ST AN594 Application note

AN594
Application note
Direct LCD drive with
ST621xx and ST626xx

Introduction

This note describesatechnique for drivingaLiquid Crystal Display (LCD) withastandard ST62 microcontroller (MCU), without any dedicated LCD driver. This technique offersadisplay capa­bility for applications which require a small display atalow cost together with the versatile ca­pabilities of the standard ST62xx MCU. Higher display requirements are easily handled by dedicated members of the ST62 MCU family, for example the ST6240B.
The first part of this note describes the typical waveforms required to drive an LCD correctly withamultiplexing rate of1or2(duplex). The following parts present two solutions based on standard ST62 MCUs driving directly the LCD. The first is based on an ST6215 without using software interrupts and the second on an ST6265 where the LCD is controlled by timer inter­rupts.
In both examples the program size, the CPUtime occupation due to the LCD drive and the number of surrounding components are minimized. Consequently many additional tasks can be added to the MCU program.

LCD requirements

Withazero Root Mean Square (RMS) voltage applied to it, an LCD is practically transparent. The LCD contrast, which makes the segments turn dark or opaque and thus “on”, is caused by the difference between the RMS LCD voltage applied and the LCD threshold voltage, specific to each LCD type.
The applied LCD voltage must alternate to giveazero DC value in order to ensurealong life
the LCD. The higher the multiplexing rate is, the lower the contrast, also the period of
time of the signal has to be short enough to avoid visible flickering of the LCD display. The LCD volt­age for each segment equals to the difference between theSand COM voltages (see Figure
1).
Figure 1. Equivalent electrical schematic of an LCD segment
October 2008 Rev 2
DC value should never be more than
-
100mV. Else time life can be shorten. Frequency range is 30-2000Hz typically.
-
Less, it flickers; more, consumption grows.
1/28

Direct LCD Drive

Direct LCD drive
Each LCD segment is connected to an I/O “Segment” and to one backplane common to all the segments. A display using S segments is driven with S+1 MCU output lines. The backplane is driven with a signal “COM” controlled between 0 and V
with a duty cycle of 50%.
DD
When selecting a segment “ON”, a signal with opposite polarity to “COM” is sent to the corre­sponding “Segment” pin. When the non-inverted signal “COM” is sent to the “Segment” pin, the segment is “OFF”. Using an MCU the I/O operate in output mode either at the logic levels 0 or
1.
Figure 2. LCD signals for direct drive
2/28

Duplexed LCD drive

For duplexed drive, two backplanes are used instead of one. Each LCD pin is connected to two LCD segments, each one connected on the other side to one of the two backplanes. Thus, only (S/2)+2 MCU pins are necessary to drive an LCD with S segments.
Three different voltage levels have to be gen­erated on the backplanes : 0, V
/2 and VDD.
DD
The “Segment” voltage levels are 0 and Vdd only. The LCD segment is inactive if the RMS voltage is below the LCD threshold voltage and is active if the LCD RMS voltage is above the threshold voltage. Figure 4 shows typical Backplane, Segment and LCD wave­forms.
The intermediate voltage V
/2 is only re-
DD
quired for the “Backplane” voltages. The ST62 I/O pins selected as “Backplanes” are set by software to output mode for 0 or Vdd levels and to high impedance input mode for V
/2. This voltage Vdd/2 is defined by two
DD
equal valued resistors externally connected to the I/O pin.
By using an MCU with flexible I/O pin config­uration such as the ST6215x or ST6265x, duplexed LCD drive can be made with only 4 additional resistors.
Direct LCD Drive
Figure 3. Basic LCD segment connec­tion in duplexed mode
3/28
Direct LCD Drive
Figure 4. LCD signals for duplexed mode (used in ST6215 example)
4/28
Direct LCD Drive

Example of duplexed LCD drive with ST6215x

The following example describes the drive in duplexed mode of an LCD with an ST6215. The software is made in such way that no interrupt is generated and an OFF state for the LCD is possible. The only components necessary are those to drive the ST62 (oscillator, reset,...) and four resistors to generate the backplane intermediate voltages.
The ST6215 has 20 I/O pins, thus it is able to drive up to 36 LCD segments and 2 backplanes. One digit is defined with 8 segments connected to 2 backplanes. Each digit can display 11 val­ues, from 0 to 9 and no display.
Each value to be displayed is associated to a certain LCD waveform. One LCD waveform pe­riod is separated in 4 steps corresponding to the 3 I/O configurations (1-0-input). A look-up ta­ble stores the bytes which relate the I/O configuration to the value to display.
Figure 5. ST6215 based example
5/28
Direct LCD Drive
The following tables show an example of linking one LCD digit of the display with the relevant MCU port se quences. The second digit follows the same scheme. These examples are for the sample LCD display, please adapt these tables to your particular LCD.
The digit segments are connected to PB0-PB3 lines in this example. Schematic is shown in Figure 5. Each digit configuration definesasegment status. Each couple of segments defines a timing sequence to be output by MCU “Segment” lines (see Figure 4). These sequences are coded inside the ST6215.
Table 1: Example of drive ofadigit with ST6215
Digit Segments to Display Segment Connections
Digit
Required
Digit
Required
a
f b
g
e
c
d
Segments
COM1 ON ON ON ON
COM2 OFF ON OFF ON
T1 0000 0h
T2 0101 5h
T3 1010 Ah
T4 1111 Fh
COM1 OFF OFF OFF OFF
COM2 OFF ON OFF ON
T1 1111 Fh
T2 1010 5h
T3 0101 Ah
T4 0000 0h
Status
Timing Sequences
Timing Sequences
Segment Line PB3 PB2 PB1 PB0
COM1 (PA6) d e f a
COM2 (PA7) OFF c g b
Segments
Status
MCU
Output
Sequences
MCU
Output
Sequences
Digit
Required
Blank
Digit
Required
Segments
COM1 OFF OFF OFF OFF
COM2 OFF OFF OFF OFF
Timing Sequences
T1 1111 Fh
T2 0000 0h
T3 1111 Fh
T4 0000 0h
COM1 OFF OFF ON OFF
COM2 OFF ON ON ON
Timing Sequences
T1 1101 Dh
T2 0111 7h
T3 1000 8h
T4 0010 2h
Status
Segments
Status
MCU
Output
Sequences
MCU
Output
Sequences
-
6/28
Digit
Required
Digit
Required
Segments
COM1 ON ON OFF ON
COM2 OFF OFF ON ON
Timing Sequences
T1 0010 2h
T2 0011 3h
T3 1100 Ch
T4 1101 Dh
COM1 ON OFF OFF ON
COM2 OFF ON ON ON
Timing Sequences
T1 0110 6h
T2 0111 7h
T3 1000 8h
T4 1001 9h
Status
Segments
Status
MCU
Output
Sequences
MCU
Output
Sequences
Digit
Required
Digit
Required
Segments
COM1 ON OFF ON ON
COM2 OFF ON ON OFF
Timing Sequences
T1 0100 4h
T2 0110 6h
T3 1001 9h
T4 1011 Bh
COM1 ON ON ON ON
COM2 OFF ON ON OFF
Timing Sequences
T1 0000 0h
T2 0110 6h
T3 1001 9h
T4 1111 Fh
Status
Segments
Status
MCU
Output
Sequences
MCU
Output
Sequences
Direct LCD Drive
Digit
Required
Digit
Required
Segments
COM1 OFF OFF OFF ON
COM2 OFF ON OFF ON
T1 1110 Eh
T2 0101 5h
T3 1010 Ah
T4 0001 1h
COM1 ON ON ON ON
COM2 OFF ON ON ON
T1 0000 0h
T2 0111 7h
T3 1000 8h
T4 1111 Fh
Status
Timing Sequences
Segments
Status
Timing Sequences
MCU
Output
Sequences
MCU
Output
Sequences
Digit
Required
Segments
COM1 ON OFF ON ON
COM2 OFF ON ON ON
Timing Sequences
T1 0100 4h
T2 0111 7h
T3 1000 8h
T4 1011 Bh
Status
MCU
Output
Sequences
7/28
Direct LCD Drive

Example of duplexed LCD drive with ST6265x

In this example the LCD drive tasks are controlled by interrupts from an on-chip timer. This soft­ware block can be easily included in a central task such as motor control, temperature measure­ment or heating. Figure 6 shows the circuit of the application. Only 4 resistors are added to drive the LCD in the duplexed mode.
Figure 6. ST6265x based example
8/28
Direct LCD Drive
The software for the LCD display operates in interrupt mode, driving I/O pins by the CPU at in­stants defined by the Timer1 interrupts. When the LCD drive tasks are finished, the main appli­cation program can continue.
The major tasks of the LCD display routine are:
generation of the alternate signals which control the backplanes (PB0, PB1)
-
drive of the LCD segments through PortA
-
conversion of the hexadecimal data to decimal data
-
program Timer1 for the next drive sequence
-
The backplane pattern sequences are different between ST6215x and ST6265x examples. The ST6215x software is based on non-symetrical signals (see Figure 4). The backplane pat­terns are symetrical in the ST6265x software. Both are equivalent on the LCD viewpoint.
The ROM code size used is 300 bytes for the program and 256 bytes for the tables. With an CPU frequency of 8MHz, the display task duration is 240μs and the full task duration including decimal conversion is 510μs. With an LCD period signal of 14ms, the CPU duty cycle of occu­pation is 2.5% for the LCD drive task. The program can be adjusted to other applications by modifying the timer duration (FASTIM) and the segment drive byte table. The LCD drive phase may also be synchronized to the mains zero crossing or a software loop duration, saving the timer for other tasks.

Summary

The examples presented in this note show that a simple LCD can be driven directly by standard ST621x/2x/6x/9x microcontrollers. The ST62’s flexible I/O configuration and the large voltage range of operation of the ST62 family MCU allow an LCD driver to be achieved with very few surrounding components, small CPU time occupation and reduced ROM program size.
Such an approach is a very cost effective solution for simple LCD displays operating with a multiplexing rate of 1 or 2 and up to 36 segments. For LCDs requiring more segment drive ca­pability and/or higher multiplexing rates ST624x and ST628x provide highly integrated and easy to implement solutions.
Such LCD drive features can easily be included in a larger application including keyboard inter­face, sensor display or motor control.
We thank the company Akotronic for the ST6215x application example they have developed for this note.
Annex 1: Software of the ST6215x based application Annex 2: Flowchart and software of the ST6265x based application
9/28
Direct LCD Drive

ANNEX 1: Software of the ST6215x based application

;*************************************************************************** ;*DEMONSTRATION SOFTWARE FOR MANAGEMENT OF A BIPLEXED LIQUID CRISTAL ;*DISPLAY ( LCD ) WITH ST621X OR ST622X SGS THOMSON MICROCONTROLLERS ;*************************************************************************** ;* This program has been developped by AKOTRONIC comp. ;* PARC DE LA MOTHE 03400 YZEURE FRANCE
;*************************************************************************** ;* PROGRAM FOR LIQUID CRISTAL DISPLAY DRIVE ;*************************************************************************** ;* REGISTER DECLARATION ;***************************************************************************
.ROMSIZE 4 . VERS “ST6225" ; SWD, 4MHZ x .DEF 80h!m ; INDEX REGISTER
Y .DEF 81h!m ; INDEX REGISTER V .DEF 82h ; SHORT DIRECT REGISTER W .DEF 83h ; SHORT DIRECT REGISTER
A .DEF 0FFh!m ; ACCUMULATOR DRA .DEF 0C0h ; PORT A DATA REGISTER
DRB .DEF 0C1h ; PORT B DATA REGISTER DRC .DEF 0C2h ; PORT C DATA REGISTER DDRA .DEF 0C4h ; PORT A DIRECTION REGISTER DDRB .DEF 0C5h ; PORT B DIRECTION REGISTER DDRC .DEF 0C6h ; PORT C DIRECTION REGISTER
IOR .DEF 0C8h ; INTERRUPT OPTION REGISTER DWR .DEF 0C9h ; DATA ROM WINDOW REGISTER
ORA .DEF 0CCh ; PORT A OPTION REGISTER ORB .DEF 0CDh ; PORT B OPTION REGISTER ORC .DEF 0CEh ; PORT C OPTION REGISTER
ADR .DEF 0D0h ; A/D DATA REGISTER ADCR .DEF 0D1h ; A/D CONTROL REGISTER
PSC .DEF 0D2h ; TIMER PRESCALER REGISTER TCR .DEF 0D3h ; TIMER COUNTER REGISTER TSCR .DEF 0D4h ; TIMER STATUS CONTROL REGISTER
WDR .DEF 0D8h ; WATCHDOG REGISTER
;************************************************************************** ;* DATA DECLARATION ;**************************************************************************
TOUCHU .DEF 084h ;Low Significant DIGIT button ( L.S. DIGIT ) TOUCHD .DEF 085h ;More significant DIGIT button ( M.S. DIGIT ) TOUCH .DEF 086h ;pushed button COPYA .DEF 087h ;COPY of PORT A COPYB .DEF 088h ;COPY of PORT B COPYC .DEF 089h ;COPY of PORT C TABD .DEF 08Ah ;data/ROM window address to display M.S. DIGIT TABU .DEF 08Bh ;data/ROM window address to display L.S. DIGIT LOOP .DEF 08Ch ;LOOP
RELACHE.DEF 08Dh ;latch counter TOUCHP .DEF 08Eh ;previous valided button FLAGS .DEF 08Fh ;FLAGS : 0/ push on/off
;**************************************************************************
10/28
Direct LCD Drive
ANNEX 1: Software of the ST6215x based application (Continued)
;************************************************************************** ;* TABLE 1 of the Low Significant DIGIT ( L.S. DIGIT ) ;**************************************************************************
.ORG 0F00H .BYTE 00FH,09FH,06FH,0FFH,0FFH,09FH,06FH,00FH .BYTE 04FH,0CFH,03FH,0BFH,05FH,0DFH,02FH,0AFH .BYTE 0BFH,0DFH,02FH,04FH,01FH,05FH,0AFH,0EFH .BYTE 00FH,05FH,0AFH,0FFH,07FH,09FH,06FH,08FH .BYTE 00FH,0DFH,02FH,0FFH,01FH,0DFH,02FH,0EFH .BYTE 00H,00H,00H,00H,00H,00H,00H,00H .BYTE 00H,00H,00H,00H,00H,00H,00H,00H
.BYTE 00H,00H,00H,00H,00H,00H,00H,00H ;************************************************************************** ;**************************************************************************
;* TABLE 2 of the More Significant DIGIT ( M.S. DIGIT ) ;**************************************************************************
.ORG 0F40H
.BYTE 0FFH,0F0H,0FFH,0F0H,0FFH,0F5H,0FAH,0F0H
.BYTE 0F2H,0F3H,0FCH,0FDH,0F6H,0F7H,0F8H,0F9H
.BYTE 0FDH,0F7H,0F8H,0F2H,0F4H,0F6H,0F9H,0FBH
.BYTE 0F0H,0F6H,0F9H,0FFH,0FEH,0F5H,0FAH,0F1H
.BYTE 0F0H,0F7H,0F8H,0FFH,0F4H,0F7H,0F8H,0FBH
.BYTE 00H,00H,00H,00H,00H,00H,00H,00H
.BYTE 00H,00H,00H,00H,00H,00H,00H,00H
.BYTE 00H,00H,00H,00H,00H,00H,00H,00H ;************************************************************************** ;**************************************************************************
;* INTERRUPT VECTORS ;**************************************************************************
.ORG 0FF0h IT_ADC NOP
IT_TIMER JP T_IT_TIMER IT_PORTBC JP T_ITPBC IT_PORTA JP T_ITPA
NMI NOP
RES JP DEBUT ;**************************************************************************
RETI
NOP NOP NOP NOP
RETI
11/28
Direct LCD Drive
ANNEX 1: Software of the ST6215x based application (Continued)
;************************************************************************** ;* INITIALIZATION SUBROUTINE ;**************************************************************************
.ORG 880h DEBUT RETI ; END OF RESET INTERRUPT
LDI DDRA,0C7H ; A0 to A2 PUSH PULL OUTPUT = 0
LDI ORA,0C7H ; A3 to A5 pull up input ; A6 & A7 output = 0
LDI DRA,00H ; A3 to A5 for keyboard ; A6 -> BP1, A7 -> BP2
LDI COPYA,00H
LDI DDRB,0FFH ; B0 A B7 push pull output = 0
LDI ORB,0FFH ; port B controls LC Display
LDI DRB,00H ;
LDI COPYB,00H ;
LDI DDRC,00H ;
LDI ORC,00H ; C4 C5 C6 C7 unused inputs
LDI DRC,00H ;
LDI COPYC,00H ;
LDI DWR,3CH ; origin of the table
LDI FLAGS,00h ; reset flags ;**************************************************************************
;* END OF INITIALIZATION SUBROUTINE ;**************************************************************************
;************************************************************************** ;* MAIN LCD DRIVE SUBROUTINE ;* ;* task : generate alternative signals to control LCD backplanes BP1/BP2 ;* drive the segments of the LCD ;* calculate duration of each duration phase ;**************************************************************************
SOMMEIL RES 0,FLAGS
LDI ORA,0CFh ; A3 becomes interrupt input
LDI IOR,10h ; valid interrupt
STOP ; wait at ON/OFF button activation
LDI ORA,0C7h ;
CLR IOR ; inihibit INTERRUPTS
CALL CLAVIER ; keyboard test
JRR 0,FLAGS,SOMMEIL ; IF no push on ON/OFF button , THEN stand by I1BOUCLE RES 0,FLAGS ; ELSE INITIALIZATION of MAIN LOOP
LDI TOUCHU,00h ; ON/OFF FLAG is reset, UNITEE A 0
LDI TOUCHD,00h ; reset M.S. DIGIT
LDI IOR,10h ; valid interrupts ;************************************************************************** BOUCLE1 LDI TCR,18 ; initialization of timer
LDI TSCR,7Fh ; program it at 1,5 ms
LD A,TOUCHU ; determine data/rom window address
SLA A ;
SLA A ; multiply TOUCHU by 4
LD TABU,A ; initialize data/rom address
LD A,TOUCHD ; of TABLES 1 & 2
SLA A ;
SLA A ;
LD TABD,A ;
CALL DATALCD ; determine segments driver byte for PHASE 1
LDI ORA,47h ; BP1 = Vdd ; BP2 = Vdd/2 therefore
LDI DDRA,47h ; A6 becomes push pull output at V
LDI DRA,0C0h ; A7 becomes high impedance input
LD DRB,A ; load segments driver byte on port
CALL CLAVIER ; test of keyboard
WAIT ;***************************************************************************
DD
12/28
ANNEX 1: Software of the ST6215x based application (Continued)
Direct LCD Drive
BOUCLE2 LDI TCR,18 ; timer initialization
;************************************************************************** BOUCLE3 LDI TCR,18 ; timer initialization
;************************************************************************** BOUCLE4 LDI TCR,18 ; timer initialization
;************************************************************************** FINBOUCLE JRR 0,FLAGS,BOUCLE1 ;IF ON/OFF button remains pushed,
PREPSOMM CALL CLAVIER ; test of keyboard
;************************************************************************** ;* END OF MAIN PROGRAM ;**************************************************************************
LDI TSCR,7Fh ; program it at 1.5 ms INC TABU ; determine data/rom window address
INC TABD ; of tables 1 & 2 for phase 2 CALL DATALCD ; determine segments driver byte for PHASE 2 LDI ORA,07h ; BP1 = Vdd/2 ; BP2 = Vss therefore
LDI DRA,40h LDI DDRA,87h ; A6 becomes high impedance input LDI ORA,87h ; & A7 becomes push pull output at Vss LD DRB,A ; load segments driver byte on port
WAIT
LDI TSCR,7Fh ; program it at 1.5 ms INC TABU ; determine data/rom window address
INC TABD ; of tables 1 & 2 for phase 2 CALL DATALCD ; determine segments driver byte for PHASE 3 LDI DRA,0C0h ; BP1 = Vdd/2 ; BP2 = Vdd therefore
LD DRB,A ; load segments driver byte on port WAIT
LDI TSCR,7Fh ; program it at 1.5 ms INC TABU ; determine data/rom window address
INC TABD ; of tables 1 & 2 for phase 2 CALL DATALCD ; determine segments driver byte for PHASE 4 LDI ORA,07h ; BP1 = Vss ; BP2 =A Vdd/2 therefore
LDI DRA,80h LDI DDRA,47h ; A6 becomes output at Vss LDI ORA,47h ; A7 becomes high impedance input LD DRB,A ; load segments driver byte on port
WAIT
LDI DRA,00h LDI DDRA,0C7h LDI ORA,0C7h ; BP1 & BP2 on output to Vss LDI DRB,00h
LD A,TOUCH CPI A,0Ah ; wait falling edge of ON/OFF button JRZ PREPSOMM ; before stop display mode JP SOMMEIL
; A6 remains high impedance input ; A7 becomes push pull output at Vdd
; THEN circuit is in stand by & display is ; ELSE continue digits display
13/28
Direct LCD Drive
ANNEX 1: Software of the ST6215x based application (Continued)
;************************************************************************** ;* TABLE SUBROUTINE ;* ;* task : define LCD segments driver byte to load on port B ;* TABU defines half driver byte for L.S.DIGIT ;* TABD defines half driver byte for M.S.DIGIT ;**************************************************************************
DATALCD LDI DWR,3Ch ; move data/rom window to L.S.DIGIT TABLE 2
;************************************************************************** ;* END OF TABLE SUBROUTINE ;**************************************************************************
;************************************************************************** ;* KEYBOARD SUBROUTINE ;* ;* task : controls display operation ;* searchs TOUCHU (L.S.DIGIT) & TOUCHD (M.S.DIGIT) displayed data ;* ;**************************************************************************
CLAVIER LDI LOOP,02h CLAVIER1 LD A,DRA
CLAVIER2 LD Y,A
TSTCOL JRR 3,Y,COL1 ; if A3 = 0 then column #1
COL3 LDI TOUCH,3 ; else column #3 is selected so TOUCH <=3
COL2 LDI TOUCH,2 ;column #2 so TOUCH <=2
COL1 LDI TOUCH,1 ;column #1 so TOUCH <=1
LDI A,40H ADD A,TABU LD X,A LD A,(X) LD Y,A ; half segment driver byte is loaded
LDI DWR,3Dh ; move data/rom window to M.S.DIGIT TABLE 1 LDI A,40h ADD A,TABD LD X,A LD A,(X) AND A,Y ; LCD driver byte is loaded in accumulator
RET
ANDI A,38h CPI A,38h ; test 2 times if some buttons are pushed JRNZ CLAVIER2 ; IF yes THEN check them ( A3 -> A5 ) DEC LOOP JRNZ CLAVIER1 LDI TOUCH,0FFh JP CLAVIER4 ; ELSE test if keyboard is changed
LD A,DRA ANDI A,38h CP A,Y JRZ TSTCOL ; IF check is OK , THEN determine column LDI TOUCH,0FFh JP CLAVIER4 ; ELSE test if one button was pushed
JRR 4,Y,COL2 ; if A4 = 0 then column #2
JP TSTLIGN
JP TSTLIGN
14/28
ANNEX 1: Software of the ST6215x based application (Continued)
Direct LCD Drive
TSTLIGN RES 0,ORA ;
LIGN1 JP CLAVIER3 ; else row #1 is selected & TOUCH unchanged LIGN2 LD A,TOUCH
LIGN3 LD A,TOUCH
LIGN4 JRS 0,TOUCH,ONOFF1
ONOFF1 LDI TOUCH,0Ah ; TOUCH 0Ah means action on ON/OFF button CLAVIER3 RES 3,ORA ;
CLAVIER4 LD A,TOUCH
CLAVIER5 LD TOUCHP,A ; ELSE TOUCHP TOUCH
CLAVIER7 CPI A,0Ah ; ELSE test ON/OFF button
ONOFF2 SET 0,FLAGS FINCLAV RET ;*************************************************************************
;* END OF KEYBOARD SUBROUTINE ;*************************************************************************
RES 1,ORA ; RES 2,ORA ; A0, A1 & A2 become open drain output RES 0,DDRA ; RES 1,DDRA ; RES 2,DDRA ; then pull up input
SET 3,DDRA; SET 4,DDRA; SET 5,DDRA ; A3, A4 & A5 become open drain output SET 3,ORA ; SET 4,ORA ; SET 5,ORA ; then push pull output at Vss
LD A,DRA ANDI A,07h JRR 0,A,LIGN2 ; if A0 = 0 then row #2 JRR 1,A,LIGN3 ; if A1 = 0 then row #3 JRR 2,A,LIGN4 ; if A2 = 0 then row #4
ADDI A,3 LD TOUCH,A ; row #2 so TOUCH TOUCH + 3 JP CLAVIER3
ADDI A,6 LD TOUCH,A ; row #3 so TOUCH TOUCH + 6 JP CLAVIER3
LDI TOUCH,00h JP CLAVIER3
RES 4,ORA ; RES 5,ORA ; A3, A4 & A5 become open drain ouput RES 3,DDRA ; RES 4,DDRA ; RES 5,DDRA ; then pull up inputs
SET 0,DDRA ; SET 1,DDRA ; SET 2,DDRA ; A0, A1 & A2 become open drain output SET 0,ORA; SET 1,ORA; SET 2,ORA ; then push pull output at Vss
CP A,TOUCHP JRNZ CLAVIER5 JP FINCLAV ; IF unchanged state keyboard THEN end
CPI A,0FFh JRNZ CLAVIER7 ; IF any keyboard buttons are pushed JP FINCLAV ; THEN end of subroutine
JRZ ONOFF2 ; IF yes THEN set FLAGS LD A,TOUCHU ; ELSE shift keyboard value LD TOUCHD,A; LD A,TOUCH; LD TOUCHU,A ; to be displayed JP FINCLAV
15/28
Direct LCD Drive
ANNEX 1: Software of the ST6215x based application (Continued)
;************************************************************************** ;* PORT A INTERRUPT SUBROUTINE ;**************************************************************************
T_ITPA NOP
;************************************************************************** ;* END OF PORT A INTERRUPT SUBROUTINE ;**************************************************************************
;************************************************************************** ;* OTHER INTERRUPTS SUBROUTINE ;**************************************************************************
T_IT_TIMER LDI TSCR,00h
T_ITPBC NOP
;**************************************************************************
RETI
RETI
RETI
16/28
TIMER_1 INTERRUPT
RELOAD TIMER_1
END OF INTERRUPT
PROGRAM BACKPLANES
PB0= HI-Z PB1= 0
PROGRAM SEGMENTS
UPDATE SEGMENTS
DRIVER BYTE
PROGRAM BACKPLANES
PB0= 0 PB1= HI-Z
UPDATE SEGMENTS
DRIVER BYTE
PROGRAM BACKPLANES
PB0= HI-Z PB1= 1
UPDATE SEGMENTS
DRIVER BYTE
CONVERT IN
DECIMAL MODE
PROGRAM BACKPLANES
PB0= 1 PB1= HI-Z
UPDATE SEGMENTS
DRIVER BYTE
IS LOOP 1 ?
IS LOOP 2 ?
IS LOOP 3 ?
PHASE 1
PHASE 2
PHASE 3 PHASE 4
NO
(*)
(*)
(*)(*)
(*)
(*) : SUBROUTINE TASK
YES
NO
YES
YES
NO
VR001862

ANNEX 2: Flowchart of the ST6265x based application

Direct LCD Drive
17/28
Direct LCD Drive
ANNEX 2: Software of the ST6265x based application
;************************************************************************* ;* SGS THOMSON MICROELECTRONICS ;* ;* CENTRAL APPLICATIONS LABORATORY ;* ;* ROUSSET FRANCE ;* ;************************************************************************** ;**************************************************************************
;* ;* 19 FEB 1993 ;* ;* ;* ;* LCD005 ;* ;**************************************************************************
;************************************************************************** ;* LCD DRIVER SOFTWARE PROGRAM ;* ST62E65 ;* DUPLEXED CONTROL OF 2 DIGITS WITH PORT A; ;* PA0 to PA3 FOR DIGIT1;PA4 to PA7 FOR DIGIT2; ;* BACPLANES ON PB0 & PB1
;* ;* with 4 phase sequences generator ;* with Hexadecimal/Decimal DATA conversion ;* ;**************************************************************************
;************************************************************************** ;* ST6265/6 Registers Declaration ;**************************************************************************
x .def 80h ; Index register. y .def 81h ; Index register. v .def 82h ; Short direct register. w .def 83h ; Short direct register.
a .def 0ffh ; Accumulator. pa .def 0c0h ; Port a data register.
pb .def 0c1h ; Port b data register. pc .def 0c2h ; Port c data register.
padir .def 0c4h ; Port a direction register. pbdir .def 0c5h ; Port b direction register. pcdir .def 0c6h ; Port c direction register.
paopt .def 0cch ; Port a option register. pbopt .def 0cdh ; Port b option register. pcopt .def 0ceh ; Port c option register.
ior .def 0c8h ; Interrupt Option Register. drwr .def 0c9h ; Data rom window register.
adc .def 0d0h ; A/D result register. adcc .def 0d1h ; A/D control register.
psc1 .def 0d2h ; Timer 1 prescaler register. tcr1 .def 0d3h ; Timer 1 counter register. tscr1 .def 0d4h ; Timer 1 status control register.
18/28
ANNEX 2: Software of the ST6265x based application (Continued)
mc .def 0d5h ; Timer 2 mode control register. sc0 .def 0d6h ; Timer 2 status/control register. sc1 .def 0d7h ; Timer 2 status/control register. rc .def 0d9h ; Timer 2 reload/capture register. cp .def 0dah ; Timer 2 compare register. lr .def 0dbh ; Timer 2 load register.
wdt .def 0d8h ; Watchdog register. oscr .def 0dch ; Oscillator control register. lvi .def 0ddh ; Multiplex register / lvi flag register. spirad .def 0e0h ; SPI register RAD.
spidiv .def 0e1h ; SPI register DIV. spimod .def 0e2h ; SPI register MOD. mbr .def 0e8h ; memory bank register. eecr .def 0eah ; eeprom control register. ;************************************************************************
;* RAM DATA DEFINITION ;************************************************************************
duty0 .def 087h,0ffh,0ffh ; user request reference counter1 .def 089h,0ffh,0ffh ; duty0 variation rate control byte
DIG1 .def 0a6h,0ffh,0ffh ; data/rom @ of DIGIT1 segment driver DIG2 .def 0a7h,0ffh,0ffh ; data/rom @ of DIGIT2 segment driver LCDCTL .def 0a8h,0ffh,0ffh ; LCD phase sequence control byte pbbuf .def 0aah,0ffh,0ffh ; buffer byte of data port b BCD .def 0a9h,0ffh,0ffh ; BinCodDec converted DATA
AUX1 .def 0a3h,0ffh,0ffh ; accumulator save byte AUX2 .def 0a4h,0ffh,0ffh ; data/rom window register save byte AUX3 .def 0a5h,0ffh,0ffh ; x register save byte
;************************************************************************ ;* EQUATES DEFINITION ;************************************************************************
FASTIM .equ 036h ; duration of each LCD drive phase (14 ms at 8 MHz) ;************************************************************************ ;************************************************************************
;* MACROFUNCTIONS DEFINITION ;************************************************************************
.macro jumpnc jpadress,?lbl
jrc lbl
jp jpadress lbl .endm
;************************************************************************ .macro jumpz jpadress,?lbl
jrnz lbl
jp jpadress lbl
.endm ;************************************************************************
Direct LCD Drive
19/28
Direct LCD Drive
ANNEX 2: Software of the ST6265x based application (Continued)
;************************************************************************ ;* INTERRUPT VECTORS ;************************************************************************
.org 0ff0h it_tim1 jp LCD_LP ; timer1 interrupt synchronizes LCD drive
it_tim2 nop ; it. timer2
it_pc_spi nop ; it. port c & SPI
it_pa_pb nop ; it. port a & port b
nmi nop
res jp START
;*********************************************************************** ;* MAIN PROGRAM EXAMPLE ;*********************************************************************** .org 0880h
START reti ; end of reset interrupt
MAIN call DUTY0
;*********************************************************************** ;* END OF MAIN PROGRAM ;***********************************************************************
reti
reti
reti nop nop nop nop
reti
call INIT
jp MAIN
;*********************************************************************** ;* MAIN INITIALIZATION SUBROUTINE ;***********************************************************************
INIT ldi wdt,00000111b ; watchdog initialization
; b0 & b1 is common :Hi/Impedance Input
; b2 &b3 is input for +/- push button
; pb buffer byte load
20/28
ldi eecr,040h ; EEPROM in stand by for power saving ldi oscr,008h ; CKOUT output disabled for power saving
ldi pbdir,00110000b
ldi pbopt,00110000b
ldi pbbuf,00000011b
ldi pb,00000011b ; b6,b7 in input with pull up ldi padir,0ffh ; a0 to a7 in push pull output
ldi paopt,0ffh ; pa = driver of LCD segments ldi pa,00h ; output is zero
ldi pcdir,00h ; ldi pcopt,00h ; c0 -> c7 inputs with pull up ldi pc,00h ;
ldi drwr,3ch ; data/rom window origin clr LCDCTL ; clear LCD phase sequence control ldi ior , 010h ; interrupt validation
ldi tcr1 ,009h ; load timer1 for LCD phase generation ldi tscr1,07fh ; timer initialization
clr duty0 ldi wdt, 00000111b ; hello watchdog
ANNEX 2: Software of the ST6265x based application (Continued)
Direct LCD Drive
;*********************************************************************** ;* END OF MAIN INITIALIZATION ;***********************************************************************
;************************************************************************ ;* MAIN TASK EXAMPLE : ACQUISITION OF USER SPEED REFERENCE DUTY0 *
;* * ;* duty0 is a user reference that can vary from 0 to 255d * ;************************************************************************
DUTY0 jrr 2,pb,slower ; if PB2=0,then slower ; priority on slower
slower ld a,duty0
faster ld a,duty0
retour ret ;***********************************************************************
;* end subroutine get_dut0 ;***********************************************************************
;*********************************************************************** ;* DUPLEXED LCD DRIVER INTERRUPT SUBROUTINE ;* ;* task : generate alternative signals of LCD backplanes control ;* drive the segments of LCD through port a ;* calculate duration of each LCD phase ;* ;***********************************************************************
LCD_LP ldi wdt,0ffh ; hello watchdog ; ld AUX1, a ; |
; ld a, x ; | save context of main task (if needed) ; ld AUX3, a ; | ; ldi tscr1,00h ; timer stop (if needed)
;************************************************************************ ;* LCD phase generation can be here synchronized by other clock system. ;* for instance : mains voltage synchronization or external clock ;************************************************************************
; determine phase1 operation
ret
jrr 3,pb,faster ; if PB3=0,then faster ; else continue ret ; if PB2 & PB3 are high; then continue
cpi a,000h jumpz retour ld a,counter1 addi a,01h ld counter1,a jumpnc retour dec duty0 ; increment duty cycle ret
cpi a,0ffh jrz retour ld a,counter1 addi a,01h ld counter1, a jrnc retour inc duty0 ; decrement duty cycle
ldi tcr1 , FASTIM ; LCD phase duration calculation ldi tscr1, 07fh ; timer initialization
jrr 0,LCDCTL,LOOP1
21/28
Direct LCD Drive
ANNEX 2: Software of the ST6265x based application (Continued)
; determine phase2 operation
; determine phase3 operation
;************************* PHASE 4 ********************************* LOOP4 inc DIG1 ; increment DIG1 & DIG2 for phase 4
;
;************************* PHASE 3 ******************************** LOOP3 inc DIG1 ; increment DIG1 & DIG2 for phase 3
; ld a,AUX3 ;| ; ld x,a ;| ; ld a,AUX2 ;|return to main tasks with context ; ld drwr,a ;| ( AUX2 <== drwr in main program ) ; ld a,AUX1 ;|
;************************* PHASE 2 ********************************* LOOP2 inc DIG1 ; increment DIG1 & DIG2 for phase 2
; ld a,AUX3 ;| ; ld x,a ;| ; ld a,AUX2 ;|return to main tasks with context ; ld drwr,a ;| ( AUX2 <== drwr in main program ) ; ld a,AUX1 ;|
jrr 1,LCDCTL,LOOP2
jrr 2,LCDCTL,LOOP3
inc DIG2 ; call DATALCD ; calculate phase4 segments driver byte
ldi pbbuf,00000011b ; pb buffer load ldi pb ,00000011b ; pb1 in High Impedance (HI) & pb0 to 0 ldi pbdir,00110001b ; ldi pbbuf,00000010b ; pb buffer load ldi pb ,00000010b ; ld pa,a ; load segment driver byte on port a
ld a,AUX3 ;| ld x,a ;| ld a,AUX2 ;|return to main tasks with context ; ld drwr,a ;| ( AUX2 <== drwr in main program )
ld a,AUX1 ;| clr LCDCTL ; end of loop4 & full LCD sequence
reti
inc DIG2 call DATALCD ; calculate phase3 segments driver byte
ldi pbopt,00110000b ; pb0 in HI & pb1 to 0 ldi pbdir,00110010b ; ldi pbbuf,00000001b ; pb buffer load ldi pb, 00000001b ; ld pa ,a ; load segment driver byte on port a
set 2,LCDCTL ; end of loop3 reti
inc DIG2 call DATALCD ; calculate phase2 segments driver byte
ldi pbopt,00110000b ; pb1 in HI & pb0 to 1 ldi pbdir,00110001b ; ldi pbopt,00110001b ; ld pa,a ; load segment driver byte on port a
22/28
ANNEX 2: Software of the ST6265x based application (Continued)
set 1,LCDCTL ; end of loop2 reti
;************************* PHASE 1 ********************************* LOOP1 call DECCONV ; do hexa-decimal data conversion
; ld a,AUX3 ; ; ld x,a ; ; ld a,AUX2 ; return to main tasks with context ; ld drwr,a ;(AUX2 <== drwr in main program) ; ld a,AUX1 ;
;************************************************************************ ;* END OF LCD DRIVER SUBROUTINE ;************************************************************************
;************************************************************************ ;* DEC DATA/LCD SEGMEMTS CONVERSION SUBROUTINE ;* ;* task : calculate the segments driver byte of the LCD ;* depends on the displayed data AND on the # of phase ;* based on DIG1 & DIG2 calculation ;* LCD segments driver full byte is in accumulator ;************************************************************************
DATALCD ldi drwr,3ch ; move data/rom window on DIGIT2 table
;************************************************************************ ;* END OF DATA/LCD CONVERSION SUBROUTINE ;************************************************************************
call DATALCD ; calculate phase1 segment driver byte
ldi pbbuf,00000011b ; pb buffer load ldi pb,00000011b ; b1 to 1 & b0 in HI ldi pbdir,00110010b ; b2 — > b7 unchanged ldi pbopt,00110010b ; ld pa,a ;load segment driver byte on port a
set 0,LCDCTL ; end of loop1 reti
ld a,DIG2 ld x,a ld a,(x) ld y,a ; load DIGIT2 driver half byte (MSB)
ldi drwr,3dh ; move data/rom window on DIGIT1 table ld a,DIG1 ld x,a ld a,(x) and a,y ; load DIGIT1 driver half byte (LSB)
ret
; driver data is stored in accumulator
Direct LCD Drive
23/28
Direct LCD Drive
ANNEX 2: Software of the ST6265x based application (Continued)
;************************************************************************ ;* HEXADECIMAL — > DECIMAL DATA CONVERSION SUBROUTINE ;* ;* task : convert an hexadecimal data in a Binary Coded Decimal data ;* determine data/rom window address of segments driver byte ;* ;* ;* hexadecimal data is a stable data varying from 0 to 256 ;* result is a percent decimal data varying from 0 to 99 ;* BCD Binary Coded Decimal data ;* ;* for instance, data is duty0 ;* ;* DIG1 = data/rom WDW @ of DIGIT1 segments driver = 01wxyzAB ;* DIGIT1 = wxyz ( from 0 to 9 ) and ;* AB are defined by phase operation : AB = 00 for phase1 ... ;* AB = 11 for phase4 ;* DIG2 = data/rom WDXW @ of DIGIT2 segments driver ;* similar writing than DIG1 ;* ;*************************************************************************
DECCONV jrr 7,duty0,ET1 ; DATA <== duty0
ET1 ldi drwr,038h ; b7 of DATA is 0 : 00 < DATA < 49 ET2 ld a,duty0 ;
ldi drwr,039h ; b7 of DATA is 1 : 50 < DATA < 99 jp ET2
rlc a ; rlc a ; rlc a ; calculation of BinCodDec DATA rlc a ; address rlc a ;
rlc a ; rlc a ; rlc a ; set 6,a ; res 7,a ; ld x,a ; ld a,(x) ; ld BCD,a ; BCD <= Binary Coded Decimal DATA
andi a,00fh ; determine DIGIT1 value and the sla a ; data/rom address of DIGIT1 segments sla a ; driver addi a,040h ; ld DIG1,a ; DIG1 = data/rom @ of segment driver
ld a,BCD ; determine DIGIT2 value and the andi a,0f0h ; data/rom address of DIGIT2 segments rlc a ; driver rlc a ;
rlc a ; rlc a ; rlc a ; sla a ; sla a ;
24/28
ANNEX 2: Software of the ST6265x based application (Continued)
addi a,040h ; ld DIG2,a ; DIG2 = data/rom @ of LCD driver
;*********************************************************************** ;* END OF HEXA — > DECIMAL DATA CONVERSION SUBROUTINE ;***********************************************************************
;*********************************************************************** ;* TABLE OF HEXA — > DECIMAL DATA CONVERSION ( 00 TO 49 BinCodDec ) ;***********************************************************************
.org 0e00h .byte 00h,01h,02h,02h,03h,04h,05h,05h
.byte 06h,07h,08h,09h,09h,10h,11h,12h .byte 12h,13h,14h,15h,16h,16h,17h,18h .byte 19h,20h,20h,21h,22h,23h,23h,24h .byte 25h,26h,27h,27h,28h,29h,30h,30h .byte 31h,32h,33h,34h,34h,35h,36h,37h .byte 37h,38h,39h,40h,41h,41h,42h,43h .byte 44h,45h,45h,46h,47h,48h,48h,49h
;*********************************************************************** ;* END OF HEXA —> DECIMAL DATA CONVERSION TABLE ( 00 to 49 ) ;***********************************************************************
;*********************************************************************** ;* TABLE OF HEXA —> DECIMAL DATA CONVERSION ( 50 to 99 BinCodDec ) ;***********************************************************************
.org 0e40h .byte 50h,51h,52h,52h,53h,54h,55h,55h .byte 56h,57h,58h,59h,59h,60h,61h,62h
.byte 62h,63h,64h,65h,66h,66h,67h,68h .byte 69h,70h,70h,71h,72h,73h,73h,74h .byte 75h,76h,77h,77h,78h,79h,80h,80h .byte 81h,82h,83h,84h,84h,85h,86h,87h .byte 88h,88h,89h,90h,91h,91h,92h,93h .byte 94h,95h,95h,96h,97h,98h,98h,99h
;*********************************************************************** ;* END OF HEXA — > DECIMAL DATA CONVERSION TABLE ( 50 to 99 ) ;***********************************************************************
;*********************************************************************** ;* SEGMENT CONTROL WITHOUT ANY POINT DISPLAY
;*PA0,4 —-> SEG CB ;*PA1,5 —-> SEG DH ;*PA2,6 —-> SEG DH ;*PA3,7 —-> SEG GA ;* ;*PA0,PA1,PA2,PA3—-> DIGIT1 ;*PA4,PA5,PA6,PA7—-> DIGIT2 ;* ;*Backplane #1 (pb1) biases C,D,E,G ;*Backplane #2 (pb0) biases A,B,F,H ;* ;*These tables are dedicated to one LCD type with two digits and LCD ;*control is described above ; when LCD is changing these tables have ;* to be modified
ret
a
fb
g
e
c
d
Direct LCD Drive
25/28
Direct LCD Drive
ANNEX 2: Software of the ST6265x based application (Continued)
;************************************************************************ ;* DIGIT2 TABLE ;************************************************************************
.org 0f00h .byte 08fh,02fh,07fh,0dfh,0efh,0efh,01fh,01fh .byte 01fh,06fh,0efh,09fh,04fh,06fh,0bfh,09fh .byte 06fh,0afh,09fh,05fh,04fh,03fh,0bfh,0cfh .byte 00fh,03fh,0ffh,0cfh,0efh,06fh,01fh,09fh .byte 00fh,02fh,0ffh,0dfh,04fh,02fh,0bfh,0dfh .byte 0ffh,0ffh,00fh,00fh,000h,000h,000h,000h .byte 000h,000h,000h,000h,000h,000h,000h,000h .byte 000h,000h,000h,000h,000h,000h,000h,000h
;************************************************************************ ;* DIGIT1 TABLE ;************************************************************************
.org 0f40h .byte 0f8h,0f2h,0f7h,0fdh,0feh,0feh,0f1h,0f1h .byte 0f1h,0f6h,0feh,0f9h,0f4h,0f6h,0fbh,0f9h .byte 0f6h,0fah,0f9h,0f5h,0f4h,0f3h,0fbh,0fch .byte 0f0h,0f3h,0ffh,0fch,0feh,0f6h,0f1h,0f9h .byte 0f0h,0f2h,0ffh,0fdh,0f4h,0f2h,0fbh,0fdh .byte 0ffh,0ffh,0f0h,0f0h,000h,000h,000h,000h
26/28
Table 6. Revision history
Date Revision Description of changes
April 1993
03-Oct-2008 2
Direct LCD Drive
1
Initial release
Logo and disclaimer modified Title modified
27/28
Direct LCD Drive
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its
subsidiaries (“ST”) reserve the right to make changes, corrections, modifications or improvements, to this document,
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein,
and ST assumes no liability whatsoever relating to the choice, selection or use of the ST products and services
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this docu­ment. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a
warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST
PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF
ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY,
AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING APPLICATIONS, NOR IN PRODUCTS
OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE
NOT SPECIFIED AS “AUTOMOTIVE GRADE” MAY ONLY BE USED IN AUTOMOTIVE
Resale of ST products with provisions different from the statements and/or technical features set forth in this document
shall immediately void any warranty granted by ST for the ST product or service described herein and shall not create or
and the products and services described herein at any time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
described herein.
contained therein.
INTELLECTUAL PROPERTY RIGHT.
APPLICATIONS AT USER’S OWN RISK.
extend in any manner whatsoever, any liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective
owners.
© 2008 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany -
Hong Kong - India - Israel - Italy - Japan - Malaysia - Malta - Morocco - Singapore - Spain - Sweden -
Switzerland - United Kingdom - United States of America
www.st.com
28/28
Loading...
