Wire insulation material PvR
Status LED 1 LED (yellow) output state
Supply voltage limits 10...36 V DC
Switching frequency <= 5000 Hz
Voltage drop <= 2 V (closed
Current consumption <= 10 mA (no-load)
Delay first up <= 10 ms
Delay response <= 0.1 ms
Delay recovery <= 0.1 ms
Marking CE
Threaded length 1.02 in (26 mm)
Height 0.31 in (8 mm)
Length 1.3 in (33 mm)
Product weight 0.06 lb(US) (0.025 kg)
Environment
Product certifications CSA
Ambient air temperature for operation -13...158 °F (-25...70 °C)
Ambient air temperature for storage -40...185 °F (-40...85 °C)
Vibration resistance 25 gn, amplitude: +/- 2 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
Shock resistance 50 gn (duration = 11 ms) conforming to IEC 60068-2-27
UL
Ecolab
Ordering and shipping details
Category 22486 - SENSORS, PROXIMITY
Discount Schedule DS2
GTIN 00785901912828
Nbr. of units in pkg. 1
Package weight(Lbs) 0.12
Returnability N
Country of origin FR
Offer Sustainability
RoHS (date code: YYWW) Compliant - since 1010 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
Product environmental profile Available
Product end of life instructions Available
California proposition 65 WARNING: This product can expose you to chemicals including:
- - - - - - - Substance 1 Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
- - - - - - - Substance 2 Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
- - - - - - - More information For more information go to www.p65warnings.ca.gov
reproductive harm.
Contractual warranty
Warranty period 18 months
2
