 2 19/24
Package information TSV620, TSV620A, TSV621, TSV621A
4.4 SC70-6 (or SOT323-6) package mechanical data
Figure 24. SC70-6 (or SOT323-6) package mechanical drawing
Table 11. SC70-6 (or SOT323-6) package mechanical data
Dimensions
Ref
Min. Typ. Max. Min. Typ. Max.
A 0.80 1.10 0.031 0.043
A1 0.10 0.004
A2 0.80 1.00 0.031 0.039
b 0.15 0.30 0.006 0.012
c 0.10 0.18 0.004 0.007
D 1.80 2.20 0.071 0.086
E 1.15 1.35 0.045 0.053
e 0.65 0.026
HE 1.80 2.40 0.071 0.094
L 0.10 0.40 0.004 0.016
Q1 0.10 0.40 0.004 0.016
Millimeters Inches
20/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Package information
Figure 25. SC70-6 (or SOT323-6) package footprint
Doc ID 14912 Rev 2 21/24
Ordering information TSV620, TSV620A, TSV621, TSV621A
5 Ordering information
Table 12. Order codes
Part number
TSV620ILT
TSV620ICT SC70-6 K14
TSV620AILT SOT23-6 K110
TSV620AICT SC70-6 K15
TSV621ILT SOT23-5 K106
TSV621ICT SC70-5 K16
TSV621AILT SOT23-5 K139
TSV621AICT SC70-5 K39
Temperature
range
-40° C to +125° C
Package Packing Marking
SOT23-6
Tape & reel
K107
22/24 Doc ID 14912 Rev 2
TSV620, TSV620A, TSV621, TSV621A Revision history
6 Revision history
Table 13. Document revision history
Date Revision Changes
12-Jan-2009 1 Initial release.
Added TSV620 device (version with shutdown function).
Added
Table 4: Shutdown characteristics VCC=1.8V.
Table 7: Shutdown characteristics VCC=5V.
Added
Section 3.4: Shutdown function (TSV620) on page 13.
19-Oct-2009 2
Added
Added
Section 4.2: SOT23-6 package mechanical data.
Section 4.4: SC70-6 (or SOT323-6) package mechanical
Added
data.
Added order codes in
Ta bl e 1 2 .
Doc ID 14912 Rev 2 23/24
TSV620, TSV620A, TSV621, TSV621A
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE
GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2009 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Philippines - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
24/24 Doc ID 14912 Rev 2
Loading...
