ST PM6685 User Manual

with auxilary voltages for notebook system power
Features
6 V to 28 V input voltage range
Fixed 5 V - 3.3 V output voltages
deliver 100 mA of peak current
PM6685
Dual step-down main supply controller
1.230 V ±1% reference voltage available
Lossless current sensing using low side
MOSFETs' R
Negative current limit
Soft-start internally fixed at 2 ms
Soft output discharge
Latched OVP and UVP
Selectable pulse skipping at light loads
Selectable minimum frequency (33 kHz) in
DS(on)
pulse skip mode
4 mW maximum quiescent power
Independent power good signals
Output voltage ripple compensation
Applications
Notebook computers
Tablet PC or slates
Mobile system power supply
3 and -4 Cells Li+ battery-powered devices
VFQFPN-32 (5mm x 5mm)
Description
PM6685 is a dual step-down controller specifically designed to provide extremely high efficiency conversion with loss-less current sensing technique. The constant on-time architecture assures fast load transient response and the embedded voltage feed-forward provides nearly constant switching frequency operation.
An embedded integrator control loop compensates the DC voltage error due to the output ripple. The pulse skipping technique increases efficiency for very light loads. Moreover, a minimum switching frequency of 33kHz is selectable in order to avoid audio noise issues.
The PM6685 provides a selectable switching frequency, allowing either 200 kHz/300 kHz, 300 kHz/400 kHz, or 400 kHz/500 kHz operation of the 5 V/3.3 V switching sections.

Table 1. Device summary

Order code Package Packaging
PM6685
VFQFPN-32 (5 mm x 5 mm)
PM6685TR Tape and reel
March 2011 Doc ID 11674 Rev 8 1/48
Tube
www.st.com
48
Contents PM6685
Contents
1 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Pin settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 Maximum rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Typical operating characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6 Application schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7 Device description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.1 Constant on time PWM control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.2 Constant on time architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.3 Output ripple compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.4 Pulse skip mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.5 No-audible skip mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7.6 Current limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7.7 Soft start and soft end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.8 Gate drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.9 Reference voltage and bandgap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.10 Internal linear regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.11 Power up sequencing and operative modes . . . . . . . . . . . . . . . . . . . . . . . 28
8 Monitoring and protections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.1 Power good signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.2 Thermal protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.3 Overvoltage protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2/48 Doc ID 11674 Rev 8
PM6685 Contents
8.4 Undervoltage protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.5 Design guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.6 Switching frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.7 Inductor selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.8 Output capacitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8.9 Input capacitors selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8.10 Power MOSFETs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.11 Closing the integrator loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
9 Other parts design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
10 Design example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.1 Inductor selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.2 Output capacitor selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.3 Power MOSFETs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.4 Current limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.5 Input capacitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.6 Synchronous rectifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.7 Integrator loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.8 Layout guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
11 Package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
12 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Doc ID 11674 Rev 8 3/48
Block diagram PM6685
L
5V
S
+-+
4V
V
2
V
3.3V
L
4.8V
U
V
T
V
L
V
+
-
2.6V
VCCV

1 Block diagram

Figure 1. Functional block diagram

IN
REF
PGOOD
LDO3
OUT3
SKIP
FSEL
BOOT3
HGATE3
PHASE3
CSENSE3
COMP3
CC
FREQUENCY
SELECTOR
LDO5
REFERENCE GENERATOR
LEVEL
SHIFTER
REF
DO5 ENABLE
.55
-
3.3V
SMPS
CONTROLLER
LINEAR
REGULATOR
LINEAR
REGULATOR
DO3 ENABLE
CONTROLLER
5V
SMPS
+
-
VLO
LEVEL
SHIFTER
UVLO
DO5
5SW
OUT5
BOOT5
HGATE5
PHASE5
CSENSE5
COMP5
LDO5
LGATE3
PGOOD3
SHDN
LDO3 SEL
EN3
LDO3 MODE
SELECTOR
UVLO
TARTUP
CONTROLLER
ERMIC
FAULT
LDO3 ENABLE
LDO5 ENABLE
TERMIC
CONTROLLER
LGATE5
PGOOD5
EN5
4/48 Doc ID 11674 Rev 8
PM6685 Pin settings

2 Pin settings

2.1 Connections

Figure 2. Pin connection (top view)

6*1'
&203
)6(/
(1
6+'1
3*22'B/'2
/'2
287
95()
9&&
287
&203
/'2B6(/
       
      
+*$7(
%227
3+$6(
/*$7(
&6(16(
3*1'
3*22'
/*$7(
(1
3*22'
6.,3


%227

+*$7(

3+$6(
&6(16(


9,1

/'2
96:

6*1'
Doc ID 11674 Rev 8 5/48
Pin settings PM6685

2.2 Functions

Table 2. Pin functions

Pin Name Description
Signal ground. Reference for internal logic circuitry. It must be connected to the signal ground
1SGND1
plan of the power supply. The signal ground plan and the power ground plan must be connected together in one point near the PGND pin.
2 COMP3 DC voltage error compensation pin for the 3.3V switching section.
Frequency selection pin.
3 FSEL
It provides a selectable switching frequency, allowing, allowing three different values of switching frequencies for the 5V/3.3V switching sections.
3.3V SMPS enable input. – The 3.3V section is enabled applying a voltage greater than 2.4V to this pin.
4EN3
– The 3.3V section is disabled applying a voltage lower than 0.8V. When the section is disabled the High Side gate driver goes low and Low Side gate driver goes high. If both EN3 and EN5 pins are low and SHDN pin is high the device enters in standby mode.
Shutdown control input. – The device switch off if the SHDN voltage is lower than 0.8V (Shutdown mode)
5 SHDN
– The device switch on if the SHDN voltage is greater than 1.7V. The SHDN pin can be connected to the battery through a voltage divider to program an undervoltage lockout. In shutdown mode, the gate drivers of the two switching sections are in high impedance (high-Z).
6
PGOOD
LDO3
Power Good signal for the 3.3V linear regulator. This pin is an open drain output. It is shorted to GND if LDO3_SEL pin is at its low level or if the output voltage on LDO3 pin is lower than 2.6V.
7 LDO3 3.3V Linear regulator output. LDO3 can provide 100mA peak current.
8OUT3
9BOOT3
Output voltage sense for the 3.3V switching section.This pin must be directly connected to the output voltage of the switching section.
Bootstrap capacitor connection for the switching 3.3V section. It supplies the high-side gate driver.
10 HGATE3 High-side gate driver output for the 3.3V section.
11 PHASE3 Switch node connection and return path for the high side driver for the 3.3V section.
12 CSENSE3
Current sense input for the 3.3V section. This pin must be connected through a resistor to the drain of the synchronous rectifier (R
sensing) to set the current limit threshold.
DSON
13 LGATE3 Low-side gate driver output for the 3.3V section.
14 PGND Power ground. This pin must be connected to the power ground plan of the power supply.
15 LGATE5 Low-side gate driver output for the 5V section.
16 SGND2
Signal ground for analog circuitry. It must be connected to the signal ground plan of the power supply.
Internal 5V regulator bypass connection.
17 V5SW
– If V5SW is connected to OUT5 (or to an external 5V supply) and V5SW is greater than 4.9V,
the LDO5 regulator shuts down and the LDO5 pin is directly connected to OUT5 through a 3W (max) switch.
– If V5SW is connected to GND, the LDO5 linear regulator is always on.
18 LDO5
5V internal regulator output. It can provide up to 100mA peak current. LDO5 pin supplies embedded low side gate drivers and an external load.
6/48 Doc ID 11674 Rev 8
PM6685 Pin settings
Table 2. Pin functions (continued)
Pin Name Description
19 VIN
20 CSENSE5
21 PHASE5 Switch node connection and return path for the high side driver for the 5V section.
22 HGATE5 High-side gate driver output for the 5V section.
23 BOOT5 Bootstrap capacitor connection for the 5V section. It supplies the high-side gate driver.
24 SKIP
25 EN5
26 PGOOD5
27 PGOOD3
28 LDO3SEL
29 OUT5
30 COMP5 DC voltage error compensation pin for the 5V switching section.
31 VCC
32 VREF
Device input supply voltage. A bypass filter (4W and 4.7mF) between the battery and this pin is recommended.
Current sense input for the 5V section. This pin must be connected through a resistor to the drain of the synchronous rectifier (R
Pulse skip mode control input. – If the pin is connected to LDO5 the PWM mode is enabled.
– If the pin is connected to GND, the pulse skip mode is enabled. – If the pin is connected to VREF the pulse skip mode is enabled but the switching frequency is
kept higher than 33kHz (No-audible pulse skip mode).
5V SMPS enable input. – The 5V section is enabled applying a voltage greater than 2.4V to this pin.
– The 5V section is disabled applying a voltage lower than 0.8V. When the section is disabled the High Side gate driver goes low and Low Side gate driver goes high.
Power Good signal for the 5V section. This pin is an open drain output. The pin is pulled low if the output is disabled or if it is out of approximately +/- 10% of its nominal
value.
Power Good signal for the 3.3V section. This pin is an open drain output. The pin is pulled low if the output is disabled or if it is out of approximately +/- 10% of its nominal
value.
Control pin for the 3.3V internal linear regulator. This pin determines three operative modes for the LDO3.
– If LDO3_SEL pin is connected to GND the LDO3 output is always disabled. – If LDO3_SEL pin is connected to LDO5 the LDO3 internal regulator is always enabled. – If LDO3_SEL pin is connected to VREF and OUT3 is greater than about 3V, the LDO3
regulator shuts down and the LDO3 pin is be directly connected to OUT3 through a 3W (max) switch.
Output voltage sense for the 5V switching section.This pin must be directly connected to the output voltage of the switching section.
Device Supply Voltage pin. It supplies the all the internal analog circuitry except the gate drivers (see LDO5). Connect this pin to LDO5.
High accuracy output voltage reference (1.230V). It can deliver 50uA. Bypass to SGND with a 100nF capacitor.
sensing) to set the current limit threshold.
DSON
33 EXP PAD Exposed pad.
Doc ID 11674 Rev 8 7/48
Electrical data PM6685

3 Electrical data

3.1 Maximum rating

Table 3. Absolute maximum ratings

Parameter Value Unit
COMPx,FSEL,LDO3_SEL,VREF,SKIP to SGND1,SGND2 -0.3 to VCC + 0.3 V
ENx,SHDN,PGOOD_LDO3,OUTx,PGOODx,VCC to SGND1,SGND2
LDO3 to SGND1,SGND2 -0.3 to LDO5 + 0.3 V
LGATEx to PGND -0.3
HGATEx and BOOTx, to PHASEx -0.3 to 6 V
PHASEx to PGND -0.6
CSENSEx, to PGND -0.6 to 42 V
CSENSEx to BOOTx_ -6 to 0.3 V
V5SW, LDO5 _to PGND -0.3 to 6 V
VIN to PGND -0.3 to 36 V
-0.3 to 6 V
(1)
to LDO5 + 0.3
(2)
to 36
V
V
PGND to SGND1,SGND2_ -0.3 to 0.3 V
Power Dissipation at Tamb = 25ºC 2 W
Maximum withstanding Voltage range test condition: CDF-AEC-Q100-002- “Human Body Model” acceptance criteria: “Normal Performance”
1. LGATEx to PGND up to -1V for t < 40ns
2. PHASE to PGND up to -2.5V for t < 10ns

3.2 Thermal data

Table 4. Thermal data

Symbol Parameter Value Unit
R
T
thJA
STG
T
J
Thermal resistance junction to ambient 35 °C/W
Storage temperature range -40 to 150 °C
Junction operating temperature range -10 to 125 °C
VIN pin ±1000 V
Other pins ±2000
8/48 Doc ID 11674 Rev 8
PM6685 Electrical characteristics

4 Electrical characteristics

VIN = 12V, TA = 0°C to 85°C, unless otherwise specified

Table 5. Electrical characteristics

Symbol Parameter Test condition Min Typ Max Unit
Supply section
VIN
Input voltage range
Vout=Vref, LDO5 in regulation FSEL to GND
5.5 28 V
Vcc IC supply voltage 4.5 5.5 V
V
V5SW
Turn-on voltage threshold
Turn-off voltage threshold
4.6 4.75 V
4.8 4.9 V
Hysteresis 20 50 mV
V
V5SW
Rdson
Maximum operating range
LDO5 internal bootstrap switch resistance
LDO3 internal bootstrap switch resistance
5.5 V
V5SW > 4.9V 1.8 3 Ω
VOUT3 = 3.3V 1.8 3 Ω
OUT3, OUT5 discharge
Rdson
mode on-resistance
16 25 Ω
OUT3, OUT5_ discharge mode
synchronous rectifier
0.2 0.35 0.5 V
turn-on level
Pin
Operating power consumption
>5.1V,V
V
OUT5
V5SW to 5V LDO5, LDO3 no load
OUT3
>3.34V
4mW
Ish VIN shutdown current SHDN connected to GND, 14 18 μA
Isb VIN standby current
ENx to GND, V5SW to GND, LDO3_SEL to 5V
270 380 μA
Shutdown section
Device on threshold 1.2 1.5 1.7 V
V
SHDN
Device off threshold 0.8 0.85 0.9 V
Soft start section
Soft start ramp time 2 3.5 ms
Current limit and zero crossing comparator
Doc ID 11674 Rev 8 9/48
Electrical characteristics PM6685
Table 5. Electrical characteristics (continued)
Symbol Parameter Test condition Min Typ Max Unit
I
CSENSE
Input bias current limit 90 100 110 μA
Comparator offset V
Zero crossing comparator offset
Fixed negative current limit
threshold
On time pulse width
Ton ON-time duration
OFF time
T
OFFMIN
Minimum off time 400 500 ns
Volt age ref ere nc e
Voltage accuracy 4.2V<V
V
REF
Load regulation -100μA< I
Undervoltage lockout fault threshold
CSENSE-VPGND
V
PGND-VPHASE
V
PGND-VPHASE
-6 6 mV
-1 11 mV
-120 mV
OUT5=5V 1685 1985 2285
FSEL to GND
OUT3=3.3V 780 920 1060
OUT5=5V 1115 1315 1515
FSEL to VREF
OUT3=3.3V 585 690 795
OUT5=5V 830 980 1130
FSEL to LDO5
OUT3=3.3V 470 555 640
< 5.5V 1.217 1.230 1.243 V
LDO5
< 100μA -4 4 mV
REF
Falling edge of REF 0.95 V
ns
Integrator
Normal mode 250
Over voltage clamp
COMP
Under voltage clamp -150
Line regulation
Both SMPS, 6V<Vin<28V
LDO5 linear regulator
V
LDO5
I
LDO5
UVLO
LDO5 linear output voltage
LDO5 line regulation
LDO5 current limit
Under voltage lockout of LDO5
6V<VIN<28V, 0<I
6V< VIN < 28V, I LDO3_SEL tied to GND
> UVLO, I
V
LDO5
V
>5.1V, V
OUT5
<50mA 4.9 5.0 5.1 V
LDO5
=50mA
LDO5
=0A
LDO3
>3.34V
OUT3
10/48 Doc ID 11674 Rev 8
(1)
mVPulse skip mode 60
0.004 %/V
,
0.004 %/V
270 350 400 mA
3.94 4 4.13 V
PM6685 Electrical characteristics
Table 5. Electrical characteristics (continued)
Symbol Parameter Test condition Min Typ Max Unit
LDO3 linear regulator
V
LDO3
I
LDO3
LDO3 linear output voltage
LDO3 current limit V
0.5mA<I
LDO5
<50mA 3.23 3.3 3.37 V
LDO3
> UVLO 130 165 200 mA
High and low gate drivers
HGATE Driver On­resistance
LGATE Driver On­resistance
HGATEx high state (pull-up) 2.0 3 Ω
HGATEx low state (pull-down) 1.6 2.7 Ω
LGATEx high state (pull-up) 1.4 2.1 Ω
LGATEx low state (pull-down) 0.8 1.2 Ω
PGOOD pins UVP/OVP protections
OVP Over voltage threshold
Both SMPS sections with respect to VREF.
113 116 120 %
UVP Under voltage threshold 66 70 72 %
Upper threshold (VFB-VREF)
107 110 113 %
PGOOD3,5
I
PGOOD3,5
V
PGOOD3,5
PGOOD
LDO3
Lower threshold (VFB-VREF)
PGOOD leakage current
V
PGOOD3,5
forced to 5.5V 1 uA
Output low voltage ISink = 4mA 150 250 mV
Rising voltage threshold 77.7 81.1 %
90 92 94 %
Falling voltage threshold 72.1 76.6 %
Hysteresis 20 30 mV
I
PGOOD_LDO3
V
PGOOD_LDO3
PGOOD leakage current
Output low voltage ISink = 4mA 150 250 mV
Thermal shutdown
T
SDN
Shutdown temperature 150 °C
Power management pins
SMPS disabled threshold
EN3,5
SMPS enabled threshold
V
PGOOD LDO3
(2)
(2)
forced to 5.5V 1 uA
0.8
Doc ID 11674 Rev 8 11/48
V
2.4
Electrical characteristics PM6685
Table 5. Electrical characteristics (continued)
Symbol Parameter Test condition Min Typ Max Unit
FSEL
LDO3
SEL
Frequency selection range
3.3V linear regulator selection pin
Pulse skip mode
SKIP
Frequency clamp mode
Input leakage current
1. by demonstration board test
2. by design
Low level
Middle level
High level
Always-off level
Bootstrap level
Always-on level
(2)
(2)
(2)
V
EN3,4
V
SKIP
V
SHDN
V
FSEL
V
LDO3_SEL
(2)
(2)
(2)
(2)
(2)
(2)
1.0 V
V
-0.8
LDO5
1.0 V
V
-0.8
LDO5
1.0 V
V
-0.8
LDO5
= 0 to 5V 1
= 0 to 5V 1
= 0 to 5V 0.1
= 0 to 5V 1
= 0 to 5V 1
0.5
LDO5
0.5
LDO5
0.5
LDO5
-1.5
-1.5
-1.5
V
VPWM mode
μA
12/48 Doc ID 11674 Rev 8
PM6685 Typical operating characteristics

5 Typical operating characteristics

FSEL = GND (200/300 kHz), SKIP = GND (skip mode), LDO3_SEL = VREF, V5SW = OUT5, input voltage VIN = 12 V, SHDN, EN3 and EN5 high, no load unless specified.
Figure 3. 5 V output efficiency vs
load current
Figure 4. 3.3 V output efficiency vs
load current
Figure 5. PWM no load input battery vs input
voltage
Figure 6. Skip no load battery current vs input
voltage
Doc ID 11674 Rev 8 13/48
Typical operating characteristics PM6685
Figure 7. Standby mode input battery current
vs input voltage
Figure 9. 5V switching frequency vs load
current
Figure 8. Shutdown mode input device
current vs input voltage
Figure 10. 3.3V switching frequency vs load
current

Figure 11. LDO5 vs output voltage Figure 12. LDO3 vs output voltage

14/48 Doc ID 11674 Rev 8
PM6685 Typical operating characteristics
Figure 13. 5V voltage regulation
vs load current
Figure 15. Voltage reference vs
load current
Figure 14. 3.3 V voltage regulation
vs load current
Figure 16. OUT5, LDO3 and LDO5
Power-Up

Figure 17. 5 V PWM load transient Figure 18. 3.3 V PWM load transient

Doc ID 11674 Rev 8 15/48
Typical operating characteristics PM6685
Figure 19. 5 V soft start (0.75 Ω load) Figure 20. 3.3 V soft start (0.55 Ω load)

Figure 21. 5 V soft end (no load) Figure 22. 3.3 V soft end (no load)

Figure 23. 5 V soft end (1 Ω load) Figure 24. 3.3 V soft end (1 Ω load)
16/48 Doc ID 11674 Rev 8
PM6685 Typical operating characteristics

Figure 25. 5 V no audible skip mode Figure 26. 3.3 V no audible skip mode

Doc ID 11674 Rev 8 17/48
Application schematic PM6685

6 Application schematic

Figure 27. Simplified application schematic

5V-
SGND
5V+
1
1
VIN
+
PGND
OUT5
PM6685
SGND
SGND
PGND
SGND
23
22
20
17
29
CSENSE5
V5SW
CSENSE3
PGND
12
14
1
PGND
21
15
BOOT5
HGATE5
PHASE5
LGATE5
VCC
LDO5
VIN
HGATE3
PHASE3
LGATE3
13
BOOT3
SGND
9
10
11
V+
BOOT1
BOOT2
SGND
+
SGND
31
18
19
V+
V+
PGOOD3
PGOOD5
SHDN
4
EN3
EN5
32
VREF
24
SGND
SKIP
3
FSEL
LDO3
SGND
SGND
+
V+
SGND
SGND2
COMP3
302516
COMP5
OUT3
8
2
26
27
5
PGOOD5
PGOOD3
PGOOD LD O3
LDO3SEL
6
28
7
V+
PGOODLDO3
V+
SGND
18/48 Doc ID 11674 Rev 8
PGND
PGND
+
1
1
VIN
PM6685 Device description

7 Device description

The PM6685 is a dual step-down controller dedicated to provide logic voltages for notebook computers.
It is based on a Constant On Time control architecture. This type of control offers a very fast load transient response with a minimum external component count. A typical application circuit is shown in Figure 27 on page 18. The PM6685 regulates two fixed output voltages: 5 V and 3.3 V. The switching frequency of the two sections can be adjusted to approximately 200/300 kHz, 300/400 kHz or 400/500 kHz respectively. In order to maximize the efficiency at light load condition, a pulse skipping mode can be selected. The PM6685 includes also two linear regulators (LDO5 and LDO3) that allow the shutdown of the respective switching sections in low consumption status. On the other hand, to maximize the efficiency in higher consumption status, the linear regulators can be turned off and their outputs can be supplied directly from the switching outputs. The PM6685 provides protection versus overvoltage, undervoltage and overtemperature as well as power good signals for monitoring purposes. An external 1.230 V reference is available.

7.1 Constant on time PWM control

If the SKIP pin is tied to 5 V, the device works in PWM mode. Each power section has an independent on time control.The PM6685 implements a pseudo-fixed switching frequency, constant on time (COT) controller as core of the switched mode section. Each power section has an independent COT control.
The COT controller is based on a relatively simple algorithm and uses the ripple voltage due to the output capacitor’s ESR to trigger the fixed on-time one-shot generator. In this way, the output capacitor’s ESR acts as a current sense resistor providing the appropriate ramp signal to the PWM comparator. On-time one-shot duration is directly proportional to the output voltage VOUT, sensed at the OUT5/OUT3 pins, and inversely proportional to the input voltage VIN, sensed at the VIN pin, as follows:
Equation 1
V
OUT
KT ×=
ON
This leads to a nearly constant switching frequency, regardless of input and output voltages.
When the output voltage goes lower than the regulated voltage Vreg, the on-time one shot generator directly drives the high side MOSFET for a fixed on time allowing the inductor current to increase; after the on time, an off time phase, in which the low side MOSFET is turned on, follows. Figure 28 on page 20 shows the inductor current and the output voltage waveforms in PWM mode.
V
IN
Doc ID 11674 Rev 8 19/48
Device description PM6685

Figure 28. Constant on time PWM control

The duty cycle D of the buck converter in steady state is:
Equation 2
V
OUT
D =
V
IN
The PWM control works at a nearly fixed frequency f
SW
:
Equation 3
V
OUT
D
f =
sw
T
ON
V
==
IN
V
ON
OUT
×
V
K
1
K
ON
IN
As mentioned the steady state switching frequency is theoretically independent from battery voltage and from output voltage. Actually the frequency depends on parasitic voltage drops that are present during the charging path (high side switch resistance, inductor resistance (DCR)) and discharging path (low side switch resistance, DCR). As a result the switching frequency increases as a function of the load current. Standard switching frequency values can be selected for both sections by pin FSEL as shown in the following table:

Table 6. FSEL pin selection

SMPS 5V SMPS 3.3V
FSEL
Frequency K
ON
SGND 212kHz 4,7µs 297,6kHz 3.36µs
VREF 323kHz 3µs 400kHz 2.5µs
LDO5 432kHz 2.31µs 500kHz 2.0µs
Frequency K
ON
The values in the table are measured with Vin =12 V, operation mode = PWM and I The other output are unloaded.
20/48 Doc ID 11674 Rev 8
load
= 2 A.
PM6685 Device description

7.2 Constant on time architecture

Figure 29 on page 21 shows the simplified block diagram of a constant on time controller. A
minimum off-time constrain (380 ns typ) is introduced to allow inductor valley current sensing on the synchronous switch. A minimum on-time(150 ns typ) is also introduced to assure the start-up switching sequence.
PM6685 has a one-shot generator for each power section that turns on the high side MOSFET when the following conditions are satisfied simultaneously: the PWM comparator is high, the synchronous rectifier current is below the current limit threshold, and the minimum off-time has timed out. Once the on-time has timed out, the high side switch is turned off, while the synchronous switch is turned on according to the anti-cross conduction circuitry management. When the negative input voltage at the PWM comparator, which is a scaled-down replica of the output voltage ripple (see the R reaches the valley limit (determined by internal reference V
fb1/Rfb2
r
is turned off according to the anti-cross conduction logic once again, and a new cycle begins.

Figure 29. Constant ON-time block diagram

4OFF
MIN
4OFF
MIN
4OFF
MIN
4OFF
MIN
divider in Figure 29),
=0.9 V), the low-side MOSFET
#3%.3%
#3%.3%
#3%.3%
#3%.3%
#/-0
#/-0
#/-0
#/-0
/54
/54
/54
/54
6).
6).
6).
6).
3+)0
3+)0
3+)0
3+)0
0OSITIVE
0OSITIVE
0OSITIVE
0OSITIVE
#URRENT,IMIT
#URRENT,IMIT
#URRENT,IMIT
#URRENT,IMIT

6R
6R
6R
6R
07-
07-
07-
07-
#OMPARATOR
#OMPARATOR
#OMPARATOR
GM
GM
GM
GM
6R
6R
6R
6R
#OMPARATOR
2&B
2&B
2&B
2&B
2&B
2&B
2&B
2&B
6
6
:ERO
:ERO
:ERO
:ERO
4ON
4ON
4ON
4ON
#OMP
#OMP
#OMP
#OMP

7.3 Output ripple compensation

In a classic constant on time control, the system regulates the valley value of the output voltage and not the average value, as shown in Figure 28 on page 20. In this condition, the output voltage ripple is source of a DC static error.
3
3
2
2
CROSS
CROSS
CROSS
CROSS
"//4
"//4
"//4
"//4
(3
(3
(3
BANDGAP
BANDGAP
BANDGAP
BANDGAP
6
6
6
6
6R
6R
6R
6R
(3
DRIVER
DRIVER
DRIVER
DRIVER
6
6
6
,$/
,$/
,$/
,$/
,3
,3
,3
,3
DRIVER
DRIVER
DRIVER
DRIVER
('!4%
('!4%
('!4%
('!4%
0(!3%
0(!3%
0(!3
0(!3
,'!4%
,'!4%
,'
,'
!4%
!4%
0'.$
0'.$
0'.$
0'.$
62%&
62%&
62%
62%
&
&
%
%
,EVEL
,EVEL
,EVEL
6
6
6
,EVEL
SHIFTER
SHIFTER
SHIFTER
SHIFTER
1
1
1
1
1
3
1
3
2
2
,$/
,$/
,$/
,$/
To compensate this error, an integrator network can be introduced in the control loop, by connecting the output voltage to the COMP5/COMP3(for the 5 V and 3.3 V sections respectively) pin through a capacitor C
Doc ID 11674 Rev 8 21/48
as in Figure 30 on page 22.
INT
Device description PM6685

Figure 30. Circuitry for output ripple compensation

COM P PIN
COM P PIN VOLTAGE
VOLTAGE
? V
Vr
Vr
OU TPU T V OLT AG E
OU TPU T V OLT AG E
? V
I=gm(V1 -Vr)
t
t
CFILTCFILT
CFILTCFILT
?V
?V
t
t
LL
LL
D
D
D
D
CINT
CINT
CINT
CINT
RINT
RINT
RINT
RINT
COMP
COMP
COMP
COMP
ROUTROUT
ROUTROUT
COUTCOUT
COUTCOUT
OUTOU T
OUTOU T
VCINTVC I NT
VCINTVC I NT
I=gm(V1 -Vr)
VrVr
VrVr
RFb2RFb2
RFb2RFb2
-
--
gmgm
gmgm
VrVr
VrVr
+
+
PWMPWM
PWMPWM
-
-
Comp aratorComparator
Comp aratorComparator
+
+
RFb1
RFb1
RF b1
RF b1
V1V1
V1V1
The integrator amplifier generates a current, proportional to the DC errors, which decreases the output voltage in order to compensate the total static error, including the voltage drop on PCB traces. In addition, C voltage on COMP5/COMP3 pin is the sum of the reference voltage V (see Figure 30). In fact when the voltage on the COMP pin reaches V and the output increases.
For example, we consider V C
INT
>>C
FILT
, the C
DC voltage drop V
INT
an AC path for the output voltage ripple. Then the COMP pin ripple is a replica of the output ripple, with a DC value of Vr+25 mV =925 mV.
For more details about the output ripple compensation network, see the paragraph “Closing the integrator loop” in the Design guidelines.

7.4 Pulse skip mode

If the SKIP pin is tied to ground, the device works in skip mode.
At light loads a zero-crossing comparator truncates the low-side switch on-time when the inductor current becomes negative. In this condition the section works in discontinuous conduction mode. The threshold between continuous and discontinuous conduction mode is:
Equation 4
provides an AC path for the output ripple. In steady state, the
INT
=5 V with an output ripple of ΔV=50m V. Considering
OUT
is about 5 V-Vr+25 mV=4.125 V. C
CINT
and the output ripple
r
, a fixed Ton begins
r
ensures
INT
)SKIP(ILOAD ×
=
For higher loads the inductor current doesn’t cross the zero and the device works in the same way as in PWM mode and the frequency is fixed to the nominal value.
22/48 Doc ID 11674 Rev 8
VV
OU TIN
T
L2
×
ON
PM6685 Device description

Figure 31. PWM and pulse skip mode inductor current

HGRPSLNVHVOX3HGRP0:3
,QGXFWRUFXUUHQW
/RZVLGHRQ

7RQ  7R I I

7.5 No-audible skip mode

If SKIP pin is tied to V kHz is enabled. At light load condition, If there is not a new switching cycle within a 30 µs (typ.) period, a no-audible skip mode cycle begins.

Figure 32. Frequency clamp skip mode

, a no-audible skip mode with a minimum switching frequency of 33
REF
/RDGFXUUHQW
7RQ 7RQ
7RQ
7RI I
/RZVLGHRII
7LPH
The low side switch is turned on until the output voltage crosses about Vreg+1%. Then the high side MOSFET is turned on for a fixed on time period. Afterwards the low side switch is enabled until the inductor current reaches the zero-crossing threshold. This keeps the switching frequency higher than 33 kHz. As a consequence of the control, the regulated voltage can be slightly higher than Vreg (up to 1%).
If, due to the load, the frequency is higher than 33 kHz, the device works like in skip mode.
No-audible skip mode reduces audio frequency noise that may occur in pulse skip mode at very light loads, keeping the efficiency higher than in PWM mode.

7.6 Current limit

The current-limit circuit employs a “valley” current-sensing algorithm. During the conduction time of the low side MOSFET the current flowing through it is sensed. The current-sensing element is the low side MOSFET on-resistance(Figure 33)
Doc ID 11674 Rev 8 23/48
Device description PM6685
Figure 33. R
sensing technique
DSON
+6
+*$7(
3+$6(
5FVHQVH
&6(16(
/*$7(
/6
5'6
RQ
An internal 100 μA ΔI a voltage drop on R voltage drop, the controller doesn’t initiate a new cycle. A new cycle starts only when the sensed current goes below the current limit.
Since the current limit circuit is a valley current limit, the actual peak current limit is greater than the current limit threshold by an amount equal to the inductor ripple current. Moreover the maximum output current is equal to the valley current limit plus half of the inductor ripple current:
current source (I
L
CSENSE
. If the voltage across the sensing element is greater than this
CSENSE
) is connected to C
pin and determines
SENSE
Equation 5
LvalleyLOAD
2
Δ
I
L
+=
I(max)I
The output current limit depends on the current ripple, as shown in Figure 34 on page 24:

Figure 34. Current waveforms in current limit conditions

&XUUHQW
'&FXUUHQWOLPLW PD[LPXPORDG
0D[LPXPORDGFXUUHQW LVLQIOXHQFHGE\WKH LQGXFWRUFXUUHQWULSSOH
,QGXFWRUFXUUHQW
9DOOH\FXUUHQWWKUHVKROG
7LPH
Being fixed the valley threshold, the greater the current ripple is, greater the DC output current is
24/48 Doc ID 11674 Rev 8
PM6685 Device description
The valley current limit can be set with resistor R
CSENSE
:
Equation 6
IRR×
I
CSENSE
LvalleyDSon
calculation.
DSon
=
Where I
CSENSE
= 100 µA, R
CSENSE
is the drain-source on resistance of the low side switch.
DSon
Consider the temperature effect and the worst case value in R
The accuracy of the valley current threshold detection depends on the offset of the internal comparator (ΔV
) and on the accuracy of the current generator(ΔI
OFF
CSENSE
):
Equation 7
I
Δ
Lvalley
I
Lvalley
=
I
Δ
CSENSE
I
CSENSE
+
⎢ ⎣
Where RSNS is the sensing element (R
V
Δ
DSon
OFF
×
IR
CSENSECSENSE
).
×
100
Δ
R
CSENSE
+
R
CSENSE
Δ
R
SNS
+
R
SNS
PM6685 provides also a fixed negative peak current limit to prevent an excessive reverse inductor current when the switching section sinks current from the load in PWM mode. This negative current limit threshold is measured between PHASE and SGND pins, comparing the magnitude drop on the PHASE node during the conduction time of the low side MOSFET with an internal fixed voltage of 120 mV.
If the current is sensed on the low side MOSFET, the negative valley-current limit INEG (if the device works in PWM mode) is given by:
Equation 8

7.7 Soft start and soft end

Each switching section is enabled separately by asserting high EN5/EN3 pins respectively. In order to realize the soft start, at the startup the overcurrent threshold is set 25% of the nominal value and the undervoltage protection (see related sections) is disabled. The controller starts charging the output capacitor working in current limit. The overcurrent threshold is increased from 25% to 100% of the nominal value with steps of 25% every 700 μs (typ.). After 2.8 ms (typ.) the undervoltage protection is enabled. The soft start time is not programmable. A minimum capacitor C overshoot on the output:
Equation 9
I =
NEG
is required to ensure a soft start without any
INT
C ×
INT
I
Lvalley
mV120
R
DSon
uA6
Δ
I
L
+
4
2
C
out
Doc ID 11674 Rev 8 25/48
Device description PM6685

Figure 35. Soft start waveforms

6ZLWFKLQJRXWSXW
&XUUHQWOLPLWWKUHVKROG
When a switching section is turned off(EN5/EN3 pins low), the controller enters in soft end mode. The output capacitor is discharged through an internal 16 Ω P-MOSFET switch; when the output voltage reaches 0.3 V, the low-side MOSFET turns on, keeping the output to ground. The soft end time also depends on load condition.

7.8 Gate drivers

The integrated high-current drivers allow to use different power MOSFETs. The high side driver MOSFET uses a bootstrap circuit which is indirectly supplied by LDO5 output. The BOOT and PHASE pins work respectively as supply and return rails for the HS driver.
The low side driver uses the internal LDO5 output for the supply rail and PGND pin as return rail.
An important feature of the gate drivers is the adaptive anti-cross conduction protection, which prevents high side and low side MOSFETs from being on at the same time. When the high side MOSFET is turned off the voltage at the phase node begins to fall. The low side MOSFET is turned on when the voltage at the phase node reaches an internal threshold. When the low side MOSFET is turned off, the high side remains off until the LGATE pin voltage goes approximately under 1 V.
The power dissipation of the drivers is a function of the total gate charge Qg of the external power MOSFETs and of the switching frequency, as shown in the following equation:
(1(1
7LPH
Where V
26/48 Doc ID 11674 Rev 8
is the 5 V driver supply.
driver
fQVP ××=
swgdriverdriver
PM6685 Device description

7.9 Reference voltage and bandgap

The 1.230 V (typ.) internal bandgap voltage is accurate to ±1% over the temperature range. It is externally available (VREF pin) and can supply up to ±100μA and can be used as a voltage threshold for the multifunction pins FSEL, SKIP and LDO3_SEL to select the appropriate working mode. Bypass VREF to ground with a 100nF minimum capacitor.
If VREF goes below 0.87 V (typ.), the system detects a fault condition and all the circuitry is turned off. A toggle on the input voltage (power on reset) or a toggle on SHDN pin is necessary to restart the device.
An internal divider of the bandgap provides a voltage reference Vr of 0.9 V. This voltage is used as reference for the linear and the switching regulators outputs. The overvoltage protection, the undervoltage protection and the power good signals are referred to Vr.

7.10 Internal linear regulators

The PM6685 has two linear regulators providing respectively 5 V(LDO5) and 3.3 V(LDO3) at ±2% accuracy. High side drivers, low side drivers and most of internal circuitry are supplied by LDO5 output through VCC pin (an external RC filter may be applied between LDO5 and VCC). Both linear regulators can provide an average output current of 50 mA and a peak output current of 100 mA. Bypass both LDO5 and LDO3 outputs with a minimum 1 μF ceramic capacitor and a 4,7 μF tantalum capacitor (ESR < 2 Ω). If the 5 V output goes below 4V, the system detects a fault condition and all the circuitry is turned off. A power on reset or a toggle on SHDN pin is necessary to restart the device.
V5SW pin allows to keep the 5 V linear regulator always active or to enable the internal bootstrap-switch over function: if the 5 V switching output is connected to V5SW, when the voltage on V5SW pin is above 4.8 V, an internal 3.0 Ω max p-channel MOSFET switch connects V5SW pin to LDO5 pin and simultaneously LDO5 shuts down. This configuration allows to achieve higher efficiency. V5SW can be connected also to an external 5 V supply. LDO5 regulator turns off and LDO5 is supplied externally. If V5SW is connected to ground, the internal 5 V regulator is always on and supplies LDO5 output.

Table 7. V5SW multifunction pin

V5SW Description
GND The 5V linear regulator is always turned on and supplies LDO5 output.
Switching 5V
output
External 5V
supply
The 5V linear regulator is turned off when the voltage on V5SW is above 4.8V and LDO5 output is supplied by the switching 5V output.
The 5V linear regulator is turned off when the voltage on V5SW is above 4.8V and LDO5 output is supplied by the external 5V.
The 3.3 V linear regulator is supplied by LDO5 output.
LDO3_SEL pin allows to keep 3.3 V linear regulator always enabled, always disabled or to enable the internal bootstrap-switch over function. According to
If LDO3_SEL is connected to VREF pin, when the power good signal of the 3.3 V
Ta ble 7 :
switching output voltage PGOOD3(see related sections) is high, the internal linear
Doc ID 11674 Rev 8 27/48
Device description PM6685
regulator is turned off and LDO3 output is connected directly to OUT3 pin through an internal 3 Ω max p-channel MOSFET switch.
If LDO3_SEL is connected to 5V, the internal 3.3 V regulator is always on and supplies
LDO3 output.
If LDO3_SEL is connected to ground, the internal 3.3 V regulator is always off and
LDO3 output is clamped to ground.

Table 8. LDO3_SEL multifunction pin

LDO3_SEL Description
GND The 3.3V linear regulator is always turned off.
VREF
LDO5 The 3.3V linear regulator is always turned on and supplies LDO3 output.
The 3.3V linear regulator is turned off when PGOOD3 is high. LDO3 output is supplied by the switching 3.3V output.

7.11 Power up sequencing and operative modes

Let’s consider SHDN, EN5 and EN3 low at the beginning. The battery voltage is applied as input voltage. The device is in shutdown mode.
When the SHDN pin voltage is above the shutdown device on threshold(1.5V typ.), the controller begins the power-up sequence. All the latched faults are cleared. LDO5 undervoltage control is blanked for 4 ms and the internal regulator LDO5 turns on. If the LDO5 output is above the UVLO threshold after this time, the device enters in standby mode. The switching outputs are kept to ground by turning on the low side MOSFETs.
When EN5 and EN3 pins are forced high the switching sections begin their soft start sequence.
LDO3 management is independent from the general power up sequence and depends only on LDO3_SEL.

Table 9. Operatives modes

Mode Conditions Description
Run
SHDN is high EN3/EN5 pins are high
Switching regulators are enabled; internal linear regulators outputs are enabled.
Internal Linear regulators active (LDO5 is always on
Stand
Shutdown SHDN is low All circuits off.
28/48 Doc ID 11674 Rev 8
by Both EN5/EN3 pins are low and SHDN pin is high
while LDO3 depends on LDO3_SEL pin). In Standby mode LGATE5/LGATE3 pins are forced high while HGATE5/HGATE3 pins are forced low.
PM6685 Monitoring and protections

8 Monitoring and protections

8.1 Power good signals

The PM6685 provides three independent power good signals: one for each switching section(PGOOD5/PGOOD3) and the other for the internal linear regulator LDO3(PGOOD_LDO3).
PGOOD5/PGOOD3 signals are low if the output voltage is out of ±10% of the designed set point or during the soft-start, the soft end and when the device works in standby and shutdown mode.
PGOOD_LDO3 signal is low when the output voltage of LDO3 output is lower than its falling voltage threshold(2.6 V typ.). Each power good pin is an open-drain output and can sink current up to 4 mA.

8.2 Thermal protection

The PM6685 has a thermal protection to preserve the device from overheating. The thermal shutdown occurs when the die temperature goes above +150°C. In this case all internal circuitry is turned off and the power sections are turned off after the discharge mode.
A power on reset or a toggle on the SHDN pin is necessary to restart the device.

8.3 Overvoltage protection

When the switching output voltage is about 115% of its nominal value, a latched overvoltage protection occurs. In this case, the synchronous rectifier immediately turns on while the high-side MOSFET turns off. The output capacitor is rapidly discharged and the load is preserved from being damaged. The overvoltage protection is also active during the soft start. Once an overvoltage protection has been detected, a toggle on SHDN, EN3/EN5 pins or a power on reset is necessary to exit from the latched state.

8.4 Undervoltage protection

When the switching output voltage is below 70% of its nominal value, a latched undervoltage protection occurs. In this case the switching section is immediately disabled and both switches are open. The controller enters in soft end mode and the output is eventually kept to ground, turning low side MOSFET on. The undervoltage circuit protection is enabled only at the end of the soft-start. Once an overvoltage protection has been detected, a toggle on SHDN, EN5/EN3 pin or a power on reset is necessary to clear the undervoltage fault and starts with a new soft-start phase.
Doc ID 11674 Rev 8 29/48
Monitoring and protections PM6685

Table 10. Protections and operatives modes

Mode Conditions Description
Overvoltage
protection
Undervoltage
protection
Thermal
shutdown
OUT5/OUT3 > 115% of the nominal value
OUT5/OUT3 < 70% of the nominal value
> +150°C
T
J

8.5 Design guidelines

The design of a switching section starts from two parameters:
Input voltage range: in notebook applications it varies from the minimum battery
voltage, VINmin to the AC adapter voltage, VINmax.
Maximum load current: it is the maximum required output current, ILOAD(max).

8.6 Switching frequency

It’s possible to set 3 different working frequency ranges for the two sections: 200 kHz/300 kHz, 400 kHz/500 kHz, 600 kHz/700 kHz with FSEL pin.
Switching frequency mainly influences two parameters:
Inductor size: for a given saturation current and RMS current, greater frequency allows
to use lower inductor values, which means smaller size.
Efficiency: switching losses are proportional to frequency. High frequency generally
involves low efficiency.
LGATE5/LGATE3 pin is forced high, LDO5 remains active. Exit by a power on reset or toggling SHDN or
EN5/EN3
LGATE5/LGATE3 is forced high after the soft end
mode, LDO5 remains active. Exit by a power on reset or toggling SHDN or EN5/EN3
All circuitry off. Exit by a POR on VIN or toggling
SHDN.

8.7 Inductor selection

Once that switching frequency is defined, inductor selection depends on the desired inductor ripple current and load transient performance.
Low inductance means great ripple current and could generate great output noise. On the other hand, low inductor values involve fast load transient response.
A good compromise between the transient response time, the efficiency, the cost and the size is to choose the inductor value in order to maintain the inductor ripple current ΔIL between 20% and 50% of the maximum output current ILOAD(max). The maximum ΔIL occurs at the maximum input voltage. With this considerations, the inductor value can be calculated with the following relationship:
Equation 10
VV
L ×
=
30/48 Doc ID 11674 Rev 8
OUTIN
If
Δ×
Lsw
V
OUT
V
IN
PM6685 Monitoring and protections
where fsw is the switching frequency, VIN is the input voltage, VOUT is the output voltage and ΔIL is the selected inductor ripple current.
In order to prevent overtemperature working conditions, inductor must be able to provide an RMS current greater than the maximum RMS inductor current ILRMS:
Equation 11
Δ
2
L
(max))I(I
LOADLRMS
+=
2
(max))I(
12
Where ΔIL(max) is the maximum ripple current:
Equation 12
VV
sw
Lf
×
(max)I ×
L
=Δ
V
OUTmaxIN
OUT
V
maxIN
If hard saturation inductors are used, the inductor saturation current should be much greater than the maximum inductor peak current Ipeak:
Equation 13
LOAD
2
Δ
(max)I
L
+=
(max)IIpeak
Using soft saturation inductors it’s possible to choose inductors with saturation current limit nearly to Ipeak.
Below there is a list of some inductor manufacturers.

Table 11. Inductor manufacturer

Manufacturer Series Inductor value (µH) RMS current (A) Saturation current (A)
COILCRAFT SER1360 4 to 8 6 to 8.6 7 to 12
COILCRAFT MLC 2.2 to 4.5 13.6 to 8.8 11.5 to 17
TDK RLF12560 2.7 to 10 7.5 to 11.5 7.5 to 14.4

8.8 Output capacitor

The selection of the output capacitor is based on the ESR value Rout and the voltage rating rather than on the capacitor value Cout.
The output capacitor has to satisfy the output voltage ripple requirements. Lower inductor value can reduce the size of the choke but increases the inductor current ripple ΔIL.
Since the voltage ripple VRIPPLEout is given by:
Equation 14
IRV Δ×=
LoutRIPPLEout
Doc ID 11674 Rev 8 31/48
Monitoring and protections PM6685
A low ESR capacitor is required to reduce the output voltage ripple. Switching sections can work correctly even with 20 mV output ripple.
However, to reduce jitter noise between the two switching sections it’s preferable to work with an output voltage ripple greater than 30 mV. If lower output ripple is required, a further compensation network is needed (see
Closing the integrator loop paragraph).
Finally the output capacitor choice deeply impacts on the load transient response (see
transient response

Table 12. Output capacitor manufacturer

Manufacturer Series
SANYO
PANASONIC SPCAP UD, UE 150 to 220 4 to 6.3 9 to 18
paragraph). Below there is a list of some capacitor manufacturers.
POSCAP TPB,TPD

8.9 Input capacitors selection

In a buck topology converter the current that flows into the input capacitor is a pulsed current with zero average value. The input RMS current of the two switching sections can be roughly estimated as follows:
Equation 15
Where D1, D2 are the duty cycles and I1, I2 are the maximum load currents of the two sections.
Capacitor value
(μF)
150 to 330 4 to 6.3 35 to 65
2
11CinRMS
Rated voltage (V) ESR max (mΩ)
2 221
)D1(ID)D1(IDI
××+××=
2
Load
Input capacitor should be chosen with an RMS rated current higher than the maximum RMS current given by both sections.
Tantalum capacitors are good in term of low ESR and small size, but they occasionally can burn out if subjected to very high current during the charge. Ceramic capacitors have usually a higher RMS current rating with smaller size and they remain the best choice.
Below there is a list of some ceramic capacitor manufacturers.

Table 13. Input capacitor manufacturer

Manufacturer Series
TAYIO YUDEN UMK325BJ106KM-T10 10 50
TAYIO YUDEN GMK325BJ106MN 10 35
TDK C3225X5R1E106M 10 25
32/48 Doc ID 11674 Rev 8
Capacitor value
(μF)
Rated voltage (V)
PM6685 Monitoring and protections

8.10 Power MOSFETs

Logic-level MOSFETs are recommended, since low side and high side gate drivers are powered by LDO5. Their breakdown voltage VBR
In notebook applications, power management efficiency is a high level requirement. The power dissipation on the power switches becomes an important factor in switching selections. Losses of high-side and low-side MOSFETs depend on their working conditions.
The power dissipation of the high-side MOSFET is given by:
Equation 16
Maximum conduction losses are approximately:
Equation 17
must be higher than VINmax.
DSS
PPP +=
switchingconductionDHighSide
V
RP ××=
DSonconduction
OUT
V
LOAD
minIN
2
(max)I
where RDSon is the drain-source on resistance of the high side MOSFET.
Switching losses are approximately:
Equation 18
I
Δ
L
+×
2
ft)
××
swoff
2
P
switching
I
Δ
(max)I(V
LOADIN
=
L
×
2
2
ft)
××
+
(max)I(V
LOADINswon
where ton and toff are the switching times of the turn off and turn off phases of the MOSFET.
As general rule, high side MOSFETs with low gate charge are recommended, in order to minimize driver losses.
Below there is a list of possible choices for the high side MOSFET.

Table 14. High side MOSFET manufacturer

Manufacturer Type Gate charge (nC) Rated reverse voltage (V)
ST STS12NH3LL 10 30
ST STS17NH3LL 18 30
The power dissipation of the low side MOSFET is given by:
Equation 19
PP =
conductionDLowSide
Maximum conduction losses occur at the maximum input voltage:
Doc ID 11674 Rev 8 33/48
Monitoring and protections PM6685
Equation 20
DSonconduction
Choose a synchronous rectifier with low R
⎛ ⎜
1RP ×
×=
⎜ ⎝
. When high side MOSFET turns on, the fast
DSon
V
OUT
LOAD
V
maxIN
2
(max)I
variation of the phase node voltage can bring up even the low side gate through its gate­drain capacitance CRSS, causing cross-conduction problems. Choose a low side MOSFET that minimizes the ratio CRSS/CGS (CGS = CISS - CRSS).
Below there is a list of some possible low side MOSFETs.

Table 15. Low side MOSFET manufacturer

Manufacturer Type RDSon (mΩ)
ST STS17NF3LL 5.5 0.047 30
ST STS25NH3LL 3.5 0.011 30
Rated reverse voltage
(V)
Dual n-channel MOSFETs can be used in applications with a maximum output current of about 3 A. Below there is a list of some MOSFET manufacturers.

Table 16. Dual MOSFET manufacturer

Manufacturer Type RDSon (mΩ) Gate charge (nC)
ST STS8DNH3LL 25 10 30
ST STS4DNF60L 65 32 60
Rated reverse
voltage (V)
A rectifier across the low side MOSFET is recommended. The rectifier works as a voltage clamp across the synchronous rectifier and reduces the negative inductor swing during the dead time between turning the high-side MOSFET off and the synchronous rectifier on. It can increase the efficiency of the switching section, since it reduces the low side switch losses. A schottky diode is suitable for its low forward voltage drop (0.3 V). The diode reverse voltage must be greater than the maximum input voltage VINmax. A minimum recovery reverse charge is preferable. Below there is a list of some schottky diode manufacturers.

Table 17. Schottky diode manufacturer

Manufacturer Series
ST STPS1L30M 0.34 30 0.00039
ST STPS1L20M 0.37 20 0.000075
Forward voltage

8.11 Closing the integrator loop

The design of external feedback network depends on the output voltage ripple. If the ripple is higher than approximately 30 mV, the feedback network ( keep the loop stable.
(V)
Rated reverse
voltage (V)
Reverse current
(uA)
Figure 36) is usually enough to
34/48 Doc ID 11674 Rev 8
PM6685 Monitoring and protections

Figure 36. Circuitry for output ripple compensation

#/-00).
#/-00). 6/,4!'%
6/,4!'%
ǻ6
6R
6R
/540546/,4!'%
/540546/,4!'%
ǻ6
)GM66R
T
T
#&),4
#&),4
#&),4
#&),4
ǻ6
ǻ6
T
T
,
,
,
,
$
$
$
$
#)
#)
.4
.4
#).4
#).4
2)
2)
.4
.4
2).4
2).4
#/-0
#/-0
#/-0
#/-0
2/54
2/54
2/54
2/54
#/54
#/54
#/54
#/54
/54
/54
/54
/54
6#
6#
).4
).4
6#).4
6#).4
)GM66R

6R
6R
6R
6R
2&B
2&B
2&B
2&B
GM
GM
GM
GM
6R
6R
6R
6R
07-
07-
-
-
07
07
#OMPARATOR
#OMPARATOR
#OMPARATOR
#OMPARATOR
2&B
2&B
2&B
2&B
6
6
6
6
The stability of the system depends firstly on the output capacitor zero frequency. The following condition should be satisfied:
Equation 21
fkf
=×>
Zoutsw
k
RC2
××π
outout
where k is a design parameter greater than 3 and Rout is the ESR of the output capacitor. It determinates the minimum integrator capacitor value CINT:
Equation 22
g
C ×
>
INT
2
m
f
sw
f
×π
⎜ ⎝
Zout
k
Vr
V
OUT
⎟ ⎠
where gm=50us is the integrator transconductance.
In order to ensure stability it must be also verified that:
Equation 23
g
C ×
INT
m
>
f2
×π
Vr
V
OUTZout
In order to reduce ground noise due to load transient on the other section, it is recommended to add a resistor RINT and a capacitor Cfilt that, together with CINT, realize a low pass filter (see
Figure 36). The cutoff frequency fCUT must be much greater (10 or more
times) than the switching frequency of the section:
Doc ID 11674 Rev 8 35/48
Monitoring and protections PM6685
J
J
U
9
Equation 24
f2
CUT
1
CC
×
××π
filtINT
CC
+
filtINT
R
=
INT
Due to the capacitive divider (CINT, Cfilt), the ripple voltage at the COMP pin is given by:
Equation 25
C
INT
VV
RIPPLEoutRIPPLE
INT
×=
CC
+
filtINT
RIPPLEout
qV
×=
Where VRIPPLEout is the output ripple and q is the attenuation factor of the output ripple.
If the ripple is very small (lower than approximately 30 mV), a further compensation network, named virtual ESR network, is needed. This additional part generates a triangular ripple that is added to the ESR output voltage ripple at the input of the integrator network. The complete control schematic is represented in
Figure 37.

Figure 37. Virtual ESR network

W
&
&
&2033,1 92/7$*(
9U
&
)),,//7
&
7
5
,,117
5
W
7
ǻ9
3
&&22003
7
&
,,117
&
22887
7
, JP99U
P
P
9
55))EE
9U
33::00
&&RRPPSSDDUUDDWWRRU
U
5)E
9
ǻ9
ǻ
287387 92/7$*(
W
712'( 92/7$*(
5
5
7
55
/
/
5
22887
5
'
'
&
22887
&
The T node voltage is the sum of the output voltage and the triangular waveform generated by the virtual ESR network. In fact the virtual ESR network behaves like a further equivalent ESR RESR.
A good trade-off is to design the network in order to achieve an RESR given by:
Equation 26
V
=
RIPPLE
Δ
I
R
ESR
36/48 Doc ID 11674 Rev 8
7
7
R
L
out
PM6685 Monitoring and protections
where ΔIL is the inductor current ripple and VRIPPLE is the overall ripple of the T node voltage. It should be chosen higher than approximately 30mV.
The stability of the system depends firstly on the output capacitor value and on RTOT:
Equation 27
RRR +=
outESRTOT
The following condition should be satisfied:
Equation 28
fkf
=×>
Zsw
k
××π
RC2
TOTout
Where k is a free design parameter greater than 3 and determines the minimum integrator capacitor value CINT:
Equation 29
g
C ×
>
INT
m
f
sw
2
×π
k
Vr
V
OUT
f
Z
In order to ensure stability it must be also verified that:
Equation 30
g
C ×
INT
m
>
f2
×π
Vr
V
OUTZout
C must be selected as shown:
Equation 31
C5C ×>
INT
R must be chosen in order to have enough ripple voltage on integrator input:
Equation 32
R
L
=
ESR
CR
×
R1 can be selected as follows:
Doc ID 11674 Rev 8 37/48
Monitoring and protections PM6685
Equation 33
⎛ ⎜
R
×
1R
=
R
1
⎟ ⎟
fC
×π×
Z
1
fC
×π×
Z
Example:
5 V section, f
=200 kHz, L=4.7 µH, Cout=100 µF ceramic (Rout~0 Ω). We design
SW
RESR = 30 mΩ. We choose CINT=1 nF by equations 31, 32 and Cfilt=47 pF, RINT=1.8 kΩ by eq.26,27. C=6.8 nF by Eq.33. Then R=22 kΩ (eq.34) and R1=1 kΩ (eq.35).
38/48 Doc ID 11674 Rev 8
PM6685 Other parts design
S
S

9 Other parts design

VIN filter
A VIN pin low pass filter is suggested to reduce switching noise. The low pass filter is shown in the next figure:

Figure 38. VIN pin filter

5
5
1
,QSXW YROWDJH
Typical components values are: R=3.9 Ω and C=4.7 µF.
VCC filter
A VCC low pass filter helps to reject switching commutations noise:
&
&

99,,1
)
)

Figure 39. Inductor current waveforms

//''22
5
5
&
99&&&
&
&
Typical components values are: R=47 Ω and C=1 µF.
VREF capacitor
A 10 nF to 100 nF ceramic capacitor on VREF pin must be added to ensure noise rejection.
LDO3 and LDO5 output capacitors
Bypass the output of each linear regulator with 1 µF ceramic capacitor closer to the LDO pin and a 4.7 µF tantalum capacitor (ESR=2 Ω). In most applicative conditions a 4.7 µF ceramic output capacitor can be enough to ensure stability.
Bootstrap circuit
The external bootstrap circuit is represented in the next figure:
Doc ID 11674 Rev 8 39/48
Other parts design PM6685
$
$

Figure 40. Bootstrap circuit

'
'
7
5
%%22227
5
%%22227
7
&
%%22227
/
/
&
33+
//''22
+
7
66(
(
The bootstrap circuit capacitor value CBOOT must provide the total gate charge to the high side MOSFET during turn on phase. A typical value is 100 nF.
The bootstrap diode D must charge the capacitor during the off time phases. The maximum rated voltage must be higher than VINmax.
A resistor RBOOT on the BOOT pin could be added in order to reduce noise when the phase node rises up, working like a gate resistor for the turn on phase of the high side MOSFET.
40/48 Doc ID 11674 Rev 8
PM6685 Design example

10 Design example

The following design example considers an input voltage from 7 V to 16 V. The two switching outputs must deliver a maximum current of 5A. The selected switching frequencies are 200 kHz for the 5 V section and 300 kHz for the 3.3 V section.

10.1 Inductor selection

OUT5: I
Equation 34
We choose standard value L = 6 µH ΔI
L(max)
I
= 5.07 A
LRMS
I
= 5 A + 0.95 A = 6.43 A
peak
OUT3: ILOAD = 5 A, 50% ripple current.
Equation 35
We choose standard value L=4 µH. ΔI
L(max)
= 5.04 A
I
LRMS
I
= 5 A + 1.1 A = 6.1 A
peak
= 5 A, 60% ripple current.
LOAD
= 2.86 A @V
= 2.2 A @V
IN
IN
=16 V
=16 V
L μ
=
L μ
=
)V5V16(V5
56.0V16KHz200
)33.316(33.3
55.0V16KHz300
H7.5
H52.3

10.2 Output capacitor selection

We would like to have an output ripple greater than 35mV.
OUT5: POSCAP 6TPB330M
OUT3: POSCAP 6TPB330M

10.3 Power MOSFETs

OUT5: High side: STS12NH3LL
Low side: STS12NH3LL
OUT3: High side: STS12NH3LL
Doc ID 11674 Rev 8 41/48
Design example PM6685
Low side: STS12NH3LL

10.4 Current limit

OUT5:
Equation 36
(min)I
Δ
Equation 37
(max)I(min)I
LOADLvalley
L
=
2
22.4
=
(Let’s assume the maximum temperature Tmax = 75°C in R
OUT3:
Equation 38
Equation 39
(Let’s assume Tmax = 75°C in R

10.5 Input capacitor

Maximum input capacitor RMS current is about 3.4 A. Then I
We put three 10 µF ceramic capacitors with Irms = 1.5 A.
R
CSENSE
R
CSENSE
686m25.16
LOADLvalley
681m25.16
calculation)
DSon
A22.4
μ
A100
(min)I
Δ
(max)I(min)I
L
=
2
A19.4
μ
A100
ΩΩ
calculation)
DSon
=
ΩΩ
CinRMS
A19.4
> 3.4 A

10.6 Synchronous rectifier

OUT5: Schottky diode STPS1L30M
OUT3: Schottky diode STPS1L30M

10.7 Integrator loop

(Refer to Figure 30 on page 22)
OUT5: The ripple is greater than 30 mV, then the virtual ESR network is not required.
C
=1 nF; C
INT
42/48 Doc ID 11674 Rev 8
= 47 pF; R
filt
INT
= 1 kΩ
PM6685 Design example
OUT3: The ripple is greater than 30 mV, then the virtual ESR network is not required.
C
=1 nF; C
INT
= 47 pF; R
filt
INT
= 1 kΩ

10.8 Layout guidelines

The layout is very important in terms of efficiency, stability and noise of the system. It is possible to refer to the PM6685 demonstration board for a complete layout example.
For good PC board layout follows these guidelines:
Place on the top side all the power components (inductors, input and output capacitors,
MOSFETs and diodes). Refer them to a power ground plan, PGND. If possible, reserve a layer to PGND plan. The PGND plan is the same for both the switching sections.
AC current paths layout is very critical (see Figure 41 on page 44). The first priority is to
minimize their length. Trace the LS MOSFET connection to PGND plan as short as possible. Place the synchronous diode D near the LS MOSFET. Connect the LS MOSFET drain to the switching node with a short trace.
Place input capacitors near HS MOSFET drain. It is recommended to use the same
input voltage plan for both the switching sections, in order to put together all input capacitors.
Place all the sensitive analog signals (feedbacks, voltage reference, current sense
paths) on the bottom side of the board or in an inner layer. Isolate them from the power top side with a signal ground layer, SGND. Connect the SGND and PGND plans only in one point (a multiple vias connection is preferable to a 0 ohm resistor connection) near the PGND device pin. Place the device on the top or on the bottom size and connect the exposed pad and the SGND pins to the SGND plan (see
Figure 41 on page 44).
Doc ID 11674 Rev 8 43/48
Design example PM6685

Figure 41. Current paths, ground connection and driver traces layout

As general rule, make the high side and low side drivers traces wide and short.
The high side driver is powered by the bootstrap circuit. It’s very important to place capacitor CBOOT and diode DBOOT as near as possible to the HGATE pin (for example on the layer opposite to the device). Route HGATE and PHASE traces as near as possible in order to minimize the area between them. The Low side gate driver is powered by the 5V linear regulator output. Placing PGND and LGATE pins near the low side MOSFETs reduces the length of the traces and the crosstalk noise between the two sections.
The linear regulator outputs are referred to SGND as long as the reference voltage
Vref. Place their output filtering capacitors as near as possible to the device.
Place input filtering capacitors near VCC and VIN pins.
It would be better if the feedback networks connected to COMP and OUT pins are
“referred” to SGND in the same point as reference voltage Vref. To avoid capacitive coupling place these traces as far as possible from the gate drivers and phase (switching) paths.
Place the current sense traces on the bottom side. Use a dedicated connection
between the switching node and the current limit resistor RCSENSE.
44/48 Doc ID 11674 Rev 8
PM6685 Package mechanical data

11 Package mechanical data

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK
®
packages, depending on their level of environmental compliance. ECOPACK® specifications, grade definitions and product status are available at: www.st.com. ECOPACK is an ST trademark.

Table 18. VFQFPN 5x5x1.0 32L pitch 0.50 package dimensions

Databook (mm)
Dim.
Min Typ Max
A0.80.91
A1 0 0.02 0.05
A3 0.2
b 0.18 0.25 0.3
D4.8555.15
D2 See exposed pad variations
E4.8555.15
E2 See exposed pad variations
e0.5
L 0.3 0.4 0.5
ddd 0.05

Table 19. Exposed pad variations

(1)(2)
D2
(2)
(2)
E2
Min Typ Max Min Typ Max
2.90 3.10 3.20 2.90 3.10 3.20
1. VFQFPN stands for Thermally Enhanced Very thin Fine pitch Quad Flat Package No lead. Very thin:
A = 1.00mm Max.
2. Dimensions D2 & E2 are not in accordance with JEDEC.
Doc ID 11674 Rev 8 45/48
Package mechanical data PM6685

Figure 42. VFQFPN 5x5x1.0 32L pitch 0.50 package drawings

46/48 Doc ID 11674 Rev 8
PM6685 Revision history

12 Revision history

*

Table 20. Document revision history

Date Revision Changes
17-Jan-2006 1 Initial release
21-Apr-2006 2 Few updates
03-May-2006 3 Graphical updates
29-Jun-2006 4 Mechanical data updated
11-Sep-2006 5
24-Oct-2006 6 Order code table updated
18-Oct-2007 7
30-Mar-2011 8
Changes electrical characteristics, added COMP value skip mode, pin out updated
Updated: Current sensing option and absolute maximum ratings Table 3 on page 8.
Updated: Coverpage, Ta ble 2 , Ta bl e 5 , Section 7, Figure 29,
Section 7.9
Doc ID 11674 Rev 8 47/48
PM6685
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY, DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2011 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Philippines - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
48/48 Doc ID 11674 Rev 8
Loading...
