AN2929
Application note
Wide range [90 V - 265 V] input, 5 V - 12 W output VIPER27LN demonstration board with improved standby performance
Introduction
In consumer applications such as LCD or plasma TVs, some models of DVD recorders, settop boxes with hard disk, as well as desktop computers, the power supply often includes two modules: the main power supply that provides most of the power and is off when the application is in standby mode and the auxiliary power supply that provides energy for specific peripherals such as USB ports, remote receivers, and modems.
The auxiliary power supply is also on when the application is in standby mode and it is often required that its input power be as low as possible. The demonstration board presented in this application note meets the specification of a wide range of auxiliary power supplies for these applications and is optimized for very low standby consumption, helping to meet the most stringent energy-saving requirements.
April 2011 |
Doc ID 15333 Rev 2 |
1/32 |
www.st.com
Contents |
AN2929 |
|
|
Contents
1 |
Board description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
|
|
1.1 |
Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
|
1.2 |
Schematic and bill of material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
|
1.3 |
Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
2 |
Testing the board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 9 |
|
|
2.1 |
Typical board waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
|
2.2 |
Precision of the regulation and output voltage ripple . . . . . . . . . . . . . . . . |
10 |
|
2.3 |
Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
13 |
|
2.4 |
Light-load performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
|
2.5 |
Overload protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
|
2.6 |
Secondary winding short-circuit protection . . . . . . . . . . . . . . . . . . . . . . . |
22 |
|
2.7 |
Output overvoltage protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
|
2.8 |
Brownout protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
|
2.9 |
EMI measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
3 |
Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
30 |
|
4 |
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
30 |
|
5 |
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
31 |
2/32 |
Doc ID 15333 Rev 2 |
AN2929 |
List of figures |
|
|
List of figures
Figure 1. |
VIPER27LN demonstration board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 1 |
Figure 2. |
Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 5 |
Figure 3. |
Transformer size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Figure 4. |
Transformer size and pin diagram [inches (mm)] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
Figure 5. |
Drain current and voltage at full load 115 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Figure 6. |
Drain current and voltage at full load 230 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Figure 7. |
Drain current and voltage at full load 90 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Figure 8. |
Drain current and voltage at full load 265 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
Figure 9. |
Output voltage ripple 115 VINAC full load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Figure 10. |
Output voltage ripple 230 VINAC full load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
11 |
Figure 11. |
Output voltage ripple 115 VINAC at no load (burst mode) . . . . . . . . . . . . . . . . . . . . . . . . . . |
12 |
Figure 12. |
Output voltage ripple 230 VINAC 50 mA at no load (burst mode) . . . . . . . . . . . . . . . . . . . . |
12 |
Figure 13. |
Efficiency vs. VIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
14 |
Figure 14. |
Efficiency vs. load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
14 |
Figure 15. |
Active mode efficiency vs. VIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
15 |
Figure 16. |
Input voltage averaged efficiency vs. load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
16 |
Figure 17. |
ENERGY STAR® efficiency criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
Figure 18. |
Input power vs. input voltage for different loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Figure 19. |
Average switching frequency vs. input voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Figure 20. |
Output power vs. input voltage with input power of 1 W. . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
Figure 21. |
Output short-circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
Figure 22. |
Operation with output shorted. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
22 |
Figure 23. 2nd OCP tripping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
23 |
|
Figure 24. |
Operating with secondary winding shorted - restart mode . . . . . . . . . . . . . . . . . . . . . . . . . |
23 |
Figure 25. |
OVP circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Figure 26. |
OVP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Figure 27. |
Jumper J7 setting, brownout disabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
Figure 28. |
Jumper J7 setting, brownout enabled. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
Figure 29. |
Brownout protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
26 |
Figure 30. |
Input AC voltage steps from 90 VAC to 75 VAC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
28 |
Figure 31. |
Input voltage steps from 90 VAC to 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
28 |
Figure 32. |
115 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
Figure 33. |
230 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
Doc ID 15333 Rev 2 |
3/32 |
List of tables |
AN2929 |
|
|
List of tables
Table 1. Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Table 2. Bill of material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Table 3. Transformer characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Table 4. Output voltage and VDD line-load regulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Table 5. Output voltage ripple. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 6. Burst mode related output voltage ripple . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Table 7. Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Table 8. Active mode efficiencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Table 9. Line voltage averaged efficiency vs. load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Table 10. Energy efficiency criteria for standard models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Table 11. Energy efficiency criteria for low-voltage models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Table 12. No-load input power (no brownout) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Table 13. Energy consumption criteria for no load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 14. Low-load performance POUT = 25 mW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Table 15. Low-load performance POUT = 50 mW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Table 16. Output power when the input power is 1 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 17. Input and output load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Table 18. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4/32 |
Doc ID 15333 Rev 2 |
AN2929 |
Board description |
|
|
1.1Electrical specifications
The electrical specifications of the VIPER27LN demonstration board are listed in Table 1.
Table 1. |
Electrical specifications |
|
|
Symbol |
Parameter |
Value |
Unit |
|
|
|
|
VIN |
Input voltage range |
[90VRMS; 265VRMS] |
V |
VOUT |
Output voltage |
5 |
V |
IOUT |
Max output current |
2.4 |
A |
VOUT_LF |
Precision of output regulation |
±5% |
|
|
|
|
|
|
|
|
|
VOUT_HF |
High-frequency output voltage ripple |
50 |
mV |
|
|
|
|
|
|
|
|
TA |
Max ambient operating temperature |
60 |
°C |
The schematic of the board is shown in Figure 2. Table 2 gives the list of components (bill of material).
Figure 2. |
Schematic |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
"2 |
|
|
|
|
# |
+% |
|
|
|
3403 |
|
|
6 ! |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
* |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
"2)$ '% |
|
|
U& 6 |
|
|
|
$ |
344( , |
$ |
|
|
|
|
|
, U( |
|
|
|||
|
|
|
P& 6 |
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
# |
2 |
|
|
|
|
|
|
|
$ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
-EG |
|
|
|
|
|
|
|
|
# |
|
|
# |
#/. |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
:, U& 6 |
|
|
U& 6 |
9+ |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
# |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
# |
|
|
|
|
$ |
|
|
$ |
|
|
|
|
|
|
:, U& 6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
. |
|
"!4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 #!0 |
|
|
|
|
|
|
|
|
|
42!.3&/2-%2 |
|
|
|
|
|
|
||
|
|
|
4 |
|
|
|
|
2 |
|
2 |
|
|
|
# |
9 N& |
|
|
|
|
|
|
|
|
|
|
|
|
-EG |
|
-EG |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
K |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
#- #HOKE |
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
K |
|
|
|
|
|
|
# |
|
8 |
|
|
|
|
|
|
|
6)0%2 ,. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
*5-0%2 |
|
5 |
|
|
|
|
|
|
|
|
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
6$$ |
|
|
|
/04/ |
|
|
|
|
|
|
||
|
|
|
|
|
& |
|
|
* |
|
|
$2!). |
|
|
|
K |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
0# |
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
"2 |
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
! &53% |
# |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
||
|
|
|
|
|
|
|
|
|
|
|
#/.42/, |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
U& 6 |
|
|
|
|
|
|
|
|
|
|
# |
|
|
|
||
/HMH. 4# |
|
|
|
#/.4 |
|
|
|
|
|
|
|
|
|
K |
||||||||
|
|
|
# |
|
|
|
|
|
|
|
|
|
||||||||||
|
.4# |
|
|
|
|
|
N |
|
|
&" |
3/52#% |
|
|
|
|
N& |
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
T |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
62 |
K |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
# |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
6Z |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
K |
K |
|
|
N& |
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
$ |
|
|
|
|
|
|
|
43 |
|
|
|
||||
|
|
|
|
|
|
|
|
|
# |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
|
|
|
|
|
|
|
|
|
|
|
N& |
|
2 |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
K |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
K |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
* |
#/. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
!-V |
Doc ID 15333 Rev 2 |
5/32 |
Board description |
|
|
AN2929 |
|
|
|
|
|
|
|
Table 2. |
Bill of material |
|
|
|
|
|
|
|
|
Reference |
Part |
Description |
Manufacturer |
|
|
|
|
|
|
BR1 |
DF06M |
600 V 1 A diodes bridge |
Fairchild \ General |
|
Semiconductor |
|||
|
|
|
|
|
|
|
|
|
|
|
C1, C13 |
|
22 nF X2 capacitor |
Evox Rifa |
|
|
|
|
|
|
C3 |
|
450 V 33 µF electrolytic capacitor |
|
|
|
|
|
|
|
C4 |
|
35 V 22 µF electrolytic capacitor |
|
|
|
|
|
|
|
C5 |
Not mounted |
Not mounted |
|
|
|
|
|
|
|
C6 |
|
25 V ceramic capacitor |
|
|
|
|
|
|
|
C7 |
|
25 V ceramic capacitor |
|
|
|
|
|
|
|
C8 |
|
Y1 2.2 nF capacitor |
|
|
|
|
|
|
|
C9, C14 |
16 V ZL 1000 µF 10X20 |
1000 µF 16 V electrolytic capacitor |
Rubycon |
|
|
|
|
|
|
C10 |
16 V 100 µF YK |
100 µF 16 V YK rubycon |
Rubycon |
|
|
|
|
|
|
C11, C12 |
10 nF |
25 V ceramic capacitor |
|
|
|
|
|
|
|
D1 |
BAT46 |
Diode |
STMicroelectronics |
|
|
|
|
|
|
D2 |
1N4148 |
Diode |
|
|
|
|
|
|
|
D3 |
STTH1L06 |
Diode |
STMicroelectronics |
|
|
|
|
|
|
D4 |
STPS745 |
Diode |
STMicroelectronics |
|
|
|
|
|
|
D5 |
1.5KE250 |
Transil |
STMicroelectronics |
|
|
|
|
|
|
D6 |
BZX79-C18 |
Zener diode |
NXP |
|
|
|
|
|
|
F1 |
TR5 250 V 1 A |
Fuse |
|
|
|
|
|
|
|
L1 |
|
3.3uH |
|
|
|
|
|
|
|
NTC1 |
B57236S160M |
16 Ω NTC |
EPCOS |
|
|
|
|
|
|
OPTO1 |
PC817 |
Opto coupler |
Sharp |
|
|
|
|
|
|
R1 |
|
3.3 Ω axial resistor |
|
|
|
|
|
|
|
R16, R17 |
|
1600 kΩ 1% axial resistor |
|
|
|
|
|
|
|
R3 |
|
56 kΩ 1% axial resistor |
|
|
|
|
|
|
|
R6 |
|
12 kΩ axial resistor |
|
|
|
|
|
|
|
R8 |
|
120 kΩ 1% axial resistor |
|
|
|
|
|
|
|
R9 |
|
39 kΩ 1% resistor |
|
|
|
|
|
|
|
R10 |
|
270 kΩ axial resistor |
|
|
|
|
|
|
|
R14 |
|
220 kΩ 1% axial resistor |
|
|
|
|
|
|
|
R12 |
|
27 kΩ axial resistor |
|
|
|
|
|
|
|
R13 |
|
1 kΩ axial resistor |
|
|
|
|
|
|
|
R19 |
|
120 Ω axial resistor |
|
|
|
|
|
|
|
R20 |
|
Heatsink |
|
|
|
|
|
|
6/32 |
Doc ID 15333 Rev 2 |
AN2929 |
|
|
Board description |
|
|
|
|
|
|
|
Table 2. |
Bill of material (continued) |
|
|
|
|
|
|
|
|
Reference |
Part |
Description |
Manufacturer |
|
|
|
|
|
|
T1 |
750871111 |
Switch-mode power transformer |
Würth Elektronik |
|
|
|
|
|
|
T2 |
BU15-4530R4BL |
Common-mode choke |
Coilcraft |
|
|
|
|
|
|
U1 |
VIPER27LN |
Offline high-voltage converters |
STMicroelectronics |
|
|
|
|
|
|
VR1 |
TS431AIZ-AP |
Voltage reference |
STMicroelectronics |
|
|
|
|
|
The transformer characteristics are listed in the table below.
Table 3. |
Transformer characteristics |
|
||
|
Properties |
Test condition |
Value |
|
|
|
|
||
Manufacturer |
|
Würth Elektronik |
||
|
|
|
||
Part number |
|
750871111 |
||
|
|
|
||
Primary inductance |
Measured at 10 kHz 0.1 V |
1.7 mH ± 10% |
||
|
|
|
||
Leakage inductance |
Measured at 100 kHz 0.1 V |
60 μH |
||
|
|
|
||
Primary-to-secondary turn |
Measured at 10 kHz 0.1 V |
13.5 ± 3% |
||
ratio (6 - 4)/(7, 9 – 12, 14) |
||||
|
|
|||
|
|
|
||
Primary-to-auxiliary turn |
Measured at 10k Hz 0.1 V |
5.19 ± 3% |
||
ratio (6 - 4)/(3 - 1) |
||||
|
|
|||
|
|
|
|
|
|
Insulation |
Primary to secondary |
4 kV |
|
|
|
|
|
Doc ID 15333 Rev 2 |
7/32 |
Board description |
AN2929 |
|
|
The figures below show the size and pin distances (inches and [mm]) of the transformer.
(a) Top view |
(b) Bottom view |
|
|
(a) Pins distances |
|
|
(b) Electrical diagram |
|
|
||
|
|
||
|
|
|
|
8/32 |
Doc ID 15333 Rev 2 |
AN2929 |
Testing the board |
|
|
Drain voltage and current waveforms were captured for the two nominal input voltages and for the minimum and the maximum voltage of the converter’s input operating range.
Figure 5 and Figure 6 show the drain current and the drain voltage waveforms at the nominal input voltages of 115 VAC and 230 VAC when the load is the maximum (2.4 A). Figure 7 and Figure 8 show the same waveforms for the same load condition, but for the minimum (90 VAC) and the maximum (265 VAC) input voltages.
The converter is designed to operate in continuous conduction mode (in full-load condition) at low line. CCM (continuous conduction mode) allows reducing the root mean square current values at the primary side in the power switch inside the VIPER27LN and at the secondary side in the output diode (D4) and in the output capacitors (C9 and C14). Reducing RMS currents means reducing the power dissipation (mainly in the VIPER27LN) and the stress on these components.
Figure 5. Drain current and voltage at Figure 6. |
Drain current and voltage at |
|
full load 115 VAC |
full load 230 VAC |
|
|
|
|
Figure 7. Drain current and voltage at Figure 8. |
Drain current and voltage at |
|
full load 90 VAC |
full load 265 VAC |
|
|
|
|
Doc ID 15333 Rev 2 |
9/32 |
Testing the board |
AN2929 |
|
|
The output voltage of the board was measured in different line and load conditions (see Table 4). The output voltage is practically not affected by the line condition. The VDD voltage was also measured to verify that it is inside the operating range of the device.
Table 4. |
Output voltage and VDD line-load regulation |
|
|
||||
VINAC (V) |
|
No load |
Half load |
Full load |
|||
|
|
|
|
|
|
|
|
|
VOUT (V) |
VDD (v) |
VOUT (V) |
VDD (V) |
VOUT (V) |
VDD (V) |
|
|
|
||||||
|
|
|
|
|
|
|
|
90 |
|
5.05 |
9.79 |
5.05 |
18.9 |
5.04 |
19.8 |
|
|
|
|
|
|
|
|
115 |
|
5.05 |
9.71 |
5.05 |
18.9 |
5.04 |
19.7 |
|
|
|
|
|
|
|
|
230 |
|
5.05 |
9.37 |
5.05 |
18.8 |
5.04 |
19.6 |
|
|
|
|
|
|
|
|
265 |
|
5.05 |
9.22 |
5.05 |
18.8 |
5.04 |
19.6 |
|
|
|
|
|
|
|
|
In a dual-output flyback converter, when just one output is regulated, the unregulated output does not rigorously respect the turn ratio. The unregulated output voltage value depends not only on the turn ratio but also, approximately, from the output current ratio (output current of the regulated output divided by the output current of the unregulated output).
As confirmed from the results in Table 4, the VDD voltage (unregulated auxiliary output) increases as the load on the regulated output increases. In order to avoid that the VDD voltage exceeds its operating range, an external clamp was used (D6, R19). See schematic in Figure 2.
The ripple at the switching frequency superimposed at the output voltage was also measured and the results are given in Table 5. The board is provided with an LC filter for cleaner output voltage. The high-frequency voltage ripple across capacitor C9 (VOUT_FLY), which is the output capacitor of the flyback converter before the LC filter, was also measured to verify the effectiveness of the LC filter and to provide complete results.
Table 5. |
Output voltage ripple |
|
|
|
|||
VINAC (VRMS) |
|
Half load |
|
Full load |
|||
|
|
|
|
|
|
||
VOUT (mV) |
|
VOUT_FLY (mV) |
VOUT (mV) |
|
VOUT_FLY (mV) |
||
|
|
|
|
||||
90 |
|
25 |
|
275 |
40 |
|
172 |
|
|
|
|
|
|
|
|
115 |
|
26 |
|
275 |
37 |
|
201 |
|
|
|
|
|
|
|
|
230 |
|
26 |
|
273 |
36 |
|
194 |
|
|
|
|
|
|
|
|
265 |
|
25 |
|
272 |
36 |
|
195 |
|
|
|
|
|
|
|
|
10/32 |
Doc ID 15333 Rev 2 |
