STE70NM50
N-CHANNEL 500V - 0.045Ω - 70A ISOTOP
Zener-Protected MDmesh™Power MOSFET
TYPE V
STE70NM50 500V < 0.05Ω 70 A
n
TYPICAL RDS(on) = 0.045Ω
n
HIGH dv/dt AND AVALANCHE CAPABILITIES
n
IMPROVED ESD CAPABILITY
n
LOW INPUT CAPACITANCE AND GATE
DSS
R
DS(on)
I
D
CHARGE
n
LOW GATE INPUT RESIST ANC E
n
TIGHT PROCESS CONTRO L
n
INDUSTRY’S LOWEST ON-RESISTANCE
DESCRIPTION
The MDmesh™
is a new revolutionary MOSFET
technology that associates the Multiple Drain process with the Company’s PowerMESH™ horizontal
layout. The resulting product has an outstanding low
on-resistance, impressively high dv/dt and excellent
avalanche characteristics. The adoption of the
Company’s proprietary strip technique yields overall
dynamic performance that is significantly better than
that of similar competition’s products.
APPLICATIONS
The MDmesh™ family is very suitable for increasing
power density of high voltage converters allowing
system miniaturization and higher efficiencies.
ISOTOP
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS
Symbol Parameter Value Unit
V
DS
V
DGR
V
GS
I
D
I
D
I
DM
P
TOT
V
ESD(G-S)
dv/dt (1) Peak Diode Recovery voltage slope 15 V/ns
T
stg
T
j
(•)Pu l se width limited by safe operating area
Drain-source Voltage (VGS = 0)
Drain-gate Voltage (RGS = 20 kΩ)
Gate- source Voltage ±30 V
Drain Current (continuous) at TC = 25°C
Drain Current (continuous) at TC = 100°C
(l)
Drain Current (pulsed) 280 A
Total Dissipation at TC = 25°C
Gate source ESD(HBM-C=100pF, R=15KΩ) 6KV
Derating Factor 5 W/°C
Storage Temperature –65 to 150 °C
Max. Operating Junction Temperature 150 °C
(1)ISD ≤60A, di/dt ≤400A/µs, VDD ≤ V
500 V
500 V
70 A
44 A
600 W
, Tj ≤ T
(BR)DSS
JMAX
1/8September 2002
STE70NM50
THERMA L D ATA
Rthj-case Thermal Resistance Junction-case Max 0.2 °C/W
Rthj-amb Thermal Resistance Junction-ambient Max 30 °C/W
T
l
AVALANCHE CHARACTERISTICS
Symbol Parameter Max Value Unit
I
AR
E
AS
Maximum Lead Temperature For Soldering Purpose 300 °C
Avalanche Current, Repetitive or Not-Repetitive
(pulse width limited by T
max)
j
Single Pulse Avalanche Energy
(starting T
= 25 °C, ID = IAR, VDD = 35 V)
j
30 A
1.4 J
ELECTRICAL CHARACTERISTICS (T
= 25 °C UNLESS OTHERWISE SPECIFIED)
CASE
OFF
Symbol Parameter Test Conditions Min. Typ. Max. Unit
V
(BR)DSS
Drain-source
ID = 250 µA, VGS = 0 500 V
Breakdown Voltage
ON
I
I
GSS
(1)
DSS
Zero Gate Voltage
Drain Current (V
GS
Gate-body Leakage
Current (V
DS
= 0)
= 0)
V
= Max Rating
DS
VDS = Max Rating, TC = 125 °C
V
= ± 20V ± 10 µA
GS
10 µA
100 µA
Symbol Parameter Test Conditions Min. Typ. Max. Unit
V
GS(th)
R
DS(on)
Gate Threshold Voltage
Static Drain-source On
V
= VGS, ID = 250µA
DS
VGS = 10V, ID = 30A
345V
0.045 0.05 Ω
Resistance
DYNAMIC
Symbol Parameter Test Conditions Min. Typ. Max. Unit
(1) Forward Transconductance VDS > I
g
fs
C
iss
C
oss
C
rss
Input Capacitance
Output Capacitance 980 pF
Reverse Transfer
I
D
V
Capacitance
R
G
Gate Input Resistance f=1 MHz Gate DC Bias = 0
Test Signal Level = 20mV
Open Drain
Note: 1. Pulsed: Pu l se duration = 300 µs, duty c ycle 1.5 %.
= 30A
DS
D(on)
x R
DS(on)max,
= 25V, f = 1 MHz, VGS = 0
35 S
7500 pF
200 pF
1.5 Ω
2/8
STE70NM50
ELECTRICAL CHARACTERISTICS (CONTINUED)
SWITCHING ON
Symbol Parameter Test Conditions Min. Typ. Max. Unit
V
t
d(on)
Q
Q
Q
t
r
g
gs
gd
Turn-on Delay Time
Rise Time 58 ns
Total Gate Charge
Gate-Source Charge 53 nC
Gate-Drain Charge 97 nC
SWITCHING OFF
Symbol Param eter Test Conditions Min. Typ. Max. Unit
t
r(Voff)
t
t
f
c
Off-voltage Rise Time
Fall Time 46 ns
Cross-over Time 108 ns
SOURCE DRAIN DIODE
Symbol Parameter Test Conditions Min. Typ. Max. Unit
I
SD
I
SDM
VSD (1)
t
rr
Q
rr
I
rrm
t
rr
Q
rr
I
rrm
Note: 1. Pulsed: Pulse duration = 300 µs, duty cycle 1.5 %.
2. Pulse width limi ted by safe operating area.
(2)
Source-drain Current 60 A
Source-drain Current (pulsed) 240 A
Forward On Voltage
Reverse Recovery Time
Reverse Recovery Charg e
Reverse Recovery Curren t
Reverse Recovery Time
Reverse Recovery Charg e
Reverse Recovery Curren t
= 250V, ID = 30A
DD
RG= 4.7Ω VGS = 10V
(see test circuit, Figure 3)
V
= 400V, ID = 60A,
DD
V
= 10V
GS
V
= 400V, ID = 60A,
DD
RG= 4.7Ω, V
GS
= 10V
(see test circuit, Figure 5)
ISD = 60A, VGS = 0
= 60A, di/dt = 100A/µs,
I
SD
V
= 100 V, Tj = 25°C
DD
(see test circuit, Figure 5)
= 60A, di/dt = 100A/µs,
I
SD
VDD = 100 V, Tj = 150°C
(see test circuit, Figure 5)
51 ns
190 266 nC
51 ns
1.5 V
532
9.9
37
636
13.4
42
ns
µC
A
ns
µC
A
GATE-SOURCE ZENER DIODE
Symbol Parameter Test Conditions Min. Typ. Max. Unit
BV
GSO
Gate-Source Breakdown
Igs=± 1mA (Open Drain) 30 V
Voltage
PROTECTION FEATURES OF GATE-TO-SOURCE ZENER DIODES
The built-in back-to-back Zener diodes have specificall y been des igned to enhan ce not only the device’s
ESD capability, but also to make them safely absorb possible voltage transients that may occasionally be
applied from gate to source. In this respect the 25V Zener voltage is appropriate to achieve an efficient
and cost-effective intervention to protect the device’s integrity. These integrated Zener diodes thus avoid
the usage of external components.
3/8
