SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Do not install this device on an unstable surface where it could fall and cause either
personal injury or damage to the device and/or other equipment.
When installing this device, ensure that the mount is sufficiently robust to support
the weight of the unit and to prevent unwanted movement.
Do not expose this device to excessive vibration.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct
sunlight.
This device ventilates excessive heat through the slots and openings in the case. Do
not block or cover these openings. Ensure that the device is in an open area where
it can get sufficient airflow to keep from overheating.
Do not place or install this device in an area where it can be exposed to excessive
amounts of dust, humidity, oil, smoke, or combustible vapors.
Use only in a well-ventilated area. Do not use in close, confined spaces.
Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
When installing this device, ensure that there are no flammable or combustible
materials within about 2 feet on all sides. Ensure that there is at least 2 feet of
clearance between the unit and the surface or object(s) being illuminated.
2
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
This device uses a grounded power cord and requires a ground connection for safe
operation. Ensure that the power source has a proper ground connection. Do not
modify the plug or use a "cheater" plug to bypass the ground connection.
Disconnect the unit from the power source when replacing the fuse. Replace the
fuse only with the same type.
Unplug this device from the power source when not in use.
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
Ensure that power is turned off and disconnected before making any electrical
connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
Avoid direct eye exposure to the light from this device.
Do not connect this light to a dimmer pack.
Do not look directly into the light source.
This device should only be operated by qualified adults.
In the event of serious operating problem, stop using the unit immediately.
Keep away from corrosive materials.
3
INTRODUCTION
Thank you for purchasing this Stage Wash PAR Light! This light features eighteen 18-watt
RGBWA-UV LEDs, 7- and 11-channel DMX control, built-in automatic and sound activated
programs, and the ability to operate as a Master or Slave light when connected with other
lights. The light can be operated using a DMX controller or stand-alone using the built-in
programs. The light can be zoomed, with variable beam angles from 8 ~ 60°.
FEATURES
Eighteen 18-watt RGBWA-UV LEDs
7-channel or 11-channel DMX control options
Variable beam angle/zoom from 8 ~ 60°
100 ~ 240 VAC, 50/60 Hz input power
Master or Slave mode options
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at support@monoprice.com
4
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Stage Wash PAR Light
1x User's Manual
CONTROLS
1. MENU: Press the MENU button to cycle through
the functions in the menu system. If editing a
value, pressing the MENU button will cancel any
changes made and will cycle to the next
function in the list.
2. UP: Press the UP button to increase the displayed value.
3. DOWN: Press the DOWN button to decrease the displayed value.
4. ENTER: Press the ENTER button to save the displayed value.
MASTER/SLAVE MODE
Multiple lights can be daisy-chained together using DMX cables. The first fixture should be
set to the desired operating mode, with all other fixtures set to A001. For example, set the
first fixture to CC99 to use the color jumping mode at the fastest rate, then set all other
fixtures to A001. All fixtures will then perform color jumping in unison.
5
MENU SYSTEM
Function
Values
Description
A###
001-512
11-channel DMX mode and address selection
d###
001-512
7-channel DMX mode and address selection
CC##
00-99
Color jumping mode (slow to fast)
CP##
00-99
Color gradient mode (slow to fast)
dE##
00-99
Color pulse variable mode (slow to fast)
bEb1
N/A
Sound activated mode with auto sensitivity
r###
000-255
Red dimmer (dark to bright)
G###
000-255
Green dimmer (dark to bright)
b###
000-255
Blue dimmer (dark to bright)
o###
000-255
White dimmer (dark to bright)
y###
000-255
Amber dimmer (dark to bright)
P###
000-255
Ultra-violet dimmer (dark to bright)
t###
000-255
Zoom (8° to 60°)
6
DMX MODE
Channel
Values
Function
1
0-255
Master dimmer (dark to bright)
2
0-255
Strobe (slow to fast)
3
0-40
No function
41-60
Color jumping mode
61-80
Color gradient mode
81-100
Color pulse variable mode
101-120
Sound control mode 1
121-140
Sound control mode 2
141-160
Color jumping mode (built-in program)
161-180
Color gradient mode (built-in program)
181-200
Color pulse variable mode (built-in program)
201-220
Sound control mode 1 (built-in program)
221-255
Sound control mode 2 (built-in program)
4
0-255
Program speed (slow to fast) or sound sensitivity (less to more)
5
0-255
Red dimmer (dark to bright)
6
0-255
Green dimmer (dark to bright)
7
0-255
Blue dimmer (dark to bright)
8
0-255
White dimmer (dark to bright)
9
0-255
Yellow dimmer (dark to bright)
10
0-255
Purple dimmer (dark to bright)
11
0-255
Zoom (8° to 60°)
11-Channel
7
7-Channel
Channel
Value Range
Function
1
0-255
Red dimmer (dark to bright)
2
0-255
Green dimmer (dark to bright)
3
0-255
Blue dimmer (dark to bright)
4
0-255
White dimmer (dark to bright)
5
0-255
Yellow dimmer (dark to bright)
6
0-255
Purple dimmer (dark to bright)
7
0-255
Zoom adjust (8° to 60°)
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to tech@monoprice.com
8
SPECIFICATIONS
Model
612712
Light Source
18x 18-watt RGBWA-UV LEDs
Beam Angle
8° ~ 60°
Control Modes
DMX, Auto Programs, Sound Activated, Master/Slave
DMX Channels
7 or 11
Input Power
100 ~ 240 VAC, 50/60 Hz
Power Consumption
300 watts
Dimensions
12.1" x 12.1" x 13.8" (308 x 308 x 350 mm)
Weight
7.7 lbs. (3.5 kg)
