FEATURES SUMMARY

■ 5 V±10% Single Supply Voltage:

■ Up to 4 Mbit of Primary Flash Memory (8

uniform sectors)

■ 256Kbit Secondary Flash Memory (4 uniform

sectors)

■ Up to 64 Kbit SRAM

■ Over 3,000 Gates of PLD: DPLD

■ 52 Reconfigurable I/O ports

■ Enhanced JTAG Serial Port

■ Programmable power management

■ High Endurance:

– 100,000 Erase/Write Cycles of Flash Memory – 1,000 Erase/Write Cycles of PLD

PSD935G2

Confi gurabl e Memory Syst em on a C hi p

for 8-Bit Microcontrollers

PRELIMINARY DATA

Figure 1. Packages

TQFP80 (U)

January 2002

This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice.

1/3

1.0 Introduction

PSD9XX Family

PSD935G2

Configurable Memory System on a Chip for 8-Bit Microcontrollers

The PSD9XX series of Programmable Microcontroller (MCU) Peripherals brings In-System-Programmability (ISP) to Flash memory and programmable logic. The result is a simple and flexible solution for embedded designs. PSD9XX devices combine many of the peripheral functions found in MCU based applications:

• 4 Mbit of Flash memory

• A secondary Flash memory for boot or data

• Over 3,000 gates of Flash programmable logic

• 64 Kbit SRAM

• Reconfigurable I/O ports

• Programmable power management.

PSD9XX Family PSD935G2

1.0 Introduction

(Cont.)

Please refer to the revision block at the end of this document for updated information.

The PSD935G2 device offers two methods to program PSD Flash memory while the PSD is soldered to a circuit board.

❏ In-System Programming (ISP) via JTAG

An IEEE 1149.1 compliant JTAG-ISP interface is included on the PSD enabling the entire device (both flash memories, the PLD, and all configuration) to be rapidly programmed while soldered to the circuit board. This requires no MCU participation, which means the PSD can be programmed anytime, even while completely blank.

The innovative JTAG interface to flash memories is an industry first, solving key problems faced by designers and manufacturing houses, such as:

• First time programming – How do I get firmware into the flash the very first time?

JTAG is the answer, program the PSD while blank with no MCU involvement.

• Inventory build-up of pre-programmed devices – How do I maintain an accurate

count of pre-programmed flash memory and PLD devices based on customer demand? How many and what version? JTAG is the answer, build your hardware with blank PSDs soldered directly to the board and then custom program just before they are shipped to customer. No more labels on chips and no more wasted inventory.

• Expensive sockets – How do I eliminate the need for expensive and unreliable

sockets? JTAG is the answer. Solder the PSD directly to the circuit board. Program first time and subsequent times with JTAG. No need to handle devices and bend the fragile leads.

❏ In-Application re-Programming (IAP)

Two independent flash memory arrays are included so the MCU can execute code from one memory while erasing and programming the other. Robust product firmware updates in the field are possible over any communication channel (CAN, Ethernet, UART, J1850, etc) using this unique architecture. Designers are relieved of these problems:

• Simultaneous read and write to flash memory – How can the MCU program the

same memory from which it is executing code? It cannot. The PSD allows the MCU to operate the two flash memories concurrently, reading code from one while erasing and programming the other during IAP.

• Complex memory mapping – How can I map these two memories efficiently?

A Programmable Decode PLD is embedded in the PSD. The concurrent PSD memories can be mapped anywhere in MCU address space, segment by segment with extremely high address resolution. As an option, the secondary flash memory can be swapped out of the system memory map when IAP is complete. A built-in page register breaks the MCU address limit.

• Separate program and data space – How can I write to flash memory while it

resides in “program” space during field firmware updates, my 80C51 won’t allow it The flash PSD provides means to “reclassify” flash memory as “data” space during IAP, then back to “program” space when complete.

PSDsoft – ST’s software development tool – guides you through the design process step-by-step making it possible to complete an embedded MCU design capable of ISP/IAP in just hours. Select your MCU and PSDsoft will take you through the remainder of the design with point and click entry, covering...PSD selection, pin definitions, programmable logic inputs and outputs, MCU memory map definition, ANSI C code generation for your MCU, and merging your MCU firmware with the PSD design. When complete, two different device programmers are supported directly from PSDsoft – FlashLINK (JTAG) and PSDpro.

The PSD935G2 is available in an 80-pin TQFP package.

PSD935G2 PSD9XX Family

❏ A simple interface to 8-bit microcontrollers that use either multiplexed or

non-multiplexed busses. The bus interface logic uses the control signals generated by the microcontroller automatically when the address is decoded and a read or write is performed. A partial list of the MCU families supported include:

• Intel 8031, 80196, 80188, 80C251

• Motorola 68HC11 and 68HC16

• Philips 8031 and 80C51XA

• Zilog Z80, Z8 and Z180

• Infineon C500 family

❏ 4 Mbit Flash memory. This is the main Flash memory. It is divided into eight

equal-sized blocks that can be accessed with user-specified addresses.

❏ Internal secondary 256 Kbit Flash boot memory. It is divided into four equal-sized

blocks that can be accessed with user-specified addresses. This secondary memory brings the ability to execute code and update the main Flash concurrently.

❏ 64 Kbit SRAM. The SRAM’s contents can be protected from a power failure by

connecting an external battery.

❏ General Purpose PLD (GPLD) with 24 outputs. The GPLD may be used to implement

external chip selects or combinatorial logic function.

❏ Decode PLD (DPLD) that decodes address for selection of internal memory blocks. ❏ 52 individually configurable I/O port pins that can be used for the following functions:

• MCU I/Os

• PLD I/Os

• Latched MCU address output

• Special function I/Os.

• I/O ports may be configured as open-drain outputs.

❏ Standby current as low as 50 µA for 5 V devices. ❏ Built-in JTAG compliant serial port allows full-chip In-System Programmability (ISP).

With it, you can program a blank device or reprogram a device in the factory or the field.

❏ Internal page register that can be used to expand the microcontroller address space

by a factor of 256.

❏ Internal programmable Power Management Unit (PMU) that supports a low power

mode called Power Down Mode. The PMU can automatically detect a lack of microcontroller activity and put the PSD9XX into Power Down Mode.

❏ Erase/Write cycles:

• Flash memory – 100,000 minimum

• PLD – 1,000 minimum

2.0 Key Features

3.0 PSD9XX Series

Part # Flash

Flash Main Boot

Serial ISP Memory Memory

PSD9XX I/O PLD Input Output PLD JTAG/ISP Kbit Kbit SRAM Supply

Series Device Pins Inputs Macrocells Macrocells Outputs Port 8 Sectors (4 Sectors) Kbit Voltage

PSD935G2 52 66 24 Yes 4096 256 64 5V

PSD9XX PSD913G2 27 57 19 Yes 1024 256 16 5V

PSD934F2 27 57 19 Yes 2048 256 64 5V

Table 1. PSD9XX Product Matrix

PSD9XX Family PSD935G2

PROG.

MCU BUS

INTRF.

ADIO

PORT

CNTL0,

CNTL1,

CNTL2

AD0 – AD15

PLD

INPUT

BUS

PROG.

PORT

PROG.

PORT

POWER

MANGMT

UNIT

4 MBIT MAIN FLASH

MEMORY

8 SECTORS

VSTDBY

PA0 – PA7

PROG.

PORT

PROG.

PORT

PROG.

PORT

PB0 – PB7

PROG.

PORT

PROG.

PORT

PF0 – PF7

PG0 – PG7

PE0 – PE7

PC0 – PC7

PD0 – PD3

ADDRESS/DATA/CONTROL BUS

256 KBIT SECONDARY

FLASH MEMORY

(BOOT OR DATA)

4 SECTORS

64 KBIT BATTERY

BACKUP SRAM

RUNTIME CONTROL

AND I/O REGISTERS

SRAM SELECT

GPLD OUTPUT

I/O PORT PLD INPUT

CSIOP

FLASH ISP PLD

(GPLD)

FLASH DECODE

PLD

(

DPLD

)

PLD, CONFIGURATION

& FLASH MEMORY

LOADER

JTAG

SERIAL

CHANNEL

(

PE6

)

PAGE

EMBEDDED

ALGORITHM

SECTOR

SELECTS

SECTOR

SELECTS

GLOBAL

CONFIG. &

SECURITY

Figure 1. PSD935G2 Block Diagram

*Additional address lines can be brought into PSD via Port A, B, C, D, or F.

PSD935G2 PSD9XX Family

PSD9XX devices contain several major functional blocks. Figure 1 on page 3 shows the architecture of the PSD9XX device family. The functions of each block are described briefly in the following sections. Many of the blocks perform multiple functions and are user configurable.

4.1 Memory

The PSD935G2 contains the following memories:

• 4 Mbit Flash

• A secondary 256 Kbit Flash memory for boot or data

• 64 Kbit SRAM.

Each of the memories is briefly discussed in the following paragraphs. A more detailed discussion can be found in section 9.

The 4 Mbit Flash is the main memory of the PSD935G2. It is divided into eight equally-sized sectors that are individually selectable.

The 256 Kbit secondary Flash memory is divided into four equally-sized sectors. Each sector is individually selectable.

The 64 Kbit SRAM is intended for use as a scratchpad memory or as an extension to the microcontroller SRAM. If an external battery is connected to the PSD9XX’s Vstby pin, data will be retained in the event of a power failure.

Each block of memory can be located in a different address space as defined by the user. The access times for all memory types includes the address latching and DPLD decoding time.

4.2 PLDs

The device contains two PLD blocks, each optimized for a different function, as shown in Table 2. The functional partitioning of the PLDs reduces power consumption, optimizes cost/performance, and eases design entry.

The Decode PLD (DPLD) is used to decode addresses and generate chip selects for the PSD935G2 internal memory and registers. The General Purpose PLD (GPLD) can implement user-defined external chip selects and logic functions. The PLDs receive their inputs from the PLD Input Bus and are differentiated by their output destinations, number of Product Terms.

The PLDs consume minimal power by using Zero-Power design techniques. The speed and power consumption of the PLD is controlled by the Turbo Bit in the PMMR0 register and other bits in the PMMR2 registers. These registers are set by the microcontroller at runtime. There is a slight penalty to PLD propagation time when invoking the non-Turbo bit.

4.3 I/O Ports

The PSD935G2 has 52 I/O pins divided among seven ports (Port A, B, C, D, E, F and G). Each I/O pin can be individually configured for different functions. Ports can be configured as standard MCU I/O ports, PLD I/O, or latched address outputs for microcontrollers using multiplexed address/data busses.

The JTAG pins can be enabled on Port E for In-System Programming (ISP). Ports F and G can also be configured as a data port for a non-multiplexed bus.

4.4 Microcontroller Bus Interface

The PSD935G2 easily interfaces with most 8-bit microcontrollers that have either multiplexed or non-multiplexed address/data busses. The device is configured to respond to the microcontroller’s control signals, which are also used as inputs to the PLDs. Section

9.3.5 contains microcontroller interface examples.

4.0 PSD9XX Architectural Overview

Name Abbreviation Inputs Outputs Product Terms

Decode PLD DPLD 66 15 40 General PLD GPLD 66 24 136

Table 2. PLD I/O Table

PSD9XX Architectural Overview

(cont.)

4.5 ISP via JTAG Port

In-System Programming can be performed through the JTAG pins on Port E. This serial interface allows complete programming of the entire PSD935G2 device. A blank device can be completely programmed. The JTAG signals (TMS, TCK, TSTAT, TERR, TDI, TDO) can be multiplexed with other functions on Port E. Table 3 indicates the JTAG signals pin assignments.

4.6 In-System Programming (ISP)

Using the JTAG signals on Port E, the entire PSD935G2 (memory, logic, configuration) device can be programmed or erased without the use of the microcontroller.

Port E Pins JTAG Signal

PE0 TMS PE1 TCK PE2 TDI PE3 TDO PE4 TSTAT PE5 TERR

Table 3. JTAG Signals on Port E

PSD9XX Family PSD935G2

4.7 In-Application re-Programming (IAP)

The main Flash memory can also be programmed in-system by the microcontroller executing the programming algorithms out of the secondary Flash memory, or SRAM. Since this is a sizable separate block, the application can also continue to operate. The secondary Flash boot memory can be programmed the same way by executing out of the main Flash memory. Table 4 indicates which programming methods can program different functional blocks of the PSD9XX.

Device

Functional Block JTAG-ISP Programmer IAP

Main Flash memory Yes Yes Yes Flash Boot memory Yes Yes Yes PLD Array (DPLD and GPLD) Yes Yes No PSD Configuration Yes Yes No

Table 4. Methods of Programming Different Functional Blocks of the PSD935G2

4.8 Page Register

The eight-bit Page Register expands the address range of the microcontroller by up to 256 times.The paged address can be used as part of the address space to access external memory and peripherals or internal memory and I/O. The Page Register can also be used to change the address mapping of blocks of Flash memory into different memory spaces for IAP.

4.9 Power Management Unit

The Power Management Unit (PMU) in the PSD935G2 gives the user control of the power consumption on selected functional blocks based on system requirements. The PMU includes an Automatic Power Down unit (APD) that will turn off device functions due to microcontroller inactivity. The APD unit has a Power Down Mode that helps reduce power consumption.

The PSD935G2 also has some bits that are configured at run-time by the MCU to reduce power consumption of the GPLD. The turbo bit in the PMMR0 register can be turned off and the GPLD will latch its outputs and go to standby until the next transition on its inputs. Additionally, bits in the PMMR2 register can be set by the MCU to block signals from entering the GPLD to reduce power consumption. See section 9.5.

PSD935G2 PSD9XX Family

Merge MCU Firmware

with PSD Configuration

PSD Programmer

*.OBJ FILE

Define PSD Pin and

Node functions

Point and click definition of

PSD pin functions, internal nodes,

and MCU system memory map.

Choose MCU and PSD

Automatically Configures MCU

bus interface and other PSD

attributes.

PSDPro or

FlashLink (JTAG)

A composite object file is created

containing MCU firmware and

PSD configuration.

C Code Generation

Generate C Code

Specific to PSD

Functions

User's choice of

Microcontroller

Compiler/Linker

*.OBJ file

available

for 3rd party

programmers

(Conventional or JTAG-ISP)

MCU Firmware

Hex or S-Record

format

Figure 2. PSDsoft Development Tool

5.0 Development System

The PSD9XX series is supported by PSDsoft a Windows-based (95, 98, NT) software development tool. A PSD design is quickly and easily produced in a point and click environment. The designer does not need to enter Hardware Definition Language (HDL) equations (unless desired) to define PSD pin functions and memory map information. The general design flow is shown in Figure 2 below. PSDsoft is available from our web site (www.st.com/psm) or other distribution channels.

PSDsoft directly supports two low cost device programmers from ST. PSDpro and FlashLINK (JTAG). Both of these programmers may be purchased through your local rep/distributor, or directly from our web site using a credit card. The PSD9XX is also supported by third party device programmers, see web site for current list.

PSD9XX Family PSD935G2

The following table describes the pin names and pin functions of the PSD935G2. Pins that have multiple names and/or functions are defined using PSD Configuration.

6.0 Table 5. PSD935G2 Pin Descriptions

Pin*

(TQFP

Pin Name Pkg.) Type Description

ADIO0-7 3-7 I/O This is the lower Address/Data port. Connect your MCU

10-12 address or address/data bus according to the following rules:

1. If your MCU has a multiplexed address/data bus where the data is multiplexed with the lower address bits, connect AD[0:7] to this port.

2. If your MCU does not have a multiplexed address/data bus, connect A[0:7] to this port.

3. If you are using an 80C51XA in burst mode, connect A4/D0 through A11/D7 to this port.

ALE or AS latches the address. The PSD drives data out only if the read signal is active and one of the PSD functional blocks was selected. The addresses on this port are passed to the PLDs.

ADIO8-15 13-20 I/O This is the upper Address/Data port. Connect your MCU

address or address/data bus according to the following rules:

1. If your MCU has a multiplexed address/data bus where the data is multiplexed with the lower address bits, connect A[8:15 ] to this port.

2. If your MCU does not have a multiplexed address/data bus, connect A[8:15 ] to this port.

3. If you are using an 80C251 in page mode, connect AD[8:15] to this port

4. If you are using an 80C51XA in burst mode, connect A[12:19] to this port.

ALE or AS latches the address. The PSD drives data out only if the read signal is active and one of the PSD functional blocks was selected. The addresses on this port are passed to the PLDs.

CNTL0 59 I The following control signals can be connected to this port,

based on your MCU:

1. WR — active-low write input.

2. R_W — active-high read/active low write input.

This pin is connected to the PLDs. Therefore, these signals can be used in decode and other logic equations.

CNTL1 60 I The following control signals can be connected to this port,

based on your MCU:

1. RD — active-low read input.

2. E — E clock input.

3. DS — active-low data strobe input.

4. PSEN — connect PSEN to this port when it is being used as an active-low read signal. For example, when the 80C251 outputs more than 16 address bits, PSEN is actually the read signal.

This pin is connected to the PLDs. Therefore, these signals can be used in decode and other logic equations.

CNTL2 40 I This pin can be used to input the PSEN (Program Select

Enable) signal from any MCU that uses this signal for code exclusively. If your MCU does not output a Program Select Enable signal, this port can be used as a generic input. This port is connected to the PLD as input.

Reset 39 I Active low input. Resets I/O Ports, PLD Micro

⇔Cells, some of the configuration registers and JTAG registers. Must be active at power up. Reset also aborts the Flash programming/erase cycle that is in progress.

PSD935G2 PSD9XX Family

Pin*

(TQFP

Pin Name Pkg.) Type Description

PA0-PA7 51-58 I/O Port A, PA0-7. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port

Drain 2. GPLD output.

3. Input to the PLD.

PB0-PB7 61-68 I/O Port B, PB0-7. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. GPLD output.

3. Input to the PLD.

PC0-PC7 41-48 I/O Port C, PC0-7. This port is pin configurable and has multiple

CMOS functions:

or Slew 1. MCU I/O — standard output or input port.

Rate 2. External chip select (ECS0-7) output.

3. Input to the PLD.

PD0 79 I/O Port D pin PD0 can be configured as:

CMOS 1. ALE or AS input — latches addresses on ADIO0-15 pins

or Open 2. AS input — latches addresses on ADIO0-15 pins on the

Drain rising edge.

3. Input to the PLD.

4. Transparent PLD input.

PD1 80 I/O Port D pin PD1 can be configured as:

CMOS 1. MCU I/O

or Open 2. Input to the PLD.

Drain 3. CLKIN clock input — clock input to the GPLD

Micro⇔Cells, the APD power down counter and GPLD AND Array.

PD2 1 I/O Port D pin PD2 can be configured as:

CMOS 1. MCU I/O

or Open 2. Input to the PLD.

Drain 3. CSI input — chip select input. When low, the CSI enables

the internal PSD memories and I/O. When high, the internal memories are disabled to conserve power. CSI trailing edge can get the part out of power-down mode.

PD3 2 I/O

Port D pin PD3 can be configured as:

CMOS

1. MCU I/O

or Open

2. Input to the PLD.

Drain

PE0 71 I/O Port E, PE0. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TMS input for JTAG/ISP interface.

PE1 72 I/O Port E, PE1. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TCK input for JTAG/ISP interface (Schmidt Trigger).

PE2 73 I/O Port E, PE2. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TDI input for JTAG/ISP interface.

Table 5. PSD935G2 Pin Descriptions

(cont.)

PSD9XX Family PSD935G2

Pin*

(TQFP

Pin Name Pkg.) Type Description

PE3 74 I/O Port E, PE3. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TDO output for JTAG/ISP interface.

PE4 75 I/O Port E, PE4. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TSTAT output for the ISP interface.

4. Rdy/Bsy — for in-circuit Parallel Programming.

PE5 76 I/O Port E, PE5. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. TERR active low output for ISP interface.

PE6 77 I/O Port E, PE6. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. Vstby — SRAM standby voltage input for battery

backup SRAM

PE7 78 I/O Port E, PE7. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address output.

3. Vbaton — battery backup indicator output. Goes high when

power is drawn from an external battery.

PF0-PF7 31-38 I/O Port F, PF0-7. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Input to the PLD.

3. Latched address outputs.

4. As address A0-3 inputs in 80C51XA mode

5. As data bus port (D0-7) in non-multiplexed bus configuration

PG0-PG7 21-28 I/O Port G, PG0-7. This port is pin configurable and has multiple

CMOS functions:

or Open 1. MCU I/O — standard output or input port.

Drain 2. Latched address outputs.

GND 8,30,

49,50,

9,29,

Table 5. PSD935G2 Pin Descriptions

(cont.)

PSD935G2 PSD9XX Family

Table 6 shows the offset addresses to the PSD935G2 registers relative to the CSIOP base address. The CSIOP space is the 256 bytes of address that is allocated by the user to the internal PSD935G2 registers. Table 6 provides brief descriptions of the registers in CSIOP space. For a more detailed description, refer to section 9.

7.0 PSD935G2 Register Description and Address Offset

Data In 00 01 10 11 30 40 41

Reads Port pin as input, MCU I/O input mode

Control 32 42 43

Selects mode between MCU I/O or Address Out

Stores data for output

Data Out 04 05 14 15 34 44 45 to Port pins, MCU I/O

output mode

Direction 06 07 16 17 36 46 47

Configures Port pin as input or output

Configures Port pins as either CMOS or Open

Drive Select 08 09 18 19 38 49 Drain on some pins, while

selecting high slew rate on other pins.

Flash Protection

C0 Read only – Flash Sector

Protection

Flash Boot

Read only – PSD Security

Protection

C2 and Flash Boot Sector

Protection

PMMR0 B0

Power Management Register 0

PMMR2 B4

Power Management Register 2

Page E0 Page Register

Places PSD memory

VM E2

areas in Program and/or Data space on an individual basis.

Memory_ID0 F0

Read only – Flash and SRAM size

Memory_ID1 F1

Read only – Boot type and size

Table 6. Register Address Offset

PSD9XX Family PSD935G2

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Data In Registers – Port A, B, C, D, E, F and G

8.0 Register Bit Definition

All the registers in the PSD935G2 are included here for reference. Detail description of the registers are found in the Functional Block section of the Data Sheet.

Bit definitions:

Read only registers, read Port pin status when Port is in MCU I/O input Mode.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Data Out Registers – Port A, B, C, D, E, F and G

Bit definitions:

Latched data for output to Port pin when pin is configured in MCU I/O output mode.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Direction Registers – Port A, B, C, D, E, F and G

Bit definitions:

Set Register Bit to 0 = configure corresponding Port pin in Input mode (default). Set Register Bit to 1 = configure corresponding Port pin in Output mode.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Control Registers – Ports E, F and G

Bit definitions:

Set Register Bit to 0 = configure corresponding Port pin in MCU I/O mode (default). Set Register Bit to 1 = configure corresponding Port pin in Latched Address Out mode.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Drive Registers – Ports A, B, D, E, and G

Bit definitions:

Set Register Bit to 0 = configure corresponding Port pin in CMOS output driver (default). Set Register Bit to 1 = configure corresponding Port pin in Open Drain output driver.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port Pin 7 Port Pin 6 Port Pin 5 Port Pin 4 Port Pin 3 Port Pin 2 Port Pin 1 Port Pin 0

Drive Registers – Ports C and F

Bit definitions:

Set Register Bit to 0 = configure corresponding Port pin as CMOS output driver (default). Set Register Bit to 1 = configure corresponding Port pin in Slew Rate mode.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Sec7_Prot Sec6_Prot Sec5_Prot Sec4_Prot Sec3_Prot Sec2_Prot Sec1_Prot Sec0_Prot

Flash Protection Register

Bit definitions: Read Only Register

Sec_Prot 1 = Flash Sector is write protected. Sec_Prot 0 = Flash Sector is not write protected.

PSD935G2 PSD9XX Family

8.0 Register Bit Definition

(cont.)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Security_Bit

***

Sec3_Prot Sec2_Prot Sec1_Prot Sec0_Prot

Flash Boot Protection Register

Bit definitions:

Sec_Prot 1 = Boot Block Sector is write protected. Sec_Prot 0 = Boot Block Sector is not write protected.

Security_Bit 0 = Security Bit in device has not been set.

1 = Security Bit in device has been set.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Pgr7 Pgr6 Pgr5 Pgr4 Pgr3 Pgr2 Pgr1 Pgr0

Page Register

Bit definitions:

Configure Page input to PLD. Default Pgr[7:0] = 00.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PLD PLD PLD

APD

Mcells clk array-clk Turbo enable

PMMR0 Register

Bit definitions: (default is 0)

Bit 1 0 = Automatic Power Down (APD) is disabled.

1 = Automatic Power Down (APD) is enabled.

Bit 3 0 = PLD Turbo is on.

1 = PLD Turbo is off, saving power.

Bit 4 0 = CLKIN input to the PLD AND array is connected.

Every CLKIN change will power up the PLD when Turbo bit is off.

1 = CLKIN input to PLD AND array is disconnected, saving power.

Bit 5 0 = CLKIN input to the PLD Micro⇔Cells is connected.

1 = CLKIN input to the PLD Micro ⇔Cells is disconnected, saving power.

*Not used bit should be set to zero.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PLD PLD PLD PLD PLD

PLD

array DBE array Ale array Cntl2 array Cntl1 array Cntl0 array addr

PMMR2 Register

Bit definitions (defauld is 0):

Bit 0 0 = Address A[7:0] are connected into the PLD array.

1 = Address A[7:0] are blocked from the PLD array, saving power.

Note: in XA mode, A3-0 come from PF3-0 and A7-4 come from ADIO7-4.

Bit 2 0 = Cntl0 input to the PLD AND array is connected.

1 = Cntl0 input to the PLD AND array is disconnected, saving power.

Bit 3 0 = Cntl1 input to the PLD AND array is connected.

1 = Cntl1 input to the PLD AND array is disconnected, saving power.

Bit 4 0 = Cntl2 input to the PLD AND array is connected.

1 = Cntl2 input to the PLD AND array is disconnected, saving power.

Bit 5 0 = Ale input to the PLD AND array is connected.

1 = Ale input to the PLD AND array is disconnected, saving power.

Bit 6 0 = DBE input to the PLD AND array is connected.

1 = DBE input to the PLD AND array is disconnected, saving power.

*Not used bit should be set to zero.

PSD9XX Family PSD935G2

8.0 Register Bit Definition

(cont.)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

***

FL_data Boot_data FL_code Boot_code SR_code

VM Register

Bit definitions:

Bit 0 0 = PSEN can’t access SRAM in 80C51XA modes.

1 = PSEN can access SRAM in 80C51XA modes.

Bit 1 0 = PSEN can’t access Boot in 80C51XA modes.

1 = PSEN can access Boot in 80C51XA modes.

Bit 2 0 = PSEN can’t access main Flash in 80C51XA modes.

1 = PSEN can access main Flash in 80C51XA modes.

Bit 3 0 = RD can’t access Boot in 80C51XA modes.

1 = RD can access Boot in 80C51XA modes.

Bit 4 0 = RD can’t access main Flash in 80C51XA modes.

1 = RD can access main Flash in 80C51XA modes.

Note: Upon reset, Bit1-Bit4 are loaded to configurations selected by the user in PSDsoft. Bit 0 is always cleared

by reset. Bit 0 to Bit 4 are active only when the device is configured in Philips 80C51XA mode. Not used bit should be set to zero.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

S_size 3 S_size 2 S_size 1 S_size 0 F_size 3 F_size 2 F_size 1 F_size 0

Memory_ID0 Register

Bit definitions:

F_size[3:0] = 4h, main Flash size is 2M bit. F_size[3:0] = 5h, main Flash size is 8M bit. S_size[3:0] = 0h, SRAM size is 0K bit. S_size[3:0] = 1h, SRAM size is 16K bit. S_size[3:0] = 3h, SRAM size is 64K bit.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

B_type 1 B_type 0 B_size 3 B_size 2 B_size 1 B_size 0

Memory_ID1 Register

Bit definitions:

B_size[3:0] = 0h, Boot block size is 0K bit. B_size[3:0] = 2h, Boot block size is 256K bit. B_type[1:0] = 0h, Boot block is Flash memory.

*Not used bit should be set to zero.

PSD935G2 PSD9XX Family

9.0 The PSD935G2 Functional Blocks

As shown in Figure 1, the PSD935G2 consists of six major types of functional blocks:

❏ Memory Blocks ❏ PLD Blocks ❏ Bus Interface ❏ I/O Ports ❏ Power Management Unit ❏ JTAG-ISP Interface

The functions of each block are described in the following sections. Many of the blocks perform multiple functions, and are user configurable.

9.1 Memory Blocks

The PSD935G2 has the following memory blocks:

• The main Flash memory

• Secondary Flash memory

• SRAM.

The memory select signals for these blocks originate from the Decode PLD (DPLD) and are user-defined in PSDsoft.

Table 7 summarizes which versions of the PSD935G2 contain which memory blocks.

Main Flash Secondary Flash

Device Flash Size Sector Size Block Size Sector Size SRAM

PSD935G2 512KB 64KB 32KB 8KB 8KB

Table 7. Memor y Blocks

9.1.1 Main Flash and Secondary Flash Memory Description

The main Flash memory block is divided evenly into eight sectors. The secondary Flash memory is divided into four sectors of eight Kbytes each. Each sector of either memory can be separately protected from program and erase operations.

Flash memory may be erased on a sector-by-sector basis and programmed word-by-word. Flash sector erasure may be suspended while data is read from other sectors of memory and then resumed after reading.

During a program or erase of Flash, the status can be output on the Rdy/Bsy pin of Port PE4. This pin is set up using PSDsoft.

9.1.1.1 Memory Block Selects

The decode PLD in the PSD935G2 generates the chip selects for all the internal memory blocks (refer to the PLD section). Each of the eight Flash memory sectors have a Flash Select signal (FS0 -FS7) which can contain up to three product terms. Each of the four Secondary Flash memory sectors have a Select signal (CSBOOT0-3) which can contain up to three product terms. Having three product terms for each sector select signal allows a given sector to be mapped in different areas of system memory. When using a microcontroller (80C51) with separate Program and Data space, these flexible select signals allow dynamic re-mapping of sectors from one space to the other before and after IAP.

PSD9XX Family PSD935G2

9.1.1.2 Upper and Lower Block IN MAIN FLASH SECTOR

The PSD935G2’s main Flash has eight 64K bytes sector. The 64K byte sector size may cause some difficulty in code mapping for an 8-bit MCU with only 64K byte address space. To resolve this mapping issue, the PSD935G2 provides additional logic (Figure 3) for the user to split the 8 sectors such that each sector has a lower and upper 32K byte block, and the two blocks can reside in different pages but in the same address range.

If your design works with 64KB sectors, you don’t need to configure this logic. If the design requires 32KB blocks in each sector, you need to define a “FA15” PLD equation in PSDsoft as the A15 address input to the main Flash module. FA15 consists of 3 product terms and will control whether the MCU is accessing the lower or upper 32KB in the selected sector. Below is an example for Flash sector chip select FS0. A typical equation is FA15 = pgr4 of the Page Register. When pgr4 is 0 (page 00), the lower 32KB is selected. When Pgr4 is switched to 1 by the user, the upper 32KB is selected. PSDsoft will automatically generate the PLD equations shown, based on your point and click selections.

page = [pgr7...pgr0]; “Page Register output

“Sector Chip Select Equation

FS0 = ((0000h <= address <= 7FFFh) & page = 00h) # “select first 32KB block

((0000h <= address <= 7FFFh) & page = 10h); “select second 32KB block

FA15 = pgr4; “as address A15 input to the main Flash

If no FA15 equation is defined in PSDsoft, the A15 that comes from the MCU address bus will be routed as input to the main Flash instead of FA15. The FA15 equation has no impact in the Sector Erase operation. Note: FA15 affects all eight sectors of the main Flash simultaneously, you cannot direct FA15 to a particular Flash sector only.

9.1.1.3 The Ready/Busy Pin (PE4)

Pin PE4 can be used to output the Ready/Busy status of the PSD935G2. The output on the pin will be a ‘0’ (Busy) when Flash memory blocks are being written to, or when the Flash memory block is being erased. The output will be a ‘1’ (Ready) when no write or erase operation is in progress.

The PSD935G2 Functional Blocks

(cont.)

DPLD

ARRAY

FA15

A15

* Set by PSDsoft

FLASH CHIP SELECTS FS0-7

MUX

NVM CONTROL BIT

MAIN

FLASH

SECTOR

ADDR A15

A [14:0]

Figure 3. Selecting the Upper or Lower Block in a Main Flash Sector

PSD935G2 PSD9XX Family

9.1.1.4 Memory Operation

The main Flash and secondary Flash memories are addressed through the microcontroller interface on the PSD935G2 device. The microcontroller can access these memories in one of two ways:

❏ The microcontroller can execute a typical bus write or read operation just as it would

if accessing a RAM or ROM device using standard bus cycles.

❏ The microcontroller can execute a specific instruction that consists of several write

and read operations. This involves writing specific data patterns to special addresses within the Flash to invoke an embedded algorithm. These instructions are summarized in Table 8.

Typically, Flash memory can be read by the microcontroller using read operations, just as it would read a ROM device. However, Flash memory can only be erased and programmed with specific instructions. For example, the microcontroller cannot write a single byte directly to Flash memory as one would write a byte to RAM. To program a byte into Flash memory, the microcontroller must execute a program instruction sequence, then test the status of the programming event. This status test is achieved by a read operation or polling the Rdy/Busy pin (PE4).

The Flash memory can also be read by using special instructions to retrieve particular Flash device information (sector protect status and ID).

9.1.1.4.1 Instructions

An instruction is defined as a sequence of specific operations. Each received byte is sequentially decoded by the PSD and not executed as a standard write operation. The instruction is executed when the correct number of bytes are properly received and the time between two consecutive bytes is shorter than the time-out value. Some instructions are structured to include read operations after the initial write operations.

The sequencing of any instruction must be followed exactly. Any invalid combination of instruction bytes or time-out between two consecutive bytes while addressing Flash memory will reset the device logic into a read array mode (Flash memory reads like a ROM device).

The PSD935G2 main Flash and secondary Flash support these instructions (see Table 8):

❏ Erase memory by chip or sector ❏ Suspend or resume sector erase ❏ Program a byte ❏ Reset to read array mode ❏ Read Main Flash Identifier value ❏ Read sector protection status ❏ Bypass Instruction

These instructions are detailed in Table 8. For efficient decoding of the instructions, the first two bytes of an instruction are the coded cycles and are followed by a command byte or confirmation byte. The coded cycles consist of writing the data AAh to address X555h during the first cycle and data 55h to address XAAAh during the second cycle (unless the Bypass Instruction feature is used. See 9.1.1.7). Address lines A15-A12 are don’t care during the instruction write cycles. However, the appropriate sector select signal (FSi or CSBOOTi) must be selected.

The main Flash and the secondary Flash Block have the same set of instructions (except Read main Flash ID). The chip selects of the Flash memory will determine which Flash will receive and execute the instruction. The main Flash is selected if any one of the FS0-7 is active, and the secondary Flash Block is selected if any one of the CSBOOT0-3 is active.

The PSD935G2 Functional Blocks

(cont.)

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

FS0-7

Instruction CSBOOT0-3 Cycle 1 Cycle 2 Cycle 3 Cycle 4 Cycle5 Cycle 6 Cycle 7

Read (Note 5) 1 “Read”

RA RD

Read Main Flash ID 1 AAh 55h 90h “Read” (Notes 6,13) @555h @AAAh @555h ID

@x01h

Read Sector Protection 1 AAh 55h 90h “Read” (Notes 6,8,13) @555h @AAAh @555h 00h or 01h

@x02h

Program a Flash Byte 1 AAh 55h A0h PD@PA

@555h @AAAh @555h

Erase One Flash Sector 1 AAh 55h 80h AAh 55h 30h 30h

@555h @AAAh @555h @555h @AAAh @SA @next SA

(Note 7)

Erase Flash Block 1 AAh 55h 80h AAh 55h 10h (Bulk Erase) @555h @AAAh @555h @555h @AAAh @555h

Suspend Sector Erase 1 B0h (Note 11) @xxxh

Resume Sector Erase 1 30h (Note 12) @xxxh

Reset (Note 6) 1 F0 @ any

address

Unlock Bypass 1 AAh 55h 20h

@555h @AAAh @555h

Unlock Bypass Program 1 A0h PD@PA (Note 9) @xxxh

Unlock Bypass Reset 1 90h 00h (Note 10) @xxxh @xxxh

Table 9. Instructions

X = Don’t Care. RA = Address of the memory location to be read. RD = Data read from location RA during read operation. PA = Address of the memory location to be programmed. Addresses are latched on the falling edge of the WR#

(CNTL0) pulse. PD = Data to be programmed at location PA. Data is latched o the rising edge of WR# (CNTL0) pulse. SA = Address of the sector to be erased or verified. The chip select (FS0-7 or CSBOOT0-3) of the sector to be

erased must be active (high).

NOTES:

1. All bus cycles are write bus cycle except the ones with the “read” label.

2. All values are in hexadecimal.

3. FS0-7 and CSBOOT0-3 are active high and are defined in PSDsoft.

4. Only Address bits A11-A0 are used in Instruction decoding. A15-12 (or A16-A12) are don’t care.

5. No unlock or command cycles required when device is in read mode.

6. The Reset command is required to return to the read mode after reading the Flash ID, Sector Protect status

or if DQ5 (error flag) goes high.

7. Additional sectors to be erased must be entered within 80µs.

8. The data is 00h for an unprotected sector and 01h for a protected sector. In the fourth cycle, the sector chip

select is active and (A1 = 1, A0 = 0).

9. The Unlock Bypass command is required prior to the Unlock Bypass Program command.

10. The Unlock Bypass Reset command is required to return to reading array data when the device is in the

Unlock Bypass mode.

11. The system may read and program functions in non-erasing sectors, read the Flash ID or read the Sector

Protect status, when in the Erase Suspend mode. The erase Suspend command is valid only during a sector erase operation.

12. The Erase Resume command is valid only during the Erase Suspend mode.

13. The MCU cannot invoke these instructions while executing code from the same Flash memory for which the

instruction is intended. The MCU must fetch, for example, codes from the secondary block when reading the Sector Protection Status of the main Flash.

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.1.1.5 Power-Up Condition

The PSD935G2 internal logic is reset upon power-up to the read array mode. The FSi and CSBOOTi select signals, along with the write strobe signal, must be in the false state during power-up for maximum security of the data contents and to remove the possibility of data being written on the first edge of a write strobe signal. Any write cycle initiation is locked when VCCis below VLKO.

9.1.1.6 Read

Under typical conditions, the microcontroller may read the Flash, or secondary Flash memories using read operations just as it would a ROM or RAM device. Alternately, the microcontoller may use read operations to obtain status information about a program or erase operation in progress. Lastly, the microcontroller may use instructions to read special data from these memories. The following sections describe these read functions.

9.1.1.6.1 Read the Contents of Memory

Main Flash and secodary Flash memories are placed in the read array mode after power-up, chip reset, or a Reset Flash instruction (see Table 8). The microcontroller can read the memory contents of main Flash or secondary Flash by using read operations any time the read operation is not part of an instruction sequence.

9.1.1.6.2 Read the Main Flash Memory Identifier

The main Flash memory identifier is read with an instruction composed of 4 operations: 3 specific write operations and a read operation (see Table 8). The PSD935G2 main Flash memory ID is E8h.

9.1.1.6.3 Read the Flash Memory Sector Protection Status

The Flash memory sector protection status is read with an instruction composed of 4 operations: 3 specific write operations and a read operation (see Table 8). The read operation will produce 01h if the Flash sector is protected, or 00h if the sector is not protected.

The sector protection status for all NVM blocks (main Flash or secondary Flash) can also be read by the microcontroller accessing the Flash Protection and Flash Boot Protection registers in PSD I/O space. See section 9.1.1.9.1 for register definitions.

9.1.1.6.4 Read the Erase/Program Status Bits

The PSD935G2 provides several status bits to be used by the microcontroller to confirm the completion of an erase or programming instruction of Flash memory. These status bits minimize the time that the microcontroller spends performing these tasks and are defined in Table 9. The status bits can be read as many times as needed.

FSi/

CSBOOTi DQ7 DQ6 DQ5 DQ4 DQ3 DQ2 DQ1 DQ0

Data Toggle Error

Erase

Flash V

Polling Flag Flag

X Time- X X X

out

Table 9. Status Bits

NOTES: 1. X = Not guaranteed value, can be read either 1 or 0.

2. DQ7-DQ0 represent the Data Bus bits, D7-D0.

3. FSi/CSBOOTi are active high.

For Flash memory, the microcontroller can perform a read operation to obtain these status bits while an erase or program instruction is being executed by the embedded algorithm. See section 9.1.1.7 for details.

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.1.1.6.5 Data Polling Flag DQ7

When Erasing or Programming the Flash memory bit DQ7 outputs the complement of the bit being entered for Programming/Writing on DQ7. Once the Program instruction or the Write operation is completed, the true logic value is read on DQ7 (in a Read operation). Flash memory specific features:

❏ Data Polling is effective after the fourth Write pulse (for programming) or after the

sixth Write pulse (for Erase). It must be performed at the address being programmed or at an address within the Flash sector being erased.

❏ During an Erase instruction, DQ7 outputs a ‘0’. After completion of the instruction,

DQ7 will output the last bit programmed (it is a ‘1’ after erasing).

❏ If the location to be programmed is in a protected Flash sector, the instruction is

ignored.

❏ If all the Flash sectors to be erased are protected, DQ7 will be set to ‘0’ for

about 100 µs, and then return to the previous addressed location. No erasure will be performed.

9.1.1.6.6 Toggle Flag DQ6

The PSD935G2 offers another way for determining when the Flash memory Program instruction is completed. During the internal Write operation and when either the FSi or CSBOOTi is true, the DQ6 will toggle from ‘0’ to ‘1’ and ‘1’ to ‘0’ on subsequent attempts to read any byte of the memory.

When the internal cycle is complete, the toggling will stop and the data read on the Data Bus D0-7 is the addressed memory location. The device is now accessible for a new Read or Write operation. The operation is finished when two successive reads yield the same output data. Flash memory specific features:

❏ The Toggle bit is effective after the fourth Write pulse (for programming) or after the

sixth Write pulse (for Erase).

❏ If the location to be programmed belongs to a protected Flash sector, the instruction

is ignored.

❏ If all the Flash sectors selected for erasure are protected, DQ6 will toggle to ‘0’ for

about 100 µs and then return to the previous addressed location.

9.1.1.6.7 Error Flag DQ5

During a correct Program or Erase, the Error bit will set to ‘0’. This bit is set to ‘1’ when there is a failure during Flash programming, Sector erase, or Bulk Erase.

In the case of Flash programming, the Error Bit indicates the attempt to program a Flash bit(s) from the programmed state (0) to the erased state (1), which is not a valid operation. The Error bit may also indicate a timeout condition while attempting to program a byte.

In case of an error in Flash sector erase or byte program, the Flash sector in which the error occurred or to which the programmed location belongs must no longer be used. Other Flash sectors may still be used. The Error bit resets after the Reset instruction.

9.1.1.6.8 Erase Time-out Flag DQ3

The Erase Timer bit reflects the time-out period allowed between two consecutive Sector Erase instructions. The Erase timer bit is set to ‘0’ after a Sector Erase instruction for a time period of 100 µs + 20% unless an additional Sector Erase instruction is decoded. After this time period or when the additional Sector Erase instruction is decoded, DQ3 is set to ‘1’.

PSD935G2 PSD9XX Family

9.1.1.7 Programming Flash Memory

Flash memory must be erased prior to being programmed. The MCU may erase Flash memory all at once or by-sector. Flash memory sector erases to all logic ones (FF hex), and its bits are programmed to logic zeros. Although erasing Flash memory occurs on a sector basis, programming Flash memory occurs on a word basis.

The PSD935G2 main Flash and secondary Flash memories require the MCU to send an instruction to program a word or perform an erase function (see Table 8).

Once the MCU issues a Flash memory program or erase instruction, it must check for the status of completion. The embedded algorithms that are invoked inside the PSD935G2 support several means to provide status to the MCU. Status may be checked using any of three methods: Data Polling, Data Toggle, or the Ready/Busy output pin.

9.1.1.7.1 Data Polling

Polling on DQ7 is a method of checking whether a Program or Erase instruction is in progress or has completed. Figure 4 shows the Data Polling algorithm.

When the MCU issues a programming instruction, the embedded algorithm within the PSD935G2 begins. The MCU then reads the location of the word to be programmed in Flash to check status. Data bit DQ7 of this location becomes the compliment of data bit 7of the original data word to be programmed. The MCU continues to poll this location, comparing DQ7 and monitoring the Error bit on DQ5. When the DQ7 matches data bit 7 of the original data, and the Error bit at DQ5 remains ‘0’, then the embedded algorithm is complete. If the Error bit at DQ5 is ‘1’, the MCU should test DQ7 again since DQ7 may have changed simultaneously with DQ5 (see Figure 4).

The Error bit at DQ5 will be set if either an internal timeout occurred while the embedded algorithm attempted to program the location or if the MCU attempted to program a ‘1’ to a bit that was not erased (not erased is logic ‘0’).

It is suggested (as with all Flash memories) to read the location again after the embedded programming algorithm has completed to compare the word that was written to Flash with the word that was intended to be written.

When using the Data Polling method after an erase instruction, Figure 4 still applies. However, DQ7 will be ‘0’ until the erase operation is complete. A ‘1’ on DQ5 will indicate a timeout failure of the erase operation, a ‘0’ indicates no error. The MCU can read any location within the sector being erased to get DQ7 and DQ5.

PSDsoft generates ANSI C code functions which implement these Data Polling algorithms.

The PSD935G2 Functional Blocks

(cont.)

PSD9XX Family PSD935G2

Figure 4. Data Polling Flow Chart

START

READ DQ5 & DQ7

at VALID ADDRESS

YES

DQ7

DATA7

DQ5

DQ7

DATA

READ DQ7

FAIL

Program/Erase

Operation Failed

Issue Reset Instruction

PASS

Program/Erase

Operation is

Completed

The PSD935G2 Functional Blocks

(cont.)

9.1.1.7.2 Data Toggle

Checking the Data Toggle bit on DQ6 is a method of determining whether a Program or Erase instruction is in progress or has completed. Figure 5 shows the Data Toggle algorithm.

When the MCU issues a programming instruction, the embedded algorithm within the PSD935G2 begins. The MCU then reads the location to be programmed in Flash to check status. Data bit DQ6 of this location will toggle each time the MCU reads this location until the embedded algorithm is complete. The MCU continues to read this location, checking DQ6 and monitoring the Error bit on DQ5. When DQ6 stops toggling (two consecutive reads yield the same value), and the Error bit on DQ5 remains ‘0’, then the embedded algorithm is complete. If the Error bit on DQ5 is ‘1’, the MCU should test DQ6 again, since DQ6 may have changed simultaneously with DQ5 (see Figure 5).

The Error bit at DQ5 will be set if either an internal timeout occurred while the embedded algorithm attempted to program, or if the MCU attempted to program a ‘1’ to a bit that was not erased (not erased is logic ‘0’).

PSD935G2 PSD9XX Family

9.1.1.7.2 Data Toggle (cont.)

When using the Data Toggle method after an erase instructin, Figure 5 still applies. DQ6 will toggle until the erase operation is complete. A ‘1’ on DQ5 will indicate a timeout failure of the erase operation, a ‘0’ indicates no error. The MCU can read any even location within the sector being erased to get DQ6 and DQ5.

PSDsoft generates ANSI C code functions which implement these Data Toggling algorithms.

The PSD935G2 Functional Blocks

(cont.)

Figure 5. Data Toggle Flow Chart

START

READ

DQ5 & DQ6

YES

DQ6

TOGGLE

DQ5

DQ6

TOGGLE

READ DQ6

FAIL

Program/Erase

Operation Failed

Issue Reset Instruction

PASS

Program/Erase

Operation is

Completed

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.1.1.8 Unlock Bypass Instruction

The unlock bypass feature allows the system to program words to the flash memories faster than using the standard program instruction. The unlock bypass instruction is initiated by first writing two unlock cycles. This is followed by a third write cycle containing the unlock bypass command, 20h (see Table 8). The flash memory then enters the unlock bypass mode. A two-cycle Unlock Bypass Program instruction is all that is required to program in this mode. The first cycle in this instruction contains the unlock bypass programm command, A0h; the second cycle contains the program address and data. Additional data is programmed in the same manner. This mode dispenses with the initial two unlock cycles required in the standard program instruction, resulting in faster total programming time. During the unlock bypass mode, only the Unlock Bypass Program and Unlock Bypass Reset instructions are valid. To exit the unlock bypass mode, the system must issue the two-cycle unlock bypass reset instruction. The first cycle must contain the data 90h; the second cycle the data 00h. Addresses are don’t care for both cycles. The Flash memory then returns to reading array data mode.

9.1.1.9 Erasing Flash Memory

9.1.1.9.1. Flash Bulk Erase Instruction

The Flash Bulk Erase instruction uses six write operations followed by a Read operation of the status register, as described in Table 8. If any byte of the Bulk Erase instruction is wrong, the Bulk Erase instruction aborts and the device is reset to the Read Flash memory status.

During a Bulk Erase, the memory status may be checked by reading status bits DQ5, DQ6, and DQ7, as detailed in section 9.1.1.7. The Error bit (DQ5) returns a ‘1’ if there has been an Erase Failure (maximum number of erase cycles have been executed).

It is not necessary to program the array with 00h because the PSD935G2 will automatically do this before erasing to 0FFh.

During execution of the Bulk Erase instruction, the Flash memory will not accept any instructions.

9.1.1.9.2 Flash Sector Erase Instruction

The Sector Erase instruction uses six write operations, as described in Table 8. Additional Flash Sector Erase confirm commands and Flash sector addresses can be written subsequently to erase other Flash sectors in parallel, without further coded cycles, if the additional instruction is transmitted in a shorter time than the timeout period of about 100 µs. The input of a new Sector Erase instruction will restart the time-out period.

The status of the internal timer can be monitored through the level of DQ3 (Erase time-out bit). If DQ3 is ‘0’, the Sector Erase instruction has been received and the timeout is counting. If DQ3 is ‘1’, the timeout has expired and the PSD935G2 is busy erasing the Flash sector(s). Before and during Erase timeout, any instruction other than Erase suspend and Erase Resume will abort the instruction and reset the device to Read Array mode. It is not necessary to program the Flash sector with 00h as the PSD935G2 will do this automatically before erasing.

During a Sector Erase, the memory status may be checked by reading status bits DQ5, DQ6, and DQ7, as detailed in section 9.1.1.7.

During execution of the erase instruction, the Flash block logic accepts only Reset and Erase Suspend instructions. Erasure of one Flash sector may be suspended, in order to read data from another Flash sector, and then resumed.

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.1.1.9.3 Flash Erase Suspend Instruction

When a Flash Sector Erase operation is in progress, the Erase Suspend instruction will suspend the operation by writing 0B0h to any even address when an appropriate Chip Select (FSi or CSBOOTi) is true. (See Table 8). This allows reading of data from another Flash sector after the Erase operation has been suspended. Erase suspend is accepted only during the Flash Sector Erase instruction execution and defaults to read array mode. An Erase Suspend instruction executed during an Erase timeout will, in addition to suspending the erase, terminate the time out.

The Toggle Bit DQ6 stops toggling when the PSD935G2 internal logic is suspended. The toggle Bit status must be monitored at an address within the Flash sector being erased. The Toggle Bit will stop toggling between 0.1 µs and 15 µs after the Erase Suspend instruction has been executed. The PSD935G2 will then automatically be set to Read Flash Block Memory Array mode.

If an Erase Suspend instruction was executed, the following rules apply:

• Attempting to read from a Flash sector that was being erased will output invalid data.

• Reading from a Flash sector that was not being erased is valid.

• The Flash memory cannot be programmed, and will only respond to Erase Resume

and Reset instructions (read is an operation and is OK).

• If a Reset instruction is received, data in the Flash sector that was being erased will

be invalid.

9.1.1.9.4 Flash Erase Resume Instruction

If an Erase Suspend instruction was previously executed, the erase operation may be resumed by this instruction. The Erase Resume instruction consists of writing 030h to any even address while an appropriate Chip Select (FSi or CSBOOTi) is true. (See Table 8.)

9.1.1.10 Specific Features

9.1.1.10.1 Main Flash and Secondary Flash Sector Protect

Each sector of main Flash and secondary Flash memory can be separately protected against Program and Erase functions. Sector Protection provides additional data security because it disables all program or erase operations. This mode can be activated (or deactivated) through the JTAG-ISP Port or a Device Programmer.

Sector protection can be selected for each sector using the PSDsoft program. This will automatically protect selected sectors when the device is programmed through the JTAG Port or a Device Programmer. Flash sectors can be unprotected to allow updating of their contents using the JTAG Port or a Device Programmer. The microcontroller can read (but cannot change) the sector protection bits.

Any attempt to program or erase a protected Flash sector will be ignored by the device. The Verify operation will result in a read of the protected data. This allows a guarantee of the retention of the Protection status.

The sector protection status can either be read by the MCU through the Flash protection and secondary Flash protection registers (CSIOP) or use the read sector protection instruction (Table 8).

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Sec7_Prot Sec6_Prot Sec5_Prot Sec4_Prot Sec3_Prot Sec2_Prot Sec1_Prot Sec0_Prot

Flash Protection Register

9.1.1.10.2 Reset Instruction

The Reset instruction consists of one write cycle (see Table 8). It can also be optionally preceded by the standard two write decoding cycles (writing AAh to AAAh and 55h to 554h).

The Reset instruction must be executed after:

1. Reading the Flash Protection status or Flash ID using the Flash instruction.

2. When an error condition occurs (DQ5 goes high) during a Flash programming or erase cycle.

The Reset instruction will reset the Flash to normal Read Mode immediately. However, if there is an error condition (DQ5 goes high), the Flash memory will return to the Read Mode in 25 µSeconds after the Reset instruction is issued.

The Reset instruction is ignored when it is issued during a Flash programming or Bulk Erase cycle. The Reset instruction will abort the on going sector erase cycle and return the Flash memory to normal Read Mode in 25 µSeconds.

9.1.1.10.3 Reset Pin Input

The reset pulse input from the pin will abort any operation in progress and reset the Flash memory to Read Mode. When the reset occurs during a programming or erase cycle, the Flash memory will take up to 25 µSeconds to return to Read Mode. It is recommended that the reset pulse (except power on reset, see Reset Section) be at least 25 µSeconds such that the Flash memory will always be ready for the MCU to fetch the boot code after reset is over.

Bit Definitions:

Sec_Prot 1 = Main Flash Sector is write protected. Sec_Prot 0 = Main Flash Sector is not write protected.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Security_

***

Sec3_Prot Sec2_Prot Sec1_Prot Sec0_Prot

Bit

Flash Boot Protection Register

Bit Definitions:

Sec_Prot 1 = Flash Boot Sector is write protected. Sec_Prot 0 = Flash Boot Sector is not write protected.

Security_Bit 0 = Security Bit in device has not been set.

1 = Security Bit in device has been set.

Table 10. Sector Protection/Security Bit Definition

*: Not used.

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.1.2 SRAM

The SRAM is enabled when RS0 —the SRAM chip select output from the DPLD —is high. RS0 can contain up to three product terms, allowing flexible memory mapping.

The SRAM can be backed up using an external battery. The external battery should be connected to the Vstby pin (PE6). If you have an external battery connected to the PSD935G2, the contents of the SRAM will be retained in the event of a power loss. The contents of the SRAM will be retained so long as the battery voltage remains at 2V or greater. If the supply voltage falls below the battery voltage, an internal power switchover to the battery occurs.

Pin PE7 can be configured as an output that indicates when power is being drawn from the external battery. This Vbaton signal will be high with the supply voltage falls below the battery voltage and the battery on PE6 is supplying power to the internal SRAM.

The chip select signal (RS0) for the SRAM, Vstby, and Vbaton are all configured using PSDsoft.

9.1.3 Memory Select Signals

The main Flash (FSi), secondary Flash (CSBOOTi), and SRAM (RS0) memory select signals are all outputs of the DPLD. They are defined using PSDsoft. The following rules apply to the equations for the internal chip select signals:

1. Main Flash memory and secondary Flash memory sector select signals must not be larger than the physical sector size.

2. Any main Flash memory sector must not be mapped in the same memory space as another Main Flash sector.

3. A secondary Flash memory sector must not be mapped in the same memory space as another Flash Boot sector.

4. SRAM and I/O spaces must not overlap.

5. A secondary Flash memory sector may overlap a main Flash memory sector. In case of overlap, priority will be given to the Flash Boot sector.

6. SRAM and I/O spaces may overlap any other memory sector. Priority will be given to the SRAM and I/O.

Example

FS0 is valid when the address is in the range of 8000h to BFFFh, CSBOOT0 is valid from 8000h to 9FFFh, and RS0 is valid from 8000h to 87FFh. Any address in the range of RS0 will always access the SRAM. Any address in the range of CSBOOT0 greater than 87FFh (and less than 9FFFh) will automatically address Boot memory segment 0. Any address greater than 9FFFh will access the Flash memory segment 0. You can see that half of the Flash memory segment 0 and one-fourth of Boot segment 0 can not be accessed in this example. Also note that an equation that defined FS1 to anywhere in the range of 8000h to BFFFh would not be valid.

Figure 6 shows the priority levels for all memory components. Any component on a higher level can overlap and has priority over any component on a lower level. Components on the same level must not overlap. Level one has the highest priority and level 3 has the lowest.

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

Level 1

SRAM, I/O

Level 2

Secondary Flash Memory

Highest Priority

Lowest Priority

Level 3

Main Flash Memory

Figure 6. Priority Level of Memory and I/O Components

9.1.3.1. Memory Select Configuration for MCUs with Separate Program and Data Spaces

The 80C51 and compatible family of microcontrollers, can be configured to have separate address spaces for code memory (selected using PSEN) and data memory (selected using RD). Any of the memories within the PSD935G2 can reside in either space or both spaces. This is controlled through manipulation of the VM register that resides in the PSD’s CSIOP space.

The VM register is set using PSDsoft to have an initial value. It can subsequently be changed by the microcontroller so that memory mapping can be changed on-the-fly. For example, you may wish to have SRAM and main Flash in Data Space at boot, and secondary Flash memory in Program Space at boot, and later swap main and secondary Flash memory. This is easily done with the VM register by using PSDsoft to configure it for boot up and having the microcontroller change it when desired.

Table 11 describes the VM Register.

Bit 7 Bit 6* Bit 5* Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 PIO_EN FL_Data Boot_Data FL_Code Boot_Code SRAM_Code

0 = disable

0 = RD 0 = RD 0 = PSEN 0 = PSEN 0 = PSEN

PIO mode can’t can’t can’t can’t can’t

access access access access access Flash Boot Flash Flash Boot Flash SRAM

1= enable

1 = RD 1 = RD 1 = PSEN 1 = PSEN 1 = PSEN

PIO mode access access access access access

Flash Boot Flash Flash Boot Flash SRAM

Table 11. VM Register

NOTE: Bits 6-5 are not used.

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

MAIN

FLASH

DPLD

FLASH

BOOT

BLOCK

SRAM

RS0

CSBOOT0-3

FS0-7

CS CSCS

OE OE

PSEN

Figure 7. 80C51XA Memory Modes – Separate Space Mode

MAIN

FLASH

DPLD

FLASH

BOOT

BLOCK

SRAM

RS0

CSBOOT0-3

FS0-7

CS CSCS

OE OE

VM REG BIT 2

PSEN

VM REG BIT 0

VM REG BIT 1

VM REG BIT 3

VM REG BIT 4

Figure 8. 80C51XA Memory Mode – Combined Space Mode

9.1.3.2 Configuration Modes for MCUs with Separate Program and Data Spaces

9.1.3.2.1 Separate Space Modes

Code memory space is separated from data memory space. For example, the PSEN signal is used to access the program code from the main Flash Memory, while the RD signal is used to access data from the secondary Flash memory, SRAM and I/O Ports. This configuration requires the VM register to be set to 0Ch.

9.1.3.2.2 . Combined Space Modes

The program and data memory spaces are combined into one space that allows the main Flash Memory, secondary Flash memory, and SRAM to be accessed by either PSEN or RD. For example, to configure the main Flash memory in combined space mode, bits 2 and 4 of the VM register are set to “1”.

9.1.3.3 80C51XA Memory Map Example

See Application Notes for examples.

PSD9XX Family PSD935G2

RESET

D0-D7

R/W

D0 Q0

Q1 Q2 Q3 Q4 Q5 Q6 Q7

D1 D2 D3 D4 D5 D6 D7

PAGE

PGR0 PGR1

PGR2 PGR3

DPLD

AND

GPLD

INTERNAL SELECTS AND LOGIC

FLASH

PLD

PGR4 PGR5 PGR6 PGR7

Figure 9. Page Register

The PSD935G2 Functional Blocks

(cont.)

9.1.4 Page Register

The eight bit Page Register increases the addressing capability of the microcontroller by a factor of up to 256. The contents of the register can also be read by the microcontroller. The outputs of the Page Register (PGR0-PGR7) are inputs to the PLD decoder and can be included in the Flash Memory, secondary Flash memory, and SRAM chip select equations.

If memory paging is not needed, or if not all 8 page register bits are needed for memory paging, then these bits may be used in the PLD for general logic. See Application Notes.

Figure 9 shows the Page Register. The eight flip flops in the register are connected to the internal data bus D0-D7. The microcontroller can write to or read from the Page Register. The Page Register can be accessed at address location CSIOP + E0h.

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.1.5 Memory ID Registers

The 8-bit read only memory status registers are included in the CSIOP space. The user can determine the memory configuration of the PSD device by reading the Memory ID0 and Memory ID1 registers. The content of the registers are defined as follow:

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

S_size 3 S_size 2 S_size 1 S_size 0 F_size 3 F_size 2 F_size 1 F_size 0

Memory_ID0 Register

Main Flash Size

F_size3 F_size2 F_size1 F_size0 (Bit)

0 0 0 0 none 0 0 0 1 256K 0 0 1 0 512K 00111M 01002M 01014M 01108M

Bit Definition

SRAM Size

S_size3 S_size2 S_size1 S_size0 (Bit)

0 0 0 0 none 000116K 001032K 001164K

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

B_type 1 B_type 0 B_size 3 B_size 2 B_size 1 B_size 0

Memory_ID1 Register

*Not used bit should be set to zero.

Boot Block Size

B_size3 B_size2 B_size1 B_size0 (Bit)

0 0 0 0 none 0 0 0 1 128K 0 0 1 0 256K 0 0 1 1 512K

Bit Definition

B_type1 B_type0 Boot Block Type

0 0 Flash 0 1 EEPROM

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.2 PLDs

The PLDs bring programmable logic functionality to the PSD935G2. After specifying the logic for the PLDs in PSDsoft, the logic is programmed into the device and available upon power-up.

The PSD935G2 contains two PLDs: the Decode PLD (DPLD), and the General Purpose PLD (GPLD). The PLDs are briefly discussed in the next few paragraphs, and in more detail in sections 9.2.1 and 9.2.2. Figure 11 shows the configuration of the PLDs.

The DPLD performs address decoding for internal components, such as memory, registers, and I/O port selects.

The GPLD can be used to generate external chip selects, control signals or logic functions. The GPLD has 24 outputs that are connected to Port A, B and C.

The AND array is used to form product terms. These product terms are specified using PSDsoft. An Input Bus consisting of 66 signals is connected to the PLDs. The signals are shown in Table 12. The complement of the 66 signals are also available as inputs to the AND array.

Input Source Input Name Number

of Signals

MCU Address Bus A[15:0]* 16 MCU Control Signals CNTL[2:0] 3 Reset RST 1 Power Down PDN 1 Port A Input PA[7-0] 8 Port B Input PB[7-0] 8 Port C Input PC[7-0] 8 Port D Inputs PD[3:0] 4 Port F Inputs PF[7:0] 8 Page Register PGR(7:0) 8 Flash Programming Status Bit Rdy/Bsy 1

Table 12. DPLD and GPLD Inputs

NOTE: The address inputs are A[19:4] in 80C51XA mode.

The Turbo Bit

The PLDs in the PSD935G2 can minimize power consumption by switching to standby when inputs remain unchanged for an extended time of about 70 ns. Setting the Turbo mode bit to off (Bit 3 of the PMMR0 register) automatically places the PLDs into standby if no inputs are changing. Turbo-off mode increases propagation delays while reducing power consumption. Refer to the Power Management Unit section on how to set the Turbo Bit. Additionally, five bits are available in the PMMR2 register to block MCU control signals from entering the PLDs. This reduces power consumption and can be used only when these MCU control signals are not used in PLD logic equations.

PSD935G2 PSD9XX Family

PLD INPUT BUS

CSIOP SELECT

SRAM SELECT

FLASH BOOT MEMORY SELECTS

DECODE PLD

PAGE

GPLD

GENERAL PURPOSE PLD

FLASH MEMORY SELECTS

DATA

BUS

PLD OUT

PORT A

PORT B

PORT C

PLD OUT

PORT A PLD INPUT PORT B PLD INPUT

PORT C PLD INPUT

PORT D PLD INPUT

PORT F PLD INPUT

4 1 1

FA15

8 8

PORT D

PORT F

Figure 10. PLD Block Diagram

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.2.1 Decode PLD (DPLD)

The DPLD, shown in Figure 11, is used for decoding the address for internal components. The DPLD can generate the following decode signals:

• 8 sector selects for the main Flash memory (three product terms each)

• 4 sector selects for the secondary Flash memory (three product terms each)

• 1 internal SRAM select (three product terms)

• 1 internal CSIOP select (select PSD registers, one product term)

• 1 main Flash address input (FA15, three product terms). FA15 selects the lower

or upper 32KB block in the main Flash sector. See the Memory Blocks section for details.

Inputs to the DPLD chip selects may include address inputs, Page Register inputs and other user defined external inputs from Ports A, B, C, D or F.

9.2.2 General Purpose PLD (GPLD)

The General Purpose PLD implements user defined system combinatorial logic function or chip selects for external devices. Figure 12 shows how the GPLD is connected to the I/O Ports. The GPLD has 24 outputs and each are routed to a port pin. The port pin can also be configured as input to the GPLD. When it is not used as GPLD output or input, the pin can be configured to perform other I/O functions.

All GPLD outputs are identical except in the number of available product terms (PDs) for logic implementation. Select the pin that can best meet the PT requirement of your logic function or chip select. In general, a PT is consumed for each logic “OR” function that you specify in PSDsoft. However, certain logic functions can consume more than one PT even if no logic “OR” is specified (such as specifying an address range with boundaries of high granularity).

Table 13 shows the number of “native” PTs for each GPLD output pin. A native PT means that a particular PT is dedicated to an output pin. For example, Table 13 shows that PSD Port A pin PA0 has 3 native product terms. This means a guaranteed minimum of 3 PTs is available to implement logic for that pin.

PSD silicon and PSDsoft can include additional PTs beyond the native PTs to implement logic. This is a transparent operation that occurs as needed through PT expansion (internal feedback) or PT allocation (internal borrowing). You may notice in the fitter report generated by PSDsoft that for a given GPLD output pin, more PTs were used to implement logic than the number of native PTs available for that pin. This is because PSDsoft has called on unused PTs from other GPLD output pins to make your logic design fit (PT allocation or PT expansion). For optimum results, choose a GPLD output pin with a large number of native PTs for complicated logic.

GPLD Output on Port Pin Number of Native

Product Terms

Port A, pins PA0-3 3 Port A, pins PA4-7 9 Port B, pins PB0-3 4 Port B, pins PB4-7 7 Port C, pins PC0-7 1

Table 13: GPLD Product Term Availability

PSD935G2 PSD9XX Family

(INPUTS)

(32)

(16)

(1)

PDN (APD OUTPUT)

I/O PORTS (PORT A,B,C,F)

(8)

PGR0 -PGR7

[

15:0

]

(4)

(3)

[

3:0

]

(ALE,CLKIN,CSI)

CNTRL

[

2:0

] (

READ/WRITE CONTROL SIGNALS)

(1)

RESET

RD_BSY

RS0

CSIOP

8 FLASH MEMORY

SECTOR SELECTS

4 SECONDARY

FLASH MEMORY

SECTOR SELECTS

SRAM SELECT

I/O DECODER

SELECT

CSBOOT 0

CSBOOT 1

CSBOOT 2

CSBOOT 3

FS0

FS7

FA15

MAIN FLASH

ADDRESS INPUT

Figure 11. DPLD Logic Array

*NOTES: 1. The address inputs are A[19:4] in 80C51XA mode.

2. Additional address lines can be brought into PSD via Port A, B, C, C or F.

PSD9XX Family PSD935G2

PRODUCT TERM

PIN PA0-3 HAS 3 NATIVE PTs

PIN PA4-7 HAS 9 NATIVE PTs

POLARITY

SELECT

OTHER I/O

FUNCTION

OTHER I/O

FUNCTION

OTHER I/O

FUNCTION

GENERAL PURPOSE PLD (GPLD) I/O PORT

PLD INPUT BUS

MUX

PLD INPUT

AND ARRAY

PORT A

PRODUCT TERM

PIN PB0-3 HAS 4 NATIVE PTs

PIN PB4-7 HAS 7 NATIVE PTs

POLARITY

SELECT

PLD OUTPUT

MUX

AND ARRAY

PORT B

PRODUCT TERM

PIN PC0-7 HAS 1 NATIVE PT

POLARITY

SELECT

PLD OUTPUT

MUX

AND ARRAY

PORT C

Figure 12. The Micro⇔Cell and I/O Port

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.3 Microcontroller Bus Interface

The “no-glue logic” PSD935G2 Microcontroller Bus Interface can be directly connected to most popular microcontrollers and their control signals. Key 8-bit microcontrollers with their bus types and control signals are shown in Table 14. The MCU interface type is specified using the PSDsoft.

9.3.1. PSD935G2 Interface to a Multiplexed Bus

Figure 13 shows an example of a system using a microcontroller with a 8-bit multiplexed bus and a PSD935G2. The ADIO port on the PSD935G2 is connected directly to the microcontroller address/data bus. ALE latches the address lines internally. Latched addresses can be brought out to Port E, F or G. The PSD935G2 drives the ADIO data bus only when one of its internal resources is accessed and the RD input is active. Should the system address bus exceed sixteen bits, Ports A, B, C, or F may be used as additional address inputs.

9.3.2. PSD935G2 Interface to a Non-Multiplexed Bus

Figure 14 shows an example of a system using a microcontroller with a 8-bit non-multiplexed bus and a PSD935G2. The address bus is connected to the ADIO Port, and the data bus is connected to Port F. Port F is in tri-state mode when the PSD935G2 is not accessed by the microcontroller. Should the system address bus exceed sixteen bits, Ports A, B or C may be used for additional address inputs.

Data

Bus

MCU Width CNTL0 CNTL1 CNTL2 PC7 PD0** ADIO0 PF3-PF0 PF7-PF4

8031/8051 8 WR RD PSEN * ALE A0 ** 80C51XA 8 WR RD PSEN * ALE A4 A3-A0 * 80C251 8 WR PSEN **ALE A0 ** 80C251 8 WR RD PSEN * ALE A0 ** 80198 8 WR RD **ALE A0 ** 68HC11 8 R/W E **AS A0 ** 68HC05C0 8 WR RD **AS A0 ** 68HC912 8 R/W E * DBE AS A0 ** Z80 8 WR RD ***A0 D3-D0 D7-D4 Z8 8 R/W DS **AS A0 ** 68330 8 R/W DS **AS A0 ** M37702M2 8 R/W E **ALE A0 D3-D0 D7-D4

Table 14. Microcontrollers and their Control Signals

**Unused CNTL2 pin can be configured as PLD input. Other unused pins (PD3-0, PA3-0) can be **configured for other I/O functions.

**ALE/AS input is optional for microcontrollers with a non-multiplexed bus

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

MICRO-

CONTROLLER

BHE

ALE

RESET

AD[7:0

]

A[15:8

]

A[15:8

]

A[7:0

]

ADIO

PORT

A,B, or

WR (CNTRL0

)

RD (CNTRL1

)

BHE (CNTRL2

)

RST

ALE (PD0

)

PORT D

(

OPTIONAL

)

A[23:16

]

(

OPTIONAL

)

(

OPTIONAL

)

PSD935G2

Figure 13. An Example of a Typical 8-Bit Multiplexed Bus Interface

MICRO-

CONTROLLER

WR RD

BHE

ALE

RESET

D[7:0

]

A[15:0

]

A[23:16

]

D[7:0

]

ADIO

PORT

PORT A,B or

WR (CNTRL0

)

RD (CNTRL1

)

BHE (CNTRL2

)

RST

ALE (PD0

)

PORT D

(OPTIONAL)

PSD935G2

Figure 14. An Example of a Typical 8-Bit Non-Multiplexed Bus Interface

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.3.3 Microcontroller Interface Examples

Figures 15 through 19 show examples of the basic connections between the PSD935G2 and some popular microcontrollers. The PSD935G2 Control input pins are labeled as to the microcontroller function for which they are configured. The MCU interface is specified using the PSDsoft.

9.3.3.1 80C31

Figure 15 shows the interface to the 80C31, which has an 8-bit multiplexed address/data bus. The lower address byte is multiplexed with the data bus. The microcontroller control signals PSEN, RD, and WR may be used for accessing the internal memory components and I/O Ports. The ALE input (pin PD0) latches the address.

9.3.3.2 80C251

The Intel 80C251 microcontroller features a user-configurable bus interface with four possible bus configurations, as shown in Table 15.

Configuration 1 is 80C31 compatible, and the bus interface to the PSD935G2 is identical to that shown in Figure 15. Configurations 2 and 3 have the same bus connection as shown in Figure 16. There is only one read input (PSEN) connected to the Cntl1 pin on the PSD935G2. The A16 connection to the PA0 pin allows for a larger address input to the PSD935G2. Configuration 4 is shown in Figure 17. The RD signal is connected to Cntl1 and the PSEN signal is connected to the CNTL2.

The 80C251 has two major operating modes: Page Mode and Non-Page Mode. In Non-Page Mode, the data is multiplexed with the lower address byte, and ALE is active in every bus cycle. In Page Mode, data D[7:0] is multiplexed with address A[15:8]. In a bus cycle where there is a Page hit, the ALE signal is not active and only addresses A[7:0] are changing. The PSD935G2 supports both modes. In Page Mode, the PSD bus timing is identical to Non-Page Mode except the address hold time and setup time with respect to ALE is not required. The PSD access time is measured from address A[7:0] valid to data in valid.

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

Configuration 80C251 Connecting to Page Mode

Read/Write PSD935G2

Pins Pins

WR CNTL0 Non-Page Mode, 80C31 compatible

1 RD CNTL1 A [7:0] multiplex with D[7:0}

PSEN CNTL2

WR CNTL0 Non-Page Mode PSEN only CNTL1 A [7:0] multiplex with D[7:0}

WR CNTL0 Page Mode PSEN only CNTL1 A [15:8] multiplex with D[7:0}

WR CNTL0 Page Mode RD CNTL1 A [15:8] multiplex with D[7:0} PSEN CNTL2

Table 15. 80C251 Configurations

9.3.3.3 80C51XA

The Philips 80C51XA microcontroller family supports an 8- or 16-bit multiplexed bus that can have burst cycles. Address bits A[3:0] are not multiplexed, while A[19:4] are multiplexed with data bits D[15:0] in 16-bit mode. In 8-bit mode, A[11:4] are multiplexed with data bits D[7:0].

The 80C51XA can be configured to operate in eight-bit data mode. (shown in Figure 18). The 80C51XA improves bus throughput and performance by executing Burst cycles for code fetches. In Burst Mode, address A19-4 are latched internally by the PSD935G2, while the 80C51XA changes the A3-0 lines to fetch up to 16 bytes of code. The PSD access time is then measured from address A3-A0 valid to data in valid. The PSD bus timing requirement in Burst Mode is identical to the normal bus cycle, except the address setup and hold time with respect to ALE does not apply.

9.3.3.4 68HC11

Figure 19 shows an interface to a 68HC11 where the PSD935G2 is configured in 8-bit multiplexed mode with E and R/W settings. The DPLD can generate the READ and WR signals for external devices.

PSD935G2 PSD9XX Family

GND

RESET

30 49 50 70

92969

GND GND GND GND

A[15:8]

AD[7:0]

3 4 5 6

7 10 11 12

13 14 15 16 17 18 19 20

79 80

71 72 73 74 75 76 77 78

AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7

A8 A9 A10 A11 A12 A13 A14 A15

ADIO0 ADIO1 ADIO2 ADIO3 ADIO4 ADIO5 ADIO6 ADIO7

PF0 PF1 PF2 PF3 PF4 PF5 PF6 PF7

PG0 PG1 PG2 PG3 PG4 PG5 PG6 PG7

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

31 32 33 34 35 36 37 38

21 22 23 24 25 26 27 28

51 52 53 54 55 56 57 58

61 62 63 64 65 66 67 68

41 42 43 44 45 46 47 48

ADIO8 ADI09 ADIO10 ADIO11 ADIO12 ADIO13 ADIO14 ADIO15

CNTL0 (WR) CNTL1 (RD)

CNTL2 (PSEN) PD0 (ALE)

PD1 (CLKIN) PD2 (CSI) PD3

RESET

PE0 (TMS) PE1 (TCK/ST) PE2 (TDI) PE2 (TDO) PE4 (TSTAT/RDY) PE5 (TERR) PE6 (VSTBY) PE7 (VBATON)

RESET

WR RD

PSEN ALE

P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7

P2.0 P2.1 P2.2 P2.3 P2.4 P2.5 P2.6 P2.7

PSEN

ALE/P

39 38 37 36 35 34 33 32

21 22 23 24 25 26 27 28

29 30

X2 RESET

INT0 INT1 T0 T1

P1.0 P1.1 P1.2 P1.3 P1.4 P1.5 P1.6 P1.7

RXD TXD EA/VP

13 14

1 2 3 4 5 6 7 8

10 11

CRYSTAL

80C31

Figure 15. Interfacing the PSD935G2 with an 80C31

PSD9XX Family PSD935G2

GND

RESET

30 49 50 70

A16 A17

29 69

GND GND GND GND

A[17:8]

A[15:8]

AD[7:0]

3 4 5 6

7 10 11 12

13 14 15 16 17 18 19 20

59 60

79 80

71 72 73 74 75 76 77 78

A0 A1 A2 A3 A4 A5 A6 A7

AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15

ADIO0 ADIO1 ADIO2 ADIO3 ADIO4 ADIO5 ADIO6 ADIO7

PF0 PF1 PF2 PF3 PF4 PF5 PF6 PF7

PG0 PG1 PG2 PG3 PG4 PG5 PG6 PG7

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

31 32 33 34 35 36 37 38

21 22 23 24 25 26 27 28

51 52 53 54 55 56 57 58

61 62 63 64 65 66 67 68

41 42 43 44 45 46 47 48

ADIO8 ADIO9 ADIO10 ADIO11 ADIO12 ADIO13 ADIO14 ADIO15

CNTL0 (WR) CNTL1 (RD)

CNTL2 (PSEN) PD0 (ALE)

PD1 (CLKIN) PD2 (CSI) PD3

RESET

PE0 (TMS) PE1 (TCK/ST) PE2 (TDI) PE3 (TDO) PE4 (TSTAT/RDY) PE5 (TERR) PE6 (VSTBY) PE7 (VBATON)

RESET

A16

A17

ALE

P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7

P2.0 P2.1 P2.2 P2.3 P2.4 P2.5 P2.6 P2.7

RD/A16

PSEN

ALE

P1.0 P1.1 P1.2 P1.3 P1.4 P1.5 P1.6 P1.7

X1 X2 P3.0/RXD

P3.1/TXD P3.2/INT0 P3.3/INT1 P3.4/T0 P3.5/T1

RESET EA

2 3 4 5 6 7 8

9 21 20 11

13 14 15 16 17

43 42 41 40 39 38 37 36

24 25 26 27 28 29 30 31

18 19 32

CRYSTAL

80C251SB

PSD935G2

Figure 16. Interfacing the PSD935G2 to the 80C251, with One Read Input

**Connection is optional.

**Non-page mode: AD[7:0] - ADIO[7:0].

PSD935G2 PSD9XX Family

GND

RESET

30 49 50 70

92969

GND GND GND GND

AD[15:8]

A[7:0]

3 4 5 6

7 10 11 12

13 14 15 16 17 18 19 20

79 80

71 72 73 74 75 76 77 78

A0 A1 A2 A3 A4 A5 A6 A7

AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15

ADIO0 ADIO1 ADIO2 ADIO3 ADIO4 ADIO5 ADIO6 ADIO7

PF0 PF1 PF2 PF3 PF4 PF5 PF6 PF7

PG0 PG1 PG2 PG3 PG4 PG5 PG6 PG7

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

31 32 33 34 35 36 37 38

21 22 23 24 25 26 27 28

51 52 53 54 55 56 57 58

61 62 63 64 65 66 67 68

41 42 43 44 45 46 47 48

ADIO8 ADI09 ADIO10 ADIO11 ADIO12 ADIO13 ADIO14 ADIO15

CNTL0 (WR) CNTL1 (RD)

CNTL2 (PSEN) PD0 (ALE)

PD1 (CLKIN) PD2 (CSI) PD3

RESET

PE0 (TMS) PE1 (TCK/ST) PE2 (TDI) PE3 (TDO) PE4 (TSTAT/RDY) PE5 (TERR) PE6 (VSTBY) PE7 (VBATON)

RESET

WR RD

ALE

P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7

P2.0 P2.1 P2.2 P2.3 P2.4 P2.5 P2.6 P2.7

RD/A16

PSEN

ALE

P1.0 P1.1 P1.2 P1.3 P1.4 P1.5 P1.6 P1.7

X1 X2 P3.0/RXD

P3.1/TXD P3.2/INT0 P3.3/INT1 P3.4/T0 P3.5/T1

RESET EA

2 3 4 5 6 7 8

9 21 20 11

13 14 15 16 17

43 42 41 40 39 38 37 36

24 25 26 27 28 29 30 31

32 33

CRYSTAL

80C251SB

PSD935G2

PSEN

Figure 17. Interfacing the PSD935G2 to the 80C251, with Read and PSEN Inputs

PSD9XX Family PSD935G2

GND

RESET

30 49 50 70

92969

GND GND GND GND

A[19:12] D[7:0]

A[3:0]

3 4 5 6

7 10 11 12

13 14 15 16 17 18 19 20

59 60

79 80

71 72 73 74 75 76 77 78

A4D0 A5D1 A6D2 A7D3 A8D4 A9D5 A10D6 A11D7

A12 A13 A14 A15 A16 A17 A18 A19

ADIO0 ADIO1 ADIO2 ADIO3 ADIO4 ADIO5 ADIO6 ADIO7

PF0 PF1 PF2 PF3 PF4 PF5 PF6 PF7

PG0 PG1 PG2 PG3 PG4 PG5 PG6 PG7

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

31 32 33 34 35 36 37 38

21 22 23 24 25 26 27 28

51 52 53 54 55 56 57 58

61 62 63 64 65 66 67 68

41 42 43 44 45 46 47 48

ADIO8 ADI09 ADIO10 ADIO11 ADIO12 ADIO13 ADIO14 ADIO15

CNTL0 (WR) CNTL1 (RD)

CNTL2 (PSEN) PD0 (ALE)

PD1 (CLKIN) PD2 (CSI) PD3

RESET

PE0 (TMS) PE1 (TCK/ST) PE2 (TDI) PE3 (TDO) PE4 (TSTAT/RDY) PE5 (TERR) PE6 (VSTBY) PE7 (VBATON)

RESET

WRRESET

A3 A2 A1 A0

PSEN

ALE

A0 A1 A2 A3

A4D0 A5D1 A6D2 A7D3 A8D4

A9D5 A10D6 A11D7

A12D8 A13D9

A14D10 A15D11 A16D12 A17D13 A18D14 A19D15

A3 A2 A1

A0/WRH

WRL

PSEN

ALE

43 42 41 40 39 38 37 36

24 25 26 27 28 29 30 31

5 4 3 2 18 19

XTAL1

XTAL2 RXD0

TXD0 RXD1 TXD1

T2EX T2 T0

RST INT0 INT1

EA/WAIT BUSW

20 11

6 7

9 8

10 14 15

CRYSTAL

XA-G3

PSD935G2

Figure 18. Interfacing the PSD935G2 to the 80C51XA, 8-Bit Data Bus

PSD935G2 PSD9XX Family

GND

RESET

30 49 50 70

92969

GND GND GND GND

A[15:8]

AD[7:0]

3 4 5 6

7 10 11 12

13 14 15 16 17 18 19 20

59 60

79 80

71 72 73 74 75 76 77 78

AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7

A8 A9 A10 A11 A12 A13 A14 A15

ADIO0 ADIO1 ADIO2 ADIO3 ADIO4 ADIO5 ADIO6 ADIO7

PF0 PF1 PF2 PF3 PF4 PF5 PF6 PF7

PG0 PG1 PG2 PG3 PG4 PG5 PG6 PG7

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

31 32 33 34 35 36 37 38

21 22 23 24 25 26 27 28

51 52 53 54 55 56 57 58

61 62 63 64 65 66 67 68

41 42 43 44 45 46 47 48

ADIO8 ADIO9 ADIO10 ADIO11 ADIO12 ADIO13 ADIO14 ADIO15

CNTL0 (R/W) CNTL1 (E)

CNTL2 PD0 (AS)

PD1 (CLKIN) PD2 (CSI) PD3

RESET

PE0 (TMS) PE1 (TCK/ST) PE2 (TDI) PE3 (TDO) PE4 (TSTAT/RDY) PE5 (TERR) PE6 (VSTBY) PE7 (VBATON)

RESET

PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7

PB0 PB1 PB2 PB3 PB4 PB5 PB6 PB7

RESET

PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7

XT EX

IRQ XIRQ

PD0 PD1 PD2 PD3 PD4 PD5

PE0 PE1 PE2 PE3 PE4 PE5 PE6 PE7

VRH VRL

MODB MODA

34 33 32 31 30 29 28 27

8 7

19 18

20 21 22 23 24 25

43 45 47 49 44 46 48 50

52 51

2 3

9 10 11 12 13 14 15 16

42 41 40 39 38 37 36 35

6 5

CRYSTAL

68HC11E9

PSD935G2

Figure 19. Interfacing the PSD935G2 with a 68HC11

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.4 I/O Ports

There are seven programmable I/O ports: Ports A, B, C, D, E, F and G. Each of the ports is eight bits except Port D, which is 4 bits. Each port pin is individually user configurable, thus allowing multiple functions per port. The ports are configured using PSDsoft or by the microcontroller writing to on-chip registers in the CSIOP address space.

The topics discussed in this section are:

• General Port Architecture

• Port Operating Modes

• Port Configuration Registers

• Port Data Registers

• Individual Port Functionality.

9.4.1 General Port Architecture

The general architecture of the I/O Port is shown in Figure 20. Individual Port architectures are shown in Figures 21 through 23. In general, once the purpose for a port pin has been defined, that pin will no longer be available for other purposes. Exceptions will be noted.

As shown in Figure 20, the ports contain an output multiplexer whose selects are driven by the configuration bits in the Control Registers (Ports E, F and G only) and PSDsoft Configuration. Inputs to the multiplexer include the following:

❏ Output data from the Data Out Register ❏ Latched address outputs ❏ GPLD outputs (External Chip Selects)

The Port Data Buffer (PDB) is a tri-state buffer that allows only one source at a time to be read. The PDB is connected to the Internal Data Bus for feedback and can be read by the microcontroller. The Data Out and Micro⇔Cell outputs, Direction and Control Registers, and port pin input are all connected to the PDB.

The contents of these registers can be altered by the microcontroller. The PDB feedback path allows the microcontroller to check the contents of the registers.

9.4.2 Port Operating Modes

The I/O Ports have several modes of operation. Some modes can be defined using PSDsoft, some by the microcontroller writing to the Registers in CSIOP space, and some by both. The modes that can only be defined using PSDsoft must be programmed into the device and cannot be changed unless the device is reprogrammed. The modes that can be changed by the microcontroller can be done so dynamically at run-time. The PLD I/O, Data Port, Address Input, and MCU Reset modes are the only modes that must be defined before programming the device. All other modes can be changed by the microcontroller at run-time.

Table 16 summarizes which modes are available on each port. Table 19 shows how and where the different modes are configured. Each of the port operating modes are described in the following subsections.

PSD935G2 PSD9XX Family

INTERNAL DATA BUS

DATA OUT

REG.

ADDRESS

GPLD OUTPUTS

ALE

READ MUX

CONTROL REG.

DIR REG.

PLD INPUT

DATA IN

OUTPUT

SELECT

OUTPUT

MUX

PORT PIN

DATA OUT

ADDRESS

Figure 20. General I/O Port Architecture

The PSD935G2 Functional Blocks

(cont.)

Port Mode Port A Port B Port C Port D Port E Port F Port G

MCU I/O Yes Yes Yes Yes Yes Yes Yes PLD Outputs Yes Yes Yes No No No No PLD Inputs Yes Yes Yes Yes No Yes No Address Out No No No No Yes Yes Yes

(A7-0) (A7-0) (A7-0)

(A15-8) Address In Yes Yes Yes Yes No Yes No Data Port No No No No No Yes No JTAG ISP No No No No Yes No No

Table 16. Port Operating Modes

PSD9XX Family PSD935G2

Control Direction VM

Defined In Register Register Register

Mode PSDsoft Setting Setting Setting

Declare 0 1 = output,

MCU I/O

pins only (Note 1) 0 =input NA

Declare pins

PLD I/O and logic or chip NA NA

select equations

Data Port

Selected for

(Port F)

MCU with NA NA NA

non-mux bus

Address Out Declare

11NA

(Port E, F, G) pins only Address In Declare pins

(Port A,B,C,D,F) NA NA NA JTAG ISP

Declare pins

NA NA NA

only

Table 17. Port Operating Mode Settings

*NA = Not Applicable

NOTE: 1. Control Register setting is not applicable to Ports A, B and C.

9.4.2.1 MCU I/O Mode

In the MCU I/O Mode, the microcontroller uses the PSD935G2 ports to expand its own I/O ports. By setting up the CSIOP space, the ports on the PSD935G2 are mapped into the microcontroller address space. The addresses of the ports are listed in Table 6.

A port pin can be put into MCU I/O mode by writing a ‘0’ to the corresponding bit in the Control Register (Port E, F and G). The MCU I/O direction may be changed by writing to the corresponding bit in the Direction Register. See the subsection on the Direction Register in the “Port Registers” section. When the pin is configured as an output, the content of the Data Out Register drives the pin. When configured as an input, the microcontroller can read the port input through the Data In buffer. See Figure 20.

Ports A, B and C do not have Control Registers, and are in MCU I/O mode by default. They can be used for PLD I/O if they are specified in PSDsoft.

9.4.2.2 PLD I/O Mode

The PLD I/O Mode uses a port as an input to the CPLD’s Input Micro⇔Cells, and/or as an output from the GPLD. The corresponding bit in the Direction Register must not be set to ‘1’ if the pin is defined as a PLD input pin in PSDsoft. The PLD I/O Mode is specified in PSDsoft by declaring the port pins, and then specifying an equation in PSDsoft.

The PSD935G2 Functional Blocks

(cont.)

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.4.2.4 Address In Mode

For microcontrollers that have more than 16 address lines, the higher addresses can be connected to Ports A, B, C, D or F and are routed as inputs to the PLDs. The address input can be latched by the address strobe (ALE/AS). Any input that is included in the DPLD equations for the Main Flash, Boot Flash, or SRAM is considered to be an address input.

9.4.2.5 Data Port Mode

Port F can be used as a data bus port for a microcontroller with a non-multiplexed address/data bus. The Data Port is connected to the data bus of the microcontroller. The general I/O functions are disabled in Port F if the port is configured as Data Port. Data Port Mode is automatically configured in PSDsoft when a non-multiplexed bus MCU is selected.

9.4.2.3 Address Out Mode

For microcontrollers with a multiplexed address/data bus, Address Out Mode can be used to drive latched addresses onto the port pins. These port pins can, in turn, drive external devices. Either the output enable or the corresponding bits of both the Direction Register and Control Register must be set to a ‘1’ for pins to use Address Out Mode. This must be done by the MCU at run-time. See Table 18 for the address output pin assignments on Ports E, F and F for various MCUs.

Note: Do not drive address lines with Address Out Mode to an external memory device if it is intended for the MCU to boot from the external device. The MCU must first boot from PSD memory so the Direction and Control register bits can be set.

MCU Port E (3:0) Port E (7:4) Port F (3:0) Port F (7:4) Port G (3:0) Port G (7:4)

80C51XA N/A* Addr (7:4) N/A* Addr (7:4) Addr (11:8) N/A 80C251

N/A N/A N/A N/A Addr (11:8) Addr (15:12)

(Page Mode) All Other

Eight-Bit Addr (3:0) Addr (7:4) Addr (3:0) Addr (7:4) Addr (3:0) Addr (7:4) Multiplexed

8-Bit Non-Mux N/A N/A N/A N/A Addr (3:0) Addr (7:4) Bus

Table 18. I/O Port Latched Address Output Assignments

PSD9XX Family PSD935G2

9.4.3 Port Configuration Registers (PCRs)

Each port has a set of PCRs used for configuration. The contents of the registers can be accessed by the microcontroller through normal read/write bus cycles at the addresses given in Table 6. The addresses in Table 6 are the offsets in hex from the base of the CSIOP register.

The pins of a port are individually configurable and each bit in the register controls its respective pin. For example, Bit 0 in a register refers to Bit 0 of its port. The three PCRs, shown in Table 19, are used for setting the port configurations. The default power-up state for each register in Table 22 is 00h.

Control E,F,G Write/Read Direction A,B,C,D,E,F,G Write/Read Drive Select* A,B,C,D,E,F,G Write/Read

Table 19. Port Configuration Registers

*NOTE: See Table 22 for Drive Register bit definition.

The PSD935G2 Functional Blocks

(cont.)

9.4.3.1 Control Register

Any bit set to ‘0’ in the Control Register sets the corresponding Port pin to MCU I/O Mode, and a ‘1’ sets it to Address Out Mode. The default mode is MCU I/O. Only Ports E, F and G have an associated Control Register.

9.4.3.2 Direction Register

The Direction Register controls the direction of data flow in the I/O Ports. Any bit set to ‘1’ in the Direction Register will cause the corresponding pin to be an output, and any bit set to ‘0’ will cause it to be an input. The default mode for all port pins is input.

Figures 21 and 23 show the Port Architecture diagrams for Ports A/B/C and E/F/G respectively. The direction of data flow for Ports A, B, C and F are controlled by the direction register.

An example of a configuration for a port with the three least significant bits set to output and the remainder set to input is shown in Table 21. Since Port D only contains four pins, the Direction Register for Port D has only the four least significant bits active.

Direction Register Bit Port Pin Mode

0 Input 1 Output

Table 20. Port Pin Direction Control

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

00000111

Table 21. Port Direction Assignment Example

PSD935G2 PSD9XX Family

Drive

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Port A

Open Open Open Open Open Open Open Open Drain Drain Drain Drain Drain Drain Drain Drain

Port B

Open Open Open Open Open Open Open Open Drain Drain Drain Drain Drain Drain Drain Drain

Port C

Slew Slew Slew Slew Slew Slew Slew Slew

Rate Rate Rate Rate Rate Rate Rate Rate

Port D

Open Open Open Open Drain Drain Drain Drain

Port E

Open Open Open Open Open Open Open Open Drain Drain Drain Drain Drain Drain Drain Drain

Port G

Open Open Open Open Open Open Open Open Drain Drain Drain Drain Drain Drain Drain Drain

Table 22. Drive Register Pin Assignment

The PSD935G2 Functional Blocks

(cont.)

9.4.3.3 Drive Select Register

The Drive Select Register configures the pin driver as Open Drain or CMOS for some port pins, and controls the slew rate for the other port pins. An external pull-up resistor should be used for pins configured as Open Drain.

A pin can be configured as Open Drain if its corresponding bit in the Drive Select Register is set to a ‘1’. The default pin drive is CMOS.

Aside: the slew rate is a measurement of the rise and fall times of an output. A higher slew rate means a faster output response and may create more electrical noise. A pin operates in a high slew rate when the corresponding bit in the Drive Register is set to ‘1’. The default rate is slow slew.

Table 22 shows the Drive Register for Ports A, B, C, D, E and G. It summarizes which pins can be configured as Open Drain outputs and which pins the slew rate can be set for. Port F always has CMOS drive.

9.4.4 Port Data Registers

The Port Data Registers, shown in Table 23, are used by the microcontroller to write data to or read data from the ports. Table 23 shows the register name, the ports having each register type, and microcontroller access for each register type. The registers are described below.

9.4.4.1 Data In

Port pins are connected directly to the Data In buffer. In MCU I/O input mode, the pin input is read through the Data In buffer.

9.4.4.2 Data Out Register

Stores output data written by the MCU in the MCU I/O output mode. The contents of the Register are driven out to the pins if the Direction Register or the output enable product term is set to “1”. The contents of the register can also be read back by the microcontroller.

Data In A,B,C,D,E,F,G Read – input on pin

Data Out A,B,C,D,E,F,G Write/Read

Table 23. Port Data Registers

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.4.5 Ports A, B and C – Functionality and Structure

Ports A and B have similar functionality and structure, as shown in Figure 21. The two ports can be configured to perform one or more of the following functions:

❏ MCU I/O Mode ❏ GPLD Output – Combinatorial PLD outputs. ❏ PLD Input – Input to the PLDs. ❏ Address In – Additional high address inputs may be latched by ALE. ❏ Open Drain/Slew Rate – pins PC[7:0]can be configured to fast slew rate,

pins PA[7:0] and PB[7:0] can be configured to Open Drain Mode.

INTERNAL DATA BUS

DATA OUT

REG.

READ MUX

GPLD OUTPUT

PLD INPUT

DIR REG.

DATA IN

OUTPUT

SELECT

OUTPUT

MUX

PORT PIN

DATA OUT

Figure 21 Port A, B and C

PSD935G2 PSD9XX Family

The PSD935G2 Functional Blocks

(cont.)

9.4.6 Port D – Functionality and Structure

Port D has four I/O pins. See Figure 22. Port D can be configured to program one or more of the following functions:

❏ MCU I/O Mode ❏ PLD Input – direct input to PLD

Port D pins can be configured in PSDsoft as input pins for other dedicated functions:

❏ PD0 – ALE, as address strobe input ❏ PD1 – CLKIN, as clock input to the PLD and APD counter ❏ PD2 – CSI, as active low chip select input. A high input will disable the

Flash/SRAM and CSIOP.

❏ PD3 – DBE input from 68HC912

9.4.7 Port E – Functionality and Structure

Port E can be configured to perform one or more of the following functions (see Figure 23):

❏ MCU I/O Mode ❏ In-System Programming – JTAG port can be enabled for programming/erase of the

PSD935G2 device. (See Section 9.6 for more information on JTAG programming.) Pins that are configured as JTAG pins in PSDsoft will not be available for other I/O functions.

❏ Open Drain – Port E pins can be configured in Open Drain Mode ❏ Battery Backup features – PE6 can be configured as a Battery Input (Vstby) pin.

PE7 can be configured as a Battery On Indicator output pin, indicating when Vcc is less than Vbat.

❏ Latched Address Output – Provided latched address (A7-0) output

INTERNAL DATA BUS

DATA OUT

REG.

READ MUX

P D B

PLD INPUT

DIR REG.

DATA IN

OUTPUT SELECT

OUTPUT

MUX

PORT D PIN

DATA OUT

Figure 22. Port D Structure

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

INTERNAL DATA BUS

DATA OUT

REG.

DGQ

ADDRESS ALE

READ MUX

P D B

CONTROL REG.

DIR REG.

PLD INPUT (PORT F)

ISP OR BATTERY BACK-UP (PORT E)

DATA IN

OUTPUT SELECT

OUTPUT

MUX

PORT PIN

DATA OUT

ADDRESS

A[7:0] OR A[15:8

]

CONFIGURATION

BIT

Figure 23. Ports E, F and G Structure

9.4.8 Port F – Functionality and Structure

Port F can be configured to perform one or more of the following functions:

❏ MCU I/O Mode ❏ PLD Input – as direct input ot the PLD array. ❏ Address In – additional high address inputs. Direct input to the PLD array. ❏ Latched Address Out – Provide latched address out per Table 18. ❏ Slew Rate – pins can be set up for fast slew rate. ❏ Data Port – connected to D[7:0] when Port F is configured as Data Port for a

non-multiplexed bus.

9.4.9 Port G – Functionality and Structure

Port G can be configured to perform one or more of the following functions:

❏ MCU I/O Mode ❏ Latched Address Out – Provide latched address out per Table 18. ❏ Open Drain – pins can be configured in Open Drain Mode

PSD935G2 PSD9XX Family

9.5 Power Management

The PSD935G2 offers configurable power saving options. These options may be used individually or in combinations, as follows:

❏ All memory types in a PSD (Flash, Secondary Flash, and SRAM) are built with

Zero-Power technology. In addition to using special silicon design methodology, Zero-Power technology puts the memories into standby mode when address/data inputs are not changing (zero DC current). As soon as a transition occurs on an input, the affected memory “wakes up”, changes and latches its outputs, then goes back to standby. The designer does not have to do anything special to achieve memory standby mode when no inputs are changing—it happens automatically.

The PLD sections can also achieve standby mode when its inputs are not changing, see PMMR registers below.

❏ Like the Zero-Power feature, the Automatic Power Down (APD) logic allows the PSD to

reduce to standby current automatically. The APD will block MCU address/data signals from reaching the memories and PLDs. This feature is available on all PSD935G2 devices. The APD unit is described in more detail in section 9.5.1.

Built in logic will monitor the address strobe of the MCU for activity. If there is no activity for a certain time period (MCU is asleep), the APD logic initiates Power Down Mode (if enabled). Once in Power Down Mode, all address/data signals are blocked from reaching PSD memories and PLDs, and the memories are deselected internally. This allows the memories and PLDs to remain in standby mode even if the address/data lines are changing state externally (noise, other devices on the MCU bus, etc.). Keep in mind that any unblocked PLD input signals that are changing states keeps the PLD out of standby mode, but not the memories.

❏ The PSD Chip Select Input (CSI) can be used to disable the internal memories,

placing them in standby mode even if inputs are changing. This feature does not block any internal signals or disable the PLDs. This is a good alternative to using the APD logic, especially if your MCU has a chip select output. There is a slight penalty in memory access time when the CSI signal makes its initial transition from deselected to selected.

❏ The PMMR registers can be written by the MCU at run-time to manage power. All PSD

devices support “blocking bits” in these registers that are set to block designated signals from reaching both PLDs. Current consumption of the PLDs is directly related to the composite frequency of the changes on their inputs (see Figures 27 and 27a). Significant power savings can be achieved by blocking signals that are not used in PLD logic equations at run time. PSDsoft creates a fuse map that automatically blocks the low address byte (A7-A0) or the control signals (CNTL0-2, ALE and WRH/DBE) if none of these signals are used in PLD logic equations.

The PSD935G2 devices have a Turbo Bit in the PMMR0 register. This bit can be set to disable the Turbo Mode feature (default is Turbo Mode on). While Turbo Mode is disabled, the PLDs can achieve standby current when no PLD inputs are changing (zero DC current). Even when inputs do change, significant power can be saved at lower frequencies (AC current), compared to when Turbo Mode is enabled. Conversely, when the Turbo Mode is enabled, there is a significant DC current component and the AC component is higher.

9.5.1 Automatic Power Down (APD) Unit and Power Down Mode

The APD Unit, shown in Figure 24, puts the PSD into Power Down Mode by monitoring the activity of the address strobe (ALE/AS). If the APD unit is enabled, as soon as activity on the address strobe stops, a four bit counter starts counting. If the address strobe remains inactive for fifteen clock periods of the CLKIN signal, the Power Down (PDN) signal becomes active, and the PSD will enter into Power Down Mode, discussed next.

The PSD935G2 Functional Blocks

(cont.)

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

Access 5V VCC,

PLD Memory Recovery Time Typical

Propagation Access to Normal Standby

Mode Delay Time Access Current

Power Down

Normal t pd

No Access tLVDV

50 µA

(Note 1) (Note 2)

Table 25. PSD935G2 Timing and Standby Current During Power

Down Mode

NOTES: 1. Power Down does not affect the operation of the PLD. The PLD operation in this

mode is based only on the Turbo Bit.

2. Typical current consumption assuming no PLD inputs are changing state and the PLD Turbo bit is off.

Port Function Pin Level

MCU I/O No Change PLD Out No Change Address Out Undefined Data Port Three-State Peripheral I/O Three-State

Table 24. Power Down Mode’s Effect on

Ports

9.5.1 Automatic Power Down (APD) Unit and Power Down Mode (cont.) Power Down Mode

By default, if you enable the PSD APD unit, Power Down Mode is automatically enabled. The device will enter Power Down Mode if the address strobe (ALE/AS) remains inactive for fifteen CLKIN (pin PD1) clock periods.

The following should be kept in mind when the PSD is in Power Down Mode:

• If the address strobe starts pulsing again, the PSD will return to normal operation.

The PSD will also return to normal operation if either the CSI input returns low or the Reset input returns high.

• The MCU address/data bus is blocked from all memories and PLDs.

• Various signals can be blocked (prior to Power Down Mode) from entering the PLDs

by setting the appropriate bits in the PMMR registers. The blocked signals include MCU control signals and the common clock (CLKIN). Note that blocking CLKIN from the PLDs will not block CLKIN from the APD unit.

• All PSD memories enter Standby Mode and are drawing standby current. However,

the PLDs and I/O ports do not go into Standby Mode because you don’t want to have to wait for the logic and I/O to “wake-up” before their outputs can change. See Table 24 for Power Down Mode effects on PSD ports.

• Typical standby current is 50 µA for 5 V parts. This standby current value assumes

that there are no transitions on any PLD input.

PSD935G2 PSD9XX Family

APD EN PMMR0 BIT 1=1

ALE

RESET

CSI

CLKIN

TRANSITION

DETECTION

EDGE

DETECT

APD

COUNTER

POWER DOWN (

PDN

)

DISABLE BUS INTERFACE

SECONDARY FLASH SELECT

MAIN FLASH SELECT

SRAM SELECT

CLR

DISABLE MAIN AND

SECONDARY FLASH/SRAM

PLD

SELECT

Figure 24. APD Logic Block

The PSD935G2 Functional Blocks

(cont.)

Enable APD

Set PMMR0 Bit 1 = 1

PSD in Power

Down Mode

ALE/AS idle

for 15 CLKIN

clocks?

RESET

Yes

OPTIONAL

Disable desired inputs to PLD

by setting PMMR0 bit 4

and PMMR2 bits 0.

Figure 25. Enable Power Down Flow Chart

PSD9XX Family PSD935G2

Bit 1 0 = Automatic Power Down (APD) is disabled.

1 = Automatic Power Down (APD) is enabled.

Bit 3 0 = PLD Turbo is on.

1 = PLD Turbo is off, saving power.

Bit 4 0 = CLKIN input to the PLD AND array is connected.

Every CLKIN change will power up the PLD when Turbo bit is off.

1 = CLKIN input to PLD AND array is disconnected, saving power.

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

***

PLD PLD

APD

Array clk Turbo Enable

1 = off 1 = off 1 = on

Table 26. Power Management Mode Registers (PMMR0, PMMR2)**

PMMR0

***Bits 0, 2, 6, and 7 are not used, and should be set to 0, bit 5 should be set to 1. ***The PMMR0, and PMMR2 register bits are cleared to zero following power up.

***Subsequent reset pulses will not clear the registers.

The PSD935G2 Functional Blocks

(cont.)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PLD PLD PLD** PLD** PLD**

PLD

array array array array array array

DBE ALE CNTL2 CNTL1 CNTL0 Addr.

1 = off 1 = off 1 = off 1 = off 1 = off 1 = off

PMMR2

Bit 0 0 = Address A[7:0] inputs to the PLD AND array are connected.

1 = Address A[7:0] inputs to the PLD AND array are disconnected, saving power.

Note: In 80C51XA mode, A[7:1] comes from Port F (PF1-PF3) and AD10 [3:0].

Bit 2 0 = Cntl0 input to the PLD AND array is connected.

1 = Cntl0 input to PLD AND array is disconnected, saving power.

Bit 3 0 = Cntl1 input to the PLD AND array is connected.

1 = Cntl1 input to PLD AND array is disconnected, saving power.

Bit 4 0 = Cntl2 input to the PLD AND array is connected.

1 = Cntl2 input to PLD AND array is disconnected, saving power.

Bit 5 0 = ALE input to the PLD AND array is connected.

1 = ALE input to PLD AND array is disconnected, saving power.

Bit 6 0 = DBE input to the PLD AND array is connected.

1 = DBE input to PLD AND array is disconnected, saving power.

**Unused bits should be set to 0.

**Refer to Table 14 the signals that are blocked on pins CNTL0-2.

PSD935G2 PSD9XX Family

APD ALE

Enable Bit PD Polarity ALE Level APD Counter

0 X X Not Counting 1 X Pulsing Not Counting 1 1 1 Counting (Generates PDN after 15 Clocks) 1 0 0 Counting (Generates PDN after 15 Clocks)

Table 27. APD Counter Operation

The PSD935G2 Functional Blocks

(cont.)

9.5.2 Other Power Saving Options

The PSD935G2 offers other reduced power saving options that are independent of the Power Down Mode. Except for the SRAM Standby and CSI input features, they are enabled by setting bits in the PMMR0 and PMMR2 registers.

9.5.2.1 Zero Power PLD

The power and speed of the PLDs are controlled by the Turbo bit (bit 3) in the PMMR0. By setting the bit to “1”, the Turbo mode is disabled and the PLDs consume Zero Power current when the inputs are not switching for an extended time of 70 ns. The propagation delay time will be increased after the Turbo bit is set to “1” (turned off) when the inputs change at a composite frequency of less than 15 MHz. When the Turbo bit is set to a “0” (turned on), the PLDs run at full power and speed. The Turbo bit affects the PLD’s D.C. power, AC power, and propagation delay. Refer to AC/DC spec for PLD timings.

Note: Blocking MCU control signals with PMMR2 bits can further reduce PLD AC power consumption.

9.5.2.2 SRAM Standby Mode (Battery Backup)

The PSD935G2 supports a battery backup operation that retains the contents of the SRAM in the event of a power loss. The SRAM has a Vstby pin (PE6) that can be connected to an external battery. When VCCbecomes lower than Vstby then the PSD will automatically connect to Vstby as a power source to the SRAM. The SRAM Standby Current (Istby) is typically 0.5 µA. The SRAM data retention voltage is 2 V minimum. The battery-on indicator (Vbaton) can be routed to PE7. This signal indicates when the VCChas dropped below the Vstby voltage and that the SRAM is running on battery power.

9.5.2.3 The CSI Input

Pin PD2 of Port D can be configured in PSDsoft as the CSI input. When low, the signal selects and enables the internal Flash, Boot Block, SRAM, and I/O for read or write operations involving the PSD935G2. A high on the CSI pin will disable the Flash memory, Boot Block, and SRAM, and reduce the PSD power consumption. However, the PLD and I/O pins remain operational when CSI is high. Note: there may be a timing penalty when using the CSI pin depending on the speed grade of the PSD that you are using. See the timing parameter t

SLQV

in the AC/DC specs.

9.5.2.4 Input Clock

The PSD935G2 provides the option to turn off the CLKIN input to the PLD AND array to save AC power consumption. During Power Down Mode, or, if the CLKIN input is not being used as part of the PLD logic equation, the clock should be disabled to save AC power. The CLKIN will be disconnected from the PLD AND array by setting bit 4 to a “1” in PMMR0.

9.5.2.5 MCU Control Signals

The PSD935G2 provides the option to turn off the address input (A7-0) and input control signals (CNTL0-2, ALE, and DBE) to the PLD to save AC power consumption. These signals are inputs to the PLD AND array. During Power Down Mode, or, if any of them are not being used as part of the PLD logic equation, these control signals should be disabled to save AC power. They will be disconnected from the PLD AND array by setting bits 0, 2, 3, 4, 5, and 6 to a “1” in the PMMR2.

PSD9XX Family PSD935G2

The PSD935G2 Functional Blocks

(cont.)

9.5.3 Reset and Power On Requirement

9.5.3.1 Power On Reset

Upon power up the PSD935G2 requires a reset pulse of tNLNH-PO (minimum 1 ms) after VCCis steady. During this time period the device loads internal configurations, clears some of the registers and sets the Flash into operating mode. After the rising edge of reset, the PSD935G2 remains in the reset state for an additional tOPR (maximum 120 ns) nanoseconds before the first memory access is allowed.

The PSD935G2 Flash memory is reset to the read array mode upon power up. The FSi and CSBOOTi select signals along with the write strobe signal must be in the false state during power-up reset for maximum security of the data contents and to remove the possibility of data being written on the first edge of a write strobe signal. Any Flash memory write cycle initiation is prevented automatically when VCCis below VLKO.

9.5.3.2 Warm Reset

Once the device is up and running, the device can be reset with a much shorter pulse of tNLNH (minimum 150 ns). The same t OPR time is needed before the device is operational after warm reset. Figure 26 shows the timing of the power on and warm reset.

OPERATING LEVEL

POWER ON RESET

RESET

NLNH–PO

OPR

NLNH-A

NLNH

OPR

WARM RESET

Figure 26. Power On and Warm Reset Timing

9.5.3.3 I/O Pin, Register and PLD Status at Reset

Table 28 shows the I/O pin, register and PLD status during power on reset, warm reset and power down mode. PLD outputs are always valid during warm reset, and they are valid in power on reset once the internal PSD configuration bits are loaded. This loading of PSD is completed typically long before the VCCramps up to operating level. Once the PLD is active, the state of the outputs are determined by the equations specified in PSDsoft.

9.5.3.4 Reset of Flash Erase and Programming Cycles

An external reset on the RESET pin will also reset the internal Flash memory state machine. When the Flash is in programming or erase mode, the RESET pin will terminate the programming or erase operation and return the Flash back to read mode in tNLNH-A (minimum 25 µs) time.

9.6 Programming In-Circuit using the JTAG-ISP Interface

The JTAG-ISP interface on the PSD935G2 can be enabled on Port E (see Table 29). All memory (Flash and Flash Boot Block), PLD logic, and PSD configuration bits may be programmed through the JTAG-ISC interface. A blank part can be mounted on a printed circuit board and programmed using JTAG-ISP.

The standard JTAG signals (IEEE 1149.1) are TMS, TCK, TDI, and TDO. Two additional signals, TSTAT and TERR, are optional JTAG extensions used to speed up program and erase operations.

PSD935G2 PSD9XX Family

Port E Pin JTAG Signals Description

PE0 TMS Mode Select PE1 TCK Clock PE2 TDI Serial Data In PE3 TDO Serial Data Out PE4 TSTAT Status PE5 TERR Error Flag

Table 29. JTAG Port Signals

The PSD935G2 Functional Blocks

(cont.)

*SR_cod bit in the VM Register are always cleared to zero on power on or warm reset.

Port Configuration Power On Reset Warm Reset Power Down Mode

MCU I/O Input Mode Input Mode Unchanged PLD Output Valid after internal Valid Depend on inputs to

PSD configuration PLD (address are

bits are loaded blocked in PD mode) Address Out Tri-stated Tri-stated Not defined Data Port Tri-stated Tri-stated Tri-stated

Table 28. Status During Power On Reset, Warm Reset and Power Down Mode

PMMR0, 2 Cleared to “0” Unchanged Unchanged VM Register* Initialized based on Initialized based on Unchanged

the selection in the selection in PSDsoft PSDsoft Configuration Menu. Configuration Menu.

All other registers Cleared to “0” Cleared to “0” Unchanged

By default, on a blank PSD (as shipped from factory or after erasure), four pins on Port E are enabled for the basic JTAG signals TMS, TCK, TDI, and TDO.

See ST Application Note AN1153 for more details on JTAG In-System-Programming.

PSD9XX Family PSD935G2

9.6.1 Standard JTAG Signals

The JTAG configuration bit (non-volatile) inside the PSD can be set by the user in the PSDsoft. Once this bit is set and programmed in the PSD, the JTAG pins are dedicated to JTAG at all times and is in compliance with IEEE 1149.1. After power up the standard JTAG signals (TDI, TDO TCK and TMS) are inputs, waiting for a serial command from an external JTAG controller device (such as FlashLink or Automated Test Equipment). When the enabling command is received from the external JTAG controller, TDO becomes an output and the JTAG channel is fully functional inside the PSD. The same command that enables the JTAG channel may optionally enable the two additional JTAG pins, TSTAT and TERR.

The PSD935G2 supports JTAG ISP commands, but not Boundary Scan. ST’s PSDsoft software tool and FlashLink JTAG programming cable implement these JTAG-ISP commands.

9.6.2 JTAG Extensions

TSTAT and TERR are two JTAG extension signals enabled by a JTAG command received over the four standard JTAG pins (TMS, TCK, TDI, and TDO). They are used to speed programming and erase functions by indicating status on PSD pins instead of having to scan the status out serially using the standard JTAG channel. See Application Note 54.

TERR will indicate if an error has occurred when erasing a sector or programming a byte in Flash memory. This signal will go low (active) when an error condition occurs, and stay

low until a special JTAG command is executed or a chip reset pulse is received after an “ISC-DISABLE” command.

TSTAT behaves the same as the Rdy/Bsy signal described in section 9.1.1.3. TSTAT will be high when the PSD935G2 device is in read array mode (Flash memory and Boot Block contents can be read). TSTAT will be low when Flash memory programming or erase cycles are in progress, and also when data is being written to the Secondary Flash Block.

TSTAT and TERR can be configured as open-drain type signals with a JTAG command.

9.6.3 Security and Flash Memories Protection

When the security bit is set, the device cannot be read on a device programmer or through the JTAG Port. When using the JTAG Port, only a full chip erase command is allowed. All other program/erase/verify commands are blocked. Full chip erase returns the part to a non-secured blank state. The Security Bit can be set in PSDsoft.

All Flash Memory and Boot sectors can individually be sector protected against erasures. The sector protect bits can be set in PSDsoft.

The PSD935G2 Functional Blocks

(cont.)

PSD935G2 PSD9XX Family

Range Temperature VCCTolerance

Commercial 0° C to +70°C + 5 V ± 10% Industrial –40° C to +85°C + 5 V ± 10% Commercial 0° C to +70°C 3.0 V to 3.6 V Industrial –40° C to +85°C 3.0 V to 3.6 V

Symbol Parameter Condition Min Max Unit

STG

Storage Temperature PLDCC – 65 + 125 °C

Commercial 0 + 70 °C

Operating Temperature

Industrial – 40 + 85 °C

Voltage on any Pin With Respect to GND – 0.6 + 7 V

Device Programmer Supply Voltage

With Respect to GND – 0.6 + 14 V

Supply Voltage With Respect to GND – 0.6 + 7 V ESD Protection >2000 V

10.0 Absolute Maximum Ratings

NOTE: Stresses above those listed under Absolute Maximum Ratings may cause permanent

damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not recommended. Exposure to Absolute Maximum Rating conditions for extended periods of time may affect device reliability.

Symbol Parameter Condition Min Typ Max Unit

Supply Voltage All Speeds 4.5 5 5.5 V

Supply Voltage

V-Versions All Speeds

3.0 3.6 V

12.0 Recommended Operating Conditions

11.0 Operating Range

PSD9XX Family PSD935G2 Beta Information

AC/DC Parameters

The following tables describe the AD/DC parameters of the PSD9XX family:

❏ DC Electrical Specification ❏ AC Timing Specification

• PLD Timing

– Combinatorial Timing

• Microcontroller Timing

– Read Timing – Write Timing – Power Down and Reset Timing

Following are issues concerning the parameters presented:

❏ In the DC specification the supply current is given for different modes of operation.

Before calculating the total power consumption, determine the percentage of time that the PSD9XX is in each mode. Also, the supply power is considerably different if the Turbo bit is "OFF".

❏ The AC power component gives the PLD, Flash memory, and SRAM mA/MHz

specification. Figures 27 and 27a show the PLD mA/MHz as a function of the number of Product Terms (PT ) used.

❏ In the PLD timing parameters, add the required delay when Turbo bit is "OFF".

Figure 27. PLD ICC/FrequencyConsumption (V

= 5 V ± 10%)

100

110

= 5V

010155 20 25

HIGHEST COMPOSITE FREQUENCY AT PLD INPUTS (MHz)

– (mA)

TURBO ON (100%)

TURBO ON (25%)

TURBO OFF

PT 100% PT 25%

PSD935G2 PSD9XX Family

Figure 27a. PLD ICC/Frequency Consumption (PSD935G2V Versions, V

= 3 V)

= 3V

010155 20 25

– (mA)

TURBO ON (100%)

TURBO ON (25%)

TURBO OFF

HIGHEST COMPOSITE FREQUENCY AT PLD INPUTS (MHz)

PT 100% PT 25%

Conditions

Highest Composite PLD input frequency

(Freq PLD) = 8 MHz

MCU ALE frequency (Freq ALE) = 4 MHz

% Flash Access = 80% % SRAM access = 15% % I/O access = 5% (no additional power above base)

Operational Modes

% Normal = 10% % Power Down Mode = 90%

Number of product terms used

(from fitter report) = 45 PT % of total product terms = 45/176 = 25.5%

Turbo Mode = ON

Calculation (typical numbers used)

total = Ipwrdown x %pwrdown + %normal x (ICC(ac) + ICC(dc))

= Ipwrdown x %pwrdown + % normal x (%flash x 2.5 mA/MHz x Freq ALE

+ %SRAM x 1.5 mA/MHz x Freq ALE + % PLD x 2 mA/MHz x Freq PLD + #PT x 400 µA/PT

= 50 µA x 0.90 + 0.1 x (0.8 x 2.5 mA/MHz x 4 MHz

+ 0.15 x 1.5 mA/MHz x 4 MHz +2 mA/MHz x 8 MHz + 45 x 0.4 mA/PT)

= 45 µA + 0.1 x (8 + 0.9 + 16 + 18 mA) = 45 µA + 0.1 x 42.9 = 45 µA + 4.29 mA

= 4.34 mA

This is the operating power with no Flash writes or erases. Calculation is based on I

OUT

= 0 mA.

Example of PSD935G2 Typical Power Calculation at VCC= 5.0 V

AC/DC Parameters

(cont.)

PSD9XX Family PSD935G2

Conditions

Highest Composite PLD input frequency

(Freq PLD) = 8 MHz

MCU ALE frequency (Freq ALE) = 4 MHz

% Flash Access = 80% % SRAM access = 15% % I/O access = 5% (no additional power above base)

Operational Modes

% Normal = 10% % Power Down Mode = 90%

Number of product terms used

(from fitter report) = 45 PT % of total product terms = 45/176 = 25.5%

Turbo Mode = Off

Calculation (typical numbers used)

total = Ipwrdown x %pwrdown + %normal x (ICC(ac) + ICC(dc))

= Ipwrdown x %pwrdown + % normal x (%flash x 2.5 mA/MHz x Freq ALE

+ %SRAM x 1.5 mA/MHz x Freq ALE + % PLD x (from graph using Freq PLD))

= 50 µA x 0.90 + 0.1 x (0.8 x 2.5 mA/MHz x 4 MHz

+ 0.15 x 1.5 mA/MHz x 4 MHz

+ 24 mA) = 45 µA + 0.1 x (8 + 0.9 + 24) = 45 µA + 0.1 x 32.9 = 45 µA + 3.29 mA

= 3.34 mA

This is the operating power with no Flash writes or erases. Calculation is based on I

OUT

= 0 mA.

Example of Typical Power Calculation at VCC= 5.0 V in Turbo Off Mode

AC/DC Parameters

(cont.)

PSD935G2 PSD9XX Family

NOTE: 1. Reset input has hysteresis. V

IL1

is valid at or below .2VCC–.1. V

IH1

is valid at or above .8VCC.

2. CSI deselected or internal Power Down mode is active.

3. PLD is in non-turbo mode and none of the inputs are switching

4. Refer to Figure 32 for PLD current calculation.

5. IO= 0 mA

Symbol Parameter Conditions Min Typ Max Unit

Supply Voltage All Speeds 4.5 5 5.5 V

High Level Input Voltage 4.5 V < VCC< 5.5 V 2 VCC+.5 V

Low Level Input Voltage 4.5 V < VCC< 5.5 V –.5 0.8 V

IH1

Reset High Level Input Voltage (Note 1) .8 V

VCC+.5 V

IL1

Reset Low Level Input Voltage (Note 1) –.5 .2 V

–.1 V

HYS

Reset Pin Hysteresis 0.3 V

LKO

VCCMin for Flash Erase and Program 2.5 4.2 V

Output Low Voltage

= 20 µA, VCC= 4.5 V 0.01 0.1 V

IOL= 8 mA, VCC= 4.5 V 0.25 0.45 V

Output High Voltage Except V

STBY

= –20 µA, VCC= 4.5 V 4.4 4.49 V

IOH= –2 mA, VCC= 4.5 V 2.4 3.9 V

Output High Voltage V

STBY

On I

= –1 µA V

SBY

– 0.8 V

SBY

SRAM Standby Voltage 2.0 V

SBY

SRAM Standby Current (V

STBY

Pin) VCC= 0 V 0.5 1 µA

IDLE

Idle Current (V

STBY

Pin) VCC> V

SBY

–0.1 0.1 µA

SRAM Data Retention Voltage Only on V

STBY

Standby Supply Current for Power CSI > VCC–0.3 V

100 200 µA

Down Mode (Notes 2, 3 and 5)

Input Leakage Current VSS< V

< V

–1 ±.1 1 µA

Output Leakage Current 0.45 < V

< V

–10 ±5 10 µA

Output Current

Refer to I

and IOHin

the V

and VOHrow

PLD_TURBO = OFF,

0mA

f = 0 MHz (Note 3)

PLD Only

PLD_TURBO = ON, f = 0 MHz

400 700 µA/PT

(DC) Operating Supply

During Flash Write/Erase

(Note 5) Current

Flash

Only

15 30 mA

Read Only, f = 0 MHz 0 0 mA

SRAM f = 0 MHz 0 0 mA

PLD AC Base

Fig. 27

(AC)

(Note 4)

(Note 5) FLASH AC Adder 2.5 3.5 mA/MHz

SRAM AC Adder 1.5 3.0 mA/MHz

PSD935G2 DC Characteristics (5 V ± 10% Versions)

PSD9XX Family PSD935G2

AC Symbols for PLD Timing. Example:

AVLX

– Time from Address Valid to ALE Invalid.

Signal Letters

A – Address Input C – CEout Output D – Input Data E – E Input I – Interrupt Input L – ALE Input N – Reset Input or Output P – Port Signal Output R – UDS, LDS, DS, RD, PSEN Inputs S – Chip Select Input T–R/W Input W–WR Input B–Vstby Output M – Output Micro⇔Cell

Signal Behavior

t – Time L – Logic Level Low or ALE H – Logic Level High V – Valid X – No Longer a Valid Logic Level Z – Float PW – Pulse Width

Microcontroller Interface – AC/DC Parameters

(5V ±10% Versions)

-70 -90

Turbo

Symbol Parameter Conditions Min Max Min Max Off Unit

LVLX

ALE or AS Pulse Width 15 20 ns

AVLX

Address Setup Time (Note 3) 4 6 ns

LXAX

Address Hold Time (Note 3) 7 8 ns

AVQV

Address Valid to Data Valid (Note 3) 70 90 Add 12 ns

SLQV

CS Valid to Data Valid 75 100 ns RD to Data Valid (Note 5) 24 32 ns

RLQV

RD or PSEN to Data Valid, 80C51 Mode

(Note 2) 31 38 ns

RHQX

RD Data Hold Time (Note 1) 0 0 ns

RLRH

RD Pulse Width (Note 1) 27 32 ns

RHQZ

RD to Data High-Z (Note 1) 20 25 ns

EHEL

E Pulse Width 27 32 ns

THEH

R/W Setup Time to Enable 6 10 ns

ELTL

R/W Hold Time After Enable 0 0 ns

AVPV

Address Input Valid to Address

(Note 4) 20 25 ns

Output Delay

PSD935G2 PSD9XX Family

NOTES: 1. RD timing has the same timing as DS and PSEN signals.

2. RD and PSEN have the same timing.

3. Any input used to select an internal PSD935G2 function.

4. In multiplexed mode, latched addresses generated from ADIO delay to address output on any Port.

5. RD timing has the same timing as DS signals.

Read Timing (5 V ± 10% Versions)

Microcontroller Interface – PSD935G2 AC/DC Parameters

(5V ±10% Versions)

PSD9XX Family PSD935G2

-70 -90

Symbol Parameter Conditions Min Max Min Max Unit

LVLX

ALE or AS Pulse Width 15 20

AVLX

Address Setup Time (Note 1) 4 6 ns

LXAX

Address Hold Time (Note 1) 7 8 ns

AVWL

Address Valid to Leading Edge of WR

(Notes 1 and 3) 8 15 ns

SLWL

CS Valid to Leading Edge of WR (Note 3) 12 15 ns

DVWH

WR Data Setup Time (Note 3) 25 35 ns

WHDX

WR Data Hold Time (Note 3) 4 5 ns

WLWH

WR Pulse Width (Note 3) 28 35 ns

WHAX1

Trailing Edge of WR to Address Invalid

(Note 3) 6 8 ns

WHAX2

Trailing Edge of WR to DPLD Address Input Invalid

(Note 3 and 4) 0 0 ns

WHPV

Trailing Edge of WR to Port Output Valid Using I/O Port Data Register

(Note 3) 27 30 ns

AVPV

Address Input Valid to Address

(Note 2) 20 25 ns

Output Delay

Write Timing (5 V ± 10% Versions)

NOTES: 1. Any input used to select an internal PSD935G2 function.

2. In multiplexed mode, latched addresses generated from ADIO delay to address output on any Port.

3. WR timing has the same timing as E, DS signals.

4. t

WHAX2

is Address Hold Time for DPLD inputs that are used to generate chip selects for internal PSD memory.

Microcontroller Interface – PSD935G2 AC/DC Parameters

(5V ±10% Versions)

-70 -90 Slew

TURBO Rate

Symbol Parameter Conditions Min Max Min Max OFF

(Note 1) Unit

PLD Input Pin/Feedback to

20 25 Add 12 Sub 2 ns

PLD Combinatorial Output

ARD

PLD Array Delay 11 16 ns

PLD Combinatorial Timing (5 V ± 10%)

NOTE: 1. Fast Slew Rate output available on Port C and F.

PSD935G2 PSD9XX Family

Symbol Parameter Conditions Min Typ Max Unit

NLNH

Warm RESET Active Low Time (Note 1) 150 ns

OPR

RESET High to Operational Device 120 ns

NLNH-PO

Power On Reset Active Low Time 1 ms

NLNH-A

Warm RESET Active Low Time (Note 2)

25 µs

Reset Pin Timing (5 V ± 10%)

NOTE: 1. t

CLCL

is the CLKIN clock period.

Microcontroller Interface – PSD935G2 AC/DC Parameters

(5V ±10% Versions)

Symbol Parameter Conditions Min Typ Max Unit

BVBH

Vstby Detection to Vstbyon Output High (Note 1) 20 µs

BXBL

stby

Off Detection to V

stbyon

Output Low

(Note 1) 20 µs

stbyon

Timing (5 V ± 10%)

-70 -90

Symbol Parameter Conditions Min Max Min Max Unit

LVDV

ALE Access Time from Power Down

80 90 ns

Maximum Delay from APD Enable

Using CLKIN Input 15 * t

CLCL

(µs) (Note 1) µs

CLWH

to Internal PDN Valid Signal

Power Down Timing (5 V ± 10%)

NOTE: 1. RESET will not abort Flash programming/erase cycles.

2. RESET will abort Flash programming or erase cycle.

NOTE: 1. Vstbyon is measured at VCCramp rate of 2 ms.

PSD9XX Family PSD935G2

-70 -90

Symbol Parameter Conditions Min Max Min Max Unit

ISCCF

TCK Clock Frequency (except for PLD) (Note 1) 20 18 MHz

ISCCH

TCK Clock High Time (Note 1) 23 26 ns

ISCCL

TCK Clock Low Time (Note 1) 23 26 ns

ISCCF-P

TCK Clock Frequency (for PLD only) (Note 2) 2 2 MHz

ISCCH-P

TCK Clock High Time (for PLD only) (Note 2) 240 240 ns

ISCCL-P

TCK Clock Low Time (for PLD only) (Note 2) 240 240 ns

ISCPSU

ISC Port Set Up Time 6 8 ns

ISCPH

ISC Port Hold Up Time 5 5 ns

ISCPCO

ISC Port Clock to Output 21 23 ns

ISCPZV

ISC Port High-Impedance to Valid Output 21 23 ns

ISCPVZ

ISC Port Valid Output to High-Impedance

21 23 ns

ISC Timing (5 V ± 10%)

Microcontroller Interface – PSD935G2 AC/DC Parameters

(5V ±10% Versions)

Symbol Parameter Min Typ Max Unit

Flash Program 8.5 sec Flash Bulk Erase (Preprogrammed to 00) (Note 1) 3 30 sec Flash Bulk Erase 10 sec

WHQV3

Sector Erase (Preprogrammed to 00) 1 30 sec

WHQV2

Sector Erase 2.2 sec

WHQV1

Word Program 14 1200 µs Program/Erase Cycles (Per Sector) 100,000 cycles

WHWLO

Sector Erase Time-Out 100 µs

Q7VQV

DQ7 Valid to Output Valid (Data Polling) (Note 2) 30 ns

Flash Program, Write and Erase Times (5 V ± 10%)

NOTE: 1. Programmed to all zeros before erase.

2. The polling status DQ7 is valid tQ7VQV ns before the data DQ0-7 is valid for reading.

NOTES: 1. For “non-PLD” programming, erase or in ISC by-pass mode.

2. For program or erase PLD only.

PSD935G2 PSD9XX Family

Symbol Parameter Conditions Min Typ Max Unit

Supply Voltage All Speeds 3.0 3.6 V

High Level Input Voltage 3.0 V < VCC< 3.6 V .7 V

VCC+.5 V

Low Level Input Voltage 3.0 V < VCC< 3.6 V –.5 0.8 V

IH1

Reset High Level Input Voltage (Note 1) .8 V

VCC+.5 V

IL1

Reset Low Level Input Voltage (Note 1) –.5 .2 V

–.1 V

HYS

Reset Pin Hysteresis 0.3 V

LKO

VCCMin for Flash Erase and Program 1.5 2.3 V

Output Low Voltage

= 20 µA, VCC= 3.0 V 0.01 0.1 V

IOL= 4 mA, VCC= 3.0 V 0.15 0.45 V

Output High Voltage Except V

STBY

= –20 µA, VCC= 3.0 V 2.9 2.99 V

IOH= –1 mA, VCC= 3.0 V 2.7 2.8 V

Output High Voltage V

STBY

On I

= 1 µA V

SBY

– 0.8 V

SBY

SRAM Standby Voltage 2.0 V

SBY

SRAM Standby Current (V

STBY

Pin) VCC= 0 V 0.5 1 µA

IDLE

Idle Current (V

STBY

Pin) VCC> V

SBY

–0.1 0.1 µA

SRAM Data Retention Voltage Only on V

STBY

Standby Supply Current CSI >VCC–0.3 V

50 100 µA

for Power Down Mode (Notes 2 and 3)

Input Leakage Current VSS< V

< V

–1 ±.1 1 µA

Output Leakage Current 0.45 < V

< V

–10 ±5 10 µA

Output Current

Refer to I

and IOHin

the V

and VOHrow

PLD_TURBO = OFF, f = 0 MHz (Note 3)

0mA

PLD Only

PLD_TURBO = ON,

ICC(DC) Operating

f = 0 MHz

200 400 µA/PT

(Note 5) Supply Current During FLASH

FLASH Write/Erase Only

10 25 mA

Read Only, f = 0 MHz 0 0 mA

SRAM f = 0 MHz 0 0 mA

PLD AC Base (Note 4) Figure 27a

(AC) FLASH

(Note 5) AC Adder 1.5 2.0 mA/MHz

SRAM AC Adder 0.8 1.5 mA/MHz

PSD935G2 DC Characteristics (3.0 V to 3.6 V Versions) Advance Information

NOTES: 1. Reset input has hysteresis. V

IL1

is valid at or below .2VCC–.1. V

IH1

is valid at or above .8VCC.

2. CSI deselected or internal PD mode is active.

3. PLD is in non-turbo mode and none of the inputs are switching.

4. Refer to Figure 31a for PLD current calculation.

5. IO= 0 mA.

PSD9XX Family PSD935G2

AC Symbols for PLD Timing. Example:

AVLX

– Time from Address Valid to ALE Invalid.

Signal Letters

A – Address Input C – CEout Output D – Input Data E – E Input L – ALE Input N – Reset Input or Output P – Port Signal Output Q – Output Data R – WR, UDS, LDS, DS, IORD, PSEN Inputs S – Chip Select Input T–R/W Input W–Internal PDN Signal B–Vstby Output

Signal Behavior

t – Time L – Logic Level Low or ALE H – Logic Level High V – Valid X – No Longer a Valid Logic Level Z – Float PW – Pulse Width

Microcontroller Interface – PSD935G2 AC/DC Parameters

(3.0 V to 3.6 V Versions)

PSD935G2 PSD9XX Family

-90 -12

Turbo

Symbol Parameter Conditions Min Max Min Max Off Unit

LVLX

ALE or AS Pulse Width 22 24 ns

AVLX

Address Setup Time (Note 3) 7 9 ns

LXAX

Address Hold Time (Note 3) 8 10 ns

AVQV

Address Valid to Data Valid (Note 3) 90 120 Add 20** ns

SLQV

CS Valid to Data Valid 90 120 ns RD to Data Valid (Note 5) 35 35 ns

RLQV

RD or PSEN to Data Valid, 80C51 Mode

(Note 2) 45 48 ns

RHQX

RD Data Hold Time (Note 1) 0 0 ns

RLRH

RD Pulse Width (Note 1) 36 40 ns

RHQZ

RD to Data High-Z (Note 1) 38 40 ns

EHEL

E Pulse Width 38 42 ns

THEH

R/W Setup Time to Enable 10 16 ns

ELTL

R/W Hold Time After Enable 0 0 ns

AVPV

Address Input Valid to

(Note 4) 30 35 ns

Address Output Delay

Read Timing (3.0 V to 3.6 V Versions)

Microcontroller Interface – PSD935G2 AC/DC Parameters

(3.0 V to 3.6 V Versions)

NOTES: 1. RD timing has the same timing as DS and PSEN signals.

2. RD and PSEN have the same timing for 80C51.

3. Any input used to select an internal PSD4135G2V function.

4. In multiplexed mode latched address generated from ADIO delay to address output on any Port.

5. RD timing has the same timing as DS signals.

PSD9XX Family PSD935G2

-90 -12 Slew

TURBO Rate

Symbol Parameter Conditions Min Max Min Max OFF

(Note 1) Unit

PLD Input Pin/Feedback to

38 43 Add 20 Sub 6 ns

PLD Combinatorial Output

ARD

PLD Array Delay 23 27 ns

PLD Combinatorial Timing (5 V ± 10%)

NOTE: 1. Fast Slew Rate output available on Port C and F.

-90 -12

Symbol Parameter Conditions Min Max Min Max Unit

LVLX

ALE or AS Pulse Width 22 24

AVLX

Address Setup Time (Note 1) 7 9 ns

LXAX

Address Hold Time (Note 1) 8 10 ns

AVWL

Address Valid to Leading Edge of WR

(Notes 1 and 3) 15 18 ns

SLWL

CS Valid to Leading Edge of WR (Note 3) 15 18 ns

DVWH

WR Data Setup Time (Note 3) 40 45 ns

WHDX

WR Data Hold Time (Note 3) 5 8 ns

WLWH

WR Pulse Width (Note 3) 40 45 ns

WHAX1

Trailing Edge of WR to Address Invalid (Note 3) 8 10 ns

WHAX2

Trailing Edge of WR to DPLD Address

(Notes 3 and 4) 0 0 ns

Input Invalid

WHPV

Trailing Edge of WR to Port Output Valid Using I/O Port Data Register

(Note 3) 33 33 ns

AVPV

Address Input Valid to Address

(Note 2) 30 35 ns

Output Delay

Write Timing (3.0 V to 3.6 V Versions)

NOTES: 1. Any input used to select an internal PSD935G2 function.

2. In multiplexed mode, latched addresses generated from ADIO delay to address output on any Port.

3. WR timing has the same timing as E, DS signals.

4. t

WHAX2

is Address hold time for DPLD inputs that are used to generate chip selects for internal PSD memory.

Microcontroller Interface – PSD935G2 AC/DC Parameters

(3.0 V to 3.6 V Versions)

PSD935G2 PSD9XX Family

-90 -12

Symbol Parameter Conditions Min Max Min Max Unit

LVDV

ALE Access Time from Power Down

128 135 ns

Maximum Delay from APD Enable

CLWH

to Internal PDN Valid Signal

Using CLKIN Input 15 *t

CLCL

(µs) (Note 1) µs

Power Down Timing (3.0 V to 3.6 V Versions)

Symbol Parameter Conditions Min Typ Max Unit

NLNH

Warm RESET Active Low Time (Note 1) 300 ns

OPR

RESET High to Operational Device 300 ns

NLNH-PO

Power On Reset Active Low Time 1 ms Warm RESETActive Low Time

NLNH-A

(Note 2) 25 µs

Reset Pin Timing (3.0 V to 3.6 V Versions)

NOTE: 1. t

CLCL

is the CLKIN clock period.

Microcontroller Interface – PSD935G2 AC/DC Parameters

(3.0 V to 3.6 V Versions)

Symbol Parameter Conditions Min Typ Max Unit

BVBH

stby

Detection to V

stbyon

Output

High

(Note 1) 20 µs

BXBL

stby

Off Detection to V

stbyon

Output Low

(Note 1) 20 µs

stbyon

Timing (3.0 V to 3.6 V Versions)

NOTE: 1. RESET will not abort Flash programming/erase cycles.

2. RESET will abort Flash programming or erase cycle.

NOTE: 1. Vstbyon is measured at VCCramp rate of 2 ms.

PSD9XX Family PSD935G2

Microcontroller Interface – PSD935G2 AC/DC Parameters

(3.0 V to 3.6 V Versions)

Symbol Parameter Min Typ Max Unit

Flash Program 8.5 sec Flash Bulk Erase (Preprogrammed to 00) (Note 1) 3 30 sec Flash Bulk Erase 10 sec

WHQV3

Sector Erase (Preprogrammed to 00) 1 30 sec

WHQV2

Sector Erase 2.2 sec

WHQV1

Word Program 14 1200 µs Program/Erase Cycles (Per Sector) 100,000 cycles

WHWLO

Sector Erase Time-Out 100 µs

Q7VQV

DQ7 Valid to Output Valid (Data Polling)

30 ns

(Note 2)

Flash Program, Write and Erase Times (3.0 V to 3.6 V Versions)

-90 -12

Symbol Parameter Conditions Min Max Min Max Unit

ISCCF

TCK Clock Frequency (except for PLD) (Note 1) 15 12 MHz

ISCCH

TCK Clock High Time (Note 1) 30 40 ns

ISCCL

TCK Clock Low Time (Note 1) 30 40 ns

ISCCF-P

TCK Clock Frequency (for PLD only) (Note 2) 2 2 MHz

ISCCH-P

TCK Clock High Time (for PLD only) (Note 2) 240 240 ns

ISCCL-P

TCK Clock Low Time (for PLD only) (Note 2) 240 240 ns

ISCPSU

ISC Port Set Up Time 11 12 ns

ISCPH

ISC Port Hold Up Time 5 5 ns

ISCPCO

ISC Port Clock to Output 26 32 ns

ISCPZV

ISC Port High-Impedance to Valid Output 26 32 ns

ISCPVZ

ISC Port Valid Output to High-Impedance 26 32 ns

ISC Timing (3.0 V to 3.6 V Versions)

NOTES: 1. Programmed to all zeros before erase.

2. The polling status DQ7 is valid tQ7VQV ns before the data DQ0-7 is valid for reading.

NOTES: 1. For “non-PLD” programming, erase or in ISC by-pass mode.

2. For program or erase PLD only.

PSD935G2 PSD9XX Family

Figure 28. Read Timing

AVLX

LXAX

LVLX

AVQV

SLQV

RLQV

RHQX

tRHQZ

ELTL

EHEL

RLRH

THEH

AVPV

ADDRESS

VALID

ADDRESS

VALID

DATA VALID

ADDRESS OUT

ALE/AS

A/D

MULTIPLEXED

BUS

ADDRESS

NON-MULTIPLEXED

BUS

DATA

NON-MULTIPLEXED

BUS

CSI

(PSEN, DS)

R/W

AVLX

and t

LXAX

are not required 80C51XA in Burst Mode.

PSD9XX Family PSD935G2

Figure 29. Write Timing

AVLX

LXAX

LVLX

AVWL

SLWL

WHDX

WHAX

ELTL

EHEL

WLMV

WLWH

DVWH

THEH

AVPV

ADDRESS

VALID

ADDRESS

VALID

DATA

VALID

DATA

VALID

ADDRESS OUT

WHPV

STANDARD

MCU I/O OUT

ALE/AS

A/D

MULTIPLEXED

BUS

ADDRESS

NON-MULTIPLEXED

BUS

DATA

NON-MULTIPLEXED

BUS

CSI

(DS)

R/ W

PSD935G2 PSD9XX Family

Figure 30. Combinatorial Timing – PLD

GPLD INPUT

GPLD

OUTPUT

Figure 31. JTAG-ISP Timing

ISCCH

TCK

TDI/TMS

ISC OUTPUTS/TDO

ISCCL

ISCPH

ISCPSU

ISCPVZ

ISCPZV

ISCPCO

PSD9XX Family PSD935G2

Figure 32. Reset Timing

Figure 33. Key to Switching Waveforms

OPERATING LEVEL

POWER ON RESET

RESET

NLNH–PO

OPR

NLNH-A

NLNH

OPR

WARM RESET

WAVEFORMS

INPUTS OUTPUTS

STEADY INPUT

MAY CHANGE FROM HI TO LO

MAY CHANGE FROM LO TO HI

DON'T CARE

OUTPUTS ONLY

STEADY OUTPUT

WILL BE CHANGING FROM HI TO LO

WILL BE CHANGING LO TO HI

CHANGING, STATE UNKNOWN

CENTER LINE IS TRI-STATE

PSD935G2 PSD9XX Family

Symbol Parameter

Conditions Typical2 Max Unit

Capacitance (for input pins only) V

= 0 V 4 6 pF

OUT

Capacitance (for input/output pins) V

OUT

= 0 V 8 12 pF

VPP

Capacitance (for CNTL2/VPP)V

= 0 V 18 25 pF

NOTES: 1. These parameters are only sampled and are not 100% tested.

2. Typical values are for TA = 25°C and nominal supply voltages.

TA = 25 °C, f = 1 MHz

14.0 Pin Capacitance

15.0 Figure 34. AC Testing Input/Output Waveform

16.0 Figure 35. AC Testing Load Circuit

17.0 Programming

3.0V

TEST POINT 1.5V

Upon delivery from ST, the PSD935G2 device has all bits in the PLDs and memories in the “1” or high state. The configuration bits are in the “0” or low state. The code, configuration, and PLDs logic are loaded through the procedure of programming.

Information for programming the device is available directly from ST. Please contact your local sales representative. (See the last page.)

2.01 V

195 Ω

DEVICE

UNDER TEST

= 30 pF

(INCLUDING SCOPE AND JIG CAPACITANCE)

PSD9XX Family PSD935G2

18.0 PSD935G2 Pin Assignments

Pin No. Pin Assignments Pin No. Pin Assignments

1 PD2 41 PC0 2 PD3 42 PC1 3 AD0 43 PC2 4 AD1 44 PC3 5 AD2 45 PC4 6 AD3 46 PC5 7 AD4 47 PC6 8 GND 48 PC7

9VCC49 GND 10 AD5 50 GND 11 AD6 51 PA0 12 AD7 52 PA1 13 AD8 53 PA2 14 AD9 54 PA3 15 AD10 55 PA4 16 AD11 56 PA5 17 AD12 57 PA6 18 AD13 58 PA7 19 AD14 59 CNTL0 20 AD15 60 CNTL1 21 PG0 61 PB0 22 PG1 62 PB1 23 PG2 63 PB2 24 PG3 64 PB3 25 PG4 65 PB4 26 PG5 66 PB5 27 PG6 67 PB6 28 PG7 68 PB7 29 V

69 V

30 GND 70 GND 31 PF0 71 PE0 32 PF1 72 PE1 33 PF2 73 PE2 34 PF3 74 PE3 35 PF4 75 PE4 36 PF5 76 PE5 37 PF6 77 PE6 38 PF7 78 PE7 39 RESET 79 PD0 40 CNTL2 80 PD1

80-Pin Plastic Thin Quad Flatpack (TQFP) (Package Type U)

PSD935G2 PSD9XX Family

19.0 PSD935G2 Package Information

60 CNTL1 59 CNTL0 58 PA7 57 PA6 56 PA5 55 PA4 54 PA3 53 PA2 52 PA1 51 PA0 50 GND 49 GND 48 PC7 47 PC6 46 PC5 45 PC4 44 PC3 43 PC2 42 PC1 41 PC0

PD2 PD3 AD0 AD1 AD2 AD3 AD4 GND V

AD5 AD6 AD7 AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

80797877767574737271706968676665646362

PD1

PD0

PE7

PE6

PE5

PE4

PE3

PE2

PE1

PE0

GND

PB7

PB6

PB5

PB4

PB3

PB2

PB1

PB0

21222324252627282930313233343536373839

PG0

PG1

PG2

PG3

PG4

PG5

PG6

PG7

GND

PF0

PF1

PF2

PF3

PF4

PF5

PF6

PF7

RESET

CNTL2

Figure 36. Drawing U5 – 80-Pin Plastic Thin Quad Flatpack (TQFP)

(Package Type U)

PSD9XX Family PSD935G2

Figure 36A. Drawing U5 – 80-Pin Plastic Thin Quad Flatpack (TQFP) (Package Type U)

Index Mark

Standoff:

0.05 mm Min.

Load Coplanarity:

0.102 mm Max.

Be1

A2 A

1 2 3

Family: Plastic Thin Quad Flatpack (TQFP)

Millimeters Inches

Symbol Min Max Notes Min Max Notes

α 0° 7° 0° 8° A – 1.20 – 0.047

A2 0.95 1.05 0.037 0.041 B 0.17 0.27 Reference 0.007 0.011 C 0.20 0.008 D 13.95 14.05 0.512 0.551 D1 11.95 12.05 0.433 0.472 D3 9.5 Reference 0.374 Reference E 13.95 14.05 0.512 0.551 E1 11.95 12.05 0.433 0.472 E3 9.5 Reference 0.374 Reference e1 0.50 Reference 0.019 Reference L 0.45 0.75 0.018 0.030 N80 80

060198R0

PSD935G2 PSD9XX Family

20.0 Selector Guide

Part # MCU PLDs/Decoders I/O Memory Other Software

5 Data Inputs Input Macrocells Ports Flash Program Store ISP via JTAG PSDsoft

Volts

Path

Output Macrocells 2nd Flash Array IAP via MCU

Express

Outputs EEPROM Zero Power PSDsoft

Page SRAM Per. Mode

2000

Reg. w/BB

Security

PMU

APD

PSD935G2 8 52 – – 24 8-bit 52 4096Kb 256Kb – 64Kb X X X – X X X X X

PSD913F2 8 27 – _ 19 8-bit 27 1024Kb 256Kb – 16Kb X X X – X X X X X

PSD934F2 8 27 – _ 19 8-bit 27 2048Kb 256Kb – 16Kb X X X – X X X X X

Selector Guide – PSD935G2 Series

PSD9XX Family PSD935G2

21.0 Part Number Construction

22.0 Ordering Information

I/O COUNT & OTHER

NVM SIZE

SRAM SIZE

FAMILY/SERIES

PSD BRAND NAME

PSD = Standard Low Power Device

8 = Flash PSD for 8-bit MCUs

0 = 0Kb 1 = 16Kb 2 = 32Kb 3 = 64Kb

1 = 256Kb 2 = 512Kb 3 = 1Mb 4 = 2Mb 5 = 4Mb

REVISION

"Blank" = no rev.

- A = Rev. A

- B = Rev. B

- C = Rev. C

SPEED

- 70 = 70ns

- 90 = 90ns

- 12 = 120ns

- 15 = 150ns

- 20 = 200ns

PA CKAGE TYPE

J = PLCC U = TQFP M = PQFP B81 = BGA

TEMP RANGE

"Blank" = 0°C to +70°C (Commercial) I = –40°C to +85°C (Industrial)

2ND NVM TYPE, SIZE & CONFIGURATION

1 = EEPROM, 256Kb 2 = FLASH, 256Kb 3 = No 2nd Array

VOLTAGE

"blank" = 5 Volt V = 3.0 Volt

F = 27 I/O G = 52 I/O

Flash PSD Part Number Construction

41 = Flash PSD for 16-bit MUCs (with simple PLD)

9 = Flash PSD for 8-bit MUCs (with simple PLD)

42 = Flash PSD for 16-bit MUCs (with CPLD)

I I I I I I I I I I I I I I I I I I

CHARACTER # 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

PART

NUMBER

PSD 4 2 13F2 A 15J––

Operating

Speed Temperature

Part Number (ns) Package Type Range

PSD935G2-70U 70 80 Pin TQFP Comm’l PSD935G2-90U 90 80 Pin TQFP Comm’l PSD935G2-90UI 90 80 Pin TQFP Industrial

PSD935G2V-90U 90 80 Pin TQFP Comm’l PSD935G2V-12U 120 80 Pin TQFP Comm’l PSD935G2V-12UI 120 80 Pin TQFP Industrial

PSD935G2

REVISION HIST ORY

Table 1. Document Revision History

Date Rev. Description of Revision

25-Feb-2000 1.0 PSD935G2: Document written in the WSI format. Initial release

Specifications changed tLXAX -70 Min from 5 to 7 Page 70: changed Turbo Off from add 10 to add 12.

30-Nov-2000 1.1

31-Jan-2002 1.2

changed tLXAX -70 Min from 5 to 7, changed tDVWH -70 Min from 12 to 25,

changed tWLWH -70 Min from 25 to 28. PSD935G2: Configurable Memory System on a Chip for 8-Bit Microcontrollers

Front page, and back two pages, in ST format, added to the PDF file References to Waferscale, WSI, EasyFLASH and PSDsoft 2000 updated to ST, ST, Flash+PSD and PSDsoft Express

2/3

PSD935G2

Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implic ation or otherwise under any patent or patent rights of STMi croelectr onics. Specifications mentioned in thi s publicati on are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as cri tical comp onents in life support dev i ces or systems wi t hout express written ap proval of STMi croelect ro nics.

The ST log o i s registered trademark of STMicroelectronics All other nam es are the pro perty of their respectiv e owners

STMicroel ectronics group of com panies Australia - Brazil - Cana da - China - Finl and - Franc e - Germany - Ho ng Kong -

India - Israel - Italy - Japan - Malay sia - Malta - M orocco - Singapore - Spa i n - Sweden - Swi tz erland - United Kingdom - United States.

www.st.com

3/3

ST PSD935G2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
