SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Do not install this device on an unstable surface where it could fall and cause either
personal injury or damage to the device and/or other equipment.
When installing this device, ensure that the mount is sufficiently robust to support
the weight of the unit and to prevent unwanted movement.
Do not expose this device to excessive vibration.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct
sunlight.
This device ventilates excessive heat through the slots and openings in the case. Do
not block or cover these openings. Ensure that the device is in an open area where
it can get sufficient airflow to keep from overheating.
Do not place or install this device in an area where it can be exposed to excessive
amounts of dust, humidity, oil, smoke, or combustible vapors.
Use only in a well-ventilated area. Do not use in close, confined spaces.
When installing this device, ensure that there are no flammable or combustible
materials within about 2 feet on all sides. Ensure that there is at least 2 feet of
clearance between the unit and the surface or object(s) being illuminated.
Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
2
Page 3
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
This device uses a grounded power cord and requires a ground connection for safe
operation. Ensure that the power source has a proper ground connection. Do not
modify the plug or use a "cheater" plug to bypass the ground connection.
Disconnect the unit from the power source when replacing the fuse. Replace the
fuse only with the same type.
Unplug this device from the power source when not in use.
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
Ensure that power is turned off and disconnected before making any electrical
connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
Avoid direct eye exposure to the light from this device.
Do not connect this light to a dimmer pack.
Do not look directly into the light source.
This device should only be operated by qualified adults.
In the event of serious operating problem, stop using the unit immediately.
Keep away from corrosive materials.
3
Page 4
INTRODUCTION
Thank you for purchasing this Stage Wash Moving Head Light! This light features seven 12-
watt RGBW, 10-channel and 15-channel DMX control, built-in automatic and sound
activated programs, and the ability to operate as a Master or Slave light when connected
with other lights. The light can be operated using a DMX controller or stand-alone using
the built-in programs. The light can be zoomed, with variable beam angles from 8 ~ 60°.
The X and Y motors can be reversed, allowing for inverted and mirrored operation.
FEATURES
Seven 12-watt RGBW 4-in-1 LEDs
Moving head with 540° pan and 190° tilt range
10-channel or 15-channel DMX control options
Variable beam angle/zoom from 8 ~ 60°
100 ~ 240 VAC, 50/60 Hz input power
Master or Slave mode options
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at [email protected]
4
Page 5
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Stage Wash Moving Head Light
1x AC Power Cord
1x Mounting Bracket
2x Screws
2x Washers
1x User's Manual
CONTROLS
1. MENU: Press the MENU button to cycle through
the functions in the menu system. If editing a
value, pressing the MENU button will cancel any
changes made and will cycle to the next
function in the list.
2. DOWN: Press the DOWN button to increase the displayed value.
3. UP: Press the UP button to decrease the displayed value.
4. ENTER: Press the ENTER button to save the displayed value.
MASTER/SLAVE MODE
Multiple lights can be daisy-chained together using DMX cables. The first fixture should be
set to the desired operating mode and all other fixtures should be set to SL 2 slave mode
(SLnd menu function). For example, set the first fixture for sound activated mode at a
medium rate, then set all the other fixtures to SL 2 slave mode. All fixtures will then move
in unison as the music plays.
5
Page 6
MENU SYSTEM
Function
Values
Description
Addr
A001-A512
DMX starting address
CHnd
15Ch
15-channel DMX mode
10Ch
10-channel DMX mode
SLnd
Auto
Master mode with auto program function. Does not
work when a DMX cable is plugged into DMX IN.
Soun
Master mode with sound activated function. Does not
work when a DMX cable is plugged into DMX IN.
SL 1
DMX512 mode. Requires a DMX controller plugged into
DMX IN.
SL 2
Slave mode.
SHnd
SH 0
Effect 0 (recommended)
SH 1
Effect 1
SH 2
Effect 2
SH 3
Effect 3
SenS
000-100
bLnd
bLAc
The fixture will clear its state if the DMX signal is lost.
Auto
The fixture will enter auto mode if the DMX signal is lost.
Soun
The fixture will enter sound activated mode if the DMX
signal is lost.
HLod
The fixture will retain the last state if the DMX signal is
lost.
LEd
oFF
The LED display will turn off after 5 seconds with not
button input.
on
The LED display will remain on at all times.
6
Page 7
Function
Values
Description
diSP
no
The LED display is inverted.
yES
The LED display is no inverted.
rPAn
no
X motor (pan) normal operation.
yES
X motor (pan) inverted.
rTiL
no
Y motor (tilt) normal operation.
yES
Y motor (tilt) inverted.
rESt
yES
System reset.
Channel
Values
Function
1
0-255
Horizontal (pan) movement
2
0-255
Vertical (tilt) movement
3
0-255
Zoom (60° to 8°)
4
0-255
Master dimmer (dark to bright)
5
0-255
Strobe (slow to high)
6
0-255
Red dimmer (dark to bright)
7
0-255
Green dimmer (dark to bright)
8
0-255
Blue dimmer (dark to bright)
9
0-255
White dimmer (dark to bright)
10
0-200
No function
201-255
System reset
DMX MODE
10-Channel
7
Page 8
15-Channel
Channel
Value Range
Function
1
0-255
Horizontal (pan) movement
2
0-255
16-bit Horizontal (pan) fine movement
3
0-255
Vertical (tilt) movement
4
0-255
16-bit Vertical (tilt) fine movement
5
0-255
Motor speed (slow to fast)
6
0-255
Zoom (60° to 8°)
7
0-255
Master dimmer (dark to bright)
8
0-255
Strobe (slow to fast)
9
0-255
Red dimmer (dark to bright)
10
0-255
Green dimmer (dark to bright)
11
0-255
Blue dimmer (dark to bright)
12
0-255
White dimmer (dark to bright)
13
0-15
No function
16-128
Auto mode
129-255
Sound activated mode
14
0-255
Auto mode speed (fast to slow) or sound sensitivity (less to
more)
15
0-200
No function
201-255
System reset
8
Page 9
TECHNICAL SUPPORT
Model
612806
Light Source
7x 12-watt RGBW 4-in-1 LEDs
Beam Angle
8° ~ 60°
Pan Range
540°
Tilt Range
190°
Control Modes
DMX, Auto Run, Sound Activated, Master/Slave
DMX Channels
10 or 15
Input Power
100 ~ 240 VAC, 50/60 Hz
Power Consumption
95 watts
Dimensions
6.3" x 5.9" x 11.8" (160 x 150 x 300 mm)
Weight
8.9 lbs. (4.05 kg)
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to [email protected]
SPECIFICATIONS
9
