Product data sheet
Characteristics
XVLA133
pilot light Ø8 - IP40 - green - protruding LED
included - 24V - faston
Main
Range of product Harmony XVL
Product or component type LED pilot light with black bezel
Component name XVL
Mounting diameter 8 mm
Light source Protruding LED
Light block colour Green
Protection type Integral ballast resistor
[Us] rated supply voltage 24 V
IP degree of protection IP40 conforming to IEC 60529
Built-in by diode
IP40 conforming to NF C 20-010
Complementary
Supply circuit type DC
Connections - terminals Tag for Faston connectors : 2.8 x 0.5 mm
Current consumption 18 mA
[Ui] rated insulation voltage 50 V conforming to IEC 60947-1
Bulb lifespan >= 100000 h
Nominal voltage limit 0.8...1.1 Un
Terminals description ISO n°1 (X1-X2)PL
Height 12 mm
Width 12 mm
Depth 34 mm
Product weight 0.003 kg
Tag for soldering connectors
Environment
Product certifications CSA
Mar 06, 2017
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
UL
Protective treatment TC
Ambient air temperature for operation -25...70 °C
Ambient air temperature for storage -40...70 °C
Overvoltage category Class 3 conforming to IEC 60536
Class 3 conforming to NF C 20-030
Contractual warranty
Warranty period 18 months
