Product data sheet
Characteristics
XVR08B06
84mm Rotating Mirror Blue 24VAC-DC
Main
Range of product Harmony XVR
Product or component type Prewired rotating mirror beacon
Sound signalling Without
Device short name XVR
Mounting diameter 84 mm
IP degree of protection IP23 conforming to IEC 60529
[Us] rated supply voltage 24 V AC/DC
Light source High luminosity LED, blue
IP65 (with accessory) conforming to IEC 60529
Complementary
Material ABS (acrylonitrile butadiene-styrene) (body part)
CAD overall width 84 mm
CAD overall depth 84 mm
Product weight 0.3 kg
Marking CE
Product mounting By 3 M4 screws
Supply voltage limits 21.6...26.4 V AC
[Uimp] rated impulse withstand voltage 0.8 kV
Current consumption 125 mA
Flashing frequency 2.3 Hz
Clamping connection capacity 0.83 mm²
AWG gauge AWG 18
Cable length 500 mm
PC (globe)
19...30 V DC
Environment
Standards EN 61000-6-2
Oct 17, 2017
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
EN 61000-6-4
Product certifications UL
Protective treatment TC
Ambient air temperature for storage -35...70 °C
Ambient air temperature for operation -10...50 °C
Electrical shock protection class Class II conforming to IEC 61140
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 0808 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product environmental profile Available
Product end of life instructions Available
Contractual warranty
Warranty period 18 months
