Product data sheet
Characteristics
XS630B1NAM12
inductive sensor XS6 M30 - L74mm - brass Sn15mm - 12..48VDC - M12
Main
Range of product OsiSense XS
Series name General purpose
Sensor type Inductive proximity sensor
Device application Mobile equipment
Sensor name XS6
Sensor design Cylindrical M30
Size 74 mm
Body type Fixed
Detector flush mounting acceptance Flush mountable
Material Metal
Type of output signal Discrete
Wiring technique 3-wire
[Sn] nominal sensing distance 15 mm
Discrete output function 1 NO
Output circuit type DC
Discrete output type NPN
Electrical connection Male connector M12 4 pins
[Us] rated supply voltage 12...48 V DC with reverse polarity protection
Switching capacity in mA <= 200 mA DC with overload and short-circuit protection
IP degree of protection IP67 conforming to IEC 60529
IP69K conforming to DIN 40050
Complementary
Thread type M30 x 1.5
Detection face Frontal
Front material PPS
Enclosure material Nickel plated brass
Nov 06, 2017
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Operating zone 0...12 mm
Differential travel 1...15% of Sr
Status LED 1 LED (yellow) for output state
Supply voltage limits 10...58 V DC
Switching frequency <= 500 Hz
Voltage drop <= 2 V, closed state
Current consumption <= 10 mA (no-load)
Delay first up <= 10 ms
Delay response <= 0.6 ms
Delay recovery <= 1.4 ms
Marking CE
Threaded length 52 mm
Length 74 mm
Product weight 0.15 kg
Environment
Product certifications UL
Ambient air temperature for operation -25...70 °C
Ambient air temperature for storage -40...85 °C
Vibration resistance 25 gn, amplitude: +/- 2 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
Shock resistance 50 gn (duration = 11 ms) conforming to IEC 60068-2-27
E2
CSA
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 0804 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product environmental profile Available
Product environmental
Product end of life instructions Available
End of life manual
Contractual warranty
Warranty period 18 months
