ST STM32, STM8 User Manual

Embedded software solutions
ST, 3

rd

parties and open source

A full portfolio and several models

• Extensive Embedded Software ecosystem around the STM32 and STM8 microcontrollers

• You will find your solution, fitting your requirements in terms of price, feature, license scheme and support

• Generic solutions proposed by many companies, portable to/from other platforms

• Source code or binaries

• Supported by third parties

Third parties

• Built in-house, making the most of the STM32 and STM8 MCUs

• Source code or binaries

• Supported by ST

ST-designed software

• Proposed by community or third parties

• Source code, from BSD or GPL licenses to commercial products

• Supported by open-source community or third parties

Open source

2

A large community of third parties… and growing !

3

STM32 MCUs embedded software offer - overview

4

Solutions at all levels

Hardware abstraction layer (HAL)

File

system

USB

TCP/IP 2.4GHz

Display

Audio

Motor

control

Industrial

protocols

Virtual

Machines

and

Model driven
development

Automotive

Touch

sensing

Select the area of interest for more details

Safety

STL

Crypto

Connectors to

Cloud providers

NFC

Bootloader

Secure Boot

SSL
TLS

Security

Connectivity

Sub-1GHz

Building

Automation

and Control

Artificial

Neural

Networks

RTOS/

kernel

Cellular

Middleware Application fields

5

Hardware abstraction layer (HAL)

• Consistent programming interface

• When microcontrollers have different hardware implementations

• Full microcontroller coverage

• All peripherals are handled

Hardware abstraction layer

This layer is the first one to interact with the MCU hardware

7

STM32 - hardware abstraction layer

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2

F3

G4 F4 F7 H7 L0 L1 L4 /L4+ L5

F30x F37x

ST STM32Snippets Source Free N

1

N

1

Y N

1

Y N

1

ST Standard peripheral library Source Free N

1

N

1

Y N

1

Y Y Y Y N

1

Y N

1

N

1

N

1

Y N

1

ST

STM32Cube - HAL
Hardware Abstraction Layer

Open Source

Free

(BSD)

Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

ST

STM32Cube – LL
Low-Layer

Open Source

Free

(BSD)

Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

More details about hardware abstraction layer solutions: STM32 Embedded Software overview

1/ Not plan to make it available

8

STM8 - hardware abstraction layer

Provider Solution name Model Cost

Availability

STM8S

STM8AF

STM8L10x

STM8Lx5x
STM8Lx6x

STM8AL

ST Standard peripheral library Source Free Y Y Y

Back

9

Middleware and application fields

• All standard middleware covered

• RTOS/kernel

• File system

• USB

• Security (crypto, SSL/TLS, secure boot)

• Connectivity (TCP/IP, Bluetooth LE, Zigbee, Thread, Sub-1GHz, Sigfox, LoRa, Wi-Fi, NFC…),

Connectors to Cloud providers

• Display, Audio

• Safety

• Industrial protocols

• Motor Control

Middleware and application fields

Middleware stacks fill the gap between hardware and your application.
ST and third parties bring the required solutions, as well as application
software bricks to speed up customer development

11

• This is the root component to share time between several tasks on a single core.
It ensures task switching within a known and limited duration.

Middleware – RTOS / kernel

A multitude of solutions for STM32 and STM8 available now

12

STM32 – RTOS / kernel (1/4)

Provider

Solution

name

Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4 /L4+ L5

Alibaba Rhino RTOS Open Source (Apache 2.0) Free N N Y N Y N N N Y Y N Y N Y N
Arduino STM32Duino Open source LGPL v2.1 Free N N Y Y Y Y Y Y Y Y Y Y Y Y N
arm mbed OS

4

Open Source (Apache 2.0) Free Y N Y N Y Y Y N Y Y Y Y Y Y N

AWS

FreeRTOS
kernel

Source

2

Free Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

ChibiOS

ChibiOS/RT

ChibiOS/NIL

Open source (GPL3) or

Source

Free or

License

N N Y Y Y Y Y Y Y Y Y Y Y Y N

CMX CMX-RTX Source License N

3

N

3

Y N

3

Y Y Y N

3

Y Y Y Y Y Y N

3

CMX CMX-Tiny+ Source License N

3

N

3

Y N Y Y Y N

3

Y Y N Y Y N N

3

eCosCentric eCosPro

Modified GNU GPL or

Source

1

Free or

License

N

3

N

3

N N

3

Y Y Y N

3

Y Y N

3

N Y Y N

3

1/ eCos is an open-source kernel, a subset of eCosPro. eCosPro comes with TCP/IP stack, FAT, jFFS2, RAM and ROM FS
2/ FreeRTOS kernel license is MIT from V10 (former versions are under a modified GPL license)

3/ Please contact supplier
4/ Mbed OS is Threadcertified

13

STM32 – RTOS / kernel (2/4)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

eForce µC3/Compact Source License N

2

N

2

Y Y Y Y Y N

2

Y Y Y Y Y Y Y

eForce µC3/Standard Source License N N N N N N N N Y Y Y N N N N

Emcraft uCLinux

Open Source

(GPL)

1

Free

1

N N N N N N N N Y Y N

2

N N N N

Embedded
Office

Flexible Safety RTOS Source License Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

EUROS EUROS

Binaries or

source

License N

2

N

2

Y N

2

Y Y Y N

2

Y Y Y Y Y Y N

2

Microsoft

Azure RTOS
ThreadX

3

Source Free N

2

N

2

Y N

2

Y Y Y N

2

Y Y Y Y Y Y Y

Green Hills µ-velOSity Source License N

2

N

2

Y N

2

Y Y Y N

2

Y Y N

2

Y Y Y N

2

HCC eTaskSync Source License N

2

N

2

Y N

2

Y Y Y N

2

Y Y N

2

Y Y Y N

2

Keil / arm

RTX5 Open Source

(Apache 2.0)

Free

4

N

2

N

2

Y N

2

Y Y Y N

2

Y Y Y Y Y Y N

2

Mentor Nucleus Kernel Source License N

2

N

2

N N Y Y N

2

N

2

Y Y N

2

N N

2

Y N

2

1/ uCLinux is open source, but this company proposes some ports on STM32

2/ Please contact supplier

3/ ThreadX is part of the X-WARE IoT platform, which is Threadcertified
4/ RTX5 is part of arm Keil MDK software development tool

14

STM32 – RTOS / kernel (3/4)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Micrium µC-OS Open Source

(Apache 2.0)

Free N N Y N Y Y Y N Y Y N Y Y Y N

Weston

Embedded

Cesium RTOS Cs/OS2

and Cs/OS3

Source License N

2

N

2

Y N

2

Y Y Y Y Y Y N

2

Y Y Y N

2

Micro Digital SMX Source License N

2

N

2

N

2

N

2

Y Y Y N

2

Y Y N

2

N

2

N

2

N

2

N

2

NuttX NuttX Open Source

6

Free N N Y Y Y Y Y Y Y Y Y N Y Y N
Prove & Run ProvenCore-M Source License Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y
Quadros RTXC Rtos Source License N

2

N

2

N

2

N

2

Y Y N

2

N

2

Y N

2

N

2

N

2

Y N

2

N

2

Riot Riot Open Source

4

Free N N Y Y Y Y Y Y Y Y N Y Y Y Y
Rowebots UNISON software

expansion for

STM32Cube

(I-CUBE-UNISON)

3

Source Free

1

Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Rowebots UNISON

Source Free Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

RT-Thread RT-Thread

Open Source

5

Free N N Y Y Y Y N Y Y Y Y Y N Y N

1/ UNISON kernel is available free of charge to run on STM32 devices

2/ Please contact supplier

3/ Available as STM32Cube Expansion enhanced for STM32 Toolset
4/ LGPL V2.1 license
5/ GPL V2 till v3.1.0, Apache 2.0 from V3.1.0 onwards
6/ BSD till v8.2, Apache 2.0 from V9.0.0 onwards

15

STM32 – RTOS / kernel (4/4)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Sciopta SCIOPTA 61508

2

Source License N

4

N

4

Y N Y Y Y Y Y Y Y N Y Y N

4

SEGGER embOS software

expansion for
STM32Cube (I-CUBE­EMBOS)

Source License N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

Y N

6

N

6

N

6

N

6

N

6

SEGGER embOS Source License N

4

N

4

Y N

4

Y Y Y N

4

Y Y Y Y Y Y N

4

ST STM32Cube – FreeRTOS

kernel

Open source

(MIT)

5

Free Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

ST

X-CUBE-AZRTOS –
Azure RTOS ThreadX

Source Free

21

Q4

22

Q1

N 21

Q4

N N N 21Q321Q221

Q3

Beta N N 21Q2 21

Q3

Wittenstein -

High

Integrity Systems

OpenRTOS

1

Source License N

4

N

4

Y N

4

Y Y Y N

4

Y Y Y N

4

Y Y N

4

Wittenstein -

High

Integrity Systems

SafeRTOS

2

Source License N

4

N

4

Y N

4

Y Y Y N

4

Y Y Y N

4

Y Y N

4

Wittenstein -

High

Integrity Systems

SafeRTOS CORE

3

Source License N

4

N

4

Y N

4

Y Y Y N

4

Y Y Y N

4

Y Y N

4

Zephyr Zephyr kernel Open Source

(Apache 2.0)

Free Y N Y Y Y Y Y Y Y Y Y Y Y Y Y

1/ OpenRTOS is FreeRTOS with commercial support

2/ Safety certified RTOS for systems requiring certification

3/ SafeRTOS version without full safety certification/documentation

4/ Available on customer request. Please contact supplier
5/ Included in STM32Cube MCU packages (\Middlewares\Third_Party folder)

6/ Available on STM32Cube, so porting is very easy. Please contact supplier

16

STM8 – RTOS / kernel

1/ Please contact supplier

Provider Solution name Model Cost

Availability

STM8S

STM8AF

STM8L

STM8AL

AtomThreads AtomThreads RTOS Open source (BSD) Free Y N

1

Chibios ChibiOS/RT Open source (GPL3) or Source Free or License Y Y
CMX CMX-Tiny+

Source License Y N

1

SEGGER embOS

Source License Y Y

Back

17

• Many supported algorithms

• Through third parties (some with certifications) or directly from ST

Middleware – crypto

Often-seen acronyms

Symmetric ciphering

Ciphering method that ensures the reuse of a unique key, both for encryption and decryption. Example: AES, DES, 3DES, ARC4, …

Asymmetric ciphering

Ciphering method based on pair of key, a private and a public one. This also brings some kind of authentication: only the owner of private key can

decrypt content that was encrypted with a public one. And people able to decrypt with public key can be sure it was encrypted by owner of private key.

Example: ECDSA, RSA, …

Hashing

Method to calculate a unique value for a given data content. This allows ensuring a content was not modified for instance. Example: MD5, SHA, …

Cryptology helps users ensure the security of data or authentication. This
is a key element in ensuring the integrity of IoT applications for instance.

18

STM32 – crypto (1/2)

Back

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

CypherBridge

uVPN SDK

IKEv1/IKEv2/IPsec

Source License N N N N N N N N

1

Y Y Y N N Y N

1

EUROS

SSL/TLS

SSL v3, TLS 1.0, 1,1. 1.2

Binaries License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y Y Y Y N

1

EUROS

Cryptographic library, Verifiable Encryption

manager

1. Encryption methods:

- ARC4, - Blowfish,-Camellia- CAST5

- DES, - DAS, - ECC, - MD4, - MD5

- RSA, - SHA1,- SHA256, - SHA512

- TwoFish, - Whirpool, - HMAC96

- HMAC256

2. Coding:

- Rice, - RLE (Run-length encoding)

3. Compression:

- zlib, - libbz2, - LZ77,- LZW based (ZIP, GZ)

- Huffman, - Shannon-Fano

Binaries License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y Y Y Y N

1

HCC

Embedded Encryption Manager

AES, 3DES, DSS, EDH, MD5, RSA, SHA1, SHA256, ECC,
TIGER, CHACHA20

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y Y Y Y N

1

Oryx
Embedded

CycloneCrypto

Lite: MD2, MD4, MD5, SHA-1, SHA-2, HMAC, RC4, DES, triple
DES, AES, ECB, CBC, CFB, OFB, CTR, RSA, X.509
Pro: RIPEMD-128/160, Tigger/192, RC6, IDEA, Camellia,
SEED, ARIA, CCM, GCM, Diffie-Hellman, DSA
Ultimate: SAH-3, Keccak, CkaCha, Poly1305,
ChaCha20Poly1305 AEAD, PKCS #5, ECC, ECDSA, ECDH,
NIST-P, Brainpool

Open

source

(GPL2) or

Source

Free

or

license

N

1

N

1

Y N

1

Y Y Y Y Y Y Y Y Y Y Y

1/ please contact supplier

19

STM32 – crypto (2/2)

Back

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Rowebots

UNISON SSL/TLS Stack

AES, Blowfish, Triple-DES (3DES), DES, ARC4, Camellia,
XTEA
ECB, CBC, CFB, CTR, GCM, CCM
MD2, MD4, MD5, SHA-1, SHA-224, SHA-256, SHA-384,
SHA-512, RIPEMD-160
ECC

Source License N N N N Y Y Y Y Y Y Y N Y

Y N

4

SEGGER emSecure signatures Source License N

4

N

4

Y N

4

Y Y Y Y Y Y Y Y Y Y N

4

SEGGER emLib AES and emLib DES Source License N

4

N

4

Y N

4

Y Y Y Y Y Y Y Y Y Y N

4

SEGGER emFile encryption Source License N

4

N

4

Y N

4

Y Y Y Y Y Y Y Y Y Y N

4

ST

STM32 Cryptographic library

1, 2

AES, DES, 3DES, ARC4, MD5, SHA1, SHA2, RSA sig,
ECC Key gen, ECDSA, ...

Binaries Free N

6

N

6

N

6

N

6

Y Y N

6

N

6

Y N

6

N

6

N

6

Y N

6

N

6

ST X-CUBE-CRYPTOLIB Binaries Free Y N Y N Y Y Y N Y Y Y

3

Y Y Y Y

3

wolfSSL

wolfCrypt1, part of wolfSSL

MD2, MD4, MD5, SHA-1, SHA-256, SHA-384, SHA-512,
BLAKE2b, RIPEMD-160, Poly1305
AES (CBC, CTR, GCM, CCM), Camellia, DES, 3DES,
ARC4, RABBIT, HC-128, ChaCha20
RSA, DSS (DSA), DH, EDH, NTRU
ECDH-ECDSA, ECDHE-ECDSA, ECDH-RSA, ECDHE­RSA

Open

source

(GPL2) or

Source

Free or

license

N

4

N

4

N

4

N

4

N

4

Y N

4

N

4

Y Y Y Y Y Y N

4

1/ Can benefit from hardware acceleration when available.

2/ Subject to trade regulations. See website.
3/ delivered as a patch
4/ please contact supplier

5/ Available on STM32Cube, so porting is very easy

6/ Not plan to make it available

20

• Transport Layer Security (TLS) and its predecessor, Secure Sockets Layer (SSL),
are cryptographic protocols that provide communications security.

• The Transport Layer Security protocol aims primarily to provide privacy and data
integrity between a client and a server

Middleware – SSL/TLS (1/2)

21

STM32 – SSL/TLS solutions

1/ Formerly known as PolarSSL. Apache 2.0 open source or GPL 2.0 open source license

2/ Please contact supplier
3/ Apache 2.0 license, included in STM32Cube MCU packages (\Middlewares\Third_Party folder)
4/ Available on STM32Cube, so porting is very easy

Provider Solution name Model Cost

Availability

WB WL F1 F2 F4 F7 H7 L4/L4+ L5

arm Mbed TLS

1

Open source Free N N Y Y Y Y Y Y Y

CypherBridge Embedded TLS SDK (uSSL™) Source License N N N Y Y Y Y Y N

2

HCC Verifiable TLS Source License N

2

N

2

Y Y Y Y N

2

N

2

N

2

Oryx Embedded CycloneSSL

Open source (GPL2) or

Source

Free or license N

2

N

2

Y Y Y Y Y Y N

2

SEGGER emSSL Source License N

2

N

2

Y Y Y Y N

2

N

2

N

2

ST STM32Cube – mbed TLS

3

Open source Free N

4

N

4

Y Y Y Y Y N Y

wolfSSL Embedded SSL Library

Open source (GPL2) or

Source

Free or license N

2

N

2

N Y Y Y N

2

Y N

2

22

STM32 – SSL/TLS solution details

Provider Solution name Details

arm Mbed TLS

SSL version 3, TLS version 1.0, 1.1, 1.2,

More…

CypherBridge Embedded TLS SDK (uSSL™)

IETF standard SSL 3.0/TLS 1.2 protocols. Supported crypto and hash functions include: RSA, DSS, PKCSv1.5,
OAEP, DES, 3DES, AES,
RC4, SHA1, SHA2, MD2, MD4, MD5, RNG, X.509 certificate Processing

HCC Verifiable TLS

TLS 1.0, 1.1, 1.2, 1.3 (RFC 5246), CHACHA20, POLY1305, SSL3.0, DTLS 1.2 (RFC6347), 1.0 (RFC 4347), RFC
6520, HTTP over TLS (RFC 2818), HTTPS, FTPS, embedded encryption manager for full certificate management,
cipher suites: DH/DHE/DSS/ECDHE/RSA, AES/RC4/3DES, SHA/MD5

Oryx Embedded CycloneSSL

Server and/or client operation, Supports TLS 1.0, 1.1, 1.2, 1.3 and SSL 3.0, Supports DTLS 1.0 and DTLS 1.2,
Robust and efficient implementation, Supports ECC (Elliptic Curve Cryptography), Rich set of TLS cipher suites
(including Suite B profile),RSA, Diffie-Hellman and ECDH key exchange algorithms, PSK (Pre-

Shared Key) cipher
suites, Supports stream ciphers, CBC block ciphers as well as AEAD ciphers (CCM and GCM),

ChaCha20Poly1305 AEAD, Cryptographic library for common encryption algorithms (RC4, IDEA, DES, 3DES,

AES, Camellia, SEED and ARIA), Supports MD5, SHA-1, SHA-256 and SHA-384 hash algorithms, SSL/TLS
session resumption, PKIX path validation, Compliant with BSD socket API, Supports hardware accelerated
encryption engines (when available), Flexible memory footprint. Built-time configuration to embed only the
necessary features,Portable architecture (no processor dependencies), The library is distributed as a full ANSI C
and highly maintainable source code

SEGGER emSSL

TLS 1.0, 1.1 and 1.2.

More…

ST STM32Cube – mbed TLS

SSL version 3, TLS version 1.0, 1.1, 1.2,

More…

wolfSSL Embedded SSL Library

SSL version 3.0 and TLS versions 1.0, 1.1, 1.2, and 1.3 (client and server), DTLS 1.0, 1.2 support (client and

server)

More…

Back

23

A bootloader aims to enable firmware update in the field through a communication
interface.

STM32 devices embed a built-in bootloader in system memory, supporting UART,

SPI, I2C, CAN, USB interfaces.
Alternatively, developers can implement their own bootloader in user flash memory

(also called In-Application Programming)

ST also proposes a reference code for Secure Boot and Secure Firmware Update

Middleware – bootloader / secure boot

24

STM32 – bootloader / secure boot

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-IAP-USART

3

Source Free N

2

N

2

N

2

N

2

Y N

2

N

2

N

2

N

2

N2N

2

Y N

2

Y N

2

ST X-CUBE-IAP-SD

3

Source Free N

2

N

2

Y N

2

N

2

N

2

N

2

N

2

N

2

N2N

2

N

2

N

2

Y N

2

ST X-CUBE-SBSFU

4

Source Free Y N

6

N Y N N N Y Y Y Y Y Y Y N

5

ST STM32Cube – SBSFU Source Free N Y N N N N N N N N N N N N N
ST STM32Cube – OpenBootloader Source Free N N N N N N N Y N N N N N N Y
ST STM32Cube – TF-M Source Free N N N N N N N N N N N N N N Y

CypherBridge uLoadXL SDK Source License N N N N N Y N N Y Y Y N N Y N
eCosCentric RedBoot Source License N N N N Y Y Y N Y Y N

1

N Y Y N

1

EUROS Bootloader Binaries License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y Y Y Y N

Feaser OpenBLT

Open source

(GPL3) or Source

Free or

Licence

N

1

N

1

Y Y Y Y Y N

1

Y Y N

1

N

1

N

1

Y N

1

HCC Bootloaders Source License N

1

N

1

Y Y Y Y Y N

1

Y Y N

1

Y Y Y N

1

Simma Software ssBL-target, ssBL-PC Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

N

1

N

1

Y N

1

wolfSSL WolfBoot

Open source

(GPL2) or Source

Free or

license

Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

1/ Please contact supplier
2/ Available on STM32Cube, so porting is very easy
3/ In-application programming example
4/ Secure Boot + Secure Firmware update reference code to demonstrate best use of STM32 security protections
5/ For STM32L5, SBSFU is a TF-M example included in STM32CubeL5 MCU Package
6/ For STM32WL, SBSFU is included in STM32CubeWL MCU Package

25

STM32 – bootloader / secure boot details

Provider Solution name Details

ST X-CUBE-SBSFU

Secure Boot to check firmware image before execution, Secure Firmware Update with anti-rollback and

partial image update capabilities for over-the-air or local firmware image update, Secure key management

services offering cryptographic services by means of the PKCS #11 APIs, Standalone STM32 system solution

example demonstrating best use of STM32 protections to protect assets against unauthorized external or
internal access, Combined STM32 and STSAFE-A110 system solution example demonstrating hardware
Secure Element protections for secure authentication services and secure data storage

CypherBridge uLoadXL SDK

Software updates and secure boot loader for embedded platforms.
Safe install, to manage multiple images for an update, activation and safe-boot to rollback or factory version.
The integrated boot loader provides secure root of trust and software integrity checks

eCosCentric RedBoot

Debug and bootstrap firmware

Feaser OpenBLT

UART, CAN, TCP/IP, USB, SD-CARD
External flash and serial EEPROM

HCC Bootloaders

Serial, USB Device, USB Host , FAT
Ethernet, Fail-safety, AES encryption

Simma Software ssBL-target, ssBL-PC

Supported protocols include CAN, J1939, J1708, CANopen, UDS, Bluetooth, USB, and RS232

26

STM8 – bootloader

1/ Please contact supplier

Provider Solution name Model Cost

Availability

STM8S

STM8AF

STM8L

STM8AL

Simma Software ssBL-target, ssBL-PC Source License Y N

1

Back

27

• Safety solutions

• Ensuring data is not corrupted in any way (power supply removal, …)

• NAND, NOT, SSD memory access solutions

• With error correction and wear-leveling

Middleware – file system

A file system is the way in which files are named and how they are placed

logically for storage and retrieval. Several standards exist: FAT; JFFS2…

28

STM32 – file system (1/3)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

AWS FreeRTOS+TMFAT SL

2

Source Free N N Y N Y Y Y N Y Y N Y Y Y N

arm

Mbed LittleFileSystem,
FATFileSystem

Open source Free N

3

N

3

Y N

3

Y Y Y Y Y Y N Y Y Y Y

ChaN FatFS

Open source

(BSD)

Free N N N N Y N N N Y N N N N N N

CMX CMX-FFS

Source

License

N

3

N

3

Y N

3

Y Y Y N Y Y Y Y Y N N

CypherBridge uFile

Source

License

N N N N N Y N N

3

Y Y N

3

N N N

N

3

EmCraft

JFFS2, YaFFS, FAT, NFS,
etc..

Open source

(GPL)

Free N N N N N Y N N Y Y N

3

N N N N

eCosCentric

eCosPro-YAFFS1, MMFS,

JFFS2

Source

License

N N N N Y Y Y N Y Y N

3

N Y Y N

eForce µC3-FileSystem

Source

License

N

3

N

3

Y N

3

Y Y Y N

3

Y Y N

3

Y Y Y

N

3

Microsoft

Azure RTOS FileX +
LevelX

Source Free N

3

N

3

Y N

3

Y Y Y N

3

Y Y N

3

Y Y Y

N

3

1/ Free for non-commercial use
2/ For STM32 users, the license is the same as FreeRTOS kernel (MIT)
3/ Please contact supplier

29

STM32 – file system (2/3)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

EUROS FMS, FAT, SafeFAT

Binaries License N

3

N

3

Y N

3

Y Y Y N Y Y Y Y Y Y N

HCC

FAT FS: FAT, THIN,
exFAT SafeFAT /

Flash FS: SafeFlash

,

TINY, SafeFTL
SafeexFAT / FMSF

Source License N

3

N

3

Y N

3

Y Y Y N

3

Y Y Y Y Y Y N

3

Wittenstein ­High Int. Sys.

CONNECT File
System

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Green Hills

µ-velOSity File
System

Source License N N N N Y Y Y N

1

Y Y N

1

N Y Y N

1

Keil / arm MDK-ARM Flash

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Mentor

Embedded

Nucleus Storage

Source License N N N N Y Y Y N

1

Y Y N

1

N Y Y N

1

Micrium µC/FS

Open Source

(Apache 2.0)

Free N N Y N Y Y Y N Y Y N Y Y Y N

Weston
Embedded

Cesium RTOS Cs/FS

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

1/ Please contact supplier

2/ Included in STM32Cube MCU packages (\Middlewares\Third_Party folder)

30

STM32 – file system (3/3)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Micro Digital smxFS

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

N

1

N

1

N

1

N

1

Quadros RTXCfatfile

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Rowebots

Unison FAT File
System

Source License N N N N Y Y Y N

1

Y Y N

1

N Y Y N

1

SEGGER emFile

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

ST

STM32Cube ­FatFS

2

Open source

(BSD)

Free Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

ST

X-CUBE-AZRTOS ­FileX

Source Free

21

Q4

22

Q1

N 21

Q4

N N N 21

Q3

21

Q221Q3

Beta N N 21Q2 21

Q3

1/ Please contact supplier
2/ Included in STM32Cube MCU packages (\Middlewares\Third_Party folder)

31

STM8 – file system

1/ Could be very easily ported.
2/ Petit FatFS ported on STM8 available in demos

Provider Solution name Model Cost

Availability

STM8S

STM8AF

STM8L

STM8AL

ChaN Petit FatFS

Open source (BSD) Free N

1

Y

2

HCC FAT FS: FAT THIN, Flash FS:

TINY

Source License Y Y

SEGGER emFile

Source License Y Y

Back

32

Universal Serial Bus requires a dedicated software stack. This serial bus is organized in a star

topology with host and device roles, with the host organizing the traffic. Several device classes are

specified, in order to ease communication in different application cases.

Middleware – USB

Often-seen acronyms

OTG

On-The-Go: An OTG peripheral can switch host and device roles on the fly

HUB

Defines what protocols to implement to build a hub application

MS

Mass storage: Protocols to interact with storage block devices (for files)

HID

Human interface device: Protocols for peripherals interacting with humans (mouse, keyboard, etc.)

CDC

Communication device class: Protocols for serial communications, different sub-classes define details, for instance ACM for a standard COM port, or ECM for modems

Printer

Defines what protocols to implement to build a printer application

Audio

Defines what protocols to implement to build an audio application (microphone, headset, etc.)

DFU

Device firmware upgrade: Protocols to implement firmware upgrade ability

USB-PD

USB Power Delivery

TCPM

USB Type-C Port Manager

33

STM32 – USB solutions (1/3)

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Chibios ChibiOS/HAL

Open source

(GPL3) or

Source

Free or License N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

CMX

CMX-USB Device,
Host

Source License N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y N N

1

eCosCentric eCosPro-Host, Device Source License N

1

N N

1

Y Y Y N

1

Y Y N

1

N Y Y N

1

EUROS USB Host & Device Binaries License N

1

Y N

1

Y Y Y N

1

Y Y Y N Y Y N

1

EmCraft Linux USB Host

Open source (GPL)

Free N N N N Y N N

1

Y N N

1

N N N N

1

1/ Please contact supplier

34

STM32 – USB solutions (2/3)

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Microsoft Azure RTOS USBX Source Free N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

HCC

HCC-USB Host,
Device

Source License N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Keil / arm MDK-ARM USB Source License N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Mentor
Embedded

Nucleus USB Source License N N N Y Y Y N

1

Y Y N

1

N Y Y N

1

Micrium

USB Host, USB
Device

Open Source Free N Y N Y Y Y N Y Y N Y Y Y N

Weston
Embedded

Cesium RTOS
Cs/USBH, Cs/USBD

Source License N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

Micro Digital smxUSB Source License N

1

Y N

1

Y Y Y N

1

Y Y N

1

N

1

N

1

N

1

N

1

Quadros RTXCusb Source License N

1

N

1

N

1

Y Y Y N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

1/ Please contact supplier

35

STM32 – USB solutions (3/3)

Provider Solution name Model Cost

Availability

WB F0 G0

F1

F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Others

F105
F107

Rowebots Unison USB System Source

License

N N N Y Y Y N

1

Y N N

1

Y N Y N

1

SEGGER emUSB Device, emUSB Host Source

License

N

1

Y N

1

Y Y Y N

1

Y Y N

1

Y Y Y N

1

ST USB FS device library Source Free N Y N Y N N Y N

1

N N N

1

N Y N N

1

ST USB FS&HS Host&Device lib Source Free N N N N Y Y N N

1

Y N N

1

N N N N

1

ST

STM32Cube – USB
Host&Device

4

Source Free Y

2

Y

2

N Y

2

Y Y

2

Y

2

Y Y Y Y

2

Y

2

Y

2

Y

2

ST

STM32Cube – USB-C Power
Delivery

4

Source Free N N Y N N N Y N N N N N N Y

ST X-CUBE-USB-PD

5

Binary Free N

6

Y N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

6

N

1

ST X-CUBE-AZRTOS - USBX Source Free

21

Q4

N 21

Q4

N N N 21

Q321Q221Q3

Beta N N 21

Q2

21

Q3

Thesycon Embedded USB Device Source License N

1

N

1

N

1

N

1

Y N

1

N

1

Y Y N

1

N

1

N

1

N

1

N

1

Zephyr USB device stack

Open Source

(Apache 2.0)

Free N Y N Y Y Y N

1

Y Y N Y N Y N

1

1/ Please contact supplier
2/ Device only
4/ Included in STM32Cube MCU packages (\Middlewares\Third_Party folder)

5/ Examples for P-NUCLEO-USB001 and P-NUCLEO-USB002 Nucleo Packs, and for ON-FUSB3-STM32

6/ Available on STM32Cube, so porting is very easy

36

STM32 – USB solutions details (1/2)

Provider Solution name Details

Chibios ChibiOS/HAL

Device: HID, MS, CDC

CMX CMX-USB Device, Host

Device: HID, MS, CDC (ACM, ECM, RNDIS), Audio, Midi, MTP, PHDC
Host: HID, MS, CDC (ACM, ECM, RNDIS, OBEX), Audio, Midi, Printer, HUB

eCosCentric eCosPro-Host, Device

Device: MS, CDC (ACM, ECM, EEM, RNDIS)
Host: MS, CDC (ACM, ECM, EEM, RNDIS), Hub

EUROS USB Host & Device Stack

Device: HID, MS, CDC (ACM, ECM)
Host: HID, MS, CDC (ACM, ECM), HUB

Microsoft USBX

Device: HID, MS, CDC (ACM, ECM, RNDIS), Still Image, PTP, PictBridge, DFU, PIMA w/MTP
Host: HID, MS, CDC (ACM, ECM), Audio, Printer, HUB, ASIX, PIMA, GSER, PROLIFIC

EmCraft Linux USB Host

Host: HID, MS, CDC (ACM, ECM), HUB

HCC HCC-USB

Device: Connectivity (HID), File System & Storage (Mass Storage), Ethernet & Serial Interface (RNDIS, CDC-ACM,
CDC-ECM, CDC-EEM, CDC-NCM), Audio (AUDIO, 1.0, 2.0, MIDI), Multi-media & Printing (MTP, Pictbridge

, Printer PCL,
TEC), Healthcare (PHDC)
Host: Connectivity (HID, Hub, lan7500, lan9500, CCID, CP201x), File System & Storage (Mass Storage), Ethernet &
Serial Interface (RNDIS, CDC-ACM, CDC-ECM, CDC-EEM, CDC-FTDI, CDC-NCM), Audio (AUDIO, MIDI), Multi-media
& Printing (MTP, Printer)

Keil / arm MDK-ARM USB

Device: HID, MS, CDC (ACM), Audio

Host: HID, MS

Mentor Embedded Nucleus USB

Device: HID, MS, CDC (ACM, ECM)
Host: HID, MS, CDC (ACM, ECM), HUB

Micrium USB Host, USB Device

Device: HID, MS, CDC (ACM), Audio, PHDC (Medical)
Host: HID, MS, CDC (ACM), Audio, Printer, PHDC (Medical)

Weston Embedded Cesium RTOS Cs/USBH, Cs/USBD

Device: HID, MS, CDC (ACM), Audio, PHDC (Medical)
Host: HID, MS, CDC (ACM), Audio, Printer, PHDC (Medical)

37

STM32 – USB solutions details (2/2)

Provider Solution name Details

Micro Digital smxUSB

Device: HID, MS, CDC (ACM, RNDIS), Audio+Midi, Video, PTP, MTP, DFU
Host: HID, MS, CDC (ACM, ECM, Ethernet Adapter, WiFi and wireless modem,), Audio+Midi, Video, Printer, HUB

Quadros RTXCusb

Device: MS, CDC (ACM, ECM, RNDIS)
Host: HID, MS, CDC (ACM), HUB

Rowebots Unison USB System

Device: MS, CDC (ACM)
Host: MS, CDC (ACM), HUB, others on demand (inc . PHDC)

SEGGER emUSB Device, emUSB Host

Device: HID, MS, CDC (ACM), RNDIS, Printer, MTP

Host: HID, MS, CDC (ACM), HUB

ST USB FS device library

Device: HID, MS, CDC (ACM), Audio, DFU

ST USB FS&HS Host&Device

Device: HID, MS, CDC (ACM), Audio, DFU
Host: HID, MS

ST STM32Cube – USB Host&Device

Device: HID, MS, CDC (ACM), Audio, DFU
Host: HID, MS, CDC (ACM), Audio, MTP

ST STM32Cube – USB-C Power Delivery

4

USB PD 3.0, PPS, FRS, TCPCi, TCPM, source, sink, DRP, USB Type-C CC logic

ST X-CUBE-AZRTOS - USBX

Device: HID, MS, CDC (ACM, ECM, RNDIS), Still Image, PTP, PictBridge, DFU, PIMA w/MTP
Host: HID, MS, CDC (ACM, ECM), Audio, Printer, HUB, ASIX, PIMA, GSER, PROLIFIC

Thesycon Embedded USB Device

Device: Audio, CCID, Mass Storage, network, HID, CDC (ACM)

Zephyr USB device stack

Device: CDC (ACM), DFU

Back

38

• TCP and IP were developed by a US Department of Defense research project to
connect a number of different networks designed by different vendors into a

network of networks (the Internet).

• It was initially successful because it delivered a few basic services that everyone
needs (file transfer, electronic mail, remote logon) across a very large number of
client and server systems and is now widely deployed.

Middleware – TCP/IP (1/2)

39

Middleware – TCP/IP (2/2)

Often-seen acronyms

ARP

Address resolution protocol: Provides

physical address from IP address

IP

Internet protocol: Primary protocol in Internet Protocol Suite.

2 flavors: IPv4 and IPv6. IPv4 will disappear as it only supports up to 232addresses, not enough for future needs, while IPv6

supports 2

128

6LoWPAN

IPv6 over low

-power wireless personal area networks: Provides IPv6 connectivity to low-rate wireless networks

IPSec

Internet protocol security: Secured version of IP, using cryptography

TCP

Transmission control protocol: Provides reliable, ordered delivery of a stream of bytes

UDP

User datagram protocol: Provides unreliable service.

Datagrams may arrive in any order, duplicated, or may be missing. Used for time-sensitive applications, when data drop is better than

delay

DHCP

Dynamic host configuration protocol: Provides means to allocate

IP address dynamically

DNS

Domain name system: Translates domain names meaningful to humans into numerical IP

ones

FTP

File transfer protocol: Provides means to copy files from one host to another

TFTP

Trivial file transfer protocol: Similar to FTP, but based on UDP, and

simpler (for example, no directory)

SMTP

Simple mail transfer protocol: Used to send e

-mail to a server

POP

Post office protocol: Used to retrieve e

-mail from a server

HTTP

Hypertext transfer protocol: Used by web browsers

SSL/TLS

Transport layer security: Secured container for application protocols using cryptography. Example: HTTPS means HTTP over SSL,

FTPS, etc.. IPSec applies cryptography at a lower level

than SSL/TLS, making it more universal. However, SSL is widely used.

40

STM32 – TCP/IP solutions (1/2)

Provider Solution name Model Cost

Availability

WB F1 F2 F4 F7 H7 L4/L4+

AWS FreeRTOS+TMTCP

2

Source Free N

1

Y Y Y Y N

1

N

1

AWS FreeRTOS+TMUDP

2

Source Free N

1

Y Y Y Y N

1

N

1

CMX CMX-TCP/IP Source License N

1

Y Y Y Y N

1

N

1

CMX CMX-MicroNet Source License N

1

Y Y Y Y N

1

N

1

CypherBridge Embedded SSH SDK (uSSH™) Source License N

1

N Y Y Y N

1

N

1

EUROS TCP/IP stack Binaries License N

1

Y Y Y Y Y N

1

Microsoft

NetX and NetX Duo IPv4/IPv6
and NetX Secure SSL/TLS/DTLS

Source Free N

1

Y Y Y Y N

1

Y

eCosCentric

SecureSockets, SecureShell

eCosPro stacks

Source License N

1

Y Y Y Y N

1

N

1

eForce µNet3 Source License N

1

Y Y Y Y N

1

N

1

EmCraft Linux TCP/IP stack Open source (GPL) Free N N Y Y Y N

1

N

Green Hills µ-velOSity TCP/IP v4/v6 Source License N

1

Y Y Y Y N

1

N

1

Wittenstein - High
Integrity Systems

CONNECT TCP Source License N

1

Y Y Y Y N

1

N

1

1/ Please contact supplier
2/ The license is the same as FreeRTOS kernel (MIT)

41

STM32 – TCP/IP solutions (2/2)

Provider Solution name Model Cost

Availability

WB F1 F2 F4 F7 H7 L4/L4+

HCC MISRA HCC-TCP/IP v4/v6 Source License N

2

Y Y Y Y N

2

Y

Keil / arm MDK-ARM TCPNET Source License N

2

Y Y Y N

2

N

2

Y

Mentor Embedded Nucleus Network Source License N

2

Y Y Y Y N

2

Y
Micrium µC/TCP-IP Open Source Free N Y Y Y Y N Y
Weston Embedded Cesium RTOS Cs/NET Source License N

2

Y Y Y Y N

2

Y
Micro Digital smxNS and smxNS6 (Dual IPv6/v4) Source License N

2

Y Y Y Y N

2

N

2

Oryx Embedded CycloneTCP Open source (GPL2) or source Free or license N

2

Y Y Y Y Y Y

Quadros RTXC Quadnet Source License N

2

Y Y Y Y N

2

N

2

Rowebots Unison TCP-IP/v4-v6 Source License N

2

N Y Y Y N

2

N

2

SEGGER embOS/IP Source License N

2

Y Y Y Y Y Y

ST STM32Cube – LwIP

1

Open source (BSD) Free N

3

Y Y Y Y Y Y

ST X-CUBE-AZRTOS – NetX / NetX duo Source Free

21Q4

N N

21Q2

21Q3

Beta

21Q2

Zephyr Zephyr Networking Open Source (Apache 2.0) Free N Y Y Y Y N Y

1/ A port to STM32 was implemented by ST, as part of STM32Cube, Licensing model cascaded to end-user.

Included in STM32Cube MCU packages (\Middlewares\Third_Party folder)

2/ Please contact supplier
3/ Available on STM32Cube, so porting is very easy

42

STM32 – TCP/IP solution details (1/3)

Provider Solution name Details

AWS FreeRTOS+TMTCP

ARP, DHCP, DNS, LLMNR, NBNS, UDP

AWS FreeRTOS+TMUDP

ARP, DHCP and DNS

CMX CMX-TCP/IP

PPP, PPPoE, ARP, IGMP, ICMP, IPv4, UDP, TCP, DHCP(cs), DNS, FTP(cs), IMAP4, NAT, POP3(c), SMTP , SNMP, SNTP, Telnet(s),
SSL/TLS, SSH, TFTP(cs), HTTP(s)

CMX CMX-MicroNet

PPP, ARP, IGMP, ICMP, IPv4, UDP, TCP, DHCP(c), DNS, FTP(cs), POP3(c), SMTP, SNMP, SNTP, Telnet(s), SSL/TLS, TFTP (c),
HTTP(s)

CypherBridge Embedded SSH SDK (uSSH™)

SSH 2.0, Configurable DSS and RSA asymmetric session, Configurable crypto with 3DES AES and blowfish support, SCP, SFTP

EUROS TCP/IP stack

PPP, PPPoE, ARP, IGMP, ICMP, IPv4, IPv6, IPSec/IKE, UDP, TCP, DNS, DHCP(cs), FTP(cs), NAT, POP3(c), SMTP, SNMP, SNTP,
Telnet(s), SSL/TLS, TFTP, HTTP(cs), SFTP, FTPS, SSH

Microsoft NetX and NetX Duo IPv4/IPv6

PPP, ARP, IGMP, ICMP, IPv4, IPv6, IPSec/IKE, UDP, TCP, DNS, DHCP(c), FTP(cs), NAT, POP3(c), SMTP, SNMP, SNTP, Telnet(s),
TFTP, HTTP(s)

eCosCentric SecureSockets

SSH2

eCosCentric SecureShell

SSL/TLS

eCosCentric eCosPro stacks

PPP, ARP, ICMP, UDP, TCP, IPv4, IPv6, DHCP, BOOTP, SMTP, TFTP, FTP(c+s), HTTP, SNMP, NTP, mDNS, Bonjour

eForce µNet3

PPP, ARP, IGMP, ICMP, IPv4, IPv6, UDP, TCP, DNS, DHCP(c), FTP(s), HTTP(cs), TFTP, SNMP, SNTP, Telnet(s), POP3(c), SMTP,
SSL/TLS

EmCraft Linux TCP/IP stack

PPP, DNS, NAT, SSH (cs), DHCP (cs), SNMP (cs), Telnet (cs), FTP (cs), HTTP (cs)

HCC MISRA HCC-TCP/IP v4/v6

IPv4, IPv6, UDP, TCP, DNS, DHCP(cs), FTP(cs), SMTP, TFTP(s), SLIP, PPP, PPPoE, IGMP, IPSec/IKE, NAT, POP3(c), SNMP, SNTP,
Telnet(s), RTP/RTCP, EAP, EST, ESMTP, SSH, MLDv2, NDP, MQTT

Wittenstein - High Integrity
Systems

CONNECT TCP

TCP, UDP, ARP, ICMP, IPv4, DNS, DHCP, FTP, TFTP, HTTP, LLMNR,
NBNS, Auto-IP, standard sockets or callback interface

(c): Client

(s): Server

(cs): Client and Server

43

STM32 – TCP/IP solution details (2/3)

(c): Client
(s): Server
(cs): Client and Server

Provider Solution name Details

Green Hills µ-velOSity TCP/IP v4/v6

ARP, ICMP, IGMP, IPv4, IPv6, IPv4/6, UDP, TCP, DNS, DHCP(c),

Keil / arm MDK-ARM TCPNET

SLIP, PPP, ARP, IPv4, ICMP, UDP, TCP, DNS, DHCP(c), FTP(s), SMTP, SNMP, Telnet(s), TFTP(s), HTTP(s)

SICS LwIP

PPP, ARP, ICMP, IPv4, UDP, TCP, DHCP(c), IPv6

Mentor Embedded Nucleus Kernel

PPP, PPPoE, ARP, IGMP, ICMP, IPv4, IPv6, IPSec/IKE, UDP, TCP, DHCP(c), FTP(cs), NAT, SNMP, SNTP, Telnet(cs), SSL/TLS, TFTP (cs),
HTTP(cs)

Micrium µC/TCP-IP (and µC/SSL)

ARP, ICMP, IPv4, UDP, TCP, DNS, DHCP(c), FTP(cs), SMTP, POP3(c), SNTP, Telnet(s), SSL/TLS, TFTP, HTTP(s)

Weston
Embedded

Cesium RTOS Cs/NET

ARP, ICMP, IPv4, UDP, TCP, DNS, DHCP(c), FTP(cs), SMTP, POP3(c), SNTP, Telnet(s), SSL/TLS, TFTP, HTTP(s)

Micro Digital smxNS and smxNS6 (Dual IPv6/v4)

SLIP, PPP, PPPoE, ARP, IGMP, ICMP, IPv4, IPv6, IPv4/6, UDP, TCP, DNS, mDNS, DHCP(cs), FTP(cs), NAT, POP3(c), SMTP, SNMP,
SNTP, Telnet(s), SSL/TLS, TFTP, HTTP(cs), SSH

Oryx Embedded CycloneTCP

Dual stack (IPv4 and/or IPv6), Built-in support for multiple network interfaces, BSD style socket API, Blocking/non-blocking socket, operation
and event-driven functions (select and poll), Efficient data transfer (zero copy), Well-crafted TCP module with selective ACK and congestion
control, Raw socket interface, Multicast support (IGMPv2 and MLDv1), IP fragmentation and reassembly, Flexible memory footprint, Portable
architecture, Host name resolution (DNS client), DHCP and SLAAC auto-configuration, SMTP client, FTP client and server, TFTP client and
server, Web server with SSI and CGI scripting, HTTP/2 client, MQTT and MQTT-SN clients, CoAP client, SNMPv1/v2c/v3 agent, WebSocket
client and server

44

STM32 – TCP/IP solution details (3/3)

(c): Client
(s): Server
(cs): Client and Server

Provider Solution name Details

Quadros RTXC Quadnet

PPP, PPPoE, ARP, IGMP, ICMP, IPv4, IPv6, IPSec/IKE, UDP, TCP, DNS, DHCP(cs), FTP(cs), NAT, POP3(c), SMTP, SNMP, SNTP,
Telnet(s), SSL/TLS, TFTP, HTTP(cs), UPnP, Prioritized Packets Handling

Rowebots Unison TCP-IP/v4-v6

PPP, ARP, ICMP, IGMP, IPv4, IPv6, IPv4/6, 6LowPan, IPSec, UDP, TCP, DNS, DHCP(cs), SMTP(c), SNMP, Telnet(s), TFTP(cs), HTTP(cs),
NAT

SEGGER embOS/IP

PPP, PPPoE, ARP, ICMP, IGMP, IPv4, UDP, TCP, DNS, DHCP(cs), FTP(cs), SMTP(c), SNTP(c), Telnet(s), TFTP(cs), HTTP(s), PTP IEEE
1588

SICS Contiki/uIP6

IPv6, 6LoWPAN

ST STM32Cube - LwIP

PPP, ARP, ICMP, IPv4, UDP, TCP, DHCP(c), IPv6

ST X-CUBE-AZRTOS – NetX / NetX duo

PPP, ARP, IGMP, ICMP, IPv4, IPv6, IPSec/IKE, UDP, TCP, DNS, DHCP(c), FTP(cs), NAT, POP3(c), SMTP, SNMP, SNTP, Telnet(s), TFTP,
HTTP(s)

Zephyr Zephyr Networking

IPv4, IPv6 (dual stack support), ICMPv4, ICMPv6, UDP, TCP, HTTP, MQTT, CoAP, LWM2W, RPL, DNS/ 6LoWPAN

Back

45

• Solutions with STM32WB or STM32 + Bluetooth transceiver

• Several solutions are available, using STM32WB or STM32 with SPBTLE-RF, BlueNRG-MS or

other components

Middleware – 2.4GHz – Bluetooth

Often-seen acronyms

Bluetooth Low Energy

(Also called Bluetooth Smart) very interesting for application running out of battery (coin cell type) as power consumption

is very low, with a lower data rate and connection time
Classic Bluetooth Original Bluetooth before Bluetooth Low Energy appearance. Still required for certain Audio applications.
Dual mode devices Devices able to handle Classic Bluetooth, and Bluetooth Low Energy. Also called Bluetooth Smart ready
HCI Host/controller interface: Standardized communication between controller and radio chips
SPP Serial port profile: Profile that emulates serial line over Bluetooth
A2DP Advanced audio distribution profile: Profile to stream high-quality audio
HSP Headset profile: Profile to implement a basic headset application
HDP Health device profile: Profile designed to facilitate transmission and reception of medical data
HFP Hands-free profile: Typical profile used in cars for hands-free phone use

BLE is a wireless communication technology for exchanging data over
short distances, typically used in the mobile world

46

STM32 – Bluetooth solutions

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-BLE1

Binaries and Source

Free

N.A.

N

1

N

1

N

1

N

1

N

1

N

1

Y N

1

N

1

Y N

1

Y

N

1

ST STM32CubeL4-BLE

2

Source Free

N.A.

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

Y

N

1

ST STM32Cube – BLE

3

Source Free

Y N N N N N N N N N N N N N

1/ STM32L0 + BlueNRG-MS. Available on STM32Cube so porting is very easy
2/ point to point and HeartRate profile example running on running on B-L475E-IOT01Awith ST SPBTLE-RF
3/ Certified BLE stack + HCI, certified OpenThreadbinary stack, BLE/OpenThreadconcurent stack, BLE profiles and services, certified 802.15.4 MAC, Zigbee, BLE/Zigbee concurrent stack
included in STM32Cube MCU package (\Middlewares\ST folder)

47

STM32 – Bluetooth solutions

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

arm Mbed BLE

4

Source Free

Y N N N N N N N N N N N Y N

A&W PhoneLink

Binaries or Source

License and/or

royalties

N N N Y Y N N Y Y Y

1

N N N N

Clarinox ClarinoxBlue

8

Binaries or Source

License and/or

royalties

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

EUROS BLE stack

6

Binaries License

N Y Y Y Y Y Y Y Y Y Y Y Y Y

1

Rowebots

UNISON Bluetooth
System

Source License

N N N Y Y Y N Y Y Y

1

N Y

Y N

SEARAN dotStack

Binaries or Source

License and/or

royalties

N Y Y Y Y Y N Y Y Y

1

Y Y Y N

Zephyr Bluetooth

Open Source

(Apache 2.0)

Free

N N N Y N Y N Y N N N N Y N

1/ Available on customer request. Please contact supplier

2/ Available on specific conditions. Please contact supplier

4/ Support BLE, Heart Rate Service, iBeacon on ST boards: DISCO-L475VG-IOT01A, P-NUCLEO-WB55
6/ SmartBond™ DA14681 Bluetooth® low energy SoC adapted to the EUROS RTOS
8/ ClarinoxBlue supports mutliple RTOS and many wireless radio supporting HCI (UART, USB)

48

STM32 – Bluetooth solution details

Provider Solution name Details

ST X-CUBE-BLE1

BT4.0, BT4.1
All profiles supported

ST I-CUBE-nRF51DRV

BT4.0, BT4.1
All profiles supported

ST STM32Cube – BLE

BT 5.0
PTS Profiles/Services:
Client: Heart Rate Profile (HRP): Collector, Location and Navigation (LNP), Time Profile (TIP), Weight Scale Profile (WSP), Alert Notification
Profile (ANP), Health thermometer Profile (HTP): Collector, Phone Alert Status Profile (PASP), Find Me Profile (FMP), Proximity Profile (Px
Monitor, PXP), HID Over GATT Profile (HOGP): Boot Host, Report Host
Server: Heart Rate Profile (HRP): Heart Rate Sensor, Device Information Service (DIS), Link Loss (LLS), Battery Service (BAS), Tx Power
Service (TPS),
Scan Parameters (ScPP), Location and Navigation (LNS), Immediate Alert (IAS), Next DST Change Service (NDCS), Reference Time Update
Service (RTUS), Current Time Service (CTS), Weight Scale Profile (WSP), Alert Notification Profile (ANP), Environmental Sensing (ESS), Blood
Pressure Profile (BLP), Bond Management Service (BMS), Cycling Power Profile (CPP), Cycling Speed and Cadence Profile (CSCP), Health
thermometer Profile (HTP): Thermometer, Automation IO Service (AIOS), HTTP Proxy Service (HPS), Phone Alert Service (PASS), Find Me
Profile (FMP + IAS), Environmental Sensing (ESS) Proximity Profile (Px Reporter, PXP), Running and Speed Cadence Service (RSCS), HID
Service (HIDS), Glucose Service (GLS).

Zephyr Bluetooth

BT5.0, GAP, GATT, BR/EDR, Mesh

49

STM32 – Bluetooth solution details

Provider Solution name Details

arm Mbed BLE

More…

A&W

PhoneLink

BT2.1+EDR, BT4.0
Supported Profiles: HFP, HSP, PBAP, A2DP, AVRCP, HID, OBEX, FTP, OPP, SPP, PAN, MAP and more

Clarinox

ClarinoxBlue

BT4.2, BT 4.1, BT4.0 + EDR + LE + Mesh
Supported profiles: Classic Porfiles (A2DP, AVRCP, BIP, BPP, CTN, DI, FTP, GAP, GAVDP, HCRP, HDP, HFP, HID, HSP, MAP, MPS, OPP,
PAN, PBAP, SDAP, SPP), Classic Protocols (AVCTP, AVDTP, BNEP, HCI, L2CAP, MCAP, OBEX, RFCOMM, SDP), Smart Profiles / Services
(AIOP, AIOS, ANP, ANS, BAS, BCS, BMS, BLP, BLS, CGMP, CGMS, CPP, CPS, CSCP, CSCS, CTS, DIS, ESP, ESS, FMP, GAP, GLP, GLS,
HIDS, HOGP, HPS, HRP, HRS, HTP, HTS, IAS, IPS, IPSP, LLS, LNP, LNS, NDCS, OTP, OTS, PASP, PASS, PLXP, PLXS, PXP, RSCP, RSCS,
RTUS, ScPP, SCPS, TIP, TDS, TPS, UDS, WSP, WSS, Mesh, Custom), Smart Protocols (ATT, GATT, SM, MESH)

SEARAN

dotStack

BT2.1+EDR, BT4.0, BT4.1, BT 4.2, and 5.0 ready. Single and dual mode. Apps on iOS and Android
BLE (GATT) - ANP/ANS, FMP, HIDS, HOGP, PASP/PASS, PXP, TIP, BAS, DIS, IAS, LLS, TPS, ANCS, BLP/BLS, GP, HTP, HRP/HRS
BR/EDR - SPP, HID, PAN, MAP, FTP, HSP, HFP, A2DP, AVRCP, PBAP, iAP, HCRP

Back

50

Thread is an IPv6-based, low-power mesh networking technology for IoT products.
Thread uses 6LoWPAN and IEEE 802.15.4 wireless protocol with mesh
communication

Middleware – 2.4GHz – Thread

.

Solutions with STM32WB

51

STM32 – Thread solutions

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST STM32Cube – OpenThread

1

Source Free

Y N N N N N N N N N N N N N

1/ Certified OpenThreadbinary stack, BLE/OpenThreadconcurent stack included in STM32Cube MCU package (\Middlewares\ST folder)

52

ZigBee is an IEEE 802.15.4-based specification for a suite of high-level
communication protocols used to create personal area networks with small, low­power digital radios, such as for home automation, medical device data collection,
and other low-power low-bandwidth needs, designed for small scale projects
which need wireless connection.

Middleware – 2.4GHz – Zigbee

Solutions with STM32WB

53

STM32 – Zigbee solutions

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST STM32Cube – Zigbee

1

Source Free

Y N N N N N N N N N N N N N

1/ Certified Zigbee stack, BLE/Zigbee concurent stack included in STM32Cube MCU package (\Middlewares\ST folder)

Provider Solution name Details

ST STM32Cube – Zigbee

1

Support following clusters: Basic, Device Temperature Configuration, Identify, On/Off, Power Profile, Thermostat-UI-Config, Ballast-Configuration, Illuminance-Measurement,
Temperature Measurement, Pressure Measurement, Occupancy-Sensing, Messaging , Meter Identification

54

• Wi-Fi™ is an implementation of the IEEE 802.11 radio communication
specification for wireless local area networking. It is usually used with a TCP/IP

stack, so all TCP/IP bricks can be reused on Wi-Fi, adapting the lowest firmware

layer

• Solutions with STM32 + Wi-Fi transceiver

• Several solutions are available, using STM32 with modules

(Espressif ESP8266, Inventek ISM43362-M3G-L44, Innophase INP1010/INP1011)

Middleware – 2.4GHz – Wi-Fi™

55

STM32 – Wi-Fi™ solutions

Provider Solution name Model Cost

Availability

WB F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

arm Mbed Wifi

5

Source Free

N N N N N N N Y N N N N Y N

Clarinox ClarinoxWiFi

6

Binaries or

Source

License and/or

Royalties

N N N N N N N Y Y Y Y Y Y N

Innophase I-CUBE-T2-STW

8

Binaries or

Source

License

N

N

7

N

7

N7N7N

7

N

7

N7N7N7N7N

7

Y N

7

ST

STM32CubeL4/L4+–
WiFi

2

Source

Free

N

1

N

1

N

1

N1N1N

1

N

1

N1N1N1N1N

1

Y N

1

ST STM32CubeF4 – WiFi

3

Source

Free

N

1

N

1

N

1

N1N1N

1

N

1

Y

N1N1N1N

1

N

1

N

1

ST STM32CubeF7 – WiFi

4

Source

Free

N

1

N

1

N

1

N1N1N

1

N

1

N

1

Y

N1N1N

1

N

1

N

1

Zephyr Zephyr Wifi

Open Source

(Apache 2.0)

Free

Y Y Y Y Y Y Y Y Y Y Y Y Y Y

1/ Available on STM32Cube, so porting is very easy
2/ Client Server application and HTTP Server application examples running on B-L475E-IOT01A with Inventek ISM43362-M3G-L44
3/ Client Server application and HTTP Server application examples running on STM32F413H-DISCOwith Inventek ISM43362-M3G-L44
4/ In-Application programming client example running on STM32F723E-DISCO and STM32F769I-DISCO
5/ Supports ST boards including DISCO-L475VG-IOT01A, DISCO-F413ZH
6/ Clarinox WiFi protocol stack supports multiple RTOS, and SDIO, SPI, USB
7/ Available on STM32Cube, so porting is very easy

8/ Supports I-NUCLEO-T2 -EVB with INP1010/INP1011

Back

56

• LoRa® is a modulation used for wireless telecommunications. It is created to allow
long-range communications at a very low bit-rate and enables long-life battery­operated sensors. LoRaWAN™ is a standard defined by the LoRa-Alliance which
defines the communication and security protocol to ensure the interoperability.

• Solutions with STM32 + LoRa® radio

• STM32WL

• Semtech SX1276MB1MAS, SX1276MB1LAS and SX1272MB2DAS LoRa® radio expansion

boards

• Murata CMWX1ZZABZ-xxx LoRa® module (also used for Sigfox)

• USI WM-SG-SM-42 LoRa® module

• RiSiNGHF® RHF0M003 modem for LoRa®

Middleware – sub-1GHz – Lora®

57

STM32 – LoRa® solution

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST I-CUBE-LRWAN

2

Source Free

N.A.

N N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

Y Y Y N

1

ST

STM32Cube ­LoRaWAN

Source Free N Y N N N N N N N N N N N N N

arm mbedOS LoRa

3

Source

Free

N.A.

21Q1

N N N N N N N N N Y N N N

StackForce LoRaWAN stack

Source/Object

License/Royalties

N.A.

Y N N N N N N N N N Y N N N

1/ Available on STM32Cube, so porting is very easy
2/ Supports NUCLEO-L053R8, NUCLEO-L152RE and NUCLEO-L476RG with I-NUCLEO-LRWAN1

B-L072Z-LRWAN1
I-NUCLEO-LRWAN1
P-NUCLEO-LRWAN1 (NUCLEO-L073RZ + I-NUCLEO-SX1272D)
P-NUCLEO-LRWAN2 and P-NUCLEO-LRWAN3

3/ Available on DISCO-L072CZ-LRWAN1

Back

NFC

58

• Sigfox™ is a Low-Power Wide Area Network allowing low-power sensors to
benefit from a planetary network, enabling end-devices with low BOM cost

• Solutions with STM32 + radio

• STM32WL

• Murata CMWX1ZZABZ-xxx module

Middleware – Sub-1GHz – sigfox™

59

STM32 – sigfox™ solution

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-SFOX Source Free

N.A.

N N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

Y

2

N

1

N

1

N

1

ST

STM32Cube ­Sigfox

Source Free

N Y N N N N N N N N N N N N N

1/ Available on STM32Cube, so porting is very easy

2/ Supports Murata CMWX1ZZABZ-xxx module only in B-L072Z-LRWAN1

Back

NFC

60

• Sub 1GHz RF operates in the ISM spectrum bands below Sub 1GHz – typically in
the 769 – 935 MHz , 315 MHz and the 468 MHz frequency range. This spectrum

band below 1GHz is particularly useful for RF IOT applications

• Solutions with STM32WB, STM32WL or STM32 + radio (SPIRIT1 or S2-LP)

Middleware – Sub-1GHz – others

61

STM32 – Sub-1GHz – others

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-SUBG1

2

Source Free

N.A.

N N

1

N

1

N

1

N

1

N

1

N

1

Y N

1

N

1

Y Y N

1

N

1

ST

STM32Cube –

802.15.4

4

Source Free

Y N N N N N N N N N N N N N N

StackForce emb6 - 6LoWPAN

based IoT stack

3

Source/Object Free / License

N N N N N N N N N N N Y N N N

StackForce WM-Bus stack

Source/Binaries

License

N Y N N N N N N N N N Y

3

N N N

1/ Available on STM32Cube, so porting is very easy
2/ Supports WM-bus with X-NUCLEO-IDS01A4, Contiki OS and Contiki 6LoWPAN protocol on STM32F4 and STM32L1
3/ STM32L0 + SPIRIT1
4/ Certified BLE stack + HCI, certified OpenThreadbinary stack, BLE/OpenThreadconcurent stack, BLE profiles and services, certified 802.15.4 MAC
included in STM32Cube MCU package (\Middlewares\ST folder)

Back

62

• Complementary to other wireless technologies, Near Field Communication (NFC) is designed to
execute short transactions between two devices in close proximity.

• Operating in the 13.56 MHz (RFID) HF band, it is based on ISO/IEC 14443 & ISO/IEC 15693 RFID
standards, and regulated by NFC Forum industry association

• Solutions with STM32 + ST25 NFC / RFID Tag & Reader ICs

• NFC / RFID reader ICs

• ST25R3911B high performance HF Reader/NFC initiator (ISO14443, ISO15693, FeliCa) with 1.4 W output power, supporting

VHBR, capacitive sensitive wake up and Automatic Antenna Tuning (AAT)

• Other product variant: ST25R3912, ST25R3913, ST25R3914, ST25R3915 and ST25R3916

• CR95HF entry level HF Reader/ NFC Initiator (ISO14443, ISO15693, FeliCa)

• Dynamic NFC tag Ics

• ST25DV dynamic RFID ISO15693 – NFC Type 5 Tag Ics

• M24LR dynamic RFID ISO15693 / NFC compatible Tag ICs (M24LR04 is NFC Forum Type 5)

• M24SR dynamic RFID ISO14443 type A – NFC Type 4 Tag ICs

Middleware & drivers – NFC

63

• NFC / RFID readers

• X-CUBE-NFC3: Drivers and Middleware (NFC Lib, NDEF Lib) for CR95HF, HF Reader/ NFC Initiator, packaged to run on X-NUCLEO-NFC03A1

• X-CUBE-NFC5: Drivers and Middleware (RFAL Lib) for ST25R3911B, HF Reader/ NFC Initiator, packaged to run on X-NUCLEO-NFC05A1

• X-CUBE-NFC6: Drivers and Middleware (RFAL Lib) for ST25R3916 high performance NFC front-end IC, to run on X-NUCLEO-NFC06A1

• Dynamic NFC tags

• X-CUBE-NFC1: Drivers and Middleware (NDEF Lib) for M24SR Dynamic NFC/RFID Tag IC, packaged to run on X-NUCLEO-NFC01A1

• X-CUBE-NFC2: Drivers and Middleware (NDEF Lib) for M24LR Dynamic NFC/RFID Tag IC, packaged to run on X-NUCLEO-NFC02A1

• X-CUBE-NFC4: Drivers and Middleware (NDEF Lib) for ST25DV Dynamic NFC/RFID Tag IC, packaged to run on X-NUCLEO-NFC04A1

STM32 – NFC solutions

Provider

Solution

name

Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-NFC1 Source Free

N

1

N

1

Y

N

1

Y

N

1

Y

N

1

Y

N1N

1

Y Y Y

N

1

ST X-CUBE-NFC2 Source Free

N

1

N

1

N1N

1

N

1

N1N1N

1

Y

N1N

1

Y

N

1

N

1

N

1

ST X-CUBE-NFC3 Source Free

N

1

N

1

N1N

1

Y

N1N1N

1

Y

N1N1N1N

1

N

1

N

1

ST X-CUBE-NFC4 Source Free

N

1

N

1

N1N

1

N

1

N1N1N

1

Y

N1N

1

Y

N

1

N

1

N

1

ST X-CUBE-NFC5 Source Free

N

1

N

1

N1N

1

N

1

N1N1N

1

Y

N1N1N1N

1

Y

N

1

ST X-CUBE-NFC6 Source Free

N

1

N

1

N1N

1

N

1

N1N1N1N1N1N

1

Y

N

1

Y

N

1

1/ Available on STM32Cube, so porting is very easy

Back

NFC

64

STMicroelectronics framework for devices based on LPWAN cellular networks, with
ready-to-run examples using the LPWAN LTE Cat M or NB-IoT protocols to support

quick evaluation and development of IoT cloud applications

• BSD-like socket APIs for data plane

• TCP-UDP/IP connectivity with IP stack running on host or modem

• Flexible and modular SW architecture for the easy integration of different modems

• Modem Low Power support (PSM)

• Partial GSMA TS34/35 compliance

• Easy customization thanks to API and configuration flags

• Support Secure Element hosted in UICC HW or eUICC HW

• PC terminal for debug and configuration (APN, band…) using Command Line Interface (CLI)

Middleware & drivers – Cellular framework

65

Host Board STM32 Modem Vendor/Chipset Modem Model Modem Board Description Availability

P-L496G-CELL02 L4 Quectel/Qualcomm BG96 MB1329 Cellular pack that includes the daughter

board MB1329

Now

32L496Discovery L4 Quectel/Qualcomm BG96 MB1329 / Now
32L496Discovery L4 Sequans/Sequans GM01Q/ GMS01Q GM01Q-STMOD/ GMS01Q-

STMOD

With SIM from Orange for GMS01Q Now

B-L4S5I-IOT01A L4+ Quectel/Qualcomm BG96 w/ X-NUCLEO-STMODA1 with

MB1329

Can re-use eSIM on Now

B-L4S5I-IOT01A w/ X­NUCLEO-STMODA1

L4+ Sequans/Sequans GM01Q w/ X-NUCLEO-STMODA1 with

GM01Q-STMOD

Modem without eSIM Now

STEVAL-STWINKT1x L4+ Quectel/Qualcomm BG96 MB1329 Now
STEVAL-STWINKT1x L4+ Sequans/Sequans GMS01Q GMS01Q-STMOD Now
B-L462E-CELL1 L4 MURATA/Sony Semiconductor Israel LBAD0XX1SC Integrated in the Module Module LBAD0ZZ1SE with integrated

Modem and eSIM

1Q21

STM32 – Cellular framework

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-CELLULAR Source Free

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

Y N

1

1/ Available on STM32Cube, so porting is very easy

Back

Supported Hardware and cellular partners

66

• Safety targets protection of people and equipment from danger and harm,
through a set of counter-measures ensuring defined targets

Middleware – Safety

Often-seen acronyms

ClassB

The IEC 60730 safety standard defines the test and diagnostic methods that ensure the safe operation of embedded control hardware and software for household appliances.
The IEC 60730 standard category Class B prevents unsafe operation of the controlled equipment.

SIL

Safety Integrity Level (SIL) is defined by the industry standard IEC 61508 as a relative level of risk-reduction provided by a safety function, or to specify a target level of risk
reduction.

ASIL

ASIL is a risk classification scheme defined by the ISO 26262 - Functional Safety for Road Vehicles standard. This is an adaptation of the Safety Integrity Level used in IEC 61508
for the automotive industry.

Ready for certification offers on STM32
3rdparties or directly from ST

67

STM32 – Safety solutions

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-CLASSB

5

Source Free Y N Y N Y Y Y Y Y Y Y Y Y Y N

ST STM32-CLASSB-SPL Source Free N N Y N Y Y

3

N N Y

3

N N N Y

3

N N

ST X-CUBE-STL

4

Object Free N N

6

Y Y Y

N Y Y

Y Y Y Y N Y Y

1/ Porting ongoing
2/ Can be ported
3/ Derived package only (not certified)
4/ IEC 61508 SIL3 (SC3) compliant self-test library, certified by TÜV Rheinland. Delivered as compiler independant object code. Safety Manual, FMEA and FMEDA.
Available under NDA, please contact your ST sales office.
5/ IEC 60335-1 and 60730-1 compliant, certified by UL.

6/ planned for 2021/Q2

68

STM8 – Safety solutions

Back

Provider Solution name Model Cost

Availability

STM8S STM8AF

STM8L

STM8AL

ST STM8-SafeCLASSB Source Free Y

Y

Y

ST STM8A-SafeASIL

1

Document Free N

Y

Y

1/ Safety Manual, FMEA, FMEDA and specification for selt-test library

69

• Getting the most from hardware and software

• ST has built a close relationship with third parties providing software solutions based on our

microcontrollers. Customers can make the most of their hardware.

Middleware – graphical user interface

Often-seen acronyms

Anti aliasing

Technique to minimize distortion artifacts known as aliasing when presenting a high-resolution image at a lower resolution. Aliased images show

some stair effects on curves. Anti-aliasing removes this by modifying edge pixel colors.

Alpha blending

Alpha blending is the process of combining a translucent foreground color with a background color, thereby producing a new blended color.

GUI

Graphical user interface

bpp

Bits per pixel (also known as color depth: Number of bits used to represent the color of a single pixel in an image.
1 bpp corresponds to monochrome images.

Palette

Technique to lower image memory size by storing the set of colors used in a table and using this table for each pixel

JPEG

Commonly used method of lossy compression for digital image. The degree of compression can be adjusted, allowing a trade-off between storage
size and image quality. JPEG typically achieves 10:1 compression with little perceptible loss in image quality.

RGB / ARGB

Color model in which red, green and blue are merged to reproduce a broad array of colors. “A” field in ARGB format handles transparency
information.

Widgets

Element of a graphical user interface that can be changed by the user (such as text box, radio button)

.

ST’s MCUs can drive displays through serial or parallel interfaces

70

STM32 – graphical user interface solutions (1/2)

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST STemWin

Binaries Free N N N N Y Y Y N Y Y Y N Y N N

ST STM32Cube - STemWin

Binaries Free N

2

N

2

Y N

2

Y Y Y N

2

Y Y Y N

2

Y Y

N

2

ST TouchGFX

4

Source Free Y

3

Y

3

N Y

3

N N Y

3

Y

3

Y Y Y N N Y Y

3

Altia

Altia Design and Deep
screen

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y N

1

Y N

N

1

Crank Storyboard

Binaries License N

1

N

1

N N

1

N

1

N

1

Y N

1

Y Y Y N N

1

N

N

1

eCosCentric eCosPro-PEG

Source License N

1

N

1

N

1

N

1

Y Y Y N

1

Y N

1

N

1

N

1

N

1

N

1

N

1

Microsoft Azure RTOS GUIX

Source License N

1

N

1

Y N

1

Y Y Y N

1

Y Y Y Y Y Y

N

1

1/ Please contact supplier
2/ Available on STM32Cube, so porting is very easy
3/ Although no project example is provided, the TouchGFX binary can be used on these series

4/ TouchGFX is available as a software expansion for STM32Cube

71

STM32 – graphical user interface solutions (2/2)

Provider

Solution

name

Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Korulab Koru

Binaries License N N N N N N N N Y Y Y N N Y N

Micrium µC/GUI

Open Source
(Apache 2.0)

Free N N Y N Y Y Y N Y Y Y Y Y N N

Micro Digital PEG

Source License N

1

N

1

N

1

N

1

Y Y Y N

1

Y Y Y N

1

N

1

N

1

N

1

QT QT

Source License N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

Y Y N

1

N

1

N

1

Y N

1

Rowebots emWin GUI

Source License N N N N Y Y Y N Y Y Y N N N N

SEGGER emWin

Source License N

1

N

1

Y Y Y Y Y N Y Y Y Y Y Y N

Tara Systems

Embedded

Wizard

Binaries / Source License N N N N N N N N Y Y Y N N Y N

Back

1/ Please contact supplier

72

• NRE/royalty-free C source code

• Complete solution for touch keys, linear and rotary touch sensors, with acquisition, post

processing and API layers, debounce filtering and calibration functions

Middleware – touch sensing

Often-seen acronyms

Surface capacitance

The capacitance of a single ended electrode is modified when the finger gets close to it.

Projected capacitance

The capacitance between two sensing electrodes is modified when the finger gets close to them.

RC acquisition

Resistor-capacitor acquisition for surface capacitanceonly. It consists in measuring the charge and discharge time duration of a RC
cell made of the electrode capacitance and a load resistor.

CT acquisition

Charge transfer acquisition for surface capacitance only. It consists in measuring the duration for charging the electrode capacitance
and transferring part of the accumulated charge into a sampling capacitor. The CT acquisition is more robust than the RC one.

Capacitive touch sensing is an electrical cost-efficient technology, replacing
conventional mechanical switches to detect user actions, to build modern GUI look
and feel.

73

STM32 – touch-sensing solutions

Provider Solution name Acquisition Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST

STM32 Touch Sensing

Library

CT Source Free N N Y N N N Y N N N N N Y N N

ST

STM32Cube – Touch
Sensing

CT Source Free Y N Y N N N Y N Y N N Y Y Y Y

74

STM8 – touch-sensing solutions

Provider Solution name Acquisition Model Cost

Availability

STM8S / STM8AF STM8L / STM8AL

ST STM8 Touch Lib RC + CT Source Free Y

1

Y

1

1/ RC for STM8S/STM8AF, RC for STM8AL, RC and CT for STM8L

Back

75

Middleware – artificial neural networks

Thanks to a wide set of Artificial Intelligence (AI) solutions from ST you now have the possibility to
map and run Machine Learning (ML) such as Artificial Neural Networks (ANN) on the broad STM32
microcontroller portfolio. STM32Cube.AI is an extension pack of the widely used STM32CubeMX
configuration and code generation tool converting and optimizing pre-trained ANN models on
STM32 Arm® Cortex®-M-based microcontrollers

Often-seen acronyms

AI

Artificial Intelligence

ML

Machine Learning

ANN

Artificial Neural Networks

76

STM32 – artificial neural networks

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-AI

1

Source Free Y Y N N N Y Y Y Y Y Y N N Y Y

ST FP-AI-SENSING1

2

Source Free N

4

N N N N N

4

N

4

N

4

N

4

N

4

N

4

N N Y N

4

ST

FP-AI-VISION1

3

Source Free N N N N N N N N N N Y N N N N

1/ Generation of an STM32-optimized library from pre-trained Neural Network models. Support various Deep Learning frameworks such as Keras, Caffe, ConvnetJS, and Lasagne
2/ STM32Cube function pack for ultra-low power IoT node with artificial intelligence (AI) application based on audio and motion sensing
3/ STM32Cube function pack featuring examples of computer vision applications based on Convolutional Neural Network (CNN).
4/ Available on STM32Cube, so porting is very easy

Back

77

STM32 – artificial neural networks

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST X-CUBE-AI

1

Source Free Y Y N N N N Y Y Y Y Y N N Y Y

ST FP-AI-SENSING1

2

Source Free N

*

N N N N N

*

N

*

N

*

N

*

N

*

N

*

N N Y N

*

ST FP-AI-VISION1

3

Source Free N N N N N N N N N N Y N N Y

7

Y

7

ST FP-AI-FACEREC1

4

Source Free N N N N N N N N N N

21

Q1

N N Y

7

Y

7

ST FP-AI-NANOEDG1

5

Source Free N

6

N N N N N

6

N

6

N

6

N

6

N

6

N

6

N N Y Y

1/ Generation of an STM32-optimized library from pre-trained Neural Network models. Support various Deep Learning frameworks such as Keras, TensorFlow™ Lite and suppport of
all frameworks that can export to the ONNX standard format such as PyTorch™, Microsoft® Cognitive Toolkit, MATLAB® and more.
2/ STM32Cube function pack for ultra-low power IoT node with artificial intelligence (AI) application based on audio and motion sensing.
3/ STM32Cube function pack featuring examples of computer vision applications based on Convolutional Neural Network (CNN).
4/ STM32Cube function pack featuring examples of face detection and face recognition with on-board enrollment.
5/ STM32Cube function pack for artificial intelligence-based condition monitoring and predictive maintenance.

6/ Available on STM32Cube, so porting is very easy.

7/ Demo and code example available on demand.

Back

78

• Enabling your FreeRTOS application to process command line input

STM32 – instrumentation

Back

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

AWS FREERTOS+TMCLI

1

Source Free Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

1/ The license is the same as FreeRTOS kernel (MIT)

79

Connectors to cloud providers

• Examples of end device applications using ST sensors and RFID/NFC tag and connecting to
cloud providers

Amazon AWS, Google Cloud, IBM Watson, Microsoft Azure

Exosite, Grovestream, AvSystem, Litmus Automation, Ubidots

Amazon AWS, IBM Watson, Microsoft Azure

• Connectors to cloud provider (Amazon AWS, Microsoft Azure, IBM Watson…)

STM32 acts as an end device securely connected to cloud services
providers

• Configuration of the connectivity interfaces (WiFi, Ethernet…)

• Connection to the Internet and the cloud provider servers

• publication of messages

• Subscription over a variety of connectivity protocols (MQTT,

HTTPS…)

STM32Cube Expansion

Packages

• Temperature and humidity sensor (HTS221)

• Pressure sensor (LPS25HB)

• Motion sensors (LIS3MDL, LSM303AGR, LSM6DS0, LSM6DSL, IIS2DH)

• Writing/reading the RFID/NFC tag (M24SR64-Y)

STM32 ODE Functions

packs

80

STM32 - connectors to cloud providers

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

ST

X-CUBE-CLD-GEN

1

Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

Y N

3

X-CUBE-AWS

2

Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

Y N

3

X-CUBE-AZURE

2

Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

Y N

3

X-CUBE-WATSON Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

Y N

3

X-CUBE-GCP Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

Y N

3

FP-CLD-AWS1 Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y N

3

N

3

N

3

N

3

N

3

N

3

FP-CLD-AZURE1

Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y N

3

N

3

N

3

N

3

Y N

3

FP-CLD-WASTON1

Source Free N

3

N

3

N

3

N

3

N

3

N

3

N

3

N

3

Y N

3

N

3

N

3

N

3

N

3

N

3

1/ Supports B-L475E-IOT01A, 32F413HDISCOVERY, 32F769IDISCOVERY, P-L496G-CELL01 and P-L496G-CELL02. Examples with Exosite,

Grovestream, AvSystem, Litmus Automation and Ubidots cloud providers

2/ Supports B-L475E-IOT01A, 32F413HDISCOVERY, 32F769IDISCOVERY and P-L496G-CELL02. Includes Secure Firmware Update (SBSFU), integration
with X-CUBE-CELLULAR. May be connected to a provided AWS/AZURE web dashboard.
3/ Available on STM32Cube, so porting is very easy

81

STM32 - connectors to cloud providers

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

AVSystem

Anjay LwM2M SDK

Open source Free N N N N N N N N N N N N N Y N

AWS

Amazon FreeRTOS

1

Source Free

2

N N N N N N N N N N Y N N Y N

CypherBridge

uMQTT Toolkit

Source License N N N N N N N N Y Y N N N Y N

GIZWITS

I-CUBE-GIZWITS

Source Free N N N N N N N N Y Y N N N Y N

IoTerop

IOWA

Binary, Source License Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Microsoft

Azure RTOS SDK for
Azure IoT

Source License N

4

N

4

Y Y Y Y Y N

4

Y Y N

4

N

4

N

4

N

4

N

4

Keil / arm

IoT Client

3

Source License N

4

N

4

Y N

4

Y Y Y N

4

Y Y Y Y Y Y N

4

1/ “Connect to AWS Iot” and “Connect to AWS Greengrass” packages are available for STM32L4/L4+Discovery kit IoT node
2/ MIT license
3/ Amazon AWS, Google Cloud, IBM Watson, Microsoft Azure
4/ Please contact supplier

Back

82

• A complete solution for all audio aspects

• All audio aspects can be covered by solutions from ST or third parties

• Optimized for ST products

• Unlike open-source non-optimized solutions, ST works with third parties to propose optimized

algorithms for ST platforms

Application field – audio

Often-seen acronyms

Codec

A codec is a program capable of encoding and decoding a digital data stream. The encoded stream can be compressed or not, with a lossy (MP3, WMA, …) or

lossless (FLAC, ALAC, …) mechanism.

PCM

Pulse-code modulation: Digital representation of an analog signal, in which the magnitude of the analogue signal is sampled regularly, each sample being
quantized to the nearest value within a range of digital steps.

AAC, MP3, WMA

Music codecs with patents. Royalties need to be paid to patent owners.

Speex

Open source, no royalties speech codec

G711

Simple codec with no royalties often used in telephony

G726

ADPCM (adaptive differential pulse code modulation): Simple compression of PCM data

83

STM32 – audio solutions

Provider

Solution name Model Cost

Availability

WB WL F0 G0 F1

F105
F107

F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+

ST ADPCM Vocoder, Speex Vocoder Source Free N

1

N

1

N N Y N

1

N

1

N

1

N

1

N

1

N N N Y N

1

ST G711, G726, G726A Vocoders Source Free N

1

N

1

N N N

1

N

1

Y

3

N

1

N

1

Y

3

N N N N

1

N

1

ST

Audio Engine MP3 Decoder

With Channel Mixer, Equalizer and Loud

Binaries Free N

1

N

1

N N N

1

Y Y N

1

N

1

Y Y Y N N

1

N

1

ST

Audio Engine MP3 Codec

With Channel Mixer, Equalizer and Loud

Binaries Free N

1

N

1

N N N

1

Y Y N

1

N

1

Y N N N N

1

N

1

ST

Audio Engine WMA Decoder

With Channel Mixer, Equalizer and Loud

Binaries Free N

1

N

1

N N N

1

Y Y N

1

N

1

Y Y N N N

1

N

1

ST

Audio Engine AAC Decoder

AAC-LC, HE-AAC+ v1, HE-AAC+ v2

Binaries Free N

1

N

1

N N N

1

Y

3

Y

3

N

1

N

1

Y

3

N

1

N

1

N N

1

N

1

ST Audio Engine AC3 Decoder Binaries Free N

1

N

1

N N N N N N N

1

N

1

N

1

N

1

N N N

ST

Audio Engine Post Processing

Smart volume control, Equalizer,
Sample rate converters, Stereo widening

Binaries Free N

1

N

1

N N N N N N

1

N

1

Y N

1

N

1

N N N

ST

Apple iAP Streaming Library
(iPod/iPhone/iPad)

2

Source Free N

1

N

1

N N N Y Y Y N

1

Y N

1

N

1

N Y N

ST

USB audio class and stream synchro.

(feedback pipe, external PLL, …)

Binaries Free N

1

N

1

Y N N Y Y N

1

N

1

Y Y N Y N N

ST Source Rate Converter

3

Binaries Free N

1

N

1

N N Y Y Y N

1

N

1

Y Y N N N

1

N

1/ The library will run immediately on these targets, even if not ported officially.
2/ Only available by request to local sales for companies being a licensee of Apple MFi (Made for iPod) program.
3/ Available on demand. Ask your local ST Sales office.

84

STM32 – audio solutions

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1

F105
F107

F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+

ST X-CUBE-AUDIO

3

Binaries Free N

5

N

5

N N N

5

N

5

N

5

N

5

N

5

Y Y N

5

N N

5

N

5

ST X-CUBE-VS4A

4

Source Free N N N N N N N N N N Y N

5

N N N

ST STM32Cube – PDM2PCM library

6

Source Free N

5

N

5

N

5

N

5

N

5

N

5

Y N

5

N

5

Y Y Y N

5

N

5

N

5

DSPConcept Audio Weaver Algorithms Binaries License N N N N N N N N N Y Y Y N N N

Craftwork

Remote Speakers (DLNA Media
Renderer)

Binaries License N N N N N N N

1

N N Y N

1

N

1

N N N

Sensory Voice recognition

2

Binaries License N N N N N N N N N Y N

1

N

1

N N N

Vestec Voice recognition

2

Binaries License N N N N N N N N N Y N

1

N

1

N N N

1/ The library will run immediately on these targets, even if not ported officially.
2/ Available on demand. Ask your local ST Sales office.
3/ Audio processing components (BAM, BIQ, CDC, GAM, GREQ, HPV,SRC236, SRC441, OMNI2, SVC, SDR,SMR), MP3 decoder (Cortex-M7/M4/M3), MP3
encoder (Cortex-M3/M4)
4/ Framework for the Alexa Voice Service (AVS)
5/ Available on STM32Cube, so porting is very easy
6/ Included in STM32Cube MCU packages (\Middlewares\ST folder).

85

Modules Names Quality Measured MHz

Flash

Memory

Static RAM Dynamic RAM Remarks

SRC441

Standard 13.7 MHz 3204 Bytes 232 Bytes 3228 Bytes

Sampling Rate Conversion
from 44.1 to 48 kHz

High Quality 20.4 MHz 3894 Bytes 360 Bytes 3676 Bytes

SRC236

Standard

8->16: 4.4 MHz
48->96: 25.3 MHz
16->48: 12.5 MHz
8->48: 12.3 MHz
32->48: 12.7 MHz
24->16: 6.2 MHz

1740 Bytes 972 Bytes 3364 Bytes

Sampling Rate Conversion supporting ratios
2, 3, 6, 1/2, 1/3, 1/6, 3/2 and 2/3.

High Quality

8->16: 7.1 MHz
48->96: 40.7 MHz
16->48: 20.4 MHz
8->48: 20.2 MHz
32->48: 20.5 MHz
24->16: 10.2 MHz

2238 Bytes 1932 Bytes 4804 Bytes

Omnisurround – Stereo

Widening

Enhanced Mono to
Stereo

6.4 MHz

3660 Bytes 1992 Bytes 384 Bytes Signal is sampled at 48 kHzSW 2.0 to 2.0 13.2 MHz

Closely Spaced
Speakers

4.0 MHz

Omnisurround – 7.1
Virtualizer

5.1 or 7.1 -> 2.0 25.6 MHz 4764 Bytes 3028 Bytes 1152 Bytes Signal is sampled at 48 kHz

Focus – STM32 audio post-processing (1/2)

Figures of merit on STM32F4 target

86

Modules

Names

Quality Measured MHz

Flash

Memory

Static RAM

Dynamic

RAM

Remarks

Gfx Equalizer
(GrEq)

10-bands 14 MHz 4390 Bytes 552 Bytes 3840 Bytes

Graphical Equalizer.
Signal is sampled at 48 kHz, 10 parallel bands with 6

available presets
Can run in place (Input buf = Output buf)

Biquad Filters 10 Biquads 14.1 MHz 570 Bytes 600 Bytes 4 Bytes

Generic Biquads filter (used for Transducer Equalizer for
instance)

Signal is sampled at 48 kHz
Can run in place (Input buf = Output buf)

Bass Manager
(BAM)

with Limiter 17.1 MHz

9266 Bytes 2236 Bytes 5760 Bytes

Bass Manager.

Up to +/- 24 dB, between 60 and 300Hz
Can run in place (Input buf = Output buf)

without Limiter 12.7 MHz

Smart Volume
Control (SVC)

Standard 6.2 MHz

6160 Bytes 2648 Bytes 4800 Bytes

Smart Volume Control (includes DRC)
Signal is sampled at 48 kHz
Can run in place (Input buf = Output buf)

High Quality 10.9 MHz

Gain Manager
(GAM)

Standard

Stereo: 2.6 MHz

1472 Bytes 120 Bytes 1 Bytes

Gain Manager
Signal is sampled at 48 kHz
Can run in place (Input buf = Output buf)

8 channels: 8.6 MHz

Panning

L/R Panning

F/R Balancing

8.4 MHz

5654 Bytes 6872 Bytes 7680 Bytes

Signal is sampled at 48 kHz

2.0 input, 4.0 output

Contains Front and Rear Left/Right Panning, Front/Rear
balancing.

Sweet Spot Mode for one user.

Sweet Spot Mode 1 4.2 MHz
Sweet Spot Mode 2 (Ambi) 4.7 MHz 7956 Bytes 6968 Bytes 7680 Bytes

Focus – STM32 audio post-processing (2/2)

Back

Figures of merit on STM32F4 target

87

Application field – building automation and control

Building automation is the automatic centralized control of a building's heating, ventilation and air

conditioning, lighting and other systems through a building management system or building
automation system (BAS). A building controlled by a BAS is often referred to as a smart building or a
smart home.

Often-seen acronyms

BACnet

communications protocol for Building Automation and Control (BAC) networks that leverage the ASHRAE, ANSI, and ISO 16484-5 standard protocol. BACnet was designed to allow
communication of building automation and control systems for applications such as heating, ventilating, and air-conditioning control (HVAC), lighting control, access control, and fire
detection systems and their associated equipment. The BACnet protocol provides mechanisms for computerized building automation devices to exchange information, regardless of
the particular building service they perform.

DALI

Digital Addressable Lighting Interface (DALI) is a trademark for network-based systems that control lighting in building automation. The underlying technology was established by a
consortium of lighting equipment manufacturers as a successor for 0-10 V lighting control systems, and as an open standard alternative to Digital Signal Interface (DSI), on which it is
based. DALI is specified by technical standards IEC 62386 and IEC 60929. Standards conformance ensures that equipment from different manufacturers will interoperate. The DALI
trademark is allowed on devices that comply with the current standards when manufactured.

DLMS / COSEM

IEC 62056 is a set of standards for Electricity metering data exchange by International Electrotechnical Commission. The IEC 62056 standards are the International Standard
versions of the DLMS/COSEM specification. DLMS or Device Language Message Specification (originally Distribution Line Message Specification[1]), is the suite of standards
developed and maintained by the DLMS User Association and has been adopted by the IEC TC13 WG14 into the IEC 62056 series of sta

ndards. COSEM or Companion Specification

for Energy Metering, includes a set of specifications that defines the Transport and Application Layers of the DLMS protocol

DMX-512

DMX512 (Digital Multiplex) is a standard for digital communication networks that are commonly used to control stage lighting and effects. It was originally intended as a standardized
method for controlling light dimmers, which, prior to DMX512, had employed various incompatible proprietary protocols. It soon became the primary method for linking controllers
(such as a lighting console) to dimmers and special effects devices such as fog machines and intelligent lights

KNX

KNX is a standardized (EN 50090, ISO/IEC 14543), OSI-based network communications protocol for building automation. KNX is the successor to, and convergence of, three
previous standards: the European Home Systems Protocol (EHS), BatiBUS, and the European Installation Bus (EIB or Instabus)

88

STM32 – building automation and control

Provider Solution name Model Cost

Availability

WB WL F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+

MBS

BACnet stack

embedded

Source License

N

3

N

3

Y N

3

Y Y Y Y Y Y Y Y Y Y

prizm.io BACnet Stack

Source License

N

3

N

3

Y N

3

Y Y Y Y Y Y Y Y Y Y

ST

DALI

2

Source Free

N

3

N

3

N N

3

Y N N N N N N N Y N

MBS DALI 2 stack

Source License

N

3

N

3

Y Y Y Y Y Y Y Y Y Y Y Y

Andrea
Informatique

DLMS / COSEM

Binaries License

N

3

N

3

N

3

N

3

Y Y N

3

N

3

Y N

3

N

3

N

3

Y N

3

ST

DMX-512

4

Source Free

N

1

N

1

N

1

N

1

Y N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

N

1

prizm.io

DMX-512 Stack

Source License

N

3

N

3

Y Y Y Y Y Y Y Y Y Y Y Y

TAPKO

KAIstack KNX

Binaries / source

License + royalties

N

3

N

3

Y Y Y Y Y Y Y Y Y N

3

N

3

N

3

Weinzierl

KNX

Source

License

N

3

N

3

Y Y Y N

1

N

1

N

1

N

1

N N N

1

Y N

1

1/ Can be ported
2/ Provided on demand to sales office, supporting DALI slave only.
3/ Please contact supplier
4/ Provided on demand to sales office.

89

STM8 – building automation and control

Provider Solution name Application Model Cost

Availability

STM8S /

STM8AF

STM8L /

STM8AL

ST

DALI Lighting Source Free

Y N

1

TAPKO

KAIstack KNX Building automation

Binaries / source

License N Y

1/ Can be easily ported

Back

90

Application field – industrial protocols

Lower
latency

Real-time

Non real

-time

Field

(Motion control ,

drive)

Automation,

Control

(PLC)

Supervisor,
information

(configuration,

diagnostic)

Sensor/actuator

scheduling

Prioritization

TCP / UDP

RT

IRT

Fieldbus (RS485, CAN)

Ethernet

TCP

Industrial market needs are very fragmented in terms of communication protocols.
Many different protocols are available for different target applications in factory
automation

91

STM32 – industrial protocols (1/8)

Provider Solution name Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Acontis

EC-Master Factory Automation

Source License

N N N N N N N N Y N N N N

ASIX Electronics

AX58100

STM32F303RE

Motor Control

Demo Kit

6

Factory Automation

Source Free

N N N N Y N N N Y N N N N

CMX

CMX-CANopen Automation, medical

Source License

N N Y Y Y N

1

Y Y N

1

N N N

1

N

1

Cypherbridge

uMODBUS Factory Automation

Source License

Y

3

N N N N N Y

4

Y

4

N N N N N

eCosCentric

eCosPro-CAN Factory Automation Source License

N N Y Y Y N

1

Y Y N

1

N N Y N

1

CANopen Factory Automation Source License

N N Y Y Y N

1

Y Y N

1

N N Y N

1

eCosPro-ModbusTCP

Factory Automation Source License

N N N Y Y N

1

Y Y N

1

N N Y N

1

Embedded office

CANopen Factory Automation Source Free

5

N N Y Y N N Y N N N N N N

emotas

CANopen Automation, medical

Source

License Y Y Y Y Y Y Y Y Y N N Y Y

J1939 Commercial vehicles

Source

License Y Y Y Y Y Y Y Y Y N N Y Y

EnergyBus Commercial vehicles

Source

License Y Y Y Y Y Y Y Y Y N N Y Y

EtherCAT

2

Automation, medical

Source

License Y Y Y Y Y Y Y Y Y Y Y Y Y

1/ Please contact supplier
2/ Requires external hardware
3/ MODBUS RTU
4/ MODBUS TCP
5/ Apache 2.0 license
6/ EtherCAT slave motor control solution based on ASIX AX58100 + STM32 and X-CUBE-MCSDK

92

STM32 – industrial protocols (2/8)

Provider Solution name Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

EUROS

CANOpen Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

PROFINET Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

Modbus

Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

EtherCAT

1

Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

Ethernet

Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

OPC UA Server/Client Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

MQTT Client Automation

Binaries License

Y Y Y Y Y Y Y Y Y Y Y Y

1/ Requires external hardware.

93

STM32 – industrial protocols (3/8)

1/ Requires external hardware (netX52 or netX90).

2/ source for STM32, binary for external hardware.
3/ Available on STM32Cube, so porting is very easy

Provider Solution name Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Hilscher

I-

CUBE-NETX +

PROFIBUS

DP Slave

(1)

Fieldbus

Factory

automation

Source +

Binary

(2)

License

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

CANopen Slave

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

DeviceNet

Slave

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

CC

-Link Slave

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

OPC UA Server

(1)

IIoT

Source +
Binary

(2)

License

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

MQTT Client

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

94

STM32 – industrial protocols (4/8)

1/ Requires external hardware (netX52 or netX90).
2/ source for STM32, binary for external hardware.

Provider Solution name Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Hilscher

I-

CUBE-NETX +

PROFINET RT/IRT IO

-Device

(1)

Industrial real-

time Ethernet

Factory

automation

Source +

Binary

(2)

License

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

EtherCAT

Slave

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

Ethernet/IP Adapter

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

sercos

Slave

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

POWERLINK Controlled Node

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

Varan

Client

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

I-

CUBE-NETX +

Open ModbusTCP

(1)

N

3

N

3

N

3

N

3

N

3

N

3

Y Y N

3

N

3

N

3

N

3

N

3

95

STM32 – industrial protocols (5/8)

Provider

Solution

name

Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Kalycito

OPC UA

Factory automation

Open Source Free

N N N N N N

2

Y Y Y N N

N

2

N

2

Matrikon

OPC UA

Factory automation

Source /
Binaries

License

N N N Y N N

2

Y Y Y N N

N

2

N

2

MESCO

HART Slave

Process

automation

Source

Lic. + Royal.

Y Y Y Y Y N

2

Y

N

2

N

2

Y Y N

2

N

2

MicroControl

CANopen

Automation,

medical

Source License

Y Y Y Y Y Y Y Y Y N N Y

N

2

J1939

Commercial

vehicles

Source License

Y Y Y Y Y Y Y Y Y N N Y

N

2

EtherCAT

1

Factory automation

Source License

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

Y

1

PROFINET

Factory automation

Source License

N N Y Y N N Y Y Y N N N N

Micrium

µC/CAN

Factory

automation

Open Source

Free N N Y Y N N Y N N N N N N

µC/Modbus

Factory

automation

Open Source

Free Y Y Y Y Y N

2

Y Y Y Y Y Y N

2

1/ Requires external hardware.

2/ Please contact supplier.

96

STM32 – industrial protocols (6/8)

1/ Requires external hardware.

2/ Please contact supplier.

Provider Solution name Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

Mitsubishi

CC-Link IE TSN

Remote Station

SDK

Factory

automation

Source

License N N N N N N Y N N N N N N

Port

CANopen

Factory

automation

Source

License Y Y Y Y Y N

2

Y Y Y N N Y N

2

EtherCAT

1

Factory automation

Source

License Y Y Y Y Y N

2

Y Y Y N N Y N

2

PROFINET

Factory automation

Source

License N N N N N N Y Y Y N N N N

EtherNet/IP

1

Factory automation

Source

License N N N N N N Y Y Y N N N N

POWERLINK

1

Factory automation

Source

License N N N Y N N N N N N N N N

SEGGER

emModbus

Factory automation

Source License

Y Y Y Y Y Y Y Y Y Y Y Y Y

Systerel

S2OPC (OPC UA)

Factory automation

Open

Source

Free

N

2

N

2

N

2

Y N

2

N

2

N

2

Y Y N

2

N

2

N

2

N

2

97

STM32 – industrial protocols (7/8)

Provider

Solution

name

Application Model Cost

Availability

F0 G0 F1 F2 F3 G4 F4 F7 H7 L0 L1 L4/L4+ L5

TEConcept

IO-Link Device

Factory automation

Source License

Y Y Y Y Y Y Y Y Y Y Y Y Y

IO

-Link

Master

Factory automation

Source License

Y Y Y Y Y Y Y Y Y Y Y Y Y

TMGTE

IO-Link Device

Factory automation

Source License

Y Y Y Y Y Y Y Y Y Y Y Y Y

IO-Link Master

Factory automation

Source License

N N Y Y Y Y Y Y Y N N Y Y

Profibus DP

Factory automation

Source License

Y Y Y Y Y Y Y Y Y Y Y Y Y

Profinet

Factory automation

Source

License +

royalties

N N N Y N Y Y Y Y N N N N

Ethernet/IP

Factory automation

Source

License +

royalties

N N N Y N Y Y Y Y N N N N

Rowebots

UNISON

Modbus

Factory automation

Source License N N Y Y Y Y Y Y Y N Y

Y Y

98

STM8 – industrial protocols

Provider Solution name Application Model Cost

Availability

STM8S /

STM8AF

STM8L /

STM8AL

SEGGER

emModbus Factory automation Source License

Y Y

TEConcept

IO-Link Device Factory automation Source License

Y Y

TMGTE

IO-Link Device Factory automation Source License

Y Y

Back

99

• Control your 3-phase motor with top performance

• STM32 microcontrollers offer the performance of the industry-standard Arm® Cortex®-M cores running either Vector control or

FOC modes, widely used in high-performance drives for air conditioning, home appliances, drones, building and industrial
automation, medical and e-bike applications. STM32 MC SDK (motor control software development kit) firmware (X-CUBE­MCSDK and X-CUBE-MCSDK-FUL) includes the Permanent-magnet synchronous motor (PMSM) firmware library (FOC control)
and the STM32 Motor Control Workbench (to configure the FOC firmware library parameters), with its graphical user interface
(GUI). STM32 Motor Control Workbench is PC software that reduces the design effort and time needed for the STM32 PMSM
FOC firmware configuration. The user generates a project file through the GUI and initializes the library according to the
application needs. Some of the variables of the algorithm being used can be monitored and changed in real time.

Application field – motor control

Often-seen acronyms

BLDC Brushless DC: permanent magnet motor with trapezoidal shaped B-EMF, FOC applicable
PMSM Permanent magnet synchronous motor: with sinusoidal shaped B-EMF, FOC applicable
ACIM AC induction motor: type of motor, FOC applicable
FOC Field-oriented control: Mathematical technique used to achieve decoupled control of the flux and torque in a 3-phase motor.

HFI, MTPA

High Frequency Injection: algorithm for very low speed and fast acceleration (air con, fridge) and increased efficiency for low- or zero-speed, full
torque applications (washing machines, factory automation)

• “Maximum Torque Per Ampere” (MTPA): optimizes the motor torque for each load and increases the efficiency,

• “Feed Forward”: improves the current control at high speed.

100
