Product data sheet
Characteristics
ZBRRC
Programmable receiver - 4 PNP - 200 mA - 24 V
DC - 2 pusbuttons - 6 LEDs
Main
Range of product Harmony
Product or component type Programmable receiver
Device short name ZBRRC
Product specific application Interface to PLC
Function of module Monostable
Reset time 2 ms (time delay)
Transmission frequency 2405 MHz
Level or class 5M00G7W
Antenna type Omnidirectional
Complementary
Output type Transistor PNP
Output contacts 4 PNP
Time delay range 0.5 s (tolerance: - 15...15 %)
Maximum switching current 0.2 mA
[Us] rated supply voltage 24 V DC - 15...20 %
Voltage drop <= 2 V DC at 2 A
Communication port protocol Zigbee (green power) at 2.4 GHz conforming to IEEE 802.15.4
Maximum sensing distance 100 m (in free field)
25 m (transmitter in a plastic box type XAL D and receiver in a metal enclosure)
40 m (transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna)
Response time < 30 ms (after transmitter clicks)
Channels utilisation <= 32 per receiver
Utilisation category DC-13 conforming to EN/IEC 60947-5-1
Power consumption in VA 20 VA DC
Power consumption in W 20 W
Breaking capacity 4.8 W per output
Short-circuit protection 0.4 A fuse fast blow
Aug 18, 2017
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Operating position Any position without derating
Electrical connection 1 conductor cable 0.14...2.5 mm² - AWG 26...AWG 14 - solid - without cable end conforming to IEC
Tightening torque 0.5...1 N.m conforming to EN/IEC 60947-1
Housing material Self-extinguishing plastic
Status LED 1 LED, color: green for power ON
Rated short-duration power frequency
withstand voltage
[Uimp] rated impulse withstand voltage 0.8 kV
Surge withstand 0.5 kV (differential mode) conforming to IEC 61000-4-5
Rated power in W <= 1 mW
Number of channels 1
Modulation technique O-QPSK
Bandwidth 5 MHz
Antenna gain 0 dBi
Width 36 mm
Height 108 mm
Depth 75 mm
Product weight 0.13 kg
60947-1
2 conductors cable 0.14...1.5 mm² - AWG 26...AWG 16 - solid - without cable end conforming to IEC
60947-1
1 conductor cable 0.14...4 mm² - AWG 26...AWG 12 - flexible - with cable end conforming to IEC
60947-1
2 conductors cable 0.14...1.5 mm² - AWG 26...AWG 16 - flexible - with cable end conforming to IEC
60947-1
1 LED, color: green and yellow for reception signal
4 LEDs, color: green for relay ON
1 kV 50 Hz conforming to EN/IEC 60947-5-1
1 kV (common mode) conforming to IEC 61000-4-5
Environment
Standards EN/IEC 60947-5-1
Radio agreement RSS
Product certifications GOST
Marking CE
Ambient air temperature for storage -40...70 °C
Relative humidity 90 % at -20...55 °C without condensation conforming to ETSI EN 300 440-1
Vibration resistance +/- 7.5 mm (f= 5...14 Hz) conforming to IEC 60068-2-6
Shock resistance 10 gn (duration = 16 ms) 6000 shocks conforming to IEC 60068-2-27
IP degree of protection IP20 on casing conforming to IEC 60529
Pollution degree 2 conforming to IEC 60664-1
Overvoltage category III conforming to IEC 60664-1
Insulation resistance > 500 MOhm at 500 V DC conforming to NF C 20-030
[Ui] rated insulation voltage < 60 V conforming to IEC 60664-1
Electromagnetic compatibility Conducted RF disturbances (test level: 10 V) conforming to IEC 61000-4-6
SRRC
ICASA
ANATEL
ARIB T66
FCC
CCC
UL
CSA
C-Tick
2 gn (f= 8...150 Hz) conforming to IEC 60068-2-6
IP20 on terminals
Conducted emission conforming to EN 300-489-1
Immunity to microbreaks and voltage drops (test level: 7 ms) conforming to IEC 61000-4-11
Conducted and radiated emissions , class B conforming to CISPR 22
Electrostatic discharge immunity test (test level: 8 kV) in free air (in insulating parts) conforming to
IEC 61000-4-2
2
Electrostatic discharge immunity test (test level: 6 kV) on contact (on metal parts) conforming to IEC
61000-4-2
Susceptibility to electromagnetic fields (test level: 10 V/m) 80...2000 MHz conforming to IEC
61000-4-3
Susceptibility to electromagnetic fields (test level: 3 V/m) 80...2700 MHz, distance = 20 m conforming
to IEC 61000-4-3
Electrical fast transient/burst immunity test (test level: 2 kV) power supply wires conforming to IEC
61000-4-4
Radiated emission conforming to ETSI EN 300 440-1
Conducted emission conforming to ETSI EN 300 489-3
Radiated emission conforming to ETSI EN 300 440-2
Electrical fast transient/burst immunity test (test level: 1 kV) PNP output wires conforming to IEC
61000-4-4
1.2/50 µs shock waves immunity test (test level: 0.5 kV) differential mode conforming to IEC
61000-4-5
1.2/50 µs shock waves immunity test (test level: 1 kV) common mode conforming to IEC 61000-4-5
Immunity for industrial environments conforming to EN/IEC 61000-6-2
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 1113 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product environmental profile Available
End of life manual
Product end of life instructions Available
Contractual warranty
Warranty period 18 months
