ST STA308A User Manual

Multi-channel digital audio processor with DDX™

Features

! 8 channels of 24-bit DDX

! >100 dB SNR and dynamic range

! Selectable 32 kHz - 192 kHz input sample rates

! 6 channels of DSD/SACD input

! Digital gain/attenuation +58 dB to -100 dB in

0.5 dB steps

! Soft volume update

! Individual channel and master gain/attenuation

plus channel trim (-10 dB to +10 dB)

! Up to 10 independent 32-bit user

programmable biquads (EQ) per channel

! Bass/treble tone control

! Pre and post EQ full 8-channel input mix on all

8 channels

! Dual independent limiters/compressors

! Dynamic range compression or anti-clipping

modes

! AutoModes:

– 5-band graphic EQ
– 32 preset EQ curves (rock, jazz, pop, etc.)
– Automatic volume controlled loudness
– 5.1 to 2-channel downmix
– Simultaneous 5.1- and 2-channel downmix

outputs
– 3 preset volume curves
– 2 preset anti-clipping modes
– Preset movie nighttime listening mode
– Preset TV channel/commercial AGC mode
– 5.1, 2.1 bass management configurations
– AM frequency automatic output PWM

frequency shifting
– 8 preset crossover filters

! Individual channel and master soft/hard mute

! Automatic zero-detect and invalid input mute

! Automatic invalid input detect mute

®

STA308A

TQFP64

! Advanced PopFree operation

! Advanced AM interference frequency

switching and noise suppression modes

2

! I

S output channel mapping function

! Independent channel volume and DSP bypass

! Channel mapping of any input to any

processing/DDX

! DC blocking selectable high-pass filter

! Selectable per-channel DDX

or binary PWM output

! Max power correction for lower full-power THD

! Variable per channel DDX

! 192 kHz internal processing sample rate, 24-bit

to 36-bit precision

Description

The STA308A is a single chip solution for digital
audio processing and control in multi-channel
applications. It provides output capabilities for

®

DDX

(direct digital amplification). In conjunction
with a DDX
quality, high-efficiency, all digital amplification.
The device is extremely versatile, allowing for
input of most digital formats including 6.1/7.1­channel and 192 kHz, 24-bit DVD-audio,
DSD/SACD. In 5.1 application the additional 2
channels can be used for audio line-out or
headphone drive. In speaker mode, with 8
channel outputs in parallel, the STA308A can
deliver 1 W (maximum).

Table 1. Device summary

STA308A TQFP64

®

power device, it provides high-

Order code Package

®

channel

®

damped ternary

®

o

utput delay control

July 2007 Rev 4 1/63

www.st.com

63
