Squareled PQ818 User Manual

User Manual: PQ818

Manual | PQ818 | 1. Summarize

Summary

Thank you for purchasing our PQ818. Please read these instructions carefully
before begin and operate the xtures according to these instructions to avoid
any possible damages and accidents causes by misusage.

Product introduction

LED PQ818 light uses aluminum shell, designed in a fashion of hydrodyna­mic form. Appearance shows: long can, short can or short can with color
lter. It adopts high power 4-in-1 LED, which refers to single LED is made of
R,G,B,W LED, And long life span, low consumption, good color mixing eect
and high brightness are the most prominent features. Each kind of LED can
be independently dimmed. The built-in program includes dimming, strobe,
eotic, gradual change, fading and so on. It uses power switch, performs low
weight and consumption, stable capability and long life. International stan­dard DMX 512 signal is requested.

Packing List

» PQ818 1 PC
» DMX Signal Cable 1 Set
» Waterproof input power cable 1 PC
» User Manual
» Warranty Card

Manual | PQ818 | 2. Safety Information

Safety Notes

! Enquire the skilled people before any repair;
! Always make sure disconnect from the power source before setting up,

serving and moving;.
! Avoid direct eye exposure to the xture when it is on;

Safety instruction

» Make sure the power supply voltage are consistent with this lights，Ensure

the use of voltage is in the range of the request technical parameter.

» Before the installation, please check the light’s fasteners and mechanical

structure have been received in good condition and appear no damage.

» This light is designed for indoor use; working temperature is lower than 40

degree.

» The xtures maybe mounted in any position provided there is adequate

room for ventilation. Make sure there are no inammable and explosive
items (ornaments) in 0.5 meters away.

» Yellow / green cabling earthling safety; no icker when the xture is wor-

king on.

Manual | PQ818 | 3. Outside Size Picture

Manual | PQ818 | 4. Main Function

» high quality LED: low consumption, brightness, stable capability and long life
» each color of LED with 16666 dimming. RGB can make over 16.7 million colors,

adding W can achieve many eects.

» Liner dimming from 0-100%, strobe, gradual change, jumping change etc

eects

» DMX512 Controller: 4 button set DMX ID address with led display
» auto run /sound activated/master slave/interconnected multi-machine control
» using switching power supply to protect the LED to work well
» Built-in temperature control function: The output of LED will be reduced when

LED is too hot.

» lens degree: 15º 25º 45º optional
» Protection grade: IP65
» DMX Channel, Optional

Manual | PQ818 | 5. DMX Control Function

» DMX Channel (3CH)

Channel DMX Value Control Function Remark

1CH 0-255 RGB color mixing Hue

2CH 0-255 W Dimming 0-100% Color Saturation

3CH 0-255 General dimming 0-100% purity

Note: Chromaticity represents visible light, such as red, green, yellow, cyan etc.Color saturation refers to the proportion of
color chromaticity possession, 100% saturation means the color has reached the pure color. Purity value refers to the bright­ness, when purity reaches 100%, the color is the brightest.

» DMX Channel (4CH)

Channel DMX Value Control Function Remark

1CH 0-255 R 0-100%

2CH 0-255 G 0-100%

3CH 0-255 B 0-100%

4CH 0-255 W 0-100%

Manual | PQ818 | 5. DMX Control Function

» DMX Channel (5CH)

Channel DMX Value Control Function Remark

1CH 0-255 General dimming

2CH 0-255 R 0-100%

3CH 0-255 G 0-100%

4CH 0-255 B 0-100%

5CH 0-255 W 0-100%

»DMX Channel (8CH)

Channel DMX Value Control Function Remark Priority

1CH 0-255 (General dimming)

2CH 0-255 Red dimming 0——100%

3CH 0-255 Green dimming 0—100%

4CH 0-255 Blue dimming 0—100%

5CH 0-255 White 0——100%

6CH

7CH

8CH 0-255 Speed Adjustment (7CH)

9CH

0-14 Dimming

15-255 Strobe Speed

0-31 Invalid

32-63 From dark to bright Must use CH1,2,3,4,5CH,

64-95 From bright to dark

96-127 From dark—bright—dark

128-159 RGB Gradient

160-191 dark—bright—dark auto run

192-223 4 colors jumping change

224-255 Multi-colors jumping change

0-5

6-55

56-105
106-155
156-205
206-255

Set by LCD display

DIMMER0
DIMMER1
DIMMER2
DIMMER3
DIMMER4

When 7CH>31，this

function is invalid.

otherwise no light. From
the 8CH, start the speed

adjustment.

Speed adustment from

8CH

Manual | PQ818 | 6. Display Operation

» MENU : access the menu or return to a previous menu option
» ENTER: select the current menu option
» UP: menu selection or parameter increments
» DOWN: menu selection or parameters decrease

Manual | PQ818 | 7. Menu Instruction

Manual | PQ818 | 7. Menu Instruction

1. Operating instruction: MENU (UP/DOWN)+ENTER+(UP/DOWN)+ENTER

Remark: Exp: Select the DMX mode, Here are the operation details:

» Press the MENU, go back to the initial setting
» Press UP/DOWN, display “Addr”
» Press ENTER to change the content, the display will glinting at this moment
» Press UP/DOWN to change the address code to select d001
» Press ENTER to select and store the current menu options. DMX mode will be stored

automatically and the screen will stop glinting.

» Exp: Select DMX Channels optional mode, the operation is as below:
» Press MENU, go back to the initial setting
» Press UP/DOWN: display ”CHnd”
» Press ENTER to change the content, the display will glinting at this moment
» Press UP/DOWN to select the DMX channels that you need, 3CH，4CH，5CH and so on
» Press ENTER select and store the current menu options. DMX mode will be stored auto-

matically and the screen will stop glinting.

Exp: Close the display, the operation is as below:

» Press MENU, go back to the initial setting
» Press UP/DOWN, display “LED”
» Press ENTER to change the content, the display will glinting at this moment
» Press UP/DOWN to select “OFF”
» Press ENTER to conrm, the select the working mode that you need. When stop pressing,

the display will shut after a while. When the display is closed, press any button to acti­vate the display. If setting the led to “o”, when stop pressing, the display will shut after
a while.

Manual | PQ818 | 7. Menu Instruction

2.Details of program built inside(Pr- -): Press MENU, go back to the initial setting

Remark: Exp: Select the DMX mode, Here are the operation details:

» Press UP / DOWN until Pr--
» Press ENTER to choose, the display will glinting at this moment
» Press UP / DOWN to change the address code to select pr00
» Press ENTER to select and store the current menu options. DMX mode will be stored auto-

matically and the screen will stop glinting.

Remark: Pr14--- Pr30 Can change the content Of SP，correct the speed of jumping change
, SP00 is the fastest. SP15 is the slowest

» Pr00-Pr13: R,G,B.W single color or multi-colors lighting
» Pr14-Pr28: correspond with the Pr00-Pr13 add the strobe function.
» Pr29: 4 colors jumping.
» Pr30: there are kinds of colors jumping

Manual | PQ818 | 8. Operating Control Instruction

Master/Slave

Master: The master should always work as a master as long as it is not set in a DMX mode
whatever other modes it is. And it send out the signal so that the slave synchronous with
it. To avoid the host signal and DMX512 signals interfere with each other, should cut o
the DMX512 signals. The signal lines are longer than 60 meters (32 lamps) ,should incre­ase a signal amplier.

Slave: the Slave must be set in DMX mode and the address code should be A001, to assu­re receive the master’s signals correctly. Only one light can be set as a Master and others
are slaves.

Manual | PQ818 | 9. XLR cable connecting

XLR cable

The standard connection way of the XLR is: one end connect to the male plug ,and the
other connect to the female.As bellow:pin 1:ground,pin 2: negative signal,pin 3: positive

Noted: In order to avoid failures and interference signal transmission，we connect a
resistance 120Ω

The Conversion between 3 pin and 5 pin XLR
If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable

Manual | PQ818 | 10. Connecting picture:
Light connecting picture

Manual | PQ818 | 11. Trouble Shooting

Problem Checking way

Can not turn on the light

DMX can not control it

Display not bright

LED not light

Some of the LED not light

Check the power source plug is in normal or not
Check the switch of the lights is o or on
Check the fuse if in normal

Check the DMX cable is connect to the lights or not
Check the DMX512 controller work in normal or not
Check the DMX cable is normal or not
Check if the lights is in DMX mode(A001

When connect to the electricity, did the led ash one time? If so, the power source is
normal; If not, please check if the switch and the transformer has power out
Check if the power input of the IC board is normal
Check if the cable connect to the display loose
Change the main board to see if it is normal.
Chang the display

When connect to the electricity, did the led ash one time? If so, the power source is
normal; If not, please check if the switch and the transformer has power out
Check if the power input of the IC board is normal
Check if the cable connect to the display loose
Change the main board to see if it is normal.
Chang the display

LED is connect by leds in series rst, then connect parallel, so please check if the leds is
loose
Use the multimeter to check if the led is bright or not, of not, please change the led
check whether current limiting resistor is normal or not
Check constant current IC is normal or not (compared with the normal IC)

Single color leds always
bright/not bright

Noted: only professional persons can do as above

Check the switch of this color is normal or not
Change the IC control board

Manual | PQ818 | 12. Technical Specication

» Input voltage: AC 100V-264V/47-63HZ
» Output voltage:DC24V
» Consume:120W
» Lamp Type:4-in-1 LED
» Lamp Spec: High Power 8W 18PCS
» Constant current driver:500MA
» PWM Dimmer: >400HZ(16666 grades)
» Refresh rate:>400HZ
» Life span: 50000~100000hours
» Control Signal: DMX512, sound activated, auto run
» Control mode: stand alone/ sound activated
» Channel: 3CH 4CH 5CH 8CH 9CH
» Color eect:RGBW mixing
» Function Eect: dimmer, strobe, gradual change, sound activated
» Beam Angle: 25°,45°
» Cooling mode: Natural Convection
» Anti-electricity intension: 1.5KV
» Insulation Resistance: >MΩ
» Size: 284*193*254mm
