ST TDA7851A User Manual

TDA7851A

4 x 48 W MOSFET quad bridge power amplifier

Features

Multipower BCD technology

High output power capability:

4 x 48 W/4 Ω Max.

4 x 28 W/4 Ω @ 14.4 V, 1 kHz, 10 %

4 x 72 W/2 Ω Max.

MOSFET output power stage

Excellent 2 Ω driving capability

Hi-Fi class distortion

Low output noise

Standby function

Mute function

Automute at min. supply voltage detection

Low external component count:

Internally fixed gain (26 dB)

No external compensation

No bootstrap capacitors

Protections:

Output short circuit to GND, to Vs, across the load

Very inductive loads

Overrating chip temperature with soft thermal limiter

Output DC offset detection

Load dump voltage

Table 1. Device summary

Datasheet production data

'!0'03

Flexiwatt 27

Fortuitous open GND

Reversed battery

ESD

Description

The TDA7851A is a breakthrough MOSFET technology class AB audio power amplifier, designed for high-power car radio.

The fully complementary P-Channel/N-Channel output structure allows a rail-to-rail output voltage swing. This, combined with high output current and minimized saturation losses, sets new power references in the car-radio field, with unparalleled distortion performance.

Order code

Package

Packing







TDA7851A

Flexiwatt 27

Tube







June 2012

Doc ID 17715 Rev 2

1/15

This is information on a product in full production.

www.st.com

Contents

TDA7851A





Contents

1

Block diagram and application circuit . . . . . . . . . . . . . . . . . . . . . . . . . .

. 5



1.1

Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5



1.2

Application circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5

2

Pin description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6



2.1

Pin connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6



2.2

Thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6

3

Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7



3.1

Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7



3.2

Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7



3.3

Electrical characteristics curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9

4

Application hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12



4.1

DC offset detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12



4.2

SVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12



4.3

Input stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12



4.4

Standby and muting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12



4.5

Heatsink definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12

5

Package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13

6

Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

14

2/15

Doc ID 17715 Rev 2

TDA7851A

List of tables





List of tables

Table 1. Device summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Table 2. Thermal data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Table 3. Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Table 4. Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Table 5. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Doc ID 17715 Rev 2

3/15

List of figures

TDA7851A





List of figures

Figure 1. Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Figure 2. Application circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Figure 3. Pin connection (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Figure 4. Quiescent current vs. supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 5. Output power vs. supply voltage (RL = 4 Ω) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Figure 6. Output power vs. supply voltage (RL = 2 Ω) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Figure 7. Distortion vs. output power (RL = 4 Ω) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Figure 8. Distortion vs. output power (RL = 2 Ω) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Figure 9. Distortion vs. frequency (RL = 4 Ω). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Figure 10. Distortion vs. frequency (RL = 2 Ω). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Figure 11. Crosstalk vs. frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 12. Supply voltage rejection vs. frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Figure 13. Output attenuation vs. supply voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Figure 14. Power dissipation and efficiency vs. output power (RL = 4 Ω, SINE) . . . . . . . . . . . . . . . . . 10 Figure 15. Power dissipation and efficiency vs. output power (RL = 2 Ω, SINE) . . . . . . . . . . . . . . . . . 10 Figure 16. Power dissipation vs. output power (RL = 4 Ω, audio program simulation) . . . . . . . . . . . . 11 Figure 17. Power dissipation vs. output power (RL = 2 Ω, audio program simulation) . . . . . . . . . . . . 11 Figure 18. ITU R-ARM frequency response, weighting filter for transient pop. . . . . . . . . . . . . . . . . . . 11 Figure 19. Flexiwatt27 mechanical data and package dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4/15

Doc ID 17715 Rev 2

ST TDA7851A User Manual

TDA7851A

Block diagram and application circuit





1 Block diagram and application circuit

1.1Block diagram

Figure 1. Block diagram



6CC



6CC



34 "9









-54%







#$

















/54

).







/54









07 '.$









/54

).







/54









07 '.$









/54

).







/54









07 '.$









/54

).







/54









07 '.$

!# '.$

362

4!"

3 '.$

/&&3%4







$

%4%#4/2

'!0'03

1.2Application circuit

Figure 2. Application circuit

# Μ&

2 34 "9

+

#

2

Μ&



-54%

+

#

#

Μ&



).



Μ&



).



# Μ&



).



# Μ&



).



# Μ&

3 '.$





# Μ&

/&&3%4 $%4%#4/2 /54

#





2

Μ&





6

6CC

6CC



+



























/54









/54

/54

/54







362

#$

4!"

#





Μ&





2 6

+

#$ /54

'!0'03

Doc ID 17715 Rev 2

5/15
