MOTION
CONTROL
DUAL
AIR
POPLOC
USER MANUAL
ALL
TRAVEL
ISOLITE
CUSHION
NOTE: YOUR FORK’S APPEARANCE MAY VARY FROM THE ILLUSTRATIONS/PHOTOS IN THIS MANUAL.
F
OR THE LATEST INFORMATION ABOUT YOUR FORK VISIT OUR WEBSITE AT WWW.ROCKSHOX.COM.
Air Cap (IFP Pressure)
Abdeckkappe (IFP-Druck)
Tapón de la válvula de aire (presión IFP)
Capuchon (pression du piston flottant interne)
Tappo dell'aria (pressione IFP)
Rosca de ar (pressão de IFP)
Internal Floating Piston
Innenliegender Schwimmerkolben
Pistón flotante interno
Piston flottant interne
Pistone Galleggiante Interno
Inwendige vrije zuiger
Pistão flutuante interno
IFP
Rebound Assembly
Zugstufen-Baugruppe
Conjunto de rebote
Assemblage du rebond
Gruppo di ritorno
Terugveringsmontage
Unidade de recuperação
Rebound Adjuster
Zugstufen-Einsteller
Ajustador del rebote
Régleur de rebond
Regolatore del ritorno
Terugveringsknop
Regulador de recuperação
Dual Air Assembly
Dual Air-Baugruppe
Conjunto Dual Air
Assemblage Dual Air
Gruppo aria doppia
Dual Air-montage
Unidade de Dual Air
Air Cap (Negative Air)
Abdeckkappe (Negativ-Luftdruck)
Tapón de la válvula de aire (presión de aire negativa)
Capuchon (air négatif)
Tappo dell'aria (aria negativa)
Luchtdop (Negatieve lucht)
Rosca de ar (ar negativo)
Air Cap (Positive Air)
Abdeckkappe (Positiv-Luftdruck)
Tapón de la válvula de aire (presión de aire positiva)
Capuchon (air positif)
Tappo dell’aria (aria positiva)
Luchtdruk (Positieve lucht)
Rosca de ar (ar positivo)
SS II DD RR
AA CC EE
N
OTE: YOUR FORK’S APPEARANCE MAY VARY FROM THE ILLUSTRATIONS/PHOTOS IN THIS MANUAL.
FOR THE LATEST INFORMATION ABOUT YOUR FORK VISIT OUR WEBSITE AT WWW.ROCKSHOX.COM.
Cable Housing Stop Collar
Zuganschlag
Collarín de retención de la vaina del cable
Collier d’arrêt de la gaine de câble
Collare di fermo della guaina del cavo
Stopkraag kabeldoorvoer
Encaixe do cabo na anilha do batente
Floodgate / Floodgate /
Compuerta Floodgate/ Vanne Floodgate /
FloodgateOverloopbescherming /
Floodgate /
Compression Adjuster / Druckstufen-Einsteller /
A
justador de la compresión / Régleur de compression
Regolatore della compressione / Compressieknop /
Regulador de compressão /
Motion Control Compression Assembly
Baugruppe für Druckstufenregelung
Conjunto de compresión Motion Control
Assemblage de compression Motion Control
Gruppo di compressione del controllo movimento
Bewegingscontrole compressiemontage
Unidade de compressão do controlo de movimento
Motion Control Rebound Assembly
Baugruppe für Zugstufenregelung
Conjunto de rebote Motion Control
Assemblage de rebond Motion Control
Gruppo di ritorno del controllo movimento
Bewegingscontrole terugveringsmontage
Unidade de recuperação do controlo de movimento
Air Cap (Positive Air)
Abdeckkappe (Positiv-Luftdruck)
Tapón de la válvula de aire (presión de aire positiva)
Capuchon (air positif)
Tappo dell’aria (aria positiva)
Luchtdruk (Positieve lucht)
Rosca de ar (ar positivo)
Dual Air Assembly
Dual Air-Baugruppe
Conjunto Dual Air
Assemblage Dual Air
Gruppo aria doppia
Dual Air-montage
Unidade de Dual Air
Rebound Adjuster
Zugstufen-Einsteller
Ajustador del rebote
Régleur de rebond
Regolatore del ritorno
Terugveringsknop
Regulador de recuperação
Air Cap (Negative Air)
Abdeckkappe (Negativ-Luftdruck)
Tapón de la válvula de aire (presión de aire negativa)
Capuchon (air négatif)
Tappo dell'aria (aria negativa)
Luchtdop (Negatieve lucht)
Rosca de ar (ar negativo)
SS II DD TT
EE AAMM AA NN DDWWOO RRLL DDCCUU PP
4 954-311120-000, REV.B
ENGLISH SRAM CORPORATION. • SID USER MANUAL
SRAM CORPORATION • APRIL 2005 5
SRAM CORPORATION • SID USER MANUAL ENGLISH
II
NN SS TT AA LLLL AA TT II OO NN
It is extremely important that your RockShox fork is installed correctly by a qualified
bicycle mechanic. Improperly installed forks are extremely
ddaannggeerroouuss
and can result
in
sseevveerree aanndd//oorr ffaattaall iinnjjuurriieess
.
1. Remove the existing fork from the bicycle and the crown race from the fork. Measure the length of the
fork steerer tube against the length of the RockShox steerer tube. The RockShox steerer tube may need
cutting to the proper length. Make sure there is sufficient length to clamp the stem (refer to the stem
manufacturer's instructions).
2. Install the headset crown race (29.9mm for 1 1/8" steerers) firmly against the top of the fork crown.
Install the fork assembly on the bike. Adjust the headset until you feel no play or drag.
3. Install the brakes according to the manufacturer's instructions and adjust brake pads properly. Use the
fork only with disc style brakes mounted through the provided mounting holes.
4. Forks designed for standard quick releases: adjust the front wheel quick release to clear the
dropout's counter bore. The quick release nut must be tightened after the wheel is properly seated into
the dropout's counter bore. Make sure four or more threads are engaged in the quick release nut when
it is closed. Orient the quick release lever in front of and parallel to the lower tube in the locked
position. Forks designed for a thru-axle (not available for all forks): follow the installation
instructions that follow for the Maxle Quick Release system
5. Keep in mind tire clearance as you choose tires. Maximum size is 2.4" wide or 696 mm diameter
installed. Be sure to check this diameter whenever you change tires. To do this, remove air pressure and
compress the fork completely to make sure at least 5 mm of clearance exists between the top of the tire
and the bottom of the crown. Exceeding maximum tire size will cause the tire to jam against the crown
when the fork is fully compressed.
THIS FORK IS NOT DESIGNED FOR EXTREME APPLICATIONS, SUCH AS DOWNHILL STYLE RIDING OR JUMPING. WE
RECOMMEND USING ONE OF OUR OTHER FORKS SUCH AS
BOXXER FOR THIS TYPE OF RIDING.
CC
AARRBBOONNCCRROOWWNN
--SS
TTEEEERREERRIINNSSTTAALLLLAATTIIOONN
((WW
OORRLLDDCCUUPP OONNLLYY
))
The SID World Cup is designed for cross-country riding and racing. The one piece carbon crownsteerer accounts for the unique loads and stresses of mountain bike riding, while providing
vibration damping and ride control unmatched by traditional material technologies.
It is extremely important that your fork is installed correctly by a qualified bicycle mechanic.
Improperly installed forks are extremely dangerous and can result in severe and/or fatal injuries.
For installation, follow the instructions below as well as the instructions in your owner's manual.
1. The steerer tube must be cut flush with the top of the stem. Apply masking tape to the top of the
steerer tube to help prevent carbon fraying during cutting. Use a minimum 28-tooth blade to cut the
carbon steerer. For safe handling, smooth the cut surface area with 400 grit sand paper.
2. Install a 2mm spacer above the stem to allow for proper headset adjustment. Do not exceed the 30mm
maximum stack height when installing spacers (Fig. 1).
3. Do not use star nuts. Use only expansion style plugs such as the one supplied with the fork. Do not
exceed 100 in-lb of torque to the expansion plug bolt. Torque values may vary depending on headset
design and condition.
DO NOT ADD THREADS TO ROCKSHOX THREADLESS STEERERS. THE
STEERER TUBE CROWN ASSEMBLY IS A ONE-TIME PRESS FIT.
REPLACEMENT OF THE ASSEMBLY MUST BE DONE TO CHANGE THE
LENGTH, DIAMETER OR HEADSET TYPE (THREADED OR
THREADLESS).
DO NOT REMOVE OR REPLACE THE STEERER TUBE. THIS COULD
RESULT IN THE LOSS OF CONTROL OF THE BICYCLE WITH POSSIBLE
SERIOUS AND/OR FATAL INJURIES.
WARNING
!
1. The fork on your bicycle is designed for use by a single rider, on mountain trails,
and similar off-road conditions.
2. Before riding the bicycle, be sure the brakes are properly installed and adjusted. Use
your brakes carefully and learn your brakes' characteristics by practicing your braking
technique in non-emergency circumstances. Hard braking or improper use of the front
brake can cause you to fall. If the brakes are out of adjustment, improperly installed or
are not used properly, the rider could suffer serious and/or fatal injuries.
3. Your fork may fail in certain circumstances, including, but not limited to, any
condition that causes a loss of oil; collision or other activity bending or breaking
the fork's components or parts; and extended periods of non-use. Fork failure
may not be visible. Do not ride the bicycle if you notice bent or broken fork parts,
loss of oil, sounds of excessive topping out, or other indications of a possible fork
failure, such as loss of shock absorbing properties. Instead, take your bike to a
qualified dealer for inspection and repair. In the event of a fork failure, damage to
the bicycle or personal injury may result.
4. Always use genuine RockShox parts. Use of aftermarket replacement parts voids
the warranty and could cause structural failure to the shock. Structural failure could
result in loss of control of the bicycle with possible serious and/or fatal injuries.
5.Use extreme caution not to tilt the bicycle to either side when mounting the bicycle
to a carrier by the fork drop-outs (front wheel removed). The fork legs may suffer
structural damage if the bicycle is tilted while the drop-outs are in the carrier.
Make sure the fork is securely fastened down with a quick release. Make sure the
rear wheel is fastened down when using ANY bike carrier that secures the fork’s
drop-outs. Not securing the rear can allow the bike’s mass to side-load the dropouts, causing them to break or crack. If the bicycle tilts or falls out of its carrier, do
not ride the bicycle until the fork is properly examined for possible damage.
Return the fork to your dealer for inspection or call RockShox if there is any
question of possible damage (See the International Distributor List). A fork leg or
drop-out failure could result in loss of control of the bicycle with possible serious
and/or fatal injuries.
6. Forks designed for use with 'v'-style brakes: only mount cantilever-type brakes
to the existing brake posts. Forks with hangerless style braces are only designed
for ‘V’- style or hydraulic cantilever brakes. Do not use any cantilever brake other
than those intended by the brake manufacturer to work with a hangerless brace.
Do not route the front brake cable and/or cable housing through the stem or any
other mounts or cable stops. Do not use a front brake cable leverage device
mounted to the brace. Forks designed for use with disc-style brakes: follow the
brake manufacturer's installation instruction for proper installation and mounting of
the brake caliper.
7. Observe all owner's manual instructions for care and service of this product.
ROCKSHOX FORKS ARE DESIGNED FOR COMPETITIVE OFF-ROAD RIDING AND
DO NOT COME WITH THE PROPER REFLECTORS FOR ON-ROAD USE. YOUR
DEALER SHOULD INSTALL PROPER REFLECTORS TO MEET THE CONSUMER
PRODUCT SAFETY COMMISSION’S (CPSC) REQUIREMENTS FOR BICYCLE
STANDARDS IF THE FORK IS GOING TO BE USED ON PUBLIC ROADS AT ANY TIME.
IMPORTANT
Consumer Safety Information
Congratulations! You have the best in suspension components on your bicycle! This
manual contains important information about the safe operation and maintenance of your
fork. To ensure that your RockShox fork performs properly, we recommend that you have
your fork installed by a qualified bicycle mechanic. We also urge you to follow our
recommendations to help make your riding experience more enjoyable and trouble-free.
6 954-311120-000, REV.B SRAM CORPORATION • APRIL 2005 7
ENGLISH SRAM CORPORATION. • SID USER MANUAL SRAM CORPORATION • SID USER MANUAL ENGLISH
ADDING POSITIVE A IR PRESSURE (LEFT T OP CAP, ALL FORKS)
Remove the air cap to expose the air valve (on the left fork leg). Using a RockShox Air Pump
(with schrader valve), add the recommended air pressure (see “Air Pressure Guidelines").
NOTE: RECOMMENDED MAXIMUM AIR PRESSURE IS 180 PSI.
Adjusting your forks negative air pressure will change its ride characteristic. More negative air
pressure will make the fork more active over small bumps. Less negative air pressure will
reduce bobbing. Set the negative air between 50 and 90 percent of the positive air pressure
depending on terrain and riding style. Always tune positive air pressure first, then adjust
negative air pressure.
Postive Pressure Negitive Pressure
Rider Weight XC (Plush Ride) Racing (Stiff Ride)
>120lb (55 kg) 70-80 psi 70-80 psi 40-60 psi
120-140lb (55-65 kg) 80-100 psi 80-100 psi 60-80 psi
140-160lb (65-73 kg) 100-120 psi 100-120 psi 80-100 psi
160-180lb (73-82 kg) 120-140 psi 120-140 psi 100-120 psi
>180lb (82 kg) 140-160 psi 140-160 psi 120-140 psi
ADDING NEGATIVE AIR P RESSURE
Remove the schrader air cap from the bottom of the left shaft air valve. Using a RockShox air
pump, add the recommended air pressure through the bottom of the left shaft air valve. A small
amount of lubricant can escape while adjusting the negative air, use care to avoid contamination
of the disc brake rotors.
NOTE: RECOMMENDED MAXIMUM AIR PRESSURE IS 180 PSI. MORE NEGATIVE AIR THAN POSITIVE AIR WILL
CAUSE THE FORK TO LOSE TRAVEL
External Rebound Adjustment
Rebound damping controls the speed at which a fork returns to its full extension following
compression. Located at the bottom of the right fork leg is the rebound adjuster knob. Turning
the adjuster in the direction indicated by the "rabbit" on the rebound speed decal decreases
rebound damping, causing the fork to return to full extension faster. Turning the adjuster in the
direction indicated by the "turtle" increases rebound damping, slowing the return of the fork to
full extension.
Excessive rebound damping will cause the fork to "pack up" over successive bumps, reducing
travel and causing the fork to bottom out. Set your fork to rebound as fast as possible without
"topping out" or kicking back. This allows your fork to follow the contours of the trail,
maximizing stability, traction and control.
Changing Travel
To measure the amount of travel your fork has, measure the amount of exposed upper tube.
To change the travel of your fork for 80 to 63 mm you must perform a full service on your fork.
To obtain service information or instructions, visit our website at www.rockshox.com or contact
your local RockShox dealer or distributor.
MM
OOTTIIOONNCCOONNTTRROOLL
((WW
OORRLLDDCCUUPP AANNDDTTEEAAMM
))
Your fork uses the Motion Control Damping System. This system provides maximum ride
control, allowing the rider to smooth out the bumps, with on-the-fly adjustable compression
damping (including lockout for climbing).
Installation of PopLoc Remote on the SID Motion Control Damper
Before starting, clean and inspect the fork. You should perform any needed service (i.e.,
bleeding or rebuilding the Motion Control damper) before installing the PopLoc Remote. For
full technical documentation visit www.rockshox.com.
4. To prevent damage to the carbon crown-steerer, a qualified technician should take care when installing
or removing the crown race.
5. Remove any burrs from the stem clamp edges before installation on the carbon crown-steerer. Do not
use a hammer to install your stem.
6. Follow the stem manufacturer's torque specifications when installing a stem. Exceeding the torque
specifications may damage the carbon crown-steerer and reduce the strength of the fork. Cotter style
stems are not recommended as the small surface area may cause damage, especially when overtorqued.
7. Do not let brake or derailleur cables rest on, or be attached to the crown. Abrasion over time may cause
damage to the crown. If contact is unavoidable, use tape or similar protection to cover the surface.
IMPORTANT: CROWN ABRASION IS NOT COVERED UNDER WARRANTY.
8. Take your bicycle to a qualified dealer for inspection and repair if there is any question of component
integrity due to a crash or other direct impact.
PP
EE RR FF OO RRMM AA NN CC EETTUU NN II NN GG
RockShox SID forks can be tuned for your particular weight, riding style, and terrain.
Setting Sag
SID forks are designed to sag when you are sitting on your bike. Sag is the compression of the
fork caused by the rider's weight. Proper sag allows the front wheel to follow the contour of
the terrain as you ride. Sag is adjusted by increasing or decreasing the positive air pressure of
your fork. Increasing the pressure in your positive chambers will decrease sag. Decreasing the
pressure in your positive air chambers will increase sag.
To measure sag, use the travel indicator on the upper tube of the fork and ensure it is flush
against the wiper seal. Sit on the bike with normal riding apparel. Step off the bike, and
measure the distance between the wiper seal and the travel indicator. This is your sag. The sag
should be approximately 20 percent of maximum travel.
Air Pressure Guidelines
The positive air chamber is the fork’s spring. Always tune positive air pressure first, based on
the desired sag. More positive air gives a firmer ride, while less positive air gives a
softer/plusher ride. Use the tables below to assist with positive and negative air pressure.
Carbon Steerer
Stem
Head Tube
Headset
Spacer
2mm Spacer
30mm max spacer stack
Fig. 1
8 954-311120-000, REV.B SRAM CORPORATION • APRIL 2005 9
ENGLISH SRAM CORPORATION. • SID USER MANUAL SRAM CORPORATION • SID USER MANUAL ENGLISH
MM
AA II NN TT EE NN AA NN CC EE
To maintain the high performance, safety, and long life of your fork, periodic maintenance is
required. If you ride in extreme conditions, maintenance should be performed more frequently.
*WE RECOMMEND THIS SERVICE BE PERFORMED BY A QUALIFIED BICYCLE MECHANIC. TO OBTAIN
SERVICE INFORMATION OR INSTRUCTIONS, VISIT OUR WEBSITE AT WWW.ROCKSHOX.COM OR CONTACT
YOUR LOCAL ROCKSHOX DEALER OR DISTRIBUTOR.
Torque Tightening Values
Top Caps 65 in-lb
Brake Posts 80 in-lb
Cartridge Sleeve Retainer 60 in-lb
Air Shaft Nut 45 in-lb
Damper Shaft Bolt 60 in-lb
Remote Lockout clamp bolt 8 in-lb
Pure top cap clamp screw 12 in-lb
Climb-It knob screw 12 in-lb
INSTALLING THE POPLOC R EMOTE LEVER:
1. Remove the grip, shifter and brake lever from the left side of the bar
when viewed from the rider's perspective. Install PopLoc remote
inboard of shifter and brake lever. Tighten lever clamp bolt to 20
in-lb. (Fig. 1)
2. Reinstall the brake, shifter and grip according to the manufacturer's
instructions.
ATTACHING THE CABLE:
1. Install shifter cable in PopLoc lever and cut a length of cable
housing to fit between the remote and cable stop of the remote
collar. Be sure to debur the housing ends.
NOTE: BRAKE CABLE HOUSING MUST BE USED FOR CORRECT
PERFORMANCE.
2. If using a PopLoc remote with adjustable compression damping
set the damper control in the middle position (approximately 2.5
turns from fully closed). For both PopLoc and PopLoc Adjust
levers depress the lockout lever toward the handlebar until the
lever engages into the lock position.
3. Feed cable through housing and around remote lockout cap. Pull
the cable back towards the housing stop collar. Make sure that
the cable pinch bolt is contacting the housing stop collar. Tighten
cable anchor bolt to 8 in-lb. Verify fork is locked at this setting.
(Fig.2)
4. Press release button on PopLoc remote to check action of
remote. The cable anchor bolt on the remote top cap should
return to approximately 3 or 4 o'clock. (Fig. 3).
PP
UU RR EEDDEELLII TT EESSYY SS TT EE MM
((RR
AA CC EE
))
Pure DeLite offers a wide range of rebound damping
adjustment. In addition, adjusting the air pressure in this
chamber (right fork leg) helps fine-tune the small bump ride
(threshold or break-away) of the fork. This chamber should
be inflated to a minimum of 10 psi and a maximum of 60
psi. Less air pressure will make the fork feel softer and helps
absorb smaller bumps, while more air pressure will make the
fork feel stiffer.
We recommend adjusting the positive and negative air pressures before you adjust the air
pressure in the Pure Delite chamber (right side, rider’s perspective).
NOTE: AIR PRESSURE IN THE PURE DELITE SYSTEM SHOULD NOT BE USED TO TUNE THE SPRING RATE OR
BOTTOM OUT FORCE REQUIRED FOR THE FORK
.
Fig. 1
Fig. 2
Fig. 3
SRAM CORPORATION • APRIL 2005 11
SRAM CORPORATION • SID USER MANUAL ENGLISH
SRAM CORPORATION W ARRANTY
Extent of Limited Warranty
SRAM warrants its products to be free from defects in materials or workmanship for a period of
two years after original purchase. This warranty only applies to the original owner and is not
transferable. Claims under this warranty must be made through the retailer where the bicycle or
the SRAM component was purchased. Original proof of purchase is required.
Local law
This warranty statement gives the customer specific legal rights. The customer may also have
other rights which vary from state to state (USA), from province to province (Canada), and from
country to country elsewhere in the world.
To the extent that this warranty statement is inconsistent with the local law, this warranty shall be
deemed modified to be consistent with such law, under such local law, certain disclaimers and
limitations of this warranty statement may apply to the customer. For example, some states in the
United States of America, as well as some governments outside of the United States (including
provinces in Canada) may:
a. Preclude the disclaimers and limitations of this warranty statement from limiting the statutory
rights of the consumer (e.g. United Kingdom).
b. Otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations.
Limitations of Liability
To the extent allowed by local law, except for the obligations specifically set forth in this warranty
statement, In no event Shall SRAM or its third party supplies be liable for direct, indirect, special,
incidental, or consequential damages.
Limitations of Warranty
- This warranty does not apply to products that have not been incorrectly installed and/or adjusted
according to the respective SRAM technical installation manual. The SRAM installation manuals can be
found online at www.sram.com or www.rockshox.com.
- This warranty does not apply to damage to the product caused by a crash, impact, abuse of the product,
non-compliance with manufacturers specifications of usage or any other circumstances in which the
product has been subjected to forces or loads beyond its design.
- This warranty does not apply when the product has been modified.
- This warranty does not apply when the serial number or production code has been deliberately altered,
defaced or removed.
- This warranty does not apply to normal wear and tear. Wear and tear parts are subject to damage as a
result of normal use, failure to service according to SRAM recommendations and/or riding or
installation in conditions or applications other than recommended.
WEAR AND TEAR PARTS ARE IDENTIFIED AS:
• Dust seals • Bushings
• Air sealing o-rings • Glide rings
• Rubber moving parts. • Foam rings
• Rear shock mounting hardware • Upper tubes (stanchions)
and main seals
• Stripped threads/bolts (aluminium, • Brake sleeves
titanium, magnesium or steel)
• Brake pads • Chains
• Sprockets • Cassettes
• Shifter and brake cables (inner and outer) • Handlebar grips
• Shifter grips • Jockey wheels
• Disc brake rotors • Tools
- This warranty shall not cover damages caused by the use of parts of different manufacturers.
- This warranty shall not cover damages caused by the use of parts that are not compatible, suitable
and/or authorised by SRAM for use with SRAM components.
10 954-311120-000, REV.B
ENGLISH SRAM CORPORATION. • SID USER MANUAL
SERVICE INTERVALS
Judy 1/2
Judy 3/4
Clean dirt and debris from upper tubes E E
Inspect upper tubes for scratches E E
Lubricate dust seals/tubes 1010
Check top caps, brake posts and shaft
bolts for proper torque
25 25
Check air pressure * *
Remove lowers, clean/inspect
bushings and change oil bath
*50
Change oil in Motion Control System * *
Clean and lubricate Air U-Turn/Dual
Air/Air Assist assembly/Solo Air
**
Clean and lubricate coil spring or coil
U-Turn spring assembly
100 100
Clean and lubricate PopLoc cable and
housing
**
All 32mm XC
& All Mountain
Air Forks
SID Race, SL
& World Cup
Clean dirt and debris from upper tubes
E
E
E
Inspect upper tubes for scratches
E
E
E
Lubricate dust seals/tubes
10
10
10
Check top caps, brake posts and shaft
bolts for proper torque
25
25
25
Check air pressure
E
E
*
Remove lowers, clean/inspect
bushings and change oil bath
50
50
50
Change oil in Motion Control System
100
100
100
Clean and lubricate Air U-Turn/Dual
Air/Air Assist assembly/Solo Air
50
50
*
Clean and lubricate coil spring or coil
U-Turn spring assembly
*
*
100
Clean and lubricate PopLoc cable and
housing
50
50
50
Notes:
E = Every ride
Numeric values represent hours of riding time.
Increase service intervals based on rider weight, aggressive riding style/conditions, inclement weather and racing
E
25
*
25
Boxxer Ride.
Race & Team
E
E
50
50
*
*
All 32mm XC
& All Mountain
Coil Forks
E
25
E
25
Boxxer
World Cup
E
E
50
25
*
*
Loading...
