AN3290
Application Note
Reference design for double output SMPS for power line modem applications using ALTAIR04-900 primary controller
Introduction
This application note introduces a new “all-primary sensing” switching regulator ALTAIR04900, used to build an innovative solution to supply a power line communication.
A demonstration board, implementing a wide-range double-output power supply, has been developed and the results of its bench evaluation are reported in this document.
The board uses the new ALTAIR04-900, a quasi-resonant (QR) current-mode controller IC specifically designed for QR ZVS (zero voltage switching at switch turn-on) flyback converters, which combines a high-performance low-voltage PWM controller chip and a typical 16 RDSon, 900 V, avalanche-rugged power MOSFET in the same package.
The device is capable of providing constant output voltage regulation using primary-sensing constant voltage loop (CV loop). This eliminates the need for the optocoupler and the secondary voltage reference while still maintaining quite accurate regulation.
Also, using the primary constant current loop (CC loop), it is possible to set the maximum deliverable output current without any secondary components or current sensor.
April 2011 |
Doc ID 18038 Rev 1 |
1/34 |
www.st.com
Contents |
AN3290 |
|
|
Contents
1 |
Test board design and evaluation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 5 |
|
2 |
Output voltage characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
|
3 |
Efficiency and no load measurements . . . . . . . . . . . . . . . . . . . . . . . . . |
12 |
|
4 |
Typical board waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
13 |
|
5 |
Protection features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
|
|
5.1 |
Overload and short-circuit protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
|
5.2 |
Auxiliary winding disconnection (brownout) . . . . . . . . . . . . . . . . . . . . . . . |
22 |
5.3Secondary winding short-circuit and transformer saturation protection . . 23
6 |
Conducted noise measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
7 |
Modifications for ultra wide-range operations . . . . . . . . . . . . . . . . . . . |
29 |
8 |
Conclusions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
31 |
9 |
Demonstration tools and documentation . . . . . . . . . . . . . . . . . . . . . . . |
32 |
10 |
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
33 |
2/34 |
Doc ID 18038 Rev 1 |
AN3290 |
List of Tables |
|
|
List of Tables
Table 1. ALTAIR04-900 power supply: electrical specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Table 2. ALTAIR04-900 power supply - bill of material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Table 3. ALTAIR04-900 power supply: transformer characteristics . . . . . . . . . . . . . . . . . . . . . . . . . 10 Table 4. ALTAIR04-900 power supply: bill of material for 440 VAC input voltage option. . . . . . . . . 30 Table 5. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Doc ID 18038 Rev 1 |
3/34 |
List of figures |
AN3290 |
|
|
List of figures
Figure 1. Electrical schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Figure 2. PCB: component side (not to scale) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Figure 3. Demonstration board image: power supply board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Figure 4. Demonstration board image: complete (power supply and PLM boards). . . . . . . . . . . . . . . 8 Figure 5. ALTAIR04-900 power supply: transformer characteristics . . . . . . . . . . . . . . . . . . . . . . . . . 10 Figure 6. Output voltage characteristics with 3V3 @ 40 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Figure 7. Output voltage characteristics with 3V3 @ 80 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Figure 8. Efficiency vs. output power with 3V3 @ 40 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Figure 9. Efficiency vs. output power with 3V3 @ 80 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Figure 10. Normal operations in TX mode at 85 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Figure 11. Normal operations in TX mode at 115 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Figure 12. Normal operations in TX mode at 230 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Figure 13. Normal operations in TX mode at 264 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Figure 14. Normal operation in TX mode at 85 VAC and IOUT2=40 mA . . . . . . . . . . . . . . . . . . . . . . 15 Figure 15. Normal operation in TX mode at 85 VAC and IOUT2=80 mA . . . . . . . . . . . . . . . . . . . . . . 16 Figure 16. Normal operation in TX mode at 115 VAC and IOUT2=40 mA . . . . . . . . . . . . . . . . . . . . . 16 Figure 17. Normal operation in TX mode at 115 VAC and IOUT2=80 mA . . . . . . . . . . . . . . . . . . . . . 17 Figure 18. Normal operation in TX mode at 230 VAC and IOUT2=40 mA . . . . . . . . . . . . . . . . . . . . . 17 Figure 19. Normal operation in TX mode at 230 VAC and IOUT2=80 mA . . . . . . . . . . . . . . . . . . . . . 18 Figure 20. Normal operation in TX mode at 264 VAC and IOUT2=40 mA . . . . . . . . . . . . . . . . . . . . . 18 Figure 21. Normal operation in TX mode at 264 VAC and IOUT2=80 mA . . . . . . . . . . . . . . . . . . . . . 19 Figure 22. Short-circuit mode: 13 V shorted at 115 VAC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Figure 23. Short-circuit mode: 13 V shorted at 230 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Figure 24. Brownout protection activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Figure 25. Hiccup mode OCP: protection tripping at VIN=115 VAC and full load . . . . . . . . . . . . . . . . 23 Figure 26. Hiccup mode OCP: protection tripping at VIN=230 VAC and full load . . . . . . . . . . . . . . . . 24 Figure 27. Hiccup mode OCP: operating condition at VIN=115 VAC . . . . . . . . . . . . . . . . . . . . . . . . . 24 Figure 28. Hiccup mode OCP: operating condition at VIN=230 VAC . . . . . . . . . . . . . . . . . . . . . . . . . 25 Figure 29. CE average measurement at 115 VAC and full load: line . . . . . . . . . . . . . . . . . . . . . . . . . 26 Figure 30. CE average measurement at 115 VAC and full load: neutral . . . . . . . . . . . . . . . . . . . . . . . 27 Figure 31. CE average measurement at 230 VAC and full load: line . . . . . . . . . . . . . . . . . . . . . . . . . 27 Figure 32. CE average measurement at 230 VAC and full load: neutral . . . . . . . . . . . . . . . . . . . . . . . 28 Figure 33. Electrical schematic for 440 VAC input voltage option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4/34 |
Doc ID 18038 Rev 1 |
AN3290 |
Test board design and evaluation |
|
|
As a reference design, a 7.48 W nameplate output power SMPS has been specifically designed and developed according to the specifications for a complete power line communication based on ST7580 (by STMicroelectronics).
The power supply provides a 13 V output voltage to supply the power line modem (PLM) and the analog circuitry, and a post-regulated 3.3 V to supply digital circuitry and an optional external microcontroller.
Table 1 summarizes the electrical specifications of the power supply, Table 2 provides the bill of material and Table 3 lists the transformer specifications. The electrical schematic is shown in Figure 2 and the PCB layout in Figure 3 and 4.
Table 1. |
ALTAIR04-900 power supply: electrical specification |
|
|
|
||
Parameter |
Note |
Min. |
Typ. |
Max. |
Unit |
|
|
|
|
|
|
|
|
AC main input voltage |
|
85 |
|
265 |
VAC |
|
Mains frequency (fL) |
|
50 |
|
60 |
Hz |
|
Output voltage 1 |
Analog supply voltage |
11.7 |
13 |
14.3 |
V |
|
|
|
|
|
|
|
|
Output current 1 |
Rx mode |
12 |
|
|
mA |
|
|
|
|
|
|
||
Tx mode |
35 |
|
550 |
mA |
||
|
|
|
||||
|
|
|
|
|
|
|
Output voltage 2 |
Digital supply voltage |
|
3.3 |
|
V |
|
|
|
|
|
|
|
|
Output current 2 |
No external microcontroller connection |
|
40 |
50 |
mA |
|
|
|
|
|
|
||
External microcontroller connection |
|
|
100 |
mA |
||
|
|
|
|
|||
|
|
|
|
|
|
|
Total rated output power |
|
|
|
7.48 |
W |
|
|
|
|
|
|
|
|
Maximum output power |
In TX mode |
4.2 |
|
|
W |
|
|
|
|
|
|
|
|
The input stage, consists of an NTC (NTC1) which limits the inrush current produced by the capacitor charging at plug-in and a varistor (RV1) that protects the power supply against temporary line overvoltage transients. The input EMI filter is a classic Pi-filter, 1-cell for common and differential mode noise. The clamping network (D2-D3) limits the peak of the leakage inductance voltage spike at turn-off, assuring reliable operation of the ALTAIR04900.
The sense resistor R2 and the transformer primary-to-secondary turn ratio fix the maximum output current limitation, whereas the voltage divider made up of R6, R7, and R8 is used to set the output voltage setpoint, in order to ensure the desired output voltage regulation. The network connected on the COMP pin is used to compensate the loop, ensuring the right gain and phase margin to the system, whereas the voltage across the capacitor C10 is used to fix the voltage level for the CC loop; the value of this capacitor is not critical and e few nF are enough to ensure correct operation. The secondary side is provided by two output voltages; a nameplate 13 V output voltage is directly used to supply the analog circuitry of the PLM, whereas the lower voltage is achieved by a 3V3 LDO and is intended to supply the digital parts.
Doc ID 18038 Rev 1 |
5/34 |
Test board design and evaluation |
AN3290 |
|
|
Figure 1. Electrical schematic |
|
|
|
|
|
|
|
|
|
|
75 |
' |
/ |
|
|
9$ |
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
17& |
|
|
3' |
|
|
|
|
6736 |
X+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
RKP: |
|
|
|
|
|
|
|
|
|
|
||
$& , 1 |
) |
|
|
') 6 |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
& |
' |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
$ |
|
&0 |
|
|
|
|
3 .($ |
|
& |
& |
& |
5 |
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
X) |
|
Q) |
||
|
|
|
|
|
|
X) |
|
|
|
X) |
N |
|||
|
|
59 |
|
& |
|
9 |
|
|
|
|
|
|
|
|
$& , 1 |
|
9 |
|
Q); |
|
|
|
' |
|
|
|
|
|
|
|
|
|
|
|
|
|
677+ /$ |
|
|
|
|
|
||
|
|
/ |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
P+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
/)$% |
|
|
|
|
|
|
|
|
|
' |
5 |
|
|
' |
|
|
|
9$ |
|
|
|
|
|
|
|
|
|
|
|
,1 |
287 |
|
|
|
|
|
& |
& |
%$7 |
|
|
|
6736 /$ |
*1' |
|
|
||
|
|
|
|
|
|
|
|
|
& |
|
& |
5 |
||
|
|
|
Q) |
X) |
|
|
|
|
|
|
|
|||
|
|
5 |
|
|
|
|
|
|
|
|
X) |
|
X) |
1 & |
|
|
|
|
|
8 |
|
|
|
|
|
|
|
|
|
|
|
. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
$/7$,5 |
|
|
|
|
|
|
||
|
|
|
|
|
9'' |
|
|
'5$,1 |
|
|
|
|
|
*1' |
|
|
|
9 |
|
|
&855 (17 |
|
|
|
& |
|
|
|
|
|
|
|
|
|
|
&21752/ |
|
|
|
|
|
|
|
|
|
|
|
)% =& ' |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
&203 |
,5() |
*1' |
6285& ( |
|
Q) <&$3 |
|
|
|
|
|
|
|
5 |
5 |
|
& |
|
|
|
|
|
|
|
|
|
|
|
. |
. |
& |
Q) |
& |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Q) |
5 |
Q) |
|
5 |
5 |
|
|
|
|
|
|
|
|
|
|
|
|
1 & |
|
|
|
|
|
|
|
|
|
|
|
|
N |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
!-V |
!-V
6/34 |
Doc ID 18038 Rev 1 |
AN3290 |
Test board design and evaluation |
|
|
Doc ID 18038 Rev 1 |
7/34 |
Test board design and evaluation |
AN3290 |
|
|
Table 2. |
ALTAIR04-900 power supply - bill of material |
|
|
Reference |
Part |
Description |
Note |
|
|
|
|
R1 |
|
1.8 kΩ |
|
|
|
|
|
R2 |
|
1.3 Ω |
1% tolerance |
|
|
|
|
R3, R5 |
|
N.C. |
|
|
|
|
|
R4 |
|
8.2 kΩ |
|
|
|
|
|
R6 |
|
8.2 kΩ |
1% tolerance |
|
|
|
|
R7 |
|
27 kΩ |
1% tolerance |
|
|
|
|
R8 |
|
5.1 kΩ |
1% tolerance |
|
|
|
|
R9 |
|
0Ω |
|
|
|
|
|
C1 |
B41044A4108M |
1000 μF - 16 V electrolytic |
EPCOS |
|
|
|
|
C2 |
B41858C4477M |
470 μF - 16 V electrolytic |
EPCOS |
|
|
|
|
C3 |
B43851F9226M |
22 μF - 400 V electrolytic |
EPCOS |
|
|
|
|
C4, C9 |
|
100 nF ceramic – 35 V |
|
|
|
|
|
C5 |
B41851A3477M |
470 μF - 10 V electrolytic |
EPCOS |
|
|
|
|
8/34 |
Doc ID 18038 Rev 1 |
AN3290 |
|
|
Test board design and evaluation |
|
|
|
|
|
|
|
Table 2. |
ALTAIR04-900 power supply - bill of material (continued) |
||
|
|
|
|
|
|
Reference |
Part |
Description |
Note |
|
|
|
|
|
|
C6 |
B32922C3224M |
220 nF - X2 |
EPCOS |
|
|
|
|
|
|
C7 |
|
2.2 nF - Y-CAP |
|
|
|
|
|
|
|
C8 |
|
470 nF ceramic - 25 V |
|
|
|
|
|
|
|
C10 |
|
4.7 nF ceramic - 25 V |
|
|
|
|
|
|
|
C11 |
|
1 nF ceramic - 25 V |
|
|
|
|
|
|
|
C12 |
|
3.3 μF - 35 V electrolytic |
|
|
|
|
|
|
|
C13 |
ZLH series |
100 μF - 16 V electrolytic |
Rubycon |
|
|
|
|
|
|
D1 |
STPS2150A |
Power Schottky diode |
STMicroelectronics |
|
|
|
|
|
|
D2 |
P6KE200A |
Transil™ |
STMicroelectronics |
|
|
|
|
|
|
D3 |
STTH1L06A |
Ultra-fast high voltage diode |
STMicroelectronics |
|
|
|
|
|
|
D4 |
STPS1L30A |
Power Schottky diode |
STMicroelectronics |
|
|
|
|
|
|
D5 |
BAT41 |
Small signal Schottky |
STMicroelectronics |
|
|
|
|
|
|
PD1 |
DF06S |
Input bridge rectifier |
|
|
|
|
|
|
|
L1 |
B82462G4472M |
4.7 μH power inductor |
EPCOS |
|
|
|
|
|
|
L2 |
B82422H1105K |
1 mH SMT inductor |
EPCOS |
|
|
|
|
|
|
IC1 |
ALTAIR04-900 |
Primary switching regulator |
STMicroelectronics |
|
|
|
|
|
|
Q1 |
LF33AB |
3.3 V LDO voltage regulator |
STMicroelectronics |
|
|
|
|
|
|
CM |
B82721K2701 |
CM Choke |
EPCOS |
|
|
|
|
|
|
|
744612101 |
|
Wurth |
|
|
|
|
|
|
TF1 |
ECO2017SEO-X05V015 |
Flyback transformer |
TDK |
|
|
|
||
|
760-871-431 |
Wurth |
||
|
|
|
||
|
|
|
|
|
|
NTC1 |
B57236S0160M |
NTC inrush current limiter |
EPCOS |
|
|
|
|
|
|
RV1 |
B72214S0321K |
320 V Varistor |
EPCOS |
|
|
|
|
|
|
F1 |
|
2 A fuse |
|
|
|
|
|
|
Note: |
If not otherwise specified, all resistors are 5%, ¼ W. |
|
Doc ID 18038 Rev 1 |
9/34 |
Test board design and evaluation |
|
AN3290 |
|
Table 3. |
ALTAIR04-900 power supply: transformer characteristics |
||
|
Core |
|
E16 |
Primary inductance |
|
2 mH |
|
Leakage inductance |
|
1.42% nom. |
|
Primary winding |
|
7.68 ± 5% |
|
|
Np1 |
|
111 turns |
|
Np2 |
|
55 turns |
|
Ns1 |
|
13 turns |
|
Ns2 |
|
6 turns |
|
Naux |
|
17 turns |
Primary to auxiliary turn ratio |
5.59 ± 5% |
||
Primary saturation current |
550 mA (@ 100 °C) |
||
Insulation primary-secondary |
AC 3 kV (1 s – 2 mA) |
||
Figure 5. |
ALTAIR04-900 power supply: transformer characteristics |
||
|
1 |
|
10 |
|
Npri |
Nsec1 |
|
|
3 |
|
9 |
|
5 |
|
8 |
|
Naux |
Nsec2 |
|
|
4 |
|
7 |
|
|
|
|
10/34 |
Doc ID 18038 Rev 1 |
||
|
|
|
|
AN3290 |
Output voltage characteristics |
|
|
Figure 6 and 7 show the load and the line regulation of the output 1 when the other output is charged with 40 mA and 80 mA respectively.
All output voltages have been measured on the output connector of the board.
When the output 2 is heavy loaded and the output 1 is light loaded, VOUT1 increases due to the cross regulation. In any case, the voltages are within the tolerance given in the
specifications.
/UTPUT VOLTAGE;6=
|
|
|
6AC |
6AC |
|
|
6AC |
|
6AC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
/UTPUT CURRENTT;M!= |
|
|
!-V
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9DF |
|
|
|
|
|
|
|
|
9DF |
|
|
2XWSXW YROWDJH >9@ |
|
|
|
|
|
9DF |
|
|
|
|
|
|
|
9DF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
2XWSXW FXUUHQW >P$@ |
|
|
!-V
