SRS Labs ADVW791 Quick Setup Manual
1
ATOMIC
Quick
Set-Up Guide
ADVW791
(NOYRF835 & NOYRF791)
900MHz
Digital Headphones
is a trademark of SRS Labs, Inc.
2
Congratulations on the purchase of ADVW791 (RF8338-51) (900MHz) Stereo RF
Wireless Headphones to enjoy the revolutionary technology of Phase Lock Loop (PLL)
& Sound Retrieval System (SRS)! Please check the supplied component against the
following list:
1 x Transmitter
1 x Headphones
1 x Power Supply (AC/DC 12V 200mA Adaptor for Transmitter)
1 x 3.5mm Stereo Audio Cord
1 x 3.5mm Y-connection Cord
1 x Charging Cord
FUNCTION KEYS
HEADPHONES
(1) Headbelt
(2) Ear Cushion
(3) Digital Volume Up button
(4) Digital Volume Down button
(5) Power LED Indicator
(6) Digital Tuning button
(7) Digital Power ON/OFF button
(8) Charging IN Socket
(9) SRS Switch
(10) SRS LED Indicator
1
1
1
2
L
eft Hand Side
Right Hand Side
3
4
5
7
6
1
2
8
9
10
3
(11) Battery Compartment
(12) Battery cover
TRANSMITTER:
Transmitter Front Side:
(13) Charging LED Indicator
(14) Power LED Indicator
Transmitter Rear Side:
(15) Channel CH1/CH2/CH3 Switch
(16) Audio IN Socket
(17) Charging Socket
(18) DC IN Socket
ACCESSORIES:
(19) 3.5mm Y-connection Cord
(20) AC/DC Adaptor
(21) 3.5mm Stereo Audio Cord
(22) Charging Cord
13
14
16
18
17
15
19
21
20
22
