ST SPC560P34L1, SPC560P34L3, SPC560P40L1, SPC560P40L3 User Manual

SPC560P34L1, SPC560P34L3
SPC560P40L1, SPC560P40L3

32-bit Power Architecture® based MCU with 320 KB Flash memory

and 20 KB RAM for automotive chassis and safety applications

Features

■ Up to 64 MHz, single issue, 32-bit CPU core

complex (e200z0h)
– Compliant with Power Architecture

embedded category

– Variable Length Encoding (VLE)

■ Memory organization

– Up to 256 KB on-chip code flash memory

with ECC and erase/program controller

– Additional 64 (4 × 16) KB on-chip data

flash memory with ECC for EEPROM
emulation

– Up to 20 KB on-chip SRAM with ECC

■ Fail-safe protection

– Programmable watchdog timer
– Non-maskable interrupt
– Fault collection unit

■ Nexus Class 1 interface

■ Interrupts and events

– 16-channel eDMA controller
– 16 priority level controller
– Up to 25 external interrupts
– PIT implements four 32-bit timers
– 120 interrupts are routed via INTC

■ 1 general purpose eTimer unit

– 6 timers each with up/down capabilities
– 16-bit resolution, cascadable counters
– Quadrature decode with rotation direction

flag

– Double buffer input capture and output

compare

■ GPIO (37 on LQFP64; 64 on LQFP100)

individually programmable as I/O or special
function

■ Communications interfaces

– 2 LINFlex channels (1× Master/Slave, 1×

Master only)

®

LQFP100 (14 x 14 x 1.4 mm)

– Up to 3 DSPI channels with automatic chip

LQFP64 (10 x 10 x 1.4 mm

select generation (up to 8/4/4 chip selects)

– Up to 2 FlexCAN interface (2.0B Active)

with 32 message buffers

– 1 safety port based on FlexCAN with 32

message buffers and up to 8 Mbit/s at
64 MHz capability usable as second CAN
when not used as safety port

■ One 10-bit analog-to-digital converter (ADC)

– Up to 16 input channels (16 on LQFP100 /

12 on LQFP64)

– Conversion time < 1 µs including sampling

time at full precision
– Programmable Cross Triggering Unit (CTU)
– 4 analog watchdogs with interrupt

capability

■ On-chip CAN/UART bootstrap loader with Boot

Assist Module (BAM)

■ 1 FlexPWM unit: 8 complementary or

independent outputs with ADC synchronization
signals

Table 1. Device summary

Package

LQFP100 SPC560P34L3 SPC560P40L3

LQFP64 SPC560P34L1 SPC560P40L1

192 Kbyte

Code Flash

256 Kbyte

Code Flash

December 2011 Doc ID 16100 Rev 5 1/103

www.st.com
