red Ø40 Emergency stop, switching off head Ø22
trigger and latching turn release
Main
Range of productHarmony XB5
Product or component typeHead
Product destinationEmergency stop push-button
Device short nameZB5
Bezel materialPlastic
Mounting diameter22 mm
Sale per indivisible quantity1
Shape of signaling unit headRound
Type of operatorTrigger action and mechanical latching
ResetTurn to release
Operator profileRed mushroom Ø 40 mm unmarked
Complementary
CAD overall width40 mm
CAD overall height40 mm
CAD overall depth57 mm
Product weight0.046 kg
Mechanical durability300000 cycles
Station nameXALD 1 cut-out
Electrical composition codeC11 for <= 3 contacts using single blocks in front mounting
XALK 1 cut-out
C15 for 1 contacts using single blocks in front mounting
SF1 for <= 3 contacts using single blocks in front mounting
SR1 for <= 3 contacts using single blocks in rear mounting
C7 for <= 4 contacts using single blocks in front mounting
C8 for <= 4 contacts using single and double blocks in front mounting
C10 for <= 4 contacts using single and double blocks in front mounting
Jan 09, 2018
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Environment
Protective treatmentTH
Ambient air temperature for storage-40...70 °C
Ambient air temperature for operation-40...70 °C
Overvoltage categoryClass II conforming to IEC 60536
IP degree of protectionIP69
NEMA degree of protectionNEMA 13
Resistance to high pressure washer7000000 Pa at 55 °C,distance: 0.1 m
IK degree of protectionIK03 conforming to IEC 50102
StandardsEN/IEC 60204-1
Product certificationsBV
Vibration resistance5 gn (f = 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
IP67
IP66 conforming to IEC 60529
IP69K
NEMA 4X
EN/IEC 60947-1
EN/IEC 60947-5-1
EN/IEC 60947-5-4
EN/IEC 60947-5-5
EN/ISO 13850
IEC 60364-5-53
JIS C 4520
UL 508
GB 14048.5
CSA C22.2 No 14
CSA
DNV
GL
LROS (Lloyds register of shipping)
RINA
UL listed
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Offer Sustainability
Sustainable offer statusGreen Premium product
RoHS (date code: YYWW)Compliant - since 0810 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REAChReference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product environmental profileAvailable
Product environmental
Product end of life instructionsNeed no specific recycling operations
Contractual warranty
Warranty period18 months
2
Product data sheet
Dimensions Drawings
Dimensions
ZB5AS844
3
Product data sheet
ZB5AS844
Mounting and Clearance
Panel Cut-out for Pushbuttons, Switches and Pilot Lights (Finished Holes, Ready for Installation)
Connection by Screw Clamp Terminals or Plug-in Connectors or on Printed Circuit Board
(1)Diameter on finished panel or support
(2)For selector switches and Emergency stop buttons, use of an anti-rotation plate type ZB5AZ902 is recommended.
(3)
Ø22.5mm recommended (Ø22.3 0
+0.4
) / Ø0.89in. recommended (Ø0.88in. 0
+0 016
)
Connectionsa in mma in in.b in mmb in in.
By screw clamp terminals or plug-in connector401.57301.18
By Faston connectors451.77321.26
On printed circuit board301.18301.18
Detail of Lug Recess
(1)Diameter on finished panel or support
(2)For selector switches and Emergency stop buttons, use of an anti-rotation plate type ZB5AZ902 is recommended.
(3)
Ø22.5mm recommended (Ø22.3 0
+0.4
) / Ø0.89in. recommended (Ø0.88in. 0
+0 016
)
4
Product data sheet
ZB5AS844
Mounting and Clearance
Pushbuttons, Switches and Pilot Lights for Printed Circuit Board Connection
Panel Cut-outs (Viewed from Installer’s Side)
A:30mm min. / 1.18in. min.
B:40mm min. / 1.57in. min.
Printed Circuit Board Cut-outs (Viewed from Electrical Block Side)
Dimensions in mm
A:30mm min.
B:40mm min.
5
Dimensions in in.
A:1.18in. min.
B:1.57in. min.
General Tolerances of the Panel and Printed Circuit Board
The cumulative tolerance must not exceed 0.3mm / 0.012in.: T1 + T2 = 0.3mm max.
Installation Precautions
● Minimum thickness of circuit board: 1.6mm / 0.06in.
