ST LIS2DH User Manual

ultra low-power high performance 3-axis “femto” accelerometer

LGA-14

(2.0x2.0x1 mm)

Features

■ Wide supply voltage, 1.71 V to 3.6 V

■ Independent IOs supply (1.8 V) and supply

voltage compatible

■ Ultra low-power mode consumption down to 2

µA

■ ±2g/±4g/±8g/±16g dynamically selectable full-

scale

2

■ I

C/SPI digital output interface

■ 2 independent programmable interrupt

generators for free-fall and motion detection

■ 6D/4D orientation detection

■ “Sleep to wake” and “return to sleep” function

■ Freefall detection

■ Motion detection

■ Embedded temperature sensor

■ Embedded FIFO

■ ECOPACK

Applications

■ Motion activated functions

■ Display orientation

■ Shake control

■ Pedometer

■ Gaming and virtual reality input devices

■ Impact recognition and logging

®

RoHS and “Green” compliant

LIS2DH

MEMS digital output motion sensor:

Description

The LIS2DH is an ultra low-power high
performance three-axis linear accelerometer
belonging to the “femto” family, with digital I
serial interface standard output.

The LIS2DH has dynamically user selectable full
scales of ±2g/±4g/±8g/±16g and it is capable of
measuring accelerations with output data rates
from 1 Hz to 5.3 kHz.

The self-test capability allows the user to check
the functioning of the sensor in the final
application.

The device may be configured to generate
interrupt signals by two independent inertial
wake-up/free-fall events as well as by the position
of the device itself.

The LIS2DH is available in small thin plastic land
grid array package (LGA) and is guaranteed to
operate over an extended temperature range from

-40 °C to +85 °C.

2

C/SPI

Table 1. Device summary

Order codes Temperature range [°C] Package Packaging

LIS2DH -40 to +85 LGA-14 Tray

LIS2DHTR -40 to +85 LGA-14 Tape and reel

November 2011 Doc ID 022516 Rev 1 1/49

www.st.com

49
