STV0288
DVB-S and DIRECTVTM QPSK receiver with autoscan feature
DATA BRIEF
DESCRIPTION
STMicroelectronics introduces the STV0288, its
latest DVB and DIRECTV
which adds blind scan capability and DiSEqC 2.0 to
the industry-leading STV029 9 and provides a c ost
reduction path or new products.
The STV0288 contains two 8-bit analog-to-digital
converters for I-input and Q-input, a QPSK
demodulator, and a forward error correction (FE C)
unit having both an inner (Viterbi) and an outer
(Reed-Solomon) decoder. The device accepts
baseband differential signals as I and Q inputs.
High-performance clock generation is made from
an external reference which can vary f rom 4 to 30
MHz with respect to the analog to digital conversion
which is performed by two 8-bit ADC. The FEC unit
is compliant with the DIRECTV
specifications. Processing is fully digital and an
on-chip performant state-machine enables blind
search of satellite transponders without a-priori
knowledge of symbol rate. Thanks to this new
feature, the amount of software required for the
driver to operate the demodulator chip is drastically
reduced versus the previous generation.
The high sampling rate facilitates the
implementation of low-cost, direct conversion
tuners. The STV0288 is controlled via an I²C
interface.
TM
QPSK d igit al rece iver,
TM
and DSS
The device operates up to 120 MHz and can
process variable modulation rates, up to 6 0 Msps.
The chip outputs MPEG transport streams and
interfaces seamles sly to the p acket demultiplexers
embedded in the ST Omega chip family. Its low
power consumption, sm all package and low bill of
material makes it perfect for all satellite
applications.
Figure 1. Package
(TQFP64 with non exposed pas)
xxxx
Rev. 1
1/3
![](/html/4a/4ad7/4ad71e64bb3e1fe02bd4274bd8f3f7c73fbf198f100b57f1e54841a1b85fa8a1/bg2.png)
STV0288
Figure 2. STV0288
STV0288 and
STB6000 tuner
transport
stream in
Smart
card
FEATURES
n DVB-S / DIRECTV
n Ultra fast channel blind acquisition for satellite
band scanning
n Up to 60 Msps operation
n DVB common interface compliant transport
stream (12 bit)
2
n I
C serial bus interface, including private
repeater
TM
system
DRAM
IR
RX/TX
Audio
buffer
STM5105
Video
buffer
NOR
Flash
n DiSEqC
n Flexible GPIOs and interrupts
n Monitoring through I²C serial interface
n 90 nm CMOS process
n Multi supply: 1.0 V core, 2.5 V analog,
3.3 V interfaces
n Power saving features
n 1V0 DC regulator integrated
n TQFP 64 package with no exposed paddle.
TM
2.0 22 kHz to 100 kHz interface
PART NUMBERING
Table 1. Order Codes
Part Number Description
STV0288 Silicon receiver
STV0288-NIM Evaluation board
