Stack overflow detection using the ST9 timer/watchdog
1 Introduction
In real time applications, implementation of software protection is not always easy, but it is
needed to reach a high level of security against software malfunction. This is particularly
true for on-board applications in noisy environments, such as automotive, power meter or
industrial applications.
To help avoid un-controlled operations and damage to real time systems due to any possible
disturbance of the ST9 microcontroller core and I/O ports, a special peripheral acting as a
watchdog is available on all ST9 family members: the Timer/Watchdog.
The periodic restarting of the Timer/Watchdog by the application software, associated with
the automatic detection of any stack overflow, provide enhanced protection to real time
application software.
This application note shows how to detect stack overflow by using the Timer/Watchdog in
watchdog mode.
AN421
Application note
November 2011 Doc ID 2476 Rev 2 1/11
www.st.com
Contents AN421
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Stack overflow detection principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Summary of timer/watchdog features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Stack overflow detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Software description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Stack initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Timer/watchdog programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Timer/Watchdog restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2/11 Doc ID 2476 Rev 2
AN421 List of figures
List of figures
Figure 1. Example of stack overflow detection in register file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 2. System stack initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 3. Timer/watchdog initialization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 4. Restarting the timer/watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Doc ID 2476 Rev 2 3/11
Stack overflow detection principle AN421
2 Stack overflow detection principle
2.1 Summary of timer/watchdog features
The ST9 core includes a 16-bit down counter with an 8-bit prescaler capable of operating in
watchdog mode. This timer, driven by a clock at a frequency of INTCLK divided by 4, is able
to provide time periods within the range of 333 ns to 5.59 s (using a 12 MHz internal clock).
In watchdog mode, the Timer/Watchdog generates a fixed time base depending on the
Timer/Watchdog registers and prescaler, and to INTCLK. This time base can be modified on
the fly by changing the prescaler value. The new value will be taken into account only after
an End Of Count event. In watchdog mode, the End Of Count occurrence generates a
system reset.
In order to prevent the reset, the byte sequence AAh, 55h should be written into the Timer
Watchdog register Low. Once the write of 55h has been performed, the timer reloads the
prescaler register and the counting restarts from this value (the prescaler register value may
be modified between two End Of Count events).
Note: 1 For a better understanding of this application note; please refer to the ST9 Technical Manual
chapter on the 16-bit programmable Timer/Watchdog.
2 INTCLK: Internal Clock. This clock issued from the oscillator circuitry, divided or not by 2, is
the ST9 Internal Clock driving the peripherals. The maximum frequency allowed for INTCLK
is 12MHz.
2.2 Stack overflow detection
In many software applications, for example when running on ST9 ROMLESS versions or
without external memory space, the size of the stack is limited.
On ST9 devices, the system stack may be located in the Register File or in data memory
space. The ST9 stack pointer moves from the top to the bottom of the stack area.
A solution to detect stack overflow is to reserve the first two bytes after the bottom of the
stack and to store in these locations the Timer Watchdog restart value, AAh, 55h.
In the case of stack overflow, the data will be overwritten and thus destroyed and a system
reset will be generated on the next Timer Watchdog End Of Count.
4/11 Doc ID 2476 Rev 2
AN421 Stack overflow detection principle
system registers group E
group D
Stack area
AAh
55h
R0
r14
r15
System
Application
register area
group 0
Register File
System stack
pointer on
current stack
location
END_SSTACK:
Last byte of
system stack
-36
Figure 1. Example of stack overflow detection in register file
Doc ID 2476 Rev 2 5/11
Software description AN421
;***************************************************************
; STACK Declaration and end of stack initialisation
; in RAM space or Register File
;***************************************************************
; Initialisation in Register FIle
SSTACK := (BKE * 16) - 1 ; Sys.stack add.group
LG-SSTACK := 32 ; Sys.stack length
END_SSTACK := (BKE * 16) - LG_SSTACK ; Last sys.stack byte
ld SSPLR,#SSTACK + 1 ; Load sys.stack pointer
ldw RR#END_STACK - 2,#0AA55h ; Init end of stack.
; Initialisation in RAM space
SSTACK := 2000h ; top of sys.stack
END-STACK := 1000h ; Init end of stack
essp = rr0
sdm
ldw SSPR,#SSTACK ; Select data space
ld essp,#END_SSTACK ; Init End of sys.stack
ldw -2(essp),#0AA55h
3 Software description
3.1 Stack initialization
The following example initializes the system stack in groups D and C of the Register File.
In the stack management of the ST9, the stack pointer is automatically pre-decremented
before the data is stored on the stack. So the expression:
SSTACK = (BKE * 16) - 1
defines the first location of the system stack in group D and C within the Register File, while
the instruction:
ld SSPLR,#SSTACK + 1
initializes the system stack pointer in the system register. The instruction:
ldw RR#END_SSTACK,#0AA55h
initializes the first two bytes following the bottom of the system stack with the value used to
restart the Timer/Watchdog. Initialization
Figure 2. System stack initialization
6/11 Doc ID 2476 Rev 2
AN421 Software description
;***************************************************************
**
; WATCHDOG INITIALISATION
;***************************************************************
**
proc INIT_WGT[PPR] {
spp #0
ld WDTPR,#0 ; TWD prescaler register
ld WDTLR,#-30h ; ; TWD Timer counter low
ld WDTHR,#075h ; ; TWD Timer counter high
}
call INIT_WGT ; call TWD initialisation
spp #0 ; ; select page 0 register
ld WCR,#00111111b ; ; Enable the Watchdog
ei ; ; Enable Interrupt
3.2 Timer/watchdog programming
As an example, the Timer Watchdog is initialized in order to provide a time base of 10 ms
(with a ST9 driven by a clock frequency of 24 MHz internally divided by two). To enable the
Watchdog mode, the requirement is to initialize Timer prescaler and counter, to initialize the
Timer/Watchdog Control Register with its reset value, and then to enable the watchdog
mode by clearing the WDGEN bit in the Wait Control Register in page 0. Resetting this bit
causes the counter to start in Watchdog mode regardless of the start/stop,
Single/Continuous and input mode bits.
Figure 3. Timer/watchdog initialization
Note: 1 A bit (DIV2 located in the MODE Register MODER, R235 in the system group) controls the
divide by two circuit which operates on the OSCIN clock driving the ST9. The maximum
Internal Clock (INTCLK) allowable for the ST9 is 12 MHz. This internal clock drives all the
ST9 peripherals, while this same clock, optionally slowed down by the ST9 Core clock
programmable prescaler and by wait cycle insertion, drives the ST9 Core. After a reset
cycle, the clock frequency applied to the ST9 is divided by two and no Core clock prescaling
is done.
3.3 Timer/Watchdog restart
This example shows how to restart the Timer Watchdog when the stack is located in
Register File or in RAM space. In the register file, the two instructions:
ld WDTLR,#END_SSTACK-2
ld WDTLR,#END_SSTACK-1
load the restart value of Timer Watchdog.
Doc ID 2476 Rev 2 7/11
Software description AN421
; In Register File
spp #0 ; TWD register page
ld WDTLR,R#END_SSTACK-2 ; Load AAh
ld WDTLR,R#END_SSTACK-1 ; Load 55h
; In RAM space
spp #0 ; TWD register page
sdm ; Select RAM space
ld essp,#END_SSTACK ; End stack pointer
ld WDTLR,-2(essp) ; Load AAh
ld WDTLR,-1(essp) ; Load 55h
When the system stack is located in RAM space, a register essp (end of system stack
pointer) must be used to load the sequence AAh, 55h in the Timer Watchdog counter
register low.
Figure 4. Restarting the timer/watchdog
8/11 Doc ID 2476 Rev 2
AN421 Summary
4 Summary
Protection of software against externally generated perturbations can be made by additional
test routines.
This protection can easily be increased by using the ST9 Timer/Watchdog bringing software
reliability and security. With the Timer/Watchdog the ST9 program can control that the
software executing properly. Additionally, when restarting the Timer Watchdog from values
(AAh, 55h) located at the bottom of the system stack two additional security functions are
added:
● Test of the integrity of the Register File or the RAM space
● Provision of a system reset in the case of stack overflow.
Doc ID 2476 Rev 2 9/11
Revision history AN421
5 Revision history
Table 1. Document revision history
Date Revision Changes
15-Dec-1992 1 Initial release.
02-Nov-2011 2 Updated format and company logo.
